Mitsubishi Outlander PHEV (2019 year). Instruction

To release

Manual operation

1. Make sure that the operation mode of the

power switch is ON.

2. Press down the Electric parking brake

switch while depressing the brake pedal.

Automatic operation
When  the  accelerator  pedal  is  depressed
slowly  while  all  of  the  following  conditions
are  met,  the  Electric  parking  brake  is  auto-
matically released.

The Plug-in Hybrid EV System is oper-
ating.

The select position is in the “D”
(DRIVE) or the “R” (REVERSE) posi-
tion.

The driver’s seat belt is fastened.

When the parking brake is released, the brake
warning lamp (red) and the indication lamp
on the Electric parking brake switch go off.
Before driving, be sure that the Electric park-
ing brake is released and the brake warning
lamp is off.

CAUTION

After  the  Electric  parking  brake  switch  has
been operated to apply or release the Electric
parking  brake,  if  the  brake  warning  lamp
(red) and the indicator on the Electric park-
ing  brake  switch  remain  blinking  or  the
Electric  parking  brake  warning  lamp  (yel-
low)  remains  illuminated,  the  Electric  park-
ing brake system may be malfunctioning and
the  Electric  parking  brake  may  not  be  ap-
plied or released. Immediately park your ve-
hicle in a safe place and contact the nearest
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

If  a  vehicle  is  driven  without  releasing  the
Electric  parking  brake,  the  brake  will  over-
heat,  resulting  in  ineffective  braking  and
possible brake failure.

If the brake warning lamp (red) does not go
off after the parking brake has been released,
the brake system may be malfunctioning.
Contact the nearest MITSUBISHI MOTORS
Authorized Service Point.

CAUTION

If  the  acceleration  of  the  vehicle  seems  ab-
normally  slow  after  the  vehicle  has  been
parked  with  the  Electric  parking  brake  ap-
plied  in  cold  weather,  stop  the  vehicle  in  a
safe  place,  then  apply  and  release  the  Elec-
tric parking brake. If the vehicle acceleration
is

still

slow,

contact

the

nearest

MITSUBISHI MOTORS Authorized Serv-
ice Point.

NOTE

When the operation mode of the power
switch is other than ON, the parking brake
cannot be released.

If the Electric parking brake does not auto-
matically release, it may be released by man-
ual operation.

When  the  select  position  is  other  than  the
“P”  (PARK)  position,  if  you  try  to  release
the  Electric  parking  brake  without  depress-
ing the brake pedal, the warning display will
appear.

Parking brake

7-05

OGGE19E1

Starting and driving

NOTE

If you start driving without releasing the
Electric parking brake, the warning display
will appear.

If the driver’s foot contacts the accelerator
pedal in the condition that the Electric park-
ing brake can be released by an automatic
operation, the Electric parking brake may be
released automatically.

Warning display

Warning lamp (yellow)

Warning display

If  there  is  a  malfunction  in  the  system,  the
warning  lamp  will  come  on.  In  addition,  the
warning  display  appears  on  the  information
screen in the multi information display.
Under  normal  conditions,  the  warning  lamp
only  comes  on  when  the  operation  mode  is
put in ON and goes off a few seconds later.

CAUTION

When  the  Electric  parking  brake  warning
lamp (yellow) does not illuminate or remains
illuminated when the operation mode of the
power  switch  is  put  in  ON,  or  comes  on
while  driving,  the  Electric  parking  brake
may not be applied or released. Immediately
contact the nearest MITSUBISHI MOTORS
Authorized  Service  Point.  For  details,  refer
to  “Electric  parking  brake  warning  lamp
(yellow)” on page 6-56.
When  parking  your  vehicle  while  the  Elec-
tric parking brake warning lamp (yellow) is
illuminated,  park  the  vehicle  on  level  and
stable ground, put the select position to “P”
(PARK) and place chocks, blocks, or stones
behind  and  in  front  of  the  tyres  to  prevent
the vehicle from moving.

Parking

E00600602818

To park the vehicle, firmly apply the parking
brake, and then press the electrical parking
switch to lock the wheels.

