Mazda B4000 Truck (2007 year). Instruction

position. All safety belt assemblies, including retractors, buckles, front
safety belt buckle assemblies, buckle support assemblies (slide bar-if
equipped), shoulder belt height adjusters (if equipped), shoulder belt
guide on seatback (if equipped), child safety seat tether bracket
assemblies (if equipped), and attaching hardware, should be inspected
after a collision. Mazda recommends that all safety belt assemblies used
in vehicles involved in a collision be replaced. However, if the collision
was minor and an authorized Mazda technician finds that the belts do
not show damage and continue to operate properly, they do not need to
be replaced. Safety belt assemblies not in use during a collision should
also be inspected and replaced if either damage or improper operation is
noted.

The energy absorbing functions may have been activated in a collision so
the restraints should be examined; if the front airbags have deployed, the
pretensioners have also deployed and must be replaced — regardless of
whether there was an occupant in the passenger seat or not.

WARNING: Failure to inspect and if necessary replace the
safety belt assembly under the above conditions could result in
severe personal injuries in the event of a collision.

Refer to Interior in the Cleaning chapter.

Safety belt warning light and indicator chime

The safety belt warning light illuminates in the instrument cluster and a
chime sounds to remind the occupants to fasten their safety belts.

Conditions of operation

If...

Then...

The driver’s safety belt is not
buckled before the ignition
switch is turned to the ON
position...

The safety belt warning light
illuminates 1-2 minutes and the
warning chime sounds 4-8 seconds.

The driver’s safety belt is
buckled while the indicator
light is illuminated and the
warning chime is sounding...

The safety belt warning light and
warning chime turn off.

CIMS #55029

com_light-chime.01

itdseq=110

CIMS #55036

com_operation.01

itdseq=111

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 85 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

If...

Then...

The driver’s safety belt is
buckled before the ignition
switch is turned to the ON
position...

The safety belt warning light and
indicator chime remain off.

BeltMinder

The BeltMinder

t feature is a supplemental warning to the safety belt

warning function. This feature provides additional reminders by
intermittently sounding a chime and illuminating the safety belt warning
light in the instrument cluster when the driver’s and front passenger’s
safety belt is unbuckled.

The BeltMinder

t feature uses information from the front passenger

sensing system to determine if a front seat passenger is present and
therefore potentially in need of a warning. To avoid activating the
BeltMinder

t feature for objects placed in the front passenger seat,

warnings will only be given to large front seat occupants as determined
by the front passenger sensing system.

Both the driver’s and passenger’s safety belt usages are monitored and
either may activate the BeltMinder

t feature. The warnings are the same

for the driver and the front passenger. If the BeltMinder

t warnings have

expired (warnings for approximately 5 minutes) for one occupant (driver
or front passenger), the other occupant can still activate the BeltMinder

feature.

CIMS #522761

com_belt_minder-title

itdseq=112

CIMS #690991

com_belt_minder.mbs

itdseq=113

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 86 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

If...

Then...

The driver’s and front
passenger’s safety belts are
buckled before the ignition
switch is turned to the ON
position or less than 1-2
minutes have elapsed since the
ignition switch has been turned
ON...

The BeltMinder

t feature will not

activate.

The driver’s or front
passenger’s safety belt is not
buckled when the vehicle has
reached at least 3 mph (5
km/h) and 1-2 minutes have
elapsed since the ignition
switch has been turned to
ON...

The BeltMinder

t feature is activated -

the safety belt warning light
illuminates and the warning chime
sounds for 6 seconds every 30
seconds, repeating for approximately
5 minutes or until the safety belts are
buckled.

The driver’s or front
passenger’s safety belt becomes
unbuckled for approximately 1
minute while the vehicle is
traveling at least 3 mph (5
km/h) and more than 1-2
minutes have elapsed since the
ignition switch has been turned
to ON...

The BeltMinder

t feature is activated -

the safety belt warning light
illuminates and the warning chime
sounds for 6 seconds every 30
seconds, repeating for approximately
5 minutes or until the safety belts are
buckled.

