When Driving
Switches and Controls
Leaving Home Light
NOTE
The leaving home light turns on the
Operation of the leaving home light
lights when the transmitter unlock
can be turned on or off.
button is pressed while away from the
Refer to the Settings section in the
vehicle.
Mazda Connect Owner's Manual.
The following lights turn on when the
When the transmitter lock button is
leaving home light is operated.
pressed and the vehicle receives the
Low beams, Parking lights, Taillights,
transmitter signal, the headlights turn
License plate lights.
off.
When the headlight switch is turned
To turn on the lights
to the OFF position, the headlights
When the ignition switch and the
turn off.
headlight switch are in the following
Headlight Leveling
conditions, the headlights will
illuminate when the transmitter unlock
The number of passengers and weight
button is pressed and the vehicle
of cargo in the luggage compartment
receives the transmitter signal. The
change the angle of the headlights.
headlights turn off after a certain
period of time has elapsed (30
Auto type
seconds).
The angle of the headlights will be
Ignition switch: off
automatically adjusted when turning
Headlight switch: AUTO,
, or
on the headlights.
A system malfunction or operation
conditions are indicated by a warning.
Refer to Exterior Light Warning
Indication/Warning Light on page
7-30.
1. Lock button
2. Unlock button
4-57
When Driving
Switches and Controls
Manual type
Turn and Lane-Change
When adjusting the illumination angle
Signals
of the headlights, refer to the Settings
section in the Mazda Connect
Turn and Lane-Change Signals
Owner's Manual.
Select the proper headlight angle from
The ignition must be switched ON to
the following chart.
use the turn and lane-change signals.
Front seat
Illumi-
Turn Signals
nation
Rear
Move the signal lever down (for a left
Load
angle
Driver
Passenger
seat
turn) or up (for a right turn) to the stop
(num-
position. The signal will self-cancel
ber)
after the turn is completed.
×
0
If the indicator light continues to flash
×
×
0
after a turn, manually return the lever
×
×
×
1
to its original position.
×
×
×
×
2
×
×
3.5
×: Yes
: No
Daytime Running Lights
Some countries require moving
vehicles to have their lights on
(daytime running lights) during the
daytime.
1. Right turn
The daytime running lights turn on
2. Right lane change
automatically.
3. OFF
4. Left lane change
NOTE
5. Left turn
(Except Canada)
The daytime running lights can be
The turn signal indicators in the
deactivated.
instrument cluster flash according to
Refer to the Settings section in the
the operation of the turn signal lever to
Mazda Connect Owner's Manual.
show which signal is working.
4-58
When Driving
Switches and Controls
NOTE
Windshield Wipers and
There may be a problem with the
Washer
turn signal lights if they do not flash
but remain turned on, or they flash
Windshield Wipers and Washer
abnormally. Have your vehicle
inspected by an Authorized Mazda
The ignition must be switched ON to
Dealer.
use the wipers.
A personalized function is available
to change the turn indicator sound
WARNING
volume.
Refer to the Settings section in the
Use only windshield washer fluid or
Mazda Connect Owner's Manual.
plain water in the reservoir:
Using radiator antifreeze as washer
Lane-Change Signals
fluid is dangerous. If sprayed on the
Move the lever halfway toward the
windshield, it will dirty the windshield,
direction of the lane changeuntil the
affect your visibility, and could result in
an accident.
indicator flashes and hold it there. It
will return to the off position when
released.
Only use windshield washer fluid
mixed with anti-freeze protection in
Three-Flash Turn Signal
freezing weather conditions:
Using windshield washer fluid without
After releasing the turn signal lever
anti-freeze protection in freezing
from the halfway point, the turn signal
weather conditions is dangerous as it
indicator flashes 3 times. The
could freeze on the windshield and
operation can be canceled by moving
block your vision which could cause an
the lever in the direction opposite to
accident. In addition, make sure the
which it was operated.
windshield is sufficiently warmed using
NOTE
the defroster before spraying the
The three-flash turn signal function can
washer fluid.
be switched to on/off using the
personalization function.
CAUTION
Refer to the Settings section in the
Mazda Connect Owner's Manual.
¾ When the wipers are not used during
freezing temperatures or for a long
time, the wiper rubber may adhere
to the glass. If the wipers are
operated while adhered to the glass,
it could damage the wiper rubber
and motor.
¾ If the wipers are operated while the
glass is dry, the glass could be
scratched and the wiper rubber
damaged. When the glass is dry,
spray washer fluid before operating
the wipers.
4-59
When Driving
Switches and Controls
¾ If the amount of washer fluid spray is
Switch Posi-
Wiper operation
insufficient, do not use the washer
tion
switch. If the washer switch
Operation while pulling up lev-
continues to be operated with no
MIST
er
washer fluid being sprayed, it could
OFF
Stop
lead to pump damage.
INT
Intermittent
NOTE
LO
Low speed
If the windshield wipers are operated
HI
High speed
under cold weather conditions or
during snowfall, they could stop due to
Variable-speed intermittent wipers
accumulated snow on the windshield.
If the windshield wipers stop due to
Set the lever to the intermittent
accumulated snow on the windshield,
position and choose the interval timing
park the vehicle in a safe place, turn
by rotating the switch.
the wiper switch off, and then remove
Rotate the switch upward (FAST
the accumulated snow. If the wiper
direction) to shorten the interval time
switch is turned to another position
of the wiper operation, and rotate the
other than OFF, the wipers will
switch downward (SLOW direction) to
lengthen it.
operate. If the wipers do not operate
even though the wiper switch is turned
to a position other than OFF, consult
an Authorized Mazda Dealer as soon
as possible.
Windshield Wipers
Turn the wipers on by pressing the
lever up or down.
With intermittent wiper
1. Switch
With auto-wiper control
1. Indicator light
4-60
When Driving
Switches and Controls
Switch Posi-
Wiper operation
CAUTION
tion
¾ Do not shade the rain sensor by
Operation while pulling up lev-
MIST
adhering a sticker or a label on the
er
windshield. Otherwise the rain
OFF
Stop
sensor will not operate correctly.
