Mitsubishi ASX (2018 year). Instruction

Play tracks in the folder currently being
played in a random order.

NOTE

Pressing again will cancel.

Even if the file is selected, folder random
playback will not be cancelled.

All Folder Random Playback

Hold down the 2RDM key.

Play the tracks in all folders in a random or-
der.

NOTE

Pressing again will cancel.

Even if the file is selected, all folder random
playback will not be cancelled.

Scan Playback (SCAN)

Press the PTY/SCAN key.

Play the first 10 seconds of each of the tracks
on the whole USB device in order.

NOTE

Press this button again during playback if
you wish to hear that track, and that track
will play normally.

Folder Scan Playback

Hold down the PTY/SCAN key.

Play the first 10 seconds of the first track in
each folder on the USB device in order.

NOTE

Press this button again during playback if
you wish to hear that track, and that track
will play normally.

Search Tracks

Search folders and files, and select a track.

1. Turn the /SEL key to select the folder.
2. Press the /SEL key.

Files within the selected folder are dis-
played.

3. Turn the /SEL key to select the file.
4. Press the /SEL key.

This plays the selected file (track).

NOTE

While the folder is selected, press the 6
key to cancel track search mode.

If there is no operation for 10 seconds after
selecting the folder, then track search mode
will be cancelled.

Select the folder, and hold down the

/SEL

key to start playback from the first track in
that folder.

While the file is selected, press the 6

key

to return to the previous operation.

While the file is selected, hold down the 6

key to cancel track search mode.

If there is no operation for five seconds after
selecting the file, that file is played back.

Operations such as selecting a track will
cancel track search mode.

To play iPod/USB memory
device tracks via voice
operation (vehicles with
Bluetooth

2.0 interface)

E00748700032

Desired tracks on the iPod/USB memory de-
vice which is connected to the USB input ter-
minal  can  be  selected  and  played  via  voice
operation.
For  information  concerning  the  voice  recog-
nition  function  or  speaker  registration  func-
tion,  refer  to  “Bluetooth

2.0 interface” on

page 7-46.

To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth

2.0 interface)

7-32

OGAE18E1

For pleasant driving

The following explains how to prepare for
voice operation and play the tracks.

Preparation for voice operation

E00748800033

To use the voice operation, press the
SPEECH button (A) first.

To search by artist name

E00748900034

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Artist”.

NOTE

If you say “Artist <name>,” you can skip
step 3.

3. After the voice guide says “What Artist

would you like to play?,” say the artist
name.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice guide will say “More than one
match was found, would you like to play
<artist name>?” If you say “Yes,” the
system proceeds to step 6.
If you say “No,” the next matching artist
is uttered by the system.

NOTE

If you say “No” to three or all artist names
uttered by the system, the voice guide will
say “Artist not found, please try again” and
the system returns to step 2.

Search time is dependant on the number of
songs on your connected device. Devices
containing a large number of songs may take
longer to return search results.

6. After the voice guide says “Playing <ar-

tist name>,” the system creates a playlist
index for the artist.

NOTE

If  the  confirmation  function  is  active,  the
voice  guide  confirms  if  the  artist  name  is
correct.  If  the  artist  name  is  correct,  say
“Yes”.  If  not,  say  “No”.  After  the  voice
guide  says  “Artist  not  found,  please  try
again,” the system returns to step 2.

7. The system exits the voice recognition

mode and starts playback.

To search by album title

E00749000032

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Album”.

To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth

2.0 interface)

7-33

OGAE18E1

For pleasant driving

NOTE

If you say “Album <title>,” you can skip
step 3.

3. After the voice guide says “What Album

would you like to play?” say the album
title.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice  guide  will  say  “More  than  one
match was found, would you like to play
<album  title>?”  If  you  say  “Yes,”  the
system proceeds to step 6.
If  you  say  “No,”  the  next  matching  al-
bum is uttered by the system.

NOTE

If you say “No” to three or all album titles
uttered by the system, the voice guide will
say “Album not found, please try again” and
the system returns to step 2.

