Mazda CX-5 (2023 year). Manual in english - page 19





Maintenance and Care
Appearance Care
¾ Do not spray water in the engine
Use plenty of lukewarm or cold water
compartment. Otherwise, it could result
and a soft cloth when washing the
in engine-starting problems or damage
vehicle. Do not use a nylon cloth.
to electrical parts.
Rub gently when washing or drying the
¾ When washing and waxing the vehicle,
vehicle.
be careful not to apply excessive force to
Take your vehicle only to a car wash
any single area of the vehicle roof.
that keeps its brushes well maintained.
Otherwise, you could dent the vehicle.
Do not use abrasive cleansers or wax
that contain abrasives.
To help protect the finish from rust and
deterioration, wash your Mazda
thoroughly and frequently, at least once a
CAUTION
month, with lukewarm or cold water.
¾ Do not use steel wool, abrasive cleaners,
or strong detergents containing highly
If the vehicle is washed improperly, the
paint surface could be scratched. Here are
alkaline or caustic agents on
some examples of how scratching could
chrome-plated or anodized aluminum
occur.
parts. This may damage the protective
coating; also, cleaners and detergents
Scratches occur on the paint surface when:
may discolor or deteriorate the paint.
The vehicle is washed without first
Pay special attention to removing salt, dirt,
rinsing off dirt and other foreign matter.
mud, and other foreign material from the
The vehicle is washed with a rough, dry,
underside of the fenders, and make sure
or dirty cloth.
the drain holes in the lower edges of the
The vehicle is washed at a car wash that
doors and rocker panels are clean.
uses brushes that are dirty or too stiff.
Cleansers or wax containing abrasives
Insects, tar, tree sap, bird droppings,
are used.
industrial fallout, and similar deposits can
damage the finish if not removed
NOTE
immediately. When prompt washing with
plain water is ineffective, use a mild soap
Mazda is not responsible for scratches
made for use on vehicles.
caused by automatic car washes or
improper washing.
Thoroughly rinse off all soap with
Scratches are more noticeable on
lukewarm or cold water. Do not allow
vehicles with darker paint finishes.
soap to dry on the finish.
To minimize scratches on the vehicle's
paint finish:
After washing the vehicle, dry it with a
clean chamois to prevent water spots from
Rinse off any dirt or other foreign matter
forming.
using lukewarm or cold water before
washing.
6-51
Maintenance and Care
Appearance Care
Always wash and dry the vehicle before
WARNING
waxing it. In addition to the vehicle body,
wax the metal trim to maintain its luster.
Dry off brakes that have become wet by
driving slowly, releasing the accelerator
1. Use wax which contains no abrasives.
pedal and lightly applying the brakes
Wax containing abrasives will remove
several times until the brake performance
paints and could damage bright metal
returns to normal:
parts.
Driving with wet brakes is dangerous.
2. Use a good grade of natural wax for
Increased stopping distance or the vehicle
metallic, mica, and solid colors.
pulling to one side when braking could
3. When waxing, coat evenly with the
result in a serious accident. Light braking
sponge supplied or a soft cloth.
will indicate whether the brakes have been
4. Wipe off the wax with a soft cloth.
affected.
NOTE
When using an automatic car wash
A spot remover to remove oil, tar, and
similar materials will usually also take off
Retract the door mirrors.
the wax. Rewax these areas even if the rest
The automatic car wash brushes could
of the vehicle does not need it.
reduce the paint luster or hasten paint
deterioration.
Repairing Damage to the Finish
When using a high water pressure car
Deep scratches or chips on the finish
wash
should be repaired promptly. Exposed
High water temperature and high water
metal quickly rusts and can lead to major
pressure car washers are available
repairs.
depending on the type of car wash
machine. If the car washer nozzle is put
CAUTION
too close to the vehicle, the force of the
If your Mazda is damaged and needs metal
spray could damage or deform the
parts repaired or replaced, make sure the
molding, affect the sealability of parts, and
body shop applies anti-corrosion materials
allow water to penetrate the interior. Keep
to all parts, both repaired and new. This
a sufficient space (30 cm (12 in) or more)
will prevent them from rusting.
between the nozzle and the vehicle. In
addition, do not spend too much time
Bright-Metal Maintenance
spraying the same area of the vehicle, and
be very careful when spraying between
Use tar remover to remove road tar and
gaps in doors and around windows.
insects. Never do this with a knife or
similar tool.
Waxing
To prevent corrosion on bright-metal
Your vehicle needs to be waxed when
surfaces, apply wax or chrome
water no longer beads on the finish.
preservative and rub it to a high luster.
6-52
Maintenance and Care
Appearance Care
During cold weather or in coastal areas,
should not be clogged. Water trapped there
cover bright-metal parts with a coating
will cause rusting.
of wax or preservative heavier than
usual. It would also help to coat them
WARNING
with noncorrosive petroleum jelly or
some other protective compound.
Dry off brakes that have become wet by
driving slowly, releasing the accelerator
CAUTION
pedal and lightly applying the brakes
several times until the brake performance
Do not use steel wool, abrasive cleaners, or
returns to normal:
strong detergents containing highly
Driving with wet brakes is dangerous.
alkaline or caustic agents on
Increased stopping distance or the vehicle
chrome-plated or anodized aluminum
pulling to one side when braking could
parts. This may result in damage to the
result in a serious accident. Light braking
protective coating and cause discoloration
will indicate whether the brakes have been
or paint deterioration.
affected.
