Interior Features
Interior Equipment
Center, Rear
¾ Correctly insert the plug into the
accessory socket.
The accessory sockets can be used
¾ Do not insert the cigarette lighter into
regardless of whether the ignition is on or
the accessory socket.
off.
¾ Noise may occur on the audio playback
depending on the device connected to
Center
the accessory socket.
¾ Depending on the device connected to
the accessory socket, the vehicle's
electrical system may be affected, which
could cause the warning light to
illuminate. Disconnect the connected
device and make sure that the problem is
resolved. If the problem is resolved,
disconnect the device from the socket
Rear
and switch the ignition off. If the problem
is not resolved, consult an Authorized
Mazda Dealer.
NOTE
To prevent discharging of the battery, do
not use the socket for long periods with the
engine off or idling.
Connecting the accessory socket
1. Open the lid.
CAUTION
2. Pass the connection plug cord through
the cutout of the console and insert the
¾ To prevent accessory socket damage or
plug into the accessory socket.
electrical failure, pay attention to the
following:
Plug
¾ Do not use accessories that require
more than 120 W (DC 12 V, 10 A).
¾ Do not use accessories that are not
genuine Mazda accessories or the
equivalent.
¾ Close the cover when the accessory
socket is not in use to prevent foreign
objects and liquids from getting into
the accessory socket.
5-61
Interior Features
Interior Equipment
How to connect
USB Power Outlet*
The groove in the armrest box can be used
The USB power outlets can be used
to pass the cord of the device into the box
regardless of whether the ignition is
to connect it to the USB power outlets.
switched to ACC or ON.
1. Open the lid.
Only use USB devices that have a
2. Route the cord through the groove in
maximum power consumption of 10.5W
the armrest box and insert the USB
(DC5V, 2.1A) or below.
connector into the USB power outlets.
USB Connector
USB power outlet
CAUTION
¾ To prevent USB power outlets damage or
electrical failure, pay attention to the
following:
¾ Do not use USB devices that require
more than 10.5 W (DC 5 V, 2.1 A).
¾ Close the lid when the USB power
outlets are not in use to prevent
foreign objects and liquids from
getting into the USB power outlets.
¾ Correctly connect the USB connector
into the USB power outlets.
NOTE
The USB power outlets are designed
only for charging and they cannot be
used for connecting to the vehicle's
audio system.
To prevent discharging of the battery, do
not use the USB power outlets for long
periods with the engine off or idling.
5-62
*Some models.
Interior Features
Interior Equipment
¾ Before using the Wireless Charger (Qi)
Wireless Charger (Qi)*
near people who use medical devices,
You can charge mobile devices such as
ask the medical device manufacturer or
Smartphones which comply with the Qi
your physician if radio waves from the
Wireless Charging standard.
Wireless Charger (Qi) will affect the
Only use mobile devices that have a
device.
maximum power consumption of 5 W, or
¾ The Wireless Charger (Qi) can be disabled
15 W or below. The maximum power
to prevent it from affecting medical
consumption differs depending on the
devices. Consult an Authorized Mazda
mobile device.
Dealer for details.
Heed the following cautions. Otherwise,
the Wireless Charger (Qi) may malfunction
or be damaged, which could cause a fire,
burns due to heat generation, or an
accident such as electrical shock.
¾ Do not install, remove, disassemble, or
change the wiring of the Wireless
Charger (Qi). If the Wireless Charger (Qi)
needs to be installed or removed, consult
Power button
an Authorized Mazda Dealer.
¾ Do not use the Wireless Charger (Qi)
when it is malfunctioning. In addition, if
smoke, abnormal noise, or abnormal
smell is emitted from the Wireless
Charger (Qi), stop the vehicle in a safe
place, switch the ignition OFF, and
LED indicator
consult an Authorized Mazda Dealer.
Charging area
¾ When using the Wireless Charger (Qi) to
store items on, turn off the Wireless
Charger (Qi).
WARNING
¾ Do not place any metal object between
the charging area and the mobile device.
Also, do not apply items such as a
Radio waves from the Wireless Charger (Qi)
metallic sticker to the Wireless Charger
may affect the operation of medical
(Qi).
devices such as implanted-type cardiac
pacemakers or defibrillators.
*Some models.
5-63
Interior Features
Interior Equipment
¾ When charging, do not place any item
the Wireless Charger (Qi). Press the
other than the mobile device to be
power button again for about 1
charged on the Wireless Charger (Qi). In
second to cancel the function.
addition, do not place any metal object,
IC card, coin, or magnetic item near the
LED indicator
charging area.
¾ Remove dust or dirt from the charging
The status of the Wireless Charger (Qi)
area before use.
can be checked using the LED indicator.
¾ Do not apply strong force or impact to
Illumination/flash
Status
the Wireless Charger (Qi) or get it wet.
pattern
¾ Use only mobile devices which support
OFF
Does not turn on
the Wireless Charger (Qi).
Stand-by (charging is pos-
Turns on in white
sible)
Normal charging
Turns on in amber
How to use
Fast charging*1
Turns on in green
1.
