Lexus ES300H (2024 year). Manual in english

2-1. Instrument cluster

Vehi

cle

status

inform

ati

on a

nd i

ndic
ators

■

Display procedure

Select

on the main menu.

Select “Trip information”.

Select “History”.

■

Display

Latest fuel consumption

Best recorded fuel consumption

Previous fuel consumption record

Resetting the history data

Updating the latest fuel consump-
tion data

Use the displayed average fuel consump-
tion as a reference.
The image is an example only, and may
vary slightly from actual conditions.

■

Updating the history data

Update the latest fuel consumption by

selecting “Update” to measure the current

fuel consumption again.

■

Resetting the data

The fuel consumption data can be deleted

by selecting “Clear data”.

■

Trip range

Displays the estimated maximum distance

that can be driven with the quantity of fuel

remaining.

This distance is computed based on your

average fuel consumption.

As a result, the actual distance that can be

driven may differ from that displayed.

History screen

A
B
C
D

fore
dri
ving

Before driving

3-1. Key information

Keys .................................................

100

3-2. Opening, closing and locking the

doors and trunk

Doors...............................................

104

Trunk................................................

108

Smart access system with push-

button start..................................

115

3-3. Adjusting the seats

Front seats.....................................

120

Driving position memory .........

121

Head restraints............................

124

3-4. Adjusting the steering wheel and

mirrors

Steering wheel.............................

126

Inside rear view mirror.............

127

Outside rear view mirrors......

128

3-5. Opening and closing the win-

dows and moon roof

Power windows............................

131

Moon roof .....................................

133

100

3-1. Key information

3-1.Key information

The following keys are provided with
the vehicle.

Electronic keys

• Operating the smart access system with

push-button start (



P.115)

• Operating the wireless remote control

function

Mechanical keys

Key number plate

Card key (electronic key) (if
equipped)

Operating the smart access system with
push-button start (



P.115)

■

Card key (if equipped)

●

The card key is not waterproof.

●

The mechanical key that is stored inside

the card key should be used only if a

problem arises, such as when the card

key does not operate properly.

●

If it is difficult to take out the mechanical

key, push down the lock release button

using a pen tip etc. If it is still difficult to

pull it out, use a coin etc.

●

To store the mechanical key in the card

key, insert it while pressing the lock

release button.

●

If the battery cover is not installed and the

battery falls out or if the battery was

removed because the key got wet, rein-

stall the battery with the positive terminal

facing the Lexus emblem.

■

When riding in an aircraft

When bringing an electronic key onto an

aircraft, make sure you do not press any

buttons on the electronic key while inside

the aircraft cabin. If you are carrying an

electronic key in your bag etc., ensure that

the buttons are not likely to be pressed

accidentally. Pressing a button may cause

the electronic key to emit radio waves that

could interfere with the operation of the air-

craft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years.

(The card key battery life is from one year

to one year and a half.)

●

If the battery becomes low, an alarm will

sound in the cabin when the hybrid sys-

tem is stopped.

●

Battery-saving mode can reduce the

Keys

Key types

B
C
D

101

3-1. Key information

fore
dri
ving

power consumption of electronic keys

that are not used for long periods of time.

(



P.117)

●

As the electronic key always receives

radio waves, the battery will become

depleted even if the electronic key is not

used. The following symptoms indicate

that the electronic key battery may be

depleted. Replace the battery when nec-

essary. (



P.343)

• The smart access system with push-but-

ton start or the wireless remote control

does not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface

does not turn on.

You can replace the battery by yourself
(



P.343). However, as there is a danger

that the electronic key may be damaged, it
is recommended that replacement be car-
ried out by your Lexus dealer.

●

To avoid serious deterioration, do not

leave the electronic key within 3 ft. (1 m)

of the following electrical appliances that

produce a magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones and

battery chargers

• Recharging cellular phones or cordless

phones

• Table lamps

• Induction cookers

■

Replacing the battery



P.343

■

Confirmation of the registered key

number

The number of keys already registered to

the vehicle can be confirmed. Ask your

Lexus dealer for details.

