When Driving
ABS/TCS/DSC/Off-Road Traction Assist
The indicator light turns on even
though the Off-Road Traction
Assist was not operated.
Off-Road Traction Assist Switch
When the switch is pressed after
stopping the vehicle, the Off-Road
Traction Assist becomes operational.
The Off-Road Traction Assist indicator
light in the instrument cluster turn on.
If the switch is pressed again, the
Off-Road Traction Assist is stopped
and the Off-Road Traction Assist
indicator light turn off.
NOTE
If the engine is stopped with the
Off-Road Traction Assist operational,
the Off-Road Traction Assist is stopped
when the engine is started the next
time.
4-89
When Driving
Drive Selection
Drive Selection Switch
Drive Selection*
Press the drive selection switch forward
Drive Selection
(SPORT) to select the sport mode.
Pull the drive selection switch back
Drive selection is a system to switch
(OFF) to cancel the sport mode.
the vehicle's drive mode. When the
sport mode is selected, vehicle's
response against accelerator operation
is enhanced. This provides additional
quick acceleration which may be
needed to safely make maneuvers such
as lane changes, merging onto
freeways, or passing other vehicles.
CAUTION
Do not use the sport mode when
driving on slippery roads such as wet
or snow-covered roads. It may cause
tire slipping.
NOTE
In the following cases, the drive
NOTE
selection is canceled.
When the sport mode is selected,
The ignition is switched OFF.
driving at higher engine speeds
Mazda Radar Cruise Control with
increases and it may increase fuel
Stop & Go function (MRCC with
consumption. Mazda recommends
Stop & Go function) System/cruise
that you cancel the sport mode on
control is set.
normal driving.
Traffic Jam Assist (TJA) is set.
Drive mode cannot be switched in
Depending on the driving conditions
the following conditions:
when sport mode is selected, the
ABS/TCS/DSC is operating
vehicle may perform shift-down or
slightly accelerate.
Cruise control* is operating.
The Mazda Radar Cruise Control
with Stop & Go function (MRCC
with Stop & Go function) System*
is operating.
Traffic Jam Assist (TJA)* is
operating.
Steering wheel is being operated
abruptly
4-90
*Some models.
When Driving
Drive Selection
Select Mode Indicator Light
When the sport mode is selected, the
select mode indicator light turns on in
the instrument cluster.
1. Select mode indicator light
NOTE
If the drive selection cannot be
switched to sport mode, the select
mode indicator light flashes to notify
the driver.
4-91
When Driving
i-ACTIV AWD
Utility and AWD vehicles are not
i-ACTIV AWD Operation*
designed for cornering at high speeds
any more than low profile sports cars
i-ACTIV AWD Operation
are designed to perform satisfactorily
AWD provides excellent drivability on
under off-road conditions. In addition,
snow-covered and ice-packed roads,
utility vehicles have a significantly
sand and mud, as well as on steep
higher rollover rate than other types of
slopes and other slippery surfaces.
vehicles.
A system malfunction or operation
conditions are indicated by a warning.
Drive carefully when the vehicle is
Refer to AWD Warning Indication/
loaded by lowering vehicle speed and
Warning Light on page 7-27.
applying the brakes earlier:
Abrupt maneuvering and sudden
WARNING
braking when driving a loaded vehicle
is dangerous as the driving behavior of
Never spin a wheel that is off the
a vehicle with a high center of gravity is
ground:
different when it is loaded compared
Spinning a wheel that is off the ground
to when it is not, and could result in
as a result of the vehicle being stuck or
the loss of vehicle control and an
in a ditch is dangerous. The drive
accident.
assembly could be seriously damaged
Tires and Tire Chains
which could lead to an accident or
could even lead to overheating, oil
The condition of the tires plays a large
leakage, and a fire.
role in the performance of the vehicle.
Moreover, to prevent adverse effects to
AWD Driving
the drive assembly, please note the
following:
WARNING
Tires
Avoid sharp turns, excessive speed
When replacing tires, always replace
and abrupt maneuvers when driving
all front and rear tires at the same
this vehicle:
time.
Sharp turns, excessive speed and
All tires must be of the same size,
abrupt maneuvering of this vehicle is
manufacture, brand and tread
dangerous as it could result in the
pattern. Pay particular attention
increased risk of loss of vehicle control,
when equipping snow or other types
vehicle roll-over, personal injury or
of winter tires.
death.
Do not mix tread-worn tires with
This vehicle has a higher center of
normal tires.
gravity. Vehicles with a higher center of
Inspect tire inflation pressures at the
gravity such as utility and AWD vehicles
specified periods adjust to the
handle differently than vehicles with a
specified pressures.
lower center of gravity.
4-92
*Some models.
When Driving
i-ACTIV AWD
NOTE
Check the tire inflation pressure label
attached to driver's door frame for the
correct tire inflation pressure.
Make sure to equip the vehicle with
genuine tires of the specified size, on
all wheels. With AWD, the system is
calibrated for all 4 wheels being of
the same dimensions.
Tire chains
Install tire chains to the front tires.
Do not use tire chains on the rear
wheels.
Do not drive the vehicle faster than
30 km/h (19 mph) with the tire
chains installed.
Do not drive the vehicle with tire
chains on road conditions other than
snow or ice.
Towing
If the vehicle requires towing, have it
towed with all 4 wheels completely off
the ground.
Refer to Towing Description on page
7-19.
4-93
When Driving
Power Steering
Power Steering
Power Steering
Power steering is only operable when
the engine is running. If the engine is
off or if the power steering system is
inoperable, you can still steer, but it
requires more physical effort.
If the steering feels stiffer than usual
during normal driving or the steering
vibrates, consult an Authorized
Mazda Dealer.
The malfunction indication/indicator
light notifies the driver of system
abnormalities and operation
conditions.
Refer to Power Steering Malfunction
Indication/Indicator Light on page
7-25.
4-94
When Driving
i-ACTIVSENSE
Front obstruction detection when
i-ACTIVSENSE*
approaching a crosswalk
i-ACTIVSENSE
Front Cross Traffic Alert (FCTA)
........................................ page 4-121
i-ACTIVSENSE is a collective term
covering a series of advanced safety
Rear obstruction detection when
and driver support systems which
leaving a parking space
make use of cameras and sensors. The
Rear Cross Traffic Alert (RCTA)
systems consist of active safety and
........................................ page 4-124
pre-crash safety systems.
