Mazda 2 (2017 year). Instruction

7–38

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

Signal

Warning

Power Steering

Malfunction Indicator

Light

The light illuminates/

À ashes if the electric power steering has a malfunction.

If the light illuminates/

À ashes, stop the vehicle in a safe place and do not operate the

steering wheel. There is no problem if the light turns off after a while. Contact an
expert repairer, we recommend an Authorised Mazda Repairer if the light illuminates/
À ashes continuously.

NOTE

If the indicator light illuminates/

À ashes, the power steering will not operate

normally. In this happens, the steering wheel can still be operated, however, the
operation may feel heavy compared to normal, or the steering wheel could vibrate
when turning.

Repeatedly jerking the steering wheel left and right while the vehicle is stopped
or moving extremely slowly will cause the power steering system to go into
protective mode which will make the steering feel heavy, but this does not indicate
a problem. If this occurs, park the vehicle safely and wait several minutes for the
system to return to normal.

Contact Authorised Mazda Repairer and Have Vehicle Inspected

If any of the following warning lights turns on/

À ashes, the system may have a malfunction.

Contact an expert repairer, we recommend an Authorised Mazda Repairer to have your
vehicle inspected.

Signal

Warning

ABS Warning Light

If the ABS warning light stays on while you're driving, the ABS control unit has detected a
system malfunction. If this occurs, your brakes will function normally as if the vehicle had
no ABS.
Should this happen, consult an expert repairer, we recommend an Authorised Mazda
Repairer as soon as possible.

NOTE

When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS

warning light may illuminate. If this occurs, it is the result of the weak battery and
does not indicate an ABS malfunction.

(With DSC vehicles)

The brake assist system does not operate while the ABS warning light is illuminated.

7–39

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Signal

Warning

Master Warning

Light

Vehicles with type B audio

      The light turns on when the system has a malfunction.
  Operate the centre display and verify the content.
  Refer to If a Warning Light Turns On or Flashes on page 7-35 .

Vehicles with type A audio

The light illuminates continuously if any one of the following occurs. Consult an expert
repairer, we recommend an Authorised Mazda Repairer.

There is a malfunction in the battery management system.

There is a malfunction in the brake switch.

(SKYACTIV-D 1.5)

There is a malfunction in the engine's hydraulic control.

There is a malfunction in the engine's timing chain.

There is a malfunction in the blow-by heater.

There is a malfunction in the oil level sensor.

Check Engine Light

If this light illuminates while driving, the vehicle may have a problem. It is important to
note the driving conditions when the light illuminated and consult an expert repairer, we
recommend an Authorised Mazda Repairer.
The check engine light may illuminate in the following cases:

The engine's electrical system has a problem.

The emission control system has a problem.

(SKYACTIV-G 1.3, SKYACTIV-G 1.5)

The fuel tank level being very low or approaching empty.

The fuel-

¿ ller cap is missing or not tightened securely.

If the check engine light remains on, or it

À ashes continuously , do not drive at high speeds

and consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as
possible.

(Amber)

i-stop warning light

When the light is turned on

A problem in the system may be indicated under the following conditions. Have your
vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer.

The light does not turn on when the ignition is switched ON.

The light continues to remain on even though the i-stop OFF switch has been pressed
while the engine is running.

When the light is

À ashing

The light continues to

À ash if the system has a malfunction. Have your vehicle inspected at

an expert repairer, we recommend an Authorised Mazda Repairer.

(Amber)

i-ELOOP Warning

Light

The light turns on if there is any malfunction in the i-ELOOP system. Consult an expert
repairer, we recommend an Authorised Mazda Repairer.

7–40

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Signal

Warning

Automatic

Transaxle Warning

Light

The light illuminates when the transaxle has a problem.

CAUTION

If the automatic transaxle warning light illuminates, the transaxle has an electrical
problem. Continuing to drive your Mazda in this condition could cause damage to your
transaxle. Consult an expert repairer, we recommend an Authorised Mazda Repairer as
soon as possible.

(Turns on)

TCS/DSC Indicator

Light

If the light stays on, the TCS, DSC or the brake assist system may have a malfunction and
they may not operate correctly. Take your vehicle to an expert repairer, we recommend an
Authorised Mazda Repairer.

