5-1. Using the air conditioning system and defogger
Operation instructions
WARNING
Q To prevent overheating and
Q Heated steering wheel
minor burn injuries
Turns heated steering wheel on/off
Observe the following precautions
when using the seat heaters.
When the heated steering wheel is on,
the indicator illuminates on the heated
O Do not cover the seat with a blanket
steering wheel switch.
or cushion when using the seat
heater.
O Do not use seat heater more than
necessary.
Q Seat heaters
Turns seat heaters on/off
1 High temperature
2 Low temperature
When the seat heater is on,
the indica-
tor illuminates on the seat heater
switch.
When not in use, put the switch in the
neutral position. The indicator will turn
off.
QThe heated steering wheel and seat
heaters can be used when
The power switch is in ON.
5-2. Using the interior lights
291
Interior lights list
Location of the interior lights
5
Door trim lights (if
equipped)
Front interior/personal lights (→P.291, 292)
Footwell lights (if equipped)
Front console lights
When a door is opened while the door
Operating the interior lights
position is on, the lights turn on.
Turns the door position on/off
292
5-2. Using the interior lights
Operating the personal
NOTICE
lights
Q To prevent 12-volt battery dis-
charge
Do not leave the lights on longer than
necessary when the hybrid system is
off.
Turns the lights on/off
QIlluminated entry system
The lights automatically turn on/off
according to the power switch mode, the
presence of the electronic key (vehicles
with entry function), whether the doors
are locked/unlocked, and whether the
doors are opened/closed.
Q To prevent the 12-volt battery from
being discharged
If the interior lights remain on when the
power switch is turned off, the lights will
go off automatically after 20 minutes.
QThe interior lights may turn on
automatically when
If any of the SRS airbags deploy (inflate)
or in the event of a strong rear impact,
the interior lights will turn on automati-
cally.
The interior lights will turn off automati-
cally after approximately 20 minutes.
The interior lights can be turned off man-
ually. However, in order to help prevent
further collisions, it is recommended that
they be left on until safety can be
ensured.
(The interior lights may not turn on auto-
matically depending on the force of the
impact and conditions of the collision.)
Q Customization
Some functions can be customized.
(→P.431)
5-3. Using the storage features
293
List of storage features
Location of the storage features
5
Bottle holders (→P.294)
Glove box (→P.294)
Cup holders (→P.294)
Console box (→P.295)
WARNING
OLighters or spray cans may
explode. If they come into contact
Q Items that should not be left in
with other stored items, the lighter
the storage spaces
may catch fire or the spray can may
Do not leave glasses, lighters or
release gas, causing a fire hazard.
spray cans in the storage spaces, as
this may cause the following when
cabin temperature becomes high:
O Glasses may be deformed by heat
or cracked if they come into contact
with other stored items.
294
5-3. Using the storage features
Glove box
WARNING
QItems unsuitable for the cup
holder
Do not place anything other than cups
or beverage cans in the cup holders.
Other items may be thrown out of the
holders in the event of an accident or
sudden braking and cause injury. If
possible, cover hot drinks to prevent
burns.
Bottle holders
Pull up the lever to open the glove
box.
X Front
WARNING
QCaution while driving
Keep the glove box closed. In the
event of sudden braking or sudden
swerving, an accident may occur due
to an occupant being struck by the
open glove box or the items stored
inside.
Cup holders
X Rear
QBottle holders
O When storing a bottle, close the cap.
OThe bottle may not be stored depend-
ing on its size or shape.
5-3. Using the storage features
295
WARNING
Luggage compartment
features
Q Items unsuitable for the bottle
holders
Do not place anything other than a
Grocery bag hooks
bottle in the bottle holders.
Other items may be thrown out of the
holders in the event of an accident or
sudden braking and cause injury.
Console box
WARNING
Q To prevent damage to the gro-
cery bag hooks
Do not hang any object heavier than 2
kg (4.4 lb.) on the grocery bag hooks.
5
Lift the lid while pulling up the
knob.
Deck board (if equipped)
QWhen not in use
The console box can be raised to reveal
Q Opening the deck board
a secondary console box.
Open the deck board.
The deck board can be set up as
shown in the illustration.
WARNING
QCaution while driving
Keep the console box closed.
Injuries may result in the event of an
accident or sudden braking.
296
5-3. Using the storage features
Q Removing the deck board
Q Installing the deck board
1 Fold the deck board.
1 Fold the deck board.
2 Slide the deck board to the front
2
Insert the deck board diagonally.
of the vehicle.
3 Slide the deck board to the rear
3 Remove the deck board diago-
of the vehicle.
nally.
