4-4. Refueling
197
NOTICE
QRefueling
Do not spill fuel during refueling.
Doing so may damage the vehicle,
such as causing the emission control
system to operate abnormally or dam-
aging fuel system components or the
vehicle’s painted surface.
Opening the fuel tank cap
WARNING
1 Pull up the opener to open the
QWhen replacing the fuel tank cap
fuel filler door.
Do not use anything but a genuine
Mazda fuel tank cap designed for
your vehicle. Doing so may cause a
fire or other incident which may result
in death or serious injury.
4
2 Turn the fuel tank cap slowly
and remove it, then hang it on
the back of the fuel filler door.
Closing the fuel tank cap
After refueling, turn the fuel tank
cap until you hear a click. Once the
cap is released, it will turn slightly in
the opposite direction.
198
4-5. Using the driving support systems
Safety Sense*
WARNING
QSafety Sense
*: If equipped
The Safety Sense is designed to
The Safety Sense consists of
operate under the assumption that
the driver will drive safely, and is
the following drive assist sys-
designed to help reduce the impact to
tems and contributes to a safe
the occupants and the vehicle in the
and comfortable driving expe-
case of a collision or assist the driver
in normal driving conditions.
rience:
As there is a limit to the degree of rec-
ognition accuracy and control perfor-
mance that this system can provide,
Driving assist system
do not overly rely on this system. The
driver is always responsible for paying
Q PCS (Pre-Collision System)
attention to the vehicle’s surroundings
and driving safely.
→P.203
Q LTA (Lane Tracing Assist)
Sensors
→P.213
Two types of sensors, located
Q AHB (Automatic High Beam)
behind the front grille and wind-
→P.187
shield, detect information neces-
Q RSA (Road Sign Assist) (if
sary to operate the drive assist
equipped)
systems.
→P.237
Q Dynamic radar cruise control
with full-speed range
→P.223
Radar sensor
Front camera
4-5. Using the driving support systems
199
WARNING
O Do not disassemble the radar sen-
sor.
Q To avoid malfunction of the radar
sensor
ODo not modify or paint the radar
sensor or radar sensor cover.
Observe the following precautions.
Otherwise, the radar sensor may not
OIn the following cases, the radar
operate properly, possibly leading to
sensor must be recalibrated. Con-
an accident resulting in death or seri-
tact any authorized Mazda retailer
ous injury.
or Mazda authorized repairer, or
any reliable repairer for details.
OKeep the radar sensor and the
radar sensor cover clean at all
• When the radar sensor or front
times.
grille are removed and installed, or
replaced
• When the front bumper is replaced
Q To avoid malfunction of the front
camera
Observe the following precautions.
Otherwise, the front camera may not
4
operate properly, possibly leading to
an accident resulting in death or seri-
Radar sensor
ous injury.
Radar sensor cover
O Keep the windshield clean at all
times.
If the front of the radar sensor or the
front or back of the radar sensor
If the windshield is dirty or covered
with an oily film, water droplets,
cover is dirty or covered with water
snow, etc., clean the windshield.
droplets, snow, etc., clean it.
If a glass coating agent is applied to
Clean the radar sensor and radar
the windshield, it will still be neces-
sensor cover with a soft cloth to avoid
sary to use the windshield wipers to
damaging them.
remove water droplets, etc., from
the area of the windshield in front of
O Do not attach accessories, stickers
the front camera.
(including transparent stickers) or
other items to the radar sensor,
If the inner side of the windshield
radar sensor cover or surrounding
where the front camera is installed
area.
is dirty, contact any authorized
Mazda retailer or Mazda authorized
O Do not subject the radar sensor or
repairer, or any reliable repairer.
its surrounding area to a strong
impact.
If the radar sensor, front grille, or
front bumper has been subjected to
a strong impact, have the vehicle
inspected by any authorized Mazda
retailer or Mazda authorized
repairer, or any reliable repairer.
200
4-5. Using the driving support systems
WARNING
O Do not allow liquids to contact the
front camera.
O Do not attach objects, such as
stickers, transparent stickers, etc.,
O Do not allow bright lights to shine
to the outer side of the windshield in
into the front camera.
front of the front camera (shaded
ODo not dirty or damage the front
area in the illustration).
camera.
When cleaning the inside of the
windshield, do not allow glass
cleaner to contact the lens of the
front camera. Also, do not touch the
lens.
If the lens is dirty or damaged, con-
tact any authorized Mazda retailer
or Mazda authorized repairer, or
any reliable repairer.
From the top of the windshield to
O Do not subject the front camera to a
approximately 1 cm (0.4 in.) below
strong impact.
the bottom of the front camera
O Do not change the installation posi-
tion or direction of the front camera
Approximately 20 cm (7.9 in.)
or remove it.
(Approximately 10 cm [4.0 in.] to
O Do not disassemble the front cam-
the right and left from the center of
era.
the front camera)
O Do not modify any components of
O If the part of the windshield in front
the vehicle around the front camera
of the front camera is fogged up or
(inside rear view mirror, etc.) or ceil-
covered with condensation, or ice,
ing.
use the windshield defogger to
remove the fog, condensation, or
O Do not attach any accessories to
ice. (→P.286)
the hood, front grille or front bumper
that may obstruct the front camera.
O If water droplets cannot be properly
Contact any authorized Mazda
removed from the area of the wind-
retailer or Mazda authorized
shield in front of the front camera by
repairer, or any reliable repairer for
the windshield wipers, replace the
details.
wiper insert or wiper blade.
OIf a surfboard or other long object is
O Do not attach window tint to the
to be mounted on the roof, make
windshield.
sure that it will not obstruct the front
camera.
O Replace the windshield if it is dam-
aged or cracked.
O Do not modify the headlights or
After replacing the windshield, the
other lights.
front camera must be recalibrated.
Contact any authorized Mazda
retailer or Mazda authorized
repairer, or any reliable repairer for
details.
4-5. Using the driving support systems
201
QCertifications for the Safety Sense
→P.542
QIf a warning message is displayed on the multi-information display
A system may be temporarily unavailable or there may be a malfunction in the sys-
tem.
OIn the following situations, perform the actions specified in the table. When the nor-
mal operating conditions are detected, the message will disappear and the system
will become operational.
If the message does not disappear, contact any authorized Mazda retailer or Mazda
authorized repairer, or any reliable repairer.
Situation
Actions
When the area around a camera is cov-
Using the wiper and A/C function,
ered with dirt, moisture (fogged up, cov-
remove the dirt and other attached mat-
ered with condensation, ice, etc.), or
ter. (→P.286).
other foreign matter
4
If the front camera is hot, such as after
the vehicle had been parked in the sun,
use the air conditioning system to
decrease the temperature around the
front camera.
