Demister switch

E00703901340

When this switch is pressed, the mode
changes to the “

” mode. The indication

lamp  (A)  will  come  on.  The  selected  mode
(B)  is  shown  in  the  display.  (Refer  to
“Changing  the  mode  selection”  on  page
8-04.)

NOTE

When the demister switch is pressed, the air
conditioning  system  automatically  operates
and  outside  air  (as  opposed  to  recirculated
air)  is  selected.  This  automatic  switching
control  is  carried  out  to  prevent  misting  of
the  windows  even  if  “Disable  automatic  air
conditioning  control”  or  “Disable  automatic
air selection control” is set. (Refer to “Cus-
tomizing  the  air  conditioning  switch”  on
page  8-11,  “Customizing  the  air  selection”
on page 8-10.)

NOTE

To ensure a clear view, the engine may start
when the demister switch is pressed even
while the EV priority mode is activated.
Refer to “EV switch” on page 7-25.

Operating the system in auto-

matic mode

E00704102649

In normal conditions, use the system in the
AUTO mode and follow these procedures:

1. Push the AUTO switch.
2. Set the temperature control switch to the

desired temperature.

The  mode  selection,  blower  speed  ad-
justment,  recirculated/outside  air  selec-
tion,  temperature  adjustment,  and  air
conditioner  ON/OFF  status  are  all  con-
trolled automatically.

NOTE

If the blower speed selection switch, air con-
ditioning switch, MODE switch, or air selec-
tion  switch  is  operated  while  the  system  is
operating  in  the  AUTO  mode,  the  activated
function  overrides  the  corresponding  func-
tion of automatic control. All other functions
remain under automatic control.

Operating the system in man-

ual mode

E00704201308

Blower  speed  and  ventilator  mode  will  be
controlled  manually  by  setting  the  blower
speed selection switch and the MODE switch
to the desired positions.
To  return  to  automatic  operation,  press  the
AUTO switch.

Demisting of the windscreen
and door windows

E00704302016

CAUTION

For safety, make sure you have a clear view
through all the windows.

Automatic climate control air conditioner

8-13

OGGE19E1

For pleasant driving

For ordinary demisting

1. Set the air selection switch to the outside

position.

2. Set the MODE switch to the “

” posi-

tion.

3. Select your desired blower speed by

pressing the blower speed selection
switch.

4. Select your desired temperature by

pressing the temperature control switch.

5. Push the air conditioning switch.

For quick demisting

1. Push the demister switch to change to

the “

” position.

2. Set the blower to the maximum speed.
3. Set the temperature to the highest posi-

tion.

NOTE

To demist effectively, direct the air flow
from the side ventilators towards the door
windows.

Do not set the temperature to the max. cool
position. Cool air will blow against the win-
dow glasses and prevent demisting.

Important operation tips for
the air conditioner

E00708302388

Park the vehicle in the shade.
Parking in the hot sun will make the ve-
hicle inside extremely hot, and it will re-
quire more time to cool the interior.
If it is necessary to park in the sun, open
the windows for the first few minutes of
air conditioning operation to expel the
hot air.

Close the windows when the air condi-
tioner is in use. The entry of outside air
through open windows will reduce the
cooling efficiency.

Too  much  cooling  is  not  good  for  the
health.  Keep  the  difference  between  the
vehicle  interior  temperature  and  outside
temperature at 5 to 6 °C.

When  operating  the  system,  make  sure
the  air  intake,  which  is  located  in  front
of the windscreen, is free of obstructions
such as leaves and snow. Leaves collec-
ted in the air-intake plenum may reduce
air  flow  and  plug  the  plenum  water
drains.

Too much cooling/heating can affect the
EV cruising range, so maintain an appro-
priate temperature to extend the EV
cruising range.

