444

6-1. Maintenance and care

WARNING

■

When cleaning the windshield

Set the wiper switch to off.

If the wiper switch is in “AUTO”, the wip-

ers may operate unexpectedly in the fol-

lowing situations, and may result in hands

being caught or other serious injuries

and cause damage to the wiper blades.

Off

AUTO

●

When the upper part of the windshield

where the raindrop sensor is located is

touched by hand

●

When a wet rag or similar is held close

to the raindrop sensor

●

If something bumps against the wind-

shield

●

If you directly touch the raindrop sen-

sor body or if something bumps into

the raindrop sensor

■

Precautions regarding the exhaust

pipes

Exhaust gasses cause the exhaust pipes

to become quite hot.
When washing the vehicle, be careful not

to touch the pipes until they have cooled

sufficiently, as touching hot exhaust pipes

can cause burns.

■

Precaution regarding the rear

bumper with Blind Spot Monitor

If the paint of the rear bumper is chipped

or scratched, the system may malfunc-

tion. If this occurs, consult your Lexus

dealer.

A

B

NOTICE

■

To prevent paint deterioration and

corrosion on the body and compo-

nents (aluminum wheels, etc.)

●

Wash the vehicle immediately in the

following cases:

• After driving near the sea coast

• After driving on salted roads

• If coal tar or tree sap is present on the

paint surface

• If dead insects, insect droppings or

bird droppings are present on the

paint surface

• After driving in an area contaminated

with soot, oily smoke, mine dust, iron

powder or chemical substances

• If the vehicle becomes heavily soiled

with dust or mud

• If liquids such as benzene and gasoline

are spilled on the paint surface

●

If the paint is chipped or scratched,

have it repaired immediately.

●

To prevent the wheels from corroding,

remove any dirt and store in a place

with low humidity when storing the

wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic

substances or scrub with a hard brush.

This may damage the surfaces of the

lights.

●

Do not apply wax to the surfaces of the

lights.

Wax may cause damage to the lenses.

■

When using an automatic car wash

Set the wiper switch to off position.

If the wiper switch is in “AUTO”, the wip-

ers may operate and the wiper blades

may be damaged.

445

6-1. Maintenance and care

6

Mai
nte

na

nc

e a

nd

 c

are



Remove dirt and dust using a vac-
uum cleaner. Wipe dirty surfaces
with a cloth dampened with luke-
warm water.



If dirt cannot be removed, wipe it off
with a soft cloth dampened with
neutral detergent diluted to approx-
imately 1%.
Wring out any excess water from
the cloth and thoroughly wipe off
remaining traces of detergent and
water.

■

Shampooing the carpets

There are several commercial foaming-

type cleaners available. Use a sponge or

brush to apply the foam. Rub in overlapping

circles. Do not use water. Wipe dirty sur-

faces and let them dry. Excellent results are

obtained by keeping the carpet as dry as

possible.

■

Handling the seat belts

Clean with mild soap and lukewarm water

using a cloth or sponge. Also check the

belts periodically for excessive wear, fray-

ing or cuts.

NOTICE

■

When using a high pressure car wash

●

When washing the vehicle, do not

spray the camera or its surrounding

area directly with a high pressure

washer. Shock applied from high pres-

sure water may cause the device to not

operate normally.

●

Do not spray water directly on the

radar which is equipped behind the

emblem. Otherwise it may cause the

device to be damaged.

●

Do not bring the nozzle tip close to

boots (rubber or resin manufactured

cover), connectors or the following

parts.

The parts may be damaged if they

come into contact with high-pressure

water.

• Traction related parts

• Steering parts

• Suspension parts

• Brake parts

●

Keep the cleaning nozzle at least 11.9

in. (30 cm) away from the vehicle

body. Otherwise resin section, such as

moldings and bumpers, may be

deformed and damaged. Also, do not

continuously hold the nozzle in the

same place.

●

Do not spray the lower part of the

windshield continuously. If water

enters the air conditioning system

intake located near the lower part of

the windshield, the air conditioning

system may not operate correctly.

●

Do not wash the underside of the vehi-

cle using a high pressure car washer.

Cleaning and protecting the
vehicle interior

Perform cleaning in a manner
appropriate to each component
and its material.

Protecting the vehicle interior

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehi-

cle.

Doing so may cause electrical compo-

nents, etc., to malfunction or catch fire.

446

6-1. Maintenance and care

WARNING

●

Do not get any of the SRS components

or wiring in the vehicle interior wet.

(



P.37)

An electrical malfunction may cause

the airbags to deploy or not function

properly, resulting in death or serious

injury.

●

Vehicles with wireless charger:

Do not let the wireless charger

(



P.423) get wet. Failure to do so

may cause the charger to become hot

and cause burns or could cause elec-

tric shock resulting in death or serious

injury.

■

Cleaning the interior (especially

instrument panel)

Do not use a polish wax or polish cleaner.

The instrument panel may reflect off the

windshield, obstructing the driver’s view

and leading to an accident, resulting in

death or serious injury.

NOTICE

■

Cleaning detergents

●

Do not use the following types of

detergent, as they may discolor the

vehicle interior or cause streaks or

damage to painted surfaces:

• Non-seat portions: Organic sub-

stances such as benzene or gasoline,

alkaline or acidic solutions, dye, and

bleach

• Seats: Alkaline or acidic solutions,

such as thinner, benzene, and alcohol

●

Do not use a polish wax or polish

cleaner. The instrument panel’s or

other interior part’s painted surface

may be damaged.

■

Preventing damage to leather sur-

faces

Observe the following precautions to

avoid damage to and deterioration of

leather surfaces:

●

Remove any dust or dirt from leather

surfaces immediately.

●

Do not expose the vehicle to direct

sunlight for extended periods of time.

Park the vehicle in the shade, espe-

cially during summer.

●

Do not place items made of vinyl, plas-

tic, or containing wax on the uphol-

stery, as they may stick to the leather

surface if the vehicle interior heats up

significantly.

■

Water on the floor

Do not wash the vehicle floor with water.

Vehicle systems such as the audio sys-

tem may be damaged if water comes into

contact with electrical components such

as the audio system above or under the

floor of the vehicle. Water may also

cause the body to rust.

■

When cleaning the inside of the wind-

shield

Do not allow glass cleaner to contact the

lens. Also, do not touch the lens.

(



P.215)

■

Cleaning the inside of the rear quar-

ter windows and rear window

●

Do not use glass cleaner to clean the

rear quarter windows and rear win-

dow, as this may cause damage to the

rear window defogger heater wires or

antenna. Use a cloth dampened with

lukewarm water to gently wipe the

window clean. Wipe the window in

strokes running parallel to the heater

wires or antenna.

●

Be careful not to scratch or damage

the heater wires or antenna.

447

6-1. Maintenance and care

6

Mai
nte

na

nc

e a

nd

 c

are



Remove dirt using a water-damp-
ened soft cloth or synthetic chamois.



Wipe the surface with a dry soft
cloth to remove any remaining
moisture.

