Mazda Mazdaspeed 3 (2013 year). Instruction

qOperating the Satellite Radio

Audio button

Seek tuning
buttons

Manual tuning
dial

NOTE

This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
- Increase the separation between the
equipment and tuner.
- Connect the equipment into an outlet on a
circuit different from that to which the tuner is
connected.
- Consult the dealer or an experienced radio/
TV technician for help.

What is satellite radio?

With over 130 channels, SIRIUS Satellite
Radio brings you more of what you love.
Get channels and channels of commercial-
free music, plus sports, news, talk,
entertainment and more.
Commercial-free music from nearly
every genre

―rock to pop, hip-hop to

country, jazz, classical and more. Plus live
performances and artist-dedicated
channels.
Live sports Play-by-Play & Expert Talk

―every NFL game, every NASCAR

race, 24/7 sports talk, college sports and
more.
Exclusive entertainment, comedy and
talk

―The biggest names, compelling

talk, hilarious comedy.
World-class news plus local traffic and
weather.
Sign up for SIRIUS Satellite Radio today!

6-72

Interior Comfort

Some models.

Audio System

NOTE

Exclusive to Sirius. If your vehicle is equipped
with Sirius, your new Mazda includes a free
introductory subscription with a limited term
trial offer. Call 888-539-7474 to activate. For
more information, visit www.siriusxm.com.
Satellite radio is only available in regions
providing satellite radio service (some areas of
the United States and Canada). Contact
Authorized Mazda Dealer for details.

How to Activate Satellite Radio

You must call SIRIUS to activate your
service. Activation is free and takes only a
few minutes.
SIRIUS service uses an ID code to
identify your radio. This code is needed to
activate SIRIUS service, and report any
problems.

Please have the following information
ready:

SIRIUS ID (12-digit electronic serial
no, or ESN

)

Valid credit card information (may not
be required at initial sign-up)

*1 ESN: Electronic Serial Number
Be sure you are parked outside with a
clear view of open sky, you will be
instructed to turn on your radio (in
SIRIUS mode and tuned to channel 184).
Activation typically takes only 2

―5

minutes.

Displaying the SIRIUS ID (ESN)

Turn the manual tuning dial and select
channel 0 to display the twelve-digit
Electronic Serial Number (ESN) for the
SIRIUS tuner.

SIRIUS operation

All operations of the satellite radio are
conducted by means of the audio unit.

SIRIUS radio mode selection

Touch the

on-screen tab on the

audio screen to receive the previously
received SIRIUS channel.
Every time the

on-screen tab is

touched, the bank changes in the order
shown below.

SIRIUS1

SIRIUS2

SIRIUS3

NOTE

SIRIUS1, SIRIUS2 and SIRIUS3: six
stations can be stored in each bank for
convenient access to your favorite stations.

is displayed when SIRIUS1 is

selected,

is displayed when

SIRIUS2 is selected, and

displayed when SIRIUS3 is selected.

Operation in the initial state

It may take some time to start up the
equipment when it is in the initial state,
when there is a change in the user's
subscription condition, when the firmware
is updated or when the SIRIUS channel
map is changed.

“Updating Channels XXX %” is
displayed when the SIRIUS channel map
is changed.
If the user contract content is changed,

“Subscription Updated” is displayed.
When the firmware is updated, the

“Updating Receiver” is displayed.
Updating could take as long as a few
minutes depending on the geographical
area. When the unit is in an initialized
state, channel 184 is displayed after the
display indicates

“Updating Receiver”.

Interior Comfort

Audio System

6-73

NOTE

Do not perform the following operation while
“Updating Channels XXX %”,

“Updating Receiver” is displayed. Otherwise,
the updating procedure will be canceled.

Turning off the audio power

Switching to other modes

Switching the ignition off

When the SIRIUS mode is switched to
another mode, or when the power is
turned off, the present channel which is
being received is stored as the last
channel.