■

If “A New Key has been Registered

Contact Your Dealer for Details” is

shown on the multi-information display

This message will be displayed each time

the driver’s door is opened when the doors

are unlocked from the outside for approxi-

mately 10 days after a new electronic key

has been registered.

If this message is displayed but you have not

had a new electronic key registered, ask

your Lexus dealer to check if an unknown

electronic key (other than those in your

possession) has been registered.

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to

strong shocks or bend them.

●

Do not expose the keys to high tem-

peratures for long periods of time.

●

Do not get the keys wet or wash them

in an ultrasonic washer etc.

●

Do not attach metallic or magnetic

materials to the keys or place the keys

close to such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else

to the surface of the electronic key.

●

Do not place the keys near objects that

produce magnetic fields, such as TVs,

audio systems and induction cookers.

●

Do not place the keys near medical

electrical equipment such as low-fre-

quency therapy equipment or micro-

wave therapy equipment, and do not

receive medical attention with the keys

on your person.

■

Carrying the electronic key on your

person

Carry the electronic key 3.9 in. (10 cm)

or more away from electric appliances

that are turned on. Radio waves emitted

from electric appliances within 3.9 in. (10

cm) of the electronic key may interfere

with the key, causing the key to not func-

tion properly.

■

In case of a smart access system with

push-button start malfunction or

other key-related problems



P.385

■

When an electronic key is lost



P.384

102

3-1. Key information

The electronic keys are equipped with
the following wireless remote control:

Locks the doors (



P.104)

Unlocks the doors (



P.104)

Opens the windows and moon
roof

(



Opens the trunk (

Sounds the alarm (

: This setting must be customized at your

Lexus dealer.

■

Theft deterrent panic mode

When

is pressed for longer than

about one second, an alarm will sound
intermittently and the vehicle lights will flash
to deter any person from trying to break
into or damage your vehicle.
To stop the alarm, press any button on the

electronic key.

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be inserted in

NOTICE

■

Handling the card key (if equipped)

●

Do not apply excess force when

inserting the mechanical key into the

card key. Doing so may damage the

card key.

●

If the battery or card key terminals get

wet, the battery may corrode and the

card key may stop working.

If the key is dropped into water, or if

drinking water, etc. is spilled on the

key, immediately remove the battery

cover and wipe the battery and termi-

nals. (To remove the battery cover,

lightly grasp and pull it.) If the battery is

corroded, have your Lexus dealer

replace the battery.

●

Do not crush the battery cover or use

a screwdriver to remove the battery

cover. Forcibly removing the battery

cover may bend or damage the key.

●

If the battery cover is frequently

removed, the battery cover may

become loose.

●

When installing the battery, make sure

to check the direction of the battery.

Installing the battery in the wrong

direction may cause the battery to

deplete rapidly.

●

The surface of the card key may be

damaged, or its coating may peel off in

the following situations:

• The card key is carried together with

hard objects, such as coins and keys.

• The card key is scraped with a sharp

object, such as the tip of a mechanical

pencil.

• The surface of the card key is wiped

with thinner or benzene.

Wireless remote control

Using the mechanical key

103

3-1. Key information

fore
dri
ving

one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
(



P.385)

■

When required to leave the vehicle’s

key with a parking attendant

Turn the trunk opener main switch off

(



P.114), lock the glove box (



P.280)

and armrest door (



P.294) as circum-

stances demand.

Remove the mechanical key for your own

use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys



P.384

104

3-2. Opening, closing and locking the doors and trunk

3-2.Opening, closing and locking the doors and trunk

■

Smart access system with push-
button start

Carry the electronic key to enable this
function.

Grip the driver’s door handle to
unlock the door. Holding the
driver’s door handle for approxi-
mately 2 seconds unlocks all the
doors. Grip the passenger’s door
handle to unlock all the doors.

Make sure to touch the sensor on the back
of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

: The door unlock settings can be

changed.

Touch the lock sensor (the indenta-
tion on the upper part of the door
handle) to lock all the doors.

Check that the door is securely locked.

■

Wireless remote control

Locks all the doors

Check that the door is securely locked.

Unlocks all the doors

Pressing the button unlocks the driver’s
door. Pressing the button again within 5
seconds unlocks the other doors.
Press and hold to open the windows and
moon roof.

