EMISSION CONTROL

TSB Revision

ENGINE AND EMISSION CONTROL

17-79

VACUUM HOSES

VACUUM HOSE ROUTING

M1173000900398

<2.4L ENGINE>

AK301809

EVAPORATIVE
EMISSION
CANISTER

EVAPORATIVE EMISSION
VENTILATION SOLENOID

*1

EVAPORATIVE
EMISSION
PURGE
SOLENOID

CHAMBER

INTAKE MANIFOLD
PLENUM

THROTTLE
BODY

FRONT

B: BLACK
*1:RED PAINT MARK

AB

B

B

B

B

B

B

B

CHAMBER

EMISSION CONTROL

TSB Revision

ENGINE AND EMISSION CONTROL

17-80

<3.8L ENGINE>

AK301810

EVAPORATIVE EMISSION
VENTILATION SOLENOID

INTAKE MANIFOLD
PLENUM

EVAPORATIVE EMISSION
PURGE SOLENOID

CHAMBER

EVAPORATIVE
EMISSION
CANISTER

*1

THROTTLE
BODY

FRONT

B : BLACK
*1:WHITE PAINT MARK

AB

B

B

B

B

B

EMISSION CONTROL

TSB Revision

ENGINE AND EMISSION CONTROL

17-81

VACUUM CIRCUIT DIAGRAM

M1173007100252

<2.4L ENGINE>

AK301813

B: BLACK
*1:RED PAINT MARK

THROTTLE BODY

INTAKE MANIFOLD

FROM
AIR CLEANER

TO
COMBUSTION
CHAMBER

EVAPORATIVE EMISSION
PURGE SOLENOID
(ON: OPEN)

EVAPORATIVE EMISSION
VENTILATION SOLENOID
(ON: CLOSED)

EVAPORATIVE EMISSION
CANISTER

AB

FUEL
TANK

B

B

B

B

B

B

B

CHAMBER

CHAMBER

*1

EMISSION CONTROL

TSB Revision

ENGINE AND EMISSION CONTROL

17-82

<3.8L ENGINE>

VACUUM HOSE INSTALLATION

M1173007200129

1. When connecting the vacuum hoses, they should be

securely inserted onto the nipples.

2. Connect the hoses correctly, using the VACUUM HOSE

ROUTING diagram as a guide.

AK301814

B: BLACK
*1:WHITE PAINT MARK

THROTTLE BODY

INTAKE MANIFOLD

FROM
AIR CLEANER

TO
COMBUSTION
CHAMBER

EVAPORATIVE EMISSION
PURGE SOLENOID
(ON: OPEN)

EVAPORATIVE EMISSION
VENTILATION SOLENOID
(ON: CLOSED)

EVAPORATIVE EMISSION
CANISTER

AB

FUEL
TANK

B

B

B

B

B

B

CHAMBER

*1
