Mitsubishi Outlander PHEV (2019 year). Instruction

/SEL key

(counter-

clockwise)

Reduces the frequency being
received.

/SEL key

(clockwise)

Increases the frequency be-
ing received.

key

(hold down)

Release the button to start
seek station selection, and
when a station is received,
scanning stops.

key

(hold down)

Preset Memory

1. Tune in to the frequency to register.
2. Hold down any of the keys from the

1RPT key to the 6

key.

A “Beep” sounds, and the preset key is
registered.

NOTE

The preset memory can register a maximum
of 6 stations for each band (FM1, FM2,
FM3).

If a preset key that already has a station reg-
istered is selected, then this is overwritten
with the new preset.

NOTE

Pressing the preset key will select the previ-
ously registered frequency.

Auto Memory (Auto Store)

The top 6 stations with a strong signal can be
automatically registered in order with preset
keys.
Hold down the RADIO key.

After completion of auto store operations, the
product will receive the station registered in
the preset key [1].

CAUTION

Please be aware that the formerly-registered
frequency in the memory will be overwrit-
ten.

NOTE

Using auto store for FM1 and FM2 switches
to FM3.

PTY Search

Select PTY (program content), and automati-
cally scan for stations.

1. During FM reception, press the PTY/

SCAN key.
This switches to the PTY selection
mode.

2. Turn the /SEL key to select PTY.

The  PTY  (program  content)  indicator
will  flash,  and  station  selection  will  au-
tomatically  start.  When  a  station  is  re-
ceived, the station name is displayed.

NOTE

This receives the station detected first.

10 seconds after reception, PTY search
mode will be cancelled.

Listen to DAB*

E00739100014

This explains how to listen to DAB.

To listen to DAB

1. Press the RADIO key to switch the

band.
Switch between DAB1, DAB2, and
DAB3 bands.
The selected band is indicated on the
display.

Listen to DAB*

8-29

OGGE19E1

For pleasant driving

NOTE

This switches in the order FM1, FM2, FM3,
DAB1, DAB2, DAB3, MW, and LW.

Select a Service

1. Hold down the

key or the

key.

Receives the lead services of the ensem-
bles that can be received.

2. Press the

key or the

key to select

the service.

key

(hold down)

Automatically receives low-
er lead services within en-
sembles that can be received.

key

(hold down)

Automatically receives high-
er lead services within en-
sembles that can be received.

key

Switches to lower services.

key

Switches to higher services.

NOTE

Going to the first service or last service
within the ensemble switches to the next en-
semble.

Register the Service

1. Tune in to the service to register.
2. Hold down any of the keys from the

1RPT key to the 6

key.

A “Beep” sounds, and the preset key is
registered.

NOTE

If a preset key that already has a service reg-
istered is selected, then this is overwritten
with the new preset.

Pressing the preset key will select the previ-
ously registered service.

Search for a Service

Search for ensembles and services that can be
received.

1. Turn the

/SEL key to select the en-

semble.

2. Press the /SEL key.

The service name within the selected en-
semble is displayed.

3. Turn the

/SEL key to select the serv-

ice.

4. Press the /SEL key.

Receive the selected service.

NOTE

If the text information for the service name
cannot be obtained, then nothing is dis-
played.

If there is no operation for 10 seconds, then
service search mode will be cancelled.

PTY Search

Select PTY (program content), and automati-
cally scan for services.

1. Press the PTY/SCAN key.

This switches to the PTY selection
mode.

2. Turn the /SEL key to select PTY.
3. Press the

key or

key.

This starts PTY search.

key

Lower PTY search starts.

key

Higher PTY search starts.

NOTE

When selecting PTY, press any of the keys
from the 1RPT key to the 6

key to

switch to the PTY registered as a preset.

When selecting PTY, select the PTY to reg-
ister, and hold down any of the keys from
the 1RPT key to the 6

key to register the

PTY as a preset.

Listen to DAB*

8-30

OGGE19E1

For pleasant driving

NOTE

While in PTY select status, if there is no op-
eration for 2 seconds, then an upwards
search within the selected PTY will start.

Listen to Traffic Messages

E00739200015

This explains how to listen to traffic messag-
es.