Channel up

Turn the manual tuning dial to the right or
press the seek up button (

Channel down

Turn the manual tuning dial to the left or
press the seek down button (

NOTE

The channel is continuously switched to the
next or previous channel while the seek tuning
button (

) is continuously pressed.

Unsubscribed channel

When a channel which has been preset
becomes unsubscribed or the current
channel being listened to becomes
unsubscribed, the following is displayed:

“Call 888-539-SIRIUS”

“to subscribe”
NOTE

When the subscription contract is canceled, all
of the channels including channel 184 appear
as unsubscribed.

Preset channel programming

1. Select the desired channel to be

programmed.

2. Long-press any of the preset on-screen

buttons.

NOTE

Six stations can be stored in each bank,
SIRIUS1, SIRIUS2 and SIRIUS3 for
convenient access to your favorite stations.

Preset channel call-up

Touch the preset on-screen button for the
channel which you want to select.

NOTE

In the initial setting, all channels are preset to
184.

Selection from channel list

Receivable channels can be displayed on
the channel list screen. You can easily
select the channel you want to listen from
the list. Each category can be also
displayed.

1. Touch the

on-screen button.

2. Touch the channel you want to listen

from the list.

NOTE

Currently available channels (including
parental locked channels) are all displayed in
the list.

(Select from category list)

1. Touch the

on-screen

button on the channel list screen.

2. Touch the category name which you

want to select from the list.

NOTE

A category can be set only when a channel
which belongs to a category is being received.

6-74

Interior Comfort

Audio System

Scan tuning

Touch the

on-screen button to

automatically sample stations. Scanning
stops at each station for about five
seconds.
To hold a station, touch the

on-

screen button again during this interval.

NOTE

Unsubscribed channels, invalid channels,
parental lock channels and channel 0 are not
subject to the scan, therefore these channels
will skip automatically.

Channel number, channel name,
category name, artist name, song titles
and information display

The information regarding the channel
which is currently being received is
displayed.

NOTE

If channels have not been subscribed to or
parental locked, the channel name, category
name, artist name, song title and information
is not displayed.

Display scroll

If a whole title cannot be displayed at one
time, touch the

on-screen button on

the right side of the title. When the last
character is displayed, touch the

on-

screen button to display the first character
of the title.

NOTE

The

on-screen button is displayed only if a

whole title cannot be displayed at one time.

Instant replay

This function allows you to rewind and
replay the program that you were
previously or are currently listening to.

When the

on-screen button is

touched, playback starts from the
beginning of the current program.
When the

on-screen button is

touched twice, playback starts from the
beginning of the previous program.
Touch and hold the

on-screen

button to reverse the program while the
button is being pressed.
When the

on-screen button is

touched, playback starts from the
beginning of the next program.
When the

on-screen button is

touched while the last program is being
played, the instant replay mode is
canceled.
Touch and hold the

on-screen

button to fast-forward the program while
the button is being pressed.
When touching and holding the button
until the end of the program, the instant
replay mode is canceled.

Instant replay (PAUSE)

If the

on-screen button is touched,

instant replay mode is turned on in a
paused condition (PAUSE).
Touch the

on-screen button again

to resume playback from the point at
which it was paused.

Parental lock

Parental lock, parental unlock, parental
lock code change, and parental lock code
reset can be set.

Interior Comfort

Audio System

6-75

NOTE

Touch the

on-screen button during

all the settings to return to the previous
display.

Touch the

on-screen button during the

code and master code input to delete an
input number.

If only a four-digit code or master code is
input,

“Done” can be selected.

If the registered code has been forgotten,
reset the code in

“Initialize Parental Code”

to [0000].

Parental lock

If a channel is locked, the channel is
muted.

1. Turn the manual tuning dial to select

the desired channel.

2. Touch the

on-screen button to

display the settings screen.

3. Touch the

on-screen

button to display the parental lock
settings screen.