Parking on a hill

To prevent the vehicle from rolling, follow
these procedures:

Parking on a downhill slope

Turn the front wheels towards the kerb and
move the vehicle forward until the kerb side
wheel gently touches the kerb.
Apply the parking brake and press the electri-
cal parking switch.
If necessary, apply chocks to wheels.

Parking on an uphill slope

Turn the front wheels away from the kerb and
move the vehicle back until the kerb side
wheel gently touches the kerb.
Apply the parking brake and press the electri-
cal parking switch.
If necessary, apply chocks to wheels.

Parking with the engine run-

ning

Never leave the engine running while you
take a short sleep/rest. Also, never leave the
engine running in a closed or poorly ventila-
ted place.

Parking

7-06

OGGE19E1

Starting and driving

WARNING

Leaving the engine running risks injury
or death from accidentally moving the se-
lector lever or the accumulation of toxic
exhaust fumes on the passenger compart-
ment.

Where you park

WARNING

Do  not  park  your  vehicle  in  areas  where
combustible  materials  such  as  dry  grass
or  leaves  can  come  in  contact  with  a  hot
exhaust, since a fire could occur.

When leaving the vehicle

Always carry the key and lock all doors and
the tailgate when leaving the vehicle unatten-
ded.
Always try to park your vehicle in a well lit
area.

CAUTION

When you leave the vehicle, be sure that you
have stopped the Plug-in Hybrid EV System.
The engine may start suddenly by a remain-
ing amount decline of the drive battery.

Steering wheel height and
reach adjustment

E00600701652

1. Release the lever while holding the

steering wheel up.

2. Adjust the steering wheel to the desired

position.

3. Securely lock the steering wheel by pull-

ing the lever fully upward.

A- Locked

B- Release

WARNING

Do not attempt to adjust the steering
wheel while you are driving the vehicle.

Inside rear-view mirror

E00600802315

Adjust the rear-view mirror only after making
any seat adjustments so you have a clear
view to the rear of the vehicle.

Type 1

Type 2

WARNING

Do not attempt to adjust the rear-view
mirror while driving. This can be danger-
ous.
Always adjust the mirror before driving.

Adjust the rear-view mirror to maximize the
view through the rear window.

Steering wheel height and reach adjustment

7-07

OGGE19E1

Starting and driving

To adjust the vertical mirror

position

It is possible to move the mirror up and down
to adjust its position.

To adjust the mirror position

It is possible to move the mirror up/down and
left/right to adjust its position.

To reduce the glare

Type 1
The lever (A) at the bottom of the mirror can
be used to adjust the mirror to reduce the
glare from the headlamps of vehicles behind
you during night driving.

1- Normal
2- Anti-glare

Type 2

When the headlamps of the vehicles behind
you are very bright, the reflection factor of
the rear-view mirror is automatically changed
to reduce the glare.

When the operation mode of the power
switch is put in ON, the reflection factor of
the mirror is automatically changed.

NOTE

Do not hang items on, or spray glass cleaner
on the sensor (1), as reduced sensitivity
could result.

Inside rear-view mirror

7-08

OGGE19E1

Starting and driving

Outside rear-view mirrors

E00600900628

To adjust the mirror position

E00601001737

The outside rear-view mirrors can be operat-
ed when the operation mode is put in ON or
ACC.

WARNING

Do not attempt to adjust the rear-view
mirrors while driving. This can be dan-
gerous.
Always adjust the mirrors before driving.

Your vehicle is equipped with convex type
mirrors.
Please  take  into  consideration,  that  ob-
jects you see in the mirror will look small-
er  and  farther  away  compared  to  a  nor-
mal flat mirror.
Do  not  use  this  mirror  to  estimate  dis-
tance of following vehicles when changing
lanes.

1. Place the lever (A) to the same side as

the mirror whose adjustment is desired.

L- Left outside mirror adjustment
R- Right outside mirror adjustment

2. Press the switch (B) to the left, right, up

or down to adjust the mirror position.