These systems are designed to assist
Full-surround recognition
the driver in safer driving by reducing
360°View Monitor
page 4-164
the load on the driver and helping to
avert collisions or reduce their severity.
Driver fatigue detection
However, because each system has its
limitations, always drive carefully and
Driver Attention Alert (DAA)
........................................ page 4-117
do not rely solely on the systems.
Driver Monitoring (DM)
page 4-119
Active Safety Technology
Driver support systems
Active Safety Technology supports safer
Inter-vehicle distance
driving by helping the driver to
recognize potential hazards and avert
Mazda Radar Cruise Control with Stop
accidents.
& Go function (MRCC with Stop & Go
function)
page 4-128
Driver awareness support systems
Lane departure
Nighttime visibility
Lane-keep Assist System (LAS)
Adaptive Front Lighting System
........................................ page 4-152
(AFS)
page 4-99
High Beam Control System
Inter-vehicle distance and lane
(HBC)
page 4-100
keeping
Left/right side and rear side detection
Traffic Jam Assist (TJA)
page 4-138
Lane Departure Warning System
Pre-Crash Safety Technology
(LDWS)
page 4-102
Blind Spot Monitoring (BSM)
Pre-crash safety technology is designed
to assist the driver in averting collisions
........................................ page 4-105
or reducing their severity in situations
Road sign recognition
where they cannot be avoided.
Traffic Sign Recognition System
Collision damage reduction
(TSR)
page 4-110
Smart Brake Support (SBS)
Inter-vehicle distance recognition
........................................ page 4-156
Distance & Speed Alert (DSA)
........................................ page 4-116
*Some models.
4-95
When Driving
i-ACTIVSENSE
Camera and Sensors
Front radar sensor
Forward Sensing Camera (FSC)
The front radar sensor detects radio
waves reflected off a vehicle ahead
The Forward Sensing Camera (FSC)
sent from the radar sensor. The
detects lane indications and recognizes
following systems use the front radar
headlights, taillights and city lights
sensor.
during nighttime driving. In addition, it
also detects the vehicle ahead,
Distance & Speed Alert (DSA)
pedestrians, or obstructions. The
Mazda Radar Cruise Control with
following systems use the Forward
Stop & Go function (MRCC with
Sensing Camera (FSC).
Stop & Go function)
Traffic Jam Assist (TJA)
High Beam Control system (HBC)
Smart Brake Support (SBS) forward
Lane Departure Warning System
drive detection
(LDWS)
Traffic Sign Recognition System (TSR)
The front radar sensor is mounted
Distance & Speed Alert (DSA)
behind the radiator grille.
Driver Attention Alert (DAA)
Refer to Front Radar Sensor on page
Mazda Radar Cruise Control with
4-201.
Stop & Go function (MRCC with
Front side radar sensor
Stop & Go function)
Lane-keep Assist System (LAS)
The front side radar sensors detects
Traffic Jam Assist (TJA)
radio waves reflected off a vehicle
Smart Brake Support (SBS) forward
ahead sent from the radar sensor. The
drive detection
following systems use the front side
radar sensor.
The Forward Sensing Camera (FSC) is
installed at the top of the windshield
Front Cross Traffic Alert (FCTA)
near the rearview mirror.
The front side radar sensors are
Refer to Forward Sensing Camera
installed inside the front bumper, one
(FSC) on page 4-197.
on the left side and one on the right
side.
Refer to Front Side Radar Sensor on
page 4-203.
4-96
When Driving
i-ACTIVSENSE
Rear side radar sensor
and estimates the amount of
accumulated fatigue and sleepiness of
The rear side radar sensors emit radio
the driver. The following systems use
waves and detect the radio waves
the driver monitoring camera.
reflected off a vehicle approaching
from the rear or an obstruction. The
Driver Monitoring (DM)
following systems use the rear side
The driver monitoring camera is
radar sensor.
mounted in the center display.
Blind Spot Monitoring (BSM)
Refer to Driver Monitoring Camera on
Rear Cross Traffic Alert (RCTA)
page 4-207.
Smart Brake Support (SBS) reverse
i-ACTIVSENSE Status Symbol
drive detection
(Warning/Risk Avoidance Support
The rear side radar sensors are installed
System)*
inside the rear bumper, one on the left
The system notifies the driver of any of
side and one on the right side.
Refer to Rear Side Radar Sensor on
the following system status using the
color or OFF indication of the
page 4-204.
i-ACTIVSENSE status symbol
Rear/rear corner ultrasonic sensor
(Warning/risk avoidance support
system).
The ultrasonic sensor detects ultrasonic
waves reflected off obstructions at the
Lane Departure Warning System
rear sent from the ultrasonic sensors.
(LDWS)
The following systems use the
Blind Spot Monitoring (BSM)
ultrasonic sensor.
Distance & Speed Alert (DSA)
Front Cross Traffic Alert (FCTA)
Smart Brake Support (SBS) reverse
Rear Cross Traffic Alert (RCTA)
drive detection
Lane-keep Assist System (LAS)
The ultrasonic sensors are mounted in
the rear bumper.
NOTE
Refer to Rear/Rear corner Ultrasonic
The status of the system turned on
Sensor on page 4-206.
using the personalization feature is
displayed.
Front camera/side cameras/rear
camera
i-ACTIVSENSE status symbol
(warning/risk avoidance support
The front camera, side cameras, and
system) (white)
rear camera shoot images of the area
surrounding the vehicle. The 360°View
Monitor uses each camera.
Cameras are installed to the front
bumper, door mirrors, and liftgate.
Refer to Front Camera/Side Cameras/
Rear Camera on page 4-206.
System stand-by status
Driver monitoring camera
If none of the systems are activated or
The driver monitoring camera detects
if there is a problem with the system,
changes in the driver's facial features
the i-ACTIVSENSE status symbol
*Some models.
