Mazda 2 (2017 year). Instruction

3–10

Before Driving

Advanced Keyless Entry System

Operational Range

The system operates only when the driver
is in the vehicle or within operational
range while the key is being carried.

NOTE

When the battery power is low, or in
places where there are high-intensity
radio waves or noise, the operational
range may become narrower or
the system may not operate. For
determining battery replacement, Refer
to Keyless Entry System on page
3-3 .

Locking, Unlocking the Doors and

the Liftgate/Boot Lid

Exterior aerial

80 cm(31in)

Operational range

NOTE

The system may not operate if you

are too close to the windows or door
handles, or liftgate/boot lid.

If the key is left in the following

areas and you leave the vehicle, the
doors may be locked depending on
the radio wave conditions even if the
key is left in the vehicle.

Around the instrument panel

In the storage compartments such

as the glove compartment or the
centre console

On the rear parcel shelf (saloon)

Next to a communication device

such as a mobile phone

Opening the Liftgate/Boot Lid

Exterior aerial

80 cm(31in)

Operational range

3–11

Before Driving

Doors and Locks

Door Locks

WARNING

Always take all children and pets with
you or leave a responsible person with
them:
Leaving a child or a pet unattended in
a parked vehicle is dangerous. In hot
weather, temperatures inside a vehicle
can become high enough to cause
brain damage or even death.

Do not leave the key in your vehicle
with children and keep them in a place
where your children will not

¿ nd or

play with them:
Leaving children in a vehicle with the
key is dangerous. This could result in
someone being badly injured or even
killed.

Always close all the windows, lock the
doors and the liftgate/boot lid and take
the key with you when leaving your
vehicle unattended:
Leaving your vehicle unlocked is
dangerous as children could lock
themselves in a hot vehicle, which
could result in death. Also, a vehicle
left unlocked becomes an easy target
for thieves and intruders.

WARNING

After closing the doors and the liftgate/
boot lid, always verify that they are
securely closed:
Doors and the liftgate/boot lid not
securely closed are dangerous, if the
vehicle is driven with a door and the
liftgate/boot lid not securely closed,
the door and the liftgate/boot lid could
open unexpectedly resulting in an
accident.

Always con

¿ rm the safety around the

vehicle before opening a door and the
liftgate/boot lid:
Suddenly opening a door and the
liftgate/boot lid is dangerous. A passing
vehicle or a pedestrian could be hit and
cause an accident.

CAUTION

Always con

¿ rm the conditions around

the vehicle before opening/closing the
doors and the liftgate/boot lid and use
caution during strong winds or when
parked on an incline. Not being aware
of the conditions around the vehicle is
dangerous because

¿ ngers could get

caught in the door and the liftgate/boot
lid or a passing pedestrian could be hit,
resulting in an unexpected accident or
injury.

3–12

Before Driving

Doors and Locks

*Some models.

NOTE

Always stop the engine and lock the

doors. In addition, to prevent theft of
valuables, do not leave them inside
the cabin.

If the key is left in the following

areas and you leave the vehicle, the
doors may be locked depending on
the radio wave conditions even if the
key is left in the vehicle.

Around the instrument panel

In the storage compartments such

as the glove compartment or the
centre console

On the rear parcel shelf (saloon)

Next to a communication device

such as a mobile phone

The vehicle lock-out prevention

feature prevents you from locking
yourself out of the vehicle.

(European models)

All doors and the liftgate/boot lid

will automatically unlock if they are
locked using the power door locks
with any door open.

If all the doors are closed even

though the liftgate/boot lid is open,
all the doors will lock.

(Except European models)

All doors and the liftgate/boot lid

will automatically unlock if they are
locked using the power door locks
with any door or the liftgate open.

NOTE

(Door unlock (control) system with

collision detection)

This system automatically unlocks

the doors and the liftgate/boot lid in
the event the vehicle is involved in
an accident to allow passengers to
get out of the vehicle immediately
and prevent being trapped inside.
While the ignition is switched ON
and in the event the vehicle receives
an impact strong enough to in

À ate

the air bags, all the doors and the
liftgate/boot lid are automatically
unlocked after about 6 seconds have
elapsed from the time of the accident.

The doors and the liftgate/boot lid

may not unlock depending on how
an impact is applied, the force of the
impact, and other conditions of the
accident.

If door-related systems or the battery

is malfunctioning, the doors and the
liftgate/boot lid will not unlock.

3–13

Before Driving

Doors and Locks

*Some models.

