6-3. Do-it-yourself maintenance

When replacing wheels, care should
be taken to ensure that they are equiv-
alent to those removed in load capac-
ity, diameter, rim width and inset

Replacement wheels are available at
your Lexus dealer.

: Conventionally referred to as offset.

Lexus does not recommend using the
following:



Wheels of different sizes or types



Used wheels



Bent wheels that have been
straightened

■

When replacing wheels

The wheels of your vehicle are equipped

with tire pressure warning valves and trans-

mitters that allow the tire pressure warning

system to provide advance warning in the

event of a loss in tire inflation pressure.

Whenever wheels are replaced, tire pres-

sure warning valves and transmitters must

be installed. (



P.469)

NOTICE

■

When inspecting and adjusting tire

inflation pressure

Be sure to put the tire valve caps back

on.

If a valve cap is not installed, dirt or mois-

ture may get into the valve and cause an

air leak, resulting in decreased tire infla-

tion pressure.

Wheels

If a wheel is bent, cracked or heav-
ily corroded, it should be replaced.
Otherwise, the tire may separate
from the wheel or cause a loss of
handling control.

Wheel selection

WARNING

■

When replacing wheels

●

Do not use wheels that are a different

size from those recommended in the

Owner’s Manual, as this may result in a

loss of handling control.

477

6-3. Do-it-yourself maintenance

Mai
nte

e a

are



Use only Lexus wheel nuts and
wrenches designed for use with
your aluminum wheels.



When rotating, repairing or chang-
ing your tires, check that the wheel
nuts are still tight after driving 1000
miles (1600 km).



Be careful not to damage the alumi-
num wheels when using tire chains.



Use only Lexus genuine balance
weights or equivalent and a plastic
or rubber hammer when balancing

your wheels.

WARNING

●

Never use an inner tube in a leaking

wheel which is designed for a tubeless

tire. Doing so may result in an acci-

dent, causing death or serious injury.

■

Use of defective wheels prohibited

Do not use cracked or deformed wheels.
Doing so could cause the tire to leak air

during driving, possibly causing an acci-

dent.

NOTICE

■

Replacing tire pressure warning

valves and transmitters

●

Because tire repair or replacement

may affect the tire pressure warning

valves and transmitters, make sure to

have tires serviced by your Lexus

dealer or other qualified service shop.

In addition, make sure to purchase

your tire pressure warning valves and

transmitters at your Lexus dealer.

●

Ensure that only genuine Lexus wheels

are used on your vehicle.

Tire pressure warning valves and

transmitters may not work properly

with non-genuine wheels.

Aluminum wheel precautions

478

6-3. Do-it-yourself maintenance

Turn the engine switch off.

Open the glove box and remove
the separate tray. (



P.409)

Remove the panel.

Unlock the filter cover (

), pull

the filter cover out of the claws
(

), and remove the filter cover.

Remove the filter case.

Remove the air conditioning filter
from the filter case and replace it
with a new one.

The “

UP” marks shown on the filter and

the filter case should be pointing up.

■

Checking interval

Inspect and replace the air conditioning fil-

ter according to the maintenance schedule.

In dusty areas or areas with heavy traffic

flow, early replacement may be required.

(For scheduled maintenance information,

please refer to the “Owner’s Manual Sup-

plement” or “Scheduled Maintenance”.)

■

If air flow from the vents decreases dra-

matically

The filter may be clogged. Check the filter

and replace if necessary.

Air conditioning filter

The air conditioning filter must be
changed regularly to maintain air
conditioning efficiency.

Removal method

479

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

■

If the electronic key battery is depleted

The following symptoms may occur:

●

The smart access system with push-but-

ton start and wireless remote control will

not function properly.

●

The operational range will be reduced.

■

When the card key battery needs to be

replaced (if equipped)

The battery for the card key is available only

at Lexus dealers. Your Lexus dealer can

replace the battery for you.

Prepare the following before replacing
the battery:



Flathead screwdriver



Small flathead screwdriver



Lithium battery CR2032

■

Use a CR2032 lithium battery

●

Batteries can be purchased at your Lexus

dealer, local electrical appliance shops or

camera stores.

●

Replace only with the same or equivalent

type recommended by the manufacturer.

●

Dispose of used batteries according to

the local laws.

NOTICE

■

When using the air conditioning sys-

tem

Make sure that a filter is always installed.

Using the air conditioning system with-

out a filter may cause damage to the sys-

tem.

■

To prevent damage to the filter cover

When moving the filter cover in the

direction of arrow to release the fitting,

pay attention not to apply excessive

force to the claws. Otherwise, the claws

may be damaged.

Electronic key battery

Replace the battery with a new one
if it is depleted.