Underbody Maintenance
Aluminum Wheel Maintenance
Road chemicals and salt used for ice and
A protective coating is provided over the
snow removal and solvents used for dust
aluminum wheels. Special care is needed
control may collect on the underbody. If
to protect this coating.
not removed, they will speed up rusting
and deterioration of such underbody parts
CAUTION
as fuel lines, frame, floor pan, and exhaust
system, even though these parts may be
Do not use any detergent other than mild
coated with anti-corrosive material.
detergent. Before using any detergent,
verify the ingredients. Otherwise, the
Thoroughly flush the underbody and
product could discolor or stain the
wheel housings with lukewarm or cold
aluminum wheels.
water at the end of each winter. Try also to
do this every month.
NOTE
Do not use a wire brush or any abrasive
Pay special attention to these areas
cleaner, polishing compound, or solvent
because they easily hide mud and dirt. It
on aluminum wheels. They may damage
will do more harm than good to wet
the coating.
down the road grime without removing
Always use a sponge or soft cloth to
it.
clean the wheels.
The lower edges of doors, rocker panels,
and frame members have drain holes that
6-53
Maintenance and Care
Appearance Care
Rinse the wheels thoroughly with
Do not use wax containing compounds
lukewarm or cold water. Also, be sure to
(polish). Otherwise, it could result in
clean the wheels after driving on dusty
paint damage.
or salted roads to help prevent
In addition, do not use an electrical or
corrosion.
air tool to apply wax. Otherwise, the
Avoid washing your vehicle in an
frictional heat generated could result in
automatic car wash that uses high-speed
deformation of plastic parts or paint
or hard brushes.
damage.
(19-inch wheel vehicle)
If your aluminum wheels lose luster,
apply wax which contains no polishing
powder.
Plastic Part Maintenance
When cleaning the plastic lenses of the
lights, do not use gasoline, kerosene,
rectified spirit, paint, thinner, highly
acidic detergents, or strongly alkaline
detergents. Otherwise, these chemical
agents can discolor or damage the
surfaces resulting in a significant loss in
functionality. If plastic parts become
inadvertently exposed to any of these
chemical agents, flush with water
immediately.
If plastic parts such as the bumpers
become inadvertently exposed to
chemical agents or fluids such as
gasoline, oil, engine coolant, or battery
fluid, it could cause discoloration,
staining, or paint peeling. Wipe off any
such chemical agents or fluids using a
soft cloth immediately.
High water temperature and high water
pressure car washers are available
depending on the type of high pressure
car washer device. If the car washer
nozzle is put too close to the vehicle or
aimed at one area for an extended period
of time, it could deform plastic parts or
damage the paint.
6-54
Maintenance and Care
Appearance Care
off thoroughly and make sure there is
Interior Care
no remaining moisture on them.
WARNING
WARNING
Do not spray water into the vehicle cabin:
If a seat belt appears frayed or has
Spraying water into the vehicle cabin is
abrasions, have it replaced by an
dangerous as electrical devices such as the
Authorized Mazda Dealer:
audio and switches could get wet resulting
If a seat belt is used under such a condition,
in a malfunction or vehicle fire.
it cannot function at its full capacity which
could result in serious injury or death.
NOTE
Use a mild detergent to remove soiling
Do not wipe the interior using alcohol,
from a seat belt:
chlorine bleach, or organic solvents
If organic solvents are used for cleaning the
such as thinner, benzene, and gasoline.
seat belts or they become stained or
Otherwise, it may cause discoloration or
bleached, there is the possibility of them
stains.
becoming weakened and as a result, they
Rubbing hard with a stiff brush or cloth
may not function at their full capacity
may cause damage.
which could cause serious injury or death.
If the vehicle interior becomes soiled by
any of the following, wipe it off
NOTE
immediately using a soft cloth.
Clean seat belts diligently if they get dirty.
Leaving it uncleaned could cause
Leaving them uncleaned will make it
discoloration, stains, cracks, or peeling of
difficult to clean them later, and it may
the coating, and it will make it hard to
affect the smooth retracting of the seat
wipe off later.
belt.
Beverage or fragrance
Vinyl Upholstery Maintenance
Grease or oil
Remove dust and dirt from the vinyl
Soiling
upholstery using a brush or vacuum.
Seat Belt Maintenance
Remove soiling from vinyl upholstery
using a leather and vinyl upholstery
1. Clean the soiled area by lightly
cleaner.
dabbing it with a soft cloth soaked in a
mild detergent (approx. 5%) diluted
Upholstery Maintenance
with water.
1. Clean the soiled area by lightly
2. Wipe off the remaining detergent using
dabbing it with a soft cloth soaked in a
a cloth soaked in clean water and
mild detergent (approx. 5%) diluted
wrung out well.
with water.
3. Before retracting seat belts which have
been pulled out for cleaning, dry them
6-55
Maintenance and Care
Appearance Care
2.
Wipe off the remaining detergent using
If the leather upholstery gets wet,
a cloth soaked in clean water and
promptly remove moisture with a dry
wrung out well.
cloth. Remaining moisture on the
surface may cause deterioration such as
Leather Upholstery Maintenance*
hardening and shrinkage.
1.
Remove dust and sand using a vacuum
Exposure to direct sunlight for long
cleaner.
periods may cause deterioration and
2.
Wipe off the soiled area with a soft
shrinkage. When parking the car under
cloth and a suitable, special cleaner or
direct sunlight for long periods, shade
a soft cloth soaked in a mild detergent
the interior using sunshades.
(about 5%) diluted with water.
Do not leave vinyl products on the
3.