The following are reasons most often given for not wearing safety belts
(All statistics based on U.S. data):

CIMS #598714

com_safety_stats.j14

itdseq=114

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 87 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

Reasons given...

Consider...

9Crashes are rare events9

36,700 crashes occur every day.
The more we drive, the more we are
exposed to

9rare9 events, even for

good drivers. 1 in 4 of us will be
seriously injured in a crash during
our lifetime.

9I’m not going far9

3 of 4 fatal crashes occur within 25
miles of home.

9Belts are uncomfortable9

Safety belts are designed to enhance
comfort. If you are uncomfortable -
try different positions for the safety
belt upper anchorage and seatback
which should be as upright as
possible; this can improve comfort.

9I was in a hurry9

Prime time for an accident. Safety
Belt Warning Chime reminds us to
take a few seconds to buckle up.

9Safety belts don’t work9

Safety belts, when used properly,
reduce risk of death to front seat
occupants by 45% in cars, and by
60% in light trucks.

9Traffic is light9

Nearly 1 of 2 deaths occur in
single-vehicle crashes, many when
no other vehicles are around.

9Belts wrinkle my clothes9

Possibly, but a serious crash can do
much more than wrinkle your clothes,
particularly if you are unbelted.

9The people I’m with don’t
wear belts

Set the example, teen deaths occur 4
times more often in vehicles with
TWO or MORE people. Children and
younger brothers/sisters imitate
behavior they see.

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 88 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

Reasons given...

Consider...

9I have an airbag9

Airbags offer greater protection when
used with safety belts. Frontal airbags
are not designed to inflate in rear and
side crashes or rollovers.

9I’d rather be thrown clear9

Not a good idea. People who are
ejected are 40 times more likely
to DIE. Safety belts help prevent
ejection, WE CAN’T

9PICK OUR

CRASH

WARNING: Always wear the safety belt. Do not be tempted to
sit on top of the belt to fool police or to defeat the warning
system. The safety belt and safety belt warning system are
there to protect your life.

One time disable

If at any time the driver/front passenger quickly buckles then unbuckles
the safety belt for that seating position, the BeltMinder

t is disabled for

the current ignition cycle. The BeltMinder

t feature will enable during the

same ignition cycle if the occupant buckles and remains buckled for
approximately 30 seconds. Confirmation is not given for the one time
disable.

Deactivating/activating the BeltMinder

feature

The driver and front passenger BeltMinder

t are

deactivated/activated independently. When deactivating/activating
one seating position, do not buckle the other position as this will
terminate the process.

Read Steps 1 - 4 thoroughly before proceeding with the
deactivation/activation programming procedure.

Note: The driver and front passenger BeltMinder

t features must be

disabled/enabled separately. Both cannot be disable/enabled during the
same key cycle.

The driver and front passenger BeltMinder

t features can be

deactivated/activated by performing the following procedure:

Before following the procedure, make sure that:
• The parking brake is set

CIMS #982456

com_one-time-dis.pass

itdseq=115

CIMS #1515506

com_mind_on-off.pass.beltlt

itdseq=116

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 89 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

• The gearshift is in P (Park) (automatic transmission)
• The ignition switch is in the OFF position
• The driver and front passenger safety belts are unbuckled

WARNING: While the design allows you to deactivate your
BeltMinder

t, this system is designed to improve your chances of

being safely belted and surviving an accident. We recommend
you leave the BeltMinder

t system activated for yourself and

others who may use the vehicle. To reduce the risk of injury, do
not deactivate/activate the BeltMinder

t feature while driving

the vehicle.

1. Turn the ignition switch to the RUN (or ON) position. (DO NOT

START THE ENGINE)

2. Wait until the safety belt warning light turns off. (Approximately 1

minute)

• Step 3 must be completed within 50 seconds after the safety belt

warning light turns off.