Items to prepare

480

6-3. Do-it-yourself maintenance

Take out the mechanical key.

Remove the cover.

To prevent damage to the key, wrap the tip

of the screwdriver with tape.

Remove the depleted battery.

Insert a new battery with the “+” terminal

facing up.

Replacing the battery

WARNING

■

Battery precautions

Observe the following precautions. Fail-

ure to do so may result in death or seri-

ous injury.

●

Do not swallow the battery. Doing so

may cause chemical burns.

●

A coin battery or button battery is

used in the electronic key. If a battery

is swallowed, it may cause severe

chemical burns in as little as 2 hours

and may result in death or serious

injury.

●

Keep away new and removed batter-

ies from children.

●

If the cover cannot be firmly closed,

stop using the electronic key and stow

the key in the place where children

cannot reach, and then contact your

Lexus dealer.

●

If you accidentally swallow a battery or

put a battery into a part of your body,

get emergency medical attention

immediately.

■

To prevent battery explosion or leak-

age of flammable liquid or gas

●

Replace the battery with a new battery

of the same type. If a wrong type of

battery is used, it may explode.

●

Do not expose batteries to extremely

low pressure due to high altitude or

extremely high temperatures.

●

Do not burn, break or cut a battery.

NOTICE

■

When replacing the battery

Use a flathead screwdriver of appropri-

ate size. Applying excessive force may

deform or damage the cover.

481

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Turn the engine switch off.

Open the fuse box cover.



Engine compartment

Type A:
Keep the engine compartment cover
opened or removing the cover (



P.457)

and push the tab in and lift the lid off.

Type B:
Keep the engine compartment cover
opened or removing the cover (



P.457)

and push the tab in and lift the lid off.

NOTICE

■

For normal operation after replacing

the battery

Observe the following precautions to

prevent accidents:

●

Always work with dry hands.

Moisture may cause the battery to

rust.

●

Do not touch or move any other com-

ponent inside the remote control.

●

Do not bend either of the battery ter-

minals.

Checking and replacing
fuses

If any of the electrical components
do not operate, a fuse may have
blown. If this happens, check and
replace the fuses as necessary.

Checking and replacing fuses

482

6-3. Do-it-yourself maintenance



Instrument panel

Remove the cover

and then remove

the footwell light connector

Remove the lid.



Luggage compartment

Remove the cover.

Remove the lid.

Remove the fuse with the pullout
tool.

Only type A fuse can be removed using

the pullout tool.

Check if the fuse is blown.

Type A and B:

Replace the blown fuse with a new fuse of

an appropriate amperage rating. The

amperage rating can be found on the fuse

box lid.
Type C and D:

Contact your Lexus dealer.



Type A

Normal fuse

483

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Blown fuse



Type B

Normal fuse

Blown fuse



Type C

Normal fuse

Blown fuse



Type D

Normal fuse

Blown fuse

■

After a fuse is replaced

●

When installing the lid, make sure that the

tab is installed securely.

●

If the lights do not turn on even after the

fuse has been replaced, a bulb may need

replacement. (



P.485)

●

If the replaced fuse blows again, have the

vehicle inspected by your Lexus dealer.

■

If there is an overload in a circuit

The fuses are designed to blow, protecting

the wiring harness from damage.

■

When replacing light bulbs

Lexus recommends that you use genuine

Lexus products designed for this vehicle.

Because certain bulbs are connected to cir-

cuits designed to prevent overload, non-

genuine parts or parts not designed for this

vehicle may be unusable.

WARNING

■

To prevent system breakdowns and

vehicle fire

Observe the following precautions.

Failure to do so may cause damage to

the vehicle, and possibly a fire or injury.

●

Never use a fuse of a higher amperage

rating than that indicated, or use any

other object in place of a fuse.

●

Always use a genuine Lexus fuse or

equivalent.

Never replace a fuse with a wire, even

as a temporary fix.

●

Do not modify the fuses or fuse boxes.

NOTICE

■

Before replacing fuses

Have the cause of electrical overload

determined and repaired by your Lexus

dealer as soon as possible.

484

6-3. Do-it-yourself maintenance

Adjustment bolt A

Adjustment bolt B



Make sure the vehicle has a full tank
of gasoline and the area around the
headlight is not deformed.



Park the vehicle on level ground.



Make sure the tire inflation pressure
is at the specified level.



Have someone sit in the driver’s
seat.



Bounce the vehicle several times.

Using a Phillips-head screwdriver,
turn bolt A in either direction.

Remember the turning direction
and the number of turns.

Turn bolt B the same number of
turns and in the same direction as
step

If the headlight cannot be adjusted using

this procedure, take the vehicle to your

Lexus dealer to adjust the headlight aim.