1- Up
2- Down
3- Right
4- Left

3. Return the lever (A) back to the middle

position (•).

Retracting and extending the

outside mirrors

E00601102272

The outside mirror can be folded in towards
the side window to prevent damage when
parking in narrow areas.

CAUTION

Do not drive the vehicle with the mirror fol-
ded in.
The lack of rearward visibility normally pro-
vided by the mirror could lead to an acci-
dent.

Retracting and extending the

mirrors using the mirror retrac-

tor switch

With the operation mode in ON or ACC,
push the mirror retractor switch to retract the
mirrors. Push it again to extend the mirrors to
their original positions.
After placing the operation mode in OFF, it is
possible to retract and extend the mirrors us-
ing the mirror retractor switch for approxi-
mately 30 seconds.

Outside rear-view mirrors

7-09

OGGE19E1

Starting and driving

CAUTION

It  is  possible  to  retract  and  extend  the  mir-
rors by hand. After retracting a mirror using
the  mirror  retractor  switch,  however,  you
should  extend  it  by  using  the  switch  again,
not  by  hand.  If  you  extended  the  mirror  by
hand  after  retracting  it  using  the  switch,  it
would not properly lock in position. As a re-
sult,  the  mirror  could  move  because  of  the
wind or vibration while you are driving, and
this may limit the driver’s rearward visibili-
ty.

NOTE

Be careful not to get your hands trapped
while a mirror is moving.

If you move a mirror by hand or it moves af-
ter hitting a person or object, you may not be
able to return it to its original position using
the mirror retractor switch. If this happens,
push the mirror retractor switch to place the
mirror in its retracted position and then push
the switch again to return the mirror to its
original position.

When freezing has occurred and mirrors fail
to operate as intended, please refrain from
repeated pushing of the retractor switch as
this action can result in burn-out of the mir-
ror motor circuits.

Retracting and extending the

mirrors without using the mir-

ror retractor switch

The  mirrors  automatically  retract  or  extend
when the doors and tailgate are locked or un-
locked  using  the  remote  control  switches  or
the keyless operation function of the keyless
operation system.
Refer to “Keyless operation system: To oper-
ate  using  the  key-less  operation  function,
Keyless  entry  system”  on  pages  4-09  and
4-03.

NOTE

Functions  can  be  modified  as  stated  below.
Please  consult  a  MITSUBISHI  MOTORS
Authorized Service Point.
On  vehicles  equipped  with  the  Smartphone
Link  Display  Audio  or  the  MITSUBISHI
Multi-Communication  System  (MMCS),
screen  operations  can  be  used  to  make  the
adjustment.  Refer  to  the  separate  owner’s
manual for details.

•

Automatically extend when the operation
mode is put in ON, and automatically re-
tract when the driver’s door is opened af-
ter the operation mode is put in OFF.

•

Automatically extend when the vehicle
speed reaches 30 km/h (19 mph).

•

Deactivate the automatic extension func-
tion.

Heated mirror

E00601201755

To  demist  or  defrost  the  outside  rear-view
mirrors,  press  the  rear  window  demister
switch.
The indication lamp (A) will illuminate while
the demister is on.
The heater will be turned off automatically in
approximately  15  to  20  minutes  depending
on the outside temperature.

Outside rear-view mirrors

7-10

OGGE19E1

Starting and driving

NOTE

The  heated  mirror  can  be  set  so  that  it  can
turn on automatically only once if the ambi-
ent  temperature  becomes  low,  when  the  op-
eration mode is put in ON.
For further information, we recommend you
to  consult  a  MITSUBISHI  MOTORS  Au-
thorized Service Point. On vehicles equipped
with the Smartphone Link Display Audio or
the  MITSUBISHI  Multi-Communication
System  (MMCS),  screen  operations  can  be
used  to  make  the  adjustment.  Refer  to  the
separate owner’s manual for details.

Power switch

E00631801617

In  order  to  prevent  theft,  the  Plug-in  Hybrid
EV  System  will  not  start  unless  a  preregis-
tered  keyless  operation  key  is  used.  (Immo-
bilizer function)

If you are carrying the keyless operation key,
you can start the Plug-in Hybrid EV System.