“Input Parental Code” is displayed, and
input of the registered code is possible.
To enter a number, use the numerical
keypad.

5. After inputting the four digits, touch

the

on-screen button to confirm

the four digits.

6. If the four digits match the registered

code,

“Channel XXX locked” appears

and mute is turned on. If they do not
match the registered code,

“Wrong code” appears and then the
display returns to

“Input Parental Code”.

Parental unlock

Channels locked using the parental lock
function can be unlocked.

1. Select a channel to be unlocked by

turning the manual tuning dial.

2. Touch the

on-screen button to

display the settings screen.

3. Touch the

on-screen

button to display the parental unlock
settings screen.

“Input Parental Code” is displayed, and
input of the registered code is possible.
To enter a number, use the numerical
keypad.

5. After inputting the four digits, touch

the

on-screen button to confirm

the four digits.

6. If the four digits match the registered

code,

“Channel XXX unlocked”

appears and mute is canceled. If they
do not match the registered code,

“Wrong code” appears and then the
display returns to

“Input Parental Code”.

Parental-lock code change

When changing the code, the new code is
input after the previous one is input first.

1. Touch the

on-screen button to

display the settings screen.

2. Touch the

on-

screen button to display the code
change screen.

“Enter Current Code” is displayed, and
input of the registered code is possible.
To enter a number, use the numerical
keypad.

6-76

Interior Comfort

Audio System

4. After inputting the four digits, touch

the

on-screen button to confirm

the four digits.

5. If the four digits match the registered

code,

“Enter New Code” is displayed.

If they do not match the registered
code,

“Wrong code” appears and then

the display returns to

“Enter Current Code”. To enter a
number, use the numerical keypad.

6. After inputting the four digits, touch

the

on-screen button to confirm

the four digits.

“Code changed” appears to indicate
that the new code input has been
completed.

8. The display returns to its normal

display.

NOTE

Channels locked before changing the code
remain after changing the code. To unlock a
channel, input the changed code.

Parental-lock code reset

If the registered code has been forgotten,
reset the code to the default [0000] code.

1. Touch the

on-screen button to

display the settings screen.

2. Touch the

on-

screen button to display the code initial
screen.

“Enter Master Code” is displayed, and
input of the registered code is possible.
To enter a number, use the numerical
keypad.

NOTE

Master code:
The Master Code is used to initialize or re-
initialize the code in the event that the code is
not set to [0000] and/or the personalized code
is not known. The initialization process resets
the code to [0000]. The master code can
potentially defeat the intent of the security of
the parental lock if it is located by persons not
authorized by the owner to access certain
channels.
SIRIUS Satellite Radio Master Code: [0913]

4. After inputting the four digits, touch

the

on-screen button to confirm

the four digits.

5. If the four digits match the master

code,

“Code initialized” appears. If

they do not match the master code,

“Wrong code” appears and the display
returns to

“Enter Master Code”.

6. The code returns to the default [0000]

code.

Seek alert

The song title and artist name for the song
currently being listened to, and team
names at the sports game currently being
listened to can be recorded as favorites.
The user is notified when a program
begins which has favorites-related
information recorded.

Selection from seek alert program list

Select the station you want to listen to
from the list to receive the program.
Touch the

on-screen button to

return to the receiving screen.

Interior Comfort

Audio System

6-77

Storing songs, artists, and sports team
names

NOTE

A maximum of 10 songs, artists, and sports
team names each can be stored.

If the song title, artist name, sports team
name cannot be displayed,
“No available items for this program” is
displayed.

Even if the song title, and artist name are
displayed in the main screen, it may not be
possible to record information for old
songs.

If a song name is stored, the song seek
function is turned on.

If an artist name is stored, the artist seek
function is turned on.

If a sports team name is stored, the game
alert function is turned on.

1. Touch the

on-screen button to

display the current song and artist
names currently being received. The
sports team name is displayed while
the sports program is being received.

2. Select the item you want to store from

song title, artist name and sports team
name.