5-3. Using the storage features
297
4 Unfold the deck board.
Open the floor cover.
Q Changing the height of the
luggage compartment floor
By changing the position of the
deck board, the height of the lug-
gage compartment floor can be
changed.
5
X Type A
X Type B
Upper position
Lower position
Auxiliary box
Open the deck board.
298
5-3. Using the storage features
Removing the tonneau
cover (if equipped)
1 Unhook the cords.
2 Unhook
and remove the
ton-
neau cover.
Stowing the tonneau cover
(if equipped)
Tonneau cover can be stowed to
the rear seats.
5-4. Other interior features
299
Other interior features
Q To prevent 12-volt battery dis-
charged
Do not use the power outlet longer
Power outlet
than necessary when the hybrid sys-
tem is off.
The power outlet can be used for
12 V accessories that run on less
Wireless charger (if
than 10 A.
equipped)
Open the lid.
A portable device, such as a smart-
phone or mobile battery, can be
charged by just placing it on the
charging area, provided the device
is compatible with the Qi wireless
charging standard created by the
Wireless Power Consortium.
The wireless charger cannot be
used with a portable device that is
QThe power outlet can be used when
larger than the charging area. Addi-
5
The power switch is in ACC or ON.
tionally, depending on the portable
QWhen stopping the hybrid system
device, the wireless charger may
Disconnect electrical devices with
not operate properly. Refer to the
charging functions, such as mobile bat-
operation manual of the portable
tery packs.
device.
If such devices are left connected, the
hybrid system may not stop normally.
Q The “Qi” symbol
The “Qi” symbol is a trademark of
NOTICE
the Wireless Power Consortium.
Q To prevent the fuse from being
blown
Do not use an accessory that uses
more than 12 V 10 A.
Q To avoid damaging the power
outlet
Close the power outlet lid when the
power outlet is not in use.
Foreign objects or liquids that enter
the power outlet may cause a short
circuit.
300
5-4. Other interior features
Q Name for all parts
While charging, the operation indicator
light (orange) will be illuminated.
If charging does not begin, move the
portable device as close to the center of
the charging area as possible.
When charging is complete, the opera-
tion indicator light (green) will illumi-
nate.
Power supply switch
Q Recharging function
Operation indicator light
z If a certain amount of time has
Charge area
elapsed since charging com-
Q Using the wireless charger
pleted and the portable device
1 Press the power supply switch
has not been moved, the wire-
of the wireless charger.
less charger will restart charging.
Pressing the switch again turns the
z If the portable device is moved
wireless charger off.
within the charging area,
When turned on, the operation indicator
charging will stop temporarily
light (green) comes on.
When the power switch is turned off,
then restart.
the on/off state of the wireless charger
will be memorized.
2 Place a portable device on the
charging area with its charging
surface facing down.
5-4. Other interior features
301
Q Operation indicator light status
Operation indicator light
State
Off
The Wireless charger is off
Standby (charging is possible)
Green (illuminated)
Charging is complete*
A portable device has been placed on the
Orange (illuminated)
charging area (identifying the portable device)
Charging in progress
*: Depending on the portable device, the operation indicator light may stay illumi-
nated (orange) after charging has completed.
z If the operation indicator light blinks
If an error is detected, the operation indicator light will blink (orange). Take the
appropriate measures according to the table below.
Operation indicator light
Suspected cause
Measure
Contact any authorized
Blinks (orange) at a one
Vehicle to charger commu-
Mazda retailer or Mazda
5
second interval continu-
nication failure.
authorized repairer, or any
ously
reliable repairer.
A foreign object exists
between the portable
Remove the foreign object.
device and charging area.
Blinks (orange) 3 times
repeatedly
Portable device is not posi-
Move the portable device
tioned properly on the
toward the center of the
charging area.
charging area.
The temperature of the
Stop charging immediately
Blinks (orange) 4 times
wireless charger is exces-
and continue charging
repeatedly
sively high.
after a while.
standard is not guaranteed.
QThe wireless charger can be oper-
OThe wireless charger is designed to
ated when
supply low power electricity (5 W or
The power switch is in ACC or ON.
less) to a cellular phone, smartphone,
or other portable device.
