Mazda 2 (2017 year). Instruction - part 5

2–54

Essential Safety Equipment

SRS Air Bags

*Some models.

Side Air Bags

The side air bags are mounted in the outboard sides of the front seatbacks.
When the air bag crash sensors detect a side impact of greater than moderate force, the
system in

À ates the side air bag only on the side in which the vehicle was hit. The side

air bag in

À ates quickly to reduce injury to the driver or front passenger's chest caused by

directly hitting interior parts such as a door or window.
  For more details about air bag deployment, refer to "SRS Air Bag Deployment Criteria"
(page   2-56 ).

Curtain Air Bags

The curtain air bags are mounted in the front and rear window pillars, and the roof edge
along both sides.
When the air bag crash sensors detect a side impact of greater than moderate force, the
curtain air bag in

À ates quickly and helps to reduce injury mainly to the rear outboard

passenger's head caused by directly hitting interior parts such as a door or window.
  For more details about air bag deployment, refer to "SRS Air Bag Deployment Criteria"
(page   2-56 ).

Only one side curtain air bag will deploy on the
side of the vehicle that receives the force of an
impact.

2–55

Essential Safety Equipment

SRS Air Bags

Warning Light/Beep

    A system malfunction or operation conditions are indicated by a warning.
  Refer to Warning/Indicator Lights on page 4-38 .
  Refer to Warning Sound is Activated on page 7-50 .

2–56

Essential Safety Equipment

SRS Air Bags

*Some models.

SRS Air Bag Deployment Criteria

            This chart indicates the applicable SRS equipment that will deploy depending on the type of
collision.
  (The illustrations are the representative cases of collisions.)

SRS

equipment

Types of collision

A severe frontal/near frontal collision

A severe side collision

A rear collision

Front

seat belt

pretensioner

(both sides)

(impact side only)

No air bag and seat belt

pretensioner will be

activated in a rear collision.

Rear seat belt

pretensioner

X (both sides)

Driver air

bag

Front

passenger

air bag

Side air bag

(impact side only)

Curtain air

bag

X (impact side only)

    X : The SRS air bag equipment is designed to deploy in a collision.

*1    (With Front Passenger Air Bag Deactivation Switch)

The front passenger front and side air bags and the front seat belt pretensioner are designed to deploy depending
on the status of the front passenger air bag deactivation switch.

*2 (With Side/Curtain Air Bags)

In a side collision, the front seat belt pretensioners and the side/curtain air bags deploy (only on the side in
which the collision occurs).

2–57

Essential Safety Equipment

SRS Air Bags

NOTE

In a frontal offset collision, the equipped air bags and pretensioners may all deploy
depending on the direction, angle, and rate of impact.

2–58

Essential Safety Equipment

SRS Air Bags

Limitations to SRS Air Bag

In  severe  collisions  such  as  those  described  previously  in  "SRS  Air  Bag  Deployment
Criteria", the applicable SRS air bag equipment will deploy. However, in some accidents,
the equipment may not deploy depending on the type of collision and its severity.

   Limitations to front/near front collision detection:
  The following illustrations are examples of front/near front collisions that may not be
detected as severe enough to deploy the SRS air bag equipment.

Impacts involving trees or poles

Frontal offset impact to the vehicle

Rear-ending or running under a truck's tail gate

2–59

Essential Safety Equipment

SRS Air Bags

   Limitations to side collision detection:
  The following illustrations are examples of side collisions that may not be detected as severe
enough to deploy the SRS air bag equipment.

Side impacts involving trees or poles

Side impacts with two-wheeled vehicles

Roll-over

MEMO

2–60

3–1

*Some models.

3–1

Before Driving

Use of various features, including keys, doors, mirrors and windows.