“XXXXX (song, artist, sports team
name) stored

” is displayed.

NOTE

If there is not enough available storage space,
“Song Memory Full” or “Artist Memory Full”
or

“Team Memory Full” and

“Delete one to store new one” are displayed.
Delete from the list.

Seek alert setting

On or off switching to song seek, artist
seek, or game alert function, and deletion
of stored information can be performed.
Touch the

on-screen button and the

on-screen button. Touch the button

you want to change from

, or

(On or off switching)
Touch the

, and

on-screen button.

(Deletion)

1. Select song title, artist name, or sports

team name that you want to delete from
the list.

2. Touch the

on-screen button to

display

“XXXXX (song, artist, sports

team name) deleted

”.

6-78

Interior Comfort

Audio System

qOperating the Compact Disc (CD) Player

Audio button

Track up/Fast-
forward button

File dial

CD eject button

CD slot

Track down/
Reverse button

Type

Playable data

Music/MP3/WMA/
AAC CD player

Music data (CD-DA)

MP3/WMA/AAC file

NOTE

If a disc has both music data (CD-DA) and
MP3/WMA/AAC files, playback of the two or
three file types differs depending on how the
disc was recorded.

Inserting the CD

Insert the CD into the slot, label-side up.
The auto-loading mechanism will set the
CD and begin play.

NOTE

There will be a short lapse before play begins
while the player reads the digital signals on
the CD.

Ejecting the CD

Press the CD eject button (

) to eject the

CD.

Playback

Press the audio button (

) or

on-screen tab with a CD inserted.

Pause

To pause playback, touch the

on-

screen button.
Touch the

on-screen button during

a pause to cancel it.

6-80

Interior Comfort

Audio System

Fast-forward/Reverse

Operations using audio panel

Press and hold the fast-forward button
(

) to advance through a track at high

speed.
Press and hold the reverse button (

) to

reverse through a track at high speed.

Operations on screen

Touch and hold the

on-screen

button to advance through a track at high
speed.
Touch and hold the

on-screen

button to reverse through a track at high
speed.

Track search

Operations using audio panel

Press the track up button (

) or turn the

file dial clockwise once to skip forward to
the beginning of the next track.
Press the track down button (

) or turn

the file dial counterclockwise within a few
seconds after playback begins to track
down to the beginning of the previous
track.
Press the track down button (

) or turn

the file dial counterclockwise after a few
seconds have elapsed to start playback
from the beginning of the current track.

Operations on screen

Touch the

on-screen button once to

skip forward to the beginning of the next
track.
Touch the

on-screen button within

a few seconds after playback begins to
track down to the beginning of the
previous track.
Touch the

on-screen button after a

few seconds have elapsed to start
playback from the beginning of the
current track.

Displaying file list

The desired file list in the CD can be
viewed.

During music CD playback

Touch the

on-screen button to display

the track list in the CD.

During MP3/WMA/AAC CD playback

(Viewing file list in desired folder)

1. Touch the

on-screen button to

display the folder list in the CD.

2. Touch the folder which you want to

select.

(Viewing file list of current folder)
Touch the

on-screen button.

Selecting file/track

Select the file/track you want to play.

During music CD playback

1. Touch the

on-screen button to

display the track list in the CD.

2. Touch the track you want to play.

During MP3/WMA/AAC CD playback

NOTE

Press the

on-screen button on the file list

screen to display the list of folders.

(Selection from all folders in CD)

1. When the

on-screen button is

touched, the folder list in the CD is
displayed.

2. Select the folder name from the

displayed list.

3. The files in the selected folder are

displayed.

4. Select the file you want to play.

Interior Comfort

Audio System

6-81

(Selection from inside folder in which a
song is currently being played)

1. Press the

on-screen button to

select the song list.

2. Touch the song you want to listen to.

Music scan

During music CD playback

This function scans the titles on a CD and
plays 10 seconds of each song to aid you
in finding a song you want to listen to.

