Mitsubishi L200 (2018 year). Instruction

NOTE

Secure the tow rope to the same side towing
hook, to keep the tow rope as straight as pos-
sible.

2. Keep the engine running.

If the engine is not running, perform the
following  operation  to  unlock  the  steer-
ing wheel.
[Except for vehicles equipped with key-
less operation system]
On  vehicles  with  manual  transmission,
turn the ignition switch to the “ACC” or
“ON” position.
On  vehicles  with  automatic  transmis-
sion,  turn  the  ignition  switch  to  the
“ON” position.
[For vehicles with the keyless operation
system]
On  vehicles  with  manual  transmission,
put the operation mode in ACC or ON.
On  vehicles  with  automatic  transmis-
sion, put the operation mode in ON.

NOTE

For vehicles equipped with the Auto Stop &
Go (AS&G) system, press the “Auto Stop &
Go (AS&G) OFF” switch to deactivate the
Auto Stop & Go (AS&G) system before
stopping the vehicle.
Refer to “To deactivate” on page 6-26.

WARNING

When the engine is not running, the brake
booster  and  power  steering  pump  do  not
operate. This means higher brake depres-
sion  force  and  higher  steering  effort  are
required.  Therefore,  vehicle  operation  is
very difficult.

CAUTION

Do  not  leave  the  ignition  switch  in  the
“LOCK”  position  or  the  operation  mode  in
OFF.  The  steering  wheel  will  lock,  causing
loss of control.

3. Place the gearshift lever in the “N”

(Neutral) position (manual transmission)
or the selector lever in the “N” (NEU-
TRAL) position (automatic transmis-
sion).

4. On 4WD vehicles, set the drive mode se-

lector to the “2H” position.

5. Turn on the hazard warning lamps if re-

quired by law. (Follow the local driving
laws and regulations.)

6. During towing make sure that close con-

tact is maintained between the drivers of
both vehicles, and that the vehicles trav-
el at low speed.

WARNING

Avoid sudden braking, acceleration and
steering wheel movements; such driving
operation could cause damage to the tow-
ing hook or tow rope.
People in the vicinity could be injured as a
result.

When going down a long slope, the brakes
may overheat, reducing effectiveness.
Have your vehicle transported by a tow
truck.

CAUTION

The person in the vehicle being towed must
pay attention to the brake lamps of the tow-
ing vehicle and make sure the rope never be-
comes slack.

When a vehicle with an automatic transmis-
sion  is  to  be  towed  by  another  vehicle  with
all the wheels on the ground, make sure that
the  towing  speed  and  distance  given  below
are never exceeded, avoiding damage to the
transmission.

Towing speed: 30 km/h (19 mph)
Towing distance: 80 km (50 miles)

For  the  towing  speed  and  the  towing  dis-
tance, follow the local driving laws and reg-
ulations.

Towing

8-26

OKTE18E1

For emergencies

If your vehicle tows another ve-

hicle (vehicles with rear towing

hook only)

The rear towing hook is located as shown in
the illustration. Secure the tow rope to the
rear towing hook.
Otherwise, the instructions are the same as
for “When being towed by another vehicle”.

NOTE

Using any part other than the designated
towing hook could result in damage to the
vehicle body.

CAUTION

On vehicles with Super Select 4WD II, when
you are going to tow another vehicle, set the
drive mode-selector to “4H” position.
Selecting  “2H”  drive  may  increase  the  dif-
ferential  oil  temperature,  resulting  in  possi-
ble damage to the driving system.
Further,  the  drive  train  will  be  subjected  to
excessive  loading  possibly  leading  to  oil
leakage, component seizure, or other serious
faults.

NOTE

Do not tow a vehicle heavier than your own
vehicle.

Operation under adverse
driving conditions

E00801704085

On a flooded road

Avoid flooded roads. In the event driv-
ing flooded roads, doing so may cause
the following serious damage to the ve-
hicle.

• Engine stalling
• Short in electrical components
• Engine damage caused by water im-

mersion

After driving on flooded roads, be sure
to have an inspection at a MITSUBISHI
MOTORS Authorized Service Point and
take the necessary measures or repair.

Operation under adverse driving conditions

8-27

OKTE18E1

For emergencies

On a wet road

When driving in rain or on a road with
many puddles a layer of water may form
between the tyres and the road surface.
This reduces a tyre’s frictional resistance
on the road, resulting in loss of steering
stability and braking capability.