CAUTION

The  indication  lamp  (A)  will  flash  orange
when  there  is  a  problem  or  malfunction  in
the keyless operation system. Never drive if
the  indication  lamp  on  the  power  switch  is
flashing  orange.  Immediately  contact  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

If the power switch operation is not smooth
and feels like it is sticking, do not operate
the

switch.

Immediately

contact

MITSUBISHI MOTORS Authorized Serv-
ice Point.

NOTE

When operating the power switch, press the
switch  all  the  way  in.  If  the  switch  is  not
fully pressed, the Plug-in Hybrid EV System
may not start or the operation mode may not
change.  If  the  power  switch  is  pressed  cor-
rectly,  there  is  no  need  to  hold  the  power
switch down.

When the battery in the keyless operation
key has worn out, or the keyless operation
key is out of the vehicle, a warning display
will appear.

Operation mode of the power

switch and its function

OFF

The  indication  lamp  on  the  power  switch
turns off.
The  operation  mode  cannot  be  put  in  OFF
unless  the  electrical  parking  switch  is  press-
ed.

Power switch

7-11

OGGE19E1

Starting and driving

ACC

Electrical devices such as the audio and ac-
cessory socket can be operated. Can be used
when the Ready indicator is off.
The indication lamp on the power switch illu-
minates orange.

All vehicle’s electrical devices can be operat-
ed.
The indication lamp on the power switch illu-
minates blue. The indication lamp goes off
when the Plug-in Hybrid EV System is oper-
ating.

NOTE

Your  vehicle  is  equipped  with  an  electronic
immobilizer.
To  start  the  Plug-in  Hybrid  EV  System,  the
ID  code  which  the  transponder  inside  the
key sends, must match the one registered in
the  immobilizer  computer.  Refer  to  “Elec-
tronic  immobilizer  (Anti-theft  starting  sys-
tem)” on page 4-03.

Changing the operation mode

E00631901559

If you press the power switch without de-
pressing the brake pedal, you can change the
operation mode in the order of OFF, ACC,
ON, OFF.

CAUTION

When the Plug-in Hybrid EV System is not
operating, put the operation mode in OFF.
Leaving the operation mode in ON or ACC
for a long time when the Plug-in Hybrid EV
System is not operating may cause the auxil-
iary battery to discharge, making it impossi-
ble to start the Plug-in Hybrid EV System.

CAUTION

When  the  auxiliary  battery  is  disconnected,
the  current  operation  mode  is  memorized.
After  reconnecting  the  auxiliary  battery,  the
memorized  mode  is  selected  automatically.
Before  disconnecting  the  auxiliary  battery
for  repair  or  replacement,  make  sure  to  put
the operation mode in OFF.
Be  careful  if  you  are  not  sure  which  opera-
tion mode the vehicle is in when the auxili-
ary battery is run down.

The operation mode cannot be changed from
OFF to ACC or ON if the keyless operation
key is not detected to be in the vehicle. Refer
to  “Keyless  operation  system:  Operating
range  for  starting  the  Plug-in  Hybrid  EV
System  and  changing  the  operation  mode”
on page 4-08.

NOTE

If the operation mode cannot be changed to
OFF, perform the following procedure.

Press the electrical parking switch
and lock the wheels, then change the
operation mode to OFF.

One of the other causes could be low
auxiliary  battery  voltage.  If  this  oc-
curs,  the  keyless  entry  system  and
keyless  operation  will  also  not  oper-
ate.

Contact a MITSUBISHI MOTORS Author-
ized Service Point.

Power switch

7-12

OGGE19E1

Starting and driving

ACC power auto-cutout func-

tion

E00632801265

After approximately 30 minutes have elapsed
with  the  operation  mode  in  ACC,  the  func-
tion automatically cuts out the power for the
audio  system  and  other  electric  devices  that
can be operated with that position.
When  the  power  switch  operates  again,  the
power is supplied again.

NOTE

It is possible to modify functions as follows:

•

The time until the power cuts out can be
changed to approximately 60 minutes.