6. After the voice guide says “Playing <al-

bum title>,” the system creates a playlist
index for the album title.

NOTE

If  the  confirmation  function  is  active,  the
voice  guide  confirms  if  the  album  title  is
correct.  If  the  album  title  is  correct,  say
“Yes”.  If  not,  say  “No”.  After  the  voice
guide  says  “Album  not  found,  please  try
again,” the system returns to step 2.

7. The system exits the voice recognition

mode and starts playback.

To search by playlist

E00749100033

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Playlist”.

NOTE

If you say “Playlist <playlist>,” you can skip
step 3.
If the device has no playlist, the voice guide
will say “There are no playlists stored on de-
vice” and the system returns to step 2.

3. After the voice guide says “What Play-

list would you like to play?,” say the
playlist name.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice guide will say “More than one
match was found, would you like to play
<playlist>?” If you say “Yes,” the sys-
tem proceeds to step 6.
If you say “No,” the next matching play-
list name is uttered by the system.

NOTE

If you say “No” to three or all playlist names
uttered by the system, the voice guide will
say “Playlist not found, please try again” and
the system returns to step 2.

6. After the voice guide says “Playing

<playlist>,” the system creates an index
for the playlist.

To play iPod/USB memory device tracks via voice operation (vehicles with Bluetooth

2.0 interface)

7-34

OGAE18E1

For pleasant driving

NOTE

If  the  confirmation  function  is  active,  the
voice guide confirms if the playlist name is
correct.  If  the  playlist  name  is  correct,  say
“Yes”.  If  not,  say  “No”.  After  the  voice
guide  says  “Playlist  not  found,  please  try
again,” the system returns to step 2. Refer to
“Confirmation  function  setting”  on  page
7-49.

7. The system exits the voice recognition

mode and starts playback.

To search by genre

E00749200034

1. Say “Play” on the main menu.

NOTE

The Bluetooth

2.0 interface starts recogniz-

ing the connected device.
If the connected device cannot be recognized
or a connection error occurs, the Bluetooth

2.0 interface starts an appropriate voice
guide. Follow the voice guide.

2. After the voice guide says “Would you

like to play by Artist, Album, Playlist or
Genre?,” say “Genre”.

NOTE

If you say “Genre <type>,” you can skip
step 3.

3. After the voice guide says “What Genre

would you like to play?,” say the music
type.

4. If there is only one match, the system

proceeds to step 6.

5. If there are two or more matches, the

voice guide will say “More than one
match was found, would you like to play
<genre>?” If you say “Yes,” the system
proceeds to step 6.
If you say “No,” the next matching
genre is uttered by the system.

NOTE

If you say “No” to three or all genres uttered
by the system, the voice guide will say
“Genre not found, please try again” and the
system returns to step 2.

6. After the voice guide says “Playing

<genre>,” the system creates an index
for the genre.

NOTE

If  the  confirmation  function  is  active,  the
voice guide confirms if the genre is correct.
If the genre is correct, say “Yes”. If not, say
“No”. After the voice guide says “Genre not
found,  please  try  again,”  the  system  returns
to  step  2.  Refer  to  “Confirmation  function
setting” on page 7-49.

7. The system exits the voice recognition

mode and starts playback.

Listening to Bluetooth
Audio*

E00736701306

This product can play back tracks on com-
mercially-available Bluetooth-capable audio
devices.

CAUTION

Never hold these devices in your hand to op-
erate while driving, as this is dangerous.

Do not leave the Bluetooth audio device un-
attended in the vehicle.

Depending on how the devices are handled,
audio files being damaged or lost, therefore
it is recommended that data be backed up.

Listening to Bluetooth Audio*

7-35

OGAE18E1

For pleasant driving

NOTE

Depending on the type of Bluetooth-capable
audio devices, usage may not be possible, or
functions that can be used may be restricted.

Confirm together with the user manuals for
the commercially- available Bluetooth-capa-
ble audio devices.