To cope with this, observe the following
items:

(a) Drive your vehicle at a slow speed.
(b) Do not drive on worn tyres.
(c) Always maintain the specified tyre
inflation pressures.

On a snow-covered or frozen

road

When driving on a snow-covered or fro-
zen road, it is recommended that you use
snow tyres or snow traction device (tyre
chains).
Refer to the “Snow tyres” and “Snow
traction device (tyre chains)” sections.

Avoid high-speed operation, sudden ac-
celeration, abrupt brake application and
sharp cornering.

Depressing the brake pedal during travel
on  snowy  or  icy  roads  may  cause  tyre
slippage and skidding. When traction be-
tween  the  tyres  and  the  road  is  reduced
the wheels may skid and the vehicle can-
not readily be brought to a stop by con-
ventional  braking  techniques.  Braking
will differ, depending upon whether you
have  anti-lock  brake  system  (ABS).  If
you do have ABS, brake by pressing the
brake pedal hard, and keeping it pressed.
If you do not have ABS, pump the brake
pedal  with  short  rapid  jabs,  each  time
fully  applying  and  fully  releasing  for
greatest effect.

Allow extra distance between your vehi-
cle and the vehicle in front of you, and
avoid sudden braking.

Accumulation of ice on the braking sys-
tem can cause the wheels to lock. Pull
away from a standstill slowly after con-
firming safety around the vehicle.

CAUTION

Do not press the accelerator pedal rapidly. If
the wheels break free of the ice, the vehicle
could suddenly start moving and possibly
cause an accident.

On a bumpy or rutted road

Drive as slow as possible when driving on
bumpy or rutted roads.

CAUTION

The impact on tyres and/or wheels when
driving on a bumpy or rutted road can dam-
age the tyre and/or wheel.

Operation under adverse driving conditions

8-28

OKTE18E1

For emergencies

Vehicle care precautions

E00900102018

In  order  to  maintain  the  value  of  your  vehi-
cle, it is necessary to perform regular mainte-
nance  using  the  proper  procedures.  Always
maintain your vehicle in compliance with en-
vironmental  pollution  control  regulations.
Carefully select the materials used for wash-
ing,  etc.,  to  be  sure  that  they  do  not  contain
corrosives. If in doubt, we recommend you to
consult a specialist for selection of these ma-
terials.

CAUTION

Cleaning products can be dangerous. Always
follow the instructions of the cleaning prod-
uct supplier.

To avoid damage, never use the following to
clean your vehicle:

•

Petrol

•

Paint Thinner

•

Benzine

•

Kerosene

•

Turpentine

•

Naphtha

•

Lacquer Thinner

•

Carbon Tetrachloride

•

Nail Polish Remover

•

Acetone

Cleaning the interior of your
vehicle

E00900201706

After cleaning the interior of your vehicle
with water, cleaner or similar, wipe and dry
in a shady, well-ventilated area.

NOTE

To clean the inside of the rear window, al-
ways use a soft cloth and wipe the window
glass along the demister heater element so as
not to cause damage.

CAUTION

Do  not  use  organic  substances  (solvents,
benzine,  kerosene,  alcohol,  petrol,  etc.)  or
alkaline or acidic solutions.
These  chemicals  can  cause  discolouring,
staining or cracking of the surface.
If you use cleaners or polishing agents, make
sure their ingredients do not include the sub-
stances mentioned above.

Plastic, fabric and flocked

parts

E00900301505

1. Lightly wipe these off with a soft cloth

soaked in a mild soap and water solu-
tion.

2. Dip cloth in fresh water and wring it out

well. Using this cloth, wipe off the deter-
gent thoroughly.

NOTE

Do not use cleaners, conditioners, and pro-
tectants containing silicons or wax.
Such products, when applied to the instru-
ment panels or other parts, may cause reflec-
tions on the windscreen and obscure vision.
Also, if such products get on the switches of
the electrical accessories, it may lead to fail-
ure of these accessories.

Upholstery

E00900501217

1. To maintain the value of your new vehi-

cle,  handle  the  upholstery  carefully  and
keep the interior clean.
Use a vacuum cleaner and brush to clean
the  seats.  If  stained,  synthetic  leather
should  be  cleaned  with  an  appropriate
cleaner.  Cloth  fabrics  can  be  cleaned
with  either  upholstery  cleaner  or  a  mild
soap and water solution.