Wipe off the remaining detergent using
leather upholstery for long periods.
a cloth soaked in clean water and
They may affect the leather quality and
wrung out well.
coloring. If the cabin temperature
4.
Remove moisture with a dry, soft cloth
becomes hot, the vinyl may deteriorate
and allow the leather to further dry in a
and adhere to the genuine leather.
well-ventilated, shaded area. If the
Plastic Part Maintenance
leather gets wet such as from rain,
remove the moisture and dry it as soon
as possible.
CAUTION
NOTE
Do not use polishing agents.
Because genuine leather is a natural
Depending on the product ingredients,
material, its surface is not uniform and
they could cause discoloration, stains,
it may have natural scars, scratches,
cracks or peeling of the coating.
and wrinkles.
Instrument Panel Top (Soft pad)
To maintain the quality for as long as
Maintenance
possible, periodical maintenance, about
twice a year, is recommended.
Extremely soft material is used for the soft
If the leather upholstery comes into
pad surface. If the soft pad surface is
contact with any of the following, clean
rubbed harshly with a dry cloth, it could
it immediately.
result in the surface being damaged and
Leaving it uncleaned could cause
leaving white scratch marks.
premature wear, mold, or stains.
1. Wipe the soiled area with a soft cloth
soaked in a mild detergent (approx.
Sand or dirt
5%) diluted with water.
Grease or oil, such as hand cream
2. Wipe off the remaining detergent using
Alcohol, such as in cosmetic or hair
a cloth soaked in clean water and
dressing items
wrung out well.
6-56
*Some models.
Maintenance and Care
Appearance Care
Panel Maintenance
CAUTION
If a panel becomes soiled, wipe it off with
a soft cloth soaked in clean water and
¾ Do not scrape or scratch the inside of the
thoroughly wrung out.
window glass. It could damage the
If some areas require further cleaning, use
thermal filaments and the antenna lines.
the following procedure:
¾ When washing the inside of the window
1. Wipe the soiled area with a soft cloth
glass, use a soft cloth dampened in
soaked in a mild detergent (approx.
lukewarm water, gently wiping the
5 %) diluted with water.
thermal filaments and the antenna lines.
2. Wipe off the remaining detergent using
Use of glass cleaning products could
a cloth soaked in clean water and
damage the thermal filaments and the
wrung out well.
antenna lines.
NOTE
Cleaning the Floor Mats
Be particularly careful when cleaning
Rubber floor mats should be cleaned with
shiny surface panels and metallic parts
mild soap and water only.
such as plating as they can be scratched
easily.
WARNING
Active Driving Display
Maintenance*
Do not use rubber cleaners, such as tire
cleaner or tire shine, when cleaning rubber
The dust-proof sheet has a coating. When
floor mats:
cleaning, do not use a hard or
Cleaning the rubber floor mats with rubber
rough-surface cloth, or cleaning detergent.
cleaning products makes the floor mats
In addition, if a chemical solvent gets on
slippery.
the active driving display, wipe it off
This may cause an accident when
immediately. The dust-proof sheet could
depressing the accelerator or brake pedal
be damaged and the surface coating could
or when getting in or out of the vehicle.
be scratched. Use a fine, soft cloth such as
those used for cleaning eyeglasses.
After removing the floor mats for
NOTE
cleaning, always reinstall them securely
(page 3-48).
Use of compressed air when cleaning the
dust-proof sheet is recommended.
Cleaning the Window Interiors
If the windows become covered with an
oily, greasy, or waxy film, clean them with
glass cleaner. Follow the directions on the
container.
*Some models.
6-57
If Trouble Arises
7
Helpful information on what to do if a problem arises with the vehicle.
Parking in an Emergency
7-2
Warning/Indicator Lights and
Parking in an Emergency
7-2
Warning Sounds
7-22
If a Warning Light Turns On or
Flashes
7-22
Flat Tire
7-3
Message Indicated on Multi-
Spare Tire and Tool Storage
7-3
information Display*
7-37
Changing a Flat Tire
7-6
Message Indicated on Display*
.................................................... 7-39
Battery Runs Out
7-13
Warning Sound is Activated
7-41
Jump-Starting
7-13
When Liftgate Cannot be
Emergency Starting
7-16
Opened
7-46
Starting a Flooded Engine
7-16
When Liftgate Cannot be
Push-Starting
7-16
Opened
7-46
Overheating
7-17
Active Driving Display Does Not
Overheating
7-17
Operate
7-47
If the Active Driving Display Does
Emergency Towing
7-19
Not Operate
7-47
Towing Description
7-19
Tiedown Hooks*
7-20
*Some models.
7-1
If Trouble Arises
Parking in an Emergency
Parking in an Emergency
The hazard warning lights should always
be used when you stop on or near a
roadway in an emergency.
The hazard warning lights warn other
drivers that your vehicle is a traffic hazard
and that they must take extreme caution
when near it.
Depress the hazard warning flasher and all
the turn signals will flash. The hazard
warning indicator lights in the instrument
cluster flash simultaneously.
NOTE
The turn signals do not work when the
hazard warning lights are on.
Check local regulations about the use of
hazard warning lights while the vehicle
is being towed to verify that it is not in
violation of the law.
7-2
If Trouble Arises
Flat Tire
Spare Tire and Tool Storage
Spare tire and tools are stored in the locations illustrated in the diagram.
Type A
Jack lever
Lug wrench
Tiedown eyelet
Flat tire hold-down
bolt
Jack
Spare tire
Type B
Jack lever
Lug wrench
Tiedown eyelet
Flat tire hold-down
bolt
Jack
Spare tire
Some models.
