If an obstruction in the same detection range is detected continuously for 6
seconds or longer, only the warning sound stops (excluding the closest detection
range). When the detection range changes to the close side, the warning sound
resumes.

Turning oﬀ the parking sensors

The parking sensors turn oﬀ and the parking sensor OFF switch indicator light turns
on.
If the switch is pressed again, the parking sensors become operational and the
indicator light of the switch turns oﬀ.

System problem indication



If a problem occurs, the following display notiﬁes the driver. The system may have
a malfunction. Have the vehicle inspected by an Authorized Mazda Dealer.

(Vehicles without 360° View Monitor)

Driving

Parking Sensor

5-207

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Winter Driving

Carry emergency gear, including tire
chains, window scraper, ﬂares, a small
shovel, jumper cables, and a small bag
of sand or salt.
Ask an Authorized Mazda Dealer to
check the following:



Have the proper ratio of antifreeze in
the radiator.
Refer to Inspecting the Coolant on
page 9-18.



Inspect the battery and its cables.
Cold reduces battery capacity.



Use an engine oil appropriate for the
lowest ambient temperatures that
the vehicle will be driven in (page
9-22).



Inspect the ignition system for
damage and loose connections.



Use washer ﬂuid made with
antifreeze

―

but do not use engine

coolant antifreeze for washer ﬂuid
(page 9-21).

When driving on ice or in water, snow,
mud, sand, or similar hazards:



Be cautious and allow extra distance
for braking.



Avoid sudden braking and sudden
maneuvering.



Do not pump the brakes. Continue
to press down on the brake pedal.
Refer to Antilock Brake System (ABS)
on page 5-84.



If you get stuck, select a lower gear
and accelerate slowly. Do not spin
the front wheels.



For more traction in starting on
slippery surfaces such as ice or
packed snow, use sand, rock salt,
chains, carpeting, or other nonslip
material under the front wheels.

NOTE



Remove snow before driving. Snow
left on the windshield is dangerous
as it could obstruct vision.



Do not apply excessive force to a
window scraper when removing ice
or frozen snow on the mirror glass
and windshield.



Never use warm or hot water for
removing snow or ice from windows
and mirrors as it could result in the
glass cracking.



Drive slowly. Braking performance
can be adversely aﬀected if snow or
ice adheres to the brake
components. If this situation occurs,
drive the vehicle slowly, releasing the
accelerator pedal and lightly applying
the brakes several times until the
brake performance returns to
normal.

Driving

Winter Driving

5-209

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Snow Tires

WARNING

Do Not Use Tires Other Than The
Speciﬁed Size. In Addition, Do Not
Mix Diﬀerent Types Of Tires.

Using tires with sizes other than the
speciﬁed size or mixing diﬀerent tire
types is dangerous. It could
compromise the vehicle's driveability,
resulting in an accident. In addition, it
could be in violation of the law.
Use the tire size indicated on the label
applied to the door frame of the
driver’s door while the door is open.
Use only the same type tires on all four
wheels.

CAUTION

Check local regulations before using
studded tires.

Use snow tires on all 4 wheels

Do not go faster than 120 km/h (75
mph) while driving with snow tires.
When installing winter tires, use tires of
the speciﬁed size and adjust the air
pressure of all the tires to the speciﬁed
value. (page 10-69).

Mexico

The vehicle is originally equipped with
summer tires designed for optimum
traction on wet and dry roads. If your
vehicle is to be used on snow and ice
covered roads, Mazda recommends
that you replace the tires originally
equipped on your vehicle with snow
tires during the winter months.

Except Mexico

The vehicle is originally equipped with
all season radials designed to be used
all year around. In some extreme
climates you may ﬁnd it necessary to
replace them with snow tires during
the winter months to further improve
traction on snow and ice covered
roads.

Driving

Winter Driving

5-210

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Tire Chains

Check local regulations before using
tire chains.

CAUTION



Chains may aﬀect handling.



Do not go faster than 50 km/h (30
mph) or the chain manufacturer's
recommended limit, whichever is
lower.



Drive carefully and avoid bumps,
holes, and sharp turns.



Avoid locked-wheel braking.



Do not use chains on a temporary
spare tire; it may result in damage to
the vehicle and to the tire.