Important operation tips for the air conditioner

8-14

OGGE19E1

For pleasant driving

Air conditioning system refrig-

erant and lubricant recommen-

dations

If  the  air  conditioner  seems  less  effective
than  usual,  the  cause  might  be  a  refrigerant
leak.
We  recommend  you  to  have  the  system  in-
spected.
[Except for vehicles for Ukraine]
The  air  conditioning  system  in  your  vehicle
must  be  charged  with  the  refrigerant
HFO-1234yf  and  the  lubricant  POE
MA68EV.
[Vehicles for Ukraine]
The  air  conditioning  system  in  your  vehicle
must  be  charged  with  the  refrigerant
HFC-134a and the lubricant POE MA68EV.
Use of any other refrigerant or lubricant will
cause severe damage which will result in the
need to replace your vehicle’s entire air con-
ditioning  system.  The  release  of  refrigerant
into the atmosphere is not recommended.
We  recommend  you  to  recover  and  recycle
the refrigerant for reuse.

During a long period of disuse

The air conditioner should be operated for at
least  five  minutes  each  week,  even  in  cold
weather.  This  is  to  prevent  the  compressor
from  seizing  and  to  maintain  the  air  condi-
tioner in the best operating condition.

Air purifier

E00708400718

An air filter has been incorporated into this
air conditioner so that dirt and dust are
cleaned from the air.
Replace the air filter periodically as its ability
to clean the air will be reduced as it collects
pollen and dirt. For the maintenance interval,
refer to the “SERVICE BOOKLET”.

NOTE

Operation in certain conditions such as driv-
ing on a dusty road and frequent use of the
air conditioner can lead to reduction of serv-
ice life of the filter. When you feel that the
air flow is lower than normal or when the
windscreen or windows start to fog up easi-
ly, replace the air filter.
We recommend you to have it checked.

Remote Climate Control*

E00735401087

You can run the air conditioner in advance of
using the vehicle.
For details, refer to “MITSUBISHI Remote
control: Remote Climate Control” on page
3-20.

Heating

E00733901062

When  heating,  the  engine  starts  running  be-
cause the heating system uses the heat of en-
gine coolant.
On  vehicles  with  electric  heater,  it  can  de-
crease  the  number  of  times  engine  starting
because  electrical  power  stored  in  the  drive
battery is also used when heating.

NOTE

If  you  want  to  stop  the  engine  running  for
heating,  select  the  EV  priority  mode  before
operating  the  air  conditioner.  Refer  to  “EV
switch” on page 7-25.

LW/MW/FM radio/CD
player*

E00708503387

The audio system can only be used when the
operation mode of the power switch is in ON
or ACC.

Air purifier

8-15

OGGE19E1

For pleasant driving

NOTE

To listen to the audio system while the Plug-
in  Hybrid  EV  system  is  not  operating,  put
the  operation  mode  of  the  power  switch  in
ACC.
If the operation mode of the power switch is
left in ACC, the accessory power will auto-
matically  turn  off  after  a  certain  period  of
time  and  you  will  no  longer  be  able  to  use
the  audio  system.  The  accessory  power
comes on again if the operation mode of the
power switch is operated with is in the ACC.
Refer to “ACC power auto-cutout function”
on page 7-13.

If a cellular phone is used inside the vehicle,
it may create noise from the audio equip-
ment. This does not mean that anything is
wrong with your audio equipment. In such a
case, use the cellular phone at a place as far
away as possible from the audio equipment.

If foreign objects or water get into the audio
equipment,  or  if  smoke  or  a  strange  odour
comes from it, immediately turn off the au-
dio  system.  We  recommend  you  to  have  it
checked.  Never  try  to  repair  it  by  yourself.
Avoid  continuous  usage  without  inspection
by a qualified person.

Important Points on Usage

E00735500023

iPod/iPhone Playback Func-

tion*

This product supports audio playback
from iPod/iPhone devices, however dif-
fering versions mean that playback can-
not be guaranteed.