Locking, Unlocking with Key

All doors and the liftgate/boot lid lock
automatically when the driver's door is
locked using the auxiliary key. They all
unlock when the driver's door is unlocked
using the auxiliary key.
Turn the auxiliary key toward the front to
lock, toward the back to unlock.

Lock

Unlock

Double Locking System

    The double locking system is designed
to prevent someone who has broken into
your vehicle from opening the door from
the inside.

  If you have any problems with the double
locking system, consult an expert repairer,
we recommend an Authorised Mazda
Repairer.

WARNING

Never activate the double locking
system with passengers, especially
children, still inside the vehicle:
Activating the system with passengers,
especially children, still inside the
vehicle is dangerous. The passengers
cannot open the doors from inside.
They would be trapped and subjected to
extreme temperatures. This could result
in serious injuries or even death.

How to Activate the system

1. Close all the windows.
2. Switch the ignition off and take the key

with you.

3. Close all doors and the liftgate/boot lid.
4. Insert the auxiliary key in the driver's

door, turn the auxiliary key to the lock
position, and return it to the centre
position. Then turn it to the lock
position again within 3 seconds.

Centre
position

Lock
position

3–14

Before Driving

Doors and Locks

NOTE

You can also activate the system

by pressing the lock button on the
transmitter twice within 3 seconds.

(With the advanced keyless

function)

You can also activate the system by

pressing the request switch twice
within 3 seconds.

5. The indicator light illuminates for

about 3 seconds to indicate that the
system has been activated.

NOTE

The system cannot be activated when
any door or the liftgate is open.

How to Deactivate the System

Unlock the driver's door or switch the
ignition ON.

NOTE

If the power supply is interrupted (fuse
blows or the battery is disconnected),
the system can only be deactivated by
unlocking a door with the auxiliary key.

Locking, Unlocking with Request

Switch (With the advanced keyless
function)

All doors and the liftgate/boot lid can be
locked/unlocked by pressing the request
switch while the key is being carried.

Request switch

To lock

To lock the doors and the liftgate/boot lid,
press the request switch and the hazard
warning lights will

À ash once.

(Except European models)
A beep sound will be heard once.

To unlock

To unlock the doors and the liftgate/boot
lid, press the request switch and the hazard
warning lights will

À ash twice.

(Except European models)
A beep sound will be heard twice.

3–15

Before Driving

Doors and Locks

NOTE

Con

¿ rm that all doors and the

liftgate/boot lid are securely locked.

For the liftgate/boot lid, move it

without pressing the electric liftgate/
boot lid opener to verify that the
liftgate/boot lid has not been left ajar.

(European models)

All doors and the liftgate/boot lid

cannot be locked when any door is
open.

(Except European models)

All doors and the liftgate/boot lid

cannot be locked when any door or
the liftgate is open.

It may require a few seconds for

the doors to unlock after the request
switch is pressed.

(European models)

The setting can be changed so that a

beep sound is heard for con

¿ rmation

when the doors and the liftgate/
boot lid are locked/unlocked using a
request switch.

(Except European models)

A beep sound is heard for

con

¿ rmation when the doors and the

liftgate/boot lid are locked/unlocked
using the request switch. If you
prefer, the beep sound can be turned
off.

The volume of the beep sound

can also be changed. Refer to
Personalisation Features on page
9-13 .

NOTE

Use the following procedure to

change the setting.

1. Switch the ignition off and close

all of the doors and the liftgate/
boot lid.

2. Open the driver's door.
3. Within 30 seconds of opening the

driver's door, press and hold the
LOCK button on the key for 5
seconds or longer.

All of the doors and the liftgate/
boot lid lock and the beep sound
activates at the currently set
volume. The setting changes each
time the LOCK button on the key
is pressed and the beep sound
activates at the set volume. (If the
beep sound has been set to not
activate, it will not activate.)

4. The setting change is completed

by doing any one of the following:

Switching the ignition to ACC

or ON.

Closing the driver's door.

Opening the liftgate/boot lid.

Not operating the key for 10

seconds.

Pressing any button except the

LOCK button on the key.

Pressing a request switch.

(With theft-deterrent system)

The hazard warning lights

À ash when

the theft-deterrent system is armed or
turned off.

Refer to Theft-Deterrent System on

page 3-44 .

3–16

Before Driving

Doors and Locks

NOTE

(With double locking system)

The double locking system can

be activated/deactivated using the
request switch.

Refer to Double Locking System on

page 3-13 .

The setting can be changed so that

the doors and the liftgate/boot lid
are locked automatically without
pressing the request switch.

Refer to Personalisation Features on

page 9-13 .