If a sunshade was used when the vehicle
When the temperature around the front
was parked, depending on its type, the
camera is outside of the operational
sunlight reflected from the surface of the
range, such as when the vehicle is in the
sunshade may cause the temperature of
sun or in an extremely cold environment
the front camera to become excessively
high.
If the front camera is cold, such after the
vehicle is parked in an extremely cold
environment, use the air conditioning
system to increase the temperature
around the front camera.
The area in front of the front camera is
obstructed, such as when the hood is
Close the hood, remove the sticker, etc.,
open or a sticker is attached to the part of
to clear the obstruction.
the windshield in front of the front cam-
era.
When “Pre-Collision System Radar In
Check whether there is attached materi-
Self Calibration Unavailable See
als on the radar and radar cover, and if
Owner’s Manual” is displayed.
there is, remove it.
202
4-5. Using the driving support systems
OIn the following situations, if the situation has changed (or the vehicle has been
driven for some time) and the normal operating conditions are detected, the mes-
sage will disappear and the system will become operational.
If the message does not disappear, contact any authorized Mazda retailer or Mazda
authorized repairer, or any reliable repairer.
• When the temperature around the radar sensor is outside of the operational range,
such as when the vehicle is in the sun or in an extremely cold environment
• When the front camera cannot detect objects in front of the vehicle, such as when
driving in the dark, snow, or fog, or when bright lights are shining into the front
camera
• Depending on the conditions in the vicinity of the vehicle, the radar may judge the
surrounding environment can not be properly recognized. In that case, “Pre-Colli-
sion System Unavailable See Owner’s Manual” is displayed.
4-5. Using the driving support systems
203
PCS (Pre-Collision Sys-
System functions
tem)*
Q Pre-collision warning
*: If equipped
When the system determines that
the possibility of a frontal collision is
The pre-collision system uses
high, a buzzer will sound and a
a radar sensor and front cam-
warning message will be displayed
era to detect objects (P.203)
on the multi-information display to
in front of the vehicle. When
urge the driver to take evasive
the system determines that the
action.
possibility of a frontal collision
with an object is high, a warn-
ing operates to urge the driver
to take evasive action and the
potential brake pressure is
increased to help the driver
4
avoid the collision. If the sys-
tem determines that the possi-
bility of a frontal collision with
an object is extremely high, the
Q Pre-collision brake assist
brakes are automatically
When the system
determines that
applied to help avoid the colli-
sion or help reduce the impact
the possibility of a frontal collision is
high, the system applies greater
of the collision.
braking force in relation to how
The pre-collision system can
strongly the brake pedal is
be disabled/enabled and the
depressed.
warning timing can be
changed. (P.206)
Q Pre-collision braking
If the system determines that the
possibility of a frontal collision is
Detectable objects
extremely high, the brakes are
The system can detect the follow-
automatically applied to help avoid
ing (The detectable objects differs
the collision or reduce the impact of
depending on the function.):
the collision.
z Vehicles
Q Emergency steering assist
z Bicyclists
If the system determines that the
z Pedestrians
possibility of a collision with a
pedestrian is high and the driver
has begun evasive maneuver or
204
4-5. Using the driving support systems
steering, emergency steering assist
will assist the steering movements
to help enhance the vehicle stability
and for lane departure prevention.
Q Intersection right/left turn
assistance
If the system determines that there
is a high possibility of a collision in
the following situations, it will assist
WARNING
with a Pre-collision warning and, if
QLimitations of the pre-collision
necessary Pre-collision braking.
system
Depending on the configuration of
OThe driver is solely responsible for
safe driving. Always drive safely,
the intersection, it may not be pos-
taking care to observe your sur-
sible to support.
roundings.
Do not use the pre-collision system
z
When you turn right/left at an
instead of normal braking opera-
intersection and cross the path of
tions under any circumstances.
an oncoming vehicle
This system will not prevent colli-
sions or lessen collision damage or
injury in every situation. Do not
overly rely on this system. Failure to
do so may lead to an accident,
resulting in death or serious injury.
OAlthough this system is designed to
help avoid a collision or help reduce
the impact of the collision, its effec-
tiveness may change according to
various conditions, therefore the
system may not always be able to
achieve the same level of perfor-
z
When you turn right/left, pedes-
mance.
trian is detected in the forward
Read the following conditions care-
direction and estimated to enter
fully. Do not overly rely on this sys-
tem and always drive carefully.
your vehicle’s path (bicyclists are
not detected.)
• Conditions under which the system
may operate even if there is no pos-
sibility of a collision: →P.209
• Conditions under which the system
may not operate properly: →P.211
4-5. Using the driving support systems
205
WARNING
QEmergency steering assist
OAs emergency steering assist oper-
O Do not attempt to test the operation
ation will be canceled when the sys-
of the pre-collision system yourself.
tem determines that lane departure
Depending on the objects used for
prevention function has been com-
testing (dummies, cardboard
pleted.
objects imitating detectable objects,
etc.), the system may not operate
OEmergency steering assist may not
properly, possibly leading to an
operate or may be cancel in the fol-
accident.
lowing cases as the system may
determine the driver is taking
QPre-collision braking
actions.
O When the pre-collision braking
function is operating, a large
If the accelerator pedal is being
amount of braking force will be
depressed strongly, the steering
applied.
wheel is being operated sharply,
the brake pedal is being depressed
O If the vehicle is stopped by the
or the driver is giving turn signal. In
operation of the pre-collision brak-
this case the system may deter-
ing function, the pre-collision brak-
mine that the driver is taking eva-
ing function operation will be
sive action and the emergency
4
canceled after approximately 2 sec-
steering assist may not operate.
onds. Depress the brake pedal as
necessary.
In some situations, while the emer-
gency steering assist is operating,
O The pre-collision braking function
operation of the function may be
may not operate if certain opera-
canceled if the accelerator pedal is
tions are performed by the driver. If
depressed strongly, the steering
the accelerator pedal is being
wheel is operated sharply or the
depressed strongly or the steering
brake pedal is being depressed and
wheel is being turned, the system
the system determines that the
may determine that the driver is tak-
driver is taking evasive action.
ing evasive action and possibly pre-
vent the pre-collision braking
When the emergency steering
function from operating.
assist is operating, if the steering
wheel is held firmly or is operated in
O In some situations, while the pre-
the opposite direction to that which
collision braking function is operat-
the system is generating torque, the
ing, operation of the function may
function may be canceled.
be canceled if the accelerator pedal
is depressed strongly or the steer-
QWhen to disable the pre-colli-
ing wheel is turned and the system
sion system
determines that the driver is taking
In the following situations, disable the
evasive action.
system, as it may not operate prop-
erly, possibly leading to an accident
O If the brake pedal is being
resulting in death or serious injury:
depressed, the system may deter-
mine that the driver is taking eva-
OWhen the vehicle is being towed
sive action and possibly delay the
operation timing of the pre-collision
OWhen your vehicle is towing
braking function.
another vehicle
206
4-5. Using the driving support systems
WARNING
enabled/disabled on
(→P.431)
of the multi-information display.