Do not use chains on roads that are
free of snow or ice. The tires and
chains could be damaged.



Chains may scratch or chip
aluminum wheels.

NOTE

The tire pressure monitoring system
may not function correctly when using
tire chains.

Install the chains on the rear tires only.
Do not use chains on the front tires.
Please consult an Authorized Mazda
Dealer.

Installing the chains

1. If your vehicle is equipped with

wheel covers remove them,
otherwise the chain bands will
scratch them.

2. Secure the chains on the rear tires

as tightly as possible. Always follow
the chain manufacturer's
instructions.

3. Retighten the chains after driving

1/2

―

1 km (1/4

―

1/2 mile).

Driving

Winter Driving

5-211

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Turbocharger

(SKYACTIV-G 2.5T)

The turbocharger greatly enhances
engine power. Its advanced design
provides improved operation and
requires minimum maintenance.

Warnings and Cautions

for Using the

Turbocharger

CAUTION



After driving at freeway speeds or up
a long hill, idle the engine at least 30
seconds before stopping it.
Otherwise, the turbocharger could
be damaged. However, when i-stop
operates, idling is unnecessary.



Racing or over-revving the engine,
particularly after it's just been
started, can damage the
turbocharger.



To protect the engine from damage,
the engine is designed so that it
cannot be raced just after starting it
in extremely cold weather.

Driving

Turbocharger

5-212

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

How to Use the

Turbocharger

To get the most from it, observe the
following.
1. Change engine oil and ﬁlter

according to Scheduled
Maintenance.
Refer to Scheduled Maintenance
(U.S.A., Canada, and Puerto Rico)
on page 9-6.
Refer to Scheduled Maintenance
(Mexico) on page 9-9.

2. Use only recommended engine oil

(page 9-16). Extra additives are
NOT recommended.

Driving

Turbocharger

5-213

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Equipment to Make Cabin More
Comfortable

Fully Automatic Climate Control
System.....................................6-2

Air Vents............................... 6-2
How to Use the Air Vents....... 6-2
Fully Automatic Climate Control
System.................................. 6-4
Fully Automatic Climate Control
System Overview................... 6-6
How to Use the Fully Automatic
Climate Control System..........6-7
Operating Each Switch........... 6-7

Manual Climate Control
System...................................6-12

Air Vents............................. 6-12
How to Use the Air Vents..... 6-12
Manual Climate Control System
Overview............................ 6-15
How to Use the Manual Climate
Control System.................... 6-16
Operating Each Switch......... 6-18

Seat Warmer.......................... 6-21

Seat Warmer

...................... 6-21

Warnings and Cautions For Using
the Seat Warmer.................. 6-21
How to Use the Seat
Warmer...............................6-22
Convenient Ways to Use the Seat
Warmer...............................6-23

Heated Steering Wheel............ 6-24

Heated Steering Wheel

........6-24

Warnings and cautions For Using
the Heated Steering Wheel ..........
.......................................... 6-24
How to Use Heated Steering
Wheel.................................6-25
Convenient Ways to Use Heated
Steering Wheel.................... 6-25

*Some models.

6-1

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Air Vents

The location and the direction airﬂow
exits the air vents changes depending
on the air vent adjustment.

How to Use the Air Vents

Air vent open/closet

Move the knob fully in the fully open
or fully closed direction.

Driver's Side Vents

1. Open
2. Close

Passenger's Side Vents

1. Open
2. Close

Equipment to Make Cabin More Comfortable

Fully Automatic Climate Control System

6-2

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Airﬂow direction adjustment
Driver's Side Vents

Passenger's Side Vents

Airﬂow selection
Dashboard Vents

Dashboard and Floor Vents

Floor Vents

Equipment to Make Cabin More Comfortable

Fully Automatic Climate Control System

6-3

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Defroster and Floor Vents

Defroster Vents

Fully Automatic Climate

Control System

The following functions are
automatically controlled according to
the set temperature.



Airﬂow temperature control



Airﬂow amount control



Airﬂow mode switching



Recirculate/fresh air mode switching



Air conditioning (cooling/
dehumidifying functions) on/oﬀ



Seat warmer level selection



Heated steering wheel operation

NOTE

To prevent cold airﬂow immediately
after heating starts when the engine is
cold, the airﬂow amount is decreased.