Air Bag/Seat Belt

Pretensioner System

Warning Light

A system malfunction is indicated if the warning light constantly

À ashes, constantly

illuminates or does not illuminate at all when the ignition is switched ON. If any of these
occur, consult an expert repairer, we recommend an Authorised Mazda Repairer as soon as
possible. The system may not operate in an accident.

WARNING

Never tamper with the air bag/pretensioner systems and always have an expert
repairer, we recommend an Authorised Mazda Repairer perform all servicing and
repairs:
Self-servicing or tampering with the systems is dangerous. An air bag/pretensioner
could accidentally activate or become disabled causing serious injury or death.

7–41

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Signal

Warning

(Flashing)

Tyre Pressure

Monitoring System

Warning Light

If the tyre pressure monitoring system has a malfunction, the tyre pressure warning
light

À ashes for about 1 minute when the ignition is switched ON and then continues

illuminating. Have your vehicle checked by an expert repairer, we recommend an
Authorised Mazda Repairer as soon as possible.

WARNING

If the tyre pressure monitoring system warning light illuminates or

À ashes, or the tyre

pressure warning beep sound is heard, decrease vehicle speed immediately and avoid
sudden manoeuvring and braking:
If the tyre pressure monitoring system warning light illuminates or

À ashes, or the

tyre pressure warning beep sound is heard, it is dangerous to drive the vehicle at high
speeds, or perform sudden manoeuvring or braking. Vehicle drivability could worsen
and result in an accident.
To determine if you have a slow leak or a

À at, pull over to a safe position where you

can check the visual condition of the tyre and determine if you have enough air
to proceed to a place where air may be added and the system monitored again by
an expert repairer, we recommend an Authorised Mazda Repairer or a tyre repair
station.

Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is dangerous, even if you know why it is
illuminated. Have the problem taken care of as soon as possible before it develops
into a more serious situation that could lead to tyre failure and a dangerous accident.

(Red)

(Turns on)

KEY Warning Light

If any malfunction occurs in the keyless entry system, it illuminates continuously.

CAUTION

If the key warning indicator light illuminates or the push button start indicator light
(amber)

À ashes, the engine may not start. If the engine cannot be started, try starting it

using the emergency operation for starting the engine, and have the vehicle inspected at
an expert repairer, we recommend an Authorised Mazda Repairer as soon as possible.

Refer to Emergency Operation for Starting the Engine on page 4-11 .

Security Indicator

Light

If the engine does not start with the correct key, and the security indicator light remains
illuminated or

À ashing, try the following:

Make sure the key is within the operational range for signal transmission. Switch the
ignition off, and then restart the engine. If the engine does not start after 3 or more tries,
contact an expert repairer, we recommend an Authorised Mazda Repairer.

(Amber)

High Beam Control

System (HBC)

Warning Light

The light remains turned on if there is a problem with the system. Have your vehicle
inspected at an expert repairer, we recommend an Authorised Mazda Repairer.

NOTE

If the windscreen area in front of the Forward Sensing Camera (FSC) is fogged or
obstructed, the light turns on temporarily. If the light remains turned on, there may be a
problem with the system.

7–42

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Signal

Warning

(Amber)

Adaptive LED

Headlights (ALH)

Warning Light

The light remains turned on if there is a problem with the system. Have your vehicle
inspected at an expert repairer, we recommend an Authorised Mazda Repairer.

NOTE

If the windscreen area in front of the Forward Sensing Camera (FSC) is fogged or
obstructed, the light turns on temporarily. If the light remains turned on, there may be a
problem with the system.

Lane Departure

Warning System

(LDWS) Warning

Light

The warning light remains turned on if there is a problem with the system. Have your
vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer.

The LDWS does not operate when the warning light illuminates.

CAUTION

A problem in the system may be indicated under the following conditions. Have your
vehicle inspected at an expert repairer, we recommend an Authorised Mazda Repairer.

  When the light remains turned on while driving the vehicle.
  When the system is cancelled automatically, the light turns on. Normally, the system
restores automatically and the light turns off, however, if the light remains turned on,
there may be a problem with the system.

The light does not illuminate when the ignition is switched ON.

