Mitsubishi Outlander PHEV (2019 year). Instruction

NOTE

press the accelerator pedal and the vehicle
starts moving again.

If  the  following  operation  is  performed,  the
brake  auto  hold  will  be  deactivated  and  the
brake  auto  hold  indication  lamp  in  the  in-
strument cluster goes off.

•

When putting the select position to the
“P” (PARK) or “R” (REVERSE) position
while depressing the brake pedal.

•

When the Electric parking brake is ap-
plied by using the Electric parking brake
switch.

While the vehicle is held stationary with the
brake auto hold system, the Electric parking
brake  will  be  automatically  applied  under
the  following  conditions,  and  a  buzzer  will
sound and the message will appear on the in-
formation  screen  in  the  multi  information
display.

•

After approximately 10 minutes have
elapsed while applying the brake auto
hold system.

•

When the driver’s seat belt is unfastened.

•

When the driver’s door is opened.

•

When the operation mode of the power
switch is put in OFF.

NOTE

•

When the system detects the vehicle slid-
ing down a slope.

If the Electric parking brake cannot be ap-
plied automatically due to the system mal-
function, the message will appear on the
information screen in the multi informa-
tion display. Depress the brake pedal.

To start the vehicle

Depress the acceleration pedal with the select
position in any position other than “P”
(PARK) or “N” (NEUTRAL).
The brakes are released, and the brake auto
hold indication lamp in the instrument cluster
will go off.

To turn off brake auto hold

Press the brake auto hold switch to turn brake
auto  hold  off.  The  indication  lamp  on  the
switch goes off.
If  you  want  to  turn  off  the  system  while  the
brake  auto  hold  indication  lamp  is  illumina-
ted,  press  the  switch  while  depressing  the
brake pedal.

NOTE

If  the  brake  auto  hold  system  is  turned  off
without  the  brake  pedal  being  depressed,  a
buzzer  will  sound  and  the  message  will  ap-
pear  on  the  information  screen  in  the  multi
information display.

Hill start assist

E00628001237

The hill start assist makes it easy to start off
on a steep uphill slope by preventing the ve-
hicle  from  moving  backwards.  It  keeps  the
braking  force  for  about  2  seconds  when  you
move  your  foot  from  the  brake  pedal  to  the
accelerator pedal.

Hill start assist

7-37

OGGE19E1

Starting and driving

CAUTION

Do not overly rely on the hill start assist to
prevent backwards movement of the vehicle.
Under certain circumstances, even when hill
start assist is activated, the vehicle may
move backwards if the brake pedal is not
sufficiently depressed, if the vehicle is heav-
ily loaded, or if the road is very steep or slip-
pery.

The hill start assist is not designed to keep
the vehicle stopped in place on uphill slopes
for more than 2 seconds.

When facing uphill, do not rely on using the
hill start assist to maintain a stopped position
as an alternative to depressing the brake ped-
al.
Doing so could result in an accident.

Do  not  turn  the  operation  mode  in  ACC  or
OFF  while  the  hill  start  assist  is  operating.
The  hill  start  assist  could  stop  operating,
which could result in an accident.

To operate

E00628101498

1. Stop the vehicle completely using the

brake pedal.

2. Put the select position to the “D” posi-

tion.

NOTE

When reversing on an uphill slope, put the
select position to the “R” position.

3. Release the brake pedal and the hill start

assist will maintain the braking force ap-
plied while stopped for approximately 2
seconds.

4. Depress the accelerator pedal and the

hill start assist will gradually decrease
the braking force as the vehicle starts
moving.

NOTE

The hill start assist is activated when all of
the following conditions are met.

•

The Plug-in Hybrid EV System is operat-
ing.
(The hill start assist will not be activated
while the Plug-in Hybrid EV System is
starting or immediately after the Plug-in
Hybrid EV System has started.)

•

The select position is in any position other
than “P” or “N”.

•

The vehicle is completely stationary, with
the brake pedal depressed.

•

The parking brake is released.

The hill start assist will not operate if the ac-
celerator pedal is depressed before the brake
pedal is released.

The hill start assist also operates when re-
versing on an uphill slope.

Warning display

E00628201369

If an abnormal condition occurs in the sys-
tem, the following Warning lamp/Warning
display will turn on.