Start the engine.
Normal charging (charging
Flashes in amber
2.
The power for the Wireless Charger
efficiency is low)
(Qi) turns on and the LED indicator
Fast charging*1 (charging
Flashes in green
turns on.
efficiency is low)
Stand-by (charging is not
The power can be turned on/off by
Flashes in white
possible)
pressing the power button on the
Charging is stopped due to
Wireless Charger (Qi) for about 3
high temperature or foreign
Flashes in red
seconds.
matter detected
When the power is turned off, the
Charging is stopped due to
LED indicator turns off.
internal problem or mal-
Turns on in red
function
3.
Place a device compliant with the Qi
Wireless Charging standard in the
*1
Some mobile devices can switch
center of the charging area on the tray.
between normal charging and fast
The LED indicator turns on in amber
charging.
or green when charging starts.
For details on the LED indicator,
refer to the following LED indicator
CAUTION
table.
Charging starts when all the doors
¾ While a mobile device is placed on the
and liftgate are closed.
charging area, keep the vehicle key away
The function to reduce noise on the
from the Wireless Charger (Qi). The
radio operates if the power button is
vehicle key may not be detected due to
pressed for about 1 second during
radio wave interference by the Wireless
charging. Use it when noise occurs
Charger (Qi).
on the radio due to interference by
5-64
Interior Features
Interior Equipment
¾ Charging may not operate normally
¾ Do not leave mobile devices in the cabin.
under the following conditions:
The temperature inside the cabin may
become very hot, causing the devices to
¾ The mobile device is fully charged.
malfunction.
¾ There is foreign matter between the
mobile device and the charging area.
¾ The temperature of the mobile device
NOTE
is high.
¾ The mobile device is placed with the
A mobile device larger than the
charging side facing upward.
charging area cannot be charged. In
¾ The mobile device is placed in a
addition, even if the mobile device is in
position extremely deviating from the
the charging area, the charging
efficiency may decrease or charging
center of the charging area.
may not be possible depending on where
¾ Your vehicle is in an area where strong
the mobile device is placed.
radio waves or electrical noise occur
such as near a television tower, power
If the function to reduce noise on the
radio is used, fast charging may be
plant, or airport.
disabled depending on the mobile device
¾ The Near Field Communication (NFC)
being charged.
function setting of the mobile device is
If the LED indicator is flashing in amber
on (depends on the model of the
or green, the charging efficiency is low.
mobile device).
Check that there is no foreign matter
¾ Keep the following items away from the
between the mobile device and the
charging area. Otherwise the data stored
charging area, and position the mobile
on the mobile device could be erased or
device near the center of the charging
the device could malfunction.
area.
¾ Magnetic items such as magnets,
Depending on the mobile device case or
magnetic cards, and magnetic
accessories used, the mobile device may
recording media.
not charge, or the charging efficiency
¾ High precision devices such as
may be reduced resulting in a longer
wristwatches.
charging time. If charging does not start
¾ Before using the Wireless Charger (Qi),
even when a mobile device is placed on
make sure to back up the data stored on
the charging area, remove the mobile
the mobile device. The data on the
device case or any accessories.
mobile device could be deleted.
While the keyless entry is operating,
¾ Do not wipe the Wireless Charger (Qi)
charging may stop temporarily, however,
using oil, alcohol, or thinner, or spray
this does not indicate a problem.
hairspray or insecticide onto it.
During charging, the Wireless Charger
Otherwise, it could cause damage or
(Qi) and the mobile device become
cracking.
warm, however, this does not indicate a
problem.
5-65
Interior Features
Interior Equipment
If the mobile device temperature rises
Cup Holder
during charging, charging may stop due
to the protection function of the device.
If that happens, wait until the mobile
WARNING
device cools down sufficiently and then
recharge it.
Never use a cup holder to hold hot liquids
When using the Wireless Charger (Qi),
while the vehicle is moving:
applications using the Near Field
Using a cup holder to hold hot liquids while
Communication (NFC) function may
the vehicle is moving is dangerous. If the
activate, but this does not indicate a
contents spill, you could be scalded.
problem with the Wireless Charger (Qi).
Do not put anything other than cups or
drink cans in cup holders:
Trademarks
Putting objects other than cups or drink
cans in a cup holder is dangerous.
“Qi” and the Qi symbol are trademarks or
During sudden braking or maneuvering,
registered trademarks of the Wireless
Power Consortium (WPC).
occupants could be hit and injured, or
objects could be thrown around the
vehicle, causing interference with the driver
and the possibility of an accident. Only use
a cup holder for cups or drink cans.
Front
5-66
Interior Features
Interior Equipment
Rear*
Bottle Holder
The rear cup holder is on the rear center
Bottle holders are on the inside of the
armrest.
doors.
Front
Bottle holder
Rear
Bottle holder
CAUTION
Do not use the bottle holders for containers
without caps. The contents may spill when
opening/closing the door or while driving
the vehicle.
*Some models.
5-67
Interior Features
Interior Equipment
Push and release to open.