7-3
If Trouble Arises
Flat Tire
Jack
Make sure the moving parts are kept
free from dirt or rust.
To remove the jack
Make sure the screw thread is
1.
Open the luggage board, and lift it.
adequately lubricated.
Spare Tire
Your Mazda has a temporary spare tire.
The temporary spare tire is lighter and
smaller than a conventional tire, and is
designed only for emergency use and
should be used only for VERY short
periods. Temporary spare tires should
NEVER be used for long drives or
extended periods.
WARNING
Do not install the temporary spare tire on
the front wheels (driving wheels):
Driving with the temporary spare tire on
one of the front driving wheels is
dangerous. Handling will be affected. You
could lose control of the vehicle, especially
2.
Remove the jack.
on ice or snow bound roads, and have an
accident. Move a regular tire to the front
wheel and install the temporary spare tire
to the rear.
CAUTION
¾ When using the temporary spare tire,
driving stability may decrease compared
to when using only the conventional tire.
Drive carefully.
¾ To avoid damage to the temporary spare
To secure the jack
tire or to the vehicle, observe the
following precautions:
Perform the removal procedure in reverse.
¾ Do not exceed 80 km/h (50 mph).
Maintenance
Always keep the jack clean.
7-4
If Trouble Arises
Flat Tire
¾ Avoid driving over obstacles. Also, do
2.
For vehicles equipped with a
not drive through an automatic car
sub-woofer, uncouple the connector.
wash. This tire's diameter is smaller
than a conventional tire, so the ground
clearance is reduced.
¾ Do not use a tire chain on this tire
because it will not fit properly.
¾ Do not use your temporary spare tire
on any other vehicle, it has been
designed only for your Mazda.
¾ Use only one temporary spare tire on
your vehicle at the same time.
Connector
To remove the spare tire
NOTE
1. Open the luggage board, and remove
Extra strength may be required to
it.
uncouple the connector. Be sure to
squeeze the tab firmly.
3.
For vehicles equipped with a
sub-woofer, loosen the hold-down bolt
and remove the woofer and spare tire.
7-5
If Trouble Arises
Flat Tire
For vehicles not equipped with a
Changing a Flat Tire
sub-woofer, turn the spare tire
hold-down bolt counterclockwise and
NOTE
remove the spare tire.
If the following occurs while driving, it
Spare tire hold-down bolt
could indicate a flat tire.
Steering becomes difficult.
The vehicle begins to vibrate
excessively.
The vehicle pulls in one direction.
If you have a flat tire, drive slowly to a
level spot that is well off the road and out
of the way of traffic to change the tire.
Stopping in traffic or on the shoulder of a
busy road is dangerous.
To secure the spare tire
WARNING
Store the spare tire in the reverse order of
removal. After storing, verify that the
Be sure to follow the directions for
spare tire is stored securely.
changing a tire:
Changing a tire is dangerous if not done
properly. The vehicle can slip off the jack
and seriously injure someone.
No person should place any portion of their
body under a vehicle that is supported by a
jack.
Never allow anyone inside a vehicle
supported by a jack:
Allowing someone to remain in a vehicle
supported by a jack is dangerous. The
occupant could cause the vehicle to fall
resulting in serious injury.
NOTE
Make sure the jack is well lubricated
before using it.
1. Park on a hard, level surface off the
right-of-way and firmly set the parking
brake.
7-6
If Trouble Arises
Flat Tire
2. Shift into Park (P) and turn off the
1. Loosen the lug nuts by turning them
engine.
counterclockwise one turn each, but do
3. Turn on the hazard warning flasher.
not remove any lug nuts until the tire
4. Have passengers get out of the vehicle
has been raised off the ground.
and away from the vehicle and traffic.
5. Remove any luggage, the jack, tools,
and spare tire (page 7-3).
6. Block the wheel diagonally opposite
the flat tire. When blocking a wheel,
place a tire block both in front and
behind the tire.
2.
Place the jack on the ground.
3.
Turn the jack screw in the direction
shown in the figure and adjust the jack
head so that it is close to the jack-up
position.
NOTE
Jack head
When blocking a tire, use rocks or
wood blocks of sufficient size if
possible to hold the tire in place.
Removing a Flat Tire
4.
Place the jack under the jack-up
WARNING
position closest to the tire being
changed with the jack head squarely
When jacking-up a vehicle, always shift the
under the jack-up point.
selector lever to P position, apply the
parking brake, and place wheel blocks in
the position diagonally opposed to the
jack:
Changing a flat tire without using wheel
blocks is dangerous because the vehicle
may move and fall off the jack even with
the selector lever is in P position, which
could result in an accident.
Jacking position
7-7
If Trouble Arises
Flat Tire
5.
Continue raising the jack head
Use only the jack provided with your
gradually by rotating the screw with
Mazda:
your hand until the jack head is
Using a jack that is not designed for
inserted into the jack-up position.
your Mazda is dangerous. The vehicle
could slip off the jack and seriously
injure someone.
Tire blocks
Never place objects under the jack:
Jacking the vehicle with an object
under the jack is dangerous. The jack
could slip and someone could be
seriously injured by the jack or the
falling vehicle.
Jacking position
NOTE
When raising the jack head into the
jacking position and aligning the
groove in the jack head with the rail
under the vehicle body, the top of the
WARNING
jack head contacts the vehicle's
underbody without the rail contacting
Use only the front and rear jacking
the bottom of the groove.
positions recommended in this manual:
6.