Warning lamp

Warning display

CAUTION

If the warning is displayed, the hill start as-
sist will not operate. Start off carefully.

Park  your  vehicle  in  a  safe  place  and  stop
the Plug-in Hybrid EV System.
Restart  the  Plug-in  Hybrid  EV  System  and
check  whether  the  display/indicator  goes
out,  in  which  case  the  hill  start  assist  is
working normally again.
If  they  remain  displayed  or  reappear  fre-
quently, it is not necessary to stop the vehi-
cle  immediately,  but  the  vehicle  should  be
inspected by a MITSUBISHI MOTORS Au-
thorized Service Point as soon as possible.

Hill start assist

7-38

OGGE19E1

Starting and driving

Brake assist system

E00627001793

The brake assist system is a device assisting
drivers  who  cannot  depress  the  brake  pedal
firmly when it is necessary to do so (such as
in  emergency  stop  situations)  and  provides
greater braking force.

If the brake pedal is depressed suddenly, the
brakes  will  be  applied  with  more  force  than
usual.

CAUTION

The  brake  assist  system  is  not  a  device  de-
signed to exercise braking force greater than
its capacity. Make sure to always keep a suf-
ficient  distance  between  your  vehicle  and  a
vehicle  in  front  of  you  without  relying  too
much on the brake assist system.

NOTE

Once the brake assist system is operational,
it maintains great braking force even if the
brake pedal is lightly released.
To stop its operation, completely remove
your foot from the brake pedal.

NOTE

When the brake assist system is in use, you
may  feel  as  if  the  depressed  brake  pedal  is
soft,  the  pedal  moves  in  small  motions  in
conjunction with the sound of the ABS oper-
ation,  or  the  vehicle  body  and  the  steering
wheel  vibrate.  This  occurs  when  the  brake
assist system is operating normally and does
not  indicate  faulty  operation.  Continue  to
firmly depress the brake pedal.

You may hear an operation noise when the
brake pedal is depressed suddenly while sta-
tionary. This does not indicate a malfunction
and the brake assist system is operating nor-
mally.

When the anti-lock brake system warning
lamp or only Active Stability Control warn-
ing lamp illuminate, the brake assist system
in not functioning.

Emergency stop signal
system

E00626001259

This is a device that reduces the possibility of
rear end collisions by the rapid and automatic
blinking of the hazard warning lamps to alert
vehicles  approaching  from  behind  during
sudden  braking.  When  the  emergency  stop
signal  system  operates,  the  hazard  warning
indication  lamp  in  the  instrument  cluster
blinks rapidly at the same time.

CAUTION

If the ABS warning or ASC warning is dis-
played,  the  emergency  stop  signal  system
may  not  operate.  Refer  to  “ABS  warning
lamp/display” on page 7-41.
Refer  to  “ASC  warning  lamp/display”  on
page 7-45.

NOTE

[Activating condition for the emergency stop
signal system]
It activates when all of the following condi-
tions are met.

•

The vehicle speed is approximately
55 km/h (34 mph) or higher.

•

The brake pedal has been depressed, and
the system judges that it was sudden brak-
ing from the vehicle deceleration and the
operating condition of the anti-lock brake
system (ABS).

[Deactivating condition for the emergency
stop signal system]
It deactivates when one of the following
conditions is met.

•

The brake pedal is released.

•

The hazard warning flasher switch is
pressed.

•

The system judges that it was not sudden
braking from the vehicle deceleration and
the operating condition of the anti-lock
brake system (ABS).

Brake assist system

7-39

OGGE19E1

Starting and driving

Anti-lock brake system
(ABS)

E00607102489

Environmental conditions can have an effect
on  braking.  During  sudden  braking  when
there is snow, ice, oil, water etc. on the road
surface,  a  skid  may  occur.  In  this  situation,
steering  control  and  braking  effectiveness  is
reduced  and  the  stopping  distance  is  in-
creased. The vehicle may also go into an un-
controlled spin.
The ABS helps prevent the wheels from lock-
ing  during  braking,  thus  maintaining  direc-
tional  stability,  ensuring  controllability  and
providing optimum braking force.

Operating hints

Always maintain the same distance from
the vehicle in front of you as you would
for a vehicle not equipped with ABS.
Compared with vehicles not fitted with
ABS, your vehicle may require a longer
stopping distance in the following cases:

• Driving on gravel or snow-covered

roads.