Storage Compartments
Type A
WARNING
Keep storage boxes closed when driving:
Driving with the storage boxes open is
dangerous. To reduce the possibility of
injury in an accident or a sudden stop, keep
the storage boxes closed when driving.
Type B
When loading cargo, make sure that it is
completely secured:
If the cargo is not completely secured, it
may move or collapse while driving or
during sudden braking, resulting in injury
or an accident.
Do not put articles in storage spaces with
no lid:
Glove Compartment
Putting articles in storage spaces with no
lid is dangerous as they could be thrown
To open the glove compartment, pull the
around the cabin if the vehicle is suddenly
latch toward you.
accelerated and cause injury depending on
how the article is stored.
CAUTION
Do not leave lighters or eyeglasses in the
storage boxes while parked under the sun.
A lighter could explode or the plastic
material in eyeglasses could deform and
crack from high temperature.
To close the glove compartment, firmly
press in the center of the glove
Overhead Console
compartment lid.
This console box is designed to store
eyeglasses or other accessories.
5-68
Interior Features
Interior Equipment
Center Console
To open, pull the release latch.
Storage tray
The storage tray can be removed.
Storage tray
Armrest Box*
To open, push the button and pull up the
lid.
*Some models.
5-69
Interior Features
Interior Equipment
Luggage Compartment
Cargo Securing Loops
Use the cargo securing loops in the luggage compartment to secure cargo with a rope or net.
The tensile strength of the loops is 196 N (20 kgf, 44 lbf). Do not apply excessive force to
the cargo securing loops as it will damage them.
Trim side
Luggage board side
CAUTION
When not using the cargo securing loops, return them to their original positions. If the cargo
securing loops are not returned to their original positions and cargo is placed on the top of
them, the cargo securing loops could be deformed or damaged.
When using the cargo securing loops, hook them to the pins.
Cargo securing
loop
Pin
Cargo Sub-Compartment
The cargo sub-compartment is located under the luggage board, and it can be used to store
small items.
5-70
Interior Features
Interior Equipment
CAUTION
¾ Do not apply excessive force to the luggage board when setting it up. Otherwise, it could
deform or damage the luggage board.
¾ Return the luggage board to its original position before driving the vehicle. If the vehicle is
driven with the luggage board set up, it could cause an unexpected accident.
¾ When not using the handle, return it to its original position. If the handle is not returned to
its original position and cargo is placed, it could contact the handle and the handle could
be deformed or damaged.
1. Lift up the luggage board.
Luggage board
2. Insert the luggage board into the left and right grooves.
Groove
Luggage board
Luggage Board
The height of the floor surface can be adjusted by changing the installation position of the
luggage board.
5-71
Interior Features
Interior Equipment
Reversible Luggage Board*
The luggage board can be used with the underside facing up, depending on the intended use.
The underside is made of stain-resistant material which is easy to clean.
CAUTION
Do not spray large amounts of liquid such as water on the luggage board. If a large amount
of water or other liquid is poured or sprayed on the luggage board, the water or other liquid
may leak down and wet the luggage under the board.
When using the luggage board in the upper level
1. Place the front luggage board.
Groove
Luggage board
2. Insert the left and right hollows or holes of the rear luggage board into the pins.
One-sided type
Reversible type
Hollows
Pin
Hole
Pin
3. Remove in the reverse order of the installation procedure.
When using the luggage board in the lower level
1. When not using the cargo securing loops, return them to their original positions.
Refer to Cargo Securing Loops on page 5-70
5-72
*Some models.
Interior Features
Interior Equipment
2. Slide the front luggage board into the lower grooves and install.
Groove
Luggage board
3. Insert the left and right hollows or holes of the rear luggage board into the pins.
One-sided type
Reversible type
Hollows
Pin
Hole
Pin
4. Remove in the reverse order of the installation procedure.
NOTE
Loading golf bags
(Some golf bags may not fit using the following methods depending on their sizes.)
Up to four golf bags can be carried in the luggage compartment.
Bottom: Place the first and second golf bags in the luggage compartment with the bottoms
pointed to the right.
5-73
Interior Features
Interior Equipment
Top: Place the third golf bag with its bottom pointed to the left and the fourth golf bag with
its bottom pointed to the right in the luggage compartment.
Bottom
Top
The arrows indicate the bottoms of the golf bags.
The illustration shows the loading of four golf bags.
Rear Coat Hooks
WARNING
Never hang heavy or sharp objects on the
assist grips and coat hooks:
Hanging heavy or sharp-ended objects
such as a coat hanger from the assist grips
or coat hooks is dangerous as they can fly
off and hit an occupant in the cabin if a
curtain air bag was to deploy, which could
result in serious injury or death.
Always hang clothes on the coat hooks
and the assist grips without hangers.
Coat hook
5-74
Maintenance and Care
6
How to keep your Mazda in top condition.