O When transporting the vehicle via
truck, boat, train or similar means of
The system is automatically enabled
transportation
each time the power switch is turned to
O When the vehicle is raised on a lift
ON.
with the hybrid system on and the
If the system is disabled, the PCS
tires are allowed to rotate freely
warning light will turn on and a
O When inspecting the vehicle using
message will be displayed on the
a drum tester such as a chassis
dynamometer or speedometer tes-
multi-information display.
ter, or when using an on vehicle
wheel balancer
O When a strong impact is applied to
the front bumper or front grille, due
to an accident or other reasons
O If the vehicle cannot be driven in a
stable manner, such as when the
vehicle has been in an accident or
is malfunctioning
O When the vehicle is driven in a
sporty manner or off-road
Q Changing the pre-collision
warning timing
O When the tires are not properly
inflated
The pre-collision warning timing
O When the tires are very worn
can be changed on
(→P.431) of
the multi-information display.
O When tires of a size other than
specified are installed
The warning timing setting is retained
O When tire chains are installed
when the power switch is turned off.
However, if the pre-collision system is
OWhen a compact spare tire or an
disabled and re-enabled, the operation
emergency tire puncture repair kit is
used
timing will return to the default setting
(middle).
O If equipment (snow plow, etc.) that
may obstruct the radar sensor or
front camera is temporarily installed
to the vehicle
Changing settings of the
pre-collision system
Q Enabling/disabling the pre-col-
lision system
The pre-collision system can be
4-5. Using the driving support systems
207
2 Middle
This is the default setting.
3 Late
Q Changing the pedestrian alert
timing
If the pre-collision warning timing is
changed, emergency steering
assist timing will also be changed
accordingly.
If late is selected, emergency steer-
ing assist would not operate in case
of an emergency.
1 Early
Q Operation conditions for each pre-collision function
4
The pre-collision system is enabled and the system determines that the possibility of
a frontal collision with a detected object is high.
The system may not operate in the following situations:
• If a 12-volt battery terminal has been disconnected and reconnected and then the
vehicle has not been driven for a certain amount of time
• If the shift lever is in R
• When the VSC OFF indicator is illuminated (only the pre-collision warning function
will be operational)
The operation speeds and operation cancellation for each function is listed below.
O Pre-collision warning
Relative speed between
Detectable objects
Vehicle speed
your vehicle and object
Approx. 10 to 180 km/h (7
Approx. 10 to 180 km/h (7
Vehicles
to 110 mph)
to 110 mph)
Approx. 10 to 80 km/h (7 to
Approx. 10 to 80 km/h (7 to
Bicyclists and pedestrians
50 mph)
50 mph)
OPre-collision brake assist
Relative speed between
Detectable objects
Vehicle speed
your vehicle and object
Approx. 30 to 180 km/h
Approx. 30 to 180 km/h (20
Vehicles
(20 to 110 mph)
to 110 mph)
Approx. 30 to 80 km/h (20
Approx. 30 to 80 km/h (20
Bicyclists and pedestrians
to 50 mph)
to 50 mph)
208
4-5. Using the driving support systems
OPre-collision braking
Relative speed between
Detectable objects
Vehicle speed
your vehicle and object
Approx. 10 to 180 km/h (7
Approx. 10 to 180 km/h (7
Vehicles
to 110 mph)
to 110 mph)
Approx. 10 to 80 km/h (7 to
Approx. 10 to 80 km/h (7 to
Bicyclists and pedestrians
50 mph)
50 mph)
If either of the following occur while the pre-collision braking function is operating, it
will be canceled:
• The accelerator pedal is depressed strongly.
• The steering wheel is turned sharply or abruptly.
OEmergency steering assist
When the turn signals are flashing, emergency steering assist will not operate in
case of an emergency.
Relative speed between
Detectable objects
Vehicle speed
your vehicle and object
Approx. 40 to 80 km/h (25
Approx. 40 to 80 km/h (25
Pedestrians
to 50 mph)
to 50 mph)
If either of the following occur while the emergency steering assist function is operat-
ing, it will be canceled:
• The accelerator pedal is depressed strongly.
• The steering wheel is turned sharply or abruptly.
• The brake pedal is depressed.
OIntersection right/left turn assistance (pre-collision warning)
When the turn signal is not operating, support for turning left or right at an intersec-
tion which targets oncoming vehicles does not work.
Relative speed
Detectable
Oncoming vehicle
Vehicle speed
between your vehicle
objects
speed
and object
Approx. 10 to 25 km/h
Approx. 30 to 55 km/h
Approx. 40 to 80 km/h
Vehicles
(7 to 15 mph)
(20 to 35 mph)
(25 to 50 mph)
Approx. 10 to 25 km/h
Approx. 10 to 25 km/h
Pedestrians
-
(7 to 15 mph)
(7 to 15 mph)
4-5. Using the driving support systems
209
OIntersection right/left turn assistance (pre-collision braking)
When the turn signal is not operating, support for turning left or right at an intersec-
tion which targets oncoming vehicles does not work.
Relative speed
Detectable
Oncoming vehicle
Vehicle speed
between your vehicle
objects
speed
and object
Approx. 15 to 25 km/h
Approx. 30 to 45 km/h
Approx. 45 to 70 km/h
Vehicles
(10 to 15 mph)
(20 to 28 mph)
(28 to 43 mph)
Approx. 10 to 25 km/h
Approx. 10 to 25 km/h
Pedestrians
-
(7 to 15 mph)
(7 to 15 mph)
Q Object detection function
The system detects objects based on
their size, profile, motion, etc. However,
an object may not be detected depend-
ing on the surrounding brightness and
the motion, posture, and angle of the
4
detected object, preventing the system
from operating properly. (→P.211)
The illustration shows an image of
detectable objects.
• When rapidly closing on a detectable
object, etc.