■

Cleaning the areas with satin-finish

metal accents

The metal areas use a layer of real metal to

the surface. It is necessary to clean them

regularly. If dirty areas are left uncleaned

for long period of time, they may be difficult

to clean.



Remove dirt and dust using a vac-
uum cleaner.



Wipe off any excess dirt and dust
with a soft cloth dampened with
diluted detergent.

Use a diluted water solution of approxi-
mately 5% neutral wool detergent.



Wring out any excess water from
the cloth and thoroughly wipe off all
remaining traces of detergent.



Wipe the surface with a dry, soft
cloth to remove any remaining
moisture. Allow the leather to dry in
a shaded and ventilated area.

■

Caring for leather areas

Lexus recommends cleaning the interior of

the vehicle at least twice a year to maintain

the quality of the vehicle’s interior.



Remove dirt and dust using a vac-
uum cleaner.



Wipe it off with a soft cloth damp-
ened with neutral detergent diluted
to approximately 1%.



Wring out any excess water from
the cloth and thoroughly wipe off
remaining traces of detergent and
water.

Cleaning the areas with satin-
finish metal accents

Cleaning the leather areas

Cleaning the synthetic leather
areas

448

6-2. Maintenance

6-2.Maintenance

■

Repair and replacement

It is recommended that genuine Lexus parts

be used for repairs to ensure performance

of each system. If non-Lexus parts are used

in replacement or if a repair shop other than

a Lexus dealer performs repairs, confirm

the warranty coverage.

■

Allow inspection and repairs to be per-

formed by a Lexus dealer

●

Lexus technicians are well-trained spe-

cialists and are kept up to date with the

latest service information. They are well

informed about the operation of all sys-

tems on your vehicle.

●

Keep a copy of the repair order. It proves

that the maintenance that has been per-

formed is under warranty coverage. If

any problem should arise while your vehi-

cle is under warranty, your Lexus dealer

will promptly take care of it.

General maintenance should be per-
formed on a daily basis. This can be
done by yourself or by a Lexus dealer.

Scheduled maintenance should be
performed at specified intervals
according to the maintenance sched-
ule.

For details about maintenance items and
schedules, refer to the “Warranty and Ser-
vice Guide”, “Owner’s Manual Supple-
ment” or “Scheduled Maintenance”.

■

Resetting the message indicating main-

tenance is required (U.S.A. only)

After the required maintenance is per-

formed according to the maintenance

schedule, please reset the message.

To reset the message, follow the proce-

dures described below:

1

Press

 or

 of the meter control

switches to select

.

2

Press

 or

 to select “Vehicle Set-

tings” and then press

.

Maintenance requirements

To ensure safe and economical
driving, day-to-day care and regu-
lar maintenance are essential. It is
the owner’s responsibility to per-
form regular checks. Lexus recom-
mends the following maintenance:

WARNING

■

If your vehicle is not properly main-

tained

Improper maintenance could result in

serious damage to the vehicle and possi-

ble serious injury or death.

■

Handling of the battery

●

Engine exhaust, some of its constitu-

ents, and a wide variety of automobile

components contain or emit chemicals

known to the State of California to

cause cancer and birth defects and

other reproductive harm. Work in a

well ventilated area.

●

Oils, fuels and fluids contained in vehi-

cles as well as waste produced by

component wear contain or emit

chemicals known to the State of Cali-

fornia to cause cancer and birth

defects or other reproductive harm.

Avoid exposure and wash any affected

area immediately.

●

Battery posts, terminals and related

accessories contain lead and lead

compounds which are known to cause

brain damage. Wash your hands after

handling. (



P.462)

General maintenance

Scheduled maintenance

449

6-2. Maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

3

Press

 or

 to select “Scheduled

Maintenance” and then press and hold
the .

4

Press

 or

 to select “Yes” and

then press

.

A message will be displayed when the reset

procedure has been completed.

You can perform some maintenance
procedures by yourself.
Please be aware that do-it-yourself
maintenance may affect warranty cov-
erage.

The use of Lexus repair manuals is recom-
mended.
For details about warranty coverage, refer
to the separate “Owner’s Guide”, “War-
ranty and Service Guide”, “Owner’s Man-
ual Supplement” or “Warranty Booklet”.

Do-it-yourself maintenance

General maintenance

Listed below are the general main-
tenance items that should be per-
formed at the intervals specified in
the “Warranty and Service Guide”
or “Owner’s Manual Supplement”.
It is recommended that any prob-
lem you notice should be brought to
the attention of your Lexus dealer
or qualified service shop for advice.

WARNING

■

If the engine is running

Turn the engine off and ensure that there

is adequate ventilation before perform-

ing maintenance checks.

Engine compartment

Items

Check points

Battery

Check the connections.
(



P.462)

Brake fluid

Is the brake fluid at the
correct level? (



P.461)

Engine/inter-
cooler coolant

Is the engine/intercooler
coolant at the correct
level? (



P.460)

Engine oil

Is the engine oil at the
correct level?
(



P.458)

Exhaust system

There should not be any
fumes or strange
sounds.

450

6-2. Maintenance

Engine radia-
tor/con-
denser/intercoo
ler radiator

The engine radiator,
condenser and inter-
cooler radiator should
be free from foreign
objects. (



P.461)

Washer fluid

Is there sufficient washer
fluid? (



P.464)

Vehicle interior

Items

Check points

Accelerator
pedal

• The accelerator pedal

should move smoothly
(without uneven pedal
effort or catching).

Automatic
transmission
“Park” mecha-
nism

• When  parked  on  a

slope and the shift
lever is in P, is the
vehicle securely
stopped?

Brake pedal

• Does the brake pedal

move smoothly?

• Does the brake pedal

have appropriate
clearance from the
floor?

• Does the brake pedal

have the correct
amount of free play?

Items

Check points

Brakes

• The vehicle should not

pull to one side when
the brakes are
applied.

• The brakes should

work effectively.

• The brake pedal

should not feel
spongy.

• The brake pedal

should not get too
close to the floor
when the brakes are
applied.

Head restraints

• Do  the  head  restraints

move smoothly and
lock securely?

Indica-
tors/buzzers

• Do the indicators and

buzzers function
properly?

Lights

• Do all the lights come

on?

• Are the headlights

aimed correctly?

Parking brake

• Does the parking

brake switch operate
normally?

• When parked on a

slope and the parking
brake is on, is the vehi-
cle securely stopped?

Seat belts

• Do  the  seat  belts

operate smoothly?

• The seat belts should

not be damaged.

Items

Check points

451

6-2. Maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

Seats

• Do the seat controls

operate properly?

Steering wheel

• Does the steering

wheel rotate
smoothly?

• Does the steering

wheel have the cor-
rect amount of free
play?

• There  should  not  be

any strange sounds
coming from the
steering wheel.

Vehicle exterior

Items

Check points

Doors

• Do the doors operate

smoothly?

Engine hood

• Does the engine hood

lock system work
properly?

Fluid leaks

• There  should  not  be

any signs of fluid leak-
age after the vehicle
has been parked.