Essential Information
6-2
Engine Oil
6-20
Introduction
6-2
Engine Coolant
6-22
Brake Fluid
6-24
Washer Fluid
6-24
Scheduled Maintenance
6-4
Body Lubrication
6-25
Scheduled Maintenance (U.S.A.,
Wiper Blades
6-26
Canada, and Puerto Rico)
6-4
Battery
6-31
Scheduled Maintenance
Key Battery Replacement
6-33
(Mexico)
6-10
Tires
6-35
Light Bulbs
6-39
Owner Maintenance
6-15
Fuses
6-43
Owner Maintenance
Precautions
6-15
Appearance Care
6-49
Hood
6-17
Exterior Care
6-49
Engine Compartment
Interior Care
6-55
Overview
6-19
6-1
Maintenance and Care
Essential Information
Introduction
Be careful not to hurt yourself when inspecting your vehicle, replacing a tire, or doing some
kind of maintenance such as car washing. In particular, wear thick work gloves such as
cotton gloves when touching areas that are difficult to see while inspecting or working on
your vehicle. Doing inspections or procedures with your bare hands could cause injury.
If you are unsure about any procedure this manual describes, we strongly urge you to have a
reliable and qualified service shop perform the work, preferably an Authorized Mazda
Dealer.
Factory-trained Mazda technicians and genuine Mazda parts are best for your vehicle.
Without this expertise and the parts that have been designed and made especially for your
Mazda, inadequate, incomplete, and insufficient servicing may result in problems. This
could lead to vehicle damage or an accident and injuries.
For expert advice and quality service, consult an Authorized Mazda Dealer.
To continue warranty eligibility and to protect your investment, it is your responsibility to
properly maintain your vehicle according to factory recommended schedules outlined in this
manual. As part of this you must keep your maintenance records, receipts, repair orders and
any other documents as evidence this maintenance was performed. You must present these
documents, should any warranty coverage disagreement occur. Failure to do so can result in
your warranty being voided either in whole or in part.
This evidence may consist of the following:
The Mazda Scheduled Maintenance Record, refer to the Warranty Booklet, must be
completely filled out showing mileage, repair order number, date for each service, and
signed by a qualified automotive service technician who service vehicles.
Original copies of repair orders or other receipts that include the mileage and date the
vehicle was serviced. Each receipt should be signed by a qualified automotive service
technician.
For self maintenance, a statement that you completed the maintenance yourself,
displaying mileage and the date the work was performed. Also, receipts for the
replacement parts (fluid, filters, etc.) indicating the date and mileage must accompany this
statement.
6-2
Maintenance and Care
Essential Information
NOTE
If you elect to perform maintenance yourself or have your vehicle serviced at a location
other than an Authorized Mazda Dealer, Mazda requires that all fluids, parts and materials
must meet Mazda standards for durability and performance as described in this manual.
Claims against the warranty resulting from lack of maintenance, as opposed to defective
materials or authorized Mazda workmanship, will not be honored.
Any auto repair shop using parts equivalent to your Mazda's original equipment may
perform maintenance. But we recommend that it always be done by an Authorized
Mazda Dealer using genuine Mazda parts.
Selecting “Maintenance Monitor” enables the system to notify you of your vehicle's
approaching inspection/servicing period, refer to the Information section in the Mazda
Connect Owner's Manual for the details.
The malfunction diagnosis connector is designed exclusively for connecting the specially
designed device to perform on-board diagnosis.
Do not connect any devices other than the specially designed malfunction diagnosis devices
for servicing. If any device other than the malfunction diagnosis device is connected, it may
affect the vehicle's electrical devices or lead to damage such as battery depletion.
Malfunction
diagnosis
connector
6-3
Maintenance and Care
Scheduled Maintenance
Scheduled Maintenance (U.S.A., Canada, and Puerto
Rico)
Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions
(severe driving conditions) apply.
Repeated short-distance driving
Driving in dusty conditions
Driving with extended use of brakes
Driving in areas where salt or other corrosive materials are used
Driving on rough or muddy roads
Extended periods of idling or low-speed operation
Driving for long periods in cold temperatures or extremely humid climates
Driving in extremely hot conditions
Driving in mountainous conditions continually
If any do apply, follow Schedule 2. (Canada residents follow Schedule 2.)
Vehicles using Engine Oil Flexible Maintenance
Engine Oil Flexible Maintenance is selected by default for U.S.A. and Puerto Rico
residents.
If any following conditions do apply, follow Schedule 2 with engine oil fixed maintenance.
Extended periods of idling or low-speed operation such as police car, taxi or driving
school car
Driving in dusty conditions
The vehicle calculates the remaining oil life based on engine operating conditions. The
vehicle lets you know when an oil change is due by illuminating the wrench indicator light
in the instrument cluster. Change the oil as soon as possible within the next 1,000 km (600
mile) or 15 days. Refer to the Information section in the Mazda Connect Owner's Manual
for the details.
NOTE
Please ensure that the Flexible Oil Maintenance Setting is reset after each Oil and Filter
replacement.
For maintenance guidelines beyond the miles/months listed, follow the maintenance
intervals provided in the Scheduled Maintenance Tables.
