4-5. Using the driving support systems
259
QRe-enabling the Parking Support
the vehicle inspected by any autho-
Brake
rized Mazda retailer or Mazda autho-
rized repairer, or any reliable repairer.
To re-enable the Parking Support Brake
when it is disabled due to operation of
QIf a 12-volt battery terminal has
the Parking Support Brake, either
been disconnected and recon-
enable the system again (→P.256), or
nected
turn the power switch off and then back
The system needs to be initialized. To
to ON. Additionally, if the object
initialize the system, drive the vehicle
becomes no longer in the traveling
straight ahead for 5 seconds or more at
direction of the vehicle or if the traveling
a speed of approximately 35 km/h (22
direction of the vehicle changes (such
mph) or more.
as changing from moving forward to
backing up, or from backing up to mov-
ing forward), the system will be re-
enabled automatically.
Q If “PKSB Unavailable” is displayed
on the multi-information display
and the PKSB OFF indicator is on
If the vehicle is stopped due to operation
of the Parking Support Brake, the Park-
4
ing Support Brake will be disabled and
the PKSB OFF indicator will illuminate.
O A sensor may be covered with water
drops, ice, snow, dirt, etc. Remove the
water drops, ice, snow, dirt, etc., from
the sensor to return the system to nor-
mal.
Also, due to ice forming on a sensor at
low temperatures, a warning message
may be displayed or the sensor may
not be able to detect an object. Once
the ice melts, the system will return to
normal.
OIf this message is displayed, a sensor
on the front or rear bumper may be
dirty. Clean the sensors and their sur-
rounding area on the bumpers.
OIf this message continues to be dis-
played even after cleaning the sensor,
or is displayed even though the sen-
sor is clean, have the vehicle
inspected by any authorized Mazda
retailer or Mazda authorized repairer,
or any reliable repairer.
OInitialization may not have been per-
formed after a 12-volt battery terminal
was disconnected and reconnected.
Initialize the system. (→P.259)
If this message continues to be dis-
played even after initialization, have
260
4-5. Using the driving support systems
Parking Support Brake function (static objects)*
*: If equipped
If the sensors detect a static object, such as a wall, in the traveling
direction of the vehicle and the system determines that a collision
may occur due to the vehicle suddenly moving forward due to an
accidental accelerator pedal operation, the vehicle moving the unin-
tended direction due to the wrong shift lever being selected, or
while parking or traveling at low speeds, the system will operate to
lessen the impact with the detected static object and reduce the
resulting damage.
Examples of function operation
This function will operate in situations such as the following if an object is
detected in the traveling direction of the vehicle.
Q When traveling at a low speed and the brake pedal is not
depressed, or is depressed late
4-5. Using the driving support systems
261
Q When the accelerator pedal is depressed excessively
Q When the vehicle moves in the unintended direction due to the
wrong shift lever being selected
4
Types of sensors
WARNING
Q To ensure the Parking Support
→P.246
Brake can operate properly
Observe the following precautions
regarding the sensors (→P.246). Fail-
ure to do so may cause a sensor to
not operate properly, and may cause
an accident.
O Do not modify, disassemble or paint
the sensors.
262
4-5. Using the driving support systems
WARNING
OWhen using a high pressure
washer to wash the vehicle, do not
O Do not replace a sensor with a part
spray the sensors directly, as doing
other than a genuine part.
so may cause a sensor to malfunc-
tion.
O Do not subject a sensor or its sur-
rounding area to a strong impact.
OWhen using steam to clean the
vehicle, do not direct steam too
O Do not damage the sensors, and
close to the sensors as doing so
always keep them clean.
may cause a sensor to malfunction.
O If the area around a radar sensor is
QWhen to disable the Parking Sup-
subjected to an impact, the system
port Brake
may not operate properly due to a
sensor malfunction. Have the vehi-
In the following situations, disable the
cle inspected by any authorized
Parking Support Brake as the system
Mazda retailer or Mazda authorized
may operate even though there is no
repairer, or any reliable repairer.
possibility of a collision.
QHandling the suspension
OWhen inspecting the vehicle using
a chassis roller, chassis dynamo or
Do not modify the suspension, as
free roller
changes to the height or inclination of
the vehicle may prevent the sensors
OWhen loading the vehicle onto a
from detecting objects correctly or
boat, truck or other transport vessel
cause the system to not operate or
operate unnecessarily.
OIf the suspension has been modi-
fied or tires of a size other than
Q If the Parking Support Brake
specified are installed
function (static objects) oper-
ates unnecessarily, such as at a
OIf the front of the vehicle is raised or
railroad crossing
lowered due to the carried load
In the event that the Parking Support
OWhen equipment that may obstruct
Brake function (static objects) oper-
a sensor is installed, such as a tow-
ates unnecessarily, such as at a rail-
ing eyelet, bumper protector (an
road crossing, brake control will be
additional trim strip, etc.), bicycle
canceled after approximately 2 sec-
carrier, or snow plow
onds, allowing you to proceed forward
and leave the area, brake control can
OWhen using an automatic car wash
also be canceled by depressing the
brake pedal. Depressing the acceler-
ator pedal after brake control is can-
QThe Parking Support Brake func-
celed will allow you to proceed
tion (static object) will operate
forward and leave the area.
when
Q Notes when washing the vehicle
The function will operate when the
PKSB OFF indicator is not illuminated or
Do not apply intensive bursts of water
flashing (→P.87, 88) and all of the fol-
or steam to the sensor area.
lowing conditions are met:
Doing so may result in the sensor
O Hybrid system output restriction con-
malfunctioning.
trol
• The Parking Support Brake is
enabled.
• The vehicle speed is 15 km/h (9 mph)
4-5. Using the driving support systems
263
or less.
parking assist-sensor. (→P.249) There-
• There is a static object in the traveling
fore, even if the parking assist-sensor
direction of the vehicle and 2 to 4 m (6
detects an object and provides a warn-
to 13 ft.) away.
ing, the Parking Support Brake function
• The Parking Support Brake deter-
(static objects) may not start operating.
mines that a stronger-than-normal
Q Objects that the Parking Support
brake operation is necessary to avoid
Brake function (static objects) may
a collision.
not detect
OBrake control
The sensors may not be able to detect
• Hybrid system output restriction con-
certain objects, such as the following:
trol is operating.