Items

Check points

Tires

• Is the tire inflation

pressure correct?

• The tires should not

be damaged or exces-
sively worn.

• Have the tires been

rotated according to
the maintenance
schedule?

• The wheel nuts should

not be loose.

Windshield wip-
ers/rear win-
dow wiper

• The wiper blades

should not show any
signs of cracking,
splitting, wear, con-
tamination or defor-
mation.

• The wiper blades

should clear the wind-
shield/rear window
without streaking or
skipping.

Items

Check points

452

6-2. Maintenance

The OBD system determines that a
problem exists somewhere in the emis-
sion control system. Your vehicle may
not pass the I/M test and may need to
be repaired. Contact your Lexus
dealer to service the vehicle.



When the battery is disconnected
or discharged
Readiness codes that are set during
ordinary driving are erased.
Also, depending on your driving
habits, the readiness codes may not
be completely set.



When the fuel tank cap is loose
The malfunction indicator lamp
comes on indicating a temporary
malfunction and your vehicle may
not pass the I/M test.

The error code in the OBD system will
not be cleared unless the vehicle is
driven 40 or more times.

Contact your Lexus dealer to prepare
the vehicle for re-testing.

Emission inspection and
maintenance (I/M) pro-
grams

Some states have vehicle emission
inspection programs which include
OBD (On Board Diagnostics)
checks. The OBD system monitors
the operation of the emission con-
trol system.

If the malfunction indicator lamp
comes on

Your vehicle may not pass the
I/M test in the following situa-
tions:

When the malfunction indicator
lamp still remains on after sev-
eral driving trips

If your vehicle does not pass the
I/M test

453

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

6-3.Do-it-yourself maintenance

Do-it-yourself service pre-
cautions

If you perform maintenance by
yourself, be sure to follow the cor-
rect procedure as given in these
sections.

Maintenance

Items

Parts and tools

Battery condi-
tion (



P.462)

• Warm  water
• Baking soda
• Grease
• Conventional wrench

(for terminal clamp
bolts)

• Distilled water

Brake fluid level
(



P.461)

• FMVSS  No.116  DOT

3 or SAE J1703 brake
fluid
FMVSS No.116 DOT
4 or SAE J1704 brake
fluid

• Rag or paper towel
• Funnel (used only for

adding brake fluid)

Engine cool-
ant/intercooler
coolant level
(



P.460)

• “Toyota  Super  Long

Life Coolant” or a sim-
ilar high quality eth-
ylene glycol-based
non-silicate, non-
amine, non-nitrite and
non-borate coolant
with long-life hybrid
organic acid technol-
ogy

For the U.S.A.: “Toyota
Super Long Life Cool-
ant” is premixed with
50% coolant and 50%
deionized water.
For Canada: “Toyota
Super Long Life Cool-
ant” is premixed with
55% coolant and 45%
deionized water.
• Funnel (used only for

adding coolant)

Engine oil level
(



P.458)

• “Toyota  Genuine

Motor Oil” or equiva-
lent

• Rag or paper towel
• Funnel (used only for

adding engine oil)

Fuses (



P.481)

• Fuse  with  same

amperage rating as
original

Headlight aim
(



P.484)

• Phillips-head screw-

driver

Engine radiator,
condenser and
intercooler radi-
ator (



P.461)



Items

Parts and tools

454

6-3. Do-it-yourself maintenance

Tire inflation
pressure
(



P.474)

• Tire pressure gauge
• Compressed air

source

Washer fluid
(



P.464)

• Water or washer fluid

containing antifreeze
(for winter use)

• Funnel (used only for

adding water or
washer fluid)

Items

Parts and tools

WARNING

The engine compartment contains many

mechanisms and fluids that may move

suddenly, become hot, or become elec-

trically energized. To avoid death or seri-

ous injury, observe the following

precautions.

■

When working on the engine com-

partment

●

Keep hands, clothing and tools away

from the moving fan and engine drive

belt.

●

Be careful not to touch the engine,

engine radiator, exhaust manifold, etc.,

right after driving as they may be hot.

Oil and other fluids may also be hot.

●

Do not leave anything that may burn

easily, such as paper and rags, in the

engine compartment.

●

Do not smoke, cause sparks or expose

an open flame to fuel or the battery.

Fuel and battery fumes are flammable.

●

Be extremely cautious when working

on the battery. It contains poisonous

and corrosive sulfuric acid.

●

Take care because brake fluid can

harm your hands or eyes and damage

painted surfaces. If fluid gets on your

hands or in your eyes, flush the

affected area with clean water imme-

diately. If you still experience discom-

fort, consult a doctor.

■

When working near the cooling fan

or radiator grille

Be sure the engine switch is off. With the

engine switch in ON, the cooling fan may

automatically start to run if the air condi-

tioning is on and/or the coolant tempera-

ture is high. (



P.461)

■

When working on or under the vehi-

cle

Do not get under the vehicle with just the

jack supporting it. Always use automo-

tive jack stands or other solid supports.

455

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

1

Pull the hood lock release lever.

The hood will pop up slightly.

2

Pull up the auxiliary catch lever and
lift the hood.

WARNING

■

Safety glasses

Wear safety glasses to prevent flying or

falling material, fluid spray, etc., from get-

ting in your eyes.

NOTICE

■

If you remove the air cleaner filter

Driving with the air cleaner filter

removed may cause excessive engine

wear due to dirt in the air.

■

If the fluid level is low or high

It is normal for the brake fluid level to go

down slightly as the brake pads wear or

when the fluid level in the accumulator is

high.

If the reservoir needs frequent refilling, it

may indicate a serious problem.

Hood

Release the lock from the inside of
the vehicle to open the hood.

Opening the hood

WARNING

■

Pre-driving check

Check that the hood is fully closed and

locked.

If the hood is not locked properly, it may

open while the vehicle is in motion and

cause an accident, which may result in

death or serious injury.

456

6-3. Do-it-yourself maintenance

Fuse boxes (



P.481)

Battery (



P.462)

Intercooler coolant reservoir (



P.460)

Engine coolant reservoir (



P.460)

Engine oil filler cap (



P.459)

Radiator cooling fan (



P.461)

Engine oil level dipstick (



P.458)

Brake fluid reservoir (



P.461)

Washer fluid tank (



P.464)

Intercooler radiators (



P.461)

Engine radiator (



P.461)

Electric cooling fan

Condenser (



P.461)

Engine compartment

Components

A
B
C
D

E
F

G

H

I

J

K

L

M

457

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

■

Keep the engine compartment
cover opened

1

Push the tab in and pull the lock
release, and lift the cover.

2

Install the cover as shown in the
illustration.

■

Removing the engine compart-
ment cover

1

Push the tab in and pull the lock
release, and lift the cover.

2

Pull the cover toward the front of
the vehicle to remove it.

■

Installing the engine compartment
cover

Install the cover as shown in the illus-
tration.

Engine compartment cover

458

6-3. Do-it-yourself maintenance

With the engine at operating tempera-
ture and turned off, check the oil level
on the dipstick.

