Mazda 2 (2017 year). Instruction - part 7

3–26

Before Driving

Fuel and Emission

Fuel and Engine Exhaust Precautions

Fuel Requirements (SKYACTIV-G 1.3, SKYACTIV-G 1.5)

Vehicles  with  catalytic  converters  or  oxygen  sensors  must  use  ONLY  UNLEADED  FUEL,
which will reduce exhaust emissions and keep spark plug fouling to a minimum.

  The vehicle will perform best with fuel listed in the table.

Fuel

Research Octane

Number

Country

Premium unleaded fuel
(Conforming to EN 228
and within E10)

95 or above

New Caledonia, Turkey, Azerbaijan, Armenia, Georgia,
Canary Islands, Reunion, Morocco, Austria, Greece,
Italy, Switzerland, Belgium, Denmark, Finland, Norway,
Portugal, Spain, Sweden, Hungary, Germany, Poland,
Bulgaria, Croatia, Slovenia, Luxembourg, Slovakia,
Latvia, Lithuania, France, Ukraine, Czech, Estonia, Faeroe,
Iceland, Romania, The Netherlands, Macedonia, Bosnia
and Herzegovina, Serbia, Montenegro, Albania, Moldova,
Martinique, F.Guiana, Guadeloupe, Singapore, Hong Kong,
Macau, Malaysia, Brunei, Mauritius, Seychelles, South
Africa, Namibia, Botswana, Swaziland, Lesoto, Bermuda,
Jamaica, Barbados, Antigua, Guatemala, Bolivia, Uruguay,
Honduras, Nicaragua, Aruba, St. Martin, Cyprus, Malta,
Ireland, UK

Premium unleaded fuel
(within E20)

Thailand

Regular unleaded fuel

90 or above

Indonesia, Nepal, Sri Lanka, Fiji, Kenya, Tanzania,
Mozambique, Trinidad and Tobago, Chile, El Salvador,
Costa Rica, Ecuador, Haiti, Colombia, Dominican Republic
(LHD), Panama, Peru, B. Virgin, Curacao

*1 Europe

  Fuel with a lower rating will negatively affect the emission control system performance and
could also cause engine knocking and serious engine damage.

3–27

Before Driving

Fuel and Emission

CAUTION

USE ONLY UNLEADED FUEL.

Leaded fuel is harmful to the catalytic converter and oxygen sensors and will lead to

deterioration of the emission control system and or failures.

The use of E10 fuel with 10 % ethanol in Europe is safe for your vehicle. Damage to

your vehicle may occur when ethanol exceeds this recommendation.

Never add fuel system additives, otherwise the emission control system could be

damaged. Consult an expert repairer, we recommend an Authorised Mazda Repairer
for details.

Fuel Requirements (SKYACTIV-D 1.5)

The vehicle will operate ef

¿ ciently on diesel fuel with speci¿ cation EN590 or the

equivalent.

CAUTION

Never use fuel other than speci

¿ cation EN590 or the equivalent for your vehicle. Use

of petrol or paraf

¿ n in diesel engines will result in engine damage.

Never add fuel system additives. Otherwise, the emission control system could be

damaged. Consult an expert repairer, we recommend an Authorised Mazda Repairer
for details.

NOTE

When refuelling, always add at least 10 L (2.6 US gal, 2.2 Imp gal) of fuel.

3–28

Before Driving

Fuel and Emission

Emission Control System (SKYACTIV-G 1.3, SKYACTIV-G 1.5)

This vehicle is equipped with an emission control system (the catalytic converter is
part of this system) that enables the vehicle to comply with existing exhaust emissions
requirements.

WARNING

Never park over or near anything

À ammable:

Parking over or near anything

À ammable, such as dry grass, is dangerous. Even with

the engine turned off, the exhaust system remains very hot after normal use and could
ignite anything

À ammable. A resulting ¿ re could cause serious injury or death.

CAUTION

Ignoring the following precautions could cause lead to accumulate on the catalyst inside
the converter or cause the converter to get very hot. Either condition will damage the
converter and cause poor performance.

USE ONLY UNLEADED FUEL.

Do not drive your Mazda with any sign of engine malfunction.

Do not coast with the ignition switched off.

Do not descend steep grades in gear with the ignition switched off.

Do not operate the engine at high idle for more than 2 minutes.

Do not tamper with the emission control system. All inspections and adjustments must

be made by a quali

¿ ed technician.