To Listen to Traffic Messages

1. When not in MW or LW mode, press the

TP key.
If traffic messages are being broadcast,
these are received.

CAUTION

When receiving a MW or LW signal, traffic
messages cannot be received.

NOTE

Receiving traffic messages will indicate
“TRAF INF” on the display, and if text in-
formation can be received, the station name
is displayed.

NOTE

If  traffic  messages  are  received,  then  this
will  switch  to  the  volume  of  the  previously
received  traffic  messages  or  emergency
broadcasts. The volume when receiving traf-
fic messages or emergency broadcasts is that
at  which  subsequent  broadcasts  will  be  re-
ceived.

Traffic Message Standby Mode

When the broadcast of traffic messages starts,
this automatically switches to the station that
is broadcasting traffic messages.

1. When not in MW or LW mode, press the

TP key.
“TP” is indicated on the display, and the
product switches to standby mode.
If traffic messages are being broadcast,
these are received.

2. When not in MW or LW mode, press the

TP key.
“TP” disappears from the display, and
standby mode will be cancelled.

CAUTION

When receiving a MW or LW signal, traffic
message standby mode will be cancelled.

Listen to CDs

E00737800059

This explains how to listen to audio CDs
(CD-DA/CD-TEXT).

Play CDs

Insert the disc.

Insert  a  disc  to  automatically  start  playback.
→ “Insert/Eject Discs” on page 8-26
If  a  disc  is  already  within  the  product,  press
the  MEDIA  key  to  switch  to  CD  as  the
source.

Select the Track

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the 3

key or the 4

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback, random playback, and scan
playback are possible.

Listen to Traffic Messages

8-31

OGGE19E1

For pleasant driving

Repeat Playback (RPT)

Press the 1RPT key.

Repeat playback of the track currently being
played.

NOTE

Pressing again will cancel.

Selecting a track, ejecting, fast forwarding,
or rewinding will cancel.

Random Playback (RDM)

Press the 2RDM key.

Play the tracks on the disc in a random order.

NOTE

Pressing again will cancel.

Ejecting will cancel this.

Scan Playback (SCAN)

Press the PTY/SCAN key.

Play the first 10 seconds of each of the tracks
on the whole disc in order.

NOTE

Press this button again during playback if
you wish to hear that track, and that track
will play normally.

Listen to MP3s

E00737900034

This explains how to listen to audio files on a
disc.

CAUTION

CD-ROM and CD-R/RW media can only
play back MP3 format audio files.

To Listen to MP3s

NOTE

Depending on the file structure, it may take
some time to read the contents of the disc.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the 3

key or the 4

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback, random playback, and scan
playback are possible.

Repeat Playback (RPT)

Press the 1RPT key.

Repeat playback of the track currently being
played.

NOTE

Pressing again will cancel.

Selecting a file, ejecting, fast forwarding, or
rewinding will cancel.

Listen to MP3s

8-32

OGGE19E1

For pleasant driving

Folder Repeat Playback

Hold down the 1RPT key.

Repeat playback of the tracks within the fold-
er currently being played.

NOTE

Pressing again will cancel.

Even if the file is selected, folder repeat
playback will not be cancelled.

Random Playback (RDM)

Press the 2RDM key.

Play the tracks in the folder in a random or-
der.

NOTE

Pressing again will cancel.

Folder Random Playback

Hold down the 2RDM key.

Play all tracks in folders on the disc in a ran-
dom order.

NOTE

Pressing again will cancel.

Scan Playback (SCAN)

Press the SCAN key.

Play the first 10 seconds of each of the tracks
in the folder currently being played in order.

Search Tracks

Search folders and files, and select a track.

1. Turn the /SEL key to select the folder.
2. Press the /SEL key.

Files within the selected folder are dis-
played.

3. Turn the /SEL key to select the file.
4. Press the /SEL key.

This plays the selected file (track).

NOTE

While the folder is selected, press the 6
key to cancel track search mode.

If there is no operation for 10 seconds after
selecting the folder, then track search mode
will be cancelled.

NOTE

Select the folder, and hold down the

/SEL

key to start playback from the first track in
that folder.