1. Touch the

on-screen button

during playback to play 10 seconds of
each subsequent track starting from the
next song.

2. Touch the

on-screen button

during playback of the song you want
to listen to and continue the playback
from that point.

During MP3/WMA/AAC CD playback

This function scans the titles in a folder
currently being played and plays 10
seconds of each song to aid you in finding
a song you want to listen to.

1. Touch the

on-screen button

during playback to play 10 seconds of
each subsequent track starting from the
next song.

2. Touch the

on-screen button

during playback of the song you want
to listen to and continue the playback
from that point.

NOTE

If the unit is left in scan, normal playback
will resume where scan was selected.

If all the tracks are scanned, the unit will
resume normal playback.

Repeat playback

During music CD playback

Touch the

on-screen button during

playback to play the song currently being
played repeatedly.

“ ” is displayed

during playback.
Touch the

on-screen button while

“ ” is displayed to cancel.

During MP3/WMA/AAC CD playback

(Track repeat)
Touch the

on-screen button to play

the song during playback repeatedly.

“ ”

is displayed during playback.
Touch the

on-screen button two

times while

“ ” is displayed to cancel.

(Folder repeat)
Touch the

on-screen button two

times to play the songs in the folder
repeatedly.

“

” is displayed during

playback.
Touch the

on-screen button while

“

” is displayed to cancel.

Shuffle playback

During music CD playback

Touch the

on-screen button during

playback to play the songs in the CD
shuffle.

“

” is displayed during

playback.
Touch the

on-screen button while

“

” is displayed to cancel.

During MP3/WMA/AAC CD playback

(Folder shuffle)
Touch the

on-screen button during

playback to play the songs in the folder
shuffle.

“

” is displayed during

playback.
Touch the

on-screen button two

times while

“

” is displayed to cancel.

6-82

Interior Comfort

Audio System

(CD shuffle)
Touch the

on-screen button two

times during playback to play the songs in
the CD shuffle.

“

” is displayed during

playback.
Touch the

on-screen button while

“

” is displayed to cancel.

Display scroll

If a whole title cannot be displayed at one
time, touch the

on-screen button on

the right side of the title. When the last
character is displayed, touch the

on-

screen button to display the first character
of the title.

NOTE

The

on-screen button is displayed only

if a whole title cannot be displayed at one
time.

The information viewable in the display is
only CD information (such as artist name,
song title) which has been recorded to the
CD.

This unit cannot display some characters.
Characters which cannot be displayed are
indicated by an asterisk (

The number of characters which can be
displayed is restricted.

Message Display

“CD Error” is displayed, it means that

there is some CD malfunction. Check the
CD for damage, dirt, or smudges, and
then properly reinsert. If the message
appears again, take the unit to an
Authorized Mazda Dealer for service.

qHow to use Auxiliary jack/USB port

Audio can be heard from the vehicle's
speakers by connecting a commercially-
available portable audio unit to the
auxiliary jack.
Use a commercially-available, non-
impedance (3.5 ) stereo mini plug cable.
Contact an Authorized Mazda Dealer for
details.
In addition, audio can be played from the
vehicle audio device by connecting a USB
device or an iPod to the USB port.
Refer to AUX/USB/iPod Mode on page
6-88.

qError Indications

If you see an error indication on the
display, find the cause in the chart. If you
cannot clear the error indication, take the
vehicle to an Authorized Mazda Dealer.

Indication

Cause

Solution

Error

CD is inserted
upside down

Insert the CD
properly. If the error
indication continues
to display, consult an
Authorized Mazda
Dealer.

CD is defective

Insert another CD
properly. If the error
indication continues
to display, consult an
Authorized Mazda
Dealer.

qSetup

You can customize settings in the setup
display as follows:

Display

Refer to Power/Volume/Display/Sound
Controls on page 6-64.

Interior Comfort

Audio System

6-83

Sound

Refer to Power/Volume/Display/Sound
Controls on page 6-64.