Headlight aim

Vertical movement adjusting
bolts

Before checking the headlight
aim

Adjusting the headlight aim

A
B

485

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

■

LED lights

The following lights consist of a number of

LEDs. If any of the LEDs burn out, take your

vehicle to your Lexus dealer to have the

light replaced.

●

Headlights

●

Parking lights and daytime running lights

●

Front side marker lights

●

Front turn signal lights

●

Fog lights

●

Cornering lights

●

Side turn signal lights

●

Tail lights

●

Stop lights

●

Rear side marker lights

●

Rear turn signal lights

●

Back-up lights

●

High mounted stoplight

●

License plate lights

●

Outer foot lights

●

Running board lights

■

Condensation build-up on the inside of

the lens

Temporary condensation build-up on the

inside of the light lens does not indicate a

malfunction. Contact your Lexus dealer for

more information in the following situations:

●

Large drops of water have built up on the

inside of the lens.

●

Water has built up inside the light.

Light bulbs

If any lights burn out, have it
replaced by your Lexus dealer.

487

When trouble

ari

ses

When trouble arises

7-1. Essential information

Emergency flashers..................

488

If your vehicle has to be stopped

in an emergency.....................

488

If the vehicle is submerged or

water on the road is rising ..

489

7-2. Steps to take in an emergency

If your vehicle needs to be towed

.........................................................

491

If you think something is wrong

........................................................

494

Fuel pump shut off system .....

495

If a warning light turns on or a

warning buzzer sounds .......

496

If a warning message is displayed

........................................................

506

If you have a flat tire....................

511

If the engine will not start ........

521

If you lose your keys.................

522

If the electronic key does not

operate properly ....................

523

If the vehicle battery is discharged

........................................................

525

If your vehicle overheats ........

528

If the vehicle becomes stuck .

531

488

7-1. Essential information

7-1.Essential information

Press the switch.

All the turn signal lights will flash.
To turn them off, press the switch once
again.

■

Emergency flashers

●

If the emergency flashers are used for a

long time while the engine is not running,

the battery may discharge.

●

If any of the SRS airbags deploy (inflate)

or in the event of a strong rear impact, the

emergency flashers will turn on automati-

cally.

The emergency flashers will turn off auto-

matically after operating for approxi-

mately 20 minutes. To manually turn the

emergency flashers off, press the switch

twice. (The emergency flashers may not

turn on automatically depending on the

force of the impact and conditions of the

collision.)

Steadily step on the brake pedal
with both feet and firmly depress it.

Do not pump the brake pedal repeatedly

as this will increase the effort required to

slow the vehicle.

Shift the shift lever to N.



If the shift lever is shifted to N

After slowing down, stop the vehi-
cle in a safe place by the road.

Stop the engine.



If the shift lever cannot be shifted to
N

Keep depressing the brake pedal
with both feet to reduce vehicle
speed as much as possible.

To stop the engine, press and hold
the engine switch for 2 consecutive

Emergency flashers

The emergency flashers are used to
warn other drivers when the vehi-
cle has to be stopped in the road
due to a breakdown, etc.

Operating instructions

If your vehicle has to be
stopped in an emergency

Only in an emergency, such as if it
becomes impossible to stop the
vehicle in the normal way, stop the
vehicle using the following proce-
dure:

Stopping the vehicle

489

7-1. Essential information

n t

ris

seconds or more, or press it briefly
3 times or more in succession.

Stop the vehicle in a safe place by
the road.

■

If emergency stopped

The functions of the air conditioning, etc.

may be partially limited in order to reduce

the power consumption of the battery.



If the door can be opened, open the
door and exit the vehicle.



If the door cannot be opened, open
the window using the power win-
dow switch and ensure an escape
route.



If the window can be opened, exit
the vehicle through the window.



If the door and window cannot be
opened due to the rising water,
remain calm, wait until the water
level inside the vehicle rises to the
point that the water pressure inside
of the vehicle equals the water pres-
sure outside of the vehicle and then
open the door after waiting for the
rising water to enter the vehicle, and
exit the vehicle. When the outside
water level exceeds half the height
of the door, the door cannot be
opened from the inside due to water
pressure.

■

Water level exceeds the floor

When the water level exceeds the floor and

WARNING

■

If the engine has to be turned off while

driving

Turning the engine off while driving will

not cause loss of steering or braking con-

trol. However, power assist for these sys-

tems may be lost making it difficult to

steer or brake before stopping the vehi-

cle depending on the remaining charge

in the battery or usage conditions. Decel-

erate as much as possible before turning

off the engine.

If the vehicle is submerged
or water on the road is rising

This vehicle is not designed to be
able to drive on roads that are
deeply flooded with water. Do not
drive on roads where the roads may
be submerged or the water may be
rising. It is dangerous to remain in
the vehicle, if it is anticipated that
the vehicle will be flooded or set
adrift. Remain calm and follow the
following.