AUTO*1
Auto control
LO
Low speed
HI
High speed
*1
When the wiper lever is switched to the
AUTO position, the indicator light turns on.
Auto-wiper control*
When the wiper lever is in the AUTO
position, the rain sensor senses the
¾ When the ignition is switched ON
amount of rainfall on the windshield
and the wiper lever is in the AUTO
and turns the wipers on or off
position, the windshield wipers may
automatically (offintermittentlow
operate automatically in the
speedhigh speed).
following cases:
The sensitivity of the rain sensor can be
¾ The area of the windshield above
adjusted by turning the switch on the
the rain sensor is touched or wiped
wiper lever.
with a cloth.
From the center position (normal),
¾ The windshield or the rain sensor
rotate the switch upward (+ direction)
area in the cabin is hit.
for higher sensitivity (faster response)
or rotate it downward (- direction) for
When the ignition is switched ON
and the wiper lever is in the AUTO
less sensitivity (slower response).
position, do not touch the
windshield or the windshield wipers
Otherwise, the windshield wipers
will operate automatically which
could catch your fingers or damage
the windshield wipers.
When removing ice or snow, or
cleaning the windshield, always
make sure the wiper lever is in the
OFF position.
1. Switch
2. Higher sensitivity
3. Center position
4. Less sensitivity
*Some models.
4-61
When Driving
Switches and Controls
NOTE
If the headlight switch and the
windshield wiper switch are in
Switching the auto-wiper lever from
AUTO, and the wipers are operated
the OFF to the AUTO position while
at low or high speed by the auto
driving activates the windshield
wiper control for several seconds,
wipers once, after which they
bad weather conditions are
operate according to the rainfall
determined and the headlights may
amount.
be turned on.
The auto-wiper control may not
The auto-wiper control functions can
operate when the rain sensor
be turned off.
temperature is about 10 °C (14 °F)
Refer to the Settings section in the
or lower, or about 85 °C (185 °F) or
Mazda Connect Owner's Manual.
higher.
If the windshield is coated with
Windshield Washer
water repellent, the rain sensor may
Pull the wiper lever toward you to
not be able to sense the amount of
spray washer fluid and operate the
rainfall correctly and the auto-wiper
windshield wipers several times. The
control may not operate properly.
washer fluid is sprayed only while the
If dirt or foreign matter (such as ice
windshield wipers move out of their
or matter containing salt water)
stowed positions to the point where
adheres to the windshield above the
they start reversing back.
rain sensor, or if the windshield is
iced, it could cause the wipers to
move automatically. However, if the
wipers cannot remove this ice, dirt or
foreign matter, the auto-wiper
control will stop operation. In this
case, set the wiper lever to the low
speed position or high speed
1. OFF
position for manual operation, or
remove the ice, dirt or foreign matter
2. Washer
by hand to restore the auto-wiper
NOTE
operation.
If the auto-wiper lever is left in the
If the windshield washer is turned on
AUTO position, the wipers could
when the windshield wipers are not
operate automatically from the effect
operating, the windshield wipers
of strong light sources,
operate a few times.
electromagnetic waves, or infrared
If you pull the wiper lever while the
light because the rain sensor uses an
windshield wipers are reversing back
optical sensor. It is recommended
to their stowed positions, the next
that the auto-wiper lever be
time the washer fluid is sprayed is
switched to the OFF position other
during the next cycle.
than when driving the vehicle under
If the washer does not work, inspect
rainy conditions.
the fluid level (page 6-20). If the fluid
level is normal, consult an Authorized
Mazda Dealer.
4-62
When Driving
Switches and Controls
Rear Window Washer
Rear Window Wiper and
To spray washer fluid, turn the rear
Washer
wiper/washer switch to either of the
Rear Window Wiper and Washer
position. After the switch is
released, the washer will stop.
The ignition must be switched ON to
use the wiper.
NOTE
While the windshield washers are
Rear Window Wiper
operating (from the time the wiper
lever is pulled until the washer fluid
stops spraying), the rear window
washer does not spray washer fluid
even if you operate the switch.
If the washer does not work, inspect
the fluid level (page 6-20). If the fluid
level is normal and the washer still
does not work, consult an Authorized
Mazda Dealer.
Turn the wiper on by turning the rear
wiper/washer switch.
Switch Posi-
Wiper operation
tion
Spray washer fluid and operate
the rear wiper
ON
Normal
INT
Intermittent
OFF
Stop
Spray washer fluid and operate
the rear wiper
4-63
When Driving
Switches and Controls
NOTE
Rear Window Defogger
This defogger is not designed for
Rear Window Defogger
melting snow. If there is an
accumulation of snow on the rear
The rear window defogger clears fog
window, remove it before using the
from the rear window.
defogger.
The rear window defogger operation
The ignition must be switched ON to
time can be changed from 15
use the defogger.
minutes to continuous operation.
When the operation time has been
Press the switch to turn on the rear
switched to continuous operation,
window defogger. The rear window
by pressing the switch, the rear
defogger operates for about 15
window defogger will continue to
minutes and then turns off
operate until the ignition is switched
automatically.
OFF.
The indicator light illuminates when
Refer to the Settings section in the
the defogger is operating.
Mazda Connect Owner's Manual.
To turn off the rear window defogger
Windshield Wiper De-icer*
before the 15 minutes has elapsed,
press the switch again.
The thermal filaments at the following
positions heat up and facilitate the
removal of snow accumulated on the
windshield.
1. Indicator light
CAUTION
¾ Do not use sharp instruments or
window cleaners with abrasives to
clean the inside of the rear window
surface. They may damage the
defogger grid inside the window.
4-64
*Some models.
When Driving
Switches and Controls
The windshield wiper de-icer operates
Horn
in conjunction with the rear window
defogger.
Horn
To turn on the windshield wiper
de-icer, switch the ignition ON and
To sound the horn, press the
press the rear window defogger switch
mark on the steering wheel.
(page 4-64).
1. Indicator light
Mirror Defogger*
The mirror defoggers defrost the
outside mirrors.