Fully automatic air-conditioning uses
the sunlight and interior temperature
sensors to control the temperature in
the cabin by measuring interior and
exterior temperatures, humidity, and
sunlight. Do not cover the sunlight/
interior temperature sensor.

Sunlight sensor

Equipment to Make Cabin More Comfortable

Fully Automatic Climate Control System

6-4

*Some models.

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Fully Automatic Climate Control System Overview

1. Driver temperature control dial
2. AUTO switch
3. Temperature setting display (driver’s side)
4. Air intake display
5. Airﬂow display
6. Mode selector display
7. Temperature setting display (passenger’s side)
8. SYNC (synchronized temperature) switch
9. Passenger temperature control dial
10.Power switch
11.Rear window defogger switch
12.Windshield defroster switch
13.Mode selector switch
14.Fan control switch
15.Air intake selector switch
16.A/C switch

Equipment to Make Cabin More Comfortable

Fully Automatic Climate Control System

6-6

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

How to Use the Fully

Automatic Climate

Control System

1. Start the engine.
2.

The AUTO switch indicator light
turns on.

3. Turn the temperature control dial to

set the desired temperature.
Each function is automatically
controlled according to the set
temperature.

4. To stop the operation, press the

climate control system power
switch.

NOTE



The recommended set temperature
is 22

℃

(72

℉



If any mode selector switch, fan
control switch, or windshield
defroster switch is operated during
auto operation, the AUTO switch
indicator light turns oﬀ. The
functions for switches other than
those operated will continue to
operate in auto control.

Operating Each Switch

AUTO switch

Automatically controlled according to
the set temperature.

Temperature control dial

How to increase the set temperature

How to decrease the set temperature

Equipment to Make Cabin More Comfortable

Fully Automatic Climate Control System

6-7

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

NOTE



The set temperature changes in
increments of 0.5

℃

within a range

of 15

℃

(60

℉

) and 29

℃

(84

℉



When the temperature is set to the
lower or upper limit, “Lo” or “Hi” is
displayed.

SYNC (synchronized temperature)
switch

The mode switches between
independent mode and
interconnection mode each time the
switch is pressed.

Independent mode (indicator light
turned oﬀ)

The set temperature can be controlled
independently for the driver's side and
front passenger's side.
Turn the driver’s side temperature
control dial or the front passenger’s
side temperature control dial to
control the temperature.

Interconnection mode (indicator light
turned on)

The set temperature for the driver's
side and front passenger's side is
controlled simultaneously.
Turn the driver's side temperature
control dial to control the temperature.

NOTE



The set temperature for the front
passenger's side changes to that of
the driver when independent mode
is switched to interconnection mode.



When the front passenger’s side
temperature control dial is turned
while in interconnection mode
(SYNC switch indicator light turned
on), the mode switches to
independent mode (SYNC switch
indicator light turned oﬀ).

A/C switch

The cooling/dehumidifying function
switches between on and oﬀ each time
the switch is pressed. The indicator
light turns on while the function is
operating.

NOTE

The air conditioner may not operate
when the ambient temperature falls to
nearly 0

℃

to protect the system.

Rear window defogger switch

Use to defog the rear window.
Refer to How to Use the Rear Window
Defogger Switch on page 5-79.

Equipment to Make Cabin More Comfortable

Fully Automatic Climate Control System

6-8

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Air intake selector switch

The mode is switched between
recirculate mode and fresh air mode
each time the switch is pressed.
The display indicates whether
recirculate mode (

) or fresh air

mode (

) is selected.

WARNING

Do not recirculate the air in the cabin
during cold or rainy weather.

Recirculating the air in the cabin during
cold and rainy weather is dangerous as
it will cause the windows to fog up.
Your vision will be hampered, which
could lead to a serious accident.

Recirculate mode (

)

Outside air is shut oﬀ. Air within the
vehicle is recirculated. Use this
position when going through tunnels,
driving in congested traﬃc (high engine
exhaust areas) or when quick cooling is
desired.

Fresh air mode (

)

Outside air is allowed to enter the
cabin. Use this position for ventilation
or windshield defrosting.