Please be aware that depending on the
iPod/iPhone model or version, operation
may differ.

How to Clean

E00735700025

If the product becomes dirty, wipe with a
soft cloth.

If  very  dirty,  use  a  soft  cloth  dipped  in
neutral  detergent  diluted  in  water,  and
then  wrung  out.  Do  not  use  benzene,
thinners,  or  other  chemical  wipes.  This
may harm the surface.

Trademarks

E00735801238

Product names and other proper names
are the trademarks or registered trade-
marks of their respective owners.

Furthermore, even if there is no specific
denotation of trademarks or registered
trademarks, these are to be observed in
their entirety.

“Made  for  iPod”,  “Made  for  iPhone”
mean  that  an  electronic  accessory  has
been designed to connect specifically to
iPod  or  iPhone,  respectively,  and  has
been  certified  by  the  developer  to  meet
Apple performance standards.
iPhone,  iPod,  iPod  classic,  iPod  nano,
and iPod touch are trademarks of Apple
Inc.,  registered  in  the  U.S.  and  other
countries.
Apple  is  not  responsible  for  the  opera-
tion of this device or its compliance with
safety and regulatory standards.

NOTE

iPod and iTunes licensing allows individual
users to privately reproduce and play back
non- copyrighted material as well as material
that may be legally copied and reproduced.
Infringement of copyright is prohibited.

LW/MW/FM radio/CD player*

8-16

OGGE19E1

For pleasant driving

Handling of Discs

E00735901040

This explains care that should be taken in the
handling of discs.

Important Points on Handling

Fingerprints  or  other  marks  on  the  read
surface of the disc may result in its con-
tent  being  more  difficult  to  read.  When
holding the disc, grip both edges, or one
edge  and  the  centre  hole,  in  order  that
the read surface is not touched.

Do not affix paper or stickers, or other-
wise damage the disc.

Do not forcefully insert a disc if another
is already within the device. This can re-
sult in damage to discs, or malfunction.

Cleaning

Periodically clean the read surface of the
disc.  When  cleaning,  do  not  wipe  in  a
circular  motion.  Instead,  wipe  gently
outwards  from  the  centre  of  the  disc  to
the outer edge.

New discs may have burring around the
outer edge or in the hole in the centre.
Ensure you check for these. If there are
burrs, these may lead to faulty operation,
therefore ensure these are removed.

Important Points on Storage

When not using discs, ensure these are
kept in cases, and stored out of direct
sunlight.

If discs are not going to be used for a
long period of time, remove these from
the product.

Disc Playback Environment

In cold environments such as in mid-winter
when the interior of the vehicle is cold, turn-
ing the heater on and immediately trying to
use the product may cause condensation (wa-
ter droplets) to form on the disc and internal
optical components, and this may prevent the
product from operating correctly.
In these conditions, remove the disc, and wait
a short time before use.

Copyright

Actions  such  as  unauthorized  reproduction,
broadcast,  public  performance,  or  rental  of
discs  that  comprise  other  than  personal  use
are prohibited by law.

Types of Disc That Can Be

Played Back

E00736001035

The following marks are printed on the disc
label, package, or jacket.

Type

Size

Maxi-

mum

playback

time

Comments

CD-DA

12 cm 74 mi-

nutes

—

CD-
TEXT

12 cm 74 mi-

nutes

—

CD-
R/RW

12 cm —

•Disc contain-
ing MP3 files

Discs That May Not Be Played

Back

Playback of discs other than those de-
scribed in “Types of Disc That Can Be
Played Back” is not guaranteed.

8 cm discs may not be used.

Handling of Discs

8-20

OGGE19E1

For pleasant driving

Do not insert irregularly-shaped discs
(for example, heart-shaped), as these
may result in malfunction. Additionally,
discs that have transparent portions may
not be played back.

Discs that have not been finalized cannot
be played back.