Do not push-start or pull-start your vehicle.

3–29

Before Driving

Fuel and Emission

Emission Control System (SKYACTIV-D 1.5)

Your vehicle is equipped with an emission control system (the catalytic converter is
part of this system) that enables your vehicle to comply with existing exhaust emissions
requirements.

WARNING

Never park over or near anything

À ammable:

Parking over or near anything

À ammable, such as dry grass, is dangerous. Even with

the engine turned off, the exhaust system remains very hot after normal use and could
ignite anything

À ammable. A resulting ¿ re could cause serious injury or death.

CAUTION

Do not drive your Mazda with any sign of engine malfunction.

Do not coast with the ignition switched off.

Do not descend steep grades in gear with the ignition switched off.

Do not operate the engine at high idle for more than 2 minutes.

Do not tamper with the emission control system. All inspections and adjustments must

be made by a quali

¿ ed technician.

Do not push-start or pull-start your vehicle.

3–30

Before Driving

Fuel and Emission

Engine Exhaust (Carbon monoxide)

WARNING

Do not drive your vehicle if you smell exhaust gas inside the vehicle:
Engine exhaust gas is dangerous. This gas contains carbon monoxide (CO), which is
colourless, odourless, and poisonous. When inhaled, it can cause loss of consciousness
and death. If you smell exhaust gas inside the vehicle, keep all windows fully open and
contact an expert repairer, we recommend an Authorised Mazda Repairer immediately.

Do not run the engine when inside an enclosed area:
Running the engine inside an enclosed area, such as a garage, is dangerous. Exhaust
gas, which contains poisonous carbon monoxide, could easily enter the cabin. Loss of
consciousness or even death could occur.

Open the windows or adjust the heating or cooling system to draw fresh air when idling
the engine:
Exhaust gas is dangerous. When the vehicle is stopped with the windows closed and
the engine running for a long time even in an open area, exhaust gas, which contains
poisonous carbon monoxide, could enter the cabin. Loss of consciousness or even death
could occur.

Clear snow from underneath and around your vehicle, particularly the tail pipe, before
starting the engine:
Running the engine when a vehicle is stopped in deep snow is dangerous. The exhaust
pipe could be blocked by the snow, allowing exhaust gas to enter the cabin. Because
exhaust gas contains poisonous carbon monoxide, it could cause loss of consciousness
or even death to occupants in the cabin.

3–31

Before Driving

Fuel and Emission

Fuel-Filler Flap and Cap

WARNING

When removing the fuel-

¿ ller cap,

loosen the cap slightly and wait for any
hissing to stop, then remove it:
Fuel spray is dangerous. Fuel can
burn skin and eyes and cause illness
if ingested. Fuel spray is released
when there is pressure in the fuel tank
and the fuel-

¿ ller cap is removed too

quickly.

Before refuelling, stop the engine, and
always keep sparks and

À ames away

from the

¿ ller neck:

Fuel vapour is dangerous. It could be
ignited by sparks or

À ames causing

serious burns and injuries.
Additionally, use of the incorrect fuel-
¿ ller cap or not using a fuel-¿ ller cap
may result in a fuel leak, which could
result in serious burns or death in an
accident.

Do not continue refuelling after
the fuel pump nozzle shuts off
automatically:
Continuing to add fuel after the fuel
pump nozzle has shut off automatically
is dangerous because over

¿ lling the

fuel tank may cause fuel over

À ow or

leakage. Fuel over

À ow and leakage

could damage the vehicle and if the
fuel ignites it could cause a

¿ re and

explosion resulting in serious injury or
death.

CAUTION

Always use only a designated Mazda
fuel-

¿ ller cap or an approved equivalent,

available at an expert repairer, we
recommend an Authorised Mazda
Repairer. The wrong cap can result in
a serious malfunction of the fuel and
emission control systems.

Fuel-Filler Flap

To open, pull the remote fuel-

¿ ller À ap

release.
To close, press the fuel-

¿ ller À ap until it

locks securely.

Remote fuel-filler flap release

3–32

Before Driving

Fuel and Emission

Fuel-Filler Cap

To remove the fuel-

¿ ller cap, turn it

anticlockwise.
Attach the removed cap to the inner side
of the fuel

À ap.

To close the fuel-

¿ ller cap, turn it

clockwise until a click is heard.