490

7-1. Essential information

time has passed, the electrical equipment

will get damaged, the power windows will

not operate, the engine stop, and the vehi-

cle may not be able to get moving.

■

Using an emergency escape hammer

Laminated glass is used in the windshield

and the windows on this vehicle. Laminated

glass cannot be shattered with an emer-
gency hammer

: Contact your Lexus dealer or aftermar-

ket accessory manufacturer for further
information about an emergency ham-
mer.

WARNING

■

Caution while driving

Do not drive on roads where the roads

may be submerged or the water may be

rising. Otherwise the vehicle may be

damaged and cannot move, as well as

become flooded and set adrift, which

may lead to death.

491

7-2. Steps to take in an emergency

n t

ris

7-2.Steps to take in an emergency

The following may indicate a problem
with your transmission. Contact your
Lexus dealer or commercial towing
service before towing.



The engine is running but the vehi-
cle does not move.



The vehicle makes an abnormal
sound.



From the front

Use a towing dolly under the rear
wheels.



From the rear

Use a towing dolly under the front
wheels.

If your vehicle needs to be
towed

If towing is necessary, we recom-
mend having your vehicle towed by
your Lexus dealer or commercial
towing service, using a wheel-lift
type truck or flatbed truck.
Use a safety chain system for all
towing, and abide by all state/pro-
vincial and local laws.

Situations when it is necessary to
contact dealers before towing

Towing with a wheel-lift type
truck

WARNING

Observe the following precautions.
Failure to do so may result in death or

serious injury.

■

When towing the vehicle

Be sure to transport the vehicle with all

four wheels raised off the ground. If the

vehicle is towed with the tires contacting

the ground, the drivetrain or related

parts may be damaged, the vehicle may

fly off the truck.

492

7-2. Steps to take in an emergency

When using a flat-bed truck to trans-
port the vehicle, use tire strapping
belts. Refer to the owner’s manual of
the flat-bed truck for the tire strapping
method.
In order to suppress vehicle movement
during transportation, set the parking
brake and turn the engine switch off.

If a tow truck is not available in an
emergency, your vehicle may be tem-
porarily towed using cables or chains

secured to the emergency towing
hook. This should only be attempted on
hard surfaced roads for at most 50
miles (80 km) at under 18 mph (30
km/h).
A driver must be in the vehicle to steer
and operate the brakes. The vehicle’s
wheels, drive train, axles, steering and
brakes must be in good condition.

Securely attach cables or chains to
the towing hook.

Take care not to damage the vehicle body.

Enter the vehicle being towed and
start the engine.

If the engine does not start, turn the engine

switch to ON.

Put the four-wheel drive control
switch in “H4”. (The center differ-
ential is unlocked.)

Vehicles with AHC: Change the
vehicle height to N (standard)
mode and end the vehicle height
operation. (



P.350)

Shift the shift lever to N and release
the parking brake.

Turn automatic mode off. (



P.198)

When the shift lever cannot be shifted:

NOTICE

■

To prevent damage to the vehicle

when towing using a wheel-lift type

truck

●

Do not tow the vehicle from the rear

when the engine switch is off. The

steering lock mechanism is not strong

enough to hold the front wheels

straight.

●

When raising the vehicle, ensure ade-

quate ground clearance for towing at

the opposite end of the raised vehicle.

Without adequate clearance, the vehi-

cle could be damaged while being

towed.

■

Towing with a sling-type truck

Do not tow with a sling-type truck to pre-

vent body damage.

Using a flatbed truck

Emergency towing

Emergency towing procedure

493

7-2. Steps to take in an emergency

n t

ris



P.194

■

While towing

If the engine is not running, the power assist

for the brakes and steering will not function,

making steering and braking more difficult.

■

If the cables or chains touch the bumper

due to the angle at which the cables or

chains are hanging, remove the cover (if

equipped) on the bumper.
• Remove the bolt, pull the cover toward

you, and then detach the 2 claws.

WARNING

Observe the following precautions. Fail-

ure to do so may result in death or seri-

ous injury.

■

While towing

●

When towing using cables or chains,

avoid sudden starts, etc. which place

excessive stress on the towing hook,

cables or chains. The towing hook,

cables or chains may become dam-

aged, broken debris may hit people,

and cause serious damage.

●

Vehicles with AHC: Make sure to turn

off the AHC. Otherwise, the vehicle

height may change and part of your

body may be caught under the vehicle,

possibly causing injury. (



P.350)

●

Do not turn the engine switch off.

There is a possibility that the steering

wheel is locked and cannot be oper-

ated.