6-4
Maintenance and Care
Scheduled Maintenance
Schedule 1
U.S.A. and Puerto Rico residents - Engine oil flexible maintenance interval
Use when the maintenance monitor for "Oil Change" is set to "Flexible". For the deဨ
tails, refer to the Information section in the Mazda Connect Owner's Manual.
Number of months or kilometers (miles), whichever comes first.
Months
12
24
36
48
60
72
84
96
Maintenance Interval
×1000 km
12
24
36
48
60
72
84
96
×1000 miles
7.5
15
22.5
30
37.5
45
52.5
60
SKYACTIV-G
Replace every 64,000 km (40,000 miles).
2.5T
Spark plugs
Except SKY-
ACTIV-G
Replace every 120,000 km (75,000 miles).
2.5T
Air filter
R
R
Drive belts
I
I
Replace when wrench indicator light is ON. (Max interval: 12
Engine oil & filter*1
months or 12,000 km (7,500 miles))
Replace at first 192,000 km (120,000 miles) or 10 years; after
Engine coolant*2
that, every 96,000 km (60,000 miles) or 5 years.
Fuel lines and hoses*3
I
I
I
I
Hoses and tubes for emission*3
I
I
Brake lines, hoses and connections
I
I
I
I
Disc brakes
I
I
I
I
I
I
I
I
Tire (Rotation)
Rotate every 12,000 km (7,500 miles).
Steering operation and linkages
I
I
I
I
Front and rear suspension, ball joints and wheel
I
I
I
I
bearing axial play
Driveshaft dust boots
I
I
I
I
Bolts and nuts on chassis and body
T
T
T
T
Exhaust system and heat shields
I
Emergency flat tire repair kit (if equipped)*4
Inspect annually.
Cabin air filter
R
R
R
R
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
C: Clean
T: Tighten
D: Drain
6-5
Maintenance and Care
Scheduled Maintenance
Remarks:
*1
The engine oil and filter must be changed at least once a year or within 12,000 km (7,500 miles) since last
engine oil and filter change. Reset the engine oil data whenever replacing the engine oil regardless of the
message/wrench indicator light display.
*2
Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*3
According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or mileage/kilometer period to ensure long-term reliability.
*4
Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date.
Schedule 2
U.S.A. and Puerto Rico residents - Severe driving conditions maintenance interval
Number of months or kilometers (miles), whichever comes first.
Months
6
12
18
24
30
36
42
48
54
60
66
72
Maintenance Interval
×1000 km
8
16
24
32
40
48
56
64
72
80
88
96
×1000 miles
5
10
15
20
25
30
35
40
45
50
55
60
SKYACTIV-G
Replace every 64,000 km (40,000 miles).
2.5T
Spark plugs
Except SKY-
ACTIV-G
Replace every 120,000 km (75,000 miles).
2.5T
Air filter*1
R
R
Drive belts
I
I
I
Replace when wrench indicator light is ON. (Max interval: 12
Flexible*2
Engine oil & filter
months or 12,000 km (7,500 miles))
Fixed
R
R
R
R
R
R
R
R
R
R
R
R
Replace at first 192,000 km (120,000 miles) or 10 years; after
Engine coolant*3
that, every 96,000 km (60,000 miles) or 5 years.
Engine coolant level
I
I
I
I
I
I
I
I
I
I
I
I
Fuel lines and hoses*4
I
I
I
I
Hoses and tubes for emission*4
I
I
Function of all lights
I
I
I
I
I
I
I
I
I
I
I
I
Brake lines, hoses and connections
I
I
I
I
Brake and clutch fluid level
I
I
I
I
I
I
I
I
I
I
I
I
Disc brakes
I
I
I
I
I
I
I
I
I
I
I
I
Tire (Rotation)
Rotate every 8,000 km (5,000 miles).
Tire inflation pressure and tire wear
I
I
I
I
I
I
I
I
I
I
I
I
Steering operation and linkages
I
I
I
I
6-6
Maintenance and Care
Scheduled Maintenance
Number of months or kilometers (miles), whichever comes first.
Months
6
12
18
24
30
36
42
48
54
60
66
72
Maintenance Interval
×1000 km
8
16
24
32
40
48
56
64
72
80
88
96
×1000 miles
5
10
15
20
25
30
35
40
45
50
55
60
Front and rear suspension, ball joints and wheel
I
I
I
I
bearing axial play
Driveshaft dust boots
I
I
I
I
Bolts and nuts on chassis and body
T
T
T
T
Exhaust system and heat shields
I
All locks and hinges
L
L
L
L
L
L
L
L
L
L
L
L
Washer fluid level
I
I
I
I
I
I
I
I
I
I
I
I
Emergency flat tire repair kit (if equipped)*5
Inspect annually.
Cabin air filter
Replace every 48,000 km (30,000 miles) or 2 years.
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
C: Clean
T: Tighten
D: Drain
Remarks:
*1
If the vehicle is operated in very dusty or sandy areas, clean and if necessary, replace the air filter more often
than the recommended intervals.
*2
Engine oil flexible maintenance is available for U.S.A. and Puerto Rico residents whose vehicle is operated
mainly where none of the following conditions apply.