4-97
When Driving
i-ACTIVSENSE
(warning/risk avoidance support
i-ACTIVSENSE OFF symbol (warning/
system) (white) is displayed.
risk avoidance support system)
NOTE
For example, even when the Blind Spot
Monitoring (BSM) is operating
normally, if the Lane Departure
Warning System (LDWS) has a
problem, the i-ACTIVSENSE status
System OFF status
symbol (warning/risk avoidance
If all the systems are canceled using the
support system) (white) is displayed.
personalization features or the
i-ACTIVSENSE status symbol
i-ACTIVSENSE OFF switch, the
(warning/risk avoidance support
i-ACTIVSENSE OFF symbol (Warning/
system) (green)
risk avoidance support system) is
displayed.
i-ACTIVSENSE OFF Switch*
When the i-ACTIVSENSE OFF switch is
pressed, the following systems are
canceled and the i-ACTIVSENSE OFF
System activated status
symbol (Warning/risk avoidance
If any one of the systems is activated,
support system) in the instrument
the i-ACTIVSENSE status symbol
cluster is displayed.
(warning/risk avoidance support
Lane Departure Warning System
system) (green) is displayed.
(LDWS)
NOTE
Blind Spot Monitoring (BSM)
Even if the i-ACTIVSENSE status symbol
Distance & Speed Alert (DSA)
(warning/risk avoidance support
Front Cross Traffic Alert (FCTA)
system) (green) is displayed, systems
Rear Cross Traffic Alert (RCTA)
which do not meet the operation
Lane-keep Assist System (LAS)
conditions will not operate.
i-ACTIVSENSE status symbol
(warning/risk avoidance support
system) (amber)
System warning status
If any system warning is activated, the
i-ACTIVSENSE status symbol (warning/
risk avoidance support system)
(amber) is displayed.
4-98
*Some models.
When Driving
i-ACTIVSENSE
i-ACTIVSENSE OFF switch
Adaptive Front Lighting
System (AFS)*
Adaptive Front Lighting System
(AFS)
The adaptive front lighting system
(AFS) automatically adjusts the
headlight beams to the left or right in
conjunction with the operation of the
steering wheel after the headlights
have been turned on and the vehicle
speed is about 2 km/h (2 mph) or
i-ACTIVSENSE OFF symbol (Warning/
higher.
risk avoidance support system)
A system malfunction or operation
conditions are indicated by a warning.
Refer to Exterior Light Warning
Indication/Warning Light on page
7-30.
If the i-ACTIVSENSE OFF switch is
NOTE
pressed again, the systems return to
The Adaptive Front Lighting System
their original operation status and the
(AFS) can be switched to on/off using
i-ACTIVSENSE OFF symbol (Warning/
the personalization function.
risk avoidance support system) turns
Refer to the Settings section in the
off.
Mazda Connect Owner's Manual.
If the ignition is switched OFF while
you have canceled the systems using
the i-ACTIVSENSE OFF switch, the
systems are automatically enabled the
next time the ignition is switched ON.
However, if the systems are canceled
using the personalization features, the
systems are not automatically enabled.
NOTE
You can select systems you want to
cancel using the personalization
features.
Refer to the Settings section in the
Mazda Connect Owner's Manual.
*Some models.
4-99
When Driving
i-ACTIVSENSE
*1
The recognition distance of the Forward
High Beam Control
Sensing Camera (FSC) varies according to
System (HBC)*
the surrounding conditions.
The warning light turns on when the
High Beam Control System (HBC)
system has a malfunction.
Refer to High Beam Control System
The HBC determines the conditions in
(HBC) Warning Indication/Warning
front of the vehicle using the Forward
Light (Amber) on page 7-30.
Sensing Camera (FSC) while driving in
darkness to automatically switch the
CAUTION
headlights between high and low
beams.
¾ Do not adjust the vehicle height,
Refer to Forward Sensing Camera
modify the headlight units, or
(FSC) on page 4-197.
remove the camera, otherwise the
While driving the vehicle at a speed of
system will not operate normally.
about 30 km/h (19 mph) or more, the
¾ Do not rely excessively on the HBC
headlights are switched to high beams
and drive the vehicle while paying
when there are no vehicles ahead or
sufficient attention to safety. Switch
approaching in the opposite direction.
the headlights between the high
The system switches the headlights to
beams and low beams manually if
low beams when one of the following
necessary.
occurs:
The system detects a vehicle or the
NOTE
headlights/lights of a vehicle
The timing in which the system
approaching in the opposite
switches the headlights changes under
direction.
the following conditions. If the system
The vehicle is driven on roads lined
does not switch the headlights
with streetlamps or on roads in
appropriately, manually switch
well-lit cities and towns.
between high and low beams
The vehicle is driven at less than
according to the visibility as well as
about 20 km/h (12 mph).
road and traffic conditions.
The headlight high-beam indicator
When there are sources of light in
light turns on while the high beams
the area such as streetlamps,
are on.
illuminated signboards, and traffic
signals.
When there are reflective objects in
the surrounding area such as
reflective plates and signs.
When visibility is reduced under rain,
snow and foggy conditions.
When driving on roads with sharp
turn or hilly terrain.
When the headlights/rear lamps of
vehicles in front of you or in the
1. Forward Sensing Camera (FSC)*1
opposite lane are dim or not
illuminated.
4-100 *Some models.
When Driving
i-ACTIVSENSE
When there is insufficient darkness
Manual Switching
such as at dawn or dusk.
Switching to low beams
When the luggage compartment is
loaded with heavy objects or the rear
Switch the headlight switch to the
passenger seats are occupied.
position, or press the high beam
When visibility is reduced due to a
control switch.
vehicle in front of you spraying water
The HBC indicator light (green) turns
from its tires onto your windshield.
off.
To Operate the System
The HBC operates to switch the
headlights automatically between high
and low beams after the ignition is
switched ON and the headlight switch
is in the AUTO and low beam position.
The HBC determines that it is dark
based on the brightness of the
surrounding area. At the same time,
the HBC indicator light (green) in the
instrument cluster illuminates.
1. High beam control switch
If the HBC is turned off using the high
beam control switch, press the high
beam control switch again to turn the
HBC back on.
Switching to high beams
NOTE
Operation of the HBC function can be
Shift the lever to the high beam
disabled.
position.