(Auto-lock function)

A beep sound is heard when all

doors and the liftgate are closed
while the advanced key is being
carried. All doors and the liftgate/
boot lid are locked automatically
after about three seconds when
the advanced key is out of the
operational range. Also, the hazard
warning lights

À ash once. (Even

if the driver is in the operational
range, all doors and the liftgate/boot
lid are locked automatically after
about 30 seconds.) If you are out
of the operational range before the
doors and the liftgate/boot lid are
completely closed or another key
is left in the vehicle, the auto-lock
function will not work. Always make
sure that all doors and the liftgate/
boot lid are closed and locked before
leaving the vehicle. The auto-lock
function does not close the power
windows.

NOTE

Auto re-lock function

After unlocking with the request

switch, all doors and the liftgate/boot
lid will automatically lock if any
of the following operations are not
performed within about 30 seconds.
If your vehicle has a theft-deterrent
system, the hazard warning lights
will

À ash for con¿ rmation.

The time required for the doors to

lock automatically can be changed.

Refer to Personalisation Features on

page 9-13 .

Opening a door or the liftgate/boot

lid.

Switching the ignition to any

position other than off.

Locking, Unlocking with

Transmitter

All doors and the liftgate/boot lid can be
locked/unlocked by operating the keyless
entry system transmitter, refer to Keyless
Entry System (page 3-3 ).

3–17

Before Driving

Doors and Locks

*Some models.

Locking, Unlocking with Door-

Lock Switch

All doors and the liftgate/boot lid lock
automatically when the lock side is
pressed with all doors and the liftgate
closed.
They all unlock when the unlock side is
pressed.

Unlock

Lock

NOTE

The doors and the liftgate/boot lid
cannot be locked while any other door
or the liftgate is open.

Auto Lock/Unlock Function

WARNING

Do not pull the inner handle on a front
door:
Pulling the inner handle on a front
door while the vehicle is moving
is dangerous. Passengers can fall
out of the vehicle if the door opens
accidentally , which could result in
death or serious injury.

When the vehicle speed exceeds

20 km/h (12 mph), all doors and the
liftgate/boot lid lock automatically.

When the ignition is switched off, all

doors and the liftgate/boot lid unlock
automatically.

These functions can also be disabled so
that they do not operate.

Auto lock/unlock function setting
change using door-lock switch (With
door-lock switch)

The doors and the liftgate/boot lid can
be set to lock or unlock automatically by
selecting any one of the functions from the
following table and using the door-lock
switch on the interior door panel.

NOTE

Function number 3 in the following

table is the factory setting for your
vehicle.

There are only a total of six auto

lock/unlock settings available for
automatic transaxle vehicles, and
three for manual transaxle vehicles.
Be sure to press the unlock side of
the door-lock switch the correct
number of times according to the
selected function number. If the
switch is mistakenly pressed seven
times on an automatic transaxle
vehicle or four times on a manual
transaxle, the procedure will be
cancelled. If this occurs, start the
procedure from the beginning.

3–18

Before Driving

Doors and Locks

Function

number

Function

The auto door-lock function is
disabled.

All the doors and the liftgate/boot lid
lock automatically when the vehicle
speed is about 20 km/h (12 mph) or
more.

3 (Factory

Setting)

All the doors and the liftgate/boot lid
lock automatically when the vehicle
speed is about 20 km/h (12 mph) or
more. All the doors and the liftgate/
boot lid unlock when the ignition is
switched from ON to Off.

  (Automatic transaxle vehicles only)
  When the ignition is switched ON and
the selector lever is shifted from park
(P) to any other gear position, all the
doors and the liftgate/boot lid lock
automatically.
  When the selector lever is shifted to
park (P) while the ignition is switched
ON, all the doors and the liftgate/boot
lid unlock automatically.

  (Automatic transaxle vehicles only)
  All the doors and the liftgate/boot lid
lock automatically when the vehicle
speed is about 20 km/h (12 mph) or
more.
  When the selector lever is shifted to
park (P) while the ignition is switched
ON, all the doors and the liftgate/boot
lid unlock automatically.

*1 Other settings for the auto door lock function are

available at an expert repairer, we recommend an
Authorised Mazda Repairer. For details consult
an expert repairer, we recommend an Authorised
Mazda Repairer. Refer to Personalisation Features
on page 9-13 .

Settings can be changed using the
following procedure.

1. Safely park the vehicle. All doors must

remain closed.

2. Switch the ignition ON.
3. Press and hold the lock side of the

door-lock switch within 20 seconds of
switching the ignition ON, and make
sure a beep sound is heard about eight
seconds afterwards.