Depending on the type of Bluetooth-capable
audio devices, volume levels may differ.
There is the danger of loud volumes, so prior
to use, it is recommended that you turn the
volume down.
→ “Adjust Volume” on page 7-20

Depending on the status of the Bluetooth au-
dio device, it may take some time until the
device is recognized, or playback starts.

Bluetooth audio device specifications and
settings may mean that connection is not
possible, or result in differences in operation
or display.

Depending on audio data in the Bluetooth
audio device, track information may not be
displayed correctly.

Depending on the status of the vehicle and
device, the iPod/iPhone may not play back
after starting the engine.

Connect a Bluetooth-capable

Audio Device

Regarding how to connect your Bluetooth de-
vice, refer to “Connecting the Bluetooth

2.0

interface and Bluetooth device” on page
7-52.

Operation methods below describe situations
once connection has been completed.

NOTE

If  the  iPod/iPhone  is  connected  via  Blue-
tooth  as  a  Bluetooth-  capable  audio  device,
then  do  not  connect  the  iPod/iPhone  using
an iPod cable. Connection using both meth-
ods will result in erroneous operation.

Play Bluetooth Audio

1. Press the MEDIA key to set Bluetooth

Audio as the source.

The selected source is indicated on the
display.

2. Press the 5

key. Bluetooth Audio

playback starts.

NOTE

Hold down the 5

key to pause.

Press the 6

key to stop.

Select the Track (File)

Press the

key or

key to select the

track.

This enables selection of the next or previous
track.

Fast Forward or Rewind

Hold down the 3

key or the 4

key.

Fast forward/rewind is possible.

Switching Playback Mode

Repeat playback, random playback, and scan
playback are possible.

Repeat Playback (RPT)

Press the 1RPT key.

Repeat playback of the track currently being
played.

NOTE

Each time the 1RPT key is pressed, this
switches in the order Repeat OFF, 1 track re-
peat, All track repeat, and Repeat OFF.

Random Playback (RDM)

Press the 2RDM key.

Play the tracks in the Bluetooth Audio device
in a random order.

Listening to Bluetooth Audio*

7-36

OGAE18E1

For pleasant driving

Display Indicator

E00738100059

This explains content of the display indicator.

Change the Display Mode

E00738500040

You can change the content of the display in-
dicator.
Press the DISP key to switch the display con-
tent.

Each time the DISP key is pressed, the dis-
play content changes.

CAUTION

The operation of changing display contents
may impede safe driving, therefore check
safety before operation.

NOTE

Up to 11 characters may be displayed at one
time. To display 12 or more characters, press
the PAGE key, and subsequent characters
will be displayed.

During DAB Reception*

This switches in the order “Service name”,
“Ensemble name”, and “CH no. (CH ID)”.

NOTE

If the text information for the service name
and ensemble name cannot be obtained, then
nothing is displayed.

Display Indicator

7-38

OGAE18E1

For pleasant driving

During CD-DA playback

This switches in the order “Disc title”,
“Track title”, and “Operating status”.

NOTE

If there is no text information to display,
then “NO TITLE” is displayed.

During MP3/WMA/AAC Play-

back

This switches in the order “Folder title”,
“File title”, and “Operating status”.

NOTE

If there is no text information to display,
then “NO TITLE” is displayed.

Display the ID3tag

Hold down the DISP key.

This switches the ID3tag display.
[DISP]  Each  time  the  key  is  pressed,  this
switches in the order “Album name”, “Track
name”,  “Artist  name”,  “Genre  name”*,  and
“Operating status”.

*:  Displayed  when  playing  back  audio  files
on a USB device (vehicles with a Bluetooth

2.0 interface).

NOTE

During display of the ID3tag, hold down the
DISP key to switch to the folder title dis-
play.

The genre name display may not be possible.

During iPod Playback

E00738900015

This switches in the order “Albums”, “Track
name”, “Artist name”, “Genre name”*, and
“Operating status”.

NOTE

If there is no text information to display,
then “NO TITLE” is displayed.

Displayed genre name in equipment by type
(vehicles with a Bluetooth

2.0 interface).