• When approaching objects on the
roadside, such as detectable objects,
guardrails, utility poles, trees, or walls
• When there is a detectable object or
other object by the roadside at the
entrance of a curve
QConditions under which the system
may operate even if there is no pos-
sibility of a collision
OIn some situations such as the follow-
ing, the system may determine that
there is a possibility of a frontal colli-
sion and operate.
• When there are patterns or paint in
• When passing a detectable object,
front of your vehicle that may be mis-
etc.
taken for a detectable object
• When changing lanes while overtak-
• When the front of your vehicle is hit by
ing a detectable object, etc.
water, snow, dust, etc.
• When approaching a detectable
• When overtaking a detectable object
object in an adjacent lane or on the
that is changing lanes or making a
roadside, such as when changing the
right/left turn
course of travel or driving on a wind-
ing road
210
4-5. Using the driving support systems
ner
When passing a detectable object in
an oncoming lane that is stopped to
When driving through steam or smoke
make a right/left turn
When driving near an object that
reflects radio waves, such as a large
truck or guardrail
When driving near a TV tower, broad-
casting station, electric power plant,
radar equipped vehicles, etc., or other
location where strong radio waves or
electrical noise may be present
When there are many things which
can reflect the radio waves of the
When a detectable object approaches
radar in the vicinity (tunnels, truss
very close and then stops before
bridges, gravel roads, snow covered
entering the path of your vehicle
road that have tracks, etc.)
If the front of your vehicle is raised or
While making a right/left turn, when an
lowered, such as when on an uneven
oncoming vehicle or a crossing
or undulating road surface
pedestrian has already exited the path
When driving on a road surrounded by
of your vehicle
a structure, such as in a tunnel or on
While making a right/left turn, closely
an iron bridge
in front of an oncoming vehicle or a
When there is a metal object (man-
crossing pedestrian
hole cover, steel plate, etc.), steps, or
While making a right/left turn, when an
a protrusion in front of your vehicle
oncoming vehicle or a crossing
When passing under an object (road
pedestrian stops before entering the
sign, billboard, etc.)
path of your vehicle
While making a right/left turn, when an
oncoming vehicle turns right/left in
front of your vehicle
• When approaching an electric toll gate
barrier, parking area barrier, or other
barrier that opens and closes
• When using an automatic car wash
• While steering into the direction of
• When driving through or under objects
oncoming traffic
that may contact your vehicle, such as
thick grass, tree branches, or a ban-
4-5. Using the driving support systems
211
QSituations in which the system may
• If a detectable object cuts or suddenly
not operate properly
emerges in front of your vehicle
• When the front of your vehicle is hit by
OIn some situations such as the follow-
water, snow, dust, etc.
ing, an object may not be detected by
• When a very bright light ahead, such
the radar sensor and front camera,
as the sun or the headlights of oncom-
preventing the system from operating
ing traffic, shines directly into the front
properly:
camera
• When a detectable object is
• When approaching the side or front of
approaching your vehicle
a vehicle ahead
• When your vehicle or a detectable
• If a vehicle ahead is a motorcycle
object is wobbling
• If a vehicle ahead is narrow, such as a
• If a detectable object makes an abrupt
personal mobility vehicle
maneuver (such as sudden swerving,
• If a preceding vehicle has a small rear
acceleration or deceleration)
end, such as an unloaded truck
• When your vehicle approaches a
• If a preceding vehicle has a low rear
detectable object rapidly
end, such as a low bed trailer
• When a detectable object is not
directly in front of your vehicle
4
If a vehicle ahead has extremely high
ground clearance
When a detectable object is near a
wall, fence, guardrail, manhole cover,
vehicle, steel plate on the road, etc.
When a detectable object is under a
structure
When part of a detectable object is
hidden by an object, such as large
baggage, an umbrella, or guardrail
When there are many things which
can reflect the radio waves of the
radar in the vicinity (tunnels, truss
If a vehicle ahead is carrying a load
bridges, gravel roads, snow covered
which protrudes past its rear bumper
road that have tracks, etc.)
If a vehicle ahead is irregularly
When there is an effect on the radio
shaped, such as a tractor or side car
waves to the radar that is installed on
If a vehicle ahead is a child sized bicy-
another vehicle
cle, a bicycle that is carrying a large
When multiple detectable objects are
load, a bicycle ridden by more than
close together
one person, or a uniquely shaped
If the sun or other light is shining
bicycle (bicycle with a child seat, tan-
directly on a detectable object
dem bicycle, etc.)
When a detectable object is a shade
If a pedestrian/or the riding height of a
of white and looks extremely bright
bicyclist ahead is shorter than approx-
When a detectable object appears to
imately 1 m (3.2 ft.) or taller than
be nearly the same color or brightness
approximately 2 m (6.5 ft.)
as its surroundings
212
4-5. Using the driving support systems
If a pedestrian/bicyclist is wearing
rated by more than 2 lanes where
oversized clothing (a rain coat, long
oncoming vehicles are driving while
skirt, etc.), making their silhouette
making a right/left turn
obscure
When largely out of place with the
If a pedestrian is bending forward or
opposite facing targeted oncoming
squatting or bicyclist is bending for-
vehicle during a right/left turn
ward
If a pedestrian/bicyclist is moving fast
If a pedestrian is pushing a stroller,
wheelchair, bicycle or other vehicle
When driving in inclement weather
such as heavy rain, fog, snow or a
sandstorm
When driving through steam or smoke
When the surrounding area is dim,
such as at dawn or dusk, or while at
While making a right/left turn, when a
night or in a tunnel, making a detect-
pedestrian approaches from behind or
able object appear to be nearly the
side of your vehicle
same color as its surroundings
When driving in a place where the sur-
rounding brightness changes sud-
denly, such as at the entrance or exit
of a tunnel
After the hybrid system has started
the vehicle has not been driven for a
certain amount of time
While making a left/right turn and for a
few seconds after making a left/right
turn
OIn addition to the above, in some situ-
While driving on a curve and for a few
ations, such as the following, the
seconds after driving on a curve
emergency steering assist may not
If your vehicle is skidding
operate.