Always use tyres for all wheels that are of the speci

¿ ed size, and the same

manufacture, brand, and tread pattern. In addition, do not use tyres with signi

¿ cantly

different wear patterns on the same vehicle. If such improper tyres are used, the
LDWS may not operate normally.

When an emergency spare tyre is used, the system may not operate normally.

NOTE

If the windscreen area in front of the Forward Sensing Camera (FSC) is fogged or
obstructed, the light turns on temporarily. If the light remains turned on, there may be a
problem with the system.

Blind Spot

Monitoring (BSM)

OFF Indicator

Light

A problem in the system may be indicated under the following conditions.
Have your vehicle inspected at an expert repairer, we recommend an Authorised Mazda
Repairer.

The light does not turn on when the ignition is switched ON.

The light remains on even when the Blind Spot Monitoring (BSM) system can be
operated.

The light turns on while driving the vehicle.

NOTE

If the vehicle is driven on a road with less traf

¿ c and few vehicles that the radar sensors

can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF indicator
light in the instrument cluster illuminates). However, it does not indicate a malfunction.

7–43

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Signal

Warning

(Amber)

Mazda Radar Cruise

Control (MRCC)

Warning Light

The warning light turns on if there is a malfunction in the system while the Mazda Radar
Cruise Control (MRCC) system is on. Have your vehicle inspected at an expert repairer, we
recommend an Authorised Mazda Repairer.

LED Headlight
Warning Light

This light illuminates if there is a malfunction in the LED headlight. Have your vehicle
inspected by an expert repairer, we recommend an Authorised Mazda Repairer.

Taking Action

Take the appropriate action and verify that the warning light turns off.

Signal

Warning

Action to be taken

Low Fuel

Warning Light

The light turns on when the remaining fuel is
about 9.0 L (2.3 US gal, 1.9 Imp gal).

NOTE

The light illumination timing may vary
because fuel inside the fuel tank moves
around according to the driving conditions
and the vehicle posture.

Add fuel.

7–44

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Signal

Warning

Action to be taken

Seat Belt

Warning Light

(Front seat)

The seat belt warning light turns on if the
driver or front passenger's seat is occupied
and the seat belt is not fastened with the
ignition switched ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger
seat is occupied) and the vehicle is driven at
a speed faster than about 20 km/h (12 mph),
the warning light

À ashes. After a short time,

the warning light stops

À ashing, but remains

illuminated. If a seat belt remains unfastened,
the warning light

À ashes again for a given

period of time.

NOTE

If the driver or front passenger's seat
belt is unfastened after the warning light
turns on, and the vehicle speed exceeds
20 km/h (12 mph), the warning light
À ashes again.

Placing heavy items on the front
passenger's seat may cause the front
passenger's seat belt warning function
to operate depending on the weight of
the item.

To allow the front passenger's seat
weight sensor to function properly, do
not place and sit on an additional seat
cushion on the front passenger's seat.
The sensor may not function properly
because the additional seat cushion could
cause sensor interference.

If a small child is seated on the front
passenger's seat, the warning light may
not operate.

Fasten the seat belts.

(Red)

Seat Belt

Warning Light

(Rear seat)

If the rear seat belts are not fastened while the
ignition is switched ON , the driver and the
passenger are alerted by the warning light.
The warning light operates even if there is no
passenger on the rear seat.

NOTE

If a rear seat belt is not fastened by a
certain period of time after the engine has
been started, the warning light turns off.

Fasten the seat belts.

7–45

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Signal

Warning

Action to be taken

Door-Ajar

Warning Light

The light turns on if any door/liftgate/boot lid
is not closed securely.

Close the door/liftgate/boot lid securely.

Low Washer

Fluid Level

Warning Light

This warning light indicates that little washer
À uid remains.

Add washer

À uid (page 6-32 ).

120km/h

Warning Light

The 120 km/h warning light illuminates when
the vehicle speed exceeds 120 km/h.

Lower the vehicle speed.

7–46

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Signal

Warning

Action to be taken

(Turns on)

Tyre Pressure

Monitoring

System Warning

Light

When the warning light illuminates, and
the warning beep sound is heard (about 3
seconds), tyre pressure is too low in one or
more tyres.