The genre name display may not be possible.

During Bluetooth

2.0 Audio

Playback*

E00739000013

Operating details are the same as in “During
iPod Playback” on page 7-39.

Audio Quality and Volume
Balance Adjustment

E00738201233

Change audio quality settings.

Adjust Audio Quality and Vol-

ume Balance

1. Press the

/SEL key to select settings

items.
Each time the

/SEL key is pressed,

this switches in the order BASS, TRE-
BLE, FADER, BALANCE, SCV, and
Cancel.

2. Turn the /SEL key to adjust.

Ad-
just-
ment
items

Turn

counter-

clockwise

Turn clockwise

BASS -6 to 0

(low

low-pass

volume)

0 to +6
(high

low-pass

volume)

TRE-
BLE

-6 to 0
(Low high-pass
volume)

0 to +6
(High high-pass
volume)

FAD-
ER

CENTER

REAR 11
(emphasise
REAR)

FRONT 11 to
CENTER
(emphasise
FRONT)

BAL-
ANC
E

LEFT

CENTER
(emphasise
LEFT)

CENTER

RIGHT 11
(emphasise
RIGHT)

Audio Quality and Volume Balance Adjustment

7-39

OGAE18E1

For pleasant driving

Ad-
just-
ment
items

Turn

counter-

clockwise

Turn clockwise

SCV OFF, LOW

(Low speed com-
pensated volume
effect)

MID, HIGH
(High speed com-
pensated volume
effect)

System settings

E00738301319

Change system settings such as product time.

1. Press the MENU key.
2. Press the

/SEL key to select settings

items.
Each time the

/SEL key is pressed,

this switches in the order DAB settings,
Gracenote DB, AF, REG, TP-S, PI-S,
PTY language setting, PHONE settings,
CT, Adjust time and cancel.

3. Turn the /SEL key to set.
4. Press the /SEL key to determine

This completes settings, and displays the
next settings item.

*: Displayed when playing back audio

files (vehicles with Bluetooth

2.0 in-

terface.)

DAB Setting*

Change DAB setting
(“Set value” bold typeface indicated factory
settings.)

Set-
tings
name

Settings Value

Settings content

DAB -
DAB
Link
settings

OFF

If low reception
sensitivity, switch
to another service

DAB
Band
Settings

BAND III

Set used broad-
cast ban to 174
to 239 MHz.

L-BAND

Set used broad-
cast band to
1452 to 1490
MHz.

BOTH

Set used broad-
cast band to
Band III and
Band.

RDS Setting

Change RDS settings.
(“Set value” bold typeface indicated factory
settings.)

Set-

tings

name

Settings Value Settings content

AF ON

Automatyically
track the same
station as the
program being
received.

AF OFF

Do not automati-
cally track the
same station as
the program be-
ing received.

REG

REG ON

Do not automati-
cally track the
local station for
the program be-
ing received.

REG OFF

Automatically
track the local
station for the
program being
received.

TP-S

TP-S ON

Automatically
search for traffic
messages (TP
stations).

System settings

7-40

OGAE18E1

For pleasant driving

Set-

tings

name

Settings Value Settings content

TP-S OFF

Do not automati-
cally search for
traffic messages
(TP stations).

PI-S

PI-S ON

Search for the
same station or
local station in
that registered in
the preset chan-
nel.

PI-S OFF

Do not search
for the same sta-
tion or local sta-
tion for that reg-
istered in the
preset channel

PTY

ENGLISH

Set the display
language for the
program content
search (PTY
search) to Eng-
lish.

Set-

tings

name

Settings Value Settings content

FRANÇAIS

Set the display
language for the
program content
search (PTY
search) to
French.

DEUTSCH

Set the display
language for the
program content
search (PTY
search) to Ger-
man.

SVENSK

Set the display
language for the
program content
search (PTY
search) to Swed-
ish.

ESPAÑOL

Set the display
language for the
program content
search (PTY
search) to Span-
ish.