Extended periods of idling or low-speed operation such as police car, taxi or driving school car
Driving in dusty conditions
If any do apply, follow fixed maintenance.
The engine oil and filter must be changed at least once a year or within 12,000 km (7,500 miles) since last
engine oil and filter change. Reset the engine oil data whenever replacing the engine oil regardless of the
message/wrench indicator light display.
*3
Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*4
According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or mileage/kilometer period to ensure long-term reliability.
*5
Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date.
6-7
Maintenance and Care
Scheduled Maintenance
Canada residents
Number of months or kilometers (miles), whichever comes first.
Months
6
12
18
24
30
36
42
48
54
60
66
72
Maintenance Interval
×1000 km
8
16
24
32
40
48
56
64
72
80
88
96
×1000 miles
5
10
15
20
25
30
35
40
45
50
55
60
SKYACTIV-G
Replace every 64,000 km (40,000 miles).
2.5T
Spark plugs
Except SKY-
ACTIV-G
Replace every 120,000 km (75,000 miles).
2.5T
I
I
I
I
I
I
I
I
I
I
I
I
Air filter
Replace every 56,000 km (35,000 miles) or 3 years.
Drive belts
I
I
Engine oil & filter*1
R
R
R
R
R
R
R
R
R
R
R
R
Replace at first 192,000 km (120,000 miles) or 10 years; after
Engine coolant*2
that, every 96,000 km (60,000 miles) or 5 years.
Engine coolant level
I
I
I
I
I
I
I
I
I
I
I
I
Fuel lines and hoses*3
I
I
I
Hoses and tubes for emission*3
I
Function of all lights
I
I
I
I
I
I
I
I
I
I
I
I
Brake lines, hoses and connections
I
I
I
Brake and clutch fluid level
I
I
I
I
I
I
I
I
I
I
I
I
Disc brakes
Inspect every 24,000 km (15,000 miles) or 1 year.
Tire (Rotation)
Rotate every 8,000 km (5,000 miles).
Tire inflation pressure and tire wear
I
I
I
I
I
I
I
I
I
I
I
I
Steering operation and linkages
I
I
I
Front and rear suspension, ball joints and wheel
I
I
I
bearing axial play
Driveshaft dust boots
I
I
I
Bolts and nuts on chassis and body
T
T
T
Exhaust system and heat shields
Inspect every 72,000 km (45,000 miles) or 5 years.
All locks and hinges
L
L
L
L
L
L
L
L
L
L
L
L
Washer fluid level
I
I
I
I
I
I
I
I
I
I
I
I
Emergency flat tire repair kit (if equipped)*4
Inspect annually.
Cabin air filter
R
R
R
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
6-8
Maintenance and Care
Scheduled Maintenance
C: Clean
T: Tighten
D: Drain
Remarks:
*1
Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench indicator light
display.
*2
Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*3
According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or mileage/kilometer period to ensure long-term reliability.
*4
Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date.
6-9
Maintenance and Care
Scheduled Maintenance
Scheduled Maintenance (Mexico)
Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions
(severe driving conditions) apply.
Repeated short-distance driving
Driving in dusty conditions
Driving with extended use of brakes
Driving in areas where salt or other corrosive materials are used
Driving on rough or muddy roads
Extended periods of idling or low-speed operation
Driving for long periods in cold temperatures or extremely humid climates
Driving in extremely hot conditions
Driving in mountainous conditions continually
If any do apply, follow Schedule 2.
NOTE
For maintenance guidelines beyond the kilometers/months listed, follow the maintenance
intervals provided in the Scheduled Maintenance Tables.
Schedule 1
Number of months or kilometers, whichever comes first
Maintenance Interval
Months
6
12
18
24
30
36
42
48
54
60
66
72
×1000 km
10
20
30
40
50
60
70
80
90
100
110
120
Drive belts
I
I
I
Engine oil & filter*1
R
R
R
R
R
R
R
R
R
R
R
R
Cooling system
I
I
I
Replace at first 200,000 km or 10 years; after that, every
Engine coolant*2
100,000 km or 5 years
Air filter
R
R
R
R
R
R
Fuel lines and hoses
I*3
I*3
I
Hoses and tubes for emission
I*3
I*3
I
Fuel filter
Replace every 60,000 km
SKYACTIV-G
I
I
I
I
I
I
I
I
I
I
I
I
2.5T
Replace every 64,000 km
Spark plugs
Except SKY-
I
I
I
I
I
I
I
I
I
I
I
I
ACTIV-G
Replace every 120,000 km
2.5T
Brake lines, hoses and connections
I
I
I
I
I
I
Brake and clutch fluid level
I
I
I
I
I
I
I
I
I
Brake fluid
R
R
R
6-10
Maintenance and Care
Scheduled Maintenance
Number of months or kilometers, whichever comes first
Maintenance Interval
Months
6
12
18
24
30
36
42
48
54
60
66
72
×1000 km
10
20
30
40
50
60
70
80
90
100
110
120
Disc brakes
I
I
I
I
I
I
I
I
I
I
I
I
Tire (Rotation)
Rotate every 10,000 km
Tire inflation pressure and tire wear
I
I
I
I
I
I
I
I
I
I
I
I
Steering operation and linkages
I
I
I
I
I
I
I
I
I
I
I
I
Front and rear suspension, ball joints and wheel
I
I
I
I
I
I
bearing axial play
Driveshaft dust boots
I
I
I
I
I
I
Bolts and nuts on chassis and body
T
T
T
T
T
T
Exhaust system and heat shields
I
I
I
I
I
I
All locks and hinges
L
L
L
L
L
L
L
L
L
L
L
L
Washer fluid level
I
I
I
I
I
I
I
I
I
I
I
I
Emergency flat tire repair kit (if equipped)*4
Inspect annually.