Even  if  recorded  using  the  correct  for-
mat  on  a  recorder  or  computer,  applica-
tion software settings and environments;
disc  peculiarities,  damage,  or  marking;
or dirt or condensation on the lens inside
the product may render the disc unplaya-
ble.

Depending on the disc, some functions
may not be used, or the disc may not
play back.

Do not use discs with cracks or warps.

If the disc has stickers affixed, remains
from removed stickers, or affixed adhe-
sive, then do not use the disc.

Discs that have decorative labels or
stickers may not be used.

Nonstandard CDs

This product will play back audio CDs, how-
ever please be aware of the following points
regarding CD standards.

Ensure that you use discs with

on the

label surface.

Playback of other than standard CDs is
not guaranteed. Even if the audio can be
played back, the audio quality cannot be
guaranteed.

When playing back other than standard
CDs, the following may occur.

• There may be noise during playback.
• There may be jumping in the audio.
• The disc may not be recognized.
• The first track may not be played

back.

• It may take longer than usual until

start of playback of tracks.

• Playback may start from within the

track.

• Some parts may not be played back.
• Tracks may freeze during playback.
• Tracks may be displayed erroneously.

Audio Files
(MP3/WMA/AAC)

E00736100026

This product can play back MP3/WMA/AAC
format  audio  files  recorded  on  CD-ROM,
CD-R/RW, and USB devices.

There  are  limitations  on  the  files  and  media
that can be used, therefore read the following
prior  to  recording  MP3/WMA/AAC  format
audio files on discs or USB devices.

Additionally, ensure you read the user man-
uals for your CD-R/RW drive and the writing
software, and ensure these are used correctly.
If the MP3/WMA/AAC format audio files in-
cludes title information or other data, then
this can be displayed.

CAUTION

CD-ROM and CD-R/RW media can only
play back MP3 format audio files.

Actions such as copying audio CDs or files
and either distributing these to others for
free or for charge, or uploading files via the
Internet or other means to servers is an in-
fringement of the law.

Do  not  append  the  file  extensions  “.mp3”,
“.wma”,  or  “.m4a”,  to  other  than
MP3/WMA/AAC format files. Playing back
discs with these types of files recorded upon
them  may  cause  the  files  to  be  incorrectly
identified  for  playback,  which  may  lead  to
loud  noise,  resulting  in  speaker  damage  or
accident.

NOTE

Depending  on  the  condition  of  the  disc  re-
corder  or  recording  software  used,  correct
playback  may  not  be  possible.  In  these  ca-
ses, refer to the user manual for your product
or software.

Audio Files (MP3/WMA/AAC)

8-21

OGGE19E1

For pleasant driving

NOTE

Depending  on  your  computer’s  operating
system,  version,  software,  or  settings,  files
may  not  have  a  file  extension  appended.  In
these  cases,  append  the  file  extensions
“.mp3”,  “.wma”,  or  “.m4a”  when  copying
the files.

Files larger than 2GB in size cannot be
played back.

Data Formats That Can Be

Played Back

E00736200027

Data formats that can be played on discs
(CD-ROM, CDR/RW) and USB devices dif-
fer.

Data format

DISC

USB device

MP3

WMA

AAC

Folder Structure

E00736300031

Up to 8 folder levels can be recognized.

You can create a folder structure as in Genre -
Artist - Album - Track (MP3/WMA/AAC
format audio files) for management of tracks.

Folder

ROOT

Audio file

1 level

2 level

3 level

4 level

5 level

Name

Speci-

fica-

tion

Explanation

Format

specifica-

tions

ISO96
60

Level
1

Maximum 8
character file
name, and 3
character file
extension. (sin-
gle-byte alpha-
numeric capital
letters, numer-
als, “_” may be
used)

Name

Speci-

fica-

tion

Explanation

Format

specifica-

tions

ISO96
60 ex-
tension

Joliet

Files names up
to a maximum
64

characters

can be used.