Open

3–33

Before Driving

Steering Wheel

WARNING

Never adjust the steering wheel while
the vehicle is moving:
Adjusting the steering wheel while the
vehicle is moving is dangerous. Moving
it can very easily cause the driver
to abruptly turn to the left or right.
This can lead to loss of control or an
accident.

Steering Wheel Adjustment

To change the angle or length of the
steering wheel:

1. Stop the vehicle, and then pull down

the lock release lever under the steering
column.

Lock release lever

2. Tilt the steering wheel and/or adjust the

steering column length to the desired
positions, then push the lever up to lock
the column.

3. Attempt to push the steering wheel

up and down to make sure it's locked
before driving.

NOTE

Make sure that the steering wheel is
locked

¿ rmly in place. If it is dif¿ cult to

raise the lever, lightly move the steering
wheel forward and back to pull up the
lever.

3–34

Before Driving

Mirrors

*Some models.

Mirrors

Before driving, adjust the inside and
outside mirrors.

Outside Mirrors

WARNING

Be sure to look over your shoulder
before changing lanes:
Changing lanes without taking
into account the actual distance of
the vehicle in the convex mirror is
dangerous. You could have a serious
accident. What you see in the convex
mirror is closer than it appears.

NOTE

(Driver's Side Wide Angle Mirror

)

The wide angle mirror has two

curvatures on its surface separated
by a region line into outer and
inner regions. The inner region is
a standard convex mirror whereas
the outer region allows for a wider
range of visibility within the same
sweep. This combination allows for
better assurance when making lane
changes.

Region line

The perceived distance of objects

in the outer and inner regions of
the wide angle mirror is different.
Objects appearing in the outer region
are actually further away than they
are in the inner region.

3–35

Before Driving

Mirrors

Power mirror adjustment

    The ignition must be switched to ACC or
ON position.

To  adjust:

1. Rotate the mirror switch to the left or

right to choose the left or right side
mirror.

2. Press the mirror switch in the

appropriate direction.

Centre position

Mirror switch

After adjusting the mirror, lock the
control by rotating the switch to the centre
position.

Folding mirror

WARNING

Always return the outside mirrors to
the driving position before you start
driving:
Driving with the outside mirrors folded
in is dangerous. Your rear view will
be restricted, and you could have an
accident.

Manual folding mirror

Fold the outside mirror rearward until it is
À ush with the vehicle.

Power folding mirror

WARNING

Do not touch a power fold-in mirror
while it is moving:
Touching the power fold-in mirror
when it is moving is dangerous. Your
hand could be pinched and injured or
the mirror could be damaged.

Use the power fold-in switch to set the
mirror to the on-road position:
Setting the power fold-in mirror to the
on-road position by hand is dangerous.
The mirror will not lock in position and
will prevent effective rearview visibility.

Only operate the power fold-in mirror
with the vehicle safely parked:
Operating the power fold-in mirror
while the vehicle is moving is
dangerous. Wind blast on the mirror
will cause them to collapse and you will
be unable to return it to the on-road
position, preventing rearview visibility.

3–36

Before Driving

Mirrors

*Some models.

  The ignition must be switched to ACC or
ON position.
   Type A
  To fold, rotate the switch.
  To return the mirror to the driving
position, rotate the switch to the centre
position.

Centre position

   Type B
  To fold the mirrors, press the lower side
of the switch.
  To return the mirrors to their on-road
positions, press the upper side     of the
switch.

Fold in

Fold out

Automatic folding mechanism

The  automatic  folding  mechanism  operates
when the ignition is switched to ACC or
OFF.
  When the outer mirror automatic folding
switch is pressed to the  AUTO  position
(neutral position), the outside mirrors
automatically fold in and out when the
doors are locked and unlocked.
  Also, when the ignition is switched ON or
the engine is started, the outside mirrors
fold out automatically.

NOTE

The outside mirrors may not fold in and
out automatically under cold weather
conditions.
If the outside mirrors do not fold in
and out automatically, remove any ice
or snow, and then press the upper or
lower side of the outer mirror automatic
folding switch to fold the outside
mirrors in or out.

Engine-off outside mirror operation

The outside mirrors can be operated for
about 40 seconds after the ignition is
switched from ON to off.

3–37

Before Driving

Mirrors

Rearview Mirror

WARNING

Do not stack cargo or objects higher
than the seatbacks:
Cargo stacked higher than the
seatbacks is dangerous. It can block
your view in the rearview mirror, which
might cause you to hit another car
when changing lanes.