NOTE



The recirculated air position is the
default position whenever the
vehicle power is switched ON, the
climate control system is on, and the
outside temperature exceeds about
73

℉

(23

℃



To exit the default recirculated air
position, press the air intake selector
switch to select the outside air
position.



When the air intake selector switch is
set to the outside air position and
the outside temperature exceeds
about 73

℉

(23

℃

), the climate

control system may automatically
select the recirculated air position to
improve the eﬃciency of the climate
control system.

Mode selector switch

The desired airﬂow mode can be
selected.
The mode changes each time the
switch is pressed. The selected mode is
indicated on the display.

NOTE

To set the air vent to

press the

windshield defroster switch.

Equipment to Make Cabin More Comfortable

Fully Automatic Climate Control System

6-9

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Fan control switch

How to increase the airﬂow amount

How to decrease the airﬂow amount

The airﬂow amount changes each time
the switch is pressed. The airﬂow
amount is indicated on the display.
The airﬂow amount can be adjusted to
7 levels.

Climate control system power switch
(system on/oﬀ)

Switches the climate control system on
and oﬀ.

The indicator light turns on while the
function is operating.

Windshield defroster switch

Switches the windshield defroster on
(indicator light turned on) and oﬀ
(indicator light turned oﬀ).
Use to defrost the windshield and side
windows.
The fresh air mode (

) is

automatically selected, and the air
conditioner automatically turns on
when the windshield defroster is
operating.

WARNING

Do not lower the airﬂow temperature
when defrosting the windshield.

Otherwise, the outer side of the
windshield will frost causing reduced
visibility which may lead to an
accident.

NOTE



For faster defrosting, do any of the
following operations.



Operate the fan switch and
increase the airﬂow amount.



Turn the temperature control dial
to increase the airﬂow
temperature.



Be careful that the windows do not
fog up when doing any of the
following operations.

Equipment to Make Cabin More Comfortable

Fully Automatic Climate Control System

6-10

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Air Vents

The location and the direction airﬂow
exits the air vents changes depending
on the air vent adjustment.

How to Use the Air Vents

Air vent open/closet

Move the knob fully in the fully open
or fully closed direction.

Driver's Side Vents

1. Open
2. Close

Passenger's Side Vents

1. Open
2. Close

Equipment to Make Cabin More Comfortable

Manual Climate Control System

6-12

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Airﬂow direction adjustment
Driver's Side Vents

Passenger's Side Vents

Airﬂow selection
Dashboard Vents

Dashboard and Floor Vents

Floor Vents

Equipment to Make Cabin More Comfortable

Manual Climate Control System

6-13

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

How to Use the Manual
Climate Control System

Heating

1. Start the engine.
2.

3. Set the air intake selector to the

outside air position (indicator light
turns oﬀ).

4. Set the temperature control dial to

the hot position.

5. Set the fan control dial to the

desired speed.

6. If dehumidiﬁed heating is desired,

turn on the air conditioner.

NOTE



If the windshield fogs up easily, press
the

switch.



If cooler air is desired at face level,
press the

switch and adjust the

temperature control dial to maintain
maximum comfort.



The air to the ﬂoor is warmer than air
to the face (except when the
temperature control dial is set at the
extreme hot or cold position).

Cooling

1. Start the engine.

3. Set the temperature control dial to

the cold position.

4. Set the fan control dial to the

desired speed.

5. Turn on the air conditioner by

pressing the A/C switch.

6. After cooling begins, adjust the fan

control dial and temperature
control dial as needed to maintain
maximum comfort.

CAUTION

If the air conditioner is used while
driving up long hills or in heavy traﬃc,
monitor the high engine coolant
temperature warning light to see if it is
displayed (page 8-41).
The air conditioner may cause
overheating. If the warning light is
displayed, turn the air conditioner oﬀ
(page 8-21).

NOTE



When maximum cooling is desired,
set the temperature control dial to
the extreme cold position and set
the air intake selector to the
recirculated air position, then turn
the fan control dial fully clockwise.



If warmer air is desired at ﬂoor level,
press the

switch and adjust the

temperature control dial to maintain
maximum comfort.