NOTICE

■

To prevent damage to the vehicle

during emergency towing

Do not secure cables or chains to the

suspension components.

■

When towing a vehicle equipped with

a Stop & Start system

If it is necessary to tow the vehicle with all

4 wheels on the ground, perform the fol-

lowing procedure before towing the

vehicle, in order to protect the system.

Turn the engine switch off and then start

the engine or turn the engine switch to

ON.

494

7-2. Steps to take in an emergency



Fluid leaks under the vehicle
(Water dripping from the air condi-
tioning after use is normal.)



Flat-looking tires or uneven tire
wear



Engine coolant temperature gauge
needle continually points higher
than normal.



Engine oil pressure gauge continu-
ally points lower than normal.



Voltmeter continually points higher
or lower than normal.



Changes in exhaust sound



Excessive tire squeal when corner-
ing



Strange noises related to the sus-
pension system



Pinging or other noises related to
the engine



Engine missing, stumbling or run-
ning roughly



Appreciable loss of power



Vehicle pulls heavily to one side
when braking



Vehicle pulls heavily to one side
when driving on a level road



Loss of brake effectiveness, spongy
feeling, pedal almost touches the
floor

If you think something is
wrong

If you notice any of the following
symptoms, your vehicle probably
needs adjustment or repair. Con-
tact your Lexus dealer as soon as
possible.

Visible symptoms

Audible symptoms

Operational symptoms

495

7-2. Steps to take in an emergency

n t

ris

Follow the procedure below to restart
the engine after the system is activated.

Turn the engine switch to ACC or
OFF.

Restart the engine.

Fuel pump shut off system

To minimize the risk of fuel leakage
when the engine stalls or when an
airbag inflates upon collision, the
fuel pump shut off system stops the
supply of fuel to the engine.

Restarting the engine

NOTICE

■

Before starting the engine

Inspect the ground under the vehicle.
If you find that fuel has leaked onto the

ground, the fuel system has been dam-

aged and is in need of repair. Do not

restart the engine.

496

7-2. Steps to take in an emergency

■

Brake system warning light (warning buzzer)

■

Brake system warning light (warning buzzer)

■

Charging system warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

If a warning light turns on or a warning buzzer sounds

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by your Lexus dealer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

(U.S.A.)

(Canada)

(Red)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning



Immediately stop the vehicle in a safe place and con-
tact your Lexus dealer. Continuing to drive the vehi-
cle may be dangerous.

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in:



The parking brake system; or



The electronically controlled brake system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and con-
tact your Lexus dealer.

497

7-2. Steps to take in an emergency

When trouble

ari

ses

■

Low engine oil pressure warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

■

High coolant temperature warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

■

Malfunction indicator lamp

■

SRS warning light

Warning light

Details/Actions

Indicates that the engine oil pressure is too low



Immediately stop the vehicle in a safe place and con-
tact your Lexus dealer.

Warning light

Details/Actions

Indicates that the engine is overheating



Immediately stop the vehicle in a safe place.
Handling method (



P.528)

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The electronic engine control system;



The electronic throttle control system;



The electronic automatic transmission control system;
or



The Stop & Start system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

Indicates a malfunction in:



The SRS airbag system; or



The seat belt pretensioner system



Have the vehicle inspected by your Lexus dealer
immediately.

498

7-2. Steps to take in an emergency

■

ABS warning light

■

Power steering system warning light (warning buzzer)

■

PCS warning light (warning buzzer)

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The Multi-terrain ABS; or



The brake assist system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

(Red)

(Yellow)

Indicates a malfunction in the EPS (Electric Power Steer-
ing) system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

(Flashes or illuminates)

When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-
Collision System).



Have the vehicle inspected by your Lexus dealer
immediately.

When a buzzer does not sound:
The PCS (Pre-Collision System) has become temporarily
unavailable, corrective action may be necessary.



Follow the instructions displayed on the multi-infor-
mation display. (



P.218, 509)

If the PCS (Pre-Collision System) or VSC (Vehicle Stabil-
ity Control) system is disabled, the PCS warning light will
illuminate.