Rearview mirror adjustment

Before driving, adjust the rearview mirror
to centre on the scene through the rear
window.

Reducing glare from headlights

Adjust the mirror with the antidazzle lever
in the day position.
Push the antidazzle lever forward for day
driving. Pull it back to reduce glare of
headlights from vehicles at the rear.

Antidazzle lever

Day

Night

3–38

Before Driving

Windows

Power Windows

The ignition must be switched ON for the
power windows to operate.

WARNING

Make sure the opening is clear before
closing a window:
Closing a power window is dangerous.
A person's hands, head, or even neck
could be caught by the window and
result in serious injury or even death.
This warning applies especially to
children.

Never allow children to play with power
window switches:
Power window switches that are not
locked with the power window lock
switch would allow children to operate
power windows unintentionally, which
could result in serious injury if a
child's hands, head or neck becomes
caught by the window.

CAUTION

To prevent burning out the fuse and
damaging the power window system,
do not open or close more than three
windows at once.

NOTE

A power window may no longer open/
close if you continue to press the switch
after fully opening/closing the power
window. If the power window does not
open/close, wait a moment and then
operate the switch again.

Operating the Driver's Side Power

Window

Normal opening/closing

    To open the window to the desired
position, lightly hold down the switch.
  To close the window to the desired
position, lightly pull up the switch.

Driver's window

Open

Master control switches

3–39

Before Driving

Windows

Auto-opening/closing

    To fully open the window automatically,
press the switch completely down, then
release. The window will fully open
automatically.
  To fully close the window automatically,
pull the switch completely up, then
release. The window will fully close
automatically.

  To stop the window partway, pull or press
the switch in the opposite direction and
then release it.

Power window system initialization
procedure

If the battery was disconnected during
vehicle maintenance, or for other reasons
(such as a switch continues to be operated
after the window is fully open/closed),
the window will not fully open and close
automatically.
The power window auto function will only
resume on a power window that has been
reset.

1. Switch the ignition ON.
2. Make sure that the power window lock

switch located on the driver's door is
not depressed.

3. Press the switch and fully open the

window.

4. Pull up the switch to fully close the

window and continue holding the
switch for about 2 seconds after the
window fully closed.

Jam-safe window

If a person's hands, head or an object
blocks the window during the auto-closing
operation, the window will stop and open
halfway.

WARNING

Make sure nothing blocks the window
just before it reaches the fully closed
position or while holding up the power
window switch:
Blocking the power window just before
it reaches the fully closed position or
while holding up the power window
switch is dangerous.
In this case, the jam-safe function
cannot prevent the window from
closing all the way. If

¿ ngers are

caught, serious injuries could occur.

NOTE

Depending on driving conditions, a

closing power window could stop
and start opening when the window
feels a shock that is similar to
something blocking it.

In the event the jam-safe function

activates and the power window
cannot be closed automatically, pull
and hold the switch and the window
will close.

The jam-safe window function does

not operate until the system has been
reset.

3–40

Before Driving

Windows

Engine-off power window operation

The power window can be operated for
about 40 seconds after the ignition is
switched from ON to off with all doors
closed. If any door is opened, the power
window will stop operating.

NOTE

For engine-off operation of the power
window, the switch must be held up
¿ rmly throughout window closure
because the auto-closing function will
be inoperable.

Operating the Passenger Power

Windows

    To open the window to the desired
position, hold down the switch.
  To close the window to the desired
position, pull up the switch.

Open

NOTE

The power windows may be operated

when the power window lock switch
on the driver's door is in the unlocked
position.

The passenger windows may be

opened or closed using the master
control switches on the driver's door.

Left rear window

Right rear window

Front
passenger's
window

Driver's window

Master control switches

Some models.

3–41

Before Driving

Windows

*Some models.

Power Window Lock Switch

    This feature prevents all power windows
from operating, except the driver's power
window. Keep this switch in the locked
position while children are in the vehicle.
   Locked position (button depressed):
  Only the driver's power window can be
operated.
   Unlocked position (button not
depressed):
  All power windows on each door can be
operated.
   (Type A)

Locked position

Unlocked position

(Type B)

Locked position

Unlocked position

Manual Windows

To open and close the window turn the
handle on the door.

Open

Content .. 5 6 7 8 ..