The mirror defoggers operate in
conjunction with the rear window
defogger.
To turn on the mirror defoggers, switch
the ignition ON and press the rear
window defogger switch (page 4-64).
1. Indicator light
*Some models.
4-65
When Driving
Switches and Controls
Hazard Warning Flasher
HomeLink Wireless
Hazard Warning Flasher
Control System*
The hazard warning lights should
HomeLink Wireless Control
always be used when you stop on or
System
near a roadway in an emergency.
NOTE
HomeLink and HomeLink house are
registered trademarks of Gentex
Corporation.
The HomeLink system replaces up to 3
hand-held transmitters with a single
built-in component in the
auto-dimming mirror. Pressing the
HomeLink button on the
auto-dimming mirror activates garage
doors, gates and other devices
surrounding your home.
The hazard warning lights warn other
drivers that your vehicle is a traffic
hazard and that they must take
extreme caution when near it.
1. Indicator light
Depress the hazard warning flasher
2. HomeLink button
and all the turn signals will flash. The
hazard warning indicator lights in the
instrument cluster flash simultaneously.
NOTE
The turn signals do not work when
the hazard warning lights are on.
Check local regulations about the
use of hazard warning lights while
the vehicle is being towed to verify
that it is not in violation of the law.
4-66
*Some models.
When Driving
Switches and Controls
Pre-programming the HomeLink
WARNING
System
Do not use the HomeLink system with
NOTE
any garage door opener that lacks the
It is recommended that a new battery
safety stop and reverse feature:
be placed in the hand-held transmitter
Using the HomeLink system with any
of the device being programmed to
garage door opener that lacks the
HomeLink for quicker training and
safety stop and reverse feature as
accurate transmission of the
required by federal safety standards is
radio-frequency signal.
dangerous. (This includes garage doors
manufactured before April 1, 1982.)
Verify that there is a remote control
Using these garage door openers can
transmitter available for the device
increase the risk of serious injury or
you would like to program.
death. For further information, contact
HomeLink at www.homelink.com or
Programming the HomeLink
System
or an Authorized Mazda Dealer.
The HomeLink system provides 3
buttons which can be individually
Always check the areas surrounding
selected and programmed using the
garage doors and gates for people or
transmitters for current, on-market
obstructions before programming or
devices as follows:
during operation of the HomeLink
1. Press and release the HomeLink
system:
button you would like to program.
Programming or operating the
The indicator light flashes slowly in
HomeLink system without verifying the
amber when the button is pressed.
safety of areas surrounding garage
doors and gates is dangerous and
could result in an unexpected accident
and serious injury if someone were to
be hit.
NOTE
The programming will not be erased
1. Indicator light
even if the battery is disconnected.
2. HomeLink button
2. Hold the hand-held transmitter 2.5
to 7.5 cm (1 to 3 in) away from the
HomeLink button you would like to
program while keeping the
indicator light in view.
4-67
When Driving
Switches and Controls
NOTE
NOTE
Depending on the hand-held
Complete the programming within
transmitter, it may be easier to do
30 seconds.
the programming by holding it 15
7.
Return to the vehicle and firmly
to 20 cm (6 to 7.8 in) away from
press and hold the Homelink
the HomeLink button.
button, and then release it after
3.
Press the hand-held transmitter
two seconds have passed. Repeat
button continuously until the
the “press/hold/release” sequence
indicator light changes from amber
a second time, and, depending on
(flashing) to green (on/flashing).
the brand of the garage door
opener (or other rolling code
NOTE
equipped device), repeat this
Some gate operators and garage
sequence a third time to complete
door openers may require you to
the programming process.
replace this Programming Step 3
Press the programmed HomeLink
with procedures noted in the “Gate
button and make sure that the
Operator/Canadian Programming”
HomeLink System operates.
section.
8.
If the status indicator arrows are
4.
Press the HomeLink button again to
flashing, refer to Garage Door
check if the programming has been
Two-Way Communication.
completed.
If the indicator light remains on in
green, the programming is
complete and the device
becomes operational.
If the indicator light flashes
rapidly in green, firmly press and
hold the Homelink button and
1. Indicator light
release it after two seconds have
NOTE
passed. Repeat this process up to
To program the remaining two
three times to complete the
HomeLink buttons, go back to Step 1
programming. The device
of Programming the HomeLink System
becomes operational and
and repeat the procedure.
programming is complete. If the
device does not operate, go to
For questions or comments, please
the next step.
contact HomeLink at
5.
At the garage door opener receiver
(motor-head unit) in the garage,
locate the “learn” or “smart” button.
HomeLinkGentex, or the HomeLink
This can usually be found where the
toll-free hotline at 1-800-355-3515
hanging antenna wire is attached to
(for calls placed outside of the USA,
the motor-head unit.
Canada, and Puerto Rico, international
6.
Firmly press and release the “learn”
rates will apply and may differ based
or “smart” button. (The name and
on landline or mobile phone).
color of the button may vary by
manufacturer.)
4-68
When Driving
Switches and Controls
Gate operator/Canadian
Operating the HomeLink System
Programming
Press the programmed HomeLink
Canadian radio-frequency laws require
button to operate a programmed
transmitter signals to “time-out” (or
device.
quit) after several seconds of
Reprogramming the HomeLink
transmission which may not be long
system
enough for HomeLink to pick up the
signal during programming. Similar to
To program a device to HomeLink
this Canadian law, some U.S. gate
using a HomeLink button previously
operators are designed to “time-out”
trained, follow these steps:
in the same manner.
1. Press and hold the desired
HomeLink button. DO NOT release
If you live in Canada or are having
the button.
difficulties programming a gate
2. After 20 seconds, the indicator light
operator by using the programming
flashes in amber. After the indicator
procedures (regardless of where you
light flashes, release the HomeLink
live), replace Step 3 of Programming
button.
the HomeLink System with the
3. Go back to Step 2 of Programming
following:
the HomeLink System to complete
the procedure.