: This setting must be customized at your

Lexus dealer.

■

Switching the door unlock function

It is possible to set which doors the entry

function unlocks using the wireless remote

control.

Turn the power switch off.

When the indicator light on the key sur-
face is not on, press and hold

for approximately 5

seconds while pressing and holding

The setting changes each time an operation

is performed, as shown below. (When

changing the setting continuously, release

the buttons, wait for at least 5 seconds, and

repeat step

Doors

Unlocking and locking the doors
from the outside

105

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

To prevent unintended triggering of the
alarm, unlock the doors using the wireless
remote control and open and close a door
once after the settings have been changed.
(If a door is not opened within 60 seconds
after

is pressed, the doors will be

locked again and the alarm will automati-
cally be set.)
In a case that the alarm is triggered, imme-
diately stop the alarm. (



P.68)

■

Impact detection door lock release sys-

tem

In the event that the vehicle is subject to a

strong impact, all the doors are unlocked.

Depending on the force of the impact or the

type of accident, however, the system may

not operate.

■

Operation signals

A buzzer sounds and the emergency flash-

ers flash to indicate that the doors have

been locked/unlocked. (Locked: once;

Unlocked: twice)
A buzzer sounds to indicate that the win-

dows and moon roof are opening.

■

Security feature

If a door is not opened within approximately

60 seconds after the vehicle is unlocked,

the security feature automatically locks the

vehicle again. (However, depending on the

location of the electronic key, the key may

be detected as being in the vehicle. In this

case, vehicle may be unlocked.)

■

When the doors cannot be locked by

the lock sensor on the upper part of the

door handle

When the doors cannot be locked even if

the lock sensor on the surface of the door

handle is touched by a finger, touch the lock

sensor with the palm.
If you are wearing gloves, remove them.

■

Door lock buzzer

If an attempt to lock the doors using the

smart access system with push-button start

is made when a door other than the door

you are locking is open, a buzzer sounds

continuously for 5 seconds. Fully close all

the doors, and lock the vehicle once more.

■

Setting the alarm

Locking the doors will set the alarm system.

(



P.68)

■

Conditions affecting the operation of

the smart access system with push-but-

ton start or wireless remote control



P.117

■

If the smart access system with push-

button start or the wireless remote con-

trol does not operate properly

Use the mechanical key to lock and unlock

the doors. (



P.385)

Replace the key battery with a new one if it

is depleted. (



P.343)

■

If the 12-volt battery is discharged

The doors cannot be locked and unlocked

Multi-information

display/Beep

Unlocking function

Exterior: Beeps 3

times

Interior: Pings

once

Holding the driver’s
door handle unlocks
only the driver’s door.

Holding a passenger’s
door handle unlocks all
the doors.

Exterior: Beeps

twice

Interior: Pings

once

Holding a door handle
unlocks all the doors.

106

3-2. Opening, closing and locking the doors and trunk

using the smart access system with push-

button start or wireless remote control.

Lock or unlock the doors using the

mechanical key. (



P.385)

■

Rear seat reminder function

●

In order to remind you not to forget lug-

gage, etc. in the rear seat, when the

power switch is turned off after any of the

following conditions are met, a buzzer

will sound and a message will be dis-

played on the multi-information display

for approximately 6 seconds.

• The hybrid system is started within 10

minutes after opening and closing a rear

door.

• A rear door has been opened and closed

after the hybrid system was started.

However, if a rear door is opened and then

closed within approximately 2 seconds, the

rear seat reminder function may not oper-

ate.

●

The rear seat reminder function deter-

mines that luggage, etc. has been placed

in a rear seat based on opening and clos-

ing of a rear door. Therefore, depending

on the situation, the rear seat reminder

function may not operate and you may

still forget luggage, etc. in the rear seat,

or it may operate unnecessarily.

●

The rear seat reminder function can be

enabled/disabled. (



P.417)

■

Customization

Settings (e.g. unlocking function using a

key) can be changed.

(Customizable features:



P.417)

■

Door lock switches (to
lock/unlock)

Locks all the doors

Unlocks all the doors

■

Inside lock buttons (to lock)

Push down the inside lock button to
lock the door.