• The Parking Support Brake deter-
OPedestrian
mines that an immediate brake opera-
O Cotton cloth, snow, and other materi-
tion is necessary to avoid a collision.
als that are poor reflectors of ultra-
sonic waves
QThe Parking Support Brake func-
tion (static objects) will stop oper-
O Objects which are not perpendicular
ating when
to the ground, are not perpendicular to
The function will stop operating if any of
the traveling direction of the vehicle,
the following conditions are met:
are uneven or are waving
O Hybrid system output restriction con-
O Low objects
4
trol
OThin objects such as wires, fences,
• The Parking Support Brake is dis-
ropes and signposts
abled.
O Objects that are extremely close to
• The system determines that the colli-
the bumper
sion has become avoidable with nor-
mal brake operation.
OSharply-angled objects
• The static object is no longer 2 to 4 m
O Tall objects with upper sections pro-
(6 to 13 ft.) away from the vehicle or in
jecting outwards in the direction of
the traveling direction of the vehicle.
your vehicle
OBrake control
Qparking assist-sensor buzzer
• The Parking Support Brake is dis-
abled.
Regardless of whether the parking
• Approximately 2 seconds have
assist-sensor buzzer is enabled or not
elapsed since the vehicle was
(→P.246), if the Parking Support Brake
stopped by brake control.
function (static objects) is enabled
• The brake pedal is depressed after
(→P.256), the front or rear sensors
the vehicle is stopped by brake con-
detect an object and brake control is
trol.
performed, the parking assist-sensor
• The static object is no longer 2 to 4 m
buzzer will sound to notify the driver of
(6 to 13 ft.) away from the vehicle or in
the approximate distance to the object.
the traveling direction of the vehicle.
QSituations in which the Parking
QRe-enabling the Parking Support
Support Brake function (static
Brake function (static objects)
objects) may operate even if there
is no possibility of a collision
→P.259
In some situations, such as the follow-
QDetection range of the Parking Sup-
ing, the Parking Support Brake function
port Brake function (static objects)
(static objects) may operate even
The detection range of the Parking Sup-
though there is no possibility of a colli-
port Brake function (static objects) dif-
sion.
fers from the detection range of the
O Vehicle surroundings
264
4-5. Using the driving support systems
When driving on a narrow road
produce ultrasonic waves are near the
vehicle
• If a sticker or an electronic compo-
nent, such as a backlit license plate
(especially fluorescent type), fog
lights, fender pole or wireless antenna
is installed near a sensor
O Changes in the vehicle posture
• If the vehicle is significantly tilted
• If the front of the vehicle is raised or
When driving on a gravel road or in an
lowered due to the carried load
area with tall grass
• If the orientation of a sensor has been
changed due to a collision or other
impact
• If a sensor has been painted or cov-
ered with a sticker, etc.
QSituations in which the Parking
Support Brake function (static
objects) may not operate properly
In some situations, such as the follow-
ing, this function may not operate prop-
When driving toward a banner, flag,
erly.
low-hanging branch or boom barrier
O Weather
(such as those used at railroad cross-
When a sensor or the area around a
ings, toll gates and parking lots)
sensor is extremely hot or cold
When driving on a narrow path sur-
rounded by a structure, such as in a
tunnel or on an iron bridge
When parallel parking
When there is a rut or hole in the sur-
face of the road
When driving on a metal cover (grat-
ing), such as those used for drainage
ditches
When driving on a steep slope
If a sensor is hit by a large amount of
When strong winds are blowing
water, such as when driving on a
flooded road
O Weather
• If a sensor is covered with ice, snow,
dirt, etc. (when cleared, the system
will return to normal)
• If heavy rain or water strikes a sensor
• When driving in inclement weather
such as fog, snow or a sandstorm
• When strong winds are blowing
If a sensor is covered with ice, snow,
O Other ultrasonic wave sources
dirt, etc. (when cleared, the system
• When vehicle horns, vehicle detec-
will return to normal)
tors, motorcycle engines, air brakes of
If heavy rain or water strikes a sensor
large vehicles, the clearance sonar of
When driving in inclement weather
other vehicles or other devices which
such as fog, snow or a sandstorm
4-5. Using the driving support systems
265
• When the sensor is frozen (Once the
sensor thaws, the system will return to
normal)
O Vehicle surroundings
• When an object that cannot be
detected is between the vehicle and a
detected object
• If an object such as a vehicle, motor-
cycle, bicycle or pedestrian cuts in
front of the vehicle or runs out from
the side of the vehicle
• The vehicle is approaching a tall or
curved curb.
• On an extremely bumpy road, on an
incline, on gravel, or on grass.
• If objects draw too close to the sensor.
O Other ultrasonic waves sources
• When vehicle horns, vehicle detec-
tors, motorcycle engines, air brakes of
large vehicles, the clearance sonar of
4
other vehicles or other devices which
produce ultrasonic waves are near the
vehicle
• If a sticker or an electronic compo-
nent, such as a backlit license plate
(especially fluorescent type), fog
lights, fender pole or wireless antenna
is installed near a sensor
O Changes in the vehicle posture
• If the vehicle is significantly tilted
• If the front of the vehicle is raised or
lowered due to the carried load
• If the orientation of a sensor has been
changed due to a collision or other
impact
• When equipment that may obstruct a
sensor is installed, such as a bumper
protector (an additional trim strip,
etc.), bicycle carrier, or snow plow
• If the suspension has been modified
or tires of a size other than specified
are installed
• If a sensor has been painted or cov-
ered with a sticker, etc.
266
4-5. Using the driving support systems
Parking Support Brake function (rear-crossing vehi-
cles)*
*: If equipped
If a rear radar sensor detects a vehicle approaching from the right
or left at the rear of the vehicle and the system determines that the
possibility of a collision is high, this function will perform brake
control to reduce the likelihood of an impact with the approaching
vehicle.
Examples of function operation
This function will operate in situations such as the following if a vehicle is
detected in the traveling direction of the vehicle.