2. Clean the carpeting with a vacuum

cleaner and remove any stains with car-
pet cleaner. Oil and grease can be re-
moved by lightly dabbing with a clean
colourfast cloth and stain remover.

Vehicle care precautions

9-02

OKTE18E1

Vehicle care

Genuine leather*

E00900601999

1. To clean, lightly wipe the leather with a

soft cloth soaked in a mild soap and wa-
ter solution.

2. Dip cloth in fresh water and wring it out

well. Using this cloth, wipe off the deter-
gent thoroughly.

3. Apply leather protecting agent to the

genuine leather surface.

NOTE

If genuine leather is wet with water or is
washed in water, wipe off water as quickly
as possible with a dry, soft cloth.
If left damp, mildew may grow.

Organic solvents such as benzine, kerosene,
alcohol and petrol, acid or alkaline solvents
may discolour the genuine leather surface.
Be sure to use neutral detergents.

Remove dirty patches or oil substances
quickly as they can stain genuine leather.

The genuine leather surface may harden and
shrink if it is exposed to direct sun for long
hours. When your vehicle is parked, place it
in the shade as much as possible.

When the temperature of the vehicle interior
rises in summer, vinyl products left on the
genuine leather seat may deteriorate and
stick to the seat.

Cleaning the exterior of
your vehicle

E00900701264

If the following is left on your vehicle, it may
cause corrosion, discolouration and stains,
wash the vehicle as soon as possible.

Seawater, road deicing products.

Soot and dust, iron powder from facto-
ries, chemical substance (acids, alkalis,
coaltar, etc.).

Droppings from birds, carcasses of in-
sects, tree sap, etc.

Washing

E00900903794

Chemicals  contained  in  the  dirt  and  dust
picked up from the road surface can damage
the paint coat and body of your vehicle if left
in prolonged contact.
Frequent washing and waxing is the best way
to  protect  your  vehicle  from  this  damage.
This  will  also  be  effective  in  protecting  it
from  environmental  elements  such  as  rain,
snow, salt air, etc.
Do  not  wash  the  vehicle  in  direct  sunlight.
Park  the  vehicle  in  the  shade  and  spray  it
with  water  to  remove  dust.  Next,  using  an
ample amount of clean water and a car wash-
ing  brush  or  sponge,  wash  the  vehicle  from
top to bottom.

Use  a  mild  car  washing  soap  if  necessary.
Rinse  thoroughly  and  wipe  dry  with  a  soft
cloth.  After  washing  the  vehicle,  carefully
clean the joints and flanges of the doors, bon-
net and other sections where dirt is likely to
remain.

CAUTION

When washing the under side of your vehi-
cle or wheel, be careful not to injure your
hands.

If your vehicle has rain sensor wipers, place
the wiper switch lever in the “OFF” position
to deactivate the rain sensor before washing
the vehicle. Otherwise, the wipers will oper-
ate in the presence of water spray on the
windscreen and may get damaged as a result.

Refrain from excessively using a car wash as
its brushes may scratch the paint surface,
causing it to lose its gloss.
Scratches will be especially visible on darker
coloured vehicles.

Never spray or splash water on the electrical
components in the engine compartment. Do-
ing so could have an adverse effect on the
engine startability.
Exercise caution also when washing the un-
derbody; be careful not to spray water into
the engine compartment.

Some types of hot water washing equipment
apply high pressure and heat to the vehicle.
They may cause heat distortion and damage
to the vehicle resin parts and may result in
flooding of the vehicle interior. Therefore;

Cleaning the exterior of your vehicle

9-03

OKTE18E1

Vehicle care

CAUTION

•

Maintain a distance of approx. 70 cm or
more between the vehicle body and the
washing nozzle.

•

When washing around the door glass,
hold the nozzle at a distance of more than
70 cm and at right angles to the glass sur-
face.

After washing the vehicle, drive the vehicle
slowly  while  lightly  depressing  the  brake
pedal  several  times  in  order  to  dry  out  the
brakes.
Leaving  the  brakes  wet  could  result  in  re-
duced braking performance. Also, there is a
possibility  that  they  could  freeze  up  or  be-
come  inoperative  due  to  rust,  rendering  the
vehicle unable to move.