Cabin air filter
R
R
R
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
C: Clean
T: Tighten
D: Drain
Remarks:
*1
Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench indicator light
display.
*2
Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*3
According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or kilometer period to ensure long-term reliability.
*4
Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date.
Schedule 2
Number of months or kilometers, whichever comes first
Maintenance Interval
Months
3
6
9
12
15
18
21
24
27
30
33
36
×1000 km
5
10
15
20
25
30
35
40
45
50
55
60
Drive belts
I
Engine oil & filter*1
R
R
R
R
R
R
R
R
R
R
R
R
Cooling system
I
6-11
Maintenance and Care
Scheduled Maintenance
Number of months or kilometers, whichever comes first
Maintenance Interval
Months
3
6
9
12
15
18
21
24
27
30
33
36
×1000 km
5
10
15
20
25
30
35
40
45
50
55
60
Replace at first 200,000 km or 10 years; after that, every
Engine coolant*2
100,000 km or 5 years
Engine coolant level
I
I
I
I
I
I
I
I
I
I
I
I
Air filter
C
R
C
R
C
R
Fuel lines and hoses
I*3
Hoses and tubes for emission
I*3
Fuel filter
Replace every 60,000 km
SKYACTIV-G
I
I
I
I
I
I
2.5T
Replace every 64,000 km
Spark plugs
Except SKY-
I
I
I
I
I
I
ACTIV-G
Replace every 120,000 km
2.5T
Function of all lights
I
I
I
I
I
I
I
I
I
I
I
I
Brake lines, hoses and connections
I
I
I
Brake and clutch fluid level
I
I
I
I
I
Brake fluid
R
Disc brakes
I
I
I
I
I
I
Tire (Rotation)
Rotate every 10,000 km
Tire inflation pressure and tire wear
I
I
I
I
I
I
Steering operation and linkages
I
I
I
I
I
I
Front and rear suspension, ball joints and wheel
I
I
I
bearing axial play
Driveshaft dust boots
I
I
I
Bolts and nuts on chassis and body
T
T
T
Exhaust system and heat shields
I
I
I
All locks and hinges
L
L
L
L
L
L
Washer fluid level
I
I
I
I
I
I
Emergency flat tire repair kit (if equipped)*4
Inspect annually.
Cabin air filter
R
R
R
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
C: Clean
T: Tighten
D: Drain
6-12
Maintenance and Care
Scheduled Maintenance
Remarks:
*1
Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench indicator light
display.
*2
Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*3
According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or kilometer period to ensure long-term reliability.
*4
Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date.
(Cont.)
Number of months or kilometers, whichever comes first
Maintenance Interval
Months
39
42
45
48
51
54
57
60
63
66
69
72
×1000 km
65
70
75
80
85
90
95
100
105
110
115
120
Drive belts
I
I
Engine oil & filter*1
R
R
R
R
R
R
R
R
R
R
R
R
Cooling system
I
I
Replace at first 200,000 km or 10 years; after that, every
Engine coolant*2
100,000 km or 5 years
Engine coolant level
I
I
I
I
I
I
I
I
I
I
I
I
Air filter
C
R
C
R
C
R
Fuel lines and hoses
I
*3
I
Hoses and tubes for emission
I
*3
I
Fuel filter
Replace every 60,000 km
SKYACTIV-G
I
I
I
I
I
I
2.5T
Replace every 64,000 km
Spark plugs
Except SKY-
I
I
I
I
I
I
ACTIV-G
Replace every 120,000 km
2.5T
Function of all lights
I
I
I
I
I
I
I
I
I
I
I
I
Brake lines, hoses and connections
I
I
I
Brake and clutch fluid level
I
I
I
I
Brake fluid
R
R
Disc brakes
I
I
I
I
I
I
Tire (Rotation)
Rotate every 10,000 km
Tire inflation pressure and tire wear
I
I
I
I
I
I
Steering operation and linkages
I
I
I
I
I
I
Front and rear suspension, ball joints and wheel
I
I
I
bearing axial play
Driveshaft dust boots
I
I
I
6-13
Maintenance and Care
Scheduled Maintenance
Number of months or kilometers, whichever comes first
Maintenance Interval
Months
39
42
45
48
51
54
57
60
63
66
69
72
×1000 km
65
70
75
80
85
90
95
100
105
110
115
120
Bolts and nuts on chassis and body
T
T
T
Exhaust system and heat shields
I
I
I
All locks and hinges
L
L
L
L
L
L
Washer fluid level
I
I
I
I
I
I
Emergency flat tire repair kit (if equipped)*4
Inspect annually.