1

Park the vehicle on level ground.
After warming up the engine and
turning off the engine, wait about 5
minutes for the oil to drain back into
the bottom of the engine.

2

Holding a rag under the end, pull
the dipstick out.

3

Wipe the dipstick clean.

4

Reinsert the dipstick fully.

5

Holding a rag under the end, pull
the dipstick out and check whether
the oil level is above low level mark.

Low level mark

The shape of the dipstick may differ
depending on the type of vehicle or
engine.

6

Wipe the dipstick and reinsert it
fully.

■

Engine oil consumption

A certain amount of engine oil will be con-

sumed while driving. In the following situa-

tions, oil consumption may increase, and

engine oil may need to be refilled in

between oil maintenance intervals.

●

When the engine is new, for example

directly after purchasing the vehicle or

after replacing the engine

●

If low quality oil or oil of an inappropriate

viscosity is used

●

When driving at high engine speeds or

with a heavy load, when towing, or when

driving while accelerating or decelerat-

ing frequently

●

When leaving the engine idling for a long

time, or when driving frequently through

NOTICE

■

After installing an engine compart-

ment cover

Make sure the cover is securely installed

in its original position.

Checking the engine oil

NOTICE

■

To prevent serious engine damage

Check the oil level on a regular basis.

A

459

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

heavy traffic

■

Engine oil level rise

If the vehicle is repeatedly driven without

the engine warmed up, moisture caused by

dew condensation inside the engine or fuel

which did not burn mixes into the engine oil,

resulting in a rise in engine oil level. How-

ever, this is not a malfunction.
For example, the engine become difficult to

be warmed up in the following situations.

●

When driving a short distance

●

When driving at a low speed

●

When the outside temperature is low

When checking the engine oil, make sure

that the engine is warmed up. If the engine

oil level exceeds the refill upper limit mark,

contact your Lexus dealer.

■

Checking the oil type and prepar-
ing the items needed

Make sure to check the oil type and
prepare the items needed before add-
ing oil.



Engine oil selection



P.536



Oil quantity (Low level mark





Refill upper limit mark)

1.6 qt. (1.5 L, 1.3 Imp.qt.)



Items

Clean funnel

■

Adding engine oil

If the oil level is below or near the low
level mark, add engine oil of the same
type as that already in the engine.

1

Remove the oil filler cap by turning
it counterclockwise.

2

Add engine oil slowly, checking the
dipstick.

Make sure that the oil level does not

exceed the refill upper limit mark and is

between the low level mark and refill upper

limit mark.

Low level mark

Refill upper limit mark

The shape of the dipstick may differ
depending on the type of vehicle or
engine.

3

Install the oil filler cap by turning it
clockwise.

■

After changing the engine oil

The engine oil maintenance data
should be reset. Perform the following
procedures:

1

Press

 or

 of the meter con-

trol switches to select

.

Adding engine oil

A
B

460

6-3. Do-it-yourself maintenance

2

Press

 or

 to select “Vehicle

Settings” and then press

.

3

Press

 or

 to select “Oil

Maintenance” and then press

.

4

Press

 or

 to select “Yes” and

then press

.

“Reset complete” will be displayed when
the reset procedure has been completed.

■

Engine coolant reservoir

The coolant level is satisfactory if it is
between the “F” and “L” lines on the
reservoir when the engine is cold.

Reservoir cap

“F” line

“L” line

If the level is on or below the “L” line, add
coolant up to the “F” line. (



P.528)

■

Intercooler coolant reservoir

The coolant level is satisfactory if it is
between the “F” and “L” lines on the
reservoir when the engine is cold.

WARNING

■

Used engine oil

●

Used engine oil contains potentially

harmful contaminants which may

cause skin disorders such as inflamma-

tion and skin cancer, so care should be

taken to avoid prolonged and

repeated contact. To remove used

engine oil from your skin, wash thor-

oughly with soap and water.

●

Dispose of used oil and filters only in a

safe and acceptable manner. Do not

dispose of used oil and filters in house-

hold trash, in sewers or onto the

ground. Call your Lexus dealer, ser-

vice station or auto parts store for

information concerning recycling or

disposal.

●

Do not leave used engine oil within the

reach of children.

NOTICE

■

When replacing the engine oil

●

Be careful not to spill engine oil on the

vehicle components.

●

Avoid overfilling, or the engine could

be damaged.

●

Check the oil level on the dipstick

every time you refill the vehicle.

●

Be sure the engine oil filler cap is prop-

erly tightened.

■

After changing the engine oil

Make sure to reset the engine oil mainte-

nance data. If it is not reset, the next

maintenance timing will not be displayed

properly.

Checking the coolant

A

B

C

461

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

Reservoir cap

“F” line

“L” line

If the level is on or below the “L” line, add
coolant up to the “F” line. (



P.528)

■

Coolant selection

Only use “Toyota Super Long Life Coolant”

or a similar high quality ethylene glycol

based non-silicate, non-amine, non-nitrite,

and non-borate coolant with long-life

hybrid organic acid technology.
U.S.A.:
“Toyota Super Long Life Coolant” is a mix-

ture of 50% coolant and 50% deionized

water. (Minimum temperature: -31°F [-

35°C])
Canada:
“Toyota Super Long Life Coolant” is a mix-

ture of 55% coolant and 45% deionized

water. (Minimum temperature: -44°F [-

42°C])
For more details about coolant, contact

your Lexus dealer.

■

If the coolant level drops within a short

time of replenishing

Visually check the engine radiator, hoses,

engine coolant reservoir cap, intercooler

radiator, intercooler coolant reservoir cap,

drain cock and water pump.
If you cannot find a leak, have your Lexus

dealer, test the cap and check for leaks in

the cooling system.

Check the engine radiator, condenser
and intercooler radiator and clear any
foreign objects. If any of the above
parts are extremely dirty or you are not
sure of their condition, have your vehi-
cle inspected by your Lexus dealer.

■

Keep the engine compartment
cover opened or removing the
cover



P.457

■

Checking fluid level

The brake fluid level should be
between the “MAX” and “MIN” lines
on the tank.

WARNING

■

When the engine is hot

Do not remove the engine coolant reser-

voir cap or intercooler coolant reservoir

cap.

The cooling system may be under pres-

sure and may spray hot coolant if the cap

is removed, causing serious injuries, such

as burns.

A

B

C

NOTICE

■

When adding coolant

Coolant is neither plain water nor

straight antifreeze. The correct mixture

of water and antifreeze must be used to

provide proper lubrication, corrosion

protection and cooling. Be sure to read

the antifreeze or coolant label.

■

If you spill coolant

Be sure to wash it off with water to pre-

vent it from damaging parts or paint.

Checking the engine radiator,
condenser and intercooler radi-
ator

WARNING

■

When the engine is hot

Do not touch the engine radiator, con-

denser or intercooler radiator as they

may be hot and cause serious injuries,

such as burns.

Checking and adding the brake
fluid

462

6-3. Do-it-yourself maintenance

■

Adding fluid

Make sure to check the fluid type and
prepare the necessary item.