P.229

499

7-2. Steps to take in an emergency

When trouble

ari

ses

■

LTA indicator (warning buzzer)

■

BSM OFF indicator (warning buzzer)

■

RCTA OFF indicator (warning buzzer)

■

RCD OFF indicator (warning buzzer)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the LTA (Lane Tracing Assist)



Follow the instructions displayed on the multi-infor-
mation display. (



P.237)

Warning light

Details/Actions

Indicates a malfunction in the BSM (Blind Spot Monitor)
function



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the rear bumper around the radar sensor is
covered with dirt, etc. (



P.258)



Follow the instructions displayed on the multi-infor-
mation display. (



P.257, 506)

Warning light

Details/Actions

Indicates a malfunction in the RCTA (Rear Cross Traffic
Alert) function



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the rear bumper around the radar sensor is
covered with dirt, etc. (



P.258)



Follow the instructions displayed on the multi-infor-
mation display. (



P.268, 506)

Warning light

Details/Actions

Indicates a malfunction in the RCD (Rear Camera Detec-
tion) function



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the function temporarily cannot be used due
to the camera being dirty, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.274, 506)

500

7-2. Steps to take in an emergency

■

Intuitive parking assist OFF indicator (warning buzzer)

■

PKSB OFF indicator (warning buzzer)

■

Inappropriate pedal operation warning light

(warning buzzer)

: This light illuminates on the multi-information display with a message.

Warning light

Details/Actions

Indicates a malfunction in the intuitive parking assist func-
tion



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the system is temporarily unavailable, possi-
bly due to a sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.263, 506)

Warning light

Details/Actions

Indicates a malfunction in the PKSB (Parking Support
Brake) system



Have the vehicle inspected by your Lexus dealer
immediately.

Indicates that the system is temporarily unavailable, possi-
bly due to a sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.279, 506)

Warning light

Details/Actions

When a buzzer sounds:



Brake Override System is malfunctioning



Drive-Start Control is malfunctioning



Drive-Start Control is operating



Parking Support Brake function (Static Objects Front
and Rear of the Vehicle) is operating.



Follow the instructions displayed on the multi-infor-
mation display.

When a buzzer does not sound:
Brake Override System is operating.



Release the accelerator pedal and depress the brake
pedal.

501

7-2. Steps to take in an emergency

When trouble

ari

ses

■

Stop & Start cancel indicator

■

Slip indicator light

■

Low speed four-wheel drive indicator

■

Center differential lock indicator

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the Stop & Start system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

Indicates a malfunction in:



The VSC system;



The Trailer Sway Control system



The Active TRAC system;



The hill-start assist control system;



The downhill assist control system;



The Multi-terrain Select; or



The Crawl Control



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

(Flashes rapidly)

Indicates a malfunction in the four-wheel drive system.



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

(Flashes rapidly)

Indicates a malfunction in the center differential lock sys-
tem.



Have the vehicle inspected by your Lexus dealer
immediately.

502

7-2. Steps to take in an emergency

■

Parking brake indicator

■

Brake hold operated indicator (warning buzzer)

■

Low fuel level warning light

■

Tire pressure warning light

Warning light

Details/Actions

(Flashes)

(U.S.A.)

(Flashes)

(Canada)

It is possible that the parking brake is not fully engaged or
released



Operate the parking brake switch once again.

This light comes on when the parking brake is not
released. If the light turns off after the parking brake is fully
released, the system is operating normally.

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by your Lexus dealer
immediately.

Warning light

Details/Actions

Indicates that remaining fuel is approximately 3.2 gal.
(12.0 L, 2.6 Imp. gal.) or less



Refuel the vehicle.

Warning light

Details/Actions

When the light comes on after blinking for 1 minute:
Malfunction in the tire pressure warning system



Have the system checked by your Lexus dealer.

When the light comes on:
Low tire inflation pressure such as



Natural causes



Flat tire



Immediately stop the vehicle in a safe place.
Handling method (



P.504)

503

7-2. Steps to take in an emergency

When trouble

ari

ses

■

Driver’s and front passenger’s seat belt reminder light (warning buzzer)

: Driver’s seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or her seat belt is
not fastened. Once the engine switch is turned to ON, the buzzer sounds. If the seat belt
is still unfastened, the buzzer sounds intermittently for a certain period of time after the
vehicle reaches a certain speed.
Front passenger’s seat belt warning buzzer:
The front passenger’s seat belt warning buzzer sounds to alert the front passenger that
his or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds inter-
mittently for a certain period of time after the vehicle reaches a certain speed.

■

Rear passengers’ seat belt reminder light (warning buzzer)

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear passenger that his
or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds intermit-
tently for a certain period of time, after the seat belt is fastened and unfastened and the
vehicle reaches a certain speed.

■

Warning buzzer

In some cases, the buzzer may not be heard

because of noisy place or an audio sound.

■

Front passenger detection sensor, seat

belt reminder and warning buzzer

●

If luggage is placed on the front passen-

ger seat, the front passenger detection

sensor may cause the warning light to

flash and the warning buzzer to sound

even if a passenger is not sitting in the

seat.

●

If a cushion is placed on the seat, the sen-

sor may not detect a passenger, and the

warning light may not operate properly.