• Driving with snow traction device

(tyre chains) installed.

• Driving on roads where the road sur-

face is pitted or has other differences
in surface height.

• Driving on bumpy roads or other poor

driving surfaces.

Operation of ABS is not restricted to sit-
uations  where  brakes  are  applied  sud-
denly.  This  system  may  also  operate  to
prevent wheel lock when you are driving
over  manholes,  steel  road-work  plates,
or the vehicle is driven over steps or lev-
el differences in the road, road markings,
or  other  surfaces  which  are  difficult  for
the wheels to grip.

When  the  ABS  is  activated,  you  may
feel the brake pedal pulsation and the vi-
brations of the vehicle body and steering
wheel. You may also hear a characteris-
tic noise. At this time, you may feel as if
the  pedal  attempts  to  resist  being  de-
pressed.
This is a normal result of the ABS oper-
ation, and does not indicate a problem.
If  this  situation  occurs,  depress  the
brake  pedal  more  firmly  in  order  to
operate  the  ABS.  Do  not  pump  the
brake.  This  will  result  in  reduced
braking performance.

You will hear the operation sound of the
motor  coming  from  the  Plug-in  Hybrid
EV  System  compartment  immediately
following start off after starting the Plug-
in Hybrid EV System. If the brake pedal
is  depressed  at  that  moment,  you  can
feel the brake pedal pulsating.
This pulsation is due to the self-diagno-
sis  operation  of  the  ABS  and  does  not
indicate a malfunction.

The  ABS  will  operate  after  the  vehicle
has  accelerated  to  a  speed  in  excess  of
approximately 10 km/h (6 mph). It stops
operating  when  the  vehicle  decelerates
to a speed below about 5 km/h (3 mph).

CAUTION

Even  the  ABS  cannot  prevent  the  natural
laws of physics from acting on the vehicle. It
cannot for instance avoid accidents that may
result from excessive speed on bends or fol-
lowing  another  vehicle  too  closely  or  aqua-
planing. It should remain the driver’s task to
observe  safety  precautions  to  judge  speeds
and brake applications correctly in such con-
ditions.

Be sure to use tyres of the same type and
size on 4 wheels.
If tyre types or sizes are mixed, ABS may
not function normally.

Anti-lock brake system (ABS)

7-40

OGGE19E1

Starting and driving

CAUTION

Never  install  a  limited-slip  differential,
which is not MITSUBISHI MOTORS GEN-
UINE  parts,  as  the  ABS  may  not  function
normally.
We  recommend  you  to  consult  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

ABS warning lamp/display

E00607202321

Warning lamp

Warning display

If  there  is  a  malfunction  in  the  system,  the
ABS  warning  lamp  will  come  on  and  the
warning  display  will  appear  on  the  informa-
tion screen in the multi information display.
Under  normal  conditions,  the  ABS  warning
lamp  only  comes  on  when  the  operation
mode  is  put  in  ON  and  goes  off  a  few  sec-
onds later.

CAUTION

Any  of  the  following  warning  lamp/display
behaviour indicates that the ABS is not func-
tioning  and  only  the  standard  brake  system
is  working.  (The  standard  brake  system  is
functioning  normally.)  If  this  happens,  take
your  vehicle  to  a  MITSUBISHI  MOTORS
Authorized Service Point.

•

When the operation mode is put in ON,
the warning lamp does not come on or it
remains on and does not go off.

•

The warning lamp comes on while driv-
ing.

•

The warning display appears while driv-
ing.

If the warning lamp/display il-

luminate while driving

E00607302494

If only the ABS warning lamp/

display illuminate

Avoid hard braking and high-speed driv-
ing. Stop the vehicle in a safe place.
Restart  the  Plug-in  Hybrid  EV  System
and check to see whether the lamp goes
out after a few minutes driving; if it then
remains  off  during  driving,  there  is  no
problem.
However, if the lamp does not go out, or
if  it  lights  up  again  when  the  vehicle  is
driven,  we  recommend  you  to  have  the
vehicle checked as soon as possible.