Insert the jack lever and attach the lug
Attempting to jack the vehicle in
wrench to tire jack.
positions other than those
recommended in this manual is
dangerous. The vehicle could slip off
the jack and seriously injure or even kill
someone. Use only the front and rear
jacking positions recommended in this
manual.
Do not jack up the vehicle in a position
other than the designated jack-up
position or place any objects on or
under the jack:
Jacking up the vehicle in a position
other than the designated jack-up
position or placing objects on or under
the jack is dangerous as it could deform
the vehicle body or the vehicle could fall
off the jack resulting in an accident.
7-8
If Trouble Arises
Flat Tire
7.
Turn the jack handle clockwise and
8. Remove the lug nuts by turning them
raise the vehicle high enough so that
counterclockwise; then remove the
the spare tire can be installed. Before
wheel and center cap.
removing the lug nuts, make sure your
Locking Lug Nuts
Mazda is firmly in position and that it
cannot slip or move.
If your Mazda is equipped with the
optional antitheft wheel lug nuts, a special
key must be used to unlock the locking lug
nut for each wheel. The key is stored in
the glove compartment, center console
storage, storage box, or trunk. Register the
key and lug nuts with the lock
manufacturer by filling out the registration
card and mailing it in using the
accompanying envelope. If the key is lost,
consult an Authorized Mazda Dealer or
use the lock manufacturer’s order form to
order a new key.
WARNING
Antitheft wheel lug nuts cannot be
installed on a steel wheel spare tire. When
Do not jack up the vehicle higher than
installing a temporary spare tire, use one
is necessary:
of the original lug nuts in place of the
Jacking up the vehicle higher than is
locking lug nut. The original lug nuts are
necessary is dangerous as it could
stored inside your Mazda.
destabilize the vehicle resulting in an
Antitheft lug nut Special key
accident.
Do not start the engine or shake the
vehicle while it is jacked up:
Starting the engine or shaking the
vehicle while it is jacked up is
dangerous as it could cause the vehicle
To remove an antitheft lug nut
to fall off the jack resulting in an
accident.
1. Obtain the special key for the antitheft
lug nut.
Never go under the vehicle while it is
2. Place the special key on top of the
jacked up:
antitheft lug nut, and be sure to hold
Going under the vehicle while it is
the key square to it. If you hold the key
jacked up is dangerous as it could result
at an angle, you may damage both key
in death or serious injury if the vehicle
and nut. Do not use a power impact
were to fall off the jack.
wrench.
7-9
If Trouble Arises
Flat Tire
3. Place the lug wrench on top of the key
When changing or replacing a tire, not
and apply pressure. Turn the wrench
removing dirt and grime from the
counterclockwise.
mounting surfaces of the wheel, hub
and hub bolts is dangerous. The lug
To install the antitheft lug nut
nuts could loosen while driving and
1. Place the special key on top of the nut,
cause the tire to come off, resulting in
and be sure to hold the key square to it.
an accident.
If you hold the key at an angle, you
2.
Mount the spare tire.
may damage both key and nut. Do not
3.
Install the lug nuts with the beveled
use a power impact wrench.
edge inward; tighten them by hand.
2. Place the lug wrench on top of the
special key, apply pressure, and turn it
clockwise.
Nut tightening torque
108―147 (12―14,
Nꞏm (kgfꞏm, ftꞏlbf)
80―108)
Mounting the Spare Tire
1.
Remove dirt and grime from the
mounting surfaces of the wheel and
hub, including the hub bolts, with a
cloth.
WARNING
Do not apply oil or grease to lug nuts
and bolts and do not tighten the lug
nuts beyond the recommended
tightening torque:
Applying oil or grease to lug nuts and
bolts is dangerous. The lug nuts could
loosen while driving and cause the tire
to come off, resulting in an accident. In
addition, lug nuts and bolts could be
damaged if tightened more than
necessary.
WARNING
4.
Turn the lug wrench counterclockwise
and lower the vehicle.
Make sure the mounting surfaces of the
wheel, hub and lug nuts are clean
before changing or replacing tires:
7-10
If Trouble Arises
Flat Tire
5. Use the lug wrench to tighten the nuts
6. Remove the center cap by tapping it
in the order shown.
from the backside of the wheel using
the lug wrench.
7. Store the damaged tire, using the flat
tire hold-down bolt to hold it in place.
(With sub-woofer)
Flat tire
hold-down bolt
Sub-woofer
If you are unsure of how tight the nuts
should be, have them inspected at an
Authorized Mazda Dealer.
Nut tightening torque
108―147 (12―14,
Nꞏm (kgfꞏm, ftꞏlbf)
80―108)
(Without sub-woofer)
WARNING
Flat tire
Always securely and correctly tighten
hold-down bolt
the lug nuts:
Improperly or loosely tightened lug
nuts are dangerous. The wheel could
wobble or come off. This could result in
loss of vehicle control and cause a
serious accident.
Be sure to reinstall the same nuts you
removed or replace them with metric
nuts of the same configuration:
Because the wheel studs and lug nuts
on your Mazda have metric threads,
using a non-metric nut is dangerous.
On a metric stud, it would not secure
the wheel and would damage the stud,
which could cause the wheel to slip off
and cause an accident.
7-11
If Trouble Arises
Flat Tire
8. Place the luggage board on the
damaged tire.
Luggage board
9. Remove the tire blocks and store the
tools and jack.
10. Check the inflation pressure. Refer to
Tires on page 9-7.
11. Have the flat tire repaired or replaced
as soon as possible.
WARNING
Do not drive with any tires that have
incorrect air pressure:
Driving on tires with incorrect air pressure
is dangerous. Tires with incorrect pressure
could affect handling and result in an
accident. When you check the regular tires'
air pressure, check the spare tire, too.