4. Refer to the auto lock/unlock function

setting table, determine the function
number for the desired setting. Press
the unlock side of the door-lock switch
the same number of times as the
selected function number (Ex. If you
select function 2, press the unlock side
of the switch only 2 times).

5. Three seconds after the function setting

has been changed, a beep sound will
beep in the amount of the selected
function number. (Ex. Function number
3 = 3 beep sounds)

(Manual transaxle vehicles)

Press 2 times

Press 3 times

Current Function Number

Function Number 1

Function Number 2

Function Number 3

Press 4 times

Press unlock side of
lock switch once

Cancel setting

Function set (The
number of beeps
heard is the same as
the selected function
number)

Press lock side of
lock switch

Wait for 3 second

3–19

Before Driving

Doors and Locks

(Automatic transaxle vehicles)

Press unlock side of
lock switch once

Press 2 times

Press 3 times

Current Function Number

Function Number 1

Function Number 2

Press 4 times

Function Number 3

Press 5 times

Function Number 4

Press 7 times

Function Number 5

Press 6 times

Function Number 6

Cancel setting

Function set (The
number of beeps
heard is the same as
the selected function
number)

Press lock side of
lock switch

Wait for 3 second

NOTE

The doors cannot be locked or

unlocked while the setting function is
being performed.

The procedure can be cancelled by

pressing the lock side of the door-
lock switch.

Locking, Unlocking with Door-

Lock Knob

Operation from inside

     (With door-lock switch)
  To lock any door from the inside, press the
door-lock knob.
  To unlock, pull it outward.
  This does not operate the other door locks.
   (Without door-lock switch)
  All doors and the liftgate/boot lid lock
automatically when the driver's door-lock
knob is pressed. They all unlock when the
driver's door-lock knob is pulled out.

Lock

Unlock

NOTE

The red indication can be seen when the
door-lock knob is unlocked.

Red indication

3–20

Before Driving

Doors and Locks

Operation from outside

    To lock the rear and front passenger
doors with the door-lock knob from the
outside, press the door-lock knob to the
lock position and close the door (holding
the door handle in the open position is not
required).
  This does not operate the other door locks.

Door-lock knob

NOTE

When locking the door this way:

Be careful not to leave the key inside

the vehicle.

The driver's door lock knob cannot

be used while the driver's door is
open.

Rear Door Child Safety Locks

These  locks  are  intended  to  help  prevent
children from accidentally opening the
rear doors. Use them on both rear doors
whenever a child rides in the rear seat of
the vehicle.

  If you slide the child safety lock to the
lock position before closing that door, the
door cannot be opened from the inside.
The door can only be opened by pulling
the outside handle.

Unlock

Lock

3–21

Before Driving

Doors and Locks

Liftgate/Boot Lid

WARNING

Never allow a person to ride in the
luggage compartment/boot:
Allowing a person to ride in the
luggage compartment/boot is
dangerous. The person in the luggage
compartment/boot could be seriously
injured or killed during sudden braking
or a collision.

Do not drive with the liftgate/boot lid
open:
Exhaust gas in the cabin of a vehicle
is dangerous. An open liftgate/boot lid
in a moving vehicle will cause exhaust
gas to be drawn into the cabin. This
gas contains CO (carbon monoxide),
which is colourless, odourless, and
highly poisonous, and it can cause loss
of consciousness and death. Moreover,
an open liftgate/boot lid could cause
occupants to fall out in an accident.

Do not stack or leave loaded
luggage unsecured in the luggage
compartment:
Otherwise, the luggage may move
or collapse, resulting in injury or an
accident. In addition, do not load
luggage higher than the seatbacks. It
may affect the side or rear

¿ eld of view.

CAUTION

Before opening the liftgate/boot

lid, remove any snow and ice
accumulation on it. Otherwise, the
liftgate/boot lid could close under the
weight of the snow and ice resulting
in injury.

Be careful when opening/closing

the liftgate/boot lid during strong
winds. If a strong gust blows against
the liftgate/boot lid, it could close
suddenly resulting in injury.

Fully open the liftgate/boot lid and

make sure that it stays open. If the
liftgate/boot lid is only opened
partially, it could slam shut by
vibration or wind gusts resulting in
injury.

When loading or unloading luggage

in the luggage compartment/boot,
turn off the engine. Otherwise, you
could get burned by the heat of the
exhaust gas.

Be careful not to apply excessive

force to the damper stay on the
liftgate such as by putting your hand
on the stay. Otherwise, the damper
stay may bend and affect the liftgate
operation.