NOTE
If programming a garage door opener
NOTE
or gate operator, it is advised to unplug
If the programming has not been
the device during the “cycling” process
completed, the system returns to the
to prevent possible overheating.
previous programming.
While the indicator light is flashing in
amber, press the button on the
hand-held transmitter for 2 seconds
and release it repeatedly until the
indicator light changes from amber to
green.
Go back to Step 4 of Programming the
HomeLink System to complete the
procedure.
4-69
When Driving
Switches and Controls
Erasing Programmed HomeLink
Garage Door Two-Way
Buttons
Communication
The garage door two-way
NOTE
communication is a function that
All of the programmed HomeLink
communicates with the garage door
buttons are reset. Individual buttons
opener and indicates whether the
cannot be reset, however, individual
garages door is open or closed using
buttons can be reprogrammed. For
the indicator lights in the rear view
individual button reprogramming,
mirror. It can indicate the status of the
refer to Reprogramming the
garage door within a range up-to 250
HomeLink System (page 4-69).
m (820 ft).
Verify that the programming has
NOTE
been erased if you resell the vehicle.
The communication range may shorten
1.
Press the two outer HomeLink
depending on obstructions.
buttons continuously at the same
Programming two-way
time until the indicator light flashes.
communication
Within five seconds after programming
a new HomeLink button, both of the
garage door status indicator lights will
flash rapidly in green indicating that
the garage door two-way
communication has been established.
If the garage door status indicator
1. HomeLink button 3
lights flash, the two-way
2. HomeLink button 1
communication programming is
complete.
2.
Stop pressing the HomeLink
buttons.
If the garage door status indicator
lights do not flash, the two-way
communication programming is not
completed. For additional HomeLink
information and programming videos,
refer to the following Websites:
HomeLinkGentex
4-70
When Driving
Switches and Controls
Operating the garage door two-way
communication
By pressing HomeLink buttons 1 and 2
at the same time for two seconds, the
status of the garage door is indicated
for about 3 seconds as follows:
1. HomeLink button 2
2. HomeLink button 1
Garage door
Indicator light
status
Amber flashes
Closing
Amber flashes
Opening
Green turns on
Closed
Green turns on
Opened
NOTE
The programming will not be erased
even if the battery is disconnected.
4-71
When Driving
Brake
Dry off brakes that have become wet
Brake System
by driving slowly, releasing the
accelerator pedal and lightly applying
Foot Brake
the brakes several times until the
This vehicle has power-assisted brakes
brake performance returns to normal:
that adjust automatically through
Driving with wet brakes is dangerous.
normal use.
Increased stopping distance or the
vehicle pulling to one side when
Should power-assist fail, you can stop
braking could result in a serious
by applying greater force than normal
accident. Light braking will indicate
to the brake pedal. But the distance
whether the brakes have been
required to stop will be greater than
affected.
usual.
WARNING
CAUTION
¾ Do not drive with your foot held on
Do not coast with the engine stalled
the brake pedal. Doing so could
or turned off, find a safe place to stop:
result in the following:
Coasting with the engine stalled or
turned off is dangerous. Braking will
¾ The brake parts will wear out more
require more effort, and the brake's
quickly.
power-assist could be depleted if you
¾ The brakes can overheat and
pump the brake. This will cause longer
adversely affect brake
stopping distances or even an
performance.
accident.
¾ Always depress the brake pedal with
the right foot. Applying the brakes
Shift to a lower gear when going
with the unaccustomed left foot
down steep hills:
could slow your reaction time to an
Driving with your foot continuously on
emergency situation resulting in
the brake pedal or steadily applying
insufficient braking operation.
the brakes for long distances is
dangerous. This causes overheated
brakes, resulting in longer stopping
distances or even total brake failure.
This could cause loss of vehicle control
and a serious accident. Avoid
continuous application of the brakes.
¾ Wear shoes appropriate for driving in
order to avoid your shoe contacting
the brake pedal when depressing the
accelerator pedal.
Electric Parking Brake (EPB)
The EPB system applies the parking
brake using an electric motor. The
4-72
When Driving
Brake
system can operate automatically and
NOTE
manually.
The parking brake cannot be applied
The EPB switch indicator light turns on
or released while the vehicle battery
when applying the parking brake and it
is dead.
turns off when releasing the parking
Refer to If a Jump-Starting on page
brake.
7-13.
When the charging system warning
light in the instrument cluster turns
on, the parking brake cannot be
applied after switching the ignition
OFF. Before switching the ignition
OFF, apply the parking brake
manually.
The sound of the parking brake being
applied or released can be heard,
however, this does not indicate a
problem.
1. Indicator light
If the EPB is not used for long
periods, an automatic inspection of
WARNING
the system is performed while the
vehicle is parked. An operation
Do not drive the vehicle with the
sound can be heard, however, this
parking brake applied:
does not indicate a problem.
If the vehicle is driven with the parking
When applying the parking brake
brake applied, the brake parts may
and switching OFF the ignition, an
generate heat and the brake system
operation sound can be heard,
may not operate, leading to an
however, this does not indicate a
accident.
problem.
Before driving the vehicle, release the
The brake pedal may move while
parking brake and make sure that the
applying or releasing the parking
EPB indicator light in the instrument
brake, however, this does not
cluster turns off.
indicate a problem.
If the parking brake is applied with
Apply the parking brake when leaving
the ignition switched OFF or in ACC,
the vehicle:
the EPB indicator light in the
Not applying the parking brake when
instrument cluster and the indicator
parking the vehicle is dangerous as the
light in the switch may turn on for 15
vehicle may move unexpectedly and
seconds.
result in an accident. Before leaving the
When using an automatic car wash
vehicle, apply the parking brake and
which moves the vehicle with the
make sure that the EPB indicator light
front tires mounted, it is necessary to
in the instrument cluster turns on.
cancel the parking brake auto
operation before the vehicle enters
the automatic car wash. For details,
refer to Canceling the parking brake
automatic operation.
4-73
When Driving
Brake
Release the parking brake and use
and the EPB switch indicator light turn
neutral hold mode (automatic car
off.
wash mode) when it is necessary to
change the shift position to the N
position for an automatic car wash.