Fluid type

FMVSS No.116 DOT 3 or SAE J1703
brake fluid
FMVSS No.116 DOT 4 or SAE J1704
brake fluid



Items

Clean funnel

■

Refilling brake fluid

1

Turn the engine switch off.

2

Depress the brake pedal more than
40 times.

3

Remove the reservoir cap by hand.
Add brake fluid up to the “MAX”
line. If you do not follow the proce-
dure above, the reservoir may
overflow

■

Brake fluid can absorb moisture from

the air

Excess moisture in the brake fluid can

cause a dangerous loss of braking effi-

ciency. Use only newly opened brake fluid.

Check the battery as follows.

■

Keep the engine compartment
cover opened or removing the
cover



P.457

■

Battery exterior

Make sure that the battery terminals
are not corroded and that there are no
loose connections, cracks, or loose
clamps.

WARNING

■

When filling the reservoir

Take care as brake fluid can harm your

hands and eyes and damage painted sur-

faces.

If fluid gets on your hands or in your eyes,

flush the affected area with clean water

immediately.

If you still experience discomfort, see a

doctor.

NOTICE

■

If the fluid level is low or high

It is normal for the brake fluid level to go

down slightly as the brake pads wear out

or when the fluid level in the accumulator

is high.

If the reservoir needs frequent refilling,

there may be a serious problem.

Checking the battery

463

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

Terminals

Clamp

■

Checking battery fluid

Check that the level is between the
upper and lower lines.

Upper line

Lower line

If the fluid level is at or below the lower line,
add distilled water.

■

Checking the battery condition
(vehicles with battery indicator)

Check the battery condition by indica-
tor color.

Red and clear: Replacement is nec-
essary. Have the battery checked
by your Lexus dealer.

Clear and red: Charging is neces-
sary. Have the vehicle inspected by
your Lexus dealer.

Blue and red: Good condition

■

Adding distilled water

1

Remove the vent plug.

2

Add distilled water.

If the upper line cannot be seen, check the

fluid level by looking directly at the cell.

LOW

O.K.

3

Put the vent plug back on and close
it securely.

■

Install the engine compartment
cover



P.457

■

Before recharging

When recharging, the battery produces

hydrogen gas which is flammable and

explosive. Therefore, observe the following

precautions before recharging:

●

If recharging with the battery installed on

the vehicle, be sure to disconnect the

ground cable.

●

Make sure the power switch on the char-

ger is off when connecting and discon-

necting the charger cables to the battery.

■

After recharging/reconnecting the bat-

tery

The engine may not start. Follow the proce-

dure below to initialize the system.

1

Shift the shift lever to P.

2

Open and close any of the doors.

3

Restart the engine.

A
B

A
B

A

B

C

A
B

464

6-3. Do-it-yourself maintenance

●

Unlocking the doors using the smart

access system with push-button start may

not be possible immediately after recon-

necting the battery. If this happens, use

the wireless remote control or the

mechanical key to lock/unlock the doors.

●

Start the engine with the engine switch in

ACC. The engine may not start with the

engine switch turned off. However, the

engine will operate normally from the

second attempt.

●

The engine switch mode is recorded by

the vehicle. If the battery is reconnected,

the vehicle will return the engine switch

mode to the status it was in before the

battery was disconnected. Make sure to

turn off the engine before disconnect the

battery. Take extra care when connect-

ing the battery if the engine switch mode

prior to discharge is unknown.

If the engine will not start even after multiple
attempts, contact your Lexus dealer.

If none of the washer does not work or
the “Windshield Washer Fluid Low”
appears on the multi-information dis-
play, the washer tank may be empty.

WARNING

■

Chemicals in the battery

A battery contains poisonous and corro-

sive sulfuric acid and may produce

hydrogen gas which is flammable and

explosive. To reduce the risk of death or

serious injury, take the following precau-

tions while working on or near the bat-

tery:

●

Do not cause sparks by touching the

battery terminals with tools.

●

Do not smoke or light a match near the

battery.

●

Avoid contact with eyes, skin and

clothes.

●

Never inhale or swallow electrolyte.

●

Wear protective safety glasses when

working near the battery.

●

Keep children away from the battery.

■

Where to safely charge the battery

Always charge the battery in an open

area. Do not charge the battery in a

garage or closed room where there is

not sufficient ventilation.

■

Emergency measures regarding

electrolyte

●

If electrolyte gets in your eyes

Flush your eyes with clean water for at

least 15 minutes and get immediate

medical attention. If possible, continue

to apply water with a sponge or cloth

while traveling to the nearest medical

facility.

●

If electrolyte gets on your skin

Wash the affected area thoroughly. If

you feel pain or burning, get medical

attention immediately.

●

If electrolyte gets on your clothes

It can soak through clothing on to your

skin. Immediately take off the clothing

and follow the procedure above if nec-

essary.

●

If you accidentally swallow electrolyte

Drink a large quantity of water or milk.

Get emergency medical attention

immediately.

NOTICE

■

When recharging the battery

Never recharge the battery while the

engine is running. Also, be sure all acces-

sories are turned off.

■

When adding distilled water

Avoid overfilling. Water spilled during

battery recharging may cause corrosion.

Adding the washer fluid

465

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

Add washer fluid.

Check if the treadwear indicators are
showing on the tires. Also check the
tires for uneven wear, such as exces-
sive wear on one side of the tread.
Check the spare tire condition and
pressure if not rotated.

New tread

Worn tread

Treadwear indicator

The location of treadwear indicators is
shown by a “TWI” or “

” mark, etc.,

molded into the sidewall of each tire.
Replace the tires if the treadwear indica-
tors are showing on a tire.

WARNING

■

When adding washer fluid

Do not add washer fluid when the engine

is hot or running as washer fluid contains

alcohol and may catch fire if spilled on

the engine, etc.

NOTICE

■

Do not use any fluid other than

washer fluid

Do not use soapy water or engine anti-

freeze instead of washer fluid.

Doing so may cause streaking on the

vehicle’s painted surfaces, as well as

damaging the pump leading to problems

of the washer fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as neces-

sary.

Refer to the freezing temperatures listed

on the label of the washer fluid bottle.

Tires

Replace or rotate tires in accor-
dance with maintenance schedules
and treadwear.

Checking tires

A

B

C

466

6-3. Do-it-yourself maintenance

■

When to replace your vehicle’s tires

Tires should be replaced if:

●

The treadwear indicators are showing on

a tire.

●

You have tire damage such as cuts, splits,

cracks deep enough to expose the fabric,

and bulges indicating internal damage.

●

A tire goes flat repeatedly or cannot be

properly repaired due to the size or loca-

tion of a cut or other damage.

If you are not sure, consult with your Lexus

dealer.

■

Tire life

Any tire over 6 years old must be checked

by a qualified technician even if it has sel-

dom or never been used or damage is not

obvious.