If  you  start  Plug-in  Hybrid  EV  System
when the auxiliary battery voltage is in-
sufficient,  ABS  warning  lamp/display
may  illuminate,  but  this  is  not  a  failure
of ABS. When the drive battery is charg-
ed, the auxiliary battery is also charged,
and  the  warning  lamp/display  will  go
out. If the warning lamp/display contin-
ues illuminating even after the battery is
sufficiently  charged  or  the  warning
lamp/display  illuminates  frequently,
have  your  vehicle  inspected  by  a
MITSUBISHI  MOTORS  Authorized
Service Point.

If the ABS warning lamp/

display and brake warning

lamp (red)/display illuminate at

the same time

Warning lamp

(red)

Anti-lock brake system (ABS)

7-41

OGGE19E1

Starting and driving

Warning display

The  ABS  and  brake  force  distribution  func-
tion  may  not  work,  so  hard  braking  could
make the vehicle unstable.
Avoid  hard  braking  and  high-speed  driving.
Stop the vehicle in a safe place immediately
and  contact  a  MITSUBISHI  MOTORS  Au-
thorized Service Point.

NOTE

The  ABS  warning  lamp  and  brake  warning
lamp  illuminate  at  the  same  time  and  the
warning  displays  appear  alternately  on  the
information  screen  in  the  multi  information
display.

After driving on icy roads

E00618801388

After driving on snowy roads, remove any
snow and ice which may have become ad-
hered to the wheel areas.

When doing this, be careful not to damage
the wheel speed sensors (A) and cables loca-
ted at each wheel on vehicles equipped with
an ABS.

Front

Rear

Electric power steering
system (EPS)

E00629201294

The power steering system operates while the
Plug-in Hybrid EV System is operating.
It  helps  reduce  the  effort  needed  to  turn  the
steering wheel.
The  power  steering  system  has  mechanical
steering capability in case the power assist is
lost. If the power assist is lost for some rea-
son, you will still be able to steer your vehi-
cle,  but  you  will  notice  it  takes  much  more
effort to steer. If this happens, have your ve-
hicle inspected at a MITSUBISHI MOTORS
Authorized Service Point.

WARNING

Do  not  stop  the  Plug-in  Hybrid  EV  Sys-
tem while the vehicle is moving. Stopping
the  Plug-in  Hybrid  EV  System  would
make  the  steering  wheel  extremely  hard
to turn, possibly resulting in an accident.

NOTE

During  repeated  full-lock  turning  of  the
steering  wheel  (for  example,  while  you  are
manoeuvring  the  vehicle  into  a  parking
space), a protection function may be activa-
ted  to  prevent  overheating  of  the  power
steering system. This function will make the
steering  wheel  gradually  harder  to  turn.  In
this event, limit your turning of the steering
wheel  for  a  while.  When  the  system  has
cooled down, the steering action will return
to normal.

If you turn the steering wheel while the vehi-
cle  is  stationary  with  the  headlamps  on,  the
headlamps may become dim. This behaviour
is  not  abnormal.  The  headlamps  will  return
to  their  original  brightness  after  a  short
while.

Electric power steering system (EPS)

7-42

OGGE19E1

Starting and driving

Electric power steering system

warning display

If there is a malfunction in the system, the
warning display will appear on the informa-
tion screen in the multi information display.

CAUTION

If the warning display appears while the
Plug-in Hybrid EV System is operating,
have

the

vehicle

inspected

MITSUBISHI MOTORS Authorized Serv-
ice Point as soon as possible.
It may become harder to turn the steering
wheel.

Active stability control
(ASC)

E00616701468

The  Active  Stability  Control  (ASC)  takes
overall control of the anti-lock brake system,
traction control function and stability control
function  to  help  maintain  the  vehicle’s  con-
trol  and  traction.  Please  read  this  section  in
conjunction  with  the  page  on  the  anti-lock
brake  system,  traction  control  function  and
stability control function.

Anti-lock brake system (ABS)

® p. 7-40

Traction control function

® p. 7-44

Stability control function

® p. 7-44

CAUTION

Do not over-rely on the ASC. Even the ASC
cannot prevent the natural laws of physics
from acting on the vehicle.
This system, like any other system, has lim-
its and cannot help you to maintain traction
and control of the vehicle in all circumstan-
ces. Reckless driving may lead to accidents.
It is the driver’s responsibility to drive care-
fully. This means taking into account the
traffic, road and environmental conditions.