■

SRS warning light

This warning light system monitors the air-

bag sensor assembly, front impact sensors,

side impact sensors (front door), side

impact sensors (front), side impact sensors

(rear), safing sensor (rear), front passenger

occupant classification sensors, driver’s

seat position sensor, driver’s seat belt

buckle switch, rear seat belt buckle

switches, “AIR BAG ON” indicator light,

“AIR BAG OFF” indicator light, front pas-

senger’s seat belt buckle switch, driver’s

seat belt pretensioner, front passenger’s

seat belt pretensioner and force limiter,

rear seat belt pretensioners (if equipped),

airbags, interconnecting wiring and power

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their
seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

Warning light

Details/Actions

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

504

7-2. Steps to take in an emergency

sources. (



P.35)

■

If the malfunction indicator lamp comes

on while driving

First check the following:

●

Is the fuel tank empty?

If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?

If it is, tighten it securely.

The light will go off after several driving

trips.
If the light does not go off even after several

trips, contact your Lexus dealer as soon as

possible.

■

Electric power steering system warning

light (warning buzzer)

When the battery charge becomes insuffi-

cient or the voltage temporarily drops, the

electric power steering system warning

light may come on and the warning buzzer

may sound.

■

When the tire pressure warning light

comes on

Inspect the tires to check if a tire is punc-

tured.
If a tire is punctured:



P.511

If none of the tires are punctured:
Turn the engine switch to OFF then turn it

to ON. Check if the tire pressure warning

light comes on or blinks.



If the tire pressure warning light blinks for

approximately 1 minute then stays on

There may be a malfunction in the tire pres-
sure warning system. Have the vehicle
inspected by your Lexus dealer immedi-
ately.



If the tire pressure warning light comes

After the temperature of the tires has

lowered sufficiently, check the inflation

pressure of each tire and adjust them to

the specified level.

If the warning light does not turn off

even after several minutes have

elapsed, check that the inflation pres-

sure of each tire is at the specified level

and perform initialization. (



P.469)

■

The tire pressure warning light may

come on due to natural causes

The tire pressure warning light may come

on due to natural causes such as natural air

leaks and tire inflation pressure changes

caused by temperature. In this case, adjust-

ing the tire inflation pressure will turn off the

warning light (after a few minutes).

■

When a tire is replaced with a spare tire

The spare tire is also equipped with the tire

pressure warning valve and transmitter. The

tire pressure warning light will turn on if the

tire inflation pressure of the spare tire is low.

If a tire goes flat, even though the flat tire is

replaced with the spare tire, the tire pres-

sure warning light does not turn off.

Replace the spare tire with the repaired tire

and adjust the proper tire inflation pressure.

The tire pressure warning light will turn off

after a few minutes.

■

Conditions that the tire pressure warn-

ing system may not function properly



P.468

WARNING

■

If a warning light comes on or a warn-

ing buzzer sounds when a warning

message is shown on the multi-infor-

mation display

Check and follow the message shown on

the multi-information display.
Failure to do so may result in death or

serious injury.

■

If both the ABS and the brake system

warning lights remain on

Stop your vehicle in a safe place immedi-

ately and contact your Lexus dealer. The

vehicle will become extremely unstable

during braking, and the ABS system may

fail, which could cause an accident

resulting in death or serious injury.

505

7-2. Steps to take in an emergency

n t

ris

WARNING

■

When the electric power steering

system warning light comes on

When the light comes on yellow, the

assist to the power steering is restricted.

When the light comes on red, the assist

to the power steering is lost and handling

operations of the steering wheel become

extremely heavy.

When steering wheel operations are

heavier than usual, grip the steering

wheel firmly and operate it using more

force than usual.

■

If the tire pressure warning light

comes on

Be sure to observe the following precau-

tions. Failure to do so could cause a loss

of vehicle control and result in death or

serious injury.

●

Stop your vehicle in a safe place as

soon as possible. Adjust the tire infla-

tion pressure immediately.

●

If the tire pressure warning light comes

on even after tire inflation pressure

adjustment, it is probable that you have

a flat tire. Check the tires. If a tire is flat,

change it with the spare tire and have

the flat tire repaired by the nearest

Lexus dealer.

●

Avoid abrupt maneuvering and brak-

ing. If the vehicle tires deteriorate, you

could lose control of the steering

wheel or the brakes.

■

If a blowout or sudden air leakage

should occur

The tire pressure warning system may

not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if pro-

vided), should be checked monthly when

cold and inflated to the inflation pressure

recommended by the vehicle manufac-

turer on the vehicle placard or tire infla-

tion pressure label (tire and load

information label). (If your vehicle has

tires of a different size than the size indi-

cated on the vehicle placard or tire infla-

tion pressure label [tire and load

information label], you should determine

the proper tire inflation pressure for

those tires.)

