Remarks: * 1 The engine oil and filter must be changed at least once a year or within 12,000 km (7,500 miles) since last engine oil and filter change. Reset the engine oil data whenever replacing the engine oil regardless of the * 2 Use of FL-22 is recommended when replacing engine coolant. Using engine coolant other than FL-22 may cause serious damage to the engine and cooling system. * 3 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at * 4 If the vehicle is operated primarily under any of the following conditions, replace the rear differential oil at every 48,000 km (30,000 miles). * 5 If this component has been submerged in water, the oil should be replaced. * 6 Check the tire repair fluid expiration date every year when performing the periodic maintenance. Replace the tire repair fluid bottle with new one before the expiration date. ▼ Schedule 2 U.S.A. and Puerto Rico residents - Severe driving conditions maintenance interval Maintenance Interval Number of months or kilometers (miles), whichever comes first. Months 6 12 18 24 30 36 42 48 54 60 66 72 ×1000 km 8 16 24 32 40 48 56 64 72 80 88 96 ×1000 miles 5 10 15 20 25 30 35 40 45 50 55 60 Drive belts I I I Engine oil & filter Flexible *1 Replace when wrench indicator light is ON. (Max interval:12 months or 12,000 km (7,500 miles)) Fixed R R R R R R R R R R R R Engine coolant *2 Replace at first 192,000 km (120,000 miles) or 10 years; after that, every 96,000 km (60,000 miles) or 5 years. Engine coolant level I I I I I I I I I I I I Air filter *3 R R Fuel lines and hoses *4 I I I I Hoses and tubes for emission *4 I I Spark plugs Replace every 120,000 km (75,000 miles). Function of all lights I I I I I I I I I I I I Brake lines, hoses and connections I I I I Brake and clutch fluid level I I I I I I I I I I I I Disc brakes I I I I I I I I I I I I Tire (Rotation) Rotate every 8,000 km (5,000 miles). Tire inflation pressure and tire wear I I I I I I I I I I I I Maintenance and Care Scheduled Maintenance 6-6 CX-3_8GR7-EA-18B_Edition1 2017-12-20 16:18:14 |