Damper stay

3–22

Before Driving

Doors and Locks

*Some models.

CAUTION

Do not modify or replace the

liftgate damper stay. Consult an
expert repairer, we recommend an
Authorised Mazda Repairer if a
liftgate damper stay is deformed
or damaged for reasons such as a
collision or if there is some other
problem.

Opening and Closing the Liftgate/

Boot Lid

Opening the boot lid

Using the remote release button

Push the remote release button.

Opening the liftgate/boot lid with
Electric liftgate/boot lid opener

    Unlock the doors and liftgate/boot lid,
then press the electric liftgate/boot lid
opener on the liftgate/boot lid and raise the
liftgate/boot lid when the latch releases.
   (Hatchback)

Electric liftgate
opener

(Saloon)

Electric boot lid
opener

3–23

Before Driving

Doors and Locks

NOTE

(With the advanced keyless function)

A locked liftgate/boot lid can also

be opened while the key is being
carried.

When opening the liftgate/boot lid

with the doors and the liftgate/boot
lid locked, it may require a few
seconds for the liftgate/boot lid latch
to release after the electric liftgate/
boot lid opener is pressed.

The liftgate/boot lid can be closed

when the doors are locked with the
key left in the vehicle. However,
to prevent locking the key in the
vehicle, the liftgate/boot lid can
be opened by pressing the electric
liftgate/boot lid opener. If the liftgate/
boot lid cannot be opened despite
doing this procedure,

¿ rst push the

liftgate/boot lid completely closed,
then press the electric liftgate/boot
lid opener to fully open the liftgate/
boot lid .

(Hatchback)

When the latch is released by

pressing the electric liftgate opener,
the liftgate raises slightly. If the
liftgate is not operated for a certain
period of time, the liftgate cannot be
raised.

To open

Press the electric liftgate opener

again.

To close

To close the liftgate from its slightly

raised position, open it

¿ rst by

pressing the electric liftgate opener,
then close it after waiting at least 1
second.

NOTE

If the liftgate is not fully closed,

the driver is noti

¿ ed by a warning

indicated in the instrument cluster.

If the vehicle battery is dead or there

is a malfunction in the electrical
system and the liftgate/boot lid
cannot be unlocked, the liftgate/boot
lid can be opened by performing the
emergency procedure.

Refer to When Liftgate/Boot Lid

Cannot be Opened on page 7-55 .

Closing the liftgate/boot lid

     (Hatchback)
  Lower the liftgate slowly using the liftgate
grip recess, then push the liftgate closed
using both hands.
  Do not slam it. Pull up on the liftgate to
make sure it is secure.

Liftgate grip recess

(Saloon)
Use both hands to push the boot lid down
until the lock snaps shut. Do not slam it.
Pull up on the boot lid to make sure it is
secure.

3–24

Before Driving

Doors and Locks

*Some models.

Luggage Compartment

Luggage compartment cover
(Hatchback)

WARNING

Do not place anything on top of the
cover:
Placing luggage or other cargo on top
of the luggage compartment cover is
dangerous. During sudden braking
or a collision, the cargo could become
a projectile that could hit and injure
someone. The vehicle has a light
weight luggage compartment cover to
keep the contents of your luggage area
out of sight; it will not retain heavy
objects that are not tied down in an
accident such as a rollover. Tie down
all heavy objects, whether luggage or
cargo, using the tie down hooks.

Make sure luggage and cargo are
secured before driving:
Not securing cargo while driving
is dangerous as it could move or be
crushed during sudden braking or a
collision and cause injury.

CAUTION

Make sure the luggage compartment
cover is

¿ rmly secured. If it is not

¿ rmly secured, it could unexpectedly
disengage resulting in injury.

The luggage compartment can be accessed
by opening the liftgate when the straps are
attached to the sides of the liftgate.

Strap

Removing the cover

This cover can be removed for more room.

1. Remove the straps from the hooks.
2. Lift the end of the luggage

compartment cover a little, pull it
outward, and remove it from the pins.

3. Lift the front end of the luggage

compartment cover and remove it.

3–25

Before Driving

Doors and Locks

Loading golf bags (only Saloon)

Up to two golf bags can be carried in the
boot.

1. Place the bottom of the

¿ rst golf bag in

the boot with its bottom pointed to the
left and

¿ t it into the front of the boot.

2. Place the second golf bag in the boot

with its bottom pointed to the left and
¿ t it into the back of the boot.

NOTE

Some golf bags cannot

¿ t depending on

their size.

Mazda 2 (2017 year). Instruction - part 6