If the front of the vehicle is raised or
• When the white (yellow) lane lines are
lowered
difficult to see, such as when they are
faint, diverging/merging, or a shadow
is cast upon them
• When the lane is wider or narrower
than normal
• When there is a light and dark pattern
on the road surface, such as due to
road repairs
• When a pedestrian is detected near
the centerline of the vehicle
• When there is insufficient safe or
If the wheels are misaligned
unobstructed space for the vehicle to
If a wiper blade is blocking the front
be steered into
camera
• If oncoming vehicle is present
The vehicle is being driven at
• If VSC function is operating
extremely high speeds
When driving on a hill
OIn some situations such as the follow-
If the radar sensor or front camera is
ing, sufficient braking force or steering
misaligned
force may not be obtained, preventing
When driving in a traffic lane sepa-
the system from performing properly:
4-5. Using the driving support systems
213
• If the braking functions cannot operate
LTA (Lane Tracing
to their full extent, such as when the
brake parts are extremely cold,
Assist)*
extremely hot, or wet
• If the vehicle is not properly main-
*: If equipped
tained (brakes or tires are excessively
worn, improper tire inflation pressure,
When driving on highways and
etc.)
freeways with white (yellow)
• When the vehicle is being driven on a
lane lines, this function alerts
gravel road or other slippery surface
• When the road surface has deep
the driver when the vehicle
wheel tracks
might depart from its lane or
• When driving on a hill road
course* and provides assis-
• When driving on a road that has
inclines to the left or right
tance by operating the steering
QIf VSC is disabled
wheel to keep the vehicle in its
OIf VSC is disabled (→P.274), the pre-
lane or course*. Furthermore,
collision brake assist and pre-collision
the system provides steering
braking functions are also disabled.
assistance when dynamic
OThe PCS warning light will turn on and
4
radar cruise control with full-
VSC Turned OFF Pre-Collision Brake
System Unavailable” will be displayed
speed range is operating to
on the multi-information display.
keep the vehicle in its lane.
The LTA system recognizes
white (yellow) lane lines or a
course* using the front cam-
era. Additionally, it detects pre-
ceding vehicles using the front
camera and radar.
*: Boundary between asphalt and the
side of the road, such as grass,
soil, or a curb
214
4-5. Using the driving support systems
WARNING
OWhen the tires have been exces-
sively worn, or when the tire infla-
Q Before using LTA system
tion pressure is low.
O Do not rely solely upon the LTA sys-
OWhen tires of a size other than
tem. The LTA system does not
specified are installed.
automatically drive the vehicle or
reduce the amount of attention that
O Vehicle is driven in traffic lanes
must be paid to the area in front of
other than that highways and free-
the vehicle. The driver must always
ways.
assume full responsibility for driving
safely by paying careful attention to
OWhen your vehicle is towing a
the surrounding conditions and
trailer or during emergency towing
operating the steering wheel to cor-
QPreventing LTA system malfunc-
rect the path of the vehicle. Also,
tions and operations performed
the driver must take adequate
by mistake
breaks when fatigued, such as from
driving for a long period of time.
O Do not modify the headlights or
place stickers, etc., on the surface
O Failure to perform appropriate driv-
of the lights.
ing operations and pay careful
attention may lead to an accident,
O Do not modify the suspension, etc.
resulting in death or serious injury.
If the suspension, etc., needs to be
replaced, contact any authorized
O When not using the LTA system,
Mazda retailer or Mazda authorized
use the LTA switch to turn the sys-
repairer, or any reliable repairer.
tem off.
O Do not install or place anything on
QSituations unsuitable for LTA
the hood or grille. Also, do not
system
install a grille guard (bull bars, kan-
In the following situations, use the
garoo bar, etc.).
LTA switch to turn the system off. Fail-
OIf your windshield needs repairs,
ure to do so may lead to an accident,
contact any authorized Mazda
resulting in death or serious injury.
retailer or Mazda authorized
O Vehicle is driven on a road surface
repairer, or any reliable repairer.
which is slippery due to rainy
QConditions in which functions
weather, fallen snow, freezing, etc.
may not operate properly
O Vehicle is driven on a snow-cov-
In the following situations, the func-
ered road.
tions may not operate properly and
the vehicle may depart from its lane.
O White (yellow) lines are difficult to
Drive safely by always paying careful
see due to rain, snow, fog, dust,
attention to your surroundings and
etc.
operate the steering wheel to correct
O Vehicle is driven in a temporary
the path of the vehicle without relying
lane or restricted lane due to con-
solely on the functions.
struction work.
O Vehicle is driven in a construction
zone.
O A spare tire, tire chains, etc., are
equipped.
4-5. Using the driving support systems
215
WARNING
OObjects or patterns that could be
mistaken for white (yellow) lines are
O When the follow-up cruising dis-
present on the side of the road
play is displayed (→P.219) and the
(guardrails, reflective poles, etc.).
preceding vehicle changes lanes.
(Your vehicle may follow the pre-
ceding vehicle and also change
lanes.)
O Vehicle is driven where the road
diverges, merges, etc.
O When the follow-up cruising dis-
play is displayed (→P.219) and the
preceding vehicle is swaying. (Your
4
vehicle may sway accordingly and
depart from the lane.)
O When the follow-up cruising dis-
play is displayed (→P.219) and the
preceding vehicle departs from its
lane. (Your vehicle may follow the
preceding vehicle and depart from
the lane.)
O When the follow-up cruising dis-
play is displayed (→P.219) and the
preceding vehicle is being driven
extremely close to the left/right lane
O Repair marks of asphalt, white (yel-
line. (Your vehicle may follow the
low) lines, etc., are present due to
preceding vehicle and depart from
road repair.
the lane.)
O Vehicle is being driven around a
sharp curve.
OThere are shadows on the road that
run parallel with, or cover, the white
(yellow) lines.
216
4-5. Using the driving support systems
WARNING
OThe vehicle is extremely tilted due
to carrying heavy luggage or having
O The vehicle is driven in an area
improper tire pressure.
without white (yellow) lines, such as
in front of a tollgate or checkpoint,
OThe distance to the preceding vehi-
or at an intersection, etc.
cle is extremely short.
O The white (yellow) lines are
OThe vehicle is moving up and down
cracked, “Raised pavement
a large amount due to road condi-
marker” or stones are present.
tions during driving (poor roads or
road seams).
O The white (yellow) lines cannot be
seen or are difficult to see due to
OWhen driving in a tunnel or at night
sand, etc.
with the headlights off or when a
headlight is dim due to its lens
O The vehicle is driven on a road sur-
being dirty or it being misaligned.
face that is wet due to rain, pud-
dles, etc.
OThe vehicle is struck by a cross-
wind.
O The traffic lines are yellow (which
may be more difficult to recognize
OThe vehicle is affected by wind from
than lines that are white).
a vehicle driven in a nearby lane.
O The white (yellow) lines cross over
OThe vehicle has just changed lanes
a curb, etc.
or crossed an intersection.
O The vehicle is driven on a bright
O Tires which differ by structure, man-
surface, such as concrete.
ufacturer, brand or tread pattern are
used.
O If the edge of the road is not clear
or straight.
OSnow tires, etc., are equipped.