Keys ...................................................... 3-2

Keys  ...............................................  3-2
Keyless  Entry  System  ....................  3-3

Advanced Keyless Entry System ....... 3-9

Advanced Keyless Entry
System

........................................... 3-9

Operational Range ....................... 3-10

Doors and Locks ................................ 3-11

Door  Locks ...................................  3-11
Liftgate/Boot  Lid  .........................  3-21

Fuel and Emission ............................. 3-26

  Fuel and Engine Exhaust
Precautions ...................................  3-26
  Fuel-Filler Flap and Cap ..............  3-31

Steering Wheel................................... 3-33

Steering Wheel ............................. 3-33

Mirrors ............................................... 3-34

Mirrors ......................................... 3-34

Windows ............................................. 3-38

Power Windows ........................... 3-38
Manual Windows

........................ 3-41

Security System ................................. 3-42

Modi

¿ cation and Add-On

Equipment ....................................  3-42
Immobilizer  System  .....................  3-42
Theft-Deterrent  System

............... 3-44

Driving Tips ....................................... 3-48

Running-In  ...................................  3-48
  Saving Fuel and Protection of the
Environment .................................  3-48
Hazardous  Driving  .......................  3-49
Floor  Mat  .....................................  3-50
Rocking  the  Vehicle  .....................  3-51
Winter  Driving  .............................  3-51
Driving  In  Flooded  Area  ..............  3-54
Turbocharger  Information
(SKYACTIV-D 1.5) .....................  3-55

Towing ................................................ 3-56

Towing Caravans and Trailers
(Europe/Turkey/South Africa) ..... 3-56

3–2

Before Driving

Keys

WARNING

Do not leave the key in your vehicle
with children and keep them in a place
where your children will not

¿ nd or

play with them:
Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed. Children may

¿ nd these keys

to be an interesting toy to play with
and could cause the power windows or
other controls to operate, or even make
the vehicle move.

CAUTION

Because the key (transmitter) uses

low-intensity radio waves, it may
not function correctly under the
following conditions:

The key is carried with

communication devices such as
cellular phones.

The key contacts or is covered by a

metal object.

The key is near electronic devices

such as personal computers.

Non-Mazda genuine electronic

equipment is installed in the
vehicle.

There is equipment which

discharges radio waves near the
vehicle.

The key (transmitter) may consume

battery power excessively if it
receives high-intensity radio waves.
Do not place the key near electronic
devices such as televisions or
personal computers.

To avoid damage to the key

(transmitter), DO NOT:

Drop the key.

Get the key wet.

Disassemble the key.

Expose the key to high

temperatures on places such as the
instrument panel or bonnet, under
direct sunlight.

Expose the key to any kind of

magnetic

¿ eld.

Place heavy objects on the key.

Put the key in an ultrasonic

cleaner.

Put any magnetized objects close

to the key.

3–3

Before Driving

Keys

  A code number is stamped on the plate
attached to the key set; detach this plate
and store it in a safe place (not in the
vehicle) for use if you need to make a
replacement key (auxiliary key).
  Also write down the code number and
keep it in a separate safe and convenient
place, but not in the vehicle.

  If your key (auxiliary key) is lost, consult
your Authorised Mazda Repairer and have
your code number ready.

NOTE

The driver must carry the key to ensure
the system functions properly.

Auxiliary key

Transmitter

Key code number plate

To use the auxiliary key, pull out the
auxiliary key from the transmitter while
pressing the knob.

Knob

Keyless Entry System

This  system  uses  the  key  buttons  to
remotely lock and unlock the doors and
the liftgate/boot lid, and opens the boot lid.
  The system can start the engine without
having to take the key out of your purse or
pocket.
  Operating the theft-deterrent system is
also possible on theft-deterrent system-
equipped vehicles.

  System malfunctions or warnings are
indicated by the following warning lights
or beeps.

KEY Warning Light (Red)

Refer to Warning/Indicator Lights on

page 4-38 .

Ignition Not Switched Off (STOP)

Warning Beep

Refer to Ignition Not Switched Off

(STOP) Warning Beep on page 7-51 .

Key Removed from Vehicle Warning

Beep

Refer to Key Removed from Vehicle

Warning Beep on page 7-51 .

  If you have a problem with the key,
consult an expert repairer, we recommend
an Authorised Mazda Repairer.