NOTE
To prevent the jack and tool from rattling,
store them properly.
7-12
If Trouble Arises
Battery Runs Out
Jump-Starting
Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel
unsure about jump-starting, we strongly recommend that you have a competent service
technician do the work.
WARNING
Follow These Precautions Carefully:
To ensure safe and correct handling of the battery, read the following precautions carefully
before using the battery or inspecting it.
Keep flames and sparks away from open battery cells and do not allow metal tools to
contact the positive (
) or negative (
) terminal of the battery when working near a battery.
Do not allow the positive (
) terminal to contact the vehicle body:
Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during
normal battery operation, could ignite and cause the battery to explode. An exploding battery
can cause serious burns and injuries. Keep all flames including cigarettes and sparks away
from open battery cells.
Keep all flames and sparks away from open battery cells because hydrogen gas is
produced from open battery cells while charging the battery or adding battery fluid:
Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during
normal battery operation, could ignite and cause the battery to explode. An exploding battery
can cause serious burns and injuries. Keep all flames including cigarettes and sparks away
from open battery cells.
Do not jump-start a frozen battery or one with a low fluid level:
Jump-starting a frozen battery or one with a low fluid level is dangerous. It may rupture or
explode, causing serious injury.
Connect the negative cable to a good ground point away from the battery:
Connecting the end of the second jumper cable to the negative (
) terminal of the discharged
battery is dangerous.
A spark could cause the gas around the battery to explode and injure someone.
7-13
If Trouble Arises
Battery Runs Out
Route the jumper cables away from parts that will be moving:
Connecting a jumper cable near or to moving parts (cooling fans, belts) is dangerous. The
cable could get caught when the engine starts and cause serious injury.
CAUTION
Use only a 12 V booster system. You can damage a 12 V starter, ignition system, and other
electrical parts beyond repair with a 24 V power supply (two 12 V batteries in series or a 24 V
motor generator set).
1. Move the booster vehicle so that its battery is as close as possible to your vehicle's
battery.
2. Make sure that the power such as for the headlights and air conditioner is turned off.
3. Remove the battery cover.
4. Turn off the booster vehicle's engine and connect the jumper cables in the following
order.
Make sure that the jumper cables are securely connected so that they do not disconnect
due to engine vibrations.
1st lead
Positive (+) terminal on the discharged battery
Positive (+) terminal on booster vehicle's battery
2nd lead
Negative (-) terminal on booster vehicle's battery
7-14
If Trouble Arises
Battery Runs Out
Location shown in the figure (do not connect to the negative (-) terminal of the
battery)
Connect cables in numerical order
and disconnect in reverse order.
Jumper cables
Discharged battery
Booster battery
5. Start the booster vehicle's engine and rev the engine.
6. Start the engine of your vehicle. Run the engines for about 3 minutes to temporarily
charge the battery of your vehicle.
7. Disconnect the jumper cables in the reverse order of their connection.
8. Install the battery cover.
9. Have your vehicle inspected by an Authorized Mazda Dealer as soon as possible.
NOTE
Verify that the covers are securely installed.
7-15
If Trouble Arises
Emergency Starting
Starting a Flooded Engine
Push-Starting
If the engine fails to start, it may be
Do not push-start your Mazda.
flooded (excessive fuel in the engine).
WARNING
Follow this procedure:
Never tow a vehicle to start it:
1. If the engine does not start within 5
Towing a vehicle to start it is dangerous.
seconds on the first try, wait 10
The vehicle being towed could surge
seconds and try again.
forward when its engine starts, causing the
2. Make sure the parking brake is on.
2 vehicles to collide. The occupants could
3. Depress the accelerator all the way and
be injured.
hold it there.
4. Depress the brake pedal, then press the
NOTE
push button start. If the engine starts,
You cannot start a vehicle with an
release the accelerator immediately
automatic transaxle by pushing it.
because the engine will suddenly rev
up.
5. If the engine fails to start, crank it
without depressing the accelerator.
If the engine still does not start using the
previous procedure, have your vehicle
inspected by an Authorized Mazda Dealer.
7-16
If Trouble Arises
Overheating
If the temperature gauge indicates
Overheating
overheating or the high engine coolant
If the temperature gauge indicates
temperature warning light turns on:
overheating or the high engine coolant
temperature warning light turns on, the
1.
Drive safely to the side of the road and
vehicle loses power, or you hear a loud
park off the right-of-way.
knocking or pinging noise, the engine is
2.
Shift into park (P).
probably too hot.
3.
Apply the parking brake.
4.
Turn off the air conditioner.
WARNING
5.
Check whether coolant or steam is
escaping from the engine
compartment.
Pull over to a safe location, then switch
If steam is coming from the engine
the ignition off and make sure the fan is
compartment:
not running before attempting to work
Do not go near the front of the vehicle.
near the cooling fan:
Stop the engine.
Working near the cooling fan when it is
Wait until the steam dissipates, then
running is dangerous. The fan could
open the hood and start the engine.
continue running indefinitely even if the
engine has stopped and the engine
If neither coolant nor steam is
compartment temperature is high. You
escaping:
could be hit by the fan and seriously
Open the hood and idle the engine
injured.
until it cools.
CAUTION
Do not remove either cooling
If the cooling fan does not operate
system cap when the engine and radiator
while the engine is running, the engine
are hot:
temperature will increase. Stop the
When the engine and radiator are hot,
engine and call an Authorized Mazda
scalding coolant and steam may shoot out
Dealer.
under pressure and cause serious injury.