When  using  an  automatic  car  wash,  pay  at-
tention  to  the  following  items,  referring  to
the  operation  manual  or  consulting  a  car
wash operator. If the following procedure is
not  followed,  it  could  result  in  damage  to
your vehicle.

•

The outside mirrors are retracted.

•

If your vehicle is equipped with the pillar
antenna, it can be retracted.

•

If your vehicle is equipped with the roof
antenna, it can be removed.

•

The wiper arms are secured in place with
tape.

•

If your vehicle has rain sensor wipers,
place the wiper switch lever in the “OFF”
position to deactivate the rain sensor.

During cold weather

Salt and other chemicals spread on the roads
in  some  areas  in  winter  can  have  a  harmful
effect on the vehicle body. You should there-
fore wash the vehicle as often as possible in
accordance  with  our  care-instructions.  It  is
recommended to have a preservative applied
and the underfloor protection checked before
and after the cold weather season.
After washing your vehicle, wipe off all wa-
terdrops  from  the  rubber  parts  around  the
doors to prevent the doors from freezing.

Waxing

E00901001974

Waxing the vehicle will help prevent the ad-
herence  of  dust  and  road  chemicals  to  the
paintwork. Apply a wax solution after wash-
ing  the  vehicle,  or  at  least  once  every  three
months to assist displacing of water.
Do  not  wax  your  vehicle  in  direct  sunlight.
You  should  wax  after  the  surfaces  have
cooled.
For  information  on  how  to  use  wax  refer  to
the instruction manual of the wax.

CAUTION

Waxes containing high abrasive compounds
should not be used.

Polishing

E00901101151

The  vehicle  should  only  be  polished  if  the
paintwork has become stained or lost its lus-
tre.  Do  not  polish  parts  with  a  mat  coating
and  the  plastic  bumpers.  Doing  so  could
cause stains or damage the finish.

Cleaning plastic parts

E00901301876

Use a sponge or chamois leather.
If a car wax adheres on a grey or black rough
surface  of  the  bumper,  moulding  or  lamps,
the  surface  becomes  white.  In  such  a  case,
wipe  it  off  using  lukewarm  water  and  soft
cloth or chamois leather.

CAUTION

Do not use a scrubbing brush or other hard
tools as they may damage the plastic part
surface.

Do  not  bring  the  plastic  parts  into  contact
with  petrol,  light  oil,  brake  fluids,  engine
oils,  greases,  paint  thinners  and  sulphuric
acid  (battery  electrolyte)  which  may  crack,
stain or discolour the plastic parts.
If they touch the plastic parts, wipe them off
with  soft  cloth,  chamois  or  the  like  and  an
aqueous  solution  of  neutral  detergent  then
immediately  rinse  the  affected  parts  with
water.

Cleaning the exterior of your vehicle

9-04

OKTE18E1

Vehicle care

Chrome parts

E00901401183

In order to prevent spots and corrosion of
chrome parts, wash with water, dry thorough-
ly, and apply a special protective coating.
This should be done more frequently in win-
ter.

Aluminium wheels*

E00901500116

1. Remove dirt using a sponge while sprin-

kling water on the wheel.

2. Use neutral detergent on any dirt that

cannot be removed easily with water.
Rinse off the neutral detergent after
washing the wheel.

3. Dry the wheel thoroughly using a cha-

mois leather or a soft cloth.

CAUTION

Do not use a brush or other hard implement
on the wheels.
Doing so could scratch the wheels.

Do not use any cleaner that contains an abra-
sive substance or is acidic or alkaline. Doing
so could cause the coating on the wheels to
peel or become discoloured or stained.

Do not directly apply hot water using a
steam cleaner or by any other means.

Contact with seawater and road deicer can
cause corrosion. Rinse off such substances
as soon as possible.

Window glass

E00901601299

The  window  glass  can  normally  be  cleaned
using only a sponge and water.
Glass  cleaner  can  be  used  to  remove  oil,
grease,  dead  insects,  etc.  After  washing  the
glass,  wipe  dry  with  a  clean,  dry,  soft  cloth.
Never use a cloth that is used for cleaning a
painted surface to clean a window. Wax from
the painted surface could get on the glass and
lower glass transparency and visibility.