  If your key is lost or stolen, consult an
Authorised Mazda Repairer as soon as
possible for a replacement and to make the
lost or stolen key inoperative.

CAUTION

Changes or modi

¿ cations not expressly

approved by the party responsible
for compliance could void the user's
authority to operate the equipment.

3–4

Before Driving

Keys

NOTE

The keyless entry system operation

may vary due to local conditions.

The keyless entry system is fully

operational (door/liftgate/boot lid
lock/unlock) when the ignition is
switched off. The system does not
operate if the ignition is switched to
any position other than off.

If the key does not operate when

pressing a button or the operational
range becomes too small, the
battery may be weak. To install a
new battery, refer to Key Battery
Replacement (page 6-41 ).

Battery life is about one year.

Replace the battery with a new one
if the KEY indicator light (green)
À ashes in the instrument cluster.
Replacing the battery about once
a year is recommended because
the KEY warning light/indicator
light may not illuminate or

À ash

depending on the rate of battery
depletion.

Additional keys can be obtained at

an Authorised Mazda Repairer. Up to
6 keys can be used with the keyless
functions per vehicle. Bring all keys
to an Authorised Mazda Repairer
when additional keys are required.

Transmitter

Operation buttons

Operation indicator light

NOTE

(European models)

The headlights turn on/off by

operating the transmitter. Refer
to Leaving Home Light on page
4-67 .

(With theft-deterrent system)

The hazard warning lights

À ash when

the theft-deterrent system is armed or
turned off.

Refer to Theft-Deterrent System on

page 3-44 .

(With the advanced keyless

function (European models))

The setting can be changed so that a

beep sound is heard for con

¿ rmation

when the doors and the liftgate/boot
lid are locked/unlocked using the
key.

(With the advanced keyless

function (Except European
models))

A beep sound can be heard for

con

¿ rmation when the doors and the

liftgate/boot lid are locked/unlocked
using the key. If you prefer, the beep
sound can be turned off.

The volume of the beep sound can

also be changed.

Refer to Personalisation Features on

page 9-13 .

3–5

Before Driving

Keys

NOTE

Use the following procedure to

change the setting.

1. Switch the ignition off and close

all of the doors and the liftgate/
boot lid.

2. Open the driver's door.
3. Within 30 seconds of opening the

driver's door, press and hold the
LOCK button on the key for 5
seconds or longer.

All of the doors and the liftgate/
boot lid lock and the beep sound
activates at the currently set
volume. The setting changes each
time the LOCK button on the key
is pressed and the beep sound
activates at the set volume. (If the
beep sound has been set to not
activate, it will not activate.)

4. The setting change is completed

by doing any one of the following:

Switching the ignition to ACC

or ON.

Closing the driver's door.

Opening the liftgate/boot lid.

Not operating the key for 10

seconds.

Pressing any button except the

LOCK button on the key.

Pressing a request switch.

The operation indicator light

À ashes when

the buttons are pressed.

Lock button

To lock the doors and the liftgate/boot
lid, press the lock button and the hazard
warning lights will

À ash once.

(With the advanced keyless function
(Except European models))
A beep sound will be heard once.

3–6

Before Driving

Keys

NOTE

(European models)

The doors and the liftgate/boot lid

cannot be locked by pressing the lock
button while any other door is open.
The hazard warning lights will also
not

À ash.

(Except European models)

The doors and the liftgate/boot lid

cannot be locked by pressing the lock
button while any other door or the
liftgate is open. The hazard warning
lights will also not

À ash.

(With the i-stop function

(European models))

Removing the key from the vehicle,

closing all the doors and pressing the
LOCK button on the key while the
i-stop function is operating (engine
is stopped) will switch the ignition
OFF and lock all the doors (Steering
wheel also locks).

Refer to i-stop on page 4-13 .

Make sure all doors and the liftgate/

boot lid are locked after pressing the
button.

(With double locking system)

Pressing the lock button twice within

3 seconds will activate the double
locking system.

Refer to Double Locking System on

page 3-13 .