6.
Make sure the cooling fan is operating,
then turn off the engine after the
Open the hood ONLY after steam is no
temperature has decreased.
longer escaping from the engine:
7.
When cool, check the coolant level.
Steam from an overheated engine is
dangerous. The escaping steam could
seriously burn you.
7-17
If Trouble Arises
Overheating
If it is low, look for coolant leaks from
CAUTION
the radiator and hoses.
If the engine continues to overheat or
If you find a leak or other damage, or if
frequently overheats, have the cooling
coolant is still leaking:
system inspected. The engine could be
Stop the engine and call an Authorized
seriously damaged unless repairs are
Mazda Dealer.
made. Consult an Authorized Mazda
SKYACTIV-G 2.5
Dealer.
Cooling system
cap
Coolant
reservoir
Cooling fan
SKYACTIV-G 2.5T
Cooling system cap
Coolant reservoir
Cooling fan
If you find no problems, the engine is
cool, and no leaks are obvious:
Carefully add coolant as required (page
6-22).
7-18
If Trouble Arises
Emergency Towing
Towing Description
WARNING
We recommend that towing be done only
by an Authorized Mazda Dealer or a
Always tow an AWD vehicle with all four
wheels off the ground:
commercial tow-truck service.
Towing an AWD vehicle with either the
Proper lifting and towing are necessary to
front or rear wheels on the ground is
prevent damage to the vehicle. Particularly
dangerous as the drive train could be
when towing an AWD vehicle, where all
damaged, or the vehicle could trail away
the wheels are connected to the drive train,
from the tow truck and cause an accident.
proper transporting of the vehicle is
If the drive train has been damaged,
transport the vehicle on a flatbed truck.
absolutely essential to avoid damaging the
drive system. Government and local laws
must be followed.
Wheel dollies
CAUTION
¾ Do not tow the vehicle pointed backward
with driving wheels on the ground. This
may cause internal damage to the
transaxle.
A towed FWD vehicle should have its
drive wheels (front wheels) off the ground.
If excessive damage or other conditions
prevent this, use wheel dollies.
When towing a FWD vehicle with the rear
wheels on the ground, release the parking
brake.
Refer to Electric Parking Brake (EPB) on
page 4-97.
A towed AWD vehicle must have all its
wheels off the ground.
7-19
If Trouble Arises
Emergency Towing
¾ Do not tow with sling-type equipment.
Tiedown Hooks
This could damage your vehicle. Use
wheel-lift or flatbed equipment.
CAUTION
Do not use the front and rear tiedown
eyelets for towing the vehicle.
They have been designed only for securing
the vehicle to a transport vessel during
shipping.
Using the eyelets for any other purpose
could result in the vehicle being damaged.
Tiedown Hooks
¾ If the parking brake cannot be released
1. Remove the tiedown eyelet and the lug
when towing the vehicle, transport the
wrench from the luggage compartment
vehicle with all front and rear wheels
(page 7-3).
raised off the ground as shown in the
2. Wrap a flathead screwdriver or similar
figure. If the vehicle is towed without
tool with a soft cloth to prevent
raising the wheels off the ground, the
damage to a painted bumper, and open
brake system could be damaged.
the cap located on the front or rear
bumper.
Front
Wheel dollies
7-20
*Some models.
If Trouble Arises
Emergency Towing
Rear
Rear
Tiedown eyelet
Jack lever
Lug wrench
4. Hook the tying rope to the tiedown
CAUTION
eyelet.
Do not use excessive force as it may
CAUTION
damage the cap or scratch the painted
bumper surface.
If the tiedown eyelet is not securely
tightened, it may loosen or disengage
NOTE
from the bumper when tying the
Remove the cap completely and store it
vehicle. Make sure that the tiedown
so as not to lose it.
eyelet is securely tightened to the
3. Securely install the tiedown eyelet
bumper.
using the lug wrench.
Front
Lug wrench
Tiedown
eyelet
7-21
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
If a Warning Light Turns On or Flashes
If any warning light turns on/flashes, take appropriate action for each light. There is no
problem if the light turns off, however if the light does not turn off or turns on/flashes again,
consult an Authorized Mazda Dealer.
The details for some warnings can be viewed on the center display or multi-information
display (Type A/Type B) in the instrument cluster.
Center display
Mazda Connect (Type A)
1. If the warning light is turned on, select the
icon on the home screen to display the
Applications screen.
2. Select “Vehicle Status Monitor”.
3. Select “Warning Guidance” to display the current warnings.
4. Select the applicable warning to view the warning details.
Mazda Connect (Type B)
1. Select “Information” on the home screen.
2. Select “Vehicle Status Monitor”.
3. Select the applicable warning to view the warning details.
NOTE
You can also display the currently occurring warning by sliding the commander knob to the
left while on the home screen of the center display.
Multi-information display (Type A/Type B)
1. Press the INFO switch on the steering switch to display the warning indication screen.
Refer to Multi-information Display (Type A) on page 4-14.
Refer to Multi-information Display (Type B) on page 4-32.
Stop Vehicle in Safe Place Immediately
If any of the following warning lights turns on, the system may have a malfunction. Stop the
vehicle in a safe place immediately and contact an Authorized Mazda Dealer.
7-22
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
This warning has the following functions:
Parking brake warning/Warning light inspection
The light illuminates when the parking brake is applied with the ignition switched to
START or ON. It turns off when the parking brake is released.