3. For the seating position being disabled, at a moderate speed, buckle

then unbuckle the safety belt 9 times, ending in the unbuckled state.
(Step 3 must be completed within 50 seconds after the safety belt
warning light turns off.)

• After Step 3, the safety belt warning light will be turned on for three

seconds.

4. Within 10 seconds of the light turning on, at a moderate speed,

buckle then unbuckle the safety belt.

• This will disable the BeltMindert feature for that seating position if it

is currently enabled. As confirmation, the safety belt warning light will
flash 4 times per second for 3 seconds.

• This will enable the BeltMindert feature for that seating position if it

is currently disabled. As confirmation, the safety belt warning light will
flash 4 times per second for 3 seconds, followed by 3 seconds with the
light off, then followed by the safety belt warning light flashing 4 times
per second for 3 seconds again.

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 90 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

AIRBAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

The airbag supplemental restraint system is designed to work in
conjunction with the safety belts to help protect the driver and front
outboard passenger from certain upper body injuries. The term
“supplemental restraint” means the airbags are intended as a supplement
to the safety belts. Airbags alone cannot protect as well as airbags plus
safety belts in impacts for which the airbags are designed to deploy, and
airbags do not offer any protection in crashes for which they do not
deploy.

The airbag supplemental restraint system consists of:
• driver and passenger dual stage airbag modules (which include the

inflators and airbags).

• one or more impact and safing sensors.
• the same indicator light, RCM (restraints control module) and

diagnostic unit used for the Personal safety system.

• Front passenger sensing system
• Passenger airbag off indicator light.
The airbag supplemental restraints are an integral part of the Personal
Safety System. They are designed to be deployed in cases where the
Personal Safety System has determined the occupant conditions and
crash severity are appropriate to activate these devices. Refer to the
Personal Safety System section in this chapter.

Important supplemental restraint system (SRS) precautions

The supplemental restraint system is designed to work with the safety
belt to help protect the driver and right front passenger from certain
upper body injuries.

CIMS #1543011

com_air-bag-systems.mbs

itdseq=117

CIMS #683851

com_imp_precauts.mbs

itdseq=118

art=ranss583_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 91 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

WARNING: Airbags DO NOT
inflate slowly or gently and the
risk of injury from a deploying
airbag is greatest close to the
trim covering the airbag
module. Always wear your
safety belt.

WARNING: Airbags have been known to kill or injure a child in
front facing child restraints. When placing a child safety seat in
a front seating position including the center (if equipped), you
should make sure that the passenger airbag is off. If the child
safety seat is in the outboard seating position, slide the seat all
the way back.

WARNING: Do not install a
child seat in a center facing
jump seat.

WARNING: Rear facing child
seats should NEVER be placed
in front of an active airbag.

WARNING: All occupants of
the vehicle, including the
driver, should always properly
wear their safety belts, even
when an air bag supplemental
restraint system (SRS) is
provided.

art=mbsss107_a

art=mbsss114_a

art=mbsss113_b

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 92 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

WARNING: National Highway Traffic Safety Administration
(NHTSA) recommends a minimum distance of at least 25 cm (10
inches) between an occupant’s chest and the driver air bag
module.

WARNING: Never place your arm or feet over the airbag
module as a deploying airbag can result in serious arm fractures
or other injuries.

Steps you can take to properly position yourself away from the airbag:
• Move your seat to the rear as far as you can while still reaching the

pedals comfortably.

• Recline the seat slightly (one or two degrees) from the upright

position.

WARNING: Do not put anything on or over the airbag module
including hands or feet. Placing objects on or over the airbag
inflation area may cause those objects to be propelled by the
airbag into your face and torso causing serious injury.

WARNING: Do not attempt to service, repair, or modify the
Airbag Supplemental Restraint System or its fuses. See your
authorized Mazda dealership.

WARNING: Modifications to the front end of the vehicle,
including frame, bumper, front end body structure, tow hooks
and snow plows may effect the performance of the airbag
sensors increasing the risk of injury. Do not modify the front
end of the vehicle.