QPortable devices that can be
charged
QIf a cover or accessory is attached
OPortable devices compatible with the
to the portable device
Qi wireless charging standard can be
Do not charge a portable device if a
charged by the wireless charger. How-
cover or accessory which is not Qi com-
ever, compatibility with all devices
patible is attached. Depending on the
which meet the Qi wireless charging
type of cover and/or accessory
302
5-4. Other interior features
attached, it may not be possible to
QCaution regarding interference
charge the portable device. If the porta-
with electronic devices
ble device is placed on the charging
People with implantable cardiac pace-
area and does not charge, remove the
makers, cardiac resynchronization
cover and/or accessories.
therapy pacemakers or implantable
QIf interference is heard in AM radio
cardioverter defibrillators, as well as
broadcasts while charging
any other electrical medical device,
Turn off the wireless charger and check
should consult their physician about
if the noise is reduced. If noise is
the usage of the wireless charger.
reduced, press and hold the power sup-
Operations of the wireless charger
ply switch of the wireless charger for 2
may have an affect on medical
seconds. The frequency of the wireless
devices.
charger is changed and noise may be
Q To prevent damage or burns
reduced. When the frequency is
changed, the operation indicator light
Observe the following precautions.
will blink (orange) 2 times.
Failure to do so may result in the pos-
sibility of fire, equipment failure or
Q Charging precautions
damage, or burns due to heat.
OIf the electronic key cannot be
ODo not put any metallic objects
detected in the cabin, charging cannot
between the charging area and the
be performed. When a door is opened
portable device while charging.
and closed, charging may be tempo-
rarily suspended.
O Do not attach metallic objects, such
OWhile charging, the wireless charger
as aluminum stickers, to the
and the portable device will become
charging area.
warm.
O Do not cover the wireless charger
This is not a malfunction.If a portable
with a cloth or other object while
device becomes warm while charging
charging.
and charging stops due to the protec-
tion function of the portable device,
ODo not attempt to charge portable
wait until the portable device cools
devices which are not compatible
down and charge it again.
with the Qi wireless charging stan-
QSound generated during operation
dard.
When the power supply switch is turned
O Do not disassemble, modify or
on or while a portable device is being
remove the wireless charger.
identified, operation sounds may be
heard. This is not a malfunction.
ODo not apply force or impact to the
wireless charger.
Q Cleaning the wireless charger
→P.311
NOTICE
WARNING
QConditions in which the wireless
QCaution while driving
charger may not operate cor-
rectly
When charging a portable device
while driving, for safety reasons, the
In the following situations, the wire-
driver should not operate the portable
less charger may not operate cor-
device.
rectly:
OWhen a portable device is fully
charged
5-4. Other interior features
303
NOTICE
Q To prevent failure or damage to
data
O When there is a foreign object
O Do not bring magnetic cards, such
between the charging area and por-
as a credit card, or magnetic
table device
recording media, close to the wire-
O When a portable device becomes
less charger while charging. Other-
hot while charging
wise, data may be erased due to
the influence of magnetism.
O When a portable device is placed
Additionally, do not bring precision
on the wireless area with its
instruments such as wrist watches,
charging surface facing up
close to the wireless charger, as
such objects may malfunction.
O When a portable device is not cen-
tered on the charging area
O Do not leave portable devices in the
cabin. The temperature inside the
O When the vehicle is near a TV
cabin may become high when
tower, electric power plant, gas sta-
parked in the sun, and cause dam-
tion, radio station, large display, air-
age to the device.
port or other facility that generates
strong radio waves or electrical
Q To prevent 12-volt battery dis-
noise
charge
Do not use the wireless charger for a
O When the portable device is in con-
long period of time with the hybrid
tact with, or is covered by any of the
system stopped.
following metallic objects:
5
• Cards to which aluminum foil is
attached
Sun visors
• Cigarette boxes that have alumi-
num foil inside
• Metallic wallets or bags
• Coins
• Metal hand warmers
• Media such as CDs and DVDs
O When wireless keys (that emit radio
waves) other than those of your
vehicle are being used nearby.
1 To set the visor in the forward
If in situations other than above the
position, flip it down.
wireless charger does not operate
2 To set the visor in the side posi-
properly or the operation indicator
light is blinking, the wireless charger
tion, flip down, unhook, and
may be malfunctioning. Contact any
swing it to the side.
authorized Mazda retailer or Mazda
authorized repairer, or any reliable
Vanity mirrors (if equipped)
repairer.
Slide the cover to open.
304
5-4. Other interior features
The vanity light turns on. (if equipped)
X Rear (if equipped)
Q To prevent 12-volt battery dis-
WARNING
charge
Q Assist grip
If the vanity lights remain on when the
Do not use the assist grip when get-
power switch is OFF, the lights will go off
ting in or out of the vehicle or rising
automatically after 20 minutes.
from your seat.
NOTICE
NOTICE
Q To prevent the 12-volt battery
from being discharged
Q To prevent damage to the assist
grip
Do not leave the vanity lights on for
extended periods while the hybrid
Do not hang any heavy object or put a
system is off.
heavy load on the assist grip.