Equipment to Make Cabin More Comfortable

Manual Climate Control System

6-16

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43



The air to the ﬂoor is warmer than air
to the face (except when the
temperature control dial is set at the
extreme hot or cold position).

Ventilation

1. Start the engine.
2.

3. Set the air intake selector to the

outside air position (indicator light
turns oﬀ).

4. Set the temperature control dial to

the desired position.

5. Set the fan control dial to the

desired speed.

Windshield Defrosting and Defogging

1. Start the engine.
2.

3. Set the temperature control dial to

the desired position.

4. Set the fan control dial to the

desired speed.

5. If dehumidiﬁed heating is desired,

turn on the air conditioner.

WARNING

Do not defog the windshield using the

switch with the temperature

control set to the cold position:

Using the

switch with the

temperature control set to the cold
position is dangerous as it will cause
the outside of the windshield to fog
up. Your vision will be hampered,
which could lead to a serious accident.
Set the temperature control to the hot
or warm position when using the
switch.

NOTE



Fogging on the windows clears up
more easily while the air conditioner
is on, but they will fog up more easily
if the air conditioner is turned oﬀ.



Be careful that the windows do not
fog up when doing any of the
following:



Switching to recirculate mode



Turning oﬀ the air conditioner



For maximum defrosting, turn on the
air conditioner, set the temperature
control dial to the extreme hot
position, and turn the fan control
dial fully clockwise.



If warm air is desired at the ﬂoor,
press the

switch.



With the

switch, the outside air

position is automatically selected to
defrost the windshield. The air intake
selector cannot be changed to the
recirculated air position.

Dehumidifying

Operate the air conditioner in cool or
cold weather to help defog the
windshield and side windows.
1. Start the engine.

Equipment to Make Cabin More Comfortable

Manual Climate Control System

6-17

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

2. Press the desired mode switch you

want to set.

3. Set the air intake selector to the

outside air position (indicator light
turns oﬀ).

4. Set the temperature control dial to

the desired position.

5. Set the fan control dial to the

desired speed.

6. Turn on the air conditioner by

pressing the A/C switch.

NOTE

One of the functions of the air
conditioner is dehumidifying the air
and, to use this function, the
temperature does not have to be set to
cold. Therefore, set the temperature
control dial to the desired position
(hot or cold) and turn on the air
conditioner when you want to
dehumidify the cabin air.

Operating Each Switch

Temperature control dial

How to increase the set temperature

How to decrease the set temperature

MAX A/C
Fully turn the temperature control dial
counterclockwise for MAX A/C
(maximum cooling).

NOTE

When the mode is set to

with

the fan control dial in a position other
than 0 and the temperature control
dial in the MAX A/C position, the air
intake selector switches to the
recirculated air position and the A/C
turns on automatically.
If A/C is not desired, press the A/C
switch to turn it oﬀ.

Equipment to Make Cabin More Comfortable

Manual Climate Control System

6-18

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Fan control dial

How to increase the airﬂow amount

How to decrease the airﬂow amount

This dial allows variable fan speeds.
The airﬂow amount can be adjusted to
7 levels.

Mode selector switches

The desired airﬂow mode can be
selected.

A/C switch

Switches the air conditioner on and
oﬀ.
The indicator light on the switch will
illuminate when the fan control dial is
in any position except OFF.

NOTE

The air conditioner may not operate
when the ambient temperature falls to
nearly 0

℃

(32

℉

) to protect the

system.

Air intake selector switch

The mode is switched between
recirculate mode and fresh air mode
each time the switch is pressed.

Equipment to Make Cabin More Comfortable

Manual Climate Control System

6-19

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

WARNING

Do not recirculate the air in the cabin
during cold or rainy weather.

Recirculating the air in the cabin during
cold and rainy weather is dangerous as
it will cause the windows to fog up.
Your vision will be hampered, which
could lead to a serious accident.

Recirculated mode (indicator light
illuminated)

Outside air is shut oﬀ. Air within the
vehicle is recirculated. Use this
position when going through tunnels,
driving in congested traﬃc (high engine
exhaust areas), or when quick cooling
is desired.

Outside air mode (indicator light
turned oﬀ)

Outside air is allowed to enter the
cabin. Use this position for ventilation
or windshield defrosting.