NOTE

To clean the inside of the rear window, al-
ways use a soft cloth and wipe the window
glass along the demister heater element so as
not to cause damage.

Wiper blades

E00901701199

Use a soft cloth and glass cleaner to remove
grease, insect carcasses, etc., from the wiper
blades. Replace the wiper blades when they
no longer wipe properly. (Refer to page
10-15.)

Engine compartment

E00902100265

Clean  the  engine  compartment  at  the  begin-
ning and end of winter. Pay particular atten-
tion  to  flanges,  crevices  and  peripheral  parts
where  dust  containing  road  chemicals  and
other corrosive materials might collect.
If  salt  and  other  chemicals  are  used  on  the
roads in your area, clean the engine compart-
ment at least every three months.
Never spray or splash water on the electrical
components  in  the  engine  compartment,  as
this may cause damage.
Do  not  bring  the  nearby  parts,  the  plastic
parts  and  so  on  into  contact  with  sulphuric
acid  (battery  electrolyte)  which  may  crack,
stain or discolour them.
If  they  are  in  contact,  wipe  off  with  soft
cloth, chamois or the like and an aqueous sol-
ution  of  neutral  detergent  then  immediately
rinse the affected parts with plenty of water.

Cleaning the exterior of your vehicle

9-05

OKTE18E1

Vehicle care

Service precautions

E01000102595

Adequate  care  of  your  vehicle  at  regular  in-
tervals  serves  to  preserve  the  value  and  ap-
pearance as long as possible.
Maintenance items as described in this own-
er’s manual can be performed by the owner.
We recommend you to have the periodic in-
spection  and  maintenance  performed  by  a
MITSUBISHI MOTORS Authorized Service
Point or another specialist.
In  the  event  a  malfunction  or  a  problem  is
discovered,  we  recommend  you  to  have  it
checked  and  repaired.  This  section  contains
information  on  inspection  maintenance  pro-
cedures that you can do yourself. Follow the
instructions and cautions for each of the vari-
ous procedures.

WARNING

When  checking  or  servicing  the  inside  of
the  engine  compartment,  make  sure  the
engine  is  switched  off  and  has  had  a
chance to cool down.

If it is necessary to do work in the engine
compartment with the engine running, be
especially careful that your clothing, hair,
etc., does not become caught by the cool-
ing fan, drive belts, or other moving parts.

After performing the maintenance, make
sure that no tools or cloths are left behind
in the engine compartment. If they are left
behind, a fire or damage to the vehicle
may occur.

WARNING

The cooling fan can turn on automatically
even if the engine is not running. Turn the
ignition switch to “LOCK” position or put
the operation mode in OFF to be safe
while you work in the engine compart-
ment.

Do not smoke, cause sparks or allow open
flames around fuel or battery. The fumes
are flammable.

Be extremely cautious when working
around the battery. It contains poisonous
and corrosive sulphuric acid.

Do not get under your vehicle with just
the body jack supporting it. Always use
automotive jack stands.

Improper handling of components and
materials used in the vehicle can endanger
your personal safety. We recommend you
to consult a specialist for necessary infor-
mation.

Service precautions

10-02

OKTE18E1

Maintenance

RHD

LHD

1. Engine coolant reservoir
2. Brake fluid reservoir
3. Clutch fluid reservoir*
4. Engine oil cap
5. Engine oil level gauge
6. Power steering fluid reservoir
7. Washer fluid reservoir
8. Battery

Catalytic converter

E01000202596

The exhaust gas scavenging devices used
with the catalytic converter are extremely ef-
ficient for the reduction of noxious gases.
The catalytic converter is installed in the ex-
haust system.

It is important to keep the engine properly
tuned to ensure proper catalyst operation and
prevent possible catalyst damage.

WARNING

As with any vehicle, do not park or oper-
ate  this  vehicle  in  areas  where  combusti-
ble  materials  such  as  dry  grass  or  leaves
can  come  in  contact  with  a  hot  exhaust
since a fire could occur.

NOTE

Use fuel of the type recommended in “Fuel
selection” on page 2-02.

Catalytic converter

10-03

OKTE18E1

Maintenance

Bonnet

E01000304126

To open

1. Pull the release lever towards you to un-

lock the bonnet.

2. Raise the bonnet while pressing the safe-

ty lock.