•

The ACC power auto-cutout function can
be deactivated.
For details, we recommend you to consult
a  MITSUBISHI  MOTORS  Authorized
Service Point.
On  vehicles  equipped  with  the  Smart-
phone  Link  Display  Audio  or  the
MITSUBISHI Multi-Communication Sys-
tem  (MMCS),  screen  operations  can  be
used to make the adjustment.
Refer  to  the  separate  owner’s  manual  for
details.

Operation mode OFF reminder

system

E00632201445

When the operation mode is in any mode oth-
er than OFF; if you try to lock the doors and
tailgate by pressing the driver’s or front pas-
senger’s door lock/unlock switch, or the tail-
gate LOCK switch, a warning display will
appear, and the outer buzzer will sound pre-
venting you from locking the doors and tail-
gate.

Operation mode ON reminder

system

E00632301068

If the driver’s door is opened while the Plug-
in Hybrid EV System is stopped and the op-
eration mode in any mode other than OFF,
the operation mode ON reminder inner buz-
zer sounds intermittently to remind you to put
the operation mode in OFF.

Starting and stopping the
Plug-in Hybrid EV System

E00620601295

Starting the Plug-in Hybrid EV

System

E00620701661

CAUTION

When the Plug-in Hybrid EV System warn-
ing lamp comes on while the READY indi-
cator  is  on,  avoid  high-speed  driving  and
have  your  vehicle  inspected  by  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice  Point  as  soon  as  possible.  (Refer  to
“Plug-in  Hybrid  EV  System  warning  lamp”
on page 6-57.)

Never attempt to start the engine by pushing
or pulling the vehicle.

1. Check that the EV charging cable is not

connected to your vehicle.

2. Fasten the seat belt.
3. Make sure the parking brake is applied.
4. Press and hold the brake pedal down

firmly with your right foot.

Starting and stopping the Plug-in Hybrid EV System

7-13

OGGE19E1

Starting and driving

5. When you press the power switch while

depressing the brake pedal, the READY
indicator in the meter blinks and the acti-
vation of Plug-in Hybrid EV System
starts.

6. When the READY indicator changes

from blinking to staying on, the startup
of Plug-in Hybrid EV System is activa-
ted and the vehicle is now ready to drive.

CAUTION

Do not press the power switch while holding
the select lever at the operated position.

NOTE

Continue to depress the brake pedal until the
READY indicator in the meter stays on.

After the Plug-in Hybrid EV System has not
started for a while, the brake pedal effort
needed to start the Plug-in Hybrid EV Sys-
tem may become greater.
If this occurs, depress the brake pedal more
than usual.

You can drive your vehicle even if the en-
gine is stopped.

The Plug-in Hybrid EV System can be star-
ted in any operation mode.

If the READY indicator does not come on,
check the select position indicator. If the in-
dicator does not indicate “P”, press the elec-
trical parking switch to display “P” position.

NOTE

If the READY indicator does not come on,
turn the power switch to OFF once and, after
a while, press the power switch to start Plu-
gin Hybrid EV System.

Stopping the Plug-in Hybrid

EV System

E00620801457

1. Stop your vehicle completely.
2. Apply the parking brake firmly while

depressing the brake pedal.

3. After pressing the electrical parking

switch, press the power switch to stop
the Plug-in Hybrid EV System. (Refer to
“Electrical Parking switch” on page
7-18.)

WARNING

Never stop the Plug-in Hybrid EV System
during running except in an emergency.
The effectiveness of the brake becomes
very poor and the steering wheel becomes
very heavy, which can easily lead to an ac-
cident.

NOTE

Do not operate the power switch during run-
ning except in an emergency. If you have to
stop the Plug-in Hybrid EV System because
of  an  emergency  during  operation,  continue
to  press  the  power  switch  for  three  seconds
or  longer  or  press  the  power  switch  three
times  or  more  quickly.  The  Plug-in  Hybrid
EV  System  stops,  the  operation  mode  turns
to ACC, and the selector lever position shifts
to the “P” position at very slow speed.