As an added safety feature, your vehicle

has been equipped with a tire pressure

monitoring system (TPMS-tire pressure

warning system) that illuminates a low

tire pressure telltale (tire pressure warn-

ing light) when one or more of your tires

is significantly under-inflated. Accord-

ingly, when the low tire pressure telltale

(tire pressure warning light) illuminates,

you should stop and check your tires as

soon as possible, and inflate them to the

proper pressure. Driving on a signifi-

cantly under-inflated tire causes the tire

to overheat and can lead to tire failure.

Under-inflation also reduces fuel effi-

ciency and tire tread life, and may affect

the vehicle’s handling and stopping abil-

ity.

Please note that the TPMS (tire pressure

warning system) is not a substitute for

proper tire maintenance, and it is the

driver’s responsibility to maintain correct

tire pressure, even if under-inflation has

not reached the level to trigger illumina-

tion of the TPMS low tire pressure telltale

(tire pressure warning light).

506

7-2. Steps to take in an emergency

WARNING

Your vehicle has also been equipped

with a TPMS (tire pressure warning sys-

tem) malfunction indicator to indicate

when the system is not operating prop-

erly. The TPMS (tire pressure warning

system) malfunction indicator is com-

bined with the low tire pressure telltale

(tire pressure warning light). When the

system detects a malfunction, the telltale

will flash for approximately one minute

and then remain continuously illumi-

nated. This sequence will continue upon

subsequent vehicle start-ups as long as

the malfunction exists. When the mal-

function indicator is illuminated, the sys-

tem may not be able to detect or signal

low tire pressure as intended.

TPMS (tire pressure warning system)

malfunctions may occur for a variety of

reasons, including the installation of

replacement or alternate tires or wheels

on the vehicle that prevent the TPMS

(tire pressure warning system) from

functioning properly. Always check the

TPMS (tire pressure warning system)

malfunction telltale after replacing one

or more tires or wheels on your vehicle

to ensure that the replacement or alter-

nate tires and wheels allow the TPMS

(tire pressure warning system) to con-

tinue to function properly.

NOTICE

■

To ensure the tire pressure warning

system operates properly

Do not install tires with different specifi-

cations or manufacturers, as the tire

pressure warning system may not oper-

ate properly.

If a warning message is dis-
played

The multi-information display
shows warnings of system malfunc-
tions, incorrectly performed opera-
tions, and messages that indicate a
need for maintenance. When a
message is shown, perform the cor-
rection procedure appropriate to
the message.

If a warning message is displayed
again after the appropriate actions
have been performed, contact your
Lexus dealer.

507

7-2. Steps to take in an emergency

When trouble

ari

ses

The warning lights and warning buzzers operate as follows depending on the con-
tent of the message. If a message indicates the need for inspection by a dealer,
have the vehicle inspected by your Lexus dealer immediately.

: A buzzer sounds the first time a message is shown on the multi-information display.

■

Warning messages

The warning messages explained below

may differ from the actual messages

according to operation conditions and vehi-

cle specifications.

■

Warning buzzer

In some cases, the buzzer may not be heard

because of noisy place or an audio sound.

■

If a message that indicates the need for

visiting your Lexus dealer is displayed

The system or part shown on the multi-

information display is malfunctioning. Have

the vehicle inspected by your Lexus dealer

immediately.

■

If a message about an operation is

shown

●

If a message about an operation of the

accelerator pedal or brake pedal is

shown

• A warning message about an operation

of the brake pedal may be shown while

the driving assist systems such as PCS

(Pre-Collision system) or the dynamic

radar cruise control with full-speed range

is operating. If a warning message is

shown, be sure to decelerate the vehicle

or follow an instruction shown on the

multi-information display.

• A warning message is shown when Brake

Override System operates. (



P.167)

• A warning message is shown when

Drive-Start Control or Parking Support

Brake (



P.171, 275) operates. Follow

the instructions on the multi-information

display.

●

If a message about an operation of the

engine switch is shown

An instruction for operation of the engine
switch is shown when the incorrect proce-

Messages and warnings

Warning

light

Warning buzzer

Warning



Sounds

• Indicates an important situation, such as when a

system related to driving is malfunctioning or that
danger may result if the correction procedure is
not performed

• Indicates a situation, such as when damage to the

vehicle or danger may result

Comes on

or flashes

Sounds

Indicates an important situation, such as when the
systems shown on the multi-information display
may be malfunctioning



Does not sound

• Indicates a condition, such as malfunction of

electrical components, their condition, or indi-
cates the need for maintenance

• Indicates a situation, such as when an operation

has been performed incorrectly, or indicates
how to perform an operation correctly

Lexus LX600 (2024 year). Manual in english - page 15