■

Maximum load of tire

Check that the number given by dividing

the maximum load by 1.10 of the replace-

ment tire is greater than 1/2 of the Gross

Axle Weight Ratings (GAWR) of either the

front axle or the rear axle, whichever is

greater.
For the GAWR, see the Certification Label.

For the maximum load of the tire, see the

load limit at maximum cold tire inflation

pressure mentioned on the sidewall of the

tire. (



P.544)

■

Tire types

●

Summer tires

Summer tires are high-speed perfor-

mance tires best suited to highway driv-

ing under dry conditions. Since summer

tires do not have the same traction per-

formance as snow tires, summer tires are

inadequate for driving on snow-covered

or icy roads. For driving on snow-cov-

ered roads or icy roads, the use of snow

tires is recommended. When installing

snow tires, be sure to replace all four

tires.

●

All season tires

All season tires are designed to provide

better traction in snow and to be ade-

quate for driving in most winter condi-

tions as well as for use year-round. All

season tires, however, do not have ade-

quate traction performance compared

with snow tires in heavy or loose snow.

Also, all season tires fall short in accelera-

tion and handling performance com-

pared with summer tires in highway

driving.

●

Snow tires

For driving on snow-covered roads or icy

roads, we recommend using snow tires. If

you need snow tires, select tires of the

same size, construction and load capacity

as the originally installed tires. Since your

vehicle has radial tires as original equip-

ment, make sure your snow tires also

have radial construction. Do not install

studded tires without first checking local

regulations for possible restrictions.

Snow tires should be installed on all

wheels. (



P.372)

■

If the tread on snow tires wears down

below 0.16 in. (4 mm)

The effectiveness of the tires as snow tires is

lost.

WARNING

■

When inspecting or replacing tires

Observe the following precautions to

prevent accidents.

Failure to do so may cause damage to

parts of the drive train as well as danger-

ous handling characteristics, which may

lead to an accident resulting in death or

serious injury.

●

Do not mix tires of different makes,

models or tread patterns.

Also, do not mix tires of remarkably

different treadwear.

●

Do not use tire sizes other than those

recommended by Lexus.

467

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

Rotate the tires in the order shown.

To equalize tire wear and extend tire life,
Lexus recommends that tire rotation is car-
ried out at the same interval as tire inspec-
tion.

Do not fail to initialize the tire pressure
warning system after tire rotation.

■

When rotating the tires

Make sure that the engine switch is OFF. If

the tires are rotated while the engine switch

is in ON, the tire position information will

not be updated.
If this accidentally occurs, either turn the

engine switch to OFF and then to ON, or

initialize the system after checking that the

tire pressure is properly adjusted.

Your vehicle is equipped with a tire
pressure warning system that uses tire
pressure warning valves and transmit-
ters to detect low tire inflation pressure
before serious problems arise.
The tire pressure warning system of
this vehicle adopts a 2-type warning
system



When “Adjust Pressure” is dis-
played (Normal Warning)

The tire pressure warning light comes on
and a buzzer sounds when the tire inflation
pressure becomes low due to natural air
leakage or outside temperature. (Ways of
coping:



P.502, 540)



When “Immediately Check Tire
when Safe” is displayed (Emergency
Warning)

The tire pressure warning light comes on
and a buzzer sounds when the tire inflation
pressure becomes low suddenly due to a
blowout. (Ways of coping:



P.502, 511)

However, the system may not be able to
detect sudden tire ruptures (bursting, etc.).



The tire pressure detected by the
tire pressure warning system can be
displayed on the multi-information

WARNING

●

Do not mix differently constructed

tires (radial, bias-belted or bias-ply

tires).

●

Do not mix summer, all season and

snow tires.

●

Do not use tires that have been used

on another vehicle.

Do not use tires if you do not know

how they were used previously.

NOTICE

■

Driving on rough roads

Take particular care when driving on

roads with loose surfaces or potholes.

These conditions may cause losses in tire

inflation pressure, reducing the cushion-

ing ability of the tires. In addition, driving

on rough roads may cause damage to

the tires themselves, as well as the vehi-

cle’s wheels and body.

■

If tire inflation pressure of each tire

becomes low while driving

Do not continue driving, or your tires

and/or wheels may be ruined.

Tire rotation

Tire pressure warning system

468

6-3. Do-it-yourself maintenance

display.

The unit can be changed.

■

How to change the unit

1

Park the vehicle in a safe place and
turn the engine switch off.

Changing the unit cannot be performed

while the vehicle is moving.

2

Turn the engine switch to ON.

3

Press

 or

 of the meter con-

trol switches on the steering wheel
and select

.

4

Press

 or

 of the meter con-

trol switches and select “Vehicle
Settings”, and then press

.

5

Press

 or

 of the meter con-

trol switches and select “TPWS set-
ting”, and then press

.

6

Press

 or

 of the meter con-

trol switches and select “Setting
Unit”, and then press

.

7

Press

 or

 of the meter con-

trol switches and select the desired
unit, and then press

.

■

Routine tire inflation pressure checks

The tire pressure warning system does not

replace routine tire inflation pressure

checks. Make sure to check tire inflation

pressure as part of your routine of daily

vehicle checks.

■

Tire inflation pressure

●

It may take a few minutes to display the

tire inflation pressure after the engine

switch is turned to ON. It may also take a

few minutes to display the tire inflation

pressure after inflation pressure has been

adjusted.

●

Tire inflation pressure changes with tem-

perature. The displayed values may also

be different from the values measured

using a tire pressure gauge.

■

Situations in which the tire pressure

warning system may not operate prop-

erly

●

In the following cases, the tire pressure

warning system may not operate prop-

erly.

• If non-genuine Lexus wheels are used.

• A tire has been replaced with a tire that is

not an OE (Original Equipment) tire.

• A tire has been replaced with a tire that is

not of the specified size.

• Tire chains, etc. are equipped.

• An auxiliary-supported run-flat tire is

equipped.

• If a window tint that affects the radio wave

signals is installed.

• If there is a lot of snow or ice on the vehi-

cle, particularly around the wheels or

wheel housings.

• If the tire inflation pressure is extremely

higher than the specified level.

• If wheels without tire pressure warning

valves and transmitters are used.

• If the ID code on the tire pressure warn-

ing valves and transmitters is not regis-

tered in the tire pressure warning

computer.

●

Performance may be affected in the fol-

lowing situations.

• Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

• When carrying a portable radio, cellular

phone, cordless phone or other wireless

communication device

If tire position information is not correctly

469

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

displayed due to the radio wave conditions,
the display may be corrected by driving and
changing the radio wave conditions.

●

When the vehicle is parked, the time

taken for the warning to start or go off

could be extended.

●

When tire inflation pressure declines rap-

idly for example when a tire has burst, the

warning may not function.

When replacing tires or wheels, tire
pressure warning valves and transmit-
ters must also be installed.

When new tire pressure warning valves
and transmitters are installed, new ID
codes must be registered in the tire pres-
sure warning computer and the tire pres-
sure warning system must be initialized.
(



P.471)

■

When replacing the tires and wheels

If the ID code of the tire pressure warning

valve and transmitter is not registered, the

tire pressure warning system will not work

properly. After driving for about 20 min-

utes, the tire pressure warning light blinks

for 1 minute and stays on to indicate a sys-

tem malfunction.