While the file is selected, press the 6

key

to return to the previous operation.

While the file is selected, hold down the 6

key to cancel track search mode.

If there is no operation for five seconds after
selecting the file, that file is played back.

Disc operations such as selecting a track will
cancel track search mode.

Listen to an iPod

E00738001202

By connecting commercially-available iPod/
iPhone devices to this product, you can play
back tracks on these through the product.

CAUTION

Do not leave the iPod/iPhone unattended in
the vehicle.

Never hold these devices in your hand to op-
erate while driving, as this is dangerous.

No indemnification for data loss resulting
when the iPod/iPhone is connected to the
product will be possible.

Depending on how the devices are handled,
audio files being damaged or lost, therefore
it is recommended that data be backed up.

Listen to an iPod

8-33

OGGE19E1

For pleasant driving

NOTE

Depending on the generation, model, or soft-
ware  version  of  the  iPod/iPhone,  playback
on  this  product  may  not  be  possible.
(→8-16)  Additionally,  playback  as  ex-
plained  in  this  document  may  not  be  possi-
ble.

For vehicles with a Bluetooth

2.0 interface,

the  types  of  devices  that  can  be  connected
may vary.
For  details,  access  the  MITSUBISHI
MOTORS website.
Please read and agree to the “Warning about
Links  to  the  Web  Sites  of  Other  Compa-
nies”.  The  websites  mentioned  above  may
connect  you  to  websites  other  than  the
MITSUBISHI MOTORS website.
http://www.mitsubishi-motors.com/en/prod-
ucts/index.html

Usage of iPod/iPhone hardware with the lat-
est software version is recommended.

Regarding how to connect the iPod/iPhone,
refer to “How to connect an iPod” on page
8-72.

When connecting the iPod/iPhone, use a
commercially available iPod connection ca-
ble.

Set up the device in order that no unsafe ac-
tions, such as plugging in the connection ca-
ble are taken while driving.

When inserting and removing the iPod/
iPhone, for safety’s sake first stop the vehi-
cle.

Depending on the status of the iPod/iPhone,
it may take some time until the device is rec-
ognized, or playback starts.

NOTE

Depending on the iPod/iPhone, the button
functions on the product may not operate
while the iPod/iPhone is connected.

iPod/iPhone specifications and settings may
mean that connection is not possible, or re-
sult in differences in operation or display.

Depending on audio data in the iPod/iPhone,
track information may not be displayed cor-
rectly.

Depending on the status of the vehicle and
device, the iPod/iPhone may not play back
after starting the Plug-in Hybrid EV system.

Data containing copyright information may
not play back.

It is recommended that the iPod/iPhone
equaliser settings be set to flat.

Operate the iPod/iPhone while connected to
this product.

If  the  iPod/iPhone  is  connected  via  Blue-
tooth  as  a  Bluetooth-  capable  audio  device,
then  do  not  connect  the  iPod/iPhone  using
an iPod cable. Connection using both meth-
ods will result in erroneous operation.

If an iPod/iPhone does not operate correctly,
then remove the iPod/iPhone from the prod-
uct, reset, then reconnect.

Play iPod

Press the MEDIA key to set the iPod as the
source.

The selected source is indicated on the dis-
play.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the 3

key or the 4

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback and shuffle playback are
possible.

Repeat Playback (RPT)

Press the 1RPT key.

Repeat playback of the track currently being
played.

NOTE

Pressing again will cancel.

Shuffle Playback (RDM)

Press the 2RDM key.

Listen to an iPod

8-34

OGGE19E1

For pleasant driving

Play tracks in the category currently being
played in a random order.

NOTE

Pressing again will cancel.

Album Shuffle Playback

Hold down the 2RDM key.

Play back the album in a random order
(tracks in any order on the album).

NOTE

Pressing again will cancel.

Search Tracks

Search categories or track names, and select a
track.

1. Turn the /SEL key to select the cate-

gory.

2. Press the

/SEL key. Categories or

tracks within the selected category are
displayed.

3. Turn the /SEL key to select the cate-

gory or track.

4. Press the /SEL key.

Repeat steps 1 to 4, and search for
tracks.
Select the track, and press the

/SEL

key to play.