Refer to the Settings section in the
The HBC indicator light (green) turns
Mazda Connect Owner's Manual.
off and the headlight high-beam
indicator light is illuminated.
4-101
When Driving
i-ACTIVSENSE
Lane Departure Warning
WARNING
System (LDWS)*
Do not rely completely on the LDWS:
Lane Departure Warning System
¾ The LDWS system is not designed to
(LDWS)
compensate for a driver’s lack of
caution and relying too much on the
The LDWS alerts the driver that the
system could lead to an accident.
vehicle may be deviating from its lane.
¾ The functions of the LDWS have
The system detects the white (yellow)
limitations. Always stay on course
lines on the traffic lane using the
using the steering wheel and drive
forward sensing camera (FSC) and if it
with care.
determines that the vehicle might be
deviating from its lane, it notifies the
driver by the LDWS.
CAUTION
Refer to Forward Sensing Camera
(FSC) on page 4-197.
Heed the following cautions so that
Use the LDWS when you drive the
the LDWS can operate normally.
vehicle on roads with white (yellow)
¾ Do not modify the vehicle's
lines.
suspensions.
¾ Always use tires of the specified type
and size for the front and rear
wheels. Consult an Authorized
Mazda Dealer for tire replacement.
NOTE
The system may not operate normally
under the following conditions.
The white (yellow) lane lines are less
visible because of dirt or paint
flaking.
White (yellow) lane lines are less
visible because of bad weather (rain,
fog, or snow).
The vehicle is driven on a temporary
lane or section with a closed lane
resulting from construction where
1.
Forward sensing camera (FSC)
there might be multiple white
(yellow) lane lines, or they are
interrupted.
The camera picks up an obscure line,
such as a temporary line being used
for construction, or because of
shade, unmelted snow, or grooves
filled with water.
4-102 *Some models.
When Driving
i-ACTIVSENSE
The surrounding brightness suddenly
When the System Operates
changes such as when entering or
When the ignition is switched ON, the
exiting a tunnel.
i-ACTIVSENSE status symbol (warning/
Back-light is reflected off the road
risk avoidance support system) (white)
surface.
turns on and the system goes on
The road surface is wet and shiny
standby.
after rain, or there are puddles on
the road.
The width of a lane is excessively
narrow.
The vehicle is driven on roads with
tight curves.
NOTE
Heavy luggage is loaded in the
luggage compartment or on the rear
If the i-ACTIVSENSE status symbol
(warning/risk avoidance support
seat causing the vehicle to tilt.
The vehicle is driven through a fork in
system) (white) does not turn on, the
system is canceled using the
the road or a junction.
The shade of a guardrail parallel to a
i-ACTIVSENSE OFF switch or the
personalization feature.
white (yellow) lane line is cast on the
road.
Operation conditions
The illumination of the headlights is
weakened because of dirt or the
When all of the following conditions
optical axis is deviated at night.
are met, the i-ACTIVSENSE status
The road is excessively uneven.
symbol (warning/risk avoidance
The vehicle is shaken after hitting a
support system) on the
road bump.
multi-information display changes
A vehicle in front of your vehicle is
from white to green and the system
running near a white (yellow) lane
becomes operational.
line making it less visible.
The ignition is switched ON.
The windshield is dirty or foggy.
The vehicle speed is about 64 km/h
Strong light is directed from the front
(40 mph) or faster.
of the vehicle (such as sunlight, or
The system detects white (yellow)
headlights (high-beam) of
lane lines.
on-coming vehicles).
The vehicle is driven through an
intersection or a roundabout.
NOTE
When the system does not detect a
white (yellow) lane line on one side
only, the system does not operate on
the side that is not being detected.
4-103
When Driving
i-ACTIVSENSE
When temporarily canceling the
LDWS Warning
system
If the system determines that the
The LDWS goes on standby in the
vehicle may deviate from its lane, a
following cases: The LDWS operation
warning (beep sound, steering wheel
is automatically restored when the
vibration) is activated and the direction
system's operation conditions are met.
in which the system determines that
the vehicle may deviate is indicated on
The system cannot detect white
the multi-information display and the
(yellow) lane lines.
active driving display.
The vehicle speed is less than about
Multi-information display
56 km/h (35 mph).
The turn signal lever is operated.
The accelerator pedal is depressed.
The steering wheel is operated.
The brake pedal is operated.
The function is temporarily stopped.
The LDWS stops functioning in the
following cases:
The temperature in the forward
sensing camera (FSC) is too high or
too low.
The windshield around the forward
Active driving display
sensing camera (FSC) is foggy.
The windshield around the forward
sensing camera (FSC) is blocked by
an obstruction, causing poor forward
visibility.
Strong light (such as sunlight, or
NOTE
headlights (high-beam) of
on-coming vehicles) is directed at
The LDWS settings can be changed.
the forward sensing camera (FSC).
Refer to the Settings section in the
Mazda Connect Owner's Manual.
System malfunction
You may not be able to hear the
If there is a problem with the system,
LDWS warning sound depending on
the i-ACTIVSENSE status symbol
the surrounding conditions such as
(warning/risk avoidance support
outside noise.
system) (white) and the i-ACTIVSENSE
If you set the LDWS to vibrate the
warning indication/warning light on
steering wheel, you may not feel the
the multi-information display turns on
vibrations depending on the road
and a message is indicated.
surface conditions.
Refer to i-ACTIVSENSE Status Symbol
(Warning/Risk Avoidance Support
System) on page 4-97.
4-104
When Driving
i-ACTIVSENSE
Canceling the System
Blind Spot Monitoring
The LDWS can be set to inoperable.
(BSM)*
(If only the LDWS is turned off)
Refer to the Settings section in the
Blind Spot Monitoring (BSM)
Mazda Connect Owner's Manual.
The BSM is designed to assist the driver
(If the LDWS is turned off by
in checking the area to the rear of the
operating the i-ACTIVSENSE OFF
vehicle on both sides during lane
switch)
changes by notifying the driver of the
Refer to i-ACTIVSENSE OFF Switch
presence of vehicles approaching from
on page 4-98.
the rear in an adjacent lane.