Q When reversing, a vehicle is approaching and the brake pedal is not
depressed, or is depressed late
Types of sensors
WARNING
Q To ensure the Parking Support
→P.242
Brake (rear-crossing vehicles)
can operate properly
Observe the following precautions
regarding the rear radar sensors
(→P.242). Failure to do so may cause
a sensor to not operate properly, and
may cause an accident.
4-5. Using the driving support systems
267
trol is operating.
WARNING
• The Parking Support Brake deter-
O Do not modify, disassemble or paint
mines that an emergency brake oper-
the sensors.
ation is necessary to avoid a collision
with an approaching vehicle.
O Do not replace a rear radar sensor
QThe Parking Support Brake func-
with a part other than a genuine
tion (rear-crossing vehicles) will
part.
stop operating when
O Do not damage the rear radar sen-
The function will stop operating if any of
sors, and always keep the radar
the following conditions are met:
sensors and their surrounding area
O Hybrid system output restriction con-
on the bumper clean.
trol
O If the area around a rear radar sen-
• The Parking Support Brake is dis-
sor is subjected to an impact, the
abled.
system may not operate properly
• The collision becomes avoidable with
due to a sensor malfunction. Have
normal brake operation.
the vehicle inspected by any autho-
• A vehicle is no longer approaching
rized Mazda retailer or Mazda
from the right or left at the rear of the
authorized repairer, or any reliable
vehicle.
repairer.
4
O Brake control
• The Parking Support Brake is dis-
O Observe the rear radar sensor han-
abled.
dling precautions. (→P.242)
• Approximately 2 seconds have
elapsed since the vehicle was
stopped by brake control.
QThe Parking Support Brake func-
• The brake pedal is depressed after
tion (rear-crossing vehicles) will
the vehicle is stopped by brake con-
operate when
trol.
The function will operate when the
• A vehicle is no longer approaching
PKSB OFF indicator is not illuminated or
from the right or left at the rear of the
flashing (→P.87, 88) and all of the fol-
vehicle.
lowing conditions are met:
QDetection area of the Parking Sup-
O Hybrid system output restriction con-
port Brake function (rear-crossing
trol
vehicles)
• The Parking Support Brake is
The detection area of the Parking Sup-
enabled.
port Brake function (rear-crossing vehi-
• The vehicle speed is 15 km/h (9 mph)
cles) differs from the detection area of
or less.
the RCTA function (→P.253). Therefore,
• Vehicles which are approaching from
even if the RCTA function detects a
the right or left at the rear of the vehi-
vehicle and provides an alert, the Park-
cle at a traveling speed of less than
ing Support Brake function (rear-cross-
approximately 8 km/h (5 mph)
ing vehicles) may not start operating.
• The shift lever is in R.
• The Parking Support Brake deter-
QConditions under which the Park-
mines that a stronger than normal
ing Support Brake function (rear-
brake operation is necessary to avoid
crossing vehicles) will not detect a
a collision with an approaching vehi-
vehicle
cle.
The Parking Support Brake function
OBrake control
(rear-crossing vehicles) is not designed
• Hybrid system output restriction con-
to detect the following types of vehicles
268
4-5. Using the driving support systems
and/or objects:
QSituations in which the system may
operate even though there is no
O Vehicles approaching from directly
possibility of a collision
behind
In some situations such as the following,
O Vehicles backing up in a parking
the Parking Support Brake function
space next to your vehicle
(rear-crossing vehicles) may operate
O Vehicles that the sensors cannot
even though there is no possibility of a
detect due to obstructions
collision.
O When the parking space faces a street
and vehicles are being driven on the
street
O Vehicles which suddenly accelerate or
decelerate near your vehicle
O Guardrails, walls, signs, parked vehi-
cles and similar stationary objects*
O When a detected vehicle turns while
approaching the vehicle
OSmall motorcycles, bicycles, pedestri-
ans, etc.*
O Vehicles moving away from your vehi-
cle
O Vehicles approaching from the park-
ing spaces next to your vehicle*
O Objects which are extremely close to
a radar sensor*
O Vehicles which are approaching from
O When a vehicle passes by the side of
the right or left at the rear of the vehi-
your vehicle
cle at a traveling speed of less than
approximately 8 km/h (5 mph)
O Vehicles which are approaching from
the right or left at the rear of the vehi-
cle at a traveling speed of more than
approximately 24 km/h (15 mph)
*: Depending on the conditions, detec-
tion of a vehicle and/or object may
occur.
O When the distance between your vehi-
Q RCTA buzzer
cle and metal objects, such as a
Regardless of whether the RCTA func-
guardrail, wall, sign, or parked vehicle,
tion is enabled or not (→P.252), if the
which may reflect electrical waves
Parking Support Brake function is
toward the rear of the vehicle, is short
enabled (→P.256) and brake control is
performed, a buzzer will sound to notify
the driver.
4-5. Using the driving support systems
269
or wireless antenna is installed near a
radar sensor
OIf the orientation of a radar sensor has
been changed
O When multiple vehicles are approach-
ing with only a small gap between
each vehicle
OIf a vehicle is approaching the rear of
OWhen there are spinning objects near
your vehicle rapidly
your vehicle such as the fans of an air
OSituations in which the radar sensor
conditioning unit
may not detect a vehicle
OWhen water is splashed or sprayed
When a vehicle approaches from the
toward the rear bumper, such as from
right or left at the rear of the vehicle
a sprinkler
while you are turning while backing up
When turning while backing up
QSituations in which the Parking
Support Brake function (rear-cross-
ing vehicles) may not operate prop-
erly
In some situations, such as the follow-
4
ing, the radar sensors may not detect an
object and this function may not operate
properly
OStationary objects
OWhen a sensor or the area around a
When backing out of a shallow angle
sensor is extremely hot or cold
parking spot
OIf the rear bumper is covered with ice,
snow, dirt, etc.
OWhen it is raining heavily or water
strikes the vehicle
OWhen the detection area of a radar
sensor is obstructed by an adjacent
vehicle
OIf the vehicle is significantly tilted
When backing up on a slope with a
OWhen equipment that may obstruct a
sharp change in grade
sensor is installed, such as a towing
eyelet, bumper protector (an addi-
tional trim strip, etc.), bicycle carrier,
or snow plow
OIf the suspension has been modified
or tires of a size other than specified
are installed
OIf the front of the vehicle is raised or
lowered due to the carried load
OIf an electronic component, such as a
backlit license plate (especially fluo-
rescent type), fog lights, fender pole
270
4-5. Using the driving support systems
Driving mode select
switch
The driving modes can be
selected to suit driving condi-
tion.