Cabin air filter
R
R
R
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fill up, or replace if necessary.
R: Replace
L: Lubricate
C: Clean
T: Tighten
D: Drain
Remarks:
*1
Reset the engine oil data whenever replacing the engine oil regardless of the message/wrench indicator light
display.
*2
Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may
cause serious damage to the engine and cooling system.
*3
According to state/provincial and federal regulations, failure to perform maintenance on these items will not
void your emissions warranties. However, Mazda recommends that all maintenance services be performed at
the recommended time or kilometer period to ensure long-term reliability.
*4
Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the
tire repair fluid bottle with new one before the expiration date.
6-14
Maintenance and Care
Owner Maintenance
Owner Maintenance Precautions
The owner or a qualified service technician should make these vehicle inspections at the
indicated intervals to ensure safe and dependable operation.
Bring any problem to the attention of an Authorized Mazda Dealer or qualified service
technician as soon as possible.
When Refueling
Brake fluid level (page 6-24)
Engine coolant level (page 6-22)
Engine oil level (page 6-21)
Washer fluid level (page 6-24)
At Least Monthly
Tire inflation pressures (page 6-35)
At Least Twice a Year (For Example, Every Spring and Fall)
You can do the following scheduled maintenance items if you have some mechanical ability
and a few basic tools and if you closely follow the directions in this manual.
Engine coolant (page 6-22)
Engine oil (page 6-20)
Improper or incomplete service may result in problems. This section gives instructions only
for items that are easy to perform.
As explained in the Introduction (page 6-2), several procedures can be done only by a
qualified service technician with special tools.
Improper owner maintenance during the warranty period may affect warranty coverage.
Refer to Introduction (page 6-2) for owner's responsibility in protecting your investment.
For details, read the separate Mazda Warranty statement provided with the vehicle. If you
are unsure about any servicing or maintenance procedure, have it done by an Authorized
Mazda Dealer.
There are strict environmental laws regarding the disposal of waste oil and fluids. Please
dispose of your waste properly and with due regard to the environment.
We recommend that you entrust the oil and fluid changes of your vehicle to an Authorized
Mazda Dealer.
6-15
Maintenance and Care
Owner Maintenance
WARNING
Do not perform maintenance work if you lack sufficient knowledge and experience or the
proper tools and equipment to do the work. Have maintenance work done by a qualified
technician:
Performing maintenance work on a vehicle is dangerous if not done properly. You can be
seriously injured while performing some maintenance procedures.
If you must run the engine while working under the hood, make certain that you remove all
jewelry (especially rings, bracelets, watches, and necklaces) and all neckties, scarves, and
similar loose clothing before getting near the engine or cooling fan which may turn on
unexpectedly:
Working under the hood with the engine running is dangerous. It becomes even more
dangerous when you wear jewelry, loose clothing or have long hair or a long beard.
Either can become entangled in moving parts and result in injury.
Pull over to a safe location, then switch the ignition off and make sure the fan is not
running before attempting to work near the cooling fan:
Working near the cooling fan when it is running is dangerous. The fan could continue running
indefinitely even if the engine has stopped and the engine compartment temperature is high.
You could be hit by the fan and seriously injured.
Do not leave items in the engine compartment:
After you have finished checking or doing servicing in the engine compartment, do not forget
and leave items such as tools or rags in the engine compartment.
Tools or other items left in the engine compartment could cause engine damage or a fire
leading to an unexpected accident.
6-16
Maintenance and Care
Owner Maintenance
2. Insert your hand into the hood
Hood
opening, slide the latch lever to the
right, and lift up the hood.
WARNING
Lever
Always check that the hood is closed and
securely locked:
A hood that is not closed and securely
locked is dangerous as it could fly open
while the vehicle is moving and block the
driver's vision which could result in a
serious accident.
Opening the Hood
1. With the vehicle parked, pull the
3. Grasp the support rod in the padded
release handle to unlock the hood.
area and secure it in the support rod
hole indicated by the arrow to hold the
hood open.
Pad
Release handle
Support rod
6-17
Maintenance and Care
Owner Maintenance
Closing the Hood
1. Check under the hood area to make
certain all filler caps are in place and
all loose items (e.g. tools, oil
containers, etc.) have been removed.
2. Lift the hood, grasp the padded area on
the support rod, and secure the support
rod in the clip. Verify that the support
rod is secured in the clip before closing
the hood.
Clip
Clip
Clip
3. Lower the hood slowly to a height of
about 20 cm (7.9 in) above its closed
position and then let it drop.
CAUTION
When closing the hood, do not push it
excessively such as by applying your
weight. Otherwise, the hood could be
deformed.
6-18















Content      ..     15      16      17      18     ..