O The vehicle is driven on a surface
OThe vehicle is being driven at
that is bright due to reflected light,
extremely high speeds.
etc.
O The vehicle is driven in an area
Functions included in LTA
where the brightness changes sud-
system
denly, such as at the entrances and
exits of tunnels, etc.
Q Lane departure alert function
O Light from the headlights of an
oncoming vehicle, the sun, etc.,
When the system determines that
enters the camera.
the vehicle might depart from its
O The vehicle is driven on a slope.
lane or course*, a warning is dis-
played on the multi-information dis-
O The vehicle is driven on a road
which tilts left or right, or a winding
play, and either a warning buzzer
road.
will sound or the steering wheel will
O The vehicle is driven on an
vibrate to alert the driver.
unpaved or rough road.
When the warning buzzer sounds or
O The traffic lane is excessively nar-
the steering wheel vibrates, check the
row or wide.
area around your vehicle and carefully
4-5. Using the driving support systems
217
operate the steering wheel to move the
bility of a collision with an overtaking
vehicle back to the center of the lane.
vehicle in the adjacent lane is high, the
steering assist function will operate
Vehicle with BSM: When the system
even if the turn signals are operating.
determines that the vehicle might
depart from its lane and that the possi-
*: Boundary between asphalt and the
bility of a collision with an overtaking
side of the road, such as grass, soil,
vehicle in the adjacent lane is
high, the
or a curb
lane departure alert will operate even if
the
turn signals are operating.
*: Boundary between asphalt and the
side of the road, such as grass, soil,
or a curb
4
Q Vehicle sway warning function
When the vehicle is
swaying within
a lane, the warning buzzer will
sound and a message will be dis-
played on the multi-information dis-
Q Steering assist function
play to alert the driver.
When the system determines that
the vehicle might depart from its
lane or course*, the system pro-
vides assistance as necessary by
operating the steering wheel in
small amounts for a short period of
time to keep the vehicle in its lane.
Vehicle with BSM: When the system
determines that the vehicle might
depart from its lane and that the possi-
218
4-5. Using the driving support systems
Q Lane centering function
LTA system setting
This function is
linked with dynamic
radar cruise control with full-speed
Q Changing the lane centering
range and provides the required
function ON/OFF condition
assistance by operating the steer-
The lane centering function turns
ing wheel to keep the vehicle in its
ON/OFF each time the LTA switch
current lane.
is pressed.
When dynamic radar cruise control with
The LTA settings state is displayed on
full-speed range is not operating, the
the multi-information display when the
lane centering function does not oper-
LTA switch is pressed.
ate.
Also, the LTA function can be turned
In situations where the white (yellow)
ON/OFF with
on the multi-informa-
lane lines are difficult to see or are not
tion display. (→P.431)
visible, such as when in a traffic jam,
this function will operate to help follow a
preceding vehicle by monitoring the
position of the preceding vehicle.
4-5. Using the driving support systems
219
X Lane centering function ON
Flashing in orange: Lane departure
alert function is operating.
LTA Steering Assist Active Lane
Operation display of steering
Centering Active
wheel operation support
X Lane centering function OFF
Displayed when the multi-information
LTA Steering Assist Active
display is switched to the driving sup-
Q Turning the LTA system OFF
port system information screen.
Indicates that steering wheel assis-
Press and hold the LTA switch
tance of the steering assist function or
The LTA indicator light turns off when
lane centering function is operating.
the LTA is turned OFF.
Both outer sides of the lane are dis-
Press the switch again to turn the sys-
played: Indicates that steering wheel
tem on.
assist of the lane centering function is
The LTA is turned ON each time the
operating.
power switch is turned to ON.
One outer side of the lane is displayed:
Indicates that steering wheel assist of
However, the lane centering function
4
the steering assist function is operating.
keeps either the ON/OFF state prior to
the power switch being turned OFF.
Both outer sides of the lane are flash-
ing: Alerts the driver that their input is
necessary to stay in the center of the
Indications on multi-infor-
lane (lane centering function).
mation display
Follow-up cruising display
Displayed when the multi-information
display is switched to the driving sup-
port system information screen.
Indicates that steering assist of the lane
centering function is operating by moni-
toring the position of a preceding vehi-
cle.
When the follow-up cruising display is
displayed, if the preceding vehicle
moves, your vehicle may move in the
LTA indicator
same way. Always pay careful attention
The illumination condition of the indica-
to your surroundings and operate the
tor informs the driver of the system
steering wheel as necessary to correct
operation status.
the path of the vehicle and ensure
Illuminated in white: LTA system is
safety.
operating.
Lane departure alert function
Illuminated in green: Steering wheel
display
assistance of the steering assist func-
tion or lane centering function is operat-
ing.
220
4-5. Using the driving support systems
Displayed when the multi-information
Q Operation conditions of each func-
display is switched to the driving sup-
tion
port system information screen.
O Lane departure alert function
X Inside of displayed lines is white
This function operates when all of the
following conditions are met.
• LTA is turned on.
• Vehicle speed is approximately 50
km/h (32 mph) or more.*1
• System recognizes white (yellow) lane
lines or a course*2. (When a white
[yellow] line or course*2 is recognized
on only one side, the system will oper-
ate only for the recognized side.)
• Width of traffic lane is approximately 3
m (9.8 ft.) or more.
• Turn signal lever is not operated.
Indicates that the system is recog-
(Vehicle with BSM: Except when
nizing white (yellow) lines or a
another vehicle is in the lane on the side
course*. When the vehicle departs
where the turn signal was operated)
from its lane, the white line dis-
• Vehicle is not being driven around a
played on the side the vehicle
sharp curve.
departs from flashes orange.
• No system malfunctions are detected.
(→P.222)
X Inside of displayed lines is black
*1: The function operates even if the
vehicle speed is less than approxi-
mately 50 km/h (32 mph) when the
lane centering function is operating.
*2: Boundary between asphalt and the
side of the road, such as grass, soil,
or a curb
O Steering assist function
This function operates when all of the
following conditions are met in addition
Indicates that the system is not able
to the operation conditions for the lane
to recognize white (yellow) lines or
departure alert function.
• Vehicle is not accelerated or deceler-
a course* or is temporarily can-
ated by a fixed amount or more.
celed.
• Steering wheel is not operated with a
steering force level suitable for chang-
*: Boundary between asphalt and the
ing lanes.
side of the road, such as grass, soil,
• ABS, VSC, TRC and PCS are not
or a curb
operating.
• TRC or VSC is not turned off.