Assist grips
Coat hooks
An assist grip installed on the ceil-
The coat hooks are provided with
ing can be used to support your
the rear assist grips.
body while sitting on the seat.
X Type A
X Front
5-4. Other interior features
305
X Type B
close the shade.
WARNING
Q Items that cannot be hung on the
coat hook
Do not hang coat hangers or other
hard or sharp objects on the hook. If
the SRS curtain shield airbags deploy,
these items may become projectiles,
causing death or serious injury.
5
Panoramic roof shade (if
equipped)
The panoramic roof shade can be
opened and closed manually.
Q Opening the panoramic roof
shade
Pushing the tabs will release the
lock, and the shade can be opened.
Q Closing the panoramic roof
shade
Pull the tabs to the lock position to
306
5-4. Other interior features
307
Maintenance and care
6
6-1.
Maintenance and care
Cleaning and protecting the
vehicle exterior
308
Cleaning and protecting the
vehicle interior
311
6-2.
Maintenance
Maintenance requirements 314
Maintenance schedule
316
6-3.
Do-it-yourself maintenance
Do-it-yourself service precau-
tions
319
Hood
321
Positioning a floor jack
322
Engine compartment
324
12-volt battery
329
Tires
331
6
Tire inflation pressure
341
Wheels
343
Air conditioning filter
345
Cleaning the hybrid battery
(traction battery) air intake
vent and filter
347
Wireless remote control/elec-
tronic key battery
350
Checking and replacing fuses
........................................353
Light bulbs
356
308
6-1. Maintenance and care
properly or result in damage to the
Cleaning and protecting
rear spoiler.
the vehicle exterior
Q High pressure car washes
As water may enter the cabin, do not
Perform cleaning in a manner
bring the nozzle tip near the gaps
around the doors or perimeter of the
appropriate to each compo-
windows, or spray these areas continu-
nent and its material.
ously.
Q When using a car wash (vehicles
with a smart entry & start system)
Cleaning instructions
If the door handle becomes wet while
z
Working from top to bottom, lib-
the electronic key is within the effective
range, the door may lock and unlock
erally apply water to the vehicle
repeatedly. In that case, follow the fol-
body, wheel wells and underside
lowing correction procedures to wash
of the vehicle to remove any dirt
the vehicle:
and dust.
OPlace the key in a position 2 m (6 ft.)
or more separate from the vehicle
z
Wash the vehicle body using a
while the vehicle is being washed.
sponge or soft cloth, such as a
(Take care to ensure that the key is
not stolen.)
chamois.
OSet the electronic key to battery-sav-
z
For hard-to-remove marks, use
ing mode to disable the smart entry &
car wash soap and rinse thor-
start system. (→P.135)
oughly with water.
Q Wheels and wheel ornaments (if
equipped)
z
Wipe away any water.
O Remove any dirt immediately by using
z
Wax the vehicle when the water-
a neutral detergent.
proof coating deteriorates.
O Wash detergent off with water immedi-
ately after use.
If water does not bead on a clean sur-
face, apply wax when the vehicle body
O To protect the paint from damage,
make sure to observe the following
is cool.
precautions.
• Do not use acidic, alkaline or abrasive
QAutomatic car washes
detergent
• Do not use hard brushes
OBefore washing the vehicle:
• Do not use detergent on the wheels
• Fold the mirrors.
when they are hot, such as after driv-
Start washing from the front of the vehi-
ing or parking in hot weather
cle. Extend the mirrors before driving.
Q Bumpers
O Brushes used in automatic car
Do not scrub with abrasive cleaners.
washes may scratch the vehicle sur-
face, parts (wheel, etc.) and harm
QPlated portions (if equipped)
your vehicle’s paint.
If dirt cannot be removed, clean the
parts as follows:
OIn certain automatic car washes, the
rear spoiler (if equipped) may interfere
O Use a soft cloth dampened with an
with machine operation. This may pre-
approximately 5% solution of neutral
vent the vehicle from being cleaned
detergent and water to clean the dirt
6-1. Maintenance and care
309
off.
QPrecautions regarding the
OWipe the surface with a dry, soft cloth
exhaust pipe
to remove any remaining moisture.
Exhaust gasses cause the exhaust
O To remove oily deposits, use alcohol
pipe to become quite hot.
wet wipes or a similar product.
When washing the vehicle, be careful
not to touch the pipe until it has
cooled sufficiently, as touching a hot
WARNING
exhaust pipe can cause burns.