Multises-

sion

Not supported (only first session
supported)

Maxi-

mum

number

of levels

8 levels (if the root is the 1

lev-

el)

Maxi-

mum

folder

number

700 folders (including root)

Maxi-

mum file

number*

65,535 files (total number on
media. Other than MP3, WMA,
and AAC files not included)

File name

and fold-

er name

restric-

tions

Maximum 64 bytes (for Uni-
code, 32 characters), files/folders
with file/folder names longer
than this will not be displayed or
played back.

USB sup-

ported

formats

The recommended file system is
FAT32.
1 partition only

Audio Files (MP3/WMA/AAC)

8-22

OGGE19E1

For pleasant driving

: Do not include other than

MP3/WMA/AAC files. However, if
storing many tracks within the same
folder, these may not be recognized
even if less than the maximum number
of tracks. In these cases, divide the
tracks up into multiple folders.

NOTE

The order in which folders and audio files
are displayed on this product may be differ-
ent to how they are displayed on a computer.

What Is MP3?

E00736400029

MP3 is the abbreviation of “MPEG-1 Audio
Layer 3”. MPEG is an abbreviation of “Mo-
tion Picture Experts Group”, and this is a vid-
eo compression standard used in video CDs,
etc.
MP3  is  one  of  the  audio  compression  meth-
ods  contained  in  the  MPEG  audio  standard,
and reduces the quality of sounds that are be-
yond the auditory resolution of the human ear
and  that  are  hidden  by  louder  sounds,  thus
creating  high-quality  data  with  a  lower  data
size.
This can compress CD audio to approximate-
ly 1/10 its original data size without percepti-
ble loss, approximately 10 CDs can be writ-
ten to a single CD-R/RW disc.

CAUTION

MP3 files different to the standards at right
may not play back correctly, or file/folder
names may not be displayed correctly.

Standards for MP3 Files That

Can Be Played Back

Specifications for MP3 files that can be
played are as shown below.

Item

Details

Specification MPEG-1 AUDIO LAYER3

MPEG-2 AUDIO LAYER3

Sampling fre-
quency [kHz]

MPEG-1: 32/44.1/48

MPEG-2: 16/22.05/24

Bit rate [kbps] MPEG-1: 32 to 320

MPEG-2: 8 to 160

VBR (varia-

ble bit rate)

Support

Channel

mode

Stereo/ Joint stereo/ Dual
channel/ Monaural

File exten-

sion

mp3

Item

Details

Supported tag

information

ID3 tag Ver. 1.0, Ver. 1.1,
Ver. 2.2, Ver. 2.3, Ver. 2.4
(ISO-8859-1, UTF-16 (Uni-
code)), Titles, Artist name,
Album name

Maximum
number of

characters

that can be

indicated on

the display

64 characters

What Is WMA?

E00736601031

WMA is the abbreviation of Windows Media
Audio, and this is an audio compression for-
mat from Microsoft. This is a compression
format that has a higher compression ratio
than MP3.

NOTE

Microsoft, Windows Media, and Windows
are registered trademarks of Microsoft Cor-
poration (USA) and in other countries.

CAUTION

WMA supports digital rights management
(DRM). This product cannot play back
WMA files protected using this system.

Audio Files (MP3/WMA/AAC)

8-23

OGGE19E1

For pleasant driving

CAUTION

WMA files different to the standards at right
may not play back correctly, or file/folder
names may not be displayed correctly.

“Pro”, “Lossless”, and “Voice” are not sup-
ported.

Standards for WMA Files That

Can Be Played Back

Specifications for WMA files that can be
played are as shown below.

Item

Details

Specification Windows Media Audio Ver-

sion7.0/8.0/9.0

Sampling fre-
quency [kHz]

32/44.1/48

Bit rate

[kbps]

48 to 320

VBR

(variable bit

rate)

Support

Channel

mode

Stereo/Monaural

File exten-

sion

wma

Supported tag

information

WMA tags
Title name, Artist name, Al-
bum name

Item

Details

Maximum
number of

characters

that can be

indicated on

the display

64 characters

What is AAC?