WARNING: Additional equipment may effect the performance
of the airbag sensors increasing the risk of injury. Consult your
authorized Mazda dealership before installation of additional
equipment.

WARNING: The front passenger airbag is not designed to offer
protection to an occupant in the center front seating position.

CIMS #832821

com_imp_precauts.center

itdseq=119

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 93 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

Children and airbags

For additional important safety information, read all information on
safety restraints in this guide.

WARNING: Do not install a
child seat in a center facing
jump seat.

WARNING: Airbags can kill or
injure a child in a child seat.
NEVER place a rear-facing
child seat in front of an active
airbag. If you must use a
forward-facing child seat in the
front seat, move the seat all
the way back.

WARNING: Booster seats must be installed only in seating
positions equipped with a combination lap/shoulder belt.

WARNING: To reduce the risk of injury, make sure children sit
where they can be properly restrained.

How does the airbag supplemental restraint system work?

The airbag SRS is designed to
activate when the vehicle sustains
sufficient longitudinal deceleration.

The fact that the airbags did not
inflate in a collision does not mean
that something is wrong with the
system. Rather, it means the forces
were not of the type sufficient to
cause activation. Airbags are
designed to inflate in frontal and
near-frontal collisions, not rollover,
side-impact, or rear-impacts.

CIMS #1062867

com_children.mbs

itdseq=120

CIMS #683852

com_how_work.mbs

itdseq=121

art=mbsss114_a

art=comss002_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 94 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

The airbags inflate and deflate
rapidly upon activation. After airbag
deployment, it is normal to notice a
smoke-like, powdery residue or
smell the burnt propellant. This may
consist of cornstarch, talcum
powder (to lubricate the bag) or
sodium compounds (e.g., baking
soda) that result from the
combustion process that inflates the
airbag. Small amounts of sodium
hydroxide may be present which
may irritate the skin and eyes, but
none of the residue is toxic.

While the system is designed to help
reduce serious injuries, it may also
cause minor abrasions, swelling or temporary hearing loss. Because
airbags must inflate rapidly and with considerable force, there is the risk
of death or serious injuries such as fractures, facial and eye injuries or
internal injuries, particularly to occupants who are not properly
restrained or are otherwise out of position at the time of airbag
deployment. Thus, it is extremely important that occupants be properly
restrained as far away from the airbag module as possible while
maintaining vehicle control.

WARNING: Several airbag system components get hot after
inflation. Do not touch them after inflation or you may be
burned.

WARNING: If the air bag has deployed, the air bag will not
function again and must be replaced immediately. If the air bag
is not replaced, the unrepaired area will increase the risk of
injury in a collision.

Determining if the system is operational

The SRS uses readiness lights in the instrument cluster or a tone to
indicate the condition of the system. Refer to the Airbag readiness
section in the Instrumentation chapter. Routine maintenance of the
airbag is not required.

A difficulty with the system is indicated by one or more of the following:

CIMS #683853

com_deter_operational.mbs

itdseq=122

art=comss003_b

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 95 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

• The readiness lights will either

flash or stay lit.

• The readiness lights will not

illuminate immediately after
ignition is turned on.

• A series of five beeps will be heard. The tone pattern will repeat

periodically until the problem and/or light are repaired.

If any of these things happen, even intermittently, have the SRS serviced
at your authorized Mazda dealership immediately.

WARNING: Unless serviced, the system may not function
properly in the event of a collision.

Disposal of airbags and airbag equipped vehicles (including safety
belt pretensioners)

For disposal of safety belt pretensioners, airbags, or airbag equipped
vehicles, see your authorized Mazda dealership or qualified technician.
Airbags MUST BE disposed of by qualified personnel.

Front passenger sensing system

The front passenger sensing system will turn off the front passenger’s
frontal air bag under certain conditions. The driver’s frontal air bag is not
part of the front passenger sensing system. The front passenger sensing
system works with sensors that are part of the front passenger’s seat and
safety belt. The sensors are designed to detect the presence of a
properly seated occupant and determine if the front passenger’s frontal
air bag should be enabled (may inflate) or not.