NOTE
BSM operation
If the ignition is switched OFF while
The BSM detects vehicles approaching
you have canceled the system using the
from the rear while traveling in the
i-ACTIVSENSE OFF switch, the system
forward direction at a speed of 10
is automatically enabled the next time
km/h (6.3 mph) or faster and notifies
the ignition is switched ON. However,
the driver by turning on the BSM
if the system is canceled using the
warning indicator light and displaying
personalization features, the system is
the vehicle detection screen.
not automatically enabled.
If the turn signal lever is operated to
signal a turn in the direction in which
the BSM warning indicator light is
illuminated while the approaching
vehicle is detected, the BSM notifies
the driver of possible danger flashing
on the BSM warning indicator light,
and by activating the warning sound
and the warning screen indicator
display.
The detection area on this system
covers the driving lanes on both sides
of the vehicle and from the rear part of
the front doors to about 50 m (164 ft)
behind the vehicle.
1. Your vehicle
*Some models.
4-105
When Driving
i-ACTIVSENSE
2. Detection areas
In the following cases, the
i-ACTIVSENSE warning indication/
WARNING
warning light turns on and operation
of the system is stopped. If the
Always check the surrounding area
i-ACTIVSENSE warning indication/
visually before making an actual lane
warning light remains illuminated,
change:
have the vehicle inspected at an
The system is only designed to assist
Authorized Mazda Dealer as soon as
you in checking for vehicles at your rear
possible.
when making a lane change. Due to
Some problem with the system
certain limitations with the operation
including the BSM warning
of this system, the BSM warning
indicator lights is detected.
indicator light, the warning sound and
A large deviation in the installation
the warning screen indicator display
position of a rear side radar sensor
may not activate or they might be
on the vehicle has occurred.
delayed even though a vehicle is in an
There is a large accumulation of
adjacent driving lane. Always make it
snow or ice on the rear bumper
your responsibility as a driver to check
near a rear side radar sensor.
the rear.
Remove any snow, ice or mud on
the rear bumper.
NOTE
Driving on snow-covered roads for
The BSM will operate when all of the
long periods.
following conditions are met:
The temperature near the rear side
radar sensor becomes extremely
The ignition is switched ON.
hot due to driving for long periods
The i-ACTIVSENSE warning
on slopes during the summer.
indication/warning light in the
The battery voltage has decreased.
instrument cluster is turned off.
Under the following conditions, the
The vehicle speed is about 10
rear side radar sensor cannot detect
km/h (6.3 mph) or faster.
target objects or it may be difficult to
The BSM will not operate under the
detect them.
following circumstances.
The rear bumper around the rear
The vehicle speed falls below
side radar sensor is deformed.
about 10 km/h (6.3 mph) even
Radio wave interference from a
though the i-ACTIVSENSE warning
radar sensor equipped on a nearby
indication/warning light is turned
vehicle.
off.
The approaching vehicle is any of
The selector lever is shifted to
the following shapes.
reverse (R) and the vehicle is
a) The size of the vehicle body is
reversing.
extremely small.
The turning radius is small (making
b) The vehicle height is extremely
a sharp turn, turning at
low or high.
intersections).
c) A special type of vehicle with a
complex shape.
4-106
When Driving
i-ACTIVSENSE
A vehicle is in the detection area at
The BSM warning indicator light may
the rear in an adjacent driving lane
turn on and the vehicle detection
but it does not approach. The BSM
screen may be displayed in the
determines the condition based on
display in reaction to stationary
radar detection data.
objects (guardrails, tunnels,
A vehicle is traveling alongside
sidewalls, and parked vehicles) on
your vehicle at nearly the same
the road or the roadside.
speed for an extended period of
time.
Vehicles approaching in the
opposite direction.
A vehicle in an adjacent driving
lane is attempting to pass your
vehicle.
1.
Objects such as guardrails and
A vehicle is in an adjacent lane on
concrete walls running alongside
a road with extremely wide driving
the vehicle.
lanes. The detection area of the
rear side radar sensor is set at the
road width of expressways.
In the following case, the flashing of
the BSM warning indicator light, and
the activation of the warning sound
and the warning screen indicator
display may not occur or they may be
1.
Places where the width between
delayed.
guardrails or walls on each side of
A vehicle makes a lane change
the vehicle narrows.
from a driving lane two lanes over
to an adjacent lane.
Driving on steep slopes.
Crossing the summit of a hill or
mountain pass.
When there is a difference in the
height between your driving lane
and the adjacent lane.
Directly after the BSM system
becomes operable by changing the
setting.
If the road width is extremely
narrow, vehicles two lanes over may
be detected. The detection area of
the rear side radar sensor is set
according to the road width of
expressways.
4-107
When Driving
i-ACTIVSENSE
1. The walls at the entrance and
Blind Spot Monitoring (BSM)
exits of tunnels, turnouts.
Warning Indicator Lights/Display
Indicator/Blind Spot Monitoring
A BSM warning indicator light may
(BSM) Warning Beep
flash or the warning beep may be
The BSM system notifies the driver of
activated several times when making
the presence of vehicles in adjacent
a turn at a city intersection.
lanes or at the rear of the vehicle using
Turn off the BSM while pulling a
the BSM warning indicator light, the
trailer or while an accessory such as a
warning sound and the display
bicycle carrier is installed to the rear
indicator while the systems are
of the vehicle. Otherwise, the radar’s
operational.
radio waves will be blocked causing
the system to not operate normally.
BSM warning indicator lights
In the following cases, it may be
The BSM warning indicator lights are
difficult to view the illumination/
equipped on the left and right door
flashing of the BSM warning
mirrors. The warning indicator lights
indicator lights equipped on the
turn on when a vehicle approaching
door mirrors.
from the rear in an adjacent lane is
Snow or ice is adhering to the door
detected.
mirrors.
The front door glass is fogged or
covered in snow, frost or dirt.
The rear side radar sensor of the BSM
may be regulated under the radio
wave related laws of the country
where the vehicle is driven. If this
system is used abroad, it may be
necessary to turn off the system.
Refer to Rear Side Radar Sensor on
When the ignition is switched ON, the
page 4-204.
warning indicator light turns on
The system switches to the Rear
momentarily and then turns off after a
Cross Traffic Alert (RCTA) function
few seconds.
when the selector lever is shifted to
the reverse (R) position.