Selecting a drive mode
Each time the switch is pressed,
the system changes between
power mode, normal mode, and
• When a vehicle turns into the detec-
ECO drive mode.
tion area
1
Normal mode
Provides an optimal balance of fuel
economy, quietness, and dynamic per-
formance. Suitable for normal driving.
2 Power mode
Controls the hybrid system to provide
quick, powerful acceleration. Making it
suitable for when agile driving response
is desired, such as when driving on
roads with many curves.
When the Power mode is selected,
Power mode indicator comes on.
3 Eco drive mode
Helps the driver accelerate in an eco-
friendly manner and improve fuel econ-
omy through moderate throttle charac-
teristics and by controlling the operation
of the air conditioning system (heat-
4-5. Using the driving support systems
271
ing/cooling).
GPF (Gasoline Particu-
When the Eco drive mode is selected,
late Filter) system*
Eco drive mode indicator comes on.
*: If equipped
Q Operation of the air conditioning
system in Eco drive mode
The GPF system collects par-
Eco drive mode controls the heat-
ticulate matter in the exhaust
ing/cooling operations and fan speed of
gas by using an exhaust gas
the air conditioning system to enhance
filter.
fuel efficiency. To improve air condition-
ing performance, perform the following
The system will operate to
operations:
regenerate the filter automati-
O Turn off air conditioning eco mode
cally, depending on the vehicle
(→P.284)
conditions.
OAdjust the fan speed (→P.285)
O Turn off Eco drive mode
QIf “Exhaust Filter Full See Owner’s
QAutomatic deactivation of Power
Manual” is shown on the multi-
mode
information display
4
If the power switch is turned off after
OThe message may be displayed while
driving in power mode, the drive mode
high load driving with particulate mat-
will be changed to normal mode.
ter accumulating.
O Hybrid system output is restricted
while the message is displayed, how-
ever, it is possible to drive the vehicle
unless the malfunction indicator lamp
comes on.
OParticulate matter can accumulate
more quickly if the vehicle is fre-
quently driven short trips or at low
speeds, or if the hybrid system is reg-
ularly started in an extremely cold
environment. Excessive accumula-
tion of particulate matter can be pre-
vented by periodically driving long
distances continuously with intermit-
tent releasing of the accelerator pedal,
such as when driving on highways
and freeways.
QIf the malfunction indicator lamp
comes on or “Hybrid System Mal-
function Output Power Reduced
Visit Your Dealer” is shown on the
multi-information display
The amount of accumulated particulate
matter has exceeded a certain level.
Have the vehicle inspected by any
authorized Mazda retailer or Mazda
272
4-5. Using the driving support systems
authorized repairer, or any reliable
Driving assist systems
repairer immediately.
NOTICE
To keep driving safety and per-
formance, the following sys-
Q To prevent the GPF system from
not operating properly
tems operate automatically in
O Do not use fuel other than the spec-
response to various driving sit-
ified type
uations. Be aware, however,
O Do not modify the exhaust pipes
that these systems are supple-
mentary and should not be
relied upon too heavily when
operating the vehicle.
Summary of the driving
assist systems
Q ECB (Electronically Con-
trolled Brake System)
The electronically controlled sys-
tem generates braking force corre-
sponding to the brake operation
Q ABS (Anti-lock Brake System)
Helps to prevent wheel lock when
the brakes are applied suddenly, or
if the brakes are applied while driv-
ing on a slippery road surface
Q Brake assist
Generates an increased level of
braking force after the brake pedal
is depressed when the system
detects a panic stop situation
Q VSC (Vehicle Stability Control)
Helps the driver to control skidding
when swerving suddenly or turning
on slippery road surfaces.
4-5. Using the driving support systems
273
Q VSC+ (Vehicle Stability Con-
lights are automatically controlled
trol+)
to reduce the vehicle speed and
help reduce the possibility of further
Provides cooperative control of the
damage due to a secondary colli-
ABS, TRC, VSC and EPS.
sion.
Helps to maintain directional stabil-
ity when swerving on slippery road
Q When the TRC/VSC/ABS systems
surfaces by controlling steering per-
are operating
formance.
The slip indicator light will flash while the
Q TRC (Traction Control)
TRC/VSC/ABS
systems are operating.
Helps to maintain drive power and
prevent the drive wheels from spin-
ning when starting the vehicle or
accelerating on slippery roads
Q Active Cornering Assist (ACA)
4
Helps to prevent the vehicle from
drifting to the outer side by perform-
Q Disabling the TRC system
ing inner wheel brake control when
If
the vehicle gets stuck in mud, dirt
or
snow, the TRC system may reduce
attempting to accelerate while turn-
power from the hybrid system to the
ing
wheels. Pressing
to turn the system
Q Hill-start assist control
off may make it easier for you to rock the
vehicle in order to free it.
Helps to reduce the backward
To turn the TRC system off, quickly
movement of the vehicle when
starting on an uphill
press and release
The “Traction Control Turned OFF” will
Q EPS (Electric Power Steering)
be shown on the multi-information dis-
Employs an electric motor to
play.
reduce the amount of effort needed
Press
again to turn the system
to turn the steering wheel.
back on.
Q Emergency brake signal
When the brakes are applied sud-
denly, the emergency flashers auto-
matically flash to alert the vehicle
behind.
Q Secondary Collision Brake
When the SRS airbag sensor
Traction Control Turned OFF
detects a collision and the system
operates, the brakes and brake
274
4-5. Using the driving support systems
Q Turning off both TRC and VSC sys-
Q Automatic system cancelation of
tems
hill-start assist control
To turn the TRC and VSC systems off,
The hill-start assist control will turn off in
any of the following situations:
press and hold
for more than 3 sec-
OThe shift lever is shifted to P or N.
onds while the vehicle is stopped.