When the light turns on
If the brake system warning light remains turned on even though the parking brake is
released, the brake fluid may be low or there could be a problem with the brake sys-
tem. Park the vehicle in a safe place immediately and contact an Authorized Mazda
Dealer.
When the light is flashing
The light flashes if the Electric Parking Brake (EPB) has a malfunction.
If the light remains flashing even if the Electric Parking Brake (EPB) switch is oper-
ated, consult an Authorized Mazda Dealer as soon as possible.
Brake System Warning
WARNING
Indication/Warning
Light
Do not drive with the brake system warning light illuminated. Contact an Authorized
Mazda Dealer to have the brakes inspected as soon as possible:
Driving with the brake system warning light illuminated is dangerous. It indicates that
your brakes may not work at all or that they could completely fail at any time. If this
light remains illuminated, after checking that the parking brake is fully released, have
the brakes inspected immediately.
CAUTION
In addition, the effectiveness of the braking may diminish so you may need to depress
the brake pedal more strongly than normal to stop the vehicle.
If the electronic brake force distribution control unit determines that some compo-
nents are operating incorrectly, the control unit may illuminate the brake system
warning light and the ABS warning light simultaneously. The problem is likely to be
the electronic brake force distribution system.
WARNING
Electronic Brake Force
Distribution System
Do not drive with both the ABS warning light and brake warning light illuminated.
Warning
Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as
soon as possible:
Driving when the brake system warning light and ABS warning light are illuminated
simultaneously is dangerous.
When both lights are illuminated, the rear wheels could lock more quickly in an emer-
gency stop than under normal circumstances.
7-23
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
If the warning light illuminates while driving, it indicates a malfunction of the alter-
nator or of the charging system.
Drive to the side of the road and park off the right-of-way. Consult an Authorized
Mazda Dealer.
Charging System Warn-
ing Indication/Warning
CAUTION
Light
Do not continue driving when the charging system warning light is illuminated be-
cause the engine could stop unexpectedly.
This warning light indicates low engine oil pressure.
CAUTION
Do not run the engine if the oil pressure is low. Otherwise, it could result in extensive
engine damage.
If the light illuminates or the warning indication is displayed while driving:
1. Drive to the side of the road and park off the right-of-way on level ground.
2. Turn off the engine and wait 5 minutes for the oil to drain back into the oil pan.
3. Inspect the engine oil level (page 6-21). If it's low, add the appropriate amount of
Engine Oil Warning
engine oil while being careful not to overfill.
Light
CAUTION
Do not run the engine if the oil level is low. Otherwise, it could result in extensive
engine damage.
4. Start the engine and check the warning light.
If the light remains illuminated even though the oil level is normal or after adding oil,
stop the engine immediately and have your vehicle towed to an Authorized Mazda
Dealer.
The light flashes when the engine coolant temperature is extremely high, and illumi-
nates when the engine coolant temperature increases further.
Handling Procedure
Flashing light
Drive slowly to reduce engine load until you can find a safe place to stop the vehicle
and wait for the engine to cool down.
Illuminated light
(Red)
This indicates the possibility of overheating. Park the vehicle in a safe place immedi-
High Engine Coolant
ately and stop the engine.
Temperature Warning
Refer to Overheating on page 7-17.
Indication/Warning
Light
CAUTION
Do not drive the vehicle with the high engine coolant temperature warning light illumi-
nated. Otherwise, it could result in damage to the engine.
7-24
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal
Warning
The message is displayed if the electric power steering has a malfunction.
If the message is displayed, stop the vehicle in a safe place and do not operate the
steering wheel. There is no problem if the message in the display turns off after a
while. Contact an Authorized Mazda Dealer if the message is displayed continuously.
NOTE
If the message is displayed, the power steering will not operate normally. In this
Power Steering Mal-
case, the steering wheel can still be operated, however, the operation may feel
function Indication*
heavy compared to normal, or the steering wheel could vibrate when turning.
Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem.
If this occurs, park the vehicle safely and wait several minutes for the system to
return to normal.
The light illuminates/flashes if the electric power steering has a malfunction.
If the light illuminates/flashes, stop the vehicle in a safe place and do not operate the
steering wheel. There is no problem if the light turns off after a while. Contact an Au-
thorized Mazda Dealer if the light illuminates/flashes continuously.
NOTE
If the indicator light illuminates/flashes, the power steering will not operate norఆ
Power Steering Mal-
mally. If this happens, the steering wheel can still be operated, however, the operaఆ
function Indicator
tion may feel heavy compared to normal, or the steering wheel could vibrate when
Light*
turning.
Repeatedly jerking the steering wheel left and right while the vehicle is stopped or
moving extremely slowly will cause the power steering system to go into protective
mode which will make the steering feel heavy, but this does not indicate a problem.
If this occurs, park the vehicle safely and wait several minutes for the system to
return to normal.
Contact Authorized Mazda Dealer and Have Vehicle Inspected
If any of the following warning lights or the indicator light turns on/flashes, the system may
have a malfunction. Contact an Authorized Mazda Dealer to have your vehicle inspected.
Signal
Warning
If the ABS warning light stays on while you're driving, the ABS control unit has detected
a system malfunction. If this occurs, your brakes will function normally as if the vehicle
had no ABS.
Should this happen, consult an Authorized Mazda Dealer as soon as possible.
NOTE
ABS Warning Light
When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS
warning light may illuminate. If this occurs, it is the result of the weak battery and does
not indicate an ABS malfunction.
Recharge the battery.
The brake assist system does not operate while the ABS warning light is illuminated.
*Some models.
7-25















Content      ..     17      18      19      20     ..