NOTE

While the category (1

level) is selected,

press the 6

key to cancel track search

mode.

If there is no operation for 10 seconds after
selecting the category, then track search
mode will be cancelled.

Select the category, and hold down the

/SEL key to start playback from the first

track in that category.

While the track is selected, press the 6
key to return to the previous operation.

While the track is selected, hold down the 6

key to cancel track search mode.

If there is no operation for five seconds after
selecting the track, that file is played back.

iPod operations such as selecting a track will
cancel track search mode.

Listen to Audio Files on a
USB Device

E00736501261

By connecting commercially-available USB
devices such as USB memory to this product,
you can play back audio files on these
through the product.

CAUTION

Do not leave the USB device unattended in
the vehicle.

Never hold these devices in your hand to op-
erate while driving, as this is dangerous.

Do not use hard discs, card readers, or mem-
ory readers, as damage may occur to these or
to the data contained therein. If these are er-
roneously connected, put the operation mode
of the power switch in OFF and then remove
them.

Because of the risk of data loss, it is recom-
mended that files be backed up.

No guarantee is made as regards damage to
the USB device, nor regarding loss or dam-
age to data contained therein.

Depending on how the devices are handled,
audio files being damaged or lost, therefore
it is recommended that data be backed up.

NOTE

Digital audio players that support the mass
storage class specifications can be connec-
ted.

For details regarding the types of USB devi-
ces that can be connected and the types of
files that can be played back in vehicles with
a Bluetooth

2.0 interface, refer to “Types of

connectable devices and supported file spec-
ifications” on page 8-72.

Regarding how to connect USB devices, re-
fer to “How to connect a USB memory de-
vice” on page 8-72.

Listen to Audio Files on a USB Device

8-35

OGGE19E1

For pleasant driving

NOTE

When connecting a USB device, use a con-
nection cable. Failure to use a connection ca-
ble when connecting may place undue load
on, or damage the USB connector.

Set up the device in order that no unsafe ac-
tions, such as plugging in the connection ca-
ble are taken while driving.

When inserting and removing the USB de-
vice, for safety’s sake first stop the vehicle.

Do not insert other than audio devices into
the USB port. Damage to the device or
equipment may result.

Depending on the status of the USB device,
it may take some time until the device is rec-
ognized, or playback starts.

Depending on the USB device, the button
functions on the product may not operate
while the USB device is connected.

USB device specifications and settings may
mean that connection is not possible, or re-
sult in differences in operation or display.

Depending on audio data in the USB device,
track information may not be displayed cor-
rectly.

Depending on the status of the vehicle and
device, the iPod/iPhone may not play back
after starting the Plug-in Hybrid EV system.

Data containing copyright information may
not play back.

This product can play back MP3, WMA, and
AAC format audio files.

Depending on the type of USB device, usage
may not be possible, or functions that can be
used may be restricted.

NOTE

The recommended file system for USB
memory is FAT32.

The maximum supported capacity for USB
memory is 32GB.

Operate the USB device containing recorded
audio files while connected to this product.

Play Back of Audio Files on a

USB Device

Press the MEDIA key to set

USB as the source. The selected source is in-
dicated on the display.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the 3

key or the 4

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback, random playback, and scan
playback are possible.

Repeat Playback (RPT)

Press the 1RPT key.

Repeat playback of the track currently being
played.

NOTE

Pressing again will cancel.

Selecting a file will cancel this.

Folder Repeat Playback

Hold down the 1RPT key.

Repeat playback of the tracks within the fold-
er currently being played.

NOTE

Pressing again will cancel.

Even if the file is selected, folder repeat
playback will not be cancelled.

Folder

Random

Playback

(RDM)

Press the 2RDM key.

Listen to Audio Files on a USB Device

8-36

OGGE19E1

For pleasant driving

Play tracks in the folder currently being
played in a random order.

NOTE

Pressing again will cancel.

Even if the file is selected, folder random
playback will not be cancelled.

All Folder Random Playback

Hold down the 2RDM key.

Play the tracks in all folders in a random or-
der.

NOTE

Pressing again will cancel.

Even if the file is selected, all folder random
playback will not be cancelled.