OThe accelerator pedal is depressed
The VSC OFF indicator light will come
on and the “Traction Control Turned
OThe parking brake is engaged
OFF” will be shown on the multi-infor-
O 2 seconds at maximum elapsed after
mation display.*
the brake pedal is released
QSounds and vibrations caused by
Press
again to turn the system
the ABS, brake assist, VSC, TRC
and hill-start assist control sys-
back on.
tems
*: On vehicles with PCS (Pre-Collision
O A sound may be heard from the
System), PCS will also be disabled
engine compartment when the brake
(only Pre-Collision warning is avail-
pedal is depressed repeatedly, when
able). The PCS warning light will
the hybrid system is started or just
come on and a message will be dis-
after the vehicle begins to move. This
sound does not indicate that a mal-
played on the multi-information dis-
function has occurred in any of these
play. (→P.213)
systems.
QWhen the message is displayed on
OAny of the following conditions may
the multi-information display show-
occur when the above systems are
ing that TRC has been disabled
operating. None of these indicates
that a malfunction has occurred.
even if
has not been pressed
• Vibrations may be felt through the
TRC is temporary deactivated. If the
vehicle body and steering.
information continues to show, contact
• A motor sound may be heard also
any authorized Mazda retailer or Mazda
after the vehicle comes to a stop.
authorized repairer, or any reliable
Q ECB operating sound
repairer.
ECB operating sound may be heard in
Q Operating conditions of hill-start
the following cases, but it does not indi-
assist control
cate that a malfunction has occurred.
When the following four conditions are
O Operating sound heard from the
met, the hill-start assist control will oper-
engine compartment when the brake
ate:
pedal is operated.
OThe shift lever is in a position other
O Motor sound of the brake system
than P or N (when starting off for-
heard from the front part of the vehicle
ward/backward on an upward incline).
when the driver’s door is opened.
OThe vehicle is stopped
O Operating sound heard from the
OThe accelerator pedal is not
engine compartment when one or two
depressed
minutes passed after the stop of the
hybrid system.
OThe parking brake is not engaged
QActive Cornering Assist operation
sounds and vibrations
When the Active Cornering Assist is
operated, operation sounds and vibra-
4-5. Using the driving support systems
275
tions may be generated from the brake
ates:
system, but this is not a malfunction.
OThe emergency flashers are off
QEPS operation sound
OActual vehicle speed is over 55 km/h
When the steering wheel is operated, a
(35 mph)
motor sound (whirring sound) may be
OThe system judges from the vehicle
heard. This does not indicate a malfunc-
deceleration that it is a sudden brak-
tion.
ing operation.
QAutomatic reactivation of TRC and
Q Automatic system cancelation of
VSC systems
emergency brake signal
After turning the TRC and VSC systems
The emergency brake signal will be can-
off, the systems will be automatically re-
celed in any of the following situations:
enabled in the following situations:
OThe emergency flashers are turned
OWhen the power switch is turned off
on.
OIf only the TRC system is turned off,
OThe system judges from the vehicle
the TRC will turn on when vehicle
deceleration that is not a sudden brak-
speed increases.
ing operation.
If both the TRC and VSC systems are
turned off, automatic re-enabling will
QSecondary Collision Brake operat-
not occur when vehicle speed
ing cancelation
4
increases.
The system operates when the SRS air-
bag sensor detects a collision while the
Q Operating conditions of Active Cor-
vehicle is in motion.
nering Assist
However, the system does not operate
The system operates when the following
when components are damaged.
occurs.
QSecondary Collision Brake auto-
O TRC/VSC can operate
matic cancelation
OThe driver is attempting to accelerate
The system is automatically canceled in
while turning
any of the following situations.
OThe system detects that the vehicle is
OThe vehicle speed drops approxi-
drifting to the outer side
mately 0 km/h (0 mph)
OThe brake pedal is released
O A certain amount of time elapses
QReduced effectiveness of the EPS
during operation
system
OThe accelerator pedal is depressed a
The effectiveness of the EPS system is
large amount
reduced to prevent the system from
overheating when there is frequent
WARNING
steering input over an extended period
of time. The steering wheel may feel
QThe ABS does not operate effec-
heavy as a result. Should this occur,
tively when
refrain from excessive steering input or
OThe limits of tire gripping perfor-
stop the vehicle and turn the hybrid sys-
mance have been exceeded (such
tem off. The EPS system should return
as excessively worn tires on a snow
to normal within 10 minutes.
covered road).
Q Operating conditions of emergency
OThe vehicle hydroplanes while driv-
brake signal
ing at high speed on wet or slick
When the following conditions are met,
roads.
the emergency brake signal will oper-
276
4-5. Using the driving support systems
WARNING
O Unlike the parking brake, hill-start
assist control is not intended to hold
QStopping distance when the ABS
the vehicle stationary for an
is operating may exceed that of
extended period of time. Do not
normal conditions
attempt to use hill-start assist con-
The ABS is not designed to shorten
trol to hold the vehicle on an incline,
the vehicle’s stopping distance.
as doing so may lead to an acci-
Always maintain a safe distance from
dent.
the vehicle in front of you, especially
QWhen the TRC/ABS/VSC is acti-
in the following situations:
vated
O When driving on dirt, gravel or
The slip indicator light flashes. Always
snow-covered roads
drive carefully. Reckless driving may
cause an accident. Exercise particular
O When driving with tire chains
care when the indicator light flashes.
O When driving over bumps in the
QWhen the TRC/VSC systems are
road
turned off
O When driving over roads with pot-
Be especially careful and drive at a
holes or uneven surfaces
speed appropriate to the road condi-
tions. As these are the systems to
Q TRC/VSC may not operate effec-
help ensure vehicle stability and driv-
tively when
ing force, do not turn the TRC/VSC
Directional control and power may not
systems off unless necessary.
be achievable while driving on slip-
pery road surfaces, even if the
QReplacing tires
TRC/VSC system is operating. Drive
Make sure that all tires are of the
the vehicle carefully in conditions
specified size, brand, tread pattern
where stability and power may be
and total load capacity. In addition,
lost.
make sure that the tires are inflated to
the recommended tire inflation pres-
Q Active Cornering Assist does not
sure level.
operate effectively when
The ABS, TRC and VSC systems will
ODo not overly rely on Active Corner-
not function correctly if different tires
ing Assist. Active Cornering Assist
are installed on the vehicle.
may not operate effectively when
Contact any authorized Mazda
accelerating down slopes or driving
retailer or Mazda authorized repairer,
on slippery road surfaces.
or any reliable repairer for further
information when replacing tires or
O When Active Cornering Assist fre-
wheels.
quently operates, Active Cornering
Assist may temporarily stop operat-
QHandling of tires and the suspen-
ing to ensure proper operation of
sion
the brakes, TRC and VSC.