Be sure to use the same specified type and
size of tyre on all 4 wheels. Otherwise, the
ASC may not work properly.

CAUTION

Do not install any aftermarket limited-slip
differential (LSD) on your vehicle. The ASC
may stop functioning properly.

NOTE

An operation noise may be emitted from the
Plug-in  Hybrid  EV  System  compartment  in
the  following  situations.  The  sound  is  asso-
ciated  with  checking  the  operations  of  the
ASC.  At  this  time,  you  may  feel  a  shock
from the brake pedal if you depress it. These
do not indicate a malfunction.

•

When the operation mode is put in ON.

•

When the vehicle is driven for a while af-
ter the Plug-in Hybrid EV System is
turned on.

When the ASC is activated, you may feel a
vibration in the vehicle body or hear a whin-
ing sound from the Plug-in Hybrid EV Sys-
tem compartment.
This indicates that the system is operating
normally. It does not indicate a malfunction.

When the anti-lock brake system warning
lamp is illuminated, the ASC is not active.

Active stability control (ASC)

7-43

OGGE19E1

Starting and driving

Traction control function

E00619000087

On  slippery  surfaces,  the  traction  control
function  prevents  the  drive  wheels  from  ex-
cessive  spinning,  thus  helping  the  vehicle  to
start moving from a stopped condition. It also
provides sufficient driving force and steering
performance as the vehicle turns while press-
ing the acceleration pedal.

CAUTION

When driving a vehicle on a snowy or icy
road, be sure to install snow tyres and drive
the vehicle at moderate speeds.

Stability control function

E00619101098

The  stability  control  function  is  designed  to
help the driver maintain control of the vehicle
on slippery roads or during rapid steering ma-
noeuvres.  It  works  by  controlling  the  Plugin
Hybrid  EV  System  output  and  the  brake  on
each wheel.

NOTE

The stability control function operates at
speeds of about 15 km/h (9 mph) or higher.

ASC OFF switch

E00619201871

The ASC is automatically activated when the
operation mode is put in ON. You can deacti-
vate the system by pressing down the ASC
OFF switch for 3 seconds or longer.
When the ASC is deactivated, the display/
indicator will turn on. To reactivate the ASC,
momentarily press the ASC OFF switch; the

indicator is turned off.

CAUTION

For safety reasons, the ASC OFF switch
should be operated when your vehicle is
stopped.

Be sure to keep the ASC on while driving in
normal circumstances.

CAUTION

In  case  you  turn  off  the  ASC  to  move  out
from  mud  or  sand  etc.,  press  the  ASC  OFF
switch  to  activate  the  ASC  quickly  after
moving out, and do not turn off the ASC un-
less it is necessary.

If  you  continue  to  race  the  tyre  by  depress-
ing  the  accelerator  pedal  too  much  while
ASC is turned off, parts such as the transaxle
may  be  damaged  and  this  could  lead  to  an
accident.

NOTE

When  moving  out  of  mud,  sand  or  fresh
snow, pressing the accelerator pedal may not
allow the Plug-in Hybrid EV System output
to  increase.  In  such  situations,  switching  to
“LOCK”  with  the  Drive  mode  switch  and
temporarily  turning  off  the  Active  Stability
Control  (ASC)  with  the  ASC  OFF  switch
will make it easier to move out your vehicle.
Refer  to  “Operation  under  adverse  driving
conditions: If your vehicle becomes stuck in
sand, mud or snow” on page 9-21.

By pressing the “ASC OFF” switch, both the
stability control function and the traction
control function are turned OFF.

If you continue to press the ASC OFF switch
after the ASC is turned off, the “mistaken
operation protection function” will activate
and the ASC will turn back on.

Active stability control (ASC)

7-44

OGGE19E1

Starting and driving

ASC operation indicator or

ASC OFF indicator

E00619301771

ASC operation indicator
The indicator will blink when
the ASC is operating.

ASC OFF indicator
This indicator will turn on
when the ASC is turned off
with the ASC OFF switch.

CAUTION

When indicator blinks, ASC is operating,
which means that the road is slippery or that
your vehicle’s wheels are beginning to slip.
If this happens, drive slower with less accel-
erator input.