Refer to Rear Cross Traffic Alert
(RCTA) on page 4-124.
4-108
When Driving
i-ACTIVSENSE
Function for canceling illumination
Active Driving Display (vehicles with
dimmer
active driving display)
If the BSM warning indicator lights turn
on when the parking lights are turned
on, the brightness of the BSM warning
indicator lights is dimmed.
If the BSM warning indicator lights are
The detected direction is displayed
difficult to see due to glare from
with a detection indicator (white)
surrounding brightness when traveling
when an approaching vehicle is
on snow-covered roads or under foggy
detected. In addition, if the turn signal
conditions, press the dimmer
lever is operated to signal a lane
cancellation button to cancel the
change while the vehicle is detected,
dimmer and increase the brightness of
the display changes the color (amber)
BSM warning indicator lights when
of the warning indicator.
they turn on.
BSM warning beep
Refer to Dashboard Illumination on
page 4-24.
The BSM warning beep is activated
simultaneously with the flashing of a
Display indicator
BSM warning indicator light.
The detected approaching vehicle and
warning are displayed in the
Canceling Operation of Blind Spot
Monitoring (BSM)
multi-information display and active
driving display (vehicles with active
The BSM system can be set to
driving display).
inoperable.
Multi-information Display
(If only the BSM is turned off)
Refer to the Settings section in the
Mazda Connect Owner's Manual.
(If the BSM is turned off by
operating the i-ACTIVSENSE OFF
switch)
Refer to i-ACTIVSENSE OFF Switch
on page 4-98.
NOTE
If the ignition is switched OFF while
you have canceled the system using the
i-ACTIVSENSE OFF switch, the system
is automatically enabled the next time
the ignition is switched ON. However,
if the system is canceled using the
personalization features, the system is
not automatically enabled.
4-109
When Driving
i-ACTIVSENSE
Traffic Sign Recognition System (TSR)*
Traffic Sign Recognition System (TSR)
The TSR helps prevent the driver from overlooking traffic signs, and provides support
for safer driving by displaying traffic signs on the active driving display/instrument
cluster which are recognized by the Forward Sensing Camera (FSC) or recorded in
the navigation system while the vehicle is driven.
The TSR displays the speed limit (including auxiliary signs), do not enter, and traffic
stop signs.
If the vehicle speed exceeds the speed limit sign indicated in the active driving
display/instrument cluster while the vehicle is driven, the system notifies the driver
using the indication in the active driving display/instrument cluster and a warning
sound.
Speed limit and do not enter signs
1. Sign recognized
2. Sign displayed
3. Active driving display indication
4-110 *Some models.
When Driving
i-ACTIVSENSE
4. Instrument cluster
5. Basic display
6. i-ACTIVSENSE display
7. Recognized speed limit indication color changes.
Stop sign
1. Sign recognized and displayed at same time
2. Active driving display indication
3. Instrument cluster
WARNING
Always check the traffic signs visually while driving:
The TSR helps prevent the driver from overlooking traffic signs and provides support
for safer driving. Depending on the weather conditions or problems with traffic
signs, a traffic sign may not be recognized or a traffic sign different from the actual
traffic sign may be displayed. Always make it your responsibility as a driver to check
the actual traffic signs. Otherwise, it could result in an accident.
NOTE
The TSR is not supported in some countries or regions. For information concerning
the supported countries or regions, consult an Authorized Mazda Dealer.
The TSR operates only if the navigation system SD card (Mazda genuine) is
inserted in the SD card slot. Consult an Authorized Mazda Dealer for details.
The TSR does not operate if there is a malfunction in the Forward Sensing Camera
(FSC).
Under the following conditions, the TSR may not operate normally.
4-111
When Driving
i-ACTIVSENSE
An object placed on the dashboard is reflected in the windshield and picked up
by the camera.
Heavy luggage is loaded in the luggage compartment or on the rear seat and the
vehicle is tilted.
The tire pressures are not adjusted to the specified pressure.
Tires other than standard tires are equipped.
The vehicle is driven on the ramp and surrounding area to or from a rest area or
a tollgate on a highway.
When surrounding brightness suddenly changes such as when entering or exiting
a tunnel.
The illumination of the headlights is weakened because of dirt or the optical axis
is deviated.
The windshield is dirty or foggy.
The windshield and camera are fogged (water droplets).
Strong light is directed at the front of the vehicle (such as backlight or high-beam
headlights of on-coming vehicles).
The vehicle is making a sharp turn.
Strong light reflects off the road.
A traffic sign is in a position which makes it difficult to reflect the light from the
vehicle's headlights, such as when the vehicle is driven at night or in a tunnel.
The vehicle is driven under weather conditions such as rain, fog, or snow.
The stored map data for the navigation system is not current.
A traffic sign is obscured by mud or snow.
A traffic sign is concealed by trees or a vehicle.
A traffic sign is partially shaded.
A traffic sign is bent or warped.
A traffic sign is too low or too high.
A traffic sign is too bright or too dark (including electronic traffic signs).
A traffic sign is too big or too small.
There is an object similar to the traffic sign being read (such as another traffic
sign or other signs resembling it).
The TSR can be set to invisible on the active driving display.
Refer to the Settings section in the Mazda Connect Owner's Manual.
Traffic Sign Display Indication
Stop signs
The following traffic signs are displayed
on the active driving display/
instrument cluster.
NOTE
Speed limit signs
Speed limit signs
When the vehicle speed is about 1
km/h (0.6 mph) or faster, the speed
Do not enter signs
limit sign is displayed when any one
of the following conditions are met.
4-112
When Driving
i-ACTIVSENSE
The Forward Sensing Camera (FSC)
Do not enter signs
recognizes a speed limit sign as a
A do not enter sign is displayed
sign targeted for your vehicle and
when all of the following conditions
the vehicle passes it.
are met.
The speed limit sign stored in the
navigation system is read.
The vehicle speed is about 60
In the following cases, display of the
km/h (37 mph) or slower.
speed limit sign stops.
The Forward Sensing Camera (FSC)
recognizes a do not enter sign as a
Each sensor determines that the
sign targeted for your vehicle and
vehicle has changed direction of
the vehicle passes it.
travel.