Refer to Selector Lever Operation on
page 4-37.
Manual operation
Applying the parking brake manually
When the brake pedal is firmly
depressed and the EPB switch is pulled
up, the parking brake is applied
regardless of the ignition position.
If the EPB switch is pressed without
depressing the brake pedal, a message
When the parking brake is applied, the
EPB indicator light in the instrument
is displayed on the multi-information
display to notify the driver to depress
cluster and the EPB switch indicator
light turn on.
the brake pedal.
Refer to Message Indicated on
Multi-information Display on page
7-35.
Auto operation
Applying the parking brake
automatically
When the ignition is switched from ON
to ACC or OFF, the parking brake will
be applied automatically. When the
parking brake is applied, the EPB
indicator light in the instrument cluster
Releasing the parking brake manually
and the EPB switch indicator light turn
When the brake pedal is firmly
on.
depressed and the EPB switch is
NOTE
pressed while the ignition is switched
To release the parking brake when the
ON or the engine is running, the
ignition is switched OFF, it is necessary
parking brake is released. When the
to cancel the parking brake auto
parking brake is released, the EPB
operation. For details, refer to
indicator light in the instrument cluster
Canceling the parking brake automatic
operation.
Releasing the parking brake
automatically
(Selector lever operation)
If the selector lever is shifted from the
P position to a position other than P
4-74
When Driving
Brake
with the parking brake applied and all
(Accelerator pedal operation)
of the following conditions met, the
If the accelerator pedal is depressed
parking brake is released automatically.
with the parking brake applied and all
When the parking brake is released,
of the following conditions met, the
the EPB indicator light in the
parking brake is released automatically.
instrument cluster and the EPB switch
When the parking brake is released,
indicator light turn off.
the EPB indicator light in the
instrument cluster and the EPB switch
The engine is running.
indicator light turn off.
The driver's door is closed.
Shift interlock release is enabled.
The engine is running.
The brake pedal is being depressed.
The driver's door is closed.
The driver's seat belt is fastened.
The selector lever is in the D or R
CAUTION
position.
Firmly depress the brake pedal and
perform the shift operation.
NOTE
Otherwise, the vehicle may move
If something such as the driver’s foot
unexpectedly.
contacts the accelerator pedal with the
engine running and the parking brake
When performing the following
applied, the parking brake might be
operations, shift interlock release can
released automatically. If you do not
be enabled/disabled.
intend to start driving the vehicle
1.
Switch the ignition ON.
immediately, shift the selector lever to
2.
Pull the EPB switch continuously for
the P or N position.
4 seconds or longer.
3.
Release the EPB switch once and
then pull it again continuously for 4
CAUTION
seconds or longer within 3 seconds.
If something such as the driver’s foot
(Switching from disable to enable
contacts the accelerator pedal with the
shift interlock release)
engine running and the parking brake
When shift interlock release is
applied, the parking brake may be
enabled, a sound is activated 2
released automatically and the vehicle
times and the EPB switch indicator
may move unexpectedly. If you do not
changes to fast flashing, and flashes
intend to start driving the vehicle
for 3 seconds.
immediately, shift the selector lever to
(Switching from enable to disable
the P or N position.
shift interlock release)
When shift interlock release is
Canceling the parking brake
disabled, a sound is activated 2
automatic operation
times and the EPB switch indicator
The parking brake automatic operation
light changes to slow flashing, and
can be canceled by doing any of the
flashes for 4 seconds.
following after switching the ignition
NOTE
from ON to OFF.
When the ignition is switched OFF,
Auto operation cancel method 1
the system setting before it was
turned off is maintained.
1. Switch the ignition ON.
4-75
When Driving
Brake
2. Release the parking brake manually.
where the driver cannot step on the
3. Turn off the AUTOHOLD.
brake pedal, continually pulling up the
4. Press the EPB switch continuously
EPB switch will apply the brakes and
for 2 seconds or longer (until a
decelerate or stop the vehicle. The
sound is activated).
parking brake on-reminder sound is
5. Release the EPB switch and switch
activated while the brake is applied. In
the ignition OFF within 5 seconds
addition, when releasing the switch,
after the sound was activated.
the brake is released and the sound
After the auto operation is
stops.
canceled, a sound is activated one
time, and the EPB switch indicator
WARNING
light switches from illumination to
flashing, and then turns off after 3
Use Emergency Brake only in an
seconds.
emergency situation:
Excessive use may cause the brake
Auto operation cancel method 2
parts to wear quickly or the brakes to
1. Switch the ignition ON.
heat up and become less effective.
2. Release the parking brake manually.
Warning Light
3. Turn off the AUTOHOLD.
4. Switch the ignition OFF with the
The warning light turns on when the
EPB switch pressed while the brake
system has a malfunction.
pedal is not depressed.
Refer to Brake System Warning
When the auto operation is
Indication/Warning Light on page
canceled, a sound is activated one
7-22.
time, and the EPB switch indicator
light goes from normal flashing to
Brake Pad Wear Indicator
faster flashing, and then turns off
When the disc brake pads become
after 3 seconds.
worn, the built-in wear indicators
NOTE
contact the disc plates. This causes a
screeching noise to warn that the pads
When canceling the parking brake
should be replaced.
auto operation and parking the
vehicle, shift the selector lever to the
P position and then use wheel
blocks.
The auto operation may not cancel if
the vehicle is parked on a steep
slope.
When the ignition is switched ON, the
parking brake auto operation is
restored.
When you hear this noise, consult an
How to use Emergency Brake
Authorized Mazda Dealer as soon as
possible.
If there is a problem with the brake
system (foot brake) while driving the
vehicle or in an emergency situation
4-76
When Driving
Brake
Brake Override System
WARNING
The brake override system applies the
Do not drive with worn disc pads:
brake first for safety if the brake pedal
Driving with worn disc pads is
and accelerator pedal are depressed at
dangerous. The brakes could fail and
the same time.
cause a serious accident. As soon as
NOTE
you hear a screeching noise consult an
Operation of the brake override system
Authorized Mazda Dealer.
can be turned on or off.