WARNING

If the tyre pressure monitoring system
warning light illuminates or

À ashes,

or the tyre pressure warning beep
sound is heard, decrease vehicle
speed immediately and avoid sudden
manoeuvring and braking:
If the tyre pressure monitoring system
warning light illuminates or

À ashes, or

the tyre pressure warning beep sound
is heard, it is dangerous to drive the
vehicle at high speeds, or perform
sudden manoeuvring or braking. Vehicle
drivability could worsen and result in an
accident.
To determine if you have a slow leak or
a

À at, pull over to a safe position where

you can check the visual condition of the
tyre and determine if you have enough
air to proceed to a place where air may
be added and the system monitored again
by an expert repairer, we recommend
an Authorised Mazda Repairer or a tyre
repair station.

Do not ignore the TPMS Warning Light:
Ignoring the TPMS warning light is
dangerous, even if you know why it is
illuminated. Have the problem taken
care of as soon as possible before it
develops into a more serious situation
that could lead to tyre failure and a
dangerous accident.

Inspect the tyres and adjust to the speci

¿ ed

À ation pressure (page 6-44 ).

NOTE

Perform tyre pressure adjustment when

the tyres are cold. Tyre pressure will
vary according to the tyre temperature,
therefore let the vehicle stand for
1 hour or only drive it 1.6 km (1 mile) or
less before adjusting the tyre pressures.
When pressure is adjusted on hot tyres
to the cold in

À ation pressure, the TPMS

warning light/beep may turn on after
the tyres cool and pressure drops below
speci

¿ cation.

Also, an illuminated TPMS warning
light, resulting from the tyre air
pressure dropping due to cold ambient
temperature will remain illuminated
even if the ambient temperature rises.
In this case, it will also be necessary to
adjust the tyre air pressures. If the TPMS
warning light illuminates due to a drop in
tyre air pressure, make sure to check and
adjust the tyre air pressures.

Tyres lose air naturally over time and

the TPMS cannot tell if the tyres are
getting too soft over time or you have
a

À at. However, when you ¿ nd one low

tyre in a set of four-that is an indication
of trouble; you should have someone
drive the vehicle slowly forward so you
can inspect any low tyre for cuts and any
metal objects sticking through tread or
sidewall. Put a few drops of water in the
valve stem to see if it bubbles indicating
a bad valve. Leaks need to be addressed
by more than simply rein

À ating the

tyre as leaks are dangerous — take it to
an expert repairer, we recommend an
Authorised Mazda Repairer.

7–47

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Signal

Warning

Action to be taken

(Amber)

Smart Brake

Support/Smart

City Brake

Support (SBS/

SCBS) Warning

Light

The light turns on if the windscreen or
the radar sensor are dirty, or there is a
malfunction in the system.

Vehicles with type B audio

  Verify the reason why the warning light
is illuminated on the centre display (page
7-35 ).
  If the reason why the warning light is
illuminated is due to a dirty windscreen, clean
the windscreen.
  If the warning light is illuminated because of
a dirty radar sensor, clean the front emblem.
  For any other reasons, have the vehicle
inspected at an expert repairer, we recommend
an Authorised Mazda Repairer.

Vehicles with type A audio

If the reason why the warning light is
illuminated is due to a dirty windscreen, clean
the windscreen. For any other reasons, have
the vehicle inspected at an expert repairer, we
recommend an Authorised Mazda Repairer.

KEY Warning Light

Take the appropriate action and verify that the warning light turns off.

Signal

Cause

Action to be taken

(Red)

(Flashing)

The advanced key battery is dead.

Replace the key battery (page 6-41 ).

The advanced key is not within the
operation range.

Bring the advanced key into the operation
range (page 3-7 ).

The advanced key is placed in areas inside
the cabin where it is dif

¿ cult for the key to

be detected.

A key from another manufacturer similar to
the advanced key is in the operation range.

Take the key from another manufacturer
similar to the advanced key out of the
operation range.

Without the ignition switched off, the
advanced key is taken out of the cabin, and
then all the doors are closed.

Bring the advanced key back into the
cabin.

7–48

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Message Indicated on Display

If a message is displayed in the centre display (Type B audio), take appropriate action (in a
calm manner) according to the displayed message.