When the Forward Sensing Camera
The Forward Sensing Camera (FSC)
(FSC) recognizes the do not enter
recognizes a new speed limit sign
sign and a certain period of time has
which differs from the previous
elapsed since the vehicle passed the
one (displays the new speed limit
sign, display of the do not enter sign
sign).
stops.
The speed limit sign stored in the
navigation system is not read
Stop sign
within a certain period of time (if
A stop sign is displayed when all of
the Forward Sensing Camera (FSC)
the following conditions are met:
does not recognize a speed limit
sign, the speed limit sign stored in
The vehicle speed is about 65
the navigation system is displayed).
km/h (40 mph) or slower.
The vehicle speed exceeds the
The Forward Sensing Camera (FSC)
displayed speed limit sign by 30
recognizes a stop sign as a sign
km/h (19 mph) or more after a
targeted for your vehicle.
certain period of time has elapsed
When a certain period of time has
since the speed limit sign was
elapsed since the stop sign was
displayed. (Except when there is
displayed, display of the stop sign
information for the speed limit sign
stops.
in the navigation system)
4-113
When Driving
i-ACTIVSENSE
Excessive Speed Warning
If the vehicle speed exceeds the speed limit sign displayed in the active driving
display/instrument cluster, the area around the speed limit sign flashes in amber and
the warning sound is activated at the same time. If the vehicle speed continues to
exceed the displayed speed limit sign, the indication stops flashing and remains on.
Check the surrounding conditions and adjust the vehicle speed to the legal speed
using the appropriate operation such as depressing the brake pedal.
1. Vehicle is doing 55 mph when 50 mph speed limit sign is recognized.
2. Vehicle continues to do 55 mph after 50 mph speed limit sign is recognized.
3. Active driving display indication
4. Instrument cluster
The excessive speed warning is initially set to inoperable. If you want to activate the
excessive speed warning, change the setting in the personalization features. In
addition, the warning pattern and the warning activation timing differ depending on
the setting contents.
Refer to the Settings section in the Mazda Connect Owner's Manual.
4-114
When Driving
i-ACTIVSENSE
Speed Limit Sign Alert setting
Off: The excessive speed warning is not activated.
Visual: The area around the speed limit sign displayed in the display flashes in
amber, and if the vehicle speed continues to exceed the displayed speed limit
sign, the indication stops flashing and remains on.
Visual + Audible: The area around the speed limit sign displayed in the display
flashes in amber and the warning sound is activated at the same time. If the
vehicle speed continues to exceed the displayed speed limit sign, the indication
stops flashing and remains on. The warning sound is activated continuously until
the vehicle speed decreases below the speed limit sign.
Speed Limit Sign Threshold setting
+ 0 km/h (+ 0 mph): If the vehicle speed exceeds the speed limit sign displayed in
the display, the excessive speed warning is activated.
+ 5 km/h (+ 3 mph): If the vehicle speed exceeds the speed limit sign displayed in
the display by 5 km/h (3 mph), the excessive speed warning is activated.
+ 10 km/h (+ 5 mph): If the vehicle speed exceeds the speed limit sign displayed
in the display by 10 km/h (5 mph), the excessive speed warning is activated.
NOTE
In the following cases, the excessive speed warning stops operating.
The vehicle speed is less than the speed of the displayed speed limit sign. (If the
activation timing for the excessive speed warning is changed in the
personalization features, the excessive speed warning stops operating when the
vehicle speed is less than the changed vehicle speed.
A speed limit sign indication has been updated and the vehicle speed is lower
than the updated indication.
Display of the speed limit sign stops.
The warning indication is displayed at the same time the excessive speed warning
sound is activated if the vehicle speed exceeds the speed indicated on the speed
limit sign.
Refer to Excessive Speed Warning on page 7-43.
If the Forward Sensing Camera (FSC) or data recorded in the navigation system
incorrectly recognizes the actual speed limit sign at a lower speed, the excessive
speed alarm is activated even if the vehicle is driven at the legal speed.
4-115
When Driving
i-ACTIVSENSE
Operation conditions
Distance & Speed Alert
The DSA operates when the following
(DSA)*
conditions are all met.
The ignition is switched ON.
Distance & Speed Alert (DSA)
The DSA is turned on.
The DSA is a system which provides
The selector lever is in a position
advice for maintaining the appropriate
other than R.
distance between vehicles and notifies
The vehicle speed is about 30 km/h
the driver of the recommended, safe
(19 mph) or faster.
distance to maintain with a vehicle
i-ACTIVSENSE status symbol
ahead. The system measures the
(warning/risk avoidance support
distance between your vehicle and a
system) (green) is displayed.
vehicle ahead while the vehicle speed
is about 30 km/h (19 mph) or faster. If
NOTE
the distance between your vehicle and
The objects which activate the
a vehicle ahead is close, the system
system are four-wheeled vehicles.
alerts the driver of a possible collision
The DSA may also operate in the
using an indication on the display.
presence of motorcycles and
bicycles.
WARNING
The DSA may not operate normally
when the speed of a vehicle ahead is
Do not rely completely on the DSA:
too slow.
The ability of the system to detect a
The system does not operate with
vehicle ahead is limited depending on
the following objects.
the type of vehicle ahead, weather
conditions, or traffic conditions. In
Vehicles approaching in the
addition, the system is not for
opposite direction.
maintaining the distance between your
Stationary objects (stopped
vehicle and a vehicle ahead. If you
vehicles, obstructions)
neglect to operate the accelerator and
The DSA can be set to inoperable.
brake pedals correctly, it could lead to
(If only the DSA is turned off)
an accident. Always check the safety of
Refer to the Settings section in the
the surrounding area and depress the
Mazda Connect Owner's Manual.
brake pedal or accelerator pedal while
(If the DSA is turned off by
keeping a safe distance from vehicles
operating the i-ACTIVSENSE OFF
ahead or on-coming vehicles.
switch)
Refer to i-ACTIVSENSE OFF Switch
on page 4-98.
4-116 *Some models.