NOTE

Only open the bonnet when the wipers are in
the parked position. Failure to do so may
cause damage to the bonnet, wiper arms or
front windscreen.

3. Support the bonnet by inserting the sup-

port bar in its slot.

CAUTION

Note that the support bar may disengage the
bonnet if the open bonnet is lifted by a
strong wind.

After inserting the support bar into the slot,
make sure the bar supports the bonnet se-
curely from falling down on to your head or
body.

To close

1. Unlatch the support bar and clip it in its

holder.

2. Slowly lower the bonnet to a position

about 20 cm above the closed position,
then let it drop.

3. Make sure the bonnet is securely locked

by softly lifting the centre of the bonnet.

Bonnet

10-04

OKTE18E1

Maintenance

CAUTION

Be careful that hands or fingers are not trap-
ped when closing the bonnet.

Before driving, make sure that the bonnet is
securely locked. An incompletely locked
bonnet can suddenly open while driving.
This can be extremely dangerous.

NOTE

If this does not close the bonnet, release it
from a slightly higher position.

Do not press down firmly on the bonnet as
doing so could damage it.

Engine oil

E01000404693

To check and refill engine oil

A:Minimum level
B:Maximum level

C:Oil replacement indication mark

The engine oil used has a significant effect
on the engine’s performance, service life and
startability. Be sure to use oil of the recom-
mended quality and appropriate viscosity.
All engines consume a certain amount of oil
during normal operation. Therefore, it is im-
portant to check the oil level at regular inter-
vals or before starting a long trip.

1. Park the car on a horizontal surface.
2. Switch off the engine.
3. Wait a few minutes.
4. Remove the dipstick and wipe it with a

clean cloth.

5. Reinsert the dipstick as far as it goes.
6. Remove the dipstick and read the oil lev-

el, which should always be within the
range indicated.

7. If the oil level is below the specified

limit, remove the cap located on the cyl-
inder  head  cover  and  add  enough  oil  to
raise  the  level  to  within  the  specified
range.  Do  not  overfill  to  avoid  engine
damage. Be sure to use the specified en-
gine oil and do not mix various types of
oil.

8. After adding oil, close the cap securely.
9. Confirm the oil level by repeating step 4

to 6.

NOTE

Check or refill the oil according to the fol-
lowing manner.

•

When  the  oil  level  is  checked  in  step  6
above,  check  it  on  a  low  side  of  the  dip-
stick because it is different in appearance
of  oil  level  in  the  two  sides  of  the  dip-
stick.

•

On vehicles without diesel particulate fil-
ter (DPF), the oil level should be within
the range (A) to (B) on the dipstick.

•

On vehicles with DPF, the oil level should
be  within  the  range  (A)  to  (C)  (oil  re-
placement  indication  mark)  on  the  dip-
stick.
If  the  oil  level  is  beyond  the  oil  replace-
ment  indication  mark  (C),  replace  the  oil
as soon as possible.
Then,  the  oil  should  be  refilled  to  the
maximum level (B).

Engine oil

10-05

OKTE18E1

Maintenance

NOTE

•

On vehicles with DPF, the engine oil will
increase due to a little fuel getting mixed
in  the  engine  oil  when  the  DPF  regener-
ates  to  burn  away  the  PM  (particulate
matter).  However,  it  does  not  indicate  a
malfunction.

•

The engine oil level will be increased due
to an amount of the fuel being mixed in
the engine oil when the DPF regenerates
to burn away the PM (particulate matter).
It does not indicate a malfunction.
In the following conditions, the engine oil
level may increase easily. We recommend
you to have it checked frequently.

•

frequent driving at uphill and down-
hill

•

frequent driving at high altitudes

•

frequent and extended idling

•

frequent driving through a traffic
jam

The engine oil will deteriorate rapidly if the
vehicle is subjected to severe conditions, re-
quiring earlier oil replacement. Please refer
to the maintenance schedule.

For handling of used engine oils, refer to
page 2-06.

Selection of engine oil

Select engine oil of the proper SAE vis-
cosity number according to the atmos-
pheric temperature.

Use engine oil conforming to the follow-
ing classification:

• ACEA classification:

“For service C1, C2, C3 or C4”

• JASO classification:

“For service DL-1”

If those classifications are not available, con-
tact a MITSUBISHI MOTORS Authorized
Service Point.