WARNING

■

To prevent an accident

Observe the following precautions while

driving the vehicle.

Failure to do so may result in a door

opening and an occupant being thrown

out of the vehicle, resulting in death or

serious injury.

●

Ensure that all doors are properly

closed and locked.

●

Do not pull the inside handle of the

doors while driving.

Be especially careful for the front

doors, as the doors may be opened

even if the inside lock buttons are in

locked position.

●

Set the rear door child-protector locks

when children are seated in the rear

seats.

■

When opening or closing a door

Check the surroundings of the vehicle

such as whether the vehicle is on an

incline, whether there is enough space

for a door to open and whether a strong

wind is blowing. When opening or clos-

ing the door, hold the door handle tightly

to prepare for any unpredictable move-

ment.

Unlocking and locking the doors
from the inside

107

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

■

Inside door handles (to unlock)



For the front doors

Pull the handle to unlock and open the
door.

When the door is unlocked, the inside lock
button will pop up.



For the rear doors

Pull the handle to unlock the door. Pull
the handle a second time to open the
door.

When the door is unlocked, the inside lock
button will pop up.

■

Locking the front doors from the outside

without a key

Push down the inside lock button.

Close the door.

The door cannot be locked if the power

switch is in ACCESSORY or ON mode, or

the electronic key is left inside the vehicle.

However, the key may not be detected cor-

rectly and the door may be locked.

■

Open door warning buzzer

If the vehicle speed reaches 3 mph (5

km/h), a buzzer sounds to indicate that the

door(s), the hood or the trunk is not fully

closed.

The open door(s), the hood or the trunk is

displayed on the multi-information display.

The door cannot be opened from
inside the vehicle when the lock is set.

Unlock

Lock

These locks can be set to prevent children
from opening the rear doors. Push down
on each rear door switch to lock both rear
doors.

The following functions can be set or
canceled:

For instructions on customizing, refer to
P.417.

Rear door child-protector lock

Automatic door locking and
unlocking systems

108

3-2. Opening, closing and locking the doors and trunk

Function

Operation

Speed linked
door locking
function

All doors are automati-
cally locked when vehi-
cle speed is
approximately 12 mph
(20 km/h) or higher.

Shift position
linked door lock-
ing function

All doors are automati-
cally locked when the
shift lever is shifted to a
position other than P.

Shift position
linked door
unlocking func-
tion

All doors are automati-
cally unlocked when
the shift lever is shifted
to P.

Driver’s door
linked door
unlocking func-
tion

All doors are automati-
cally unlocked when
driver’s door is opened
within approximately
45 seconds after turn-
ing the power switch
off.

Trunk

The trunk can be opened using the
trunk opener switch, entry function
or wireless remote control.
If the vehicle is equipped with a
power trunk lid, the trunk can be
closed using the trunk closer.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

Before driving

●

Make sure that the trunk lid is fully

closed. If the trunk lid is not fully

closed, it may open unexpectedly

while driving and hit near-by objects or

luggage in the trunk may be thrown

out, causing an accident.

●

Do not allow children to play in the

trunk.

If a child is accidentally locked in the

trunk, they could suffer from heat

exhaustion, suffocation or other inju-

ries.

●

Do not allow a child to open or close

the trunk lid.

Doing so may cause the trunk lid to

open unexpectedly, or cause the

child’s hands, head, or neck to be

caught by the closing trunk lid.

■

Important points while driving

Never let anyone sit in the trunk. In the

event of sudden braking or a collision,

they are susceptible to death or serious

injury.

■

Using the trunk

Observe the following precautions.

Failure to do so may cause parts of the

body to be caught, resulting in serious

injury.

109

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

WARNING

●

Remove any heavy loads, such as

snow and ice, from the trunk lid before

opening it. Failure to do so may cause

the trunk lid to suddenly shut again

after it is opened.

●

When opening or closing the trunk lid,

thoroughly check to make sure the

surrounding area is safe.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the trunk is about to open or close.

●

Use caution when opening or closing

the trunk lid in windy weather as it may

move abruptly in strong wind.

●

Vehicles without power trunk lid: The

trunk lid may suddenly shut if it is not

opened fully. It is more difficult to open

or close the trunk lid on an incline than

on a level surface, so beware of the

trunk lid unexpectedly opening or

closing by itself. Make sure that the

trunk lid is fully open and secure

before using the trunk.