When Driving
i-ACTIVSENSE
If the ignition is switched OFF while
Driver Attention Alert
you have canceled the system using
the i-ACTIVSENSE OFF switch, the
(DAA)*
system is automatically enabled the
next time the ignition is switched
Driver Attention Alert (DAA)
ON. However, if the system is
The DAA is a system which detects
canceled using the personalization
driver fatigue and decreased
features, the system is not
attentiveness, and encourages the
automatically enabled.
driver to take a rest.
Vehicle Ahead Close Proximity
When the vehicle is driven inside traffic
Warning
lane lines at about 65 to 140 km/h
(41 to 86 mph), the DAA estimates the
When the system determines that the
amount of accumulated fatigue and
distance between your vehicle and a
decreased attentiveness of the driver
vehicle ahead is close, the
based on the information from the
i-ACTIVSENSE status symbol (warning/
Forward Sensing Camera (FSC) and
risk avoidance support system)
other vehicle information, and
changes from green to amber and the
encourages the driver to take a rest
warning indication is displayed on the
using an indication on the
multi-information display. While
multi-information display and a
checking the safety of the surrounding
warning sound.
area, depress the brake pedal while
Use the DAA on expressways or
keeping a safe distance from the
highways.
vehicle ahead.
Refer to Forward Sensing Camera
(FSC) on page 4-197.
*Some models.
4-117
When Driving
i-ACTIVSENSE
White (yellow) lane lines are less
WARNING
visible because of dirt or fading/
patchiness.
Do not rely completely on DAA and
The vehicle is jolted or swayed
always drive carefully:
continuously by strong winds or
The DAA detects driver fatigue and
rough roads.
decreased attentiveness and
The vehicle is driven aggressively.
encourages the driver to take a rest,
When making frequent lane
however, it is not designed to prevent
changes.
the vehicle from straying. If you rely too
The vehicle is making a curve.
much on the DAA it could lead to an
The DAA detects driver fatigue and
accident. Drive carefully and operate
decreased attentiveness based on
the steering wheel appropriately.
the driving data when the vehicle is
In addition, the system may not be
driven at about 65 to 140 km/h (41
able to detect driver fatigue and
to 86 mph) for about 20 minutes.
decreased attentiveness correctly
The driving data will be reset under
depending on the traffic and driving
the following conditions.
conditions. The driver must take
sufficient rest in order to drive safely.
The vehicle is stopped for 15
minutes or longer.
NOTE
The vehicle is driven at less than
about 65 km/h (41 mph) for
The DAA operates when all of the
about 30 minutes.
following conditions are met.
The ignition is switched off.
The vehicle speed is about 65 to
After the DAA has displayed the first
140 km/h (41 to 86 mph).
message encouraging rest, it does
The system detects white (yellow)
not display the next one until 60
lane lines.
minutes have passed.
The system has completed learning
of the driver’s driving data after 60
minutes have passed since the
driver began driving vehicle.
The DAA does not operate under the
following conditions.
The vehicle speed is less than
about 65 km/h (41 mph).
The vehicle speed exceeds about
140 km/h (86 mph).
The vehicle is making a sharp turn.
The vehicle is changing lanes.
The system cannot detect white
(yellow) lane lines.
The DAA may not operate normally
under the following conditions.
4-118
When Driving
i-ACTIVSENSE
Driver Attention Alert (DAA)
Driver Monitoring (DM)
Display
When the system detects driver fatigue
Driver Monitoring (DM)
or decreased attentiveness, it activates
The DM is a system which detects
the warning sound and displays an
driver fatigue and sleepiness, and
alert in the multi-information display.
encourages the driver to take a rest.
While driving the vehicle at about 5
km/h (3 mph) or faster, the DM
detects changes in the driver's facial
features using the driver monitoring
camera. The system then estimates the
amount of accumulated fatigue and
sleepiness of the driver and encourages
the driver to take a rest using a warning
indication in the instrument cluster and
a warning sound.
Two types of warning indication
patterns are set for notifying the driver
1.
“Time for a Break” message is
based on the estimated amount of
displayed
accumulated fatigue and sleepiness of
the driver.
Canceling Driver Attention Alert
(DAA)
Fatigue and sleepiness are detected:
Warning pattern (caution)
The DAA can be set to not activate.
Much more fatigue and sleepiness
Refer to the Settings section in the
are detected: Warning pattern
Mazda Connect Owner's Manual.
(warning)
*Some models.
4-119
When Driving
i-ACTIVSENSE
After displaying the warning
WARNING
pattern (caution), the next warning
pattern (caution) is not displayed
Do not rely completely on the DM
until 45 minutes have passed.
and always drive carefully:
After displaying the warning
The DM is a system which detects
pattern (warning), the next
driver fatigue and sleepiness, and
warning pattern (warning) is not
encourages the driver to take a rest.
displayed until 15 minutes have
This is not designed to prevent driver
passed.
fatigue and sleepiness, and
After displaying the warning
over-reliance on the system could lead
pattern (warning), the next
to an accident. Drive carefully and turn
warning pattern (caution) is not
the steering wheel appropriately.
displayed until 45 minutes have
In addition, the system may not be
passed.
able to detect driver fatigue and
sleepiness correctly depending on the
Driver Monitoring (DM) Display
traffic and driving conditions. The
When the Driver Monitoring (DM)
driver must take sufficient rest in order
detects driver fatigue or sleepiness, it
to drive safely.
activates the warning sound and
Operation conditions
displays an alert in the instrument
cluster.
The DM begins monitoring after 20
Warning pattern (caution) (white)
minutes have passed since the driver
began driving the vehicle and when
the vehicle speed is about 5 km/h (3
mph) or faster.
NOTE
If the vehicle speed decreases to less
than about 5 km/h (3 mph) while
the DM is monitoring, the DM stops
monitoring for 6 minutes even if the
vehicle speed returns to about 5
km/h (3 mph) or faster.
If the driver monitoring camera does
1.
“Time for a Break” message is
not recognize the driver correctly, the
displayed
DM may not monitor correctly.
Refer to Driver Monitoring Camera
on page 4-207.
After the DM has displayed the first
message encouraging the driver to
take a rest, it does not display it
again during the following periods.
4-120















Content      ..     6      7      8      9     ..