Set-

tings

name

Settings Value Settings content

ITALIANO

Set the display
language for the
program content
search (PTY
search) to Ital-
ian.

CT ON

Update the time
if time data is re-
ceived.

CT OFF

Do not update
the time even if
time data is re-
ceived.

*: It is necessary to press the [TP] key and
turn traffic message standby mode “ON”.

Time Setting

Turning the RDS setting CT setting “CT
OFF” enables manual setting of the time.

1. Select “YES” at the “Adjust time”

screen, and press the /SEL key.
The hour can be adjusted. Press the

/SEL key again to adjust the minutes.

2. Turn the /key to adjust the time.
3. Press the /SEL key.

This completes the adjustment.

System settings

7-41

OGAE18E1

For pleasant driving

NOTE

In order to finish adjusting the time, hold
down the

/SEL key until the seconds are

reset to “00”.

PHONE Settings

Change the mobile phone voice cut-in set-
tings and the Bluetooth

2.0 interface lan-

guage.
Depending on the vehicle, PHONE settings
may not be possible.

NOTE

Cancel functions such as the mobile phone
“dial lock”, and connect while on the stand-
by screen.

While connected, mobile phone (receiving
calls, etc.) operations may not function cor-
rectly.

Depending  on  the  distance  between  the
product  and  the  mobile  phone,  the  condi-
tions within the vehicle, and types of screen-
ing, connection may not be possible. In these
cases,  situate  the  mobile  phone  as  close  as
possible to the product.

Even though a Bluetooth-capable mobile
phone, characteristics and specifications
may mean that correct operation may not be
possible.

NOTE

For safety’s sake, do not operate the mobile
phone while driving. When operating the
mobile phone, first stop the vehicle in a safe
location.

Even  though  a  Bluetooth-capable  mobile
phone,  phone  specifications  and  settings
may  result  in  differences  in  display,  or  pre-
vent correct operation.

Some models may not be confirmed as con-
nected, or may not connect.

Supported profiles

Hands-free

HFP (v1.5)

Phone book trans-

fer

OPP (v1.1), PBAP
(v1.0)

Vehicles without a Bluetooth

2.0 interface

A hands-free kit (available separately) is re-
cquired.
(“Set value” bold typeface indicated factory
settings.)

Settings value

Settings content

PHONE OFF

Do not use mobile
phone voice cut-in.

PHONE MUTE

During mobile phone
voice cut-in, mute
the audio.

Settings value

Settings content

PHONE ATT

During mobile phone
voice cut-in, output
audio from all speak-
ers.

PHONE IN-L

During mobile phone
voice cut-in, output
sound from the left
front speaker.

PHONE IN-R

During mobile phone
voice cut-in, output
sound from the right
front speaker.

PHONE IN-LR

During mobile phone
voice cut-in, output
sound from the left
and right front speak-
ers.

Vehicles with a Bluetooth

2.0 interface

(“Set value” bold typeface indicated factory
settings.)

Set-

tings

name

Settings value Settings content

PHONE

IN set-

tings

PHONE IN-R During mobile

phone voice cut-
in, output sound
from the right
front speaker.

System settings

7-42

OGAE18E1

For pleasant driving

Set-

tings

name

Settings value Settings content

PHONE IN-L

During  mobile
phone voice cut-
in,  output  sound
from  the  left
front speaker.

HFM

voice

lan-

guage

settings

ENGLISH

Change the hands
free module voice
language.

FRENCH

GERMAN

SPANISH

ITALIAN

DUTCH

PORTUGUESE

RUSSIAN

NOTE

Depending on the vehicle model, this may
not display.

Gracenote DB (Vehicles with a
Bluetooth

2.0 interface)

The version number can be confirmed.

1. Select “Gracenote DB” and press the

/SEL key.

2. Turn the /SEL key and selct the “DB

Version”.

3. Press the /SEL key.

The DB Version is displayed.

System settings

7-43

OGAE18E1

For pleasant driving

Troubleshooting

E00738400081

Please check these items if a message appears on the display, or if you think something is not working properly.

If This Message Appears...