Refer to the Settings section in the
NOTE
Mazda Connect Owner's Manual.
In high humidity weather conditions,
brake noises, such as brake squeak or
brake squeal can be heard. It does not
indicate a malfunction.
Brake Assist
During emergency braking situations
when it is necessary to depress the
brake pedal with greater force, the
brake assist system provides braking
assistance, thus enhancing braking
performance.
When the brake pedal is depressed
hard or depressed more quickly, the
brakes apply more firmly.
NOTE
When the brake pedal is depressed
hard or depressed more quickly, the
pedal will feel softer but the brakes
will apply more firmly. This is a
normal effect of the brake assist
operation and does not indicate a
malfunction.
When the brake pedal is depressed
hard or depressed more quickly, a
motor/pump operation noise may
be heard. This is a normal effect of
the brake assist and does not
indicate a malfunction.
The brake assist equipment does not
supersede the functionality of the
vehicle's main braking system.
4-77
When Driving
Brake
AUTOHOLD
AUTOHOLD
The AUTOHOLD function automatically holds the vehicle stopped, even if you take
your foot off the brake pedal. This function can be best used while stopped in traffic
or at a traffic light. The brakes are released when you start driving the vehicle.
WARNING
Do not rely completely on the AUTOHOLD function:
The AUTOHOLD function is only designed to assist the brake operation while the
vehicle is stopped. Neglecting to operate the brakes and relying only on the
AUTOHOLD system is dangerous and could result in an unexpected accident if the
vehicle were to suddenly move. Operate the brakes appropriately in accordance
with the road and surrounding conditions.
Note that the vehicle may move suddenly depending on the vehicle's load or if it is
towing something.
Do not release your foot from the brake pedal while the vehicle is stopped on a
steep grade:
Because there is a possibility of the vehicle not being held in the stopped position by
the AUTOHOLD function, the vehicle may move unexpectedly and result in an
accident.
Do not use the AUTOHOLD function on slippery roads such as icy or
snow-covered roads, or unpaved roads:
Even if the vehicle is held in the stopped position by the AUTOHOLD function, the
vehicle may move unexpectedly and result in an accident. Operate the accelerator
pedal, brakes, or steering wheel appropriately as necessary.
Immediately depress the brake pedal in the following cases:
Because the AUTOHOLD function is canceled forcibly, the vehicle may move
unexpectedly and result in an accident.
¾ “Depress Brake Pedal. Brake Hold Disabled” is displayed in the multi-information
display and the warning sound is activated at the same time.
Always apply the parking brake when parking the vehicle:
Not applying the parking brake when parking the vehicle is dangerous as the vehicle
may move unexpectedly and result in an accident. When parking the vehicle, shift
the selector lever to the P position and apply the parking brake.
4-78
When Driving
Brake
CAUTION
If you stop operating the accelerator pedal before the vehicle starts moving, the
force holding the vehicle in the stopped position may weaken. Firmly depress the
brake pedal or depress the accelerator pedal to accelerate the vehicle.
NOTE
Under the following conditions, a problem with the AUTOHOLD is occurring.
Have your vehicle inspected at an Authorized Mazda Dealer as soon as possible.
A message is indicated on the multi-information display and a warning sound is
activated for about 5 seconds while the AUTOHOLD is operating or when you
press the AUTOHOLD switch.
If you switch the ignition OFF while the AUTOHOLD is operating, the parking
brake is applied automatically to assist you with parking the vehicle.
The AUTOHOLD is canceled when the selector lever is shifted to R position while
the vehicle is on level ground, or facing up a hill or grade (as shown below).
Vehicle posture and road surface gradient
AUTOHOLD operation status
Vehicle tilts forward
Operates
Level ground
Does not operate, canceled
Vehicle tilts rearward
Does not operate, canceled
: Reverse driving (selector lever in the reverse (R) position)
The brake pedal response may change, sound may occur from the brakes, or the
brake pedal could vibrate from the operation of the AUTOHOLD function.
However, this does not indicate a malfunction.
4-79
When Driving
Brake
To Turn On AUTOHOLD System
NOTE
When all of the following conditions
Press the AUTOHOLD switch and
are met, the AUTOHOLD operates and
when the AUTOHOLD standby
the brakes are held.
indicator light turns on, the
AUTOHOLD function turns on.
The ignition is switched ON (engine
is running or stopped by i-stop).
The vehicle is stopped.
The brake pedal is being depressed.
The AUTOHOLD active indicator
light turns on.
The accelerator pedal is not
depressed.
The driver's seat belt is fastened.
The driver's door is closed.
There is no problem with the
AUTOHOLD function.
The parking brake is released.
1. AUTOHOLD standby indicator light
There is no problem with the Electric
NOTE
Parking Brake (EPB) function.
When all of the following conditions
The selector lever is in a position
are met, the AUTOHOLD standby
other than R position or the vehicle
indicator light turns on when the
tilts forward with the selector lever in
AUTOHOLD switch is pressed and the
the R position.
AUTOHOLD function turns on.
To release AUTOHOLD and start
The ignition is switched ON (engine
driving the vehicle
is running or stopped by i-stop).
If you try to resume driving the vehicle,
The driver's seat belt is fastened.
the brakes will be released
The driver's door is closed.
automatically and the AUTOHOLD
There is no problem with the
active indicator light turns off.
AUTOHOLD function.
NOTE
To operate AUTOHOLD and hold the
brakes
If the Electric Parking Brake (EPB)
switch is pulled while the
1. Depress the brake pedal and bring
AUTOHOLD is operating, the
the vehicle to a complete stop.
parking brake is applied and the
2. The AUTOHOLD active indicator
AUTOHOLD is released. In addition,
light in the instrument cluster turns
if the parking brake is released under
on and the brakes are held.
this condition, the AUTOHOLD
operates to hold the brakes.
3. The vehicle is held in its stopped
position even with the brake pedal
released.