Scan Playback (SCAN)

Press the PTY/SCAN key.

Play the first 10 seconds of each of the tracks
on the whole USB device in order.

NOTE

Press this button again during playback if
you wish to hear that track, and that track
will play normally.

Folder Scan Playback

Hold down the PTY/SCAN key.

Play the first 10 seconds of the first track in
each folder on the USB device in order.

NOTE

Press this button again during playback if
you wish to hear that track, and that track
will play normally.

Search Tracks

Search folders and files, and select a track.

1. Turn the /SEL key to select the folder.
2. Press the /SEL key.

Files within the selected folder are dis-
played.

3. Turn the /SEL key to select the file.
4. Press the /SEL key.

This plays the selected file (track).

NOTE

While the folder is selected, press the 6
key to cancel track search mode.

If there is no operation for 10 seconds after
selecting the folder, then track search mode
will be cancelled.

Select the folder, and hold down the

/SEL

key to start playback from the first track in
that folder.

While the file is selected, press the 6

key

to return to the previous operation.

While the file is selected, hold down the 6

key to cancel track search mode.

If there is no operation for five seconds after
selecting the file, that file is played back.

Operations such as selecting a track will
cancel track search mode.

To play iPod/USB memory
device tracks via voice
operation (vehicles with
Bluetooth

2.0 interface)

E00748700029

Desired tracks on the iPod/USB memory de-
vice which is connected to the USB input ter-
minal  can  be  selected  and  played  via  voice
operation.
For  information  concerning  the  voice  recog-
nition  function  or  speaker  registration  func-
tion,  refer  to  “Bluetooth

2.0 interface” on

page 8-51.

To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth

2.0 interface)

8-37

OGGE19E1

For pleasant driving

The following explains how to prepare for
voice operation and play the tracks.

Preparation for voice operation

E00748800059

To use the voice operation, press the
SPEECH button (A) first.

To search by artist name

E00748900021

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Artist”.

NOTE

If you say “Artist <name>,” you can skip
step 3.

3. After the voice guide says “What Artist

would you like to play?,” say the artist
name.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice guide will say “More than one
match was found, would you like to play
<artist name>?” If you say “Yes,” the
system proceeds to step 6.
If you say “No,” the next matching artist
is uttered by the system.

NOTE

If you say “No” to three or all artist names
uttered by the system, the voice guide will
say “Artist not found, please try again” and
the system returns to step 2.

Search time is dependant on the number of
songs on your connected device. Devices
containing a large number of songs may take
longer to return search results.

6. After the voice guide says “Playing <ar-

tist name>,” the system creates a playlist
index for the artist.

NOTE

If  the  confirmation  function  is  active,  the
voice  guide  confirms  if  the  artist  name  is
correct.  If  the  artist  name  is  correct,  say
“Yes”.  If  not,  say  “No”.  After  the  voice
guide  says  “Artist  not  found,  please  try
again,” the system returns to step 2.

7. The system exits the voice recognition

mode and starts playback.

To search by album title

E00749000029

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Album”.

To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth

2.0 interface)

8-38

OGGE19E1

For pleasant driving

NOTE

If you say “Album <title>,” you can skip
step 3.

3. After the voice guide says “What Album

would you like to play?” say the album
title.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice  guide  will  say  “More  than  one
match was found, would you like to play
<album  title>?”  If  you  say  “Yes,”  the
system proceeds to step 6.
If  you  say  “No,”  the  next  matching  al-
bum is uttered by the system.

NOTE

If you say “No” to three or all album titles
uttered by the system, the voice guide will
say “Album not found, please try again” and
the system returns to step 2.

6. After the voice guide says “Playing <al-

bum title>,” the system creates a playlist
index for the album title.

NOTE

If  the  confirmation  function  is  active,  the
voice  guide  confirms  if  the  album  title  is
correct.  If  the  album  title  is  correct,  say
“Yes”.  If  not,  say  “No”.  After  the  voice
guide  says  “Album  not  found,  please  try
again,” the system returns to step 2.

7. The system exits the voice recognition

mode and starts playback.

To search by playlist

E00749100020

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Playlist”.