If you press the power switch when the se-
lector lever position is other than the “P” po-
sition while your vehicle is stopped, the se-
lector lever position automatically shifts to
the “P” position, Plug-in Hybrid EV System
stops, and the power mode turns to “OFF”.

If  the  parking  lock  mechanism  is  faulty,  a
warning  is  displayed  on  the  information
screen  in  the  multi-information  display.
When this warning is displayed, the Plug-in
Hybrid EV System cannot be stopped unless
you  apply  the  parking  brake  and  then  press
the  power  switch.  Park  on  a  flat  place  with
the  parking  brake  securely  applied.  Have
your  vehicle  inspected  by  a  MITSUBISHI
MOTORS Authorized Service Point.

Starting and stopping the Plug-in Hybrid EV System

7-14

OGGE19E1

Starting and driving

If the keyless operation key is

not operating properly

E00632901237

Insert the keyless operation key into the key
slot.  Starting  the  Plug-in  Hybrid  EV  System
and  changing  the  operation  mode  should  be
now possible.
Remove  the  keyless  operation  key  from  the
key slot after starting the Plug-in Hybrid EV
System or changing the operation mode.

NOTE

Do not insert into the key slot anything other
than the keyless operation key. This could
cause damage or a malfunction.

NOTE

Remove  the  object  or  additional  key  from
the  the  keyless  operation  key  before  insert-
ing  the  key  into  the  key  slot.  The  vehicle
may not be able to receive the registered ID
code from the registered key. Therefore, the
Plug-in Hybrid EV System may not start and
the operation mode may not change.

The keyless operation key is fixed in the key
slot when inserted in the illustrated direc-
tion. Simply pull out the key to remove it
from the key slot.

Keyless operation key remind-

E00633001046

If the operation mode is in OFF and the driv-
er’s door is opened with the keyless operation
key in the key slot, the outer buzzer sounds
for approximately 3 seconds and the inner
buzzer sounds for approximately 1 minute or
a warning display will appear to remind you
to remove the key.

Selector lever (Joystick
type)

E00636100100

Selector lever operation

E00636200097

The selector lever always returns to its home
( ● ) position when it is released.

Selector lever (Joystick type)

7-15

OGGE19E1

Starting and driving

The position you select with the selector lev-
er will be illuminated on the shift position
panel shown in the illustration below.

Home
position

Move the selector lever slowly and securely
in the following method.

To select “D” (DRIVE) or “R” (RE-
VERSE):
Move the selector lever in the direction
of the arrow.

To select “N” (NEUTRAL):
Move the selector lever in the direction
of the arrow and hold it for a while.

To select “B” (REGENERATIVE
BRAKE):
Move the selector lever in the direction
of the arrow.

The  “B”  (REGENERATIVE  BRAKE)  posi-
tion can only be selected while the select po-
sition is in the “D” (DRIVE) position. When
the  selector  lever  is  moved  to  the  “B”  posi-
tion,  the  regenerative  brake  force  will  be-
come stronger.
When the selector lever is again moved to the
“B”  position,  the  maximum  regenerative
brake force will be used.
To return to the “D” position, use the selector
lever to select the “D” position.

NOTE

If you operate the selector lever to “B” twice
too quickly, the regenerative brake force
may not become the maximum.

WARNING

Do not replace the selector lever knob
with anything other than a MITSUBISHI
MOTORS genuine part. In addition, do
not hang an object on the selector lever as
it may be the cause of an accident.

When you shift the selector lever to “D”
or “R” position, always depress the brake
pedal with your right foot for your safety.
Never shift the lever while depressing the
accelerator pedal. Doing so will start your
vehicle abruptly, which may lead to a seri-
ous accident. It may also be a cause of
failure of the vehicle.

NOTE

You cannot operate the regenerative brake
while the adaptive cruise control system
(ACC) is operating.

Every time while operating the selector lev-
er, be sure to check the position displayed on
the indicator.

If  you  perform  the  following  operation,  the
buzzer  may  sound  and  the  select  position
may  automatically  shift  to  the  “N”  (NEU-
TRAL) position.