CAUTION

If the temperature in the braking system con-
tinues  to  increase  due  to  continuous  brake
control on a slippery road surface, the   in-
dicator will blink. To prevent the brake sys-
tem  from  overheating,  the  brake  control  of
the traction control function will be tempora-
rily suspended.
The  Plug-in  Hybrid  EV  System  control  of
the  traction  control  function  and  normal
brake  operation  will  not  be  affected.  Park
your vehicle in a safe place. When the tem-
perature  in  the  braking  system  has  come
down, the   indicator will be turned off and
the traction control function will start operat-
ing again.

NOTE

The   indicator may turn on when you start
the  Plug-in  Hybrid  EV  System.  This  means
that  the  battery  voltage  momentarily  drop-
ped  when  the  Plug-in  Hybrid  EV  System
was  started.  It  does  not  indicate  a  malfunc-
tion, provided that the indicator goes out im-
mediately.

ASC warning lamp/display

E00619401655

If an abnormal condition occurs in the sys-
tem, the following warning lamp/warning
display will turn on.

Warning lamp

- ASC operation indicator

- ASC OFF indicator

Warning display

CAUTION

The system may be malfunctioning.
Park  your  vehicle  in  a  safe  place  and  stop
the Plug-in Hybrid EV System.
Restart  the  Plug-in  Hybrid  EV  System  and
check  whether  the  display/indicator  goes
out. If they go out, there is no abnormal con-
dition.  If  they  do  not  go  out  or  appear  fre-
quently, it is not necessary to stop the vehi-
cle  immediately,  but  we  recommend  you  to
have your vehicle inspected.

Cruise control*

E00609102584

Cruise control is an automatic speed control
system that keeps a set speed. It can be acti-
vated at approximately 40 km/h (25 mph) or
more.

Cruise control*

7-45

OGGE19E1

Starting and driving

CAUTION

When you do not wish to drive at a set
speed, turn off the cruise control for safety.

Do not use cruise control when driving con-
ditions will not allow you to stay at the same
speed, such as in heavy traffic or on roads
that are winding, icy, snow-covered, wet,
slippery, on a steep downhill slope.

NOTE

Cruise control may not be able to keep your
speed on uphills or downhills.

Your speed may decrease on a steep uphill.
You may use the accelerator pedal if you
want to stay at your set speed.

Your speed may increase to more than the
set speed on a steep downhill. You must use
the brake to control your speed. As a result,
the set speed driving is deactivated.

The regenerative level B0 or B1 cannot be
selected under the cruise control. The buzzer
sounds if you try to select these levels.

Cruise control switches

A- CRUISE CONTROL ON/OFF switch

Used to turn on and off the cruise con-
trol.

B- "SET -" switch

Used to reduce the set speed and to set
the desired speed.

C- "RES +" switch

Used to increase the set speed and to re-
turn to the original set speed.

D- “CANCEL” switch

Used to deactivate the set speed driving.

NOTE

When operating the cruise control switches,
press the cruise control switches correctly.
The set speed driving may be deactivated
automatically if two or more switches of the
cruise control are pressed at the same time.

To activate

E00609302690

1. With the operation mode in ON, press

the CRUISE CONTROL ON/OFF
switch (A) to turn on the cruise control.
The indicator display in the meter cluster
will come on.

Cruise control*

7-46

OGGE19E1

Starting and driving

2. Accelerate or decelerate to your desired

speed,  then  push  down  and  release  the
"SET  -"  switch  (B).  The  vehicle  will
then maintain the desired speed.
The  “SET”  indicator  appears  on  the  in-
formation screen in the meter cluster.

NOTE

When you release the "SET -" switch (B),
the vehicle speed will be set.

To increase the set speed

E00609402008

There are 2 ways to increase the set speed.

"RES +" switch

Push up and hold the "RES +" switch (C)
while driving at the set speed, and your speed
will then gradually increase.

When you reach your desired speed, release
the switch. Your new cruising speed is now
set.

To increase your speed in small amounts,
push up the "RES +" switch (C) for less than
approximately 1 second and release it.
Each time you press the "RES +" switch (C),
your vehicle will go approximately 1.6 km/h
(1 mph) faster.

Accelerator pedal

While driving at the set speed, use the accel-
erator pedal to reach your desired speed and
then push down the "SET -" switch (B) and
release the switch momentarily to set a new
desired cruising speed.