●

When closing the trunk lid, take extra

care to prevent your fingers etc. from

being caught.

●

Vehicles without power trunk lid:

When closing the trunk lid, make sure

to press it lightly on its outer surface. If

the trunk grip is used to fully close the

trunk lid, it may result in hands or arms

being caught.

●

Do not attach any accessories other

than genuine Lexus parts to the trunk

lid. Such additional weight on the trunk

lid may cause the lid to suddenly shut

again after it is opened.

■

Trunk easy closer (vehicles with

power trunk lid)

In the event that the trunk lid is left slightly

open, the trunk easy closer will automati-

cally close it to the fully closed position. It

takes several seconds before the trunk

easy closer begins to operate. Be careful

not to catch fingers or anything else in

the trunk lid, as this may cause bone frac-

tures or other serious injuries.

■

Power trunk lid (if equipped)

Observe the following precautions when

operating the power trunk lid.

Failure to do so may cause serious injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the trunk is about to open or close.

●

If the trunk closer switch is pressed

while the trunk lid is opening during

automatic operation, the trunk lid

stops opening. Take extra care when

on an incline, as the trunk lid may open

or close suddenly.

110

3-2. Opening, closing and locking the doors and trunk

■

Trunk opener switch

Press the trunk opener switch.

WARNING

●

On an incline, the trunk lid may sud-

denly shut after it opens automatically.

Make sure the trunk lid is fully open

and secure before using the trunk.

●

In the following situations, the power

trunk lid may detect an abnormality

and automatic operation may be

stopped. In this case, the trunk lid has

to be operated manually. Take extra

care in this situation, as the stopped

trunk lid may suddenly shut, causing an

accident.

• When the trunk lid contacts an obsta-

cle

• When the 12-volt battery voltage sud-

denly drops, such as when the power

switch is turned to ON mode or the

hybrid system is started during auto-

matic operation

●

Do not attach any accessories other

than genuine Lexus parts to the trunk

lid. The power trunk lid may not oper-

ate, causing itself to malfunction, or the

trunk lid may suddenly shut again after

it is opened.

■

Hands Free Power Trunk Lid (vehi-

cles with power trunk lid)

Observe the following precautions.

Failure to do so may cause serious injury.

●

Exhaust gases cause the exhaust pipes

to become quite hot. When operating

the Hands Free Power Trunk Lid, be

careful not to touch the exhaust pipe.

●

Do not operate the Hands Free Power

Trunk Lid if there is little space under

the rear bumper.

■

Jam protection function (vehicles

with power trunk lid)

Observe the following precautions.

Failure to do so may cause serious injury.

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets caught just

before the trunk lid fully closes. Be

careful not to catch fingers or anything

else in the trunk lid.

●

The jam protection function may not

work depending on the shape of the

object that is caught. Be careful not to

catch fingers or anything else.

NOTICE

■

To prevent trunk easy closer mal-

functions (vehicles with power trunk

lid)

Do not apply force to the trunk lid while

the trunk easy closer is operating.

■

To prevent damage to the power

trunk lid (vehicles with power trunk

lid)

●

Make sure that there is no luggage or

snow on the trunk lid before operating

the power trunk lid. In addition, make

sure that there is no ice between the

trunk lid and frame that prevents

movement of the trunk lid. Operating

the power trunk lid when excessive

load is present on the trunk lid may

cause a malfunction.

●

Do not apply excessive force to the

trunk lid while the power trunk lid is

operating.

Opening/closing the trunk

111

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

■

Smart access system with push-
button start

While carrying the electronic key,
press the button.
When all the doors are unlocked using
one of the following methods, the trunk
can be opened without the electronic
key:



Entry function



Wireless remote control



Door lock switches



Automatic door unlocking system



Mechanical key

■

Wireless remote control

Press and hold the switch.

A buzzer sounds.

■

Hands Free Power Trunk Lid (vehi-
cles with power trunk lid)

While carrying an electronic key,
stand within the smart access sys-
tem with push-button start opera-
tion range, approximately 11.8 to
19.7 in. (30 to 50 cm) from the rear
bumper.