(Display example)

Stop Vehicle in Safe Place Immediately

If the following messages are displayed in the centre display (Type B audio), a vehicle
system may be malfunctioning. Stop the vehicle in a safe place and contact an Authorised
Mazda Repairer.

Display

Indicated Condition

Displays if the engine coolant temperature has increased
excessively.

Displays if the charging system has a malfunction.

7–50

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

Warning Sound is
Activated

Lights-On Reminder

If lights are on and the ignition is switched
to ACC or off, a continuous beep sound
will be heard when the driver's door is
opened.

NOTE

When the ignition is switched to

ACC, the “Ignition Not Switched
Off (STOP) Warning Beep” (page
7-51 ) overrides the lights-on
reminder.

A personalised function is available

to change the sound volume for the
lights-on reminder.

Refer to Personalisation Features on

page 9-13 .

Air Bag/Seat Belt Pretensioner

System Warning Beep

If  there  is  a  problem  with  the  air  bag/seat
belt pretensioner systems and the warning
light illumination, a warning beep sound
will be heard for about 5 seconds every
minute.

  The air bag and seat belt pretensioner
system warning beep sound will continue
to be heard for approximately 35 minutes.
Have your vehicle inspected at an expert
repairer, we recommend an Authorised
Mazda Repairer as soon as possible.

WARNING

Do not drive the vehicle with the air
bag/seat belt pretensioner system
warning beep sounding:
Driving the vehicle with the air bag/
seat belt pretensioner system warning
beep sounding is dangerous. In a
collision, the air bags and the seat belt
pretensioner system will not deploy and
this could result in death or serious
injury. Contact an expert repairer,
we recommend an Authorised Mazda
Repairer to have the vehicle inspected
as soon as possible.

Seat Belt Warning Beep

Front seat

If the vehicle speed exceeds about
20 km/h (12 mph) with the driver or front
passenger's seat belt unfastened, a warning
beep sounds continuously. If the seat belt
remains unfastened, the beep sound stops
once and then continues for about
90 seconds. The beep stops after the driver
or front passenger's seat belt is fastened.

7–51

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

NOTE

Placing heavy items on the front

passenger seat may cause the front
passenger seat belt warning function
to operate depending on the weight
of the item.

To allow the front passenger seat

weight sensor to function properly,
do not place and sit on an additional
seat cushion on the front passenger
seat. The sensor may not function
properly because the additional
seat cushion could cause sensor
interference.

When a small child sits on the front

passenger seat, it is possible that the
warning beep will not operate.

Rear seat

The warning beep only sounds if a seat
belt is unfastened after being fastened.

Ignition Not Switched Off (STOP)

Warning Beep

If the driver's door is opened with the
ignition switched to ACC, a beep will
be heard continuously in the cabin to
notify the driver that the ignition has not
been switched OFF (STOP). Under this
condition, the keyless entry system will
not operate, the vehicle cannot be locked,
and the battery voltage will be depleted.

Key Removed from Vehicle

Warning Beep

Vehicles with advanced keyless function

If the key is taken out of the vehicle while
the ignition is not switched OFF and
all the doors are closed, the beep which
sounds outside of the vehicle will be heard
6 times, the beep which sounds inside
the vehicle will be heard 6 times, and the
KEY warning light (red) in the instrument
cluster

À ashes continuously to notify

the driver that the ignition has not been
switched OFF.

Vehicles without advanced keyless
function

If the key is taken out of the vehicle while
the ignition is not switched OFF and all
the doors are closed, a beep will be heard
in the cabin 6 times and the KEY warning
light (red) in the instrument cluster turns
on continuously to notify the driver that
the ignition has not been switched OFF.

NOTE

Because the key utilizes low-intensity
radio waves, the Key Removed From
Vehicle Warning may activate if the key
is carried together with a metal object
or it is placed in a poor signal reception
area.

Request Switch Inoperable

Warning Beep (With the advanced
keyless function)

If the request switch is pressed with the
door open or ajar, or the ignition is not
switched OFF with a key being carried, a
beep will be heard outside for about
2 seconds to notify the driver that the door
or liftgate/boot lid cannot be locked.