NOTE



The recirculated air position is the
default position whenever the
ignition is switched ON, the climate
control system is on, and the outside
temperature exceeds about 73

℉

(23

℃



To exit the default recirculated air
position, press the air intake selector
switch to select the outside air
position.



When the air intake selector switch is
set to the outside air position and
the outside temperature exceeds
about 73

℉

(23

℃

), the climate

control system may automatically
select the recirculated air position to
improve the eﬃciency of the climate
control system.

Windshield defroster switch

Use to defrost the windshield and front
door windows.

WARNING

Do not lower the airﬂow temperature
when defrosting the windshield.

Otherwise, the outer side of the
windshield will frost causing reduced
visibility which may lead to an
accident.

Rear window defogger switch

Use to defog the rear window.
Refer to How to Use the Rear Window
Defogger Switch on page 5-79.

Equipment to Make Cabin More Comfortable

Manual Climate Control System

6-20

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Seat Warmer

The seat warmer warms the seat.

Warnings and Cautions

For Using the Seat

Warmer

WARNING

Be careful when using the seat
warmer.

The heat from the seat warmer may be
too hot for the following people and
could cause a low-temperature burn.



Infants, small children, elderly
people, and physically challenged
people



People with delicate skin



People who are excessively fatigued



People who are intoxicated



People who have taken
sleep-inducing medicine such as
sleeping pills or cold medicine

Do not use the seat warmer with
anything having high
moisture-retention ability such as a
blanket or cushion on the seat.

The seat may be heated excessively
and cause a low-temperature burn.

Do not use the seat warmer even
when taking a short nap in the
vehicle.

The seat may be heated excessively
and cause a low-temperature burn.

Do not place heavy objects with sharp
projections on the seat, or insert
needles or pins into it.

This could cause the seat to become
excessively heated and result in injury
from a minor burn.

Equipment to Make Cabin More Comfortable

Seat Warmer

*Some models.

6-21

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

CAUTION



Do not use organic solvents to clean
the seat. It may damage the seat
surface and the heater.

How to Use the Seat

Warmer

1. Start the engine.
2.

1. OFF
2. High
3. Mid
4. Low
The indicator light in the seat
warmer switch turns on according
to the set temperature.
The set temperature changes each
time the seat warmer switch is
pressed.

NOTE

If the engine is stopped while the seat
warmer is operating in manual mode,
the seat warmer does not turn on
automatically the next time the engine
is started. To turn the seat warmer on,
press the switch again.

Equipment to Make Cabin More Comfortable

Seat Warmer

6-22

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Convenient Ways to Use

the Seat Warmer

The seat temperature for front seat can
be automatically controlled (auto
mode) at 4 levels (High, Mid, Low,
OFF) according to the conditions in the
cabin.
The seat warmer can be operated in
conjunction with auto mode for the
climate control system.
1. Turn on the “Occupant Comfort”

Refer to Mazda Connect Owner's
Manual or consult an Authorized
Mazda Dealer.

2. Press the AUTO switch for the

climate control system.

NOTE



If the front passenger’s seat belt is
unfastened, the front passenger’s
seat warmer turns oﬀ.



If the seat warmer switch is pressed
during auto mode, the seat warmer
on the side where the switch was
pressed switches to manual mode.
To return to auto mode, press the
AUTO switch.



If the engine is turned oﬀ while the
seat warmer is operating in auto
mode, the seat warmer operates in
auto mode again the next time the
engine is turned on.

Equipment to Make Cabin More Comfortable

Seat Warmer

6-23

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Heated Steering Wheel

The grips on the left and right of the
steering wheel can be warmed up.

Warnings and cautions

For Using the Heated

Steering Wheel

WARNING

The following types of persons should
be careful not to touch the steering
wheel. Otherwise, it could cause a
low-temperature burn.



Infants, small children, elderly
people, and physically challenged
people



People with delicate skin



People who are excessively fatigued



People who are intoxicated



People who have taken
sleep-inducing medicine such as
sleeping pills or cold medicine

Equipment to Make Cabin More Comfortable

Heated Steering Wheel

6-24

*Some models.

Mazda3_8LX5-EA-23E_Edition2_new

2023-4-17 20:22:43

Mazda 3 (2024 year). Manual in english - page 11