A message is displayed on this product according to the situation.

Mode

Message

Cause

Response

CHECK DISC

The disc is inserted upside down.

Insert with the label side up.

The disc has condensation on it.

Wait a while before inserting again.

DISC ERROR

The disc is damaged.

Clean the read surface of the disc.

The disc is dirty.

INTERNAL E

The drive has malfunctioned for some reason.

Check that there is no problem with the disc, and insert
the disc again. If the problem persists, consult a
MITSUBISHI MOTORS Authorized Service Point.

HEAT ERROR

The temperature inside the product is high.

Remove the disc, and wait for the internal temperature
to return to normal.

USB

FILE ERROR

Files that cannot be played are selected.

Select files that can be played.
→ “Audio Files (MP3/WMA/AAC)” on page 7-15

USB BUS PWR There is high or low electrical current or voltage.

Turn the power OFF and wait a short while. If the prob-
lem persists, consult a MITSUBISHI MOTORS Author-
ized Service Point.

LSI ERROR

There is an internal malfunction for some reason.

UNSUPPORTED

FORMAT

Unsupported audio files have been played.

Confirm audio files that can be played.
→ “Audio Files (MP3/WMA/AAC)” on page 7-15

UNSUPPORTED

DEVICE

An unsupported USB device has been connected.

Please connect a USB memory device.

iPod

NO SONG

An iPod/iPhone not containing any tracks has been
connected.

Connect an iPod/iPhone containing tracks.

Troubleshooting

7-44

OGAE18E1

For pleasant driving

Mode

Message

Cause

Response

VER ERROR

This iPod/iPhone software version is not supported.

Please change to a supported software version.

Other

ERROR DC

An abnormal direct voltage has been sent to the speak-
ers.

Turn the power OFF and wait a short while. If the
problem persists, consult a MITSUBISHI MOTORS
Authorized Service Point.

If You Think Something Is Not Working Properly...

Here is a list of symptoms, causes and responses if you think something is not working properly.

Symptoms

Cause

Response

There is no sound or quiet
sound

The volume is turned to its minimum.

Adjust the volume.
→ “Adjust Volume” on page 7-20

The balance or fader is turned to one side.

Adjust the balance or fader.
→ “Adjust Audio Quality and Volume Balance” on
page 7-39

The disc cannot be inserted. A disc is already in the product.

Eject the disc.
→ “Insert/Eject Discs” on page 7-20

There is no disc in the product, but the product says it is
loading.

Press the eject button once.
→ “Insert/Eject Discs” on page 7-20

The disc cannot be played.

The disc is inserted upside down.

Insert with the label side up.

The disc has condensation on it.

Wait a while before inserting.

The disc is dirty.

Clean the read surface of the disc.

The sound skips in the
same place.

The disc is damaged or dirty.

Check the disc.

There is no sound, even if
the disc is inserted.

Damage to or dirt on the disc means that its data cannot
be read.

Check the disc. Additionally, if using CD-R/RW discs,
their characteristics may render them unable to be
played.

Troubleshooting

7-45

OGAE18E1

For pleasant driving

Link System*

E00764501918

The Link System takes overall control of the
devices connected via the USB input terminal
or the Bluetooth

2.0 interface allowing the

connected devices to be operated by using the
switches in the vehicle or voice commands.
See the following section for details on how
to operate.

Refer to “Bluetooth

2.0 interface” on page

7-46.
Refer to “USB input terminal” on page
7-67.
Refer to “Listen to Audio Files on a USB De-
vice” on page 7-30.
Refer to “To play iPod/USB memory device
tracks via voice operation ” on page 7-32.
Refer to “Listening to Bluetooth Audio*” on
page 7-35.

Bluetooth

is a registered trademark of

BLUETOOTH SIG, INC.