Kick sensor

Hands Free Power Trunk Lid oper-
ation detection area

Smart access system with push-
button start operation detection
area (



P.116)

Perform a kick operation by mov-
ing your foot to within approxi-
mately 3.9 in. (10 cm) of the rear
bumper, and then pulling your foot
back after the buzzer sounds.

• Perform the entire kick operation

within 1 second.

A
B

112

3-2. Opening, closing and locking the doors and trunk

• The trunk lid will not start operating

while a foot is detected under the
rear bumper.

• Operate the Hands Free Power

Trunk Lid without contacting the
rear bumper with your foot.

• If another electronic key is in the

cabin or trunk, it may take slightly
longer than normal for the opera-
tion to occur.

• If the buzzer sounds twice, wait for 3

seconds or more and then perform
a kick operation again.

Kick sensor

Hands Free Power Trunk Lid oper-
ation detection area

When the kick sensor detects that
your foot is pulled back, a buzzer
will sound and the trunk will auto-
matically fully open/close.

If a foot is moved under the rear bumper

while the trunk lid is opening, the trunk lid

will stop moving.

If a foot is moved under the rear bumper

while the trunk lid is closing, the trunk lid

will open.

■

Trunk closer switch (vehicles with
power trunk lid)

Press the trunk closer switch.

A buzzer will sound and the trunk lid will
fully close.

Pressing the switch while the trunk lid is
closing opens the trunk lid again.

■

Trunk grip

Using the trunk grip, pull down the
trunk lid without applying sideways
force and push the trunk lid down from
the outside to close it.

■

Trunk light

The trunk light turns on when the trunk is

opened.

■

Trunk easy closer (vehicles with power

trunk lid)

In the event that the trunk lid is left slightly

open, the trunk easy closer will automati-

cally close it to the fully closed position.

●

The trunk easy closer will operate

regardless of the power switch mode.

●

If the trunk easy closer does not operate,

open the trunk to the half open position

or more and then close it.

■

Function to prevent the trunk being

locked with the electronic key inside

●

When all doors are locked, closing the

trunk lid with the electronic key left inside

A
B

113

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

the trunk will sound an alarm.

In this case, the trunk lid can be opened

by pressing the trunk release button on

the trunk lid.

●

If the spare electronic key is put in the

trunk with all the doors locked, the key

confinement prevention function is acti-

vated so the trunk can be opened. In

order to prevent theft, take all electronic

keys with you when leaving the vehicle.

●

If the electronic key is put in the trunk

with all the doors locked, the key may not

be detected depending on the location of

the key and the surrounding radio wave

conditions. In this case, the key confine-

ment prevention function cannot be acti-

vated, causing the doors to lock when the

trunk is closed. Make sure to check

where the key is before closing the trunk.

●

The key confinement prevention function

cannot be activated if any one of the

doors is unlocked. In this case, open the

trunk using the trunk opener.

■

Overload protection function (vehicles

with power trunk lid)

The trunk lid will not operate when exces-

sive load is present on the top of the trunk

lid.

■

Fall-down protection function (vehicles

with power trunk lid)

While the trunk lid is opening automatically,

applying excessive force to it will stop the

opening operation to prevent the trunk lid

from rapidly falling down.

■

Jam protection function (vehicles with

power trunk lid)

While the trunk lid is closing automatically,

the trunk lid will stop closing and open if

something gets caught.

■

Internal trunk release lever

The trunk lid can be opened by pulling the

glow-in-the-dark lever located on the inside

of the trunk to the side. The lever will con-

tinue to glow for some time after the trunk

lid is closed.

■

Using the mechanical key

The trunk can be also opened using the

mechanical key. (



P.385)

If the trunk is unlocked using the mechani-

cal key, the power trunk lid and trunk easy

closer will not be operational. To return

them to an operational state, fully close the

trunk lid by hand.

■

If the smart access system with push-

button start or the wireless remote con-

trol does not operate properly

Use the mechanical key to unlock the trunk.