Q When washing the vehicle
QPrecaution regarding the rear
Do not apply water to the inside of the
bumper with Blind Spot Monitor
engine compartment. Doing so may
(if equipped)
cause the electrical components, etc.
If the paint of the rear bumper is
to catch fire.
chipped or scratched, the system may
malfunction. If this occurs, consult
Q When cleaning the windshield
with any authorized Mazda retailer or
(vehicles with rain-sensing wind-
Mazda authorized repairer, or any
shield wipers)
reliable repairer.
Set the wiper switch to off. If the wiper
switch is in “AUTO”, the wipers may
operate unexpectedly in the following
NOTICE
situations, and may result in hands
being caught or other serious injuries
Q To prevent paint deterioration
and cause damage to the wiper
and corrosion on the body and
blades.
components (aluminum wheels,
etc.)
O Wash the vehicle immediately in the
following cases:
6
• After driving near the sea coast
• After driving on salted roads
• If coal tar or tree sap is present on
the paint surface
Off
• If dead insects, insect droppings or
bird droppings are present on the
AUTO
paint surface
O When the upper part of the wind-
• After driving in an area contami-
shield where the raindrop sensor is
nated with soot, oily smoke, mine
located is touched by hand
dust, iron powder or chemical sub-
O When a wet rag or similar is held
stances
close to the raindrop sensor
• If the vehicle becomes heavily
O If something bumps against the
soiled with dust or mud
windshield
• If liquids such as benzene and gas-
O If you directly touch the raindrop
oline are spilled on the paint sur-
sensor body or if something bumps
face
into the raindrop sensor
OIf the paint is chipped or scratched,
have it repaired immediately.
310
6-1. Maintenance and care
NOTICE
O Do not bring the nozzle tip close to
boots (rubber or resin manufac-
O To prevent the wheels from corrod-
tured cover), connectors or the fol-
ing, remove any dirt and store in a
lowing parts. The parts may be
place with low humidity when stor-
damaged if they come into contact
ing the wheels.
with high-pressure water.
Q Cleaning the exterior lights
• Traction related parts
O Wash carefully. Do not use organic
• Steering parts
substances or scrub with a hard
brush.
• Suspension parts
This may damage the surfaces of
the lights.
• Brake parts
O Do not apply wax to the surfaces of
OKeep the cleaning nozzle at least
the lights.
30 cm (11.9 in.) away from the vehi-
Wax may cause damage to the
cles body. Otherwise resin section,
lenses.
such as moldings and bumpers,
may be deformed and damaged.
Q To prevent damage to the wind-
Also, do not continuously hold the
shield wiper arms
nozzle in the same place.
When lifting the wiper arms away
ODo not spray the lower part of the
from the windshield, pull the driver
windshield continuously. If water
side wiper arm upward first, and
enters the air conditioning system
repeat for the passenger side. When
intake located near the lower part of
returning the wipers to their original
the windshield, the air conditioning
position, do so from the passenger
system may not operate correctly.
side first.
O Do not wash the underside of the
Q When using an automatic car
vehicle using a high pressure car
wash (vehicles with rain-sensing
washer.
windshield wipers)
Set the wiper switch to the off posi-
tion. If the wiper switch is in “AUTO”,
the wipers may operate and the wiper
blades may be damaged.
Q When using a high pressure car
wash
O Vehicles with rear view monitor sys-
tem: When washing the vehicle, do
not spray the camera or its sur-
rounding area directly with a high
pressure washer. Shock applied
from high pressure water may
cause the device to not operate
normally.
ODo not spray water directly on the
radar which is equipped behind the
emblem. Otherwise it may cause
the device to be damaged.
6-1. Maintenance and care
311
Cleaning and protecting
WARNING
the vehicle interior
Q Water in the vehicle
O Do not splash or spill liquid in the
vehicle, such as on the floor, in the
Perform cleaning in a manner
hybrid battery (traction battery) air
appropriate to each compo-
intake vent, and in the luggage
nent and its material.
compartment. (→P.311)
Doing so may cause the hybrid bat-
tery, electrical components, etc. to
Protecting the vehicle inte-
malfunction or catch fire.
rior
O Do not get any of the SRS compo-
nents or wiring in the vehicle interior
z Remove dirt and dust using a
wet. (→P.36)
An electrical malfunction may
vacuum cleaner. Wipe dirty sur-
cause the airbags to deploy or not
faces with a cloth dampened with
function properly, resulting in death
lukewarm water.
or serious injury.
z If dirt cannot be removed, wipe it
O Vehicles with wireless charger:
Do not let the wireless charger
off with a soft cloth dampened
(→P.299) get wet. Failure to do so
with neutral detergent diluted to
may cause the charger to become
approximately 1%.
hot and cause burns or could cause
electric shock resulting in death or
Wring out any excess water from
serious injury.
the cloth and thoroughly wipe off
QCleaning the interior (especially
remaining traces of detergent
6
instrument panel)
and water.
