COLUMN SWITCH

CHASSIS ELECTRICAL

54A-73

COLUMN SWITCH

SPECIAL TOOL

M1542000600946

Tool

Number

Name

Use

MB990784

MB990784

Ornament remover Removal of column cover

COLUMN SWITCH

REMOVAL AND INSTALLATION

M1543009100510

AC211607

3

2

4

1

AC

A

A

A

A

A

Section A - A

2

1

Claw

A

A

A

Removal steps

1. Lower column cover
2. Upper column cover

3. Turn-signal and lighting switch
4. Windshield wiper and washer switch

Removal steps (Continued)

COLUMN SWITCH

CHASSIS ELECTRICAL

54A-74

INSPECTION

M1542011201804

COLUMN SWITCH (SWITCH BODY) CON-
TINUITY CHECK

1. Removal the lighting switch and the wiper and

washer switch.

2. Check that there is continuity between the same

terminals [terminals (3) and (11)] of each
connector of the column switch body which is still
on the steering column.

1

6

8

11

10

9

7

5

4

3

2

1

6

8

11

10

9

7

5

4

3

2

AC005499

At lighting
switch side

At wiper/washer
switch side

AD

Column switch
body

Tester
connection

Specified
condition

Lighting switch side
connector, Wiper
and washer switch
side connector

3

− 3, 4 − 4, 5

− 5, 6 − 6, 7 −
7, 8

− 8, 9 − 9,

10

− 10, 11 −

11

Less than 2
ohms

HORN

CHASSIS ELECTRICAL

54A-75

HORN

REMOVAL AND INSTALLATION

M1543007900479

AC211783AC

1

2

Removal Steps

1. Horn <LO>
2. Horn <HI>

CLOCK

CHASSIS ELECTRICAL

54A-76

HORN RELAY CONTINUITY CHECK

M1543019502418

AC305306

1

4

3

2

AB

Horn relay

Battery voltage

Tester
connection

Specified
condition

Not applied

1

− 4

Open circuit

• Connect terminal

2 to the positive
battery terminal

• Connect terminal

3 to the negative
battery terminal

1

− 4

Less than 2
ohms

CLOCK

SPECIAL TOOL

M1543000601663

Tool

Number

Name

Use

MB990784

MB990784

Ornament remover Removal of centre panel and

centre air outlet panel