• Hands off steering wheel warning is
not displayed. (→P.222)
4-5. Using the driving support systems
221
O Vehicle sway warning function
Q Temporary cancelation of functions
This function operates when all of the
O When operation conditions are no lon-
following conditions are met.
ger met, a function may be temporar-
ily canceled. However, when the
• Setting for “Sway Warning” in
of
operation conditions are met again,
the multi-information display is set to
operation of the function is automati-
ON”. (→P.431)
cally restored. (→P.220)
• Vehicle speed is approximately 50
km/h (32 mph) or more.
OIf the operation conditions (→P.220)
• Width of traffic lane is approximately 3
are no longer met while the lane cen-
m (9.8 ft.) or more.
tering function is operating, the steer-
• No system malfunctions are detected.
ing wheel may vibrate and the buzzer
(→P.222)
may sound to indicate that the func-
tion has been temporarily canceled.
OLane centering function
However, if the alert types customiza-
This function operates when all of the
tion setting is set to steering wheel
following conditions are met.
vibration, the system will notify the
LTA is turned on.
driver by vibrating the steering wheel
Setting for “Lane Center” in
of the
instead of sounding the buzzer.
multi-information display are set to
QSteering assist function/lane cen-
ON” (→P.431)
tering function
4
This function recognizes white (yel-
low) lane lines or the position of a pre-
O Depending on the vehicle speed, lane
ceding vehicle (except when the
departure situation, road conditions,
preceding vehicle is small, such as a
etc., the driver may not feel the func-
motorcycle).
tion is operating or the function may
The dynamic radar cruise control with
not operate at all.
full-speed range is operating in vehi-
OThe steering control of the function is
cle-to-vehicle distance control mode.
overridden by the driver’s steering
Width of traffic lane is approximately 3
wheel operation.
to 4 m (10 to 13 ft.).
ODo not attempt to test the operation of
Turn signal lever is not operated.
the steering assist function.
Vehicle is not being driven around a
sharp curve.
QLane departure alert function
No system malfunctions are detected.
OThe warning buzzer may be difficult to
(→P.222)
hear due to external noise, audio play-
Vehicle does not accelerate or decel-
back, etc. Also, it may be difficult to
erate by a fixed amount or more.
feel steering wheel vibrations due to
Steering wheel is not operated with a
the road conditions, etc.
steering force level suitable for chang-
ing lanes.
OIf the edge of the course* is not clear
ABS, VSC, TRC and PCS are not
or straight, the lane departure alert
operating.
function may not operate.
TRC or VSC is not turned off.
O Vehicle with BSM: It may not be possi-
Hands off steering wheel warning is
ble for the system to determine if there
not displayed. (→P.222)
is a danger of a collision with a vehicle
The vehicle is being driven in the cen-
in an adjacent lane.
ter of a lane.
Steering assist function is not operat-
ODo not attempt to test the operation of
ing.
the lane departure alert function.
*: Boundary between asphalt and the
side of the road, such as grass, soil,
222
4-5. Using the driving support systems
or a curb
O When the system determines that the
driver is driving without holding the
Q Hands off steering wheel warning
steering wheel while the steering
In the following situations, a warning
wheel assist of the steering assist
message urging the driver to hold the
function is operating.
steering wheel and the symbol shown in
If the driver continues to keep their
the illustration are displayed on the
hands off of the steering wheel and the
multi-information display to warn the
steering wheel assist is operating, the
driver. The warning stops when the sys-
tem determines that the driver holds the
buzzer sounds and the driver is warned.
steering wheel. Always keep your hands
Each time the buzzer sounds, the con-
on the steering wheel when using this
tinuing time of the buzzer becomes lon-
system, regardless of warnings.
ger.
The buzzer also sounds even if the alert
type is set to steering wheel vibration.
Q Vehicle sway warning function
When the system determines that the
vehicle is swaying while the vehicle
sway warning function is operating, a
buzzer sounds and a warning message
urging the driver to rest and the symbol
OWhen the system determines that the
shown in the illustration are simultane-
driver is driving without holding the
ously displayed on the multi-information
steering wheel while the system is
display.
operating
If the driver continues to keep their
hands off of the steering wheel, the
buzzer sounds, the driver is warned and
the function is temporarily canceled.
This warning also operates in the same
way when the driver continuously oper-
ates the steering wheel only a small
amount.
Depending on the vehicle and road con-
The buzzer also sounds even if the alert
ditions, the warning may not operate.
type is set to steering wheel vibration.
Q Warning message
OWhen the system determines that the
If the following warning message is dis-
vehicle may not turn and instead
played on the multi-information display
depart from its lane on a curve while
and the LTA indicator illuminates in
the lane centering function is operat-
orange, follow the appropriate trouble-
ing.
shooting procedure. Also, if a different
warning message is displayed, follow
Depending on the vehicle condition and
the instructions displayed on the screen.
road conditions, the warning may not
OLTA Malfunction Visit Your Dealer
operate. Also, if the system determines
that the vehicle is driving around a
The system may not be operating prop-
curve, warnings will occur earlier than
erly. Have the vehicle inspected by any
during straight-lane driving.
authorized Mazda retailer or Mazda
authorized repairer, or any reliable
4-5. Using the driving support systems
223
repairer.
Dynamic radar cruise
OLTA Unavailable
control with full-speed
The system is temporarily canceled due
range*
to a malfunction in a sensor other than
the front camera. Turn the LTA system
*: If equipped
off, wait for a little while, and then turn
the LTA system back on.
Summary of functions
OLTA Unavailable at Current Speed
The function cannot be used as the
In vehicle-to-vehicle distance con-
vehicle speed exceeds the LTA opera-
trol mode, the vehicle automati-
tion range. Drive slower.
cally accelerates, decelerates and
Q Customization
stops to match the speed changes
Function settings can be changed.
of the preceding vehicle even if the
(→P.431)
accelerator pedal is not depressed.
In constant speed control mode,
the vehicle runs at a fixed speed.
4
Use the dynamic radar cruise con-
trol with full-speed range on free-
ways and highways.
z Vehicle-to-vehicle distance con-
trol mode (→P.226)
z Constant speed control mode
(→P.230)
System components
Q Meter display
Multi-information display
Set speed
224
4-5. Using the driving support systems
Indicators
• Conditions under which the vehicle-
to-vehicle distance control mode
Q Operation switches
may not function correctly: →P.234
OSet the speed appropriately
depending on the speed limit, traffic
flow, road conditions, weather con-
ditions, etc. The driver is responsi-
ble for checking the set speed.
O Even when the system is function-
ing normally, the condition of the
preceding vehicle as detected by
the system may differ from the con-
dition observed by the driver.
