Mitsubishi Lancer Evolution IX. Manual - part 34

METER AND GAUGE

CIRCUIT DIAGRAMS

90-115

NOTES

METER AND GAUGE

CIRCUIT DIAGRAMS

90-116

METER AND GAUGE <RH drive vehicles>

M1901003501919

IGNITION
SWITCH (IG1)

COMBINATION
METER

ENGINE
COOLANT
TEMPERATURE
GAUGE UNIT

FUEL
GAUGE
UNIT (SUB)

FUEL PUMP
AND GAUGE
UNIT (MAIN)

CONTROL CIRCUIT

·ENGINE CONTROL
 SYSTEM
·ENGINE OIL LEVEL
 WARNING LAMP
·HEADLAMP
·REAR FOG LAMP
·TAIL LAMP, POSITION
 LAMP, LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER
·TURN-SIGNAL LAMP
 AND HAZARD
 WARNING LAMP
·WINDSHIELD WIPER
 AND WASHER

METER AND GAUGE

CIRCUIT DIAGRAMS

90-117

BATTERY

FRONT-ECU

TAIL LAMP
RELAY

ENGINE
SPEED
DETECTION
CONNECTOR

ENGINE-
ECU

·HEADLAMP
·HEADLAMP LEVELLING
 SYSTEM
·REAR FOG LAMP
·TAIL LAMP, POSITION
 LAMP, LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER
·TURN-SIGNAL LAMP
 AND HAZARD
 WARNING LAMP
·WINDSHIELD WIPER
 AND WASHER

·HEADLAMP
·REAR FOG LAMP
·TAIL LAMP, POSITION
 LAMP, LICENCE PLATE
 LAMP AND LIGHTING
 MONITOR BUZZER
·TURN-SIGNAL LAMP
 AND HAZARD
 WARNING LAMP
·WINDSHIELD WIPER
 AND WASHER

TAIL LAMP,
POSITION
LAMP, LICENCE
PLATE LAMP
AND LIGHTING
MONITOR
BUZZER

RELAY
BOX

RELAY
BOX

LCD ODO/ TRIP

METER AND GAUGE

CIRCUIT DIAGRAMS

90-118

METER AND GAUGE <RH drive vehicles> (CONTINUED)

J/C (2)

DIAGNOSIS
CONNECTOR

VEHICLE
SPEED
SENSOR

J/B

(FUSE     )

2

FUSIBLE
LINK

1

FRONT SIDE

ENGINE
CONTROL
SYSTEM

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue    W : White
Y : Yellow     SB : Sky blue     BR : Brown    O : Orange
GR : Grey     R : Red     P : Pink     V : Violet    PU : Purple