To decrease the set speed

E00609501930

There are 2 ways to decrease the set speed.

"SET -" switch

Push down and hold the "SET -" switch (B)
while driving at the set speed, and your speed
will slow down gradually.

Cruise control*

7-47

OGGE19E1

Starting and driving

When you reach your desired speed, release
the switch. Your new cruising speed is now
set.

To slow down your speed in small amounts,
push down the "SET -" switch (B) for less
than approximately 1 second and release it.
Each time you push down the "SET -" switch
(B), your vehicle will slow down by approxi-
mately 1.6 km/h (1 mph).

Brake pedal

While driving at the set speed, use the brake
pedal,  which  disengages  the  cruise  control,
then  push  down  the  "SET  -"  switch  (B)  and
release  the  switch  momentarily  to  set  a  new
desired cruising speed.

To temporarily increase or de-

crease the speed

E00609601481

To temporarily increase the

speed

Depress the accelerator pedal as you would
normally. When you release the pedal, you
will return to your set speed.

NOTE

In some driving conditions, the set speed
driving may be deactivated. If this happens,
refer to “To activate” on page 7-46 and re-
peat the speed setting procedure.

To temporarily decrease the

speed

Depress the brake pedal to decrease the
speed. To return to the previously set speed,
push up the "RES +" switch (C).

Cruise control*

7-48

OGGE19E1

Starting and driving

Refer to “To resume the set speed” on page
7-50.

To deactivate

E00609702955

The set speed driving can be deactivated as
follows:

Press the CRUISE CONTROL ON/OFF
switch (A) (Cruise control will be turned
off.)

Press the “CANCEL” switch (D).

Depress the brake pedal.

The set speed driving is deactivated automat-
ically in any of the following ways.

When your speed slows to approximate-
ly 15 km/h (9 mph) or more below the
set speed because of a hill, etc.

When your speed slows to approximate-
ly 40 km/h (25 mph) or less.

When the Active Stability Control
(ASC) starts operating.
Refer to “Active stability control (ASC)”
on page 7-43.

WARNING

Although the set speed driving will be de-
activated when shifting to the “N” (NEU-
TRAL)  position,  never  move  the  selector
lever  to  the  “N”  (NEUTRAL)  position
while driving.
You  would  have  no  regenerative  brake
and could cause a serious accident.

CAUTION

When  the  set  speed  driving  is  deactivated
automatically  in  any  situation  other  than
those  listed  above,  there  may  be  a  system
malfunction.
Press  the  CRUISE  CONTROL  ON/OFF
switch to turn off the cruise control and have
your  vehicle  inspected  by  a  MITSUBISHI
MOTORS Authorized Service Point.

NOTE

You cannot operate the regenerative brake
while the adaptive cruise control system
(ACC) is operating.

If you perform the following operation, the
buzzer may sound and the select position
may automatically shift to “N” position.

•

The electrical parking switch is pressed
during driving.

•

The selector lever is shifted to “R” during
driving forward.

•

The selector lever is shifted to “D” during
driving backward.

Cruise control*

7-49

OGGE19E1

Starting and driving

NOTE

•

The selector lever is shifted to “B” when
the select position is in “R”.

To resume the set speed

E00609802161

If the set driving speed is deactivated by the
condition described in “To deactivate” on
page 7-49, you can resume the previously set
speed by pushing up the "RES +" switch (C)
while driving at a speed of approximately
40 km/h (25 mph) or higher. The “SET” indi-
cator appears on the information screen in the
meter cluster.

Under either of the following conditions,
however, using the switch does not allow you
to resume the previously set speed. In these
situations, repeat the speed setting procedure:

The CRUISE CONTROL ON/OFF
switch is pressed.

The operation mode is put in OFF.

The indicator display goes off.

Speed Limiter*

E00633201093

The Speed Limiter is a driver assist function
to prevent from exceeding the speed set by
driver while Plug-in Hybrid EV System pow-
er control.

CAUTION

Because the system does not use service
brake (hydraulic brake), the vehicle speed
may exceed the set speed on the downhill.
If a driver wants to keep the vehicle speed in
such a situation, he/she must put on a service
brake.