NOTE

If you say “Playlist <playlist>,” you can skip
step 3.
If the device has no playlist, the voice guide
will say “There are no playlists stored on de-
vice” and the system returns to step 2.

3. After the voice guide says “What Play-

list would you like to play?,” say the
playlist name.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice guide will say “More than one
match was found, would you like to play
<playlist>?” If you say “Yes,” the sys-
tem proceeds to step 6.
If you say “No,” the next matching play-
list name is uttered by the system.

NOTE

If you say “No” to three or all playlist names
uttered by the system, the voice guide will
say “Playlist not found, please try again” and
the system returns to step 2.

6. After the voice guide says “Playing

<playlist>,” the system creates an index
for the playlist.

To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth

2.0 interface)

8-39

OGGE19E1

For pleasant driving

NOTE

If  the  confirmation  function  is  active,  the
voice guide confirms if the playlist name is
correct.  If  the  playlist  name  is  correct,  say
“Yes”.  If  not,  say  “No”.  After  the  voice
guide  says  “Playlist  not  found,  please  try
again,” the system returns to step 2. Refer to
“Confirmation  function  setting”  on  page
8-54.

7. The system exits the voice recognition

mode and starts playback.

To search by genre

E00749200021

1. Say “Play” on the main menu.

NOTE

The Bluetooth

(R)

2.0 interface starts recog-

nizing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Blue-
tooth

(R)

2.0 interface starts an appropriate

voice guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Genre”.

NOTE

If you say “Genre <type>,” you can skip
step 3.

3. After the voice guide says “What Genre

would you like to play?,” say the music
type.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice guide will say “More than one
match was found, would you like to play
<genre>?” If you say “Yes,” the system
proceeds to step 6.
If you say “No,” the next matching
genre is uttered by the system.

NOTE

If you say “No” to three or all genres uttered
by the system, the voice guide will say
“Genre not found, please try again” and the
system returns to step 2.

6. After the voice guide says “Playing

<genre>,” the system creates an index
for the genre.

NOTE

If  the  confirmation  function  is  active,  the
voice guide confirms if the genre is correct.
If the genre is correct, say “Yes”. If not, say
“No”. After the voice guide says “Genre not
found,  please  try  again,”  the  system  returns
to  step  2.  Refer  to  “Confirmation  function
setting” on page 8-54.

7. The system exits the voice recognition

mode and starts playback.

Listen to Bluetooth Audio*

E00736701234

This product can play back tracks on com-
mercially-available Bluetooth-capable audio
devices.

CAUTION

Never hold these devices in your hand to op-
erate while driving, as this is dangerous.

Do not leave the Bluetooth audio device un-
attended in the vehicle.

Depending on how the devices are handled,
audio files being damaged or lost, therefore
it is recommended that data be backed up.

Listen to Bluetooth Audio*

8-40

OGGE19E1

For pleasant driving

NOTE

Depending on the type of Bluetooth-capable
audio devices, usage may not be possible, or
functions that can be used may be restricted.

Confirm together with the user manuals for
the commercially- available Bluetooth-capa-
ble audio devices.

Depending on the type of Bluetooth-capable
audio devices, volume levels may differ.
There is the danger of loud volumes, so prior
to use, it is recommended that you turn the
volume down.
→ “Adjust Volume” on page 8-26

Depending on the status of the Bluetooth au-
dio device, it may take some time until the
device is recognized, or playback starts.

Bluetooth audio device specifications and
settings may mean that connection is not
possible, or result in differences in operation
or display.

Depending on audio data in the Bluetooth
audio device, track information may not be
displayed correctly.

Depending on the status of the vehicle and
device, the iPod/iPhone may not play back
after starting the Plug-in Hybrid EV system.

Connect a Bluetooth-capable

Audio Device

Regarding how to connect your Bluetooth de-
vice, refer to “Connecting the Bluetooth® 2.0
interface and Bluetooth® device” on page
8-57.

Operation methods below describe situations
once connection has been completed.

NOTE

If  the  iPod/iPhone  is  connected  via  Blue-
tooth  as  a  Bluetooth-capable  audio  device,
then  do  not  connect  the  iPod/iPhone  using
an iPod connection cable. Connection using
both methods will result in erroneous opera-
tion.