Link System End User Licence

Agreement

E00764601124

You have acquired a device that includes
software

licensed

MITSUBISHI

MOTORS CORPORATION from Visteon
Corporation, and their subsequent 3

party

suppliers. For a complete list of these 3

par-

ty products and their end user licence agree-
ments, please go to the following website.
http://www.jciblueconnect.com/faq/fulldi-
sclosure.pdf

Bluetooth

2.0 interface*

E00726002257

The Bluetooth

2.0 interface allows for mak-

ing/receiving hands-free calls in the vehicle
using a Bluetooth

compatible cellular phone

based on the wireless communication tech-
nology commonly known as Bluetooth

. It

also allows the user to play music, saved in a
Bluetooth

music player, from the vehicle’s

speakers.
The system is equipped with a voice recogni-
tion  function,  which  allows  you  to  make
hands-free  calls  by  simple  switch  operations
and  voice  command  operations  using  a  de-
fined voice tree.

The Bluetooth

2.0 interface can be used

when the ignition switch or the operation
mode is in ON or ACC.

Before you can use the Bluetooth

2.0 inter-

face, you must pair the Bluetooth

device

and Bluetooth

2.0 interface. Refer to “Con-

necting the Bluetooth® 2.0 interface and
Bluetooth® device” on page 7-52.

Bluetooth

is a registered trademark of

BLUETOOTH SIG, INC.

WARNING

Although the Bluetooth

2.0 interface al-

lows  you  to  make  hands-free  calls,  if  you
choose  to  use  the  cellular  phone  while
driving, you must not allow yourself to be
distracted from the safe operation of your
vehicle.  Anything,  including  cellular
phone  usage,  that  distracts  you  from  the
safe  operation  of  your  vehicle  increases
your risk of an accident.

Refer to and comply with all state and lo-
cal laws in your area regarding cellular
phone usage while driving.

Link System*

7-46

OGAE18E1

For pleasant driving

NOTE

If the ignition switch or the operation mode
is left in ACC, the accessory power will au-
tomatically turn off after a certain period of
time and you will no longer be able to use
the Bluetooth

2.0 interface. The accessory

power comes on again if the ignition switch
or the engine switch is operated.
Refer to “ACC power auto-cutout function”
on page 6-13.

The Bluetooth

2.0 interface cannot be used

if the Bluetooth

device has a flat battery or

the device power is turned off.

Hands-free calls will not be possible if your
phone does not have service available.

If you place the Bluetooth

device in the

luggage compartment, you may not be able
to use the Bluetooth

2.0 interface.

Some Bluetooth

devices are not compatible

with the Bluetooth

2.0 interface.

For details on the Bluetooth

2.0 interface,

you can see to access via the MITSUBISHI
MOTORS website.
Please read and agree the “Warning about
Links to the Web Sites of Other Companies”
because it connects other than MITSUBISHI
MOTORS website.
http://www.mitsubishi-motors.com/en/prod-
ucts/index.html

Software updates by cellular phone/digital
audio device manufacturers may change/
alter device connectivity.

Steering control switch and microphone

® p. 7-47

Voice recognition function

® p. 7-48

Useful voice commands

® p. 7-49

Speaker enrollment function

® p. 7-50

Connecting the Bluetooth® 2.0 interface and
Bluetooth® device

® p. 7-52

Operating a music player connected via Blue-
tooth®

® p. 7-57

How to make or receive hands-free calls

® p. 7-57
Phone book function

® p. 7-60

Steering control switch and mi-

crophone

E00727201406

1- Volume up button
2- Volume down button
3- SPEECH button
4- PICK-UP button
5- HANG-UP button
6- Microphone

Volume up button

Press this button to increase the volume.

Volume down button

Press this button to decrease the volume.

SPEECH button

Press this button to change to voice rec-
ognition mode.
While the system is in voice recognition
mode, “Listening” will appear on the au-
dio display.

If you press the button briefly while in
voice recognition mode, it will interrupt
prompting and allow voice command in-
put.
Pressing the button longer will deacti-
vate the voice recognition mode.

Pressing this button briefly during a call
will enable voice recognition and allow
voice command input.

Bluetooth

2.0 interface*

7-47

OGAE18E1

For pleasant driving

Mitsubishi ASX (2018 year). Instruction - part 19