If  the  vehicle  speed  exceeds  the  set  speed
(about  3  km/h  (2  mph)),  the  indicator  will
brink in the combination meter.
If  the  vehicle  speed  exceeds  the  set  speed
about  +3  km/h  (2  mph)  more  than  about  5
seconds  after  indicated  alert  message,  beep
alert  is  sounded  for  about  10  seconds  at  the
most.

While  running  without  alert  message,  if  you
decrease  the  set  speed  and  vehicle  speed  is
more than set speed about +3 km/h (2 mph),
alert  message  is  displayed  but  beep  alert  is
delayed.
In  this  case,  when  vehicle  speed  keeps  ex-
ceeding set speed about +3 km/h (2 mph) for
about  30  seconds  after  the  alert  message  is
appeared, beep alert is sounded for about 10
seconds at the most.
If  the  vehicle  speeds  decreases  less  than  set
speeds  after  the  alert  message  is  appeared,
the message is disappeared. When beep alert
is sounding, the beep alert also goes off.

NOTE

However, this gives priority to audio and
visual signal of safety reasons or driver’s de-
mand.

Speed Limiter*

7-50

OGGE19E1

Starting and driving

Speed Limiter control switches

E00633301052

There are 4 switches which relate to the
Speed Limiter on the steering wheel.

A- SPEED LIMITER ON/OFF switch

To turn on/off the Speed Limiter.

B- SET - switch

To set the current vehicle speed to a set
speed decrease the set speed.

C- RES + switch

To resume the Speed Limiter with set
speed memorized or increase the set
speed.

D- CANCEL switch

To cancel the Speed Limiter.

NOTE

Press the switch one by one.

NOTE

The Speed Limiter may be cancelled auto-
matically, if two or more switches are press-
ed at the same time.

Speed Limiter information on

the multi information display

area

E00633401037

The Speed Limiter information is displayed
on the multi information display area in the
combination meter.

A- Control state

There are 3 control states as below.

LIMIT OFF
When  the  Speed  Limiter  is  in
STANDBY, the vehicle speed can ex-
ceed the set speed
LIMIT
When  the  Speed  Limiter  is  in  opera-
tion. The vehicle is controlled in order
not to exceed the set speed.
OVER LIMIT
When  the  vehicle  speed  is  exceeding
the  set  speed  by  more  than  about
3 km/h (2 mph)

B- SPEED LIMITER ON indication

When the Speed Limiter is started up,
the Speed Limiter’s symbol appears.

C- Set speed

Set speed appears if it is stored.

To start up

E00633501025

First of all, press the ON/OFF switch in order
to power up the Speed Limiter when the op-
eration mode in ON.
The Speed Limiter indication will be ap-
peared in the combination meter.

Speed Limiter*

7-51

OGGE19E1

Starting and driving

To activate

E00633601055

Accelerate  or  decelerate  to  your  desired
speed, and push down the SET - switch (B).
the Speed Limiter memorizes the current ve-
hicle  speed  when  you  release  the  SET  -
switch  (B).  Now,  the  Speed  Limiter  starts
controlling  in  order  not  to  exceed  the  set
speed.

If  the  current  vehicle  speed  is  lower  than
about  30  km/h  (19  mph)  (settable  minimum
speed), the set speed is set at about 30 km/h
(19 mph).
The set speed is displayed in the combination
meter.
And,  control  state  “LIMIT”  is  displayed  in
the combination meter.

To increase the set speed

E00633700017

By using the RES + switch

E00633801044

Push up the RES + switch continuously.

Then the set speed displayed in the combina-
tion meter is gradually increased.
If the set speed reaches your desired speed,
release the RES + switch (C).

The set speed is increased each about 5 km/h
(3 mph) per about 0.5 second.
If a driver wants to increase the set speed a
little, push up RES + switch for less than
about 0.5 second and release it.

The set speed is increased 1 km/h (1 mph)
each taps.

By using the CANCEL switch,
the accelerator pedal and the
SET - switch

E00633901058

Press the CANCEL switch (D) to deactivate
the Speed Limiter.

Control state “LIMIT” is disappeared and
change control state “LIMIT OFF” in the
combination meter.

Speed Limiter*

7-52

OGGE19E1

Starting and driving

Mitsubishi Outlander PHEV (2019 year). Instruction - part 17