•

If the electrical parking switch is pressed
while the vehicle is in motion.

•

If the selector lever is moved to the “R”
(REVERSE) position while the vehicle is
moving forward.

•

If the selector lever is moved to the “D”
(DRIVE) position while the vehicle is
moving backward.

•

If  the  selector  lever  is  moved  to  the  “B”
(REGENERATIVE  BRAKE)  position  af-
ter  it  had  been  shifted  to  the  “R”  (RE-
VERSE) position.

If you perform the following operation, the
buzzer sounds and the selector lever opera-
tion is cancelled.

•

When in the “P” (PARK) position, the se-
lector lever is moved without depressing
the brake pedal.

•

When in the “P” (PARK) or “N” (NEU-
TRAL) position, the selector lever is
moved

“B”

(REGENERATIVE

BRAKE).

Selector lever (Joystick type)

7-16

OGGE19E1

Starting and driving

NOTE

•

When the operation mode is in the “ON”
position with the Plug-in Hybrid EV Sys-
tem not operated, the selector lever is
shifted to the “D” (DRIVE) or “R” (RE-
VERSE) position.

If you shift and hold the selector lever for
approximately 10 seconds or longer, the buz-
zer sounds.
The buzzer stops sounding when you release
the selector lever.

If the driver’s door is opened while the vehi-
cle  is  stopped  or  is  running  at  very  low
speed  with  the  select  position  in  other  than
the  “P”  (PARK)  position  and  the  READY
indicator  in  the  meter  is  illuminating,  the
buzzer sounds. The buzzer stops sounding if
you close the door or shift the selector lever
to “P” (PARK).

Select position indicator

E00636300102

This indicator displays the selector lever po-
sition in the meter.

NOTE

When the “B” position is selected, the selec-
ted regenerative brake force position is also
displayed at “B” position.

You cannot operate the regenerative brake
while the adaptive cruise control system
(ACC) is operating.

Selector lever positions

E00636400099

“P” PARK

The wheels are locked. When you park your
vehicle, be sure to apply the parking brake
and press the electrical parking switch.

“R” REVERSE

This position is to back up.

“N” NEUTRAL

No power is transmitted to the wheels. The
wheels are not locked.

WARNING

Never move the selector lever to the “N”
(NEUTRAL) position while driving, you
will lose regenerative braking.

Always keep your right foot on the brake
pedal when shifting into or out of “N”, to
minimize the risk of loss of control.

“D” DRIVE

This position is for normal driving.

“B” REGENERATIVE BRAKE

This position is for the regenerative braking.
You can adjust the regenerative braking force
up to two levels.
Refer to “Selector lever operation” on page
7-15.
Refer to “Braking: When driving downhill”
on page 7-34.

Select position indicator

7-17

OGGE19E1

Starting and driving

WARNING

Sudden regenerative brake may cause the
tyres to skid.
Select this position according to the road
conditions and vehicle speed.

CAUTION

When  the  capacity  of  the  drive  battery  is
close  to  full  or  when  the  drive  battery  tem-
perature  is  low,  the  regenerative  brake  will
become less effective.
In such case, depress the brake pedal strong-
ly.

NOTE

If a large regenerative braking force is gen-
erated by using the selector lever or the re-
generative braking level selector, the stop
lamps will be automatically illuminated.

Electrical Parking switch

E00636600062

When you park your vehicle, be sure to apply
the  parking  brake  and  press  the  electrical
parking switch to lock the wheels. The indi-
cator  on  the  switch  illuminates  in  green  and
the  select  position  indicator  displays  “P”  on
the information screen in the meter.

CAUTION

If  you  operate  the  electrical  parking  switch
and the select lever repeatedly within a short
time, the shifting from the “P” position or to
the  “P”  position  is  restrained  for  a  certain
period  for  the  system  protection.  In  such  a
case,  wait  for  a  while  and  then  perform  the
operation.