The front passenger sensing system is designed to meet the regulatory
requirements of Federal Motor Vehicle Safety Standard (FMVSS) 208
and is designed to turn off the front passenger’s frontal air bag if:
• the front passenger seat is unoccupied, or has small/medium objects in

the front seat,

• the system determines that a small child is present in a rear-facing

child seat that is installed according to the manufacturer’s instructions.

• the system determines that a small child is present in a forward-facing

child restraint that is installed according to the manufacturer’s
instructions,

• the system determines that a small child is present in a booster seat,

CIMS #683854

com_disposing.mbs

itdseq=123

CIMS #1534973

com_tell-tale.ran

itdseq=124

art=ranis319_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 96 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

• a front passenger takes his/her weight off of the seat for a period of

time,

WARNING: Even with Advanced Restraints Systems, children
12 and under should be properly restrained in the back seat (if
equipped).

When the front passenger seat is occupied and the sensing system has
turned off the passenger’s frontal air bag, the

9passenger air bag off9 or

9pass air bag off9 indicator will light and stay lit to remind you that the

front passenger frontal air bag is off. When the front passenger seat is
not occupied (empty seat) or in the event that the front passenger
frontal air bag is enabled (may inflate), the indicator light will be unlit.

The indicator light is located in the
center stack of the instrument
panel. To confirm the

9pass airbag

light

9 is functional, it will

momentarily illuminate when the
ignition is turned to the ON
position.

The front passenger sensing system is designed to turn off the front
passenger’s frontal air bag when a rear facing child seat, a forward-facing
child restraint, or a booster seat is detected. If the child restraint has
been installed and the indicator is not lit, then turn the vehicle off,
remove the child restraint from the vehicle and reinstall the restraint
following the child restraint manufacturer’s directions.

The front passenger sensing system is designed to enable (may inflate)
the right front passenger’s frontal air bag anytime the system senses that
a person of adult size is sitting properly in the front passenger seat.
When the passenger sensing system has allowed the air bag to be
enabled, the indicator will be unlit and stay unlit to remind you that the
air bag is enabled (may inflate).

If a person of adult-size is sitting in the front passenger’s seat, but the

9passenger air bag off9 or 9pass air bag off9 indicator is lit, it could be
that the person isn’t sitting properly in the seat. If this happens, turn the
vehicle off and ask the person to place the seatback in the full upright
position, then sit upright in the seat, centered on the seat cushion, with
the person’s legs comfortably extended. Restart the vehicle and have the
person remain in this position for about two minutes. This will allow the
system to detect that person and then enable the passenger’s air bag. If
the indicator lamp remains lit even after this, then the occupant should
be advised to ride in the back seat.

art=dnoss529_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 97 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

Occupant

Pass Airbag Off
Indicator Lamp

Passenger Airbag

Empty seat

Unlit

Disabled

Small child in child
safety seat or booster

Lit

Disabled

Small child with safety
belt buckled or
unbuckled

Lit

Disabled

Adult

Unlit

Enabled

After all occupants have adjusted their seats and put on safety belts, it’s
very important that they continue to sit upright, with their back against
the seatback, with their feet comfortably extended on the floor while the
vehicle is still in motion. Sitting improperly can increase the chance of
injury in a crash event. For example, if an occupant slouches, lies down,
turns sideways, sits forward, leans forward or sideways, or puts one or
both feet up, the chance of injury during a crash is greatly increased.

WARNING: Sitting improperly out of position or with the seat
back reclined too far can take off weight from the seat cushion
and affect the decision of the front passenger sensing system,
resulting in serious injury or death in a crash.
Always sit upright against your seatback, with your feet on the
floor.

In case there is a problem with the
passenger sensing system, the
airbag readiness lamp in the
instrument cluster will stay lit. Do
NOT attempt to repair or service the system; take your vehicle
immediately to the dealer.

WARNING: The front passenger airbag is not designed to offer
protection to an occupant in the center seating position.