7–52

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Key Left-in-luggage Compartment/

Boot Warning Beep (With the
advanced keyless function)

If the key is left in the luggage
compartment/boot with all the doors
locked and the liftgate/boot lid closed, a
beep will be heard outside for about
10 seconds to notify the driver that the
key is in the luggage compartment/boot.
In this case, take out the key by pressing
the electric liftgate/boot lid opener and
opening the liftgate/boot lid. The key
taken out of the luggage compartment/
boot may not operate because its functions
have been temporarily stopped. To restore
the key's functions, perform the applicable
procedure (page 3-8 ).

Key Left-in-vehicle Warning Beep

(With the advanced keyless
function)

If all the doors and luggage compartment/
boot are locked using another key while
the key is left in the cabin, the beep
which sounds outside of the vehicle will
be heard for about 10 seconds to notify
the driver that the key is in the cabin. In
this case, take out the key by opening the
door. A key taken out of the vehicle using
this method may not operate because its
functions have been temporarily stopped.
To restore the key's functions, perform the
applicable procedure (page 3-8 ).

Electronic Steering Lock Warning

Beep

The warning beep operates if the steering
wheel is not unlocked after the push button
start is pressed. (page 4-4 )

i-stop Warning Beep

If the driver's door is opened while

engine idling is stopped, the warning
sound operates to notify the driver that
engine idling is stopped. It stops when
the driver's door is closed.

The warning sound operates if the

following operations are performed
while the engine idling is stopped. In
such cases, the engine does not restart
automatically to ensure safety. Start the
engine using the normal method.

(European model)

The driver's seat belt is unfastened and

the driver's door is opened.

(Except European model)

(Manual transaxle)

With the shift lever in a position

other than neutral, the driver's seat
belt is unfastened and the driver's
door is opened.

(Automatic transaxle)

With the selector lever in the D or

M (not in second gear

¿ xed mode)

position, the driver's seat belt is
unfastened and the driver's door is
opened.

Vehicle Speed Alarm

The vehicle speed alarm function is
designed to alarm the driver via a single
beep sound and a warning indication in the
instrument cluster that the previously set
vehicle speed has been exceeded.
You can change the vehicle speed setting
at which the warning is triggered.

120 km/h Warning Beep

If the vehicle speed exceeds 120 km/h, a
chime sounds for 5 seconds.

7–53

If Trouble Arises

Warning/Indicator Lights and Warning Sounds

*Some models.

Outside Temperature Warning

Beep

Warns  the  driver  of  the  possibility  of  icy
roads when the outside temperature is low.
  If the outside temperature is lower than
about 4 °C (39 °F) , a beep sound is heard
once and the outside temperature display
À ashes for about ten seconds.
  Refer to Outside Temperature Display on
page   4-31 .

Over Rev. Buzzer

The buzzer sounds to notify the driver if
the engine speed is about to exceed the
permissible engine speed.

CAUTION

Operate the accelerator and shift gears
according to the driving conditions so
that the buzzer does not sound. If the
engine speed exceeds the permissible
engine speed, the engine could be
damaged.

Tyre In

À ation Pressure Warning

Beep

The warning beep sound will be heard
for about 3 seconds when there is any
abnormality in tyre in

À ation pressures

(page 4-190 ).

Power Steering Warning Buzzer

If the power steering system has
a malfunction, the power steering
malfunction light turns on or

À ashes and

the buzzer operates at the same time.
Refer to Warning Lights on page 4-38 .

Blind Spot Monitoring (BSM)

System Warning Beep

Driving forward

The warning beep operates when the
direction indicator lever is operated to
the side where the Blind Spot Monitoring
(BSM) warning light is illuminated.

NOTE

A personalised function is available
to change the Blind Spot Monitoring
(BSM) warning beep sound volume.
Refer to Personalisation Features on
page 9-13 .

Reversing

If a moving object such as a vehicle or
two-wheeled vehicle approaches on the
left or right from behind your vehicle, the
Blind Spot Monitoring (BSM) warning
sound is activated.

Lane Departure Warning Sound

While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.

NOTE

The volume of the LDWS warning

sound can be changed.

Refer to Personalisation Features on

page 9-13 .

The type of the LDWS warning

sound can be changed.

Refer to Personalisation Features on

page 9-13 .

Mazda 2 (2017 year). Instruction - part 40