E00736801033

AAC is the abbreviation of Advanced Audio
Coding, and this is an audio compression
standard used in “MPEG-2” and “MPEG-4”.
This features 1.4x the compression of MP3,
with comparable audio quality.

CAUTION

AAC supports digital rights management
(DRM). This product cannot play back AAC
files protected using this system.

AAC files different to the standards at right
may not play back correctly, or file/folder
names may not be displayed correctly.

Standards for AAC Files That

Can Be Played Back

Specifications for AAC files that can be
played are as shown below.

Item

Details

Specification

Advanced Audio
Coding
MPEG4/AAC-LC
MPEG2/AAC-LC

Sampling

frequency

[kHz]

MPEG4 8/11.025/12/16/22.05

/24/32/44.1/48

MPEG2 8/11.025/12/16/22.05

/24/32/44.1/48

Bit rate

[kbps]

MPEG4 8 to 320

MPEG2 8 to 320

VBR (variable bit

rate)

Support

Channel mode

Stereo/Monaural

File extension

m4a

Supported tag infor-

mation

AAC tags or ID3
tags
Title, Artist name,
Album name

Maximum number of

characters that can be

indicated on the dis-

play

64 characters

Audio Files (MP3/WMA/AAC)

8-24

OGGE19E1

For pleasant driving

Important Points on Safety
for the Customer

E00737000035

This product features a number of pictorial
indications as well as points concerning han-
dling so that you can use the product correct-
ly and in a safe manner, as well as prevent in-
jury or damage to yourself, other users, or
property.

WARNING

The driver should not pay close attention
to the display while driving.
This may prevent the driver looking
where they are going, and cause an acci-
dent.

The driver should not perform complica-
ted operations while driving.
Performing  complicated  operations  while
driving  may  prevent  the  driver  looking
where  they  are  going,  and  cause  an  acci-
dent.
Therefore  stop  the  vehicle  in  a  safe  loca-
tion before performing such operations.

Do not use during malfunctions, such as
when no sound is audible.
This may lead to accident, fire, or electric
shock.

Ensure water or other foreign objects do
not enter the product.
This may lead to smoking, fire, electric
shock, or malfunction.

WARNING

Do not insert foreign objects into the disc
slot.
This may lead to fire, electric shock, or
malfunction.

In  the  event  of  abnormalities  occurring
when  foreign  objects  or  water  enter  the
product,  resulting  in  smoke  or  a  strange
smell, immediately stop using the product,
and  consult  a  MITSUBISHI  MOTORS
Authorized Service Point.
Continuing to use the product may result
in accident, fire, or electric shock.

Do not disassemble or modify the prod-
uct.
This may lead to malfunction, fire, or
electric shock.

During thunderstorms, do not touch the
antenna or the front panel.
This may lead to electrical shock from
lightning.

CAUTION

Do not block ventilation holes or heat sinks
on the product.
Blocking ventilation holes or heat sinks may
prevent heat from escaping from within the
product, leading to fire or malfunction.

CAUTION

Do not turn the volume up to the extent that
you cannot hear sounds from outside the ve-
hicle while driving.
Driving without being able to hear sounds
from outside the vehicle may result in an ac-
cident.

Do not insert your hand or fingers into the
disc slot.
This may result in injury.

Operation Keys

E00737100023

Turn the Power ON/ OFF

E00737201089

1. Press the PWR/VOL key.

Turn the power on, and resume playback
from the previous status.

Important Points on Safety for the Customer

8-25

OGGE19E1

For pleasant driving

2. Press the PWR/VOL key.

Turn the power OFF.

NOTE

Hold down the steering SOURCE button to
also turn the audio function ON/OFF.