NOTE

Use  of  additives  is  not  recommended  since
they  may  reduce  the  effectiveness  of  addi-
tives  already  included  in  the  engine  oil.  It
may  result  in  failure  of  the  mechanical  as-
sembly.

Engine coolant

E01000503509

To check the coolant level

A transparent coolant reserve tank (A) is lo-
cated in the engine compartment.

Engine coolant

10-06

OKTE18E1

Maintenance

The coolant level in this tank should be kept
between the “L” (LOW) and “F” (FULL)
marks when measured while the engine is
cold.

To add coolant

The  cooling  system  is  a  closed  system  and
normally  the  loss  of  coolant  should  be  very
slight. A noticeable drop in the coolant level
could indicate leakage. If this occurs, we rec-
ommend  you  to  have  the  system  checked  as
soon as possible.

If the level should drop below the “L”
(LOW) level on the reserve tank, open the lid
and add coolant.
Also, if the reserve tank is completely empty,
remove the radiator cap (B) and add coolant
until the level reaches the filler neck.

WARNING

Do not open the radiator cap (B) while the
engine is hot. The coolant system is under
pressure and any hot coolant escaping
could cause severe burns.

Anti-freeze

The engine coolant contains an ethylene gly-
col  anti-corrosion  agent.  Some  parts  of  the
engine are cast aluminium alloy, and periodic
changing  of  the  engine  coolant  is  necessary
to prevent corrosion of these parts.

Use  “MITSUBISHI  MOTORS  GENUINE
SUPER  LONG  LIFE  COOLANT  PREMI-
UM” or equivalent*.
*: similar high quality ethylene glycol based
non-silicate,  non-amine,  nonnitrate  and  non-
borate  coolant  with  long  life  hybrid  organic
acid technology

MITSUBISHI MOTORS GENUINE Coolant
has excellent protection against corrosion and
rust formation of all metals including alumi-
nium and can avoid blockages in the radiator,
heater, cylinder head, engine block, etc.
Because  of  the  necessity  of  this  anti-corro-
sion  agent,  the  coolant  must  not  be  replaced
with  plain  water  even  in  summer.  The  re-
quired concentration of anti-freeze differs de-
pending  on  the  expected  ambient  tempera-
ture.
Above  -35  °C:  50  %  concentration  of  anti-
freeze
Below  -35  °C:  60  %  concentration  of  anti-
freeze

CAUTION

Do  not  use  alcohol  or  methanol  anti-freeze
or  any  engine  coolants  mixed  with  alcohol
or  methanol  anti-freeze.  The  use  of  an  im-
proper anti-freeze can cause corrosion of the
aluminium components.

Do not use water to adjust the concentration
of coolant.

Concentrations exceeding 60 % will result in
a reduction of both the anti-freeze and cool-
ing performance thus adversely affecting the
engine.

Do not top up with water only.

Engine coolant

10-07

OKTE18E1

Maintenance

During cold weather

If  the  temperatures  in  your  area  drop  below
freezing,  there  is  the  danger  that  the  coolant
in  the  engine  or  radiator  could  freeze  and
cause severe damage to the engine and/or ra-
diator. Add a sufficient amount of anti-freeze
to the coolant to prevent it from freezing.
The  concentration  should  be  checked  before
the start of cold weather and anti-freeze add-
ed to the system if necessary.

Washer fluid

E01000702113

Open the washer fluid reservoir cap and
check the level of washer fluid with the dip-
stick.
If the level is low, replenish the container
with washer fluid.

EMPTY

NOTE

The washer fluid container serves the wind-
screen and headlamps (if so equipped).

During cold weather

To ensure proper operation of the washers at
low temperatures, use a fluid containing an
anti-freezing agent.

Brake fluid

E01000902131

To check the fluid level

Check the brake fluid level in the reservoir.
The brake fluid level must be between the
“MAX” and “MIN” marks on the reservoir.

The brake fluid level is monitored by a float.
When  the  brake  fluid  level  falls  below  the
“MIN”  mark,  the  brake  fluid  warning  lamp
lights up.
The fluid level falls slightly with wear of the
brake pads, but this does not indicate any ab-
normality.
If  the  brake  fluid  level  falls  markedly  in  a
short  length  of  time,  it  indicates  leaks  from
the brake system.
If this occurs, we recommend you to have the
vehicle checked.