(With theft-deterrent system)

When the doors are locked by

pressing the lock button on the key
while the theft-deterrent system is
armed, the hazard warning lights will
À ash once to indicate that the system
is armed.

Unlock button

To unlock the doors and the liftgate/boot
lid, press the unlock button and the hazard
warning lights will

À ash twice.

(With the advanced keyless function
(Except European models))
A beep sound will be heard twice.

NOTE

(Auto re-lock function)

After unlocking with the key, all

doors and the liftgate/boot lid
will automatically lock if any of
the following operations are not
performed within about 30 seconds.
If your vehicle has a theft-deterrent
system, the hazard warning lights
will

À ash for con¿ rmation.

The time required for the doors to

lock automatically can be changed.

Refer to Personalisation Features on

page 9-13 .

A door or the liftgate/boot lid is

opened.

The ignition is switched to any

position other than off.

(With theft-deterrent system)

When the doors are unlocked by

pressing the unlock button on the key
while the theft-deterrent system is
turned off, the hazard warning lights
will

À ash twice to indicate that the

system is turned off.

3–7

Before Driving

Keys

*Some models.

Boot button (Saloon)

To open the boot lid, press and hold the
boot button until the boot lid opens.

Type A

Type B

Intrusion sensor cancel button

To cancel the intrusion sensor (part of
the theft-deterrent system), press the
intrusion sensor cancel button within 20
seconds after pressing the lock button and
the hazard warning lights will

À ash three

times.
Refer to Theft-Deterrent System on page
3-44 .

Operational Range

The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.

Starting the Engine

NOTE

Starting the engine may be possible

even if the key is outside of the
vehicle and extremely close to a door
and window, however, always start
the engine from the driver's seat.

If the vehicle is started and the key

is not in the vehicle, the vehicle will
not restart after it is shut off and the
ignition is switched to off.

The luggage compartment/boot is

out of the assured operational range,
however, if the key (transmitter) is
operable the engine will start.

With the advanced keyless function

Interior aerial

Operational range

3–8

Before Driving

Keys

Without the advanced keyless function

Interior aerial

Operational range

NOTE

The engine may not start if the key is
placed in the following areas:

Around the instrument panel

In the storage compartments or the

centre console

On the rear parcel shelf (saloon)

Key Suspend Function

If a key is left in the vehicle, the
functions of the key left in the vehicle are
temporarily suspended to prevent theft of
the vehicle.
To restore the functions, press the unlock
button on the functions-suspended key in
the vehicle.

3–9

Before Driving

Advanced Keyless Entry System

*Some models.

Advanced Keyless Entry
System

WARNING

Radio waves from the key may affect
medical devices such as pacemakers:
Before using the key near people who
use medical devices, ask the medical
device manufacturer or your physician
if radio waves from the key will affect
the device.

  The advanced keyless function allows you
to lock/unlock the door and the liftgate/
boot lid, or open the liftgate/boot lid while
carrying the key.

  System malfunctions or warnings are
indicated by the following warning lights
or beeps.

Request switch Inoperable Warning

Beep

Refer to Request Switch Inoperable

Warning Beep (With the advanced
keyless function) on page 7-51 .

Key Left-in-luggage Compartment/Boot

Warning Beep

Refer to Key Left-in-luggage

Compartment Warning Beep (With the
advanced keyless function) on page
7-52 .

Key Left-in-vehicle Warning Beep

Refer to Key Left-in-vehicle Warning

Beep (With the advanced keyless
function) on page 7-52 .

NOTE

The advanced keyless entry system
functions can be deactivated to prevent
any possible adverse effect on a user
wearing a pacemaker or other medical
device. If the system is deactivated,
you will be unable to start the engine
by carrying the key. Consult an expert
repairer, we recommend an Authorised
Mazda Repairer for details. If the
advanced keyless entry system has been
deactivated, you can start the engine by
following the procedure indicated when
the key battery goes dead.
Refer to Engine Start Function When
Key Battery is Dead on page 4-10 .

Content .. 3 4 5 6 ..