Adjust Volume

E00737300025

1. Turn the PWR/VOL key to adjust the

volume.

Turn the PWR/VOL key clockwise to in-
crease, and counter- clockwise to de-
crease the volume.

NOTE

The maximum value for volume is 45, and
the minimum is 0.

NOTE

The initial setting for volume is “17”.

Insert/Eject Discs

E00737400026

1. Insert the disc into the disc slot with the

label surface up.

Disc

*Label side

Disc slot

Push the disc in a certain amount, and
the product will pull the disc in, and
playback will start.

2. Press the

key.

This will eject the disc from the product,
so remove the disc.

CAUTION

When replacing discs, first ensure that the
vehicle is stopped in an area in which stop-
ping is permitted.

Do not insert your hand, fingers, or foreign
objects into the disc slot. This may lead to
injury, smoking, or fire.

8 cm CDs are not supported.

Operation Keys

8-26

OGGE19E1

For pleasant driving

Explanation of Buttons

E00737501255

This explains names and functions of each part.

key

Use to eject a disc.

2- 3

key/4

key

For audio, rewind/fast forward.
For radio, use as preset keys 3 and 4.

3- 2RDM key

For audio, play random playback; for ra-
dio, use as preset key 2.

4- 1RPT key

For audio, play repeat playback; for ra-
dio, use as preset key 1.

5- RADIO key

Switch the radio and the band.

6- PWR/VOL key

Adjust the volume, and turn the power
ON/OFF.

7- MEDIA key

Switch between CD and other sources.

8- DISP key

Switch the content of the display.

9- PTY/SCAN key

For audio, play scan playback; for radio,
search PTY.

10- TP key

Receive traffic messages.

11- Disc slot

12- PAGE key

Display indicator page advance.

13- 5

key

Play/Pause Bluetooth Audio

, and use as

preset key 5 for radio.

14- 6

key

Return during audio track search, and
stop Bluetooth Audio

For radio, use as preset key 6.

Requires a separately-purchased Bluetooth- capable audio device in equipment by type (vehicles with a Bluetooth

2.0 interface).

Operation Keys

8-27

OGGE19E1

For pleasant driving

15-

key/

key

For audio, select audio track/file; for ra-
dio, perform automatic station selection
or ensemble/service station selection.

16- MENU key

Switch to Menu mode.

17-

/SEL key

Adjust audio quality and select items.
For radio, manually select stations.

Steering wheel audio remote

control switches

E00737601517

1- Volume up/down switch

Adjust audio functions and the mobile
phone function volume.

2- button, button

Select CD and other audio source tracks
and radio stations.
Hold down to skip up and down through
tracks.

3- SOURCE button

Hold  down  to  turn  the  audio  function
ON/OFF. Additionally, each time this is
pressed, this switches the audio source.
The  order  of  switching  is  as  shown  be-
low.
If  devices  are  not  connected,  then  these
are to be skipped, and the next source se-
lected.

CD or MP3

DAB1, 2, 3

FM1, 2, 3

Bluetooth Audio

iPod

or USB device

An iPod cable (available separately) is
required.

Requires a separately-purchased Blue-
tooth-capable audio device (vehicles
with a Bluetooth

2.0 interface).

Requires DAB tuner connection.

Listen to Radio

E00737700032

This explains how to listen to FM, MW, and
LW radio broadcasts.

To Listen to the Radio

Press the RADIO key to switch the band.

Switch between FM1, FM2, FM3, MW, and
LW bands.
The selected band is indicated on the display.

NOTE

This switches in the order FM1, FM2, FM3,
DAB1*, DAB2*, DAB3*, MW, and LW.
*:When a DAB tuner is connected.

Manual/Seek Station Selection

Turn the /SEL key to the frequency to lis-
ten to.

Listen to Radio

8-28

OGGE19E1

For pleasant driving

Mitsubishi Outlander PHEV (2019 year). Instruction - part 23