Therefore, the driver must always
Vehicle-to-vehicle distance
remain alert, assess the danger of
switch
each situation and drive safely.
Relying solely on this system or
+RES” switch
assuming the system ensures
safety while driving can lead to an
Cancel switch
accident, resulting in death or seri-
-SET” switch
ous injury.
Cruise control main switch
O Switch the dynamic radar cruise
control with full-speed range setting
to off, using the cruise control main
WARNING
switch when not in use.
Q Before using dynamic radar
QCautions regarding the driving
cruise control with full-speed
assist systems
range
Observe the following precautions, as
O Driving safely is the sole responsi-
there are limitations to the assistance
bility of the driver. Do not rely solely
provided by the system. Failure to do
on the system, and drive safely by
so may cause an accident resulting in
always paying careful attention to
death or serious injury.
your surroundings.
O The dynamic radar cruise control
with full-speed range provides driv-
ing assistance to reduce the
driver’s burden. However, there are
limitations to the assistance pro-
vided.
Read the following conditions care-
fully. Do not overly rely on this system
and always drive carefully.
• When the sensor may not be cor-
rectly detecting the vehicle ahead:
→P.233
4-5. Using the driving support systems
225
WARNING
QSituations unsuitable for
dynamic radar cruise control
OAssisting the driver to measure fol-
with full-speed range
lowing distance
Do not use dynamic radar cruise con-
The dynamic radar cruise control with
trol with full-speed range in any of the
full-speed range is only intended to
following situations. Doing so may
help the driver in determining the fol-
result in inappropriate speed control
and could cause an accident resulting
lowing distance between the driver’s
in death or serious injury.
own vehicle and a designated vehicle
traveling ahead. It is not a mechanism
O Roads where there are pedestrians,
cyclists, etc.
that allows careless or inattentive
driving, and it is not a system that can
OIn heavy traffic
assist the driver in low-visibility condi-
OOn roads with sharp bends
tions.
OOn winding roads
It is still necessary for driver to pay
close attention to the vehicle’s sur-
OOn slippery roads, such as those
roundings.
covered with rain, ice or snow
4
OAssisting the driver to judge proper
OOn steep downhills, or where there
following distance
are sudden changes between sharp
up and down gradients
The dynamic radar cruise control with
full-speed range determines whether
Vehicle speed may exceed the set
the following distance between the
speed when driving down a steep hill.
driver’s own vehicle and a designated
OAt entrances to freeways and high-
vehicle traveling ahead is within a set
ways
range. It is not capable of making any
OWhen weather conditions are bad
other type of judgement. Therefore, it
enough that they may prevent the
is absolutely necessary for the driver
sensors from detecting correctly
to remain vigilant and to determine
(fog, snow, sandstorm, heavy rain,
whether or not there is a possibility of
etc.)
danger in any given situation.
OWhen there is rain, snow, etc., on
the front surface of the radar or
OAssisting the driver to operate the
front camera
vehicle
The dynamic radar cruise control with
OIn traffic conditions that require fre-
full-speed range does not include
quent repeated acceleration and
functions which will prevent or avoid
deceleration
collisions with vehicles ahead of your
OWhen your vehicle is towing a
vehicle. Therefore, if there is ever any
trailer (vehicles with towing pack-
possibility of danger, the driver must
ages) or during emergency towing
take immediate and direct control of
the vehicle and act appropriately in
OWhen an approach warning buzzer
order to ensure the safety of all
is heard often
involved.
226
4-5. Using the driving support systems
Driving in vehicle-to-vehicle distance control mode
This mode employs a radar to detect the presence of vehicles up to approx-
imately 100 m (328 ft.) ahead, determines the current vehicle-to-vehicle fol-
lowing distance, and operates to maintain a suitable following distance from
the vehicle ahead. The desired vehicle-to-vehicle distance can also be set
by operating the vehicle-to-vehicle distance switch.
When driving on downhill slopes, the vehicle-to-vehicle distance may become
shorter.
Example of constant speed cruising
When there are no vehicles ahead
The vehicle travels at the speed set by the driver.
Example of deceleration cruising and follow-up cruising
When a preceding vehicle driving slower than the set speed appears
When a vehicle is detected running ahead of you, the system automatically deceler-
ates your vehicle. When a greater reduction in vehicle speed is necessary, the sys-
tem applies the brakes (the stop lights will come on at this time). The system will
respond to changes in the speed of the vehicle ahead in order to maintain the vehi-
cle-to-vehicle distance set by the driver. Approach warning warns you when the sys-
tem cannot decelerate sufficiently to prevent your vehicle from closing in on the
vehicle ahead.
When the vehicle ahead of you stops, your vehicle will also stop (vehicle is stopped
by system control). After the vehicle ahead starts off, pressing the “+RES” switch or
depressing the accelerator pedal (start-off operation) will resume follow-up cruising.
If the start-off operation is not performed, system control continues to keep your
vehicle stopped.
4-5. Using the driving support systems
227
When the turn signal lever is operated and your vehicle moves to an overtaking lane
while driving at 80 km/h (50 mph) or more, the vehicle will accelerate to help to over-
take a passing vehicle.
The system’s identification of what is an overtaking lane may be determined solely
based on the location of the steering wheel in the vehicle (left side driver position
versus right side driver position.) If the vehicle is driven to a region where the over-
taking lane is on a different side from where the vehicle is normally driven, the vehi-
cle may accelerate when the turn signal lever is operated in the opposite direction to
the overtaking lane (e.g., if the driver normally operates the vehicle in a region
where the overtaking lane is to the right but then drives to a region where the over-
taking lane is to the left, the vehicle may accelerate when the right turn signal is acti-
vated).
Example of acceleration
When there are no longer any preceding vehicles driving slower than the
set speed
The system accelerates until the set speed is reached. The system then returns to
constant speed cruising.
4
speed control mode. (→P.230)
Setting the vehicle speed
(vehicle-to-vehicle distance
control mode)
1 Press the cruise control main
switch to activate the cruise con-
trol.
Dynamic radar cruise control indicator
will come on and a message will be dis-
played on the multi-information display.
Press the switch again to deactivate the
Radar Ready
cruise control.
2 Accelerate or decelerate, with
If the cruise control main switch is
pressed and held for 1.5 seconds or
accelerator pedal operation, to
more, the system turns on in constant
the desired vehicle speed (at or
above approximately 30 km/h
[20 mph]) and press the “-SET
switch to set the speed.
Cruise control “SET” indicator will come
on.
The vehicle speed at the moment the
switch is released becomes the set















Content      ..     5      6      7      8     ..