Do not use a polish wax or polish
cleaner. The instrument panel may
QShampooing the carpets
reflect off the windshield, obstructing
the driver’s view and leading to an
There are several commercial foaming-
accident, resulting in death or serious
type cleaners available. Use a sponge
injury.
or brush to apply the foam. Rub in over-
lapping circles. Do not use water. Wipe
dirty surfaces and let them dry. Excellent
NOTICE
results are obtained by keeping the car-
pet as dry as possible.
QCleaning detergents
QHandling the seat belts
O Do not use the following types of
Clean with mild soap and lukewarm
detergent, as they may discolor the
vehicle interior or cause streaks or
water using a cloth or sponge. Also
damage to painted surfaces:
check the belts periodically for exces-
sive wear, fraying or cuts.
• Non-seat portions: Organic sub-
stances such as benzene or gaso-
line, alkaline or acidic solutions,
dye, and bleach
312
6-1. Maintenance and care
NOTICE
Q Cleaning the inside of the rear
window
• Seats: Alkaline or acidic solutions,
O Do not use glass cleaner to clean
such as thinner, benzene, and alco-
the rear window, as this may cause
hol
damage to the rear window defog-
O Do not use a polish wax or polish
ger heater wires or antenna. Use a
cleaner. The instrument panel’s or
cloth dampened with lukewarm
other interior part’s painted surface
water to gently wipe the window
may be damaged.
clean. Wipe the window in strokes
running parallel to the heater wires
QPreventing damage to leather
or antenna.
surfaces
OBe careful not to scratch or damage
Observe the following precautions to
the heater wires or antenna.
avoid damage to and deterioration of
leather surfaces:
O Remove any dust or dirt from
Cleaning the areas with
leather surfaces immediately.
satin-finish metal accents
O Do not expose the vehicle to direct
sunlight for extended periods of
z Remove dirt using a water-
time. Park the vehicle in the shade,
dampened soft cloth or synthetic
especially during summer.
chamois.
O Do not place items made of vinyl,
plastic, or containing wax on the
z Wipe the surface with a dry, soft
upholstery, as they may stick to the
cloth to remove any remaining
leather surface if the vehicle interior
moisture.
heats up significantly.
Q Water on the floor
QCleaning the areas with satin-finish
Do not wash the vehicle floor with
metal accents
water.
The metal areas use a layer of real
Vehicle systems such as the audio
metal for the surface. It is necessary to
system may be damaged if water
clean them regularly. If dirty areas are
comes into contact with electrical
left uncleaned for long periods of time,
components such as the audio sys-
they may be difficult to clean.
tem above or under the floor of the
vehicle. Water may also cause the
body to rust.
Cleaning the leather areas
Q When cleaning the inside of the
z Remove dirt and dust using a
windshield (vehicles with Safety
Sense)
vacuum cleaner.
Do not allow glass cleaner to contact
z Wipe off any excess dirt and dust
the lens. Also, do not touch the lens.
with a soft cloth dampened with
(→P.198)
diluted detergent.
Use a diluted water solution of approxi-
mately 5% neutral wool detergent.
z Wring out any excess water from
6-1. Maintenance and care
313
the cloth and thoroughly wipe off
all remaining traces of detergent.
z Wipe the surface with a dry, soft
cloth to remove any remaining
moisture. Allow the leather to dry
in a shaded and ventilated area.
Q Caring for leather areas
Mazda recommends cleaning the inte-
rior of the vehicle at least twice a year to
maintain the quality of the vehicle’s inte-
rior.
Cleaning the synthetic
leather areas
z Remove dirt and dust using a
vacuum cleaner.
z Wipe it off with a soft cloth damp-
ened with neutral detergent
diluted to approximately 1%.
z Wring out any excess water from
6
the cloth and thoroughly wipe off
remaining traces of detergent
and water.
314
6-2. Maintenance
Maintenance require-
QHandling of the 12-volt battery
ments
12-volt battery posts, terminals and
related accessories contain lead and
lead compounds which are known to
To ensure safe and economical
cause brain damage. Wash your
hands after handling. (→P.329)
driving, day-to-day care and
regular maintenance are
essential. Mazda recommends
Scheduled maintenance
the maintenance below.
Scheduled maintenance should be
performed at specified intervals
QWhere to go for maintenance ser-
according to the maintenance
vice?
schedule.