Using tires with any kind of problem
or modifying the suspension will affect
QHill-start assist control does not
the driving assist systems, and may
operate effectively when
cause a system to malfunction.
O Do not overly rely on hill-start assist
control. Hill-start assist control may
not operate effectively on steep
inclines and roads covered with ice.
4-5. Using the driving support systems
277
WARNING
QSecondary Collision Brake
Do not rely solely upon the Secondary
Collision Brake. This system is
designed to help reduce the possibil-
ity of further damage due to a second-
ary collision, however, that effect
changes according to various condi-
tions. Overly relying on the system
may result in death or serious injury.
4
278
4-6. Driving tips
(traction battery) power is con-
Hybrid vehicle driving
sumed.
tips
Accelerator pedal/brake
For economical and ecological
driving, pay attention to the fol-
pedal operation
lowing points:
z
Drive your vehicle smoothly.
Avoid abrupt acceleration and
Using Eco drive mode
deceleration. Gradual accelera-
tion and deceleration will make
When using Eco drive mode, the
more effective use of the electric
torque corresponding to the accel-
motor (traction motor) without
erator pedal depression amount
having to use gasoline engine
can be generated more smoothly
power.
than it is in normal conditions. In
z
Avoid repeated acceleration.
addition, the operation of the air
Repeated acceleration con-
conditioning system (heating/cool-
sumes hybrid battery (traction
ing) will be minimized, improving
battery) power, resulting in poor
the fuel economy. (→P.270)
fuel consumption. Battery power
can be restored by driving with
Use of Hybrid System Indi-
the accelerator pedal slightly
cator
released.
The Eco-friendly driving is possible
by keeping the indicate of Hybrid
When braking
System Indicator within Eco area.
Make sure to operate the brakes
(→P.101)
gently and in a timely manner. A
greater amount of electrical energy
Shift lever operation
can be regenerated when slowing
down.
Shift the shift lever to D when
stopped at a traffic light, or driving
in heavy traffic etc. Shift the shift
Delays
lever to P when parking. When
Repeated acceleration and decel-
using the N, there is no positive
eration, as well as long waits at traf-
effect on fuel consumption. In the
fic lights, will lead to bad fuel
N, the gasoline engine operates but
economy. Check traffic reports
electricity cannot be generated.
before leaving and avoid delays as
Also, when using the air condition-
much as possible. When driving in
ing system, etc., the hybrid battery
4-6. Driving tips
279
a traffic jam, gently release the
Checking tire inflation pres-
brake pedal to allow the vehicle to
sure
move forward slightly while avoid-
ing overuse of the accelerator
Make sure to check the tire inflation
pedal. Doing so can help control
pressure frequently. Improper tire
excessive gasoline consumption.
inflation pressure can cause poor
fuel economy.
Also, as snow tires can cause large
Highway driving
amounts of friction, their use on dry
Control and maintain the vehicle at
roads can lead to poor fuel econ-
a constant speed. Before stopping
omy. Use tires that are appropriate
at a toll booth or similar, allow
for the season.
plenty of time to release the accel-
erator and gently apply the brakes.
Luggage
A greater amount of electrical
Carrying heavy luggage will lead to
energy can be regenerated when
4
slowing down.
poor fuel economy. Avoid carrying
unnecessary luggage. Installing a
large roof rack will also cause poor
Air conditioning
fuel economy.
Use the air conditioning only when
necessary. Doing so can help
Warming up before driving
reduce excessive gasoline con-
sumption.
Since the gasoline engine starts up
In summer: When the ambient tem-
and cuts out automatically when
perature is high, use the recircu-
cold, warming up the engine is
lated air mode. Doing so will help to
unnecessary. Moreover, frequently
reduce the burden on the air condi-
driving short distances will cause
tioning system and reduce fuel con-
the engine to repeatedly warm up,
sumption as well.
which can lead to excess fuel con-
In winter: Because the gasoline
sumption.
engine will not automatically cut out
until it and the interior of the vehicle
are warm, it will consume fuel. Also,
fuel consumption can be improved
by avoiding overuse of the heater.
280
4-6. Driving tips
Winter driving tips
O Do not drive at speeds in excess of
the speed limit or the speed limit
specified for the snow tires being
Carry out the necessary prepa-
used.
rations and inspections before
O Use snow tires on all, not just some
driving the vehicle in winter.
wheels.
Always drive the vehicle in a
QDriving with tire chains
manner appropriate to the pre-
Observe the following precautions to
vailing weather conditions.
reduce the risk of accidents.
Failure to do so may result in the vehi-
cle being unable to be driven safely,
Pre-winter preparations
and may cause death or serious
injury.
z Use fluids that are appropriate to
O Do not drive in excess of the speed
the prevailing outside tempera-
limit specified for the tire chains
being used, or 50 km/h (30 mph),
tures.
whichever is lower.
• Engine oil
O Avoid driving on bumpy road sur-
• Engine/power control unit coolant
faces or over potholes.
• Washer fluid
OAvoid sudden acceleration, abrupt
z Have a service technician
steering, sudden braking and shift-
inspect the condition of the 12-
ing operations that cause sudden
engine braking.
volt battery.
OSlow down sufficiently before enter-
z Have the vehicle fitted with four
ing a curve to ensure that vehicle
snow tires or purchase a set of
control is maintained.
tire chains for the front tires.
O Do not use LTA (Lane Tracing
Ensure that all tires are the same size
Assist) system. (if equipped)
and brand, and that chains match the
size of the tires.
NOTICE
WARNING
QRepairing or replacing snow tires
QDriving with snow tires
Request repairs or replacement of
snow tires from any authorized
Observe the following precautions to
Mazda retailer or Mazda authorized
reduce the risk of accidents.
repairer, or any reliable repairer or
Failure to do so may result in a loss of
legitimate tire retailers.
vehicle control and cause death or
This is because the removal and
serious injury.
attachment of snow tires affects the
O Use tires of the size specified.
operation of the tire pressure warning
valves and transmitters.