Language

1. Press the setup button (

2. Touch the

on-screen tab to

display the language setting screen.

3. Touch the desired language from the

list.

4. Touch the

on-screen button.

NOTE

Only the available languages are displayed.

Audio Control Switch
Operation

When the audio unit is turned on,
operation of the audio unit from the
steering wheel is possible.

NOTE

Because the audio unit will be turned off under
the following conditions, the switches will be
inoperable.

When the ignition is switched off.

When the power button on the audio unit is
pressed and the audio unit is turned off.

Without Bluetooth® Hands-Free

With Bluetooth® Hands-Free only

Talk button

Pick-up button

Talk button

Hang-up button

Pick-up button

6-84

Interior Comfort

Some models.

Audio System

With Bluetooth® Hands-Free and
navigation system

Talk button

Pick-up button

Talk button

Hang-up button

Pick-up button

NOTE

The talk button, pick-up button, and hang-
up button are operable with the audio unit
turned off.

Mazda has installed this system to prevent
distraction while driving the vehicle and
using audio controls on the dashboard.
Always make safe driving your first priority.

qAdjusting the Volume

To increase the volume, press up the
volume switch.

To decrease the volume, press down the
volume switch.
Without Bluetooth® Hands-Free

With Bluetooth® Hands-Free

qChanging the Source

Press the mode switch (

) to change

the audio source (FM1 radio

→ FM2

radio

→ AM radio → CD player or CD

changer

→ SIRIUS1 → SIRIUS2 →

SIRIUS3

→ AUX → BT audio → USB/

iPod

→ cyclical).

Without Bluetooth® Hands-Free

Interior Comfort

Audio System

6-85

Some models.

With Bluetooth® Hands-Free only

NOTE

CD, CD changer, AUX, USB/iPod, SIRIUS
digital satellite radio, and BT audio modes
cannot be selected in the following cases:

Auxiliary jack, USB device, iPod,
SIRIUS digital satellite radio unit, or BT
audio unit is not equipped on the audio
system.

CD has not been inserted.

The AUX mode is unavailable unless you
connect a commercially available portable
audio unit (such as an MP3 player) to the
auxiliary jack. Connect a portable audio
unit or similar product on the market to the
auxiliary jack to listen to music or audio
over the vehicle's speakers. Change the
audio source to AUX mode (page 6-88).

qSeek Switch

Without Bluetooth® Hands-Free

With Bluetooth® Hands-Free

When listening to the radio or SIRIUS
digital satellite radio

Press the seek switch up or down. The
radio switches to the next/previous stored
station in the order that it was stored
(1

―6).

(Radio)
Press and hold the seek switch in the up or
down position to seek all usable stations
at a higher or lower frequency whether
programmed or not.

6-86

Interior Comfort

Audio System

(SIRIUS digital satellite radio)
Press and hold the seek switch in the up or
down position to seek all usable stations
at a higher or lower channel whether
programmed or not.

NOTE

During radio reception
Radio stations which have been previously
stored in the auto memory tuning can be called
up by pressing the seek switch up or down
while any radio station stored in the auto
memory tuning is being received. Radio
stations can be called up in the order they
were stored with each press of the switch up or
down.

When playing a CD, USB, iPod or BT
audio

Press the seek switch up to skip to the
next track.
Press the seek switch down to repeat the
current track.
Press and hold the seek switch in the up or
down position to continuously switch the
tracks up or down.

qMute Switch

Press the mute switch ( ) once to mute
audio, press it again to resume audio
output.

NOTE

If the ignition is switched off with the audio
muted, the mute will be canceled.
Therefore, when the engine is restarted, the
audio is not muted. To mute the audio again,
press the mute switch (

Without Bluetooth® Hands-Free

Interior Comfort

Audio System

6-87

Some models.

Mazda Mazdaspeed 3 (2013 year). Instruction - part 20