In order to maintain your vehicle in the
best possible condition, Mazda recom-
mends that maintenance service opera-
Do-it-yourself maintenance
tions as well as other inspections and
repairs be carried out by authorized
Mazda retailers or Mazda authorized
What about do-it-yourself mainte-
repairers, or any reliable repairers. For
nance?
repairs and services covered by your
warranty, please visit an authorized
Many of the maintenance items are
Mazda retailer or repairer, who will use
easy to do yourself if you have a little
genuine Mazda parts in repairing any
mechanical ability and a few basic
difficulties you may encounter. There
automotive tools.
can also be advantages in utilizing
authorized Mazda retailers or repairers
Note, however, that some maintenance
for non-warranty repairs and services,
tasks require special tools and skills.
as members of the Mazda network will
These are best performed by qualified
be able to expertly assist you with any
technicians. Even if you’re an experi-
difficulties you may encounter.
enced do-it-yourself mechanic, we rec-
Your Mazda retailer or Mazda autho-
ommend that repairs and maintenance
rized repairer, or any reliable repairer
will perform all of the scheduled mainte-
be conducted by any authorized Mazda
nance on your vehicle reliably and eco-
retailer or Mazda authorized repairer, or
nomically due to their experience with
any reliable repairer. Any authorized
Mazda vehicles.
Mazda retailer or repairer will keep a
record of maintenance, which could be
WARNING
useful should you ever require War-
Q If your vehicle is not properly
ranty Service. Should you choose to
maintained
select a qualified and equipped profes-
Improper maintenance could result in
sional other than an authorized Mazda
serious damage to the vehicle and
repairer to service or maintain your
possible death or serious injury.
vehicle, we recommend that you
request that a record of maintenance
be kept.
6-2. Maintenance
315
Q Does your vehicle need repairs?
Be on the alert for changes in perfor-
mance and sounds, and visual tip-offs
that indicate service is needed. Some
important clues are:
OEngine misses (misfire), stumbling or
pinging
O Appreciable loss of power
OStrange engine noises
O A fluid leak under the vehicle (How-
ever, water dripping from the air con-
ditioning system after use is normal.)
O Change in exhaust sound (This may
indicate a dangerous carbon monox-
ide leak. Drive with the windows open
and have the exhaust system checked
immediately.)
OFlat-looking tires, excessive tire
squeal when cornering, uneven tire
wear
O Vehicle pulls to one side when driven
straight on a level road
OStrange noises related to suspension
movement
6
OLoss of brake effectiveness, spongy
feeling brake pedal, pedal almost
touches the floor, vehicle pulls to one
side when braking
OEngine coolant temperature continu-
ally higher than normal (→P.90, 95)
If you notice any of these clues, take
your vehicle to any authorized Mazda
retailer or Mazda authorized repairer, or
any reliable repairer as soon as possi-
ble. Your vehicle may need adjustment
or repair.
316
6-2. Maintenance
Maintenance schedule
1 Full Health and Safety service: every 30,000 km or 2 years*.
2 Intermediate oil and filter service, with Health and Safety checks: every
15,000 km or 1 year*.
3 In case your driving conditions** are more demanding than normal, your
vehicle might require shorter Health and Safety service intervals or a
more extensive servicing than listed below. Review your specific driving
conditions with your authorised Mazda repairer or independent repairer,
who will then recommend an appropriate service schedule and explain
in it detail.
*: whichever comes first
**: severe conditions such as:
- Extensive idling and/or low speed driving (e.g. taxi, door-to-door delivery,
ambulance, police, driving school, ..).
- Repeated short trips of less than 8 km while outside temperatures remain
below freezing (engine will not reach normal temperature).
- Continuous high speed driving (80% or more of max. vehicle speed) for over 2
hours.
- Heavily loaded vehicle (e.g. trailer towing).
- Frequent driving under harsh road conditions (rough roads, muddy roads,
roads with dust, melted snow, road salt).
6-2. Maintenance
317
For normal conditions
R = replacement / I = Inspection
Intermediate
Full
Health
Engine oil & oil filter*1
R
R
Engine and Inverter coolant
I
Air filter
I
I
Drive shaft boots
I
Exhaust pipes and mountings
I
Cooling and heater system
I
Cabin air filter (pollen)
R
Hybrid Battery intake filter
I
R
Fuel tank cap, fuel liners, connections and fuel
I
vapor control valve
Body inspection (for rust, corrosion and perfora-
I
tion)
Safety
Brake pedal & parking brake
I
6
Brake pads & discs
I
I
Brake fluid
R
Brake pipes & hoses
I
Front & rear suspension
I
Steering wheel and linkages
I
Tyres, lights, wiper blades, washer fluid
I
I
Suspension ball joints and dust covers
I
Floor mat
I
I
*1: Vehicle equipped with Oil Maintenance Management System: Replace engine
oil & oil filter (with health and safety checks) when the Oil Maintenance remain-
der message appears (or at least every 15,000 km / 1 year), if applicable in your
country.