■

The tire pressure warning system
must be initialized in the following
circumstances:



When rotating the tires.



When changing the tire size.



When changing between two regis-
tered wheel sets.



After registering the ID codes.
(



P.471)

When the tire pressure warning sys-
tem is initialized, the current tire infla-
tion pressure is set as the benchmark
pressure.

■

How to initialize the tire pressure
warning system

1

Park the vehicle in a safe place and
stop the engine for 20 minutes or
more.

Installing tire pressure warning
valves and transmitters

NOTICE

■

Repairing or replacing tires, wheels,

tire pressure warning valves, trans-

mitters and tire valve caps

●

When removing or fitting the wheels,

tires or the tire pressure warning

valves and transmitters, contact your

Lexus dealer as the tire pressure warn-

ing valves and transmitters may be

damaged if not handled correctly.

●

Make sure to install the tire valve caps.

If the tire valve caps are not installed,

water could enter the tire pressure

warning valves and the tire pressure

warning valves could be bound.

●

When replacing tire valve caps, do not

use tire valve caps other than those

specified. The cap may become stuck.

■

To avoid damage to the tire pressure

warning valves and transmitters

When a tire is repaired with liquid seal-

ants, the tire pressure warning valve and

transmitter may not operate properly. If a

liquid sealant is used, contact your Lexus

dealer or other qualified service shop as

soon as possible. Make sure to replace

the tire pressure warning valve and

transmitter when repairing or replacing

the tire. (



P.467)

Initializing the tire pressure
warning system

470

6-3. Do-it-yourself maintenance

2

Adjust the tire inflation pressure to
the specified cold tire inflation
pressure level.

Make sure to adjust the tire pressure to the

specified cold tire inflation pressure level.

The tire pressure warning system will oper-

ate based on this pressure level.

3

Turn the engine switch to ON.

Initialization cannot be performed while

the vehicle is moving.

4

Press

 or

 of the meter con-

trol switches on the steering wheel
and select

.

5

Press

 or

 of the meter con-

trol switches and select “Vehicle
Settings”, and then press

.

6

Press

 or

 of the meter con-

trol switches and select “TPWS set-
ting”, and then press

.

7

Press

 or

 of the meter con-

trol switches and select the “Set
Pressure”. Then press and hold



until the tire pressure warning light
blinks 3 times.

Then “Set Pressure Accepted” will be dis-

played on the multi-information display. “--

-” will be displayed on the multi-informa-

tion display for the inflation pressure of

each tire while initialization is being per-

formed.

8

Drive straight (with occasional left
and right turns) at approximately
25 mph (40 km/h) or more for
approximately 10 to 30 minutes.

When initialization is complete, the infla-

tion pressure of each tire will be displayed

on the multi-information display.
Even if the vehicle is not driven at approxi-

mately 25 mph (40 km/h) or more, initial-

ization can be completed by driving for a

long time. However, if initialization does

not complete after driving for 1 hour or

more, park the vehicle in a safe place for

approximately 20 minutes and then drive

the vehicle again.

■

When initializing

●

Initialization is performed while driving at

a vehicle speed of approximately 25 mph

(40 km/h) or more.

●

Make sure to carry out initialization after

adjusting the tire inflation pressure. Also,

make sure the tires are cold before carry-

ing out initialization or tire inflation pres-

sure adjustment.

●

The tire pressure warning system can be

initialized by yourself, but depending on

the driving conditions and driving envi-

ronment, initialization may take some

time to complete.

■

The initialization operation

●

If you have accidentally turned the engine

switch to OFF during initialization, it is not

necessary to restart the initialization

again as initialization will restart automat-

ically when the engine switch has been

turned to ON for the next time.

●

If you accidentally perform initialization

when initialization is not necessary, adjust

the tire inflation pressure to the specified

level when the tires are cold, and conduct

initialization again.

●

While the position of each tire is being

determined and the inflation pressures

are not being displayed on the multi-

information display, if the inflation pres-

sure of a tire drops, the tire pressure

warning light will come on.

471

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

■

If the tire pressure warning system is not

initialized properly

●

In the following situations, initialization

may take longer than usual to be com-

pleted or may not be possible. Normally,

initialization completes within approxi-

mately 30 minutes.

• Vehicle is not driven at approximately 25

mph (40 km/h) or more

• Vehicle is driven on unpaved roads
If initialization does not complete after driv-
ing for 1 hour or more, park the vehicle in a
safe place for approximately 20 minutes
and then drive the vehicle again.

●

If the vehicle is reversed during initializa-

tion, the data up to that point is reset, so

perform the initialization procedure

again from the beginning.

●

In the following situations, initialization

will not be started or was not completed

properly and the system will not operate

properly. Perform the initialization pro-

cedure again.

• If, when attempting to start initialization,

the tire pressure warning light does not

blink 3 times.

• If, when the vehicle has been driven for

about 20 minutes after performing initial-

ization, the tire pressure warning light

blinks for approximately 1 minute and

then illuminates.

●

If initialization cannot be completed after

performing the above procedure, con-

tact your Lexus dealer.

■

The ID codes must be registered in
the following circumstances:



When installing the new tire pres-
sure warning valve and transmitters



When installing already registered
tire pressure warning valve and
transmitters (such as replacing sum-
mer and winter tire, etc.)

Every tire pressure warning valve and
transmitter has a unique ID code. It is nec-
essary to register the ID code in the tire
pressure warning computer

■

How to register the ID codes

1

Park the vehicle in a safe place and
turn the engine switch off for 20
minutes or more.

2

Turn the engine switch to ON.
(



P.188)

3

Press

 or

 of the meter con-

trol switches on the steering wheel
and select

.

4

Press

 or

 of the meter con-

trol switches and select “Vehicle
Settings”, and then press

.

5

Press

 or

 of the meter con-

trol switches and select “TPWS set-
ting”, and then press

.

6

Press

 or

 of the meter con-

trol switches and select “Change
Wheel Set”. Then press and hold

 until the tire pressure warning

light starts slowly blinking 3 times.

Then “Identify Wheel Accepted” will be

displayed on the multi-information display.

WARNING

■

When initializing the tire pressure

warning system

Do not initialize tire inflation pressure

without first adjusting the tire inflation

pressure to the specified level. Other-

wise, the tire pressure warning light may

not come on even if the tire inflation

pressure is low, or it may come on when

the tire inflation pressure is actually nor-

mal.

Registering ID codes

472

6-3. Do-it-yourself maintenance

When registration is being performed, the

tire pressure warning light will blink for

approximately 1 minute then illuminate and

“---” will be displayed for the inflation pres-

sure of each tire on the multi-information

display.

7

Drive straight (with occasional left
and right turns) at approximately
25 mph (40 km/h) or more for
approximately 10 to 30 minutes.

