DOOR SASH TAPE
EXTERIOR
51-13
REMOVAL SERVICE POINT
<<A>> DOOR SASH TAPES REMOVAL
CAUTION
Pay attention to keep from getting burned by hot
door panel or tapes.
1. Use a hair drier to warm the tape.
2. Peel the tip of the tape with your finger, and then
peel off the tape parallel to the application
surface.
INSTALLATION SERVICE POINT
>>A<< DOOR SASH TAPES INSTALLA-
TION
CAUTION
• The ambient temperature should be 20 to
30
°C. Ensure that the working area is clean.
Ideally, the tape application should be done at
ambient temperature of 25
°C.
• If ambient temperature is less than 15°C, heat
the tape and application surface to a tempera-
ture of 20 to 30
°C. If ambient temperature is
35
°C or higher, cool down them. The adhesive
property of the tape is deteriorated at low
temperature, so the tape may come adrift eas-
ily. Meanwhile, it gets softened at hot temper-
ature.
• When beginning to apply the tape, pay partic-
ular attention. If the end of the tape cannot be
applied to the specified position with an accu-
racy of less than 1 mm, it may cause the poor
appearance or adhesion.
•
AC303428
40 to 50˚
30 to 45˚
10 to 20 mm
10 to 20 mm
AB
MB990528
MB990528
Door sash tape
Door sash tape
Backing paper
Backing paper
<Pushing direction>
<Pulling direction>
3 to 7 cm/sec.
3 to 7 cm/sec.
Use the special tool stripe tape spatula
(MB990528) to apply the tape with a steady
pace and pressure. If you do not apply the
tape with a steady pace or pressure, or abort
the application, a shallow groove (lateral
groove called as "Shock line") may be
present on the tape surface. Meanwhile, if you
apply it too quickly, air bubbles may be
formed under the tape.
1. Wrap a soft cloth (synthetic fibre) around the tip of
the special tool.
2. Use isopropyl alcohol to degrease the tape
application surface.
3. Wipe away dirt from the tape.