318
6-2. Maintenance
Additional Replacements
Air filter
Every 60,000 km / 4 years
Spark plugs
Every 90,000 km
Engine coolant
First at 150,000 km
After, every 90,000 km
Inverter coolant
First at 240,000 km
After, every 90,000 km
Additional Inspections
Automatic transmission fluid and front differential
Every 60,000 km / 4 years
fluid
Rear differential oil
Every 45,000 km / 3 years
Every 45,000 km / 2 years
Charcoal canister
Every 90,000 km*2
*2: for Finland, Norway and Sweden only
6-3. Do-it-yourself maintenance
319
Do-it-yourself service
Items
Parts and tools
precautions
Fuse with same
Fuses
amperage rating as
(→P.354)
original
If you perform maintenance by
yourself, be sure to follow the
Hybrid bat-
correct procedure as given in
tery (traction
Vacuum cleaner, etc.
these sections.
battery) air
Phillips screwdriver
intake vent
(→P.347)
Maintenance
Bulb with same num-
ber and wattage rating
Items
Parts and tools
Light bulbs
as original
(→P.357)
Warm water
Flathead screwdriver
12-volt bat-
Baking soda
Wrench
tery condi-
Grease
Radiator and
tion (→P.
Conventional wrench
condenser
329)
(for terminal clamp
(→P.328)
bolts)
Tire inflation
Tire pressure gauge
Mazda Super Long
pressure
Compressed air
Life Coolant” or a simi-
(→P.342)
source
lar high quality eth-
ylene glycol-based
Water or washer fluid
6
non-silicate, non-
containing antifreeze
amine, non-nitrite and
Washer fluid
(for winter use)
non-borate coolant
(→P.328)
Funnel (used only for
Engine/powe
with long-life hybrid
adding water or
r control unit
organic acid technol-
washer fluid)
coolant level
ogy.
(→P.326)
Mazda Super Long
WARNING
Life Coolant” is pre-
The engine compartment contains
mixed with 50% cool-
many mechanisms and fluids that
ant and 50% deionized
may move suddenly, become hot, or
water.
become electrically energized. To
avoid death or serious injury, observe
Funnel (used only for
the following precautions.
adding coolant)
QWhen working on the engine
Mazda Genuine
compartment
Motor Oil” or equiva-
Engine oil
OMake sure that the “ACCESSORY
lent
or “IGNITION ON” on the multi-
level
Rag or paper towel
information display and the
(→P.324)
Funnel (used only for
READY” indicator are both off.
adding engine oil)
320
6-3. Do-it-yourself maintenance
WARNING
NOTICE
OKeep hands, clothing and tools
QIf you remove the air cleaner fil-
away from the moving fan.
ter
Driving with the air cleaner filter
OBe careful not to touch the engine,
removed may cause excessive
power control unit, radiator, exhaust
engine wear due to dirt in the air.
manifold, etc. right after driving as
they may be hot. Oil and other flu-
QIf the fluid level is low or high
ids may also be hot.
It is normal for the brake fluid level to
O Do not leave anything that may
go down slightly as the brake pads
burn easily, such as paper and
wear or when the fluid level in the
rags, in the engine compartment.
accumulator is high.
If the reservoir needs frequent refill-
O Do not smoke, cause sparks or
ing, it may indicate a serious problem.
expose an open flame to fuel or 12-
volt battery. Fuel and 12-volt battery
fumes are flammable.
OBe extremely cautious when work-
ing on the 12-volt battery. It con-
tains poisonous and corrosive
sulfuric acid.
O Take care because brake fluid can
harm your hands or eyes and dam-
age painted surfaces. If fluid gets
on your hands or in your eyes, flush
the affected area with clean water
immediately.
If you still experience discomfort,
consult a doctor.
Q When working near the electric
cooling fan or radiator grille
Be sure the power switch is OFF.
With the power switch in ON, the
electric cooling fan may automatically
start to run if the air conditioning is on
and/or the coolant temperature is
high. (→P.328)
QSafety glasses
Wear safety glasses to prevent flying
or falling material, fluid spray, etc.
from getting in your eyes.















Content      ..     8      9      10      11     ..