Play Bluetooth Audio

1. Press the MEDIA key to set Bluetooth

Audio as the source.

The selected source is indicated on the
display.

2. Press the 5

key. Bluetooth Audio

playback starts.

NOTE

Hold down the 5

key to pause.

Press the 6

key to stop.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the 3

key or the 4

key.

Fast forward/rewind is possible.

Switch Playback Mode

Repeat playback, random playback, and scan
playback are possible.

Repeat Playback (RPT)

Press the 1RPT key.

Repeat playback of the track currently being
played.

NOTE

Each time the 1RPT key is pressed, this
switches in the order Repeat OFF, 1 track re-
peat, All track repeat, and Repeat OFF.

Random Playback (RDM)

Press the 2RDM key.

Play the tracks in the Bluetooth Audio device
in a random order.

Listen to Bluetooth Audio*

8-41

OGGE19E1

For pleasant driving

Display Indicator

E00738100033

This explains content of the display indicator.

Change the Display Mode

E00738501177

You can change the content of the display in-
dicator.
Press the DISP key to switch the display con-
tent.

Each time the DISP key is pressed, the dis-
play content changes.

CAUTION

The operation of changing display contents
may impede safe driving, therefore check
safety before operation.

NOTE

Up to 11 characters may be displayed at one
time. To display 12 or more characters, press
the PAGE key, and subsequent characters
will be displayed.

During DAB Reception*

This switches in the order “Service name”,
“Ensemble name”, and “CH no. (CH ID)”.

NOTE

If the text information for the service name
and ensemble name cannot be obtained, then
nothing is displayed.

Display Indicator

8-43

OGGE19E1

For pleasant driving

During CD-DA playback

This switches in the order “Disc title”, “Track
title”, and “Operating status”.

NOTE

If there is no text information to display,
then “NO TITLE” is displayed.

During MP3/WMA/AAC Play-

back

This switches in the order “Folder title”,
“File title”, and “Operating status”.

NOTE

If there is no text information to display,
then “NO TITLE” is displayed.

Display the ID3tag

Hold down the DISP key.

This switches the ID3tag display.
[DISP] Each time the key is pressed, this
switches in the order “Album name”, “Track
name”, “Artist name”, “Genre name”*, and
“Operating status”.

*: Displayed when playing back audio

files on a USB device (vehicles with a
Bluetooth

2.0 interface).

NOTE

During display of the ID3tag, hold down the
DISP key to switch to the folder title display.

The genre name display may not be possible.

During iPod Playback

E00738901096

This switches in the order “Albums”, “Track
name”, “Artist name”, “Genre name”*, and
“Operating status”.

NOTE

If there is no text information to display,
then “NO TITLE” is displayed.

Displayed genre name in equipment by type
(vehicles with a Bluetooth

2.0 interface).

The genre name display may not be possible.

During Bluetooth

2.0 Audio

Playback*

E00739001036

Operating details are the same as in “During
iPod Playback” on page 8-44.

Audio Quality and Volume
Balance Adjustment

E00738201161

Change audio quality settings.

Adjust Audio Quality and Vol-

ume Balance

1. Press the

/SEL key to select settings

items.
Each time the

/SEL key is pressed,

this switches in the order BASS, TRE-
BLE, FADER, BALANCE, SCV (speed
compensated volume), and Cancel.

2. Turn the /SEL key to adjust.

Adjust-

ment

items

Turn counter-

clockwise

Turn clockwise

BASS

-6 to 0
(low low-pass
volume)

0 to +6
(high low-pass
volume)

TREBLE -6 to 0

(Low high-pass
volume)

0 to +6
(High high-pass
volume)

FADER

CENTER

REAR 11
(emphasise
REAR)

FRONT 11 to
CENTER
(emphasise
FRONT)

BAL-
ANCE

LEFT 11 to
CENTER
(emphasise
LEFT)

CENTER

RIGHT 11
(emphasise
RIGHT)

Audio Quality and Volume Balance Adjustment

8-44

OGGE19E1

For pleasant driving

Mitsubishi Outlander PHEV (2019 year). Instruction - part 24