4-80
When Driving
Brake
Under the following conditions, the
To Turn Off AUTOHOLD System
parking brake is automatically
Depress the brake pedal and press the
applied and the AUTOHOLD is
AUTOHOLD switch. The AUTOHOLD
released. The AUTOHOLD is
is turned off and the AUTOHOLD
re-enabled when the conditions
standby indicator light turns off.
before the AUTOHOLD is released
are restored.
The driver’s seat belt is unfastened.
The driver’s door is opened.
When about 10 minutes or longer
have passed since the AUTOHOLD
operation started, the parking brake
is automatically applied. Because the
AUTOHOLD is restored when
releasing the parking brake, the hold
on the brakes by AUTOHOLD
function resumes.
1. AUTOHOLD standby indicator light
The AUTOHOLD can be canceled
forcibly by fully depressing the
NOTE
accelerator pedal for 1 second or
When the brakes are not held such
longer while the AUTOHOLD is
as while driving the vehicle, the
operating. Forcibly cancel the
AUTOHOLD can be turned off only
AUTOHOLD only when the
by pressing the AUTOHOLD switch.
AUTOHOLD cannot be canceled due
If the AUTOHOLD switch is pressed
to a system malfunction or it is
without depressing the brake pedal
necessary to cancel the AUTOHOLD
while AUTOHOLD is operating
in an emergency.
(AUTOHOLD active indicator light in
instrument cluster is turned on), the
message “Depress Brake Pedal and
Operate Switch to Release” is
indicated on the multi-information
display to notify the driver to depress
the brake pedal.
If any of the following conditions
occurs while the AUTOHOLD
function is operating (AUTOHOLD
active indicator light is turned on),
the parking brake is applied
automatically and the AUTOHOLD
function turns off. For the Electric
Parking Brake (EPB) operation, refer
to the Electric Parking Brake (EPB) on
page 4-72.
The ignition is switched OFF.
4-81
When Driving
Brake
There is a problem with the
Hill Launch Assist (HLA)
AUTOHOLD function.
Hill Launch Assist (HLA)
The HLA functions to assist in
accelerating the vehicle from a stop on
slopes. When releasing the brake pedal
and depressing the accelerator pedal
to accelerate the vehicle from a stop
while on a slope, the function prevents
the vehicle from rolling. The HLA also
operates when reversing on a slope.
The braking force is maintained
automatically after releasing the brake
pedal on a steep slope.
The HLA operates when the vehicle is
tilted rearward with the selector lever
in a forward gear, and operates when
the vehicle is tilted forward with the
selector lever in the R position.
WARNING
Do not rely completely on HLA:
HLA is an auxiliary device for
accelerating from a stop on a slope.
The system only operates for about 2
seconds and therefore, relying only on
the system, when accelerating from a
stop is dangerous because the vehicle
may move (roll) unexpectedly and
cause an accident.
The vehicle could roll depending on
the vehicle's load or if it is towing
something.
Always confirm the safety around the
vehicle before starting to drive the
vehicle.
NOTE
HLA does not operate on a gentle
slope. In addition, the gradient of
the slope on which the system will
operate changes depending on the
vehicle's load.
4-82
When Driving
Brake
HLA does not operate if the parking
brake is applied, or if the vehicle has
not stopped completely.
While HLA is operating, the brake
pedal may feel stiff and vibrate,
however, this does not indicate a
malfunction.
HLA does not operate while the
TCS/DSC indicator light is
illuminated.
Refer to TCS/DSC Indication/
Indicator Light (Turns on) on page
7-28.
HLA does not turn off even if the TCS
OFF switch is pressed to turn off the
TCS.
4-83
When Driving
ABS/TCS/DSC/Off-Road Traction Assist
NOTE
Antilock Brake System
Braking distances may be longer on
(ABS)
loose surfaces (snow or gravel, for
example) which usually have a hard
Antilock Brake System (ABS)
foundation. A vehicle with a normal
The ABS control unit continuously
braking system may require less
monitors the speed of each wheel. If
distance to stop under these
one wheel is about to lock up, the ABS
conditions because the tires will
responds by automatically releasing
build up a wedge of surface layer
and reapplying that wheel's brake.
when the wheels skid.
The sound of the ABS operating may
The driver will feel a slight vibration in
be heard when starting the engine or
the brake pedal and may hear a
immediately after starting the
chattering noise from the brake system.
vehicle, however, it does not indicate
This is normal ABS system operation.
a malfunction.
Continue to depress the brake pedal
without pumping the brakes.
The warning light turns on when the
system has a malfunction.
Refer to ABS Warning Indication/
Warning Light on page 7-25.
WARNING
Do not rely on ABS as a substitute for
safe driving:
The ABS cannot compensate for unsafe
and reckless driving, excessive speed,
tailgating (following another vehicle
too closely), driving on ice and snow,
and hydroplaning (reduced tire friction
and road contact because of water on
the road surface). You can still have an
accident.
4-84
When Driving
ABS/TCS/DSC/Off-Road Traction Assist
Use snow tires or tire chains and drive
Traction Control System
at reduced speeds when roads are
(TCS)
covered with ice and/or snow:
Driving without proper traction devices
Traction Control System (TCS)
on snow and/or ice-covered roads is
dangerous. The Traction Control
The Traction Control System (TCS)
System (TCS) alone cannot provide
enhances traction and safety by
adequate traction and you could still
controlling engine torque and braking.
have an accident.
When the TCS detects driving wheel
slippage, it lowers engine torque and
NOTE
operates the brakes to prevent loss of
To turn off the TCS, press the TCS OFF
traction.
switch (page 4-86).
This means that on a slick surface, the
TCS/DSC Indicator Light
engine adjusts automatically to provide
optimum power to the drive wheels,
limiting wheel spin and loss of traction.
The warning light turns on when the
system has a malfunction.
This indicator light stays on for a few
Refer to TCS/DSC Indication/
seconds when the ignition is switched
Indicator Light (Turns on) on page
ON.
7-28.
If the TCS or DSC is operating, the
indicator light flashes.