WARNING: An out of position front center occupant could
affect the decision of the front passenger sensing system.

If it is necessary to modify an advanced front airbag system to
accommodate a person with disabilities, contact the Mazda Customer

art=dewii019_a

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 98 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

Relationship Center at the phone number shown in the Customer
Assistance section of this Owner’s Guide.

The front passenger sensing system may detect small or medium objects
placed on the seat cushion. For most objects that are in the front
passenger seat, the passenger airbag will be disabled. Even though the
passenger airbag is disabled, the

9pass airbag off9 light may or may not

be illuminated according to the table below.

Objects

Pass Airbag Off
Indicator Lamp

Passenger Airbag

Small (i.e. 3 ring
binder, small purse,
bottled water)

Unlit

Disabled

Medium (i.e. heavy
briefcase, fully packed
luggage)

Lit

Disabled

Empty seat, or small
to medium object with
safety belt buckled

Lit

Disabled

WARNING: Any alteration/modification to the front passenger
seat may affect the performance of the front passenger sensing
system.

SAFETY RESTRAINTS FOR CHILDREN

See the following sections for directions on how to properly use safety
restraints for children. Also see Airbag supplemental restraint system
(SRS) in this chapter for special instructions about using airbags.

Important child restraint precautions

NOTE: You are required by law to use a child-restraint system in the
U.S. and Canada. Many states require that children use approved booster
seats until they are eight years old. Check your local and state or
provincial laws for specific requirements regarding the safety of children
in your vehicle.

WARNING: Never let a passenger hold a child on his or her lap
while the vehicle is moving. The passenger cannot protect the
child from injury in a collision.

CIMS #52677

com_safety-for-kids

itdseq=125

CIMS #683856

com_imp_precautions.mbs

itdseq=126

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 99 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

NOTE: Always follow the instructions and warnings that come with any
infant or child restraint you might use.

WARNING: Do not install a child seat in a center facing jump
seat.

Children and safety belts

If the child is the proper size, restrain the child in a safety seat.

Children who are too large for child safety seats (as specified by your
child safety seat manufacturer) should always wear safety belts.

Follow all the important safety restraint and airbag precautions that
apply to adult passengers in your vehicle.

If the shoulder belt portion of a combination lap and shoulder belt can
be positioned so it does not cross or rest in front of the child’s face or
neck, the child should wear the lap and shoulder belt. Moving the child
closer to the center of the vehicle may help provide a good shoulder belt
fit.

WARNING: Do not leave children, unreliable adults, or pets
unattended in your vehicle. Leaving a child or an animal
unattended in a parked vehicle is dangerous. In hot weather,
temperatures inside a vehicle can become high enough to cause
brain damage or even death. Always take all children and
animals with you or leave a responsible person with them.
Leaving children in a vehicle with the ignition key is dangerous.
This could result in someone being badly injured or even killed.
They could play with power windows or other controls, or even
make the vehicle move. Don’t leave the keys in your vehicle
with children.

Child booster seats

Children outgrow a typical convertible or toddler seat when they weigh
40 pounds and are around 4 years of age. Although the lap/shoulder belt
will provide some protection, these children are still too small for
lap/shoulder belts to fit properly, which could increase the risk of serious
injury.

To improve the fit of both the lap and shoulder belt on children who
have outgrown child safety seats, Mazda recommends use of a
belt-positioning booster seat.

CIMS #1065521

com_safety_belts.mbs

itdseq=127

CIMS #992731

com_booster_seat.mazda

itdseq=128

REVIEW COPY ——
2007 B-Series (mbs), Owners Guide (post-2002-fmt) (own2002), Market: USA (fus)

PAGE: 100 OP: root EDIT SESSION: 1 DATE: AUG 3 2006 at 11:45 JOB: @ibm2/ford_pdm/CLS_ford/GRP_own2002/JOB_mbs/DIV_og

Seating and Safety Restraints

100

Mazda B4000 Truck (2007 year). Instruction - part 6