Registration is complete when the tire

pressure warning light turns off and the

inflation pressure of each tire is displayed

on the multi-information display.
Registration may take longer than approxi-

mately 1 hour in certain situations, such as

when the vehicle is stopped for a long time

at traffic lights, etc.

8

Initialize the tire pressure warning
system. (



P.469)

■

When registering ID codes

●

ID code registration is performed while

driving at a vehicle speed of approxi-

mately 25 mph (40 km/h) or more.

●

Before performing ID code registration,

make sure that no wheels with tire pres-

sure warning valve and transmitters

installed are near the vehicle.

●

Make sure to initialize the tire pressure

warning system after registering the ID

codes. If the system is initialized before

registering the ID codes, the initialized

values will be invalid.

●

As the tires will be warm when registra-

tion is completed, make sure to allow the

tires to cool before performing initializa-

tion.

●

ID codes can be registered by yourself,

but depending on the driving conditions

and driving environment, registration

may take some time to complete.

■

Canceling ID code registration

●

To cancel ID code registration after it has
been started, select “Change Wheel Set”
on the multi-information display and
press and hold

 again.

●

If ID code registration has been can-

celed, the tire pressure warning light will

blink for approximately 1 minute when the

engine switch is turned to ON and then

illuminate. The tire pressure warning sys-

tem will be operational when the tire

pressure warning light turns off.

●

If the warning light does not turn off even

after several minutes have elapsed, ID

code registration may not have been

canceled correctly. To cancel registra-

tion, perform the ID code registration

start procedure again and then turn the

engine switch off before driving.

■

If ID codes are not registered properly

●

In the following situations, ID code regis-

tration may take longer than usual to be

completed or may not be possible. Nor-

mally, registration completes within

approximately 30 minutes.

If ID code registration is not complete

after driving for approximately 30 min-

utes, continue driving for a while.

• Vehicle is not parked for approximately

20 minutes or more before driving

• Vehicle is not driven at approximately 25

mph (40 km/h) or more

• Vehicle is driven on unpaved roads

• Vehicle is driven near other vehicles and

system cannot recognize tire pressure

warning valve and transmitters of your

vehicle over those of other vehicles

• Wheel with tire pressure warning valve

and transmitter installed is inside or near

the vehicle

If registration does not complete after driv-
ing for 1 hour or more, perform the ID code
registration procedure again from the
beginning.

473

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

●

If the vehicle is reversed during registra-

tion, the data up to that point is reset, so

perform the registration procedure again

from the beginning.

●

In the following situations, ID code regis-

tration will not be started or was not com-

pleted properly and the system will not

operate properly. Perform the ID code

registration procedure again.

• If, when attempting to start ID code regis-

tration, the tire pressure warning light

does not blink slowly 3 times.

• If, when the vehicle has been driven for

about 20 minutes after performing ID

code registration, the tire pressure warn-

ing light blinks for approximately 1 minute

and then illuminates.

If the ID codes cannot be registered even
when performing the above procedure,
contact your Lexus dealer.

Your vehicle is equipped with tire
pressure warning system with the func-
tion to have ID codes registered for a
second wheel set, for example a winter
set. You can register a second wheel
set by yourself or your Lexus dealer.
After registration of a second wheel
set, either of these two wheel sets can
be selected for usage with the tire
pressure warning system.

■

Operating conditions for the func-
tion



This function will perform the
change of wheel set only if a second
wheel set has been registered. If no
second wheel set has been regis-
tered, no change will be made when
selecting this function in the menu.



Only a change between both regis-
tered wheel set is possible, mixing

between these wheel sets is not sup-
ported.

■

How to change between wheel
sets

1

Park the vehicle in a safe place and
fit the vehicle with your preferred
wheel set.

2

Press

 or

 of the meter con-

trol switches on the steering wheel
and select

.

3

Press

 or

 of the meter con-

trol switches and select “Vehicle
Settings”, and then press

.

4

Press

 or

 of the meter con-

trol switches and select “TPWS set-
ting”, and then press

.

5

Press

 or

 of the meter con-

trol switches and select “Change
Wheel Set”. Then press and hold

 until the tire pressure warning

light starts slowly blinking 3 times.

Afterward, the tire pressure warning light

turns on after flashing for 1 minute.

After 2 minutes, changing the ID codes of

a second wheel set is being performed.

The tire pressure warning light will turn off.

6

Initialize the tire pressure warning
system. (



P.469)

Selecting wheel set

474

6-3. Do-it-yourself maintenance

If the tire inflation pressure settings for the

installed tires change, initialization opera-

tions are required, but if the tire inflation

pressure settings are the same, initializa-

tion is not required.

7

Drive straight (with occasional left
and right turns) at approximately
25 mph (40 km/h) or more for
approximately 10 to 30 minutes.

Changing a second wheel set is complete

when the tire pressure warning light turns

off and the inflation pressure of each tire is

displayed on the multi-information display.

The recommended cold tire inflation
pressure and tire size are displayed on
the tire and loading information label.
(



P.540)

Tire valve

Tire inflation pressure

Checking the specified tire infla-
tion pressure

Inspection and adjustment pro-
cedure

A

475

6-3. Do-it-yourself maintenance

6

Mai
nte

na

nc

e a

nd

 c

are

Tire pressure gauge

1

Remove the tire valve cap.

2

Press the tip of the tire pressure
gauge onto the tire valve.

3

Read the pressure using the gauge
gradations.

4

If the tire inflation pressure is not at
the recommended level, adjust the
pressure.
If you add too much air, press the
center of the valve to deflate.

5

After completing the tire inflation
pressure measurement and adjust-
ment, apply soapy water to the
valve and check for leakage.

6

Put the tire valve cap back on.

■

Tire inflation pressure check interval

You should check tire inflation pressure

every two weeks, or at least once a month.

Do not forget to check the spare.

■

Effects of incorrect tire inflation pres-

sure

Driving with incorrect tire inflation pressure

may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor han-

dling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drive train

If a tire needs frequent refilling, have it

checked by your Lexus dealer.

■

Instructions for checking tire inflation

pressure

When checking tire inflation pressure,

observe the following:

●

Check only when the tires are cold.

If your vehicle has been parked for at

least 3 hours or has not been driven for

more than 1 mile or 1.5 km, you will get an

accurate cold tire inflation pressure read-

ing.

●

Always use a tire pressure gauge.

It is difficult to judge if a tire is properly

inflated based only on its appearance.

●

It is normal for the tire inflation pressure

to be higher after driving as heat is gener-

ated in the tire. Do not reduce tire infla-

tion pressure after driving.

●

Never exceed the vehicle capacity

weight. Passengers and luggage weight

should be placed so that the vehicle is

balanced.

B

WARNING

■

Proper inflation is critical to save tire

performance

Keep your tires properly inflated.

If the tires are not properly inflated, the

following conditions may occur which

could lead to an accident resulting in

death or serious injury:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting from

overheated tires

●

Air leaking from between tire and

wheel

●

Wheel deformation and/or tire dam-

age

●

Greater possibility of tire damage

while driving (due to road hazards,

expansion joints, sharp edges in the

road, etc.)