Fluid type

Use  brake  fluid  conforming  to  DOT3  or
DOT4.  The  brake  fluid  is  hygroscopic.  Too
much  moisture  in  the  brake  fluid  will  ad-
versely affect the brake system, reducing the
brake performance.
In addition, the brake fluid reservoir is equip-
ped with a special cap to prevent the entrance
of air, and this cap should not be removed.

WARNING

Take care in handling brake fluid as it is
harmful  to  the  eyes,  may  irritate  your
skin  and  will  damage  painted  surfaces.
Wipe up spills immediately. If brake fluid
gets on your hands or in your eyes, flush
immediately  with  clean  water.  Follow  up
with a doctor as necessary.

Washer fluid

10-08

OKTE18E1

Maintenance

CAUTION

Use only the specified brake fluid.
Do not mix or add different brands of brake
fluid to prevent chemical reactions.
Do not let any petroleum-based fluid touch,
mix with, or get into the brake fluid.
This will damage the seals.

Keep the reservoir tank cap closed to pre-
vent the brake fluid from deteriorating ex-
cept maintenance.

Clean the filler cap before removing and
close the cap securely after maintenance.

Clutch fluid*

E01001001581

To check the fluid level

The clutch fluid in the master cylinder should
be checked when performing other under-
hood service. In addition, the system should
be checked for leakage at the same time.

Check to make certain that the clutch fluid
level is always between the “MAX” and
“MIN” level markings on the fluid reservoir.

A rapid fluid loss indicates a leak in the
clutch system which should be inspected by a
MITSUBISHI MOTORS Authorized Service
Point or another specialist and repaired im-
mediately.

Fluid type

Brake fluid conforming to DOT 3 or DOT 4
should be used.
The  reservoir  cap  must  be  fully  tightened  to
avoid  contamination  from  foreign  matter  or
moisture.
DO  NOT  ALLOW  PETROLEUM-  BASED
FLUID  TO  CONTACT,  MIX  WITH,  OR
OTHERWISE

CONTAMINATE

THE

BRAKE FLUID. SEAL DAMAGE WILL
RESULT.

WARNING

Power steering fluid

E01001102491

To check the fluid level

Check the fluid level in the reservoir while
the engine is idling.
Check to make certain that the power steering
fluid level is always between the “MAX” and
“MIN” level markings on the fluid reservoir
and top up the fluid, if necessary.

Clutch fluid*

10-09

OKTE18E1

Maintenance

Fluid type

Use “MITSUBISHI MOTORS GENUINE
PSF (Power Steering Fluid)”.

Battery

E01001203662

The condition of the battery is very important
for quick starting of the engine and proper
functioning of the vehicle’s electrical system.
Regular inspection and care are especially
important in cold weather.

Checking battery electrolyte

level

The electrolyte level must be between the
specified limit on the outside of the battery.
Replenish with distilled water as necessary.

The inside of the battery is divided into sev-
eral compartments; remove the cap from each
compartment  and  fill  to  the  upper  mark.  Do
not  top  up  beyond  the  upper  mark  because
spillage during driving could cause damage.
Check the electrolyte level at least once every
4  weeks,  depending  on  the  operating  condi-
tions.
If the battery is not used, it will discharge by
itself with time.
Check it once every 4 weeks and charge with
low current as necessary.

During cold weather

The capacity of the battery is reduced at low
temperatures.  This  is  an  inevitable  result  of
its  chemical  and  physical  properties.  This  is
why a very cold battery, particularly one that
is not fully charged, will only deliver a frac-
tion  of  the  starter  current  which  is  normally
available.
We  recommend  you  to  have  the  battery
checked before the start of cold weather and,
if necessary, have it charged or replaced.
This  does  not  only  ensure  reliable  starting,
but a battery which is kept fully charged also
has a longer life.

Disconnection and connection

To disconnect the battery cable, stop the en-
gine, first disconnect the negative (-) terminal
and then the positive (+) terminal. When con-
necting the battery, first connect the positive
(+) terminal and then the negative (-) termi-
nal.

NOTE

Open the terminal cover (A) before discon-
necting or connecting the positive (+) termi-
nal of the battery.

Battery

10-10

OKTE18E1

Maintenance

Mitsubishi L200 (2018 year). Instruction - part 22