O Maintain the recommended level of
air pressure.
Before driving the vehicle
Perform the following according to
4-6. Driving tips
281
the driving conditions:
Failure to do so may be danger-
ous because it may cause the
z
Do not try to forcibly open a win-
vehicle to move unexpectedly,
dow or move a wiper that is fro-
possibly leading to an accident.
zen. Pour warm water over the
frozen area to melt the ice. Wipe
z
If the vehicle is parked without
away the water immediately to
setting the parking brake, con-
prevent it from freezing.
firm that the shift lever cannot be
moved out of P*.
z
To ensure proper operation of
the climate control system fan,
*:
The shift lever will be locked if it is
remove any snow that has accu-
attempted to be shifted from P to any
other position without depressing the
mulated on the air inlet vents in
brake pedal. If the shift lever can be
front of the windshield.
shifted from P, there may be a prob-
z
Check for and remove any
lem with the shift lock system. Have
excess ice or snow that may
the vehicle inspected by any autho-
have accumulated on the exte-
rized Mazda retailer or Mazda autho-
4
rior lights, vehicle’s roof, chassis,
rized repairer, or any reliable repairer
or legitimate tire retailers immedi-
around the tires or on the brakes.
ately.
z
Remove any snow or mud from
the bottom of your shoes before
Selecting tire chains
getting in the vehicle.
Use the correct tire chain size when
When driving the vehicle
mounting the tire chains.
Chain size is regulated for each tire
Accelerate the vehicle slowly, keep
size.
a safe distance between you and
the vehicle ahead, and drive at a
reduced speed suitable to road
conditions.
When parking the vehicle
z Park the vehicle and shift the
shift lever to P without setting the
parking brake. The parking brake
Side chain (3 mm [0.12 in.] in
may freeze up, preventing it from
diameter)
being released. If the vehicle is
Cross chain (4 mm [0.16 in.] in
parked without setting the park-
diameter)
ing brake, make sure to block the
wheels.
282
4-6. Driving tips
Regulations on the use of
tire chains
Regulations regarding the use of
tire chains vary depending on loca-
tion and type of road. Always check
local regulations before installing
chains.
Q Tire chain installation
Observe the following precautions when
installing and removing chains:
OInstall and remove tire chains in a safe
location.
OInstall tire chains on the front tires
only. Do not install tire chains on the
rear tires.
OInstall tire chains on the front tires as
tightly as possible. Retighten chains
after driving 0.5⎯1.0 km (1/4⎯1/2
mile).
OInstall tire chains following the instruc-
tions provided with the tire chains.
NOTICE
Q Fitting tire chains
The tire pressure warning valves and
transmitters may not function cor-
rectly when tire chains are fitted.
283
Interior features
5
5-1. Using the air conditioning
system and defogger
Automatic air conditioning sys-
tem
284
Heated steering wheel/seat
heaters
289
5-2. Using the interior lights
Interior lights list
291
5-3. Using the storage features
List of storage features
293
Luggage compartment features
........................................295
5-4. Other interior features
5
Other interior features
299
284
5-1. Using the air conditioning system and defogger
Automatic air conditioning system
Air outlets are automatically selected and fan speed is automati-
cally adjusted according to the set temperature setting.
The illustrations below are for left-hand drive vehicles.
The button positions and shapes will differ for right-hand drive
vehicles.
Also, the display and button positions will differ depending on the
type of the system.
Air conditioning controls
X Vehicles with the DUAL mode
X Vehicles without the DUAL mode
Driver side temperature control dial
Passenger side temperature control dial
DUAL” switch
A/C” switch
Outside air mode switch
Recirculated air mode switch
5-1. Using the air conditioning system and defogger
285
Airflow mode control switch
Fan speed increases switch
Fan speed decreases switch
FAST/ECO” switch
Rear window defogger and outside rear view mirror defoggers switch
Windshield defogger switch
Off switch
Automatic mode switch
O
Fan speed control dial
Q Adjusting the temperature set-
Q Change the airflow mode
ting
Press the airflow mode control
To adjust the temperature setting,
switch.
turn the temperature control dial
The airflow mode changes as follows
clockwise (warm) or counterclock-
each time the switch is pressed.
wise (cool).
5
If “A/C” switch is not pressed, the sys-
tem will blow ambient temperature air
or heated air.
Q Setting the fan speed
X Vehicles with the DUAL mode
Operate the fan
speed increases
switch to increase the fan speed
and the fan speed decreases
switch to decrease the fan speed.
Pressing the off switch to turns off the
fan.
1
Upper body
X Vehicles without the DUAL mode
2
Upper body and feet
To adjust the fan speed, turn the
3
Feet
fan speed control dial clockwise
(increase) or counterclockwise
4
Feet and the windshield defog-
(decrease).
ger operates
Q Switching between outside air
and recirculated air modes
z
To change to recirculated air
286
5-1. Using the air conditioning system and defogger
mode, press the recirculated air
side rear view mirrors.
mode switch.
Press the rear window and outside
The indicator illuminates on the recircu-
rear view mirror defoggers switch.
lated air mode switch.
The defoggers will automatically turn off
z To change to outside air mode,
after a while.
press the outside air mode
When the rear window and outside rear
switch.
view mirror defoggers switch is on, the
The indicator illuminates on the outside
indicator illuminates on the rear window
air mode switch.
and outside rear view mirror defoggers
switch.
Q Set cooling and dehumidifica-
Q Using the Climate Preference
tion function
1 Press the automatic mode
Press the “A/C” switch.
switch.
When the function is on, the indicator
illuminates on the “A/C” switch.
2 Press the “FAST/ECO” switch.
Q Defogging the windshield
Each time the “FAST/ECO” switch
is pressed, the fan speed setting
Defoggers are used to defog the
mode toggles as follows.
windshield and front side windows.
Normal → “ECO” → “FAST” → Nor-
Press the windshield defogger
mal
switch.