WARNING
If the light stays on, the TCS, DSC or
Do not rely on the Traction Control
the brake assist system may have a
System (TCS) as a substitute for safe
malfunction and they may not operate
driving:
correctly. Take your vehicle to an
The Traction Control System (TCS)
Authorized Mazda Dealer.
cannot compensate for unsafe and
reckless driving, excessive speed,
NOTE
tailgating (following another vehicle
In addition to the indicator light
too closely), and hydroplaning
flashing, a slight lugging sound will
(reduced tire friction and road contact
come from the engine. This indicates
because of water on the road surface).
that the TCS/DSC is operating
You can still have an accident.
properly.
On slippery surfaces, such as fresh
snow, it will be impossible to achieve
high rpm when the TCS is on.
4-85
When Driving
ABS/TCS/DSC/Off-Road Traction Assist
TCS OFF Indicator Light*
NOTE
When TCS is on and you attempt to
free the vehicle when it is stuck, or
drive it out of freshly fallen snow, the
TCS (part of the DSC system) will
activate. Depressing the accelerator
This indicator light stays on for a few
will not increase engine power and
seconds when the ignition is switched
freeing the vehicle may be difficult.
ON.
When this happens, turn off the TCS.
It also illuminates when the TCS OFF
If the TCS is off when the engine is
switch is pressed and TCS is switched
turned off, it automatically activates
off.
when the ignition is switched ON.
Refer to TCS OFF Switch on page
Leaving the TCS on will provide the
4-86.
best traction.
If the TCS OFF switch is pressed and
If the light remains illuminated and the
held for 10 seconds or more, the
TCS is not switched off, take your
TCS OFF switch malfunction
vehicle to an Authorized Mazda
detection function operates and the
Dealer. The DSC may have a
TCS system activates automatically.
malfunction.
The TCS OFF indicator light turns off
while the TCS system is operative.
TCS OFF Switch*
Press the TCS OFF switch to turn off the
TCS. The TCS OFF indicator light in the
instrument cluster will illuminate.
Press the switch again to turn the TCS
back on. The TCS OFF indicator light*
will turn off.
4-86
*Some models.
When Driving
ABS/TCS/DSC/Off-Road Traction Assist
Dynamic Stability Control
CAUTION
(DSC)
¾ The DSC may not operate correctly
unless the following are observed:
Dynamic Stability Control (DSC)
¾ Use tires of the correct size
The Dynamic Stability Control (DSC)
specified for your Mazda on all 4
automatically controls braking and
wheels.
engine torque in conjunction with
¾ Use tires of the same
systems such as ABS and TCS to help
manufacturer, brand and tread
control side slip when driving on
pattern on all 4 wheels.
slippery surfaces, or during sudden or
¾ Do not mix worn tires.
evasive maneuvering, enhancing
¾ The DSC may not operate correctly
vehicle safety.
when tire chains are used or a
temporary spare tire is installed
Refer to ABS (page 4-84) and TCS
because the tire diameter changes.
(page 4-85).
NOTE
DSC operation is possible at speeds
If there is a problem with the DSC, the
greater than 20 km/h (12 mph).
Hill Launch Assist (HLA) may not
operate.
The warning light turns on when the
Refer to Hill Launch Assist (HLA) on
system has a malfunction.
page 4-82.
Refer to TCS/DSC Indication/
Indicator Light (Turns on) on page
TCS/DSC Indicator Light
7-28.
WARNING
Do not rely on the Dynamic Stability
Control as a substitute for safe
This indicator light stays on for a few
driving:
seconds when the ignition is switched
The Dynamic Stability Control (DSC)
ON. If the TCS or DSC is operating,
cannot compensate for unsafe and
the indicator light flashes.
reckless driving, excessive speed,
tailgating (following another vehicle
If the light stays on, the TCS, DSC or
too closely), and hydroplaning
the brake assist system may have a
(reduced tire friction and road contact
malfunction and they may not operate
because of water on the road surface).
correctly. Take your vehicle to an
You can still have an accident.
Authorized Mazda Dealer.
4-87
When Driving
ABS/TCS/DSC/Off-Road Traction Assist
Off-Road Traction Assist*
CAUTION
The Off-Road Traction Assist is a
Off-Road Traction Assist
function to assist in freeing tires that
When the vehicle tires become
are stuck. When it is not necessary to
embedded in mud, sand, or deep
use this function, avoid driving the
snow, the Off-Road Traction Assist
vehicle continuously with the Off-Road
functions to prevent drive-wheel
Traction Assist on.
spinning and to assist in freeing tires
If the vehicle is driven continuously
that are stuck.
with the Off-Road Traction Assist on,
Do not drive over rough rocky roads
the AWD warning indication/warning
and river beds.
light may display/flash.
Refer to If a Warning Light Turns On or
WARNING
Flashes on page 7-22.
Do not rely completely on the
NOTE
Off-Road Traction Assist.
The vehicle may vibrate or you might
The Off-Road Traction Assist has
hear an operation sound while the
limitations. Always drive the vehicle
Off-Road Traction Assist is operating or
safely according to the road
is operational, however, this does not
conditions. Do not drive the vehicle
indicate a problem.
recklessly, otherwise it may result in an
accident. In addition, do not drive the
Off-Road Traction Assist Indicator
vehicle under the following conditions
Light
while the Off-Road Traction Assist is
operating. Otherwise, it could
negatively affect the drivetrain parts
which could result in an accident.
¾ Vehicle is driven on paved roads.
¾ Temporary spare tire of a different
When the ignition is switched ON,
specified size is used.
the indicator light turns on and then
¾ Tire chains are used.
turns off after a few seconds.
When pressing the Off-Road Traction
Assist switch to operate the Off-Road
Traction Assist, the indicator light
turns on.
A problem in the system might be
indicated under the following
conditions. Have your vehicle
inspected by an Authorized Mazda
Dealer.
The indicator light does not turn on
when the ignition is switched ON
or it remains on.
4-88
*Some models.















Content      ..     5      6      7      8     ..