If  the  parking  lock  mechanism  is  faulty,  a
warning  is  displayed  on  the  information
screen  in  the  multi-information  display.
When  this  warning  is  displayed,  park  on  a
flat  place  with  the  parking  brake  securely
applied.  Have  your  vehicle  inspected  by  a
MITSUBISHI  MOTORS  Authorized  Serv-
ice Point.

If you press the electrical parking switch be-
fore your vehicle stops completely, the vehi-
cle makes a sudden stop, which may cause
injury to passengers. This also can be a
cause of failure of the vehicle.

Do not place an object around the electrical
parking switch. The electrical parking switch
may be pressed by the object when you
place it there or when you somehow touch it.
This will cause unintentional shifting to “P”
or “N” position, which may lead to an acci-
dent.

Electrical Parking switch

7-18

OGGE19E1

Starting and driving

CAUTION

Be careful not to spill beverages, etc. around
the electrical parking switch. The electrical
parking switch may be stuck to the pressed
position when it is pressed.

NOTE

When the selector lever is shifted from the
“P” position or to the “P” position, operating
noise and vibration of the parking lock are
felt, but this is normal.

Electrical Parking switch re-

minder buzzer

If the driver’s door is opened with the select
position other than “P” when the vehicle is at
a stop, the buzzer sounds to warn to press the
electrical parking switch.

Regenerative braking level
selector (paddle type)*

E00636700148

Regenerative  braking  level  selector  can
quickly  change  the  regenerative  brake  force
keeping  your  hand  on  the  steering  wheel
when you release your foot from the acceler-
ator pedal while driving.

By pulling the regenerative braking level se-
lector,  the  brake  force  (amount  of  electrical
energy to charge the drive battery) can be ad-
justed according to the driving condition such
as before a curve or a downhill.
Regenerative  braking  level  can  be  switched
in the 6 level from B0 (without regenerative
brake  force)  to  B5  (large  regenerative  brake
force).

increase in
regenerative force

decrease in
regenerative force

CAUTION

If a large regenerative brake force is applied
on a slippery road, tyres may skid. Always
drive safely in accordance with the prevail-
ing road condition.

If you operate the right and left paddles si-
multaneously, the regenerative brake force
level may not change.

NOTE

Repeated continuous operation of a paddle
will continuously change the brake force
levels.

If you turn on the SPORT mode, the regener-
ative braking force level will automatically
switch to B5. After the regenerative braking
force level is switched, the regenerative
braking level can be adjusted by the regener-
ative braking level selector.

If you turn on the cruise control when the
level B0 or B1 (smaller regenerative brake
force) is selected, the level is returned to the
normal level B2 automatically.

When stronger regenerative braking is gen-
erated, the stop lamps will illuminate even
when the brake pedal is not depressed.

Under the cruise control, the level B0 or B1
cannot be selected. The buzzer sounds if you
try to select these levels.

Regenerative braking level selector (paddle type)*

7-19

OGGE19E1

Starting and driving

NOTE

On vehicles with the adaptive cruise control
system (ACC), you cannot control the regen-
erative  brake  force  level  while  the  adaptive
cruise  control  system  (ACC)  is  operating.
The  buzzer  sounds  if  you  operate  the  pad-
dles.

To decrease regenerative brake

force

Each time you pull the “+” paddle towards
you, the regenerative brake force lowers by
one level.

To increase regenerative brake

force

Each time you pull the “−” paddle towards
you, the regenerative brake force rises by one
level.

To return to the normal regen-

erative brake force level of B2

Pull the “+” paddle for approximately 2 sec-
onds or longer. The select lever position indi-
cator displays “D”.

S-AWC (Super All Wheel
Control)

E00622601185

S-AWC  is  an  integrated  vehicle  dynamics
control  system  that  helps  enhance  driving
performance, cornering performance, and ve-
hicle  stability  over  a  wide  range  of  driving
conditions through integrated management of
the  twin  motor  4WD,  the  AYC  (Active  Yaw
Control), the ABS and the ASC.

S-AWC (Super All Wheel Control)

7-20

OGGE19E1

Starting and driving

Mitsubishi Outlander PHEV (2019 year). Instruction - part 15