When “ECO” is displayed on the air
Set the outside/recirculated air mode
conditioning screen, the air condi-
switch to outside air mode if the recircu-
lated air mode is used. (It may switch
tioning is controlled with low fuel
automatically.)
consumption prioritized such as
To defog the windshield and the side
reducing fan speed, etc.
windows quickly, turn the air flow and
When “FAST” is displayed on the
temperature up.
screen, fan speed will be
To return to the previous mode, press
increased.
the windshield defogger switch again
when the windshield is defogged.
QFogging up of the windows
When the windshield defogger switch is
OThe windows will easily fog up when
on, the indicator illuminates on the
the humidity in the vehicle is high.
windshield defogger switch.
Turning “A/C” on will dehumidify the
air from the outlets and defog the
Q Defogging the rear window
windshield effectively.
and outside rear view mirrors
OIf you turn “A/C” off, the windows may
fog up more easily.
Defoggers are used to defog the
OThe windows may fog up if the recir-
rear window, and to remove rain-
culated air mode is used.
drops, dew and frost from the out-
5-1. Using the air conditioning system and defogger
287
QWhen driving on dusty roads
and outside the vehicle may enter into
and accumulate in the air conditioning
Close all windows. If dust thrown up by
system. This may then cause odor to
the vehicle is still drawn into the vehicle
be emitted from the vents.
after closing the windows, it is recom-
mended that the air intake mode be set
O To reduce potential odors from occur-
to outside air mode and the fan speed to
ring:
any setting except off.
• It is recommended that the air condi-
tioning system be set to outside air
Q Outside/recirculated air mode
mode prior to turning the vehicle off.
OSetting to the recirculated air mode
• The start timing of the blower may be
temporarily is recommended in pre-
delayed for a short period of time
venting dirty air from entering the
immediately after the air conditioning
vehicle interior and helping to cool the
system is started in automatic mode.
vehicle when the outside air tempera-
O When parking, the system automati-
ture is high.
cally switches to outside air mode to
O Outside/recirculated air mode may
encourage better air circulation
automatically switch depending on the
throughout the vehicle, helping to
temperature setting or the inside tem-
reduce odors that occur when starting
perature.
the vehicle.
Q Operation of the air conditioning
QAir conditioning filter
system in Eco drive mode
→P.345
OIn Eco drive mode, the air conditioning
Q Customization
system is controlled as follows to pri-
oritize fuel efficiency:
Some functions can be customized.
5
• Engine speed and compressor opera-
(→P.431)
tion controlled to restrict heating/cool-
ing capacity
WARNING
• Fan speed restricted when automatic
mode is selected
Q To prevent the windshield from
fogging up
O To improve air conditioning perfor-
mance, perform the following opera-
Do not use the windshield defogger
tions:
switch during cool air operation in
• Adjust the fan speed
extremely humid weather. The differ-
• Turn off Eco drive mode (→P.270)
ence between the temperature of the
outside air and that of the windshield
OEven when the drive mode is set to
can cause the outer surface of the
Eco drive mode, the air conditioning
windshield to fog up, blocking your
eco mode can be turned off by press-
vision.
ing the “FAST/ECO” switch. (→P.286)
QWhen the outside temperature falls
QWhen the outside rear view mir-
to nearly 0°C (32°F)
ror defoggers are operating
The dehumidification function may not
Do not touch the outside rear view
operate even when “A/C” switch is
mirror surfaces, as they can become
pressed.
very hot and burn you.
Q Ventilation and air conditioning
odors
NOTICE
O To let fresh air in, set the air condition-
ing system to the outside air mode.
ODuring use, various odors from inside
288
5-1. Using the air conditioning system and defogger
comes on when the “DUAL” mode is
Q To prevent 12-volt battery dis-
charge
on.
Do not leave the air conditioning sys-
Pressing the “DUAL” switch when in
tem on longer than necessary when
DUAL” mode will disable “DUAL
the hybrid system is off.
mode, and the temperature setting for
the front passenger’s side will become
Using automatic mode
linked to the driver’s side.
1 Press the automatic mode
Air outlet layout and opera-
switch.
tions
2 Adjust the temperature setting.
Q Location of air outlets
3 To stop the operation, press the
The air outlets and air volume
off switch.
changes according to the selected
If the fan speed setting or air flow
air flow mode.
modes are operated, the automatic
mode indicator goes off. However,
automatic mode for functions other
than that operated is maintained.
QUsing automatic mode
Fan speed is adjusted automatically
according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while
until warm or cool air is ready to flow
: If equipped
immediately after the automatic mode
Q Adjusting the position of and
switch pressed.
opening and closing the air
outlets
Adjusting the temperature
for the driver and front pas-
senger seat separately (if
equipped)
To turn on the “DUAL” mode, per-
form any of the following proce-
dures:
z Press the “DUAL” switch.
z Adjust the front passenger’s side
Direct air flow to the left or right, up
temperature setting.
or down
The indicator on the “DUAL” switch
5-1. Using the air conditioning system and defogger
289
Center outlets: Move the knob fully to
Heated steering
the left-side to close the vent.
wheel*/seat heaters*
Side outlets: Move the knob fully to the
outside to close the vent.
*: If equipped
WARNING
z Heated steering wheel
Q To prevent the windshield defog-
Warms up the grip of the steering
ger from operating improperly
wheel
Do not place anything on the instru-
z Seat heaters
ment panel which may cover the air
outlets. Otherwise, air flow may be
Warm up the seat upholstery
obstructed, preventing the windshield
defoggers from defogging.
WARNING
Q To prevent minor burn injuries
Care should be taken if anyone in the
following categories comes in contact
with the steering wheel or seats when
the heater is on:
OBabies, small children, the elderly,
the sick and the physically chal-
lenged
5
OPersons with sensitive skin
OPersons who are fatigued
OPersons who have taken alcohol or
drugs that induce sleep (sleeping
drugs, cold remedies, etc.)
NOTICE
Q To prevent damage to the seat
heaters
Do not put heavy objects that have an
uneven surface on the seat and do
not stick sharp objects (needles,
nails, etc.) into the seat.
Q To prevent 12-volt battery dis-
charge
Do not use the functions when the
hybrid system is off.















Content      ..     7      8      9      10     ..