(



P.385)

Replace the key battery with a new one if it

is depleted. (



P.343)

■

Hands Free Power Trunk Lid operating

conditions (vehicles with power trunk

lid)

●

When the Hands Free Power Trunk Lid

(kick sensor) operation setting is turned

on and the power switch is turned off

●

When an electronic key is carried within

the operation range

■

Situations in which the Hands Free

Power Trunk Lid may not operate prop-

erly (vehicles with power trunk lid)

In the following situations, the Hands Free

Power Trunk Lid may not operate properly:

●

When a foot remains under the rear

bumper

●

If the rear bumper is strongly hit with a

foot or is touched for a while

If the rear bumper has been touched for a

while, wait for a short time before

attempting to operate the Hands Free

Power Trunk Lid again.

●

When operated while a person is too

close to the rear bumper

●

When an external radio wave source

114

3-2. Opening, closing and locking the doors and trunk

interferes with the communication

between the electronic key and the vehi-

cle (



P.117)

●

When the vehicle is parked near an elec-

trical noise source or metallic object

which affects the sensitivity of the Hands

Free Power Trunk Lid, such as a pay

parking spot, gas station, electrically

heated road, fluorescent light, or above a

steel plate.

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When mud, snow, ice, etc. is attached to

the rear bumper

●

When the vehicle has been parked for a

while near objects that may move and

contact the rear bumper, such as plants

●

When an accessory is installed to the rear

bumper

If an accessory has been installed, turn

the Hands Free Power Trunk Lid (kick

sensor) operation setting off.

■

Preventing unintentional operation of

the Hands Free Power Trunk Lid (vehi-

cles with power trunk lid)

When an electronic key is in the operation

range, the Hands Free Power Trunk Lid

may operate unintentionally, so be careful

in the following situations.

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When dirt is wiped off the rear bumper

●

When a small animal or small object, such

as a ball, moves under the rear bumper

●

When an object is moved from under the

rear bumper

●

If someone is swinging their legs while sit-

ting on the rear bumper

●

If the legs or another part of someone’s

body contacts the rear bumper while

passing by the vehicle

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Trunk

Lid, such as a pay parking spot, gas sta-

tion, electrically heated road, or fluores-

cent light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When the vehicle is parked in a place

where objects such as plants are near the

rear bumper

●

If luggage, etc. is set near the rear

bumper

●

If accessories or a vehicle cover is

installed/removed near the rear bumper

●

When the vehicle is being towed

To prevent unintentional operation, turn the
Hands Free Power Trunk Lid (kick sensor)
operation setting off.

■

Open door warning buzzer



P.107

■

Customization

Some functions can be customized. (Cus-

tomizable features:



P.417)

The trunk opener switch can be tem-
porarily disabled to protect luggage
stored in the trunk against theft.
Turn the trunk opener main switch in
the glove box off to disable the trunk
opener.

Protecting luggage against theft

115

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

Off

When the trunk opener main switch is off,
the trunk lid cannot be opened even with
the wireless remote control, entry function
or Hands Free Power Trunk Lid (if
equipped).

■

When leaving a key to the vehicle with a

parking attendant



P.103

■

Antenna location

Antennas outside the cabin

Antennas inside the cabin

Antenna inside the trunk

Antenna outside the trunk

A
B

Smart access system with
push-button start

The following operations can be
performed simply by carrying the
electronic key (including the card
key) on your person, for example in
your pocket. The driver should
always carry the electronic key.



Locks and unlocks the doors
(



P.104)



Opens the trunk (



P.111)



Starts the hybrid system
(



P.148)

116

3-2. Opening, closing and locking the doors and trunk

■

Effective range (areas within which the

electronic key is detected)

When locking or unlocking the doors
The system can be operated when the
electronic key is within about 2.3 ft. (0.7
m) of an outside door handle. (Only the
doors detecting the key can be oper-
ated.)

When opening the trunk
The system can be operated when the
electronic key is within about 2.3 ft. (0.7
m) of the trunk release button.

When starting the hybrid system or
changing power switch modes
The system can be operated when the
electronic key is inside the vehicle.

■

If an alarm sounds or a warning message

is displayed

An alarm sounds and warning messages

are displayed on the multi-information dis-

play to protect against unexpected acci-

dents or theft of the vehicle resulting from

erroneous operation. When a warning

message is displayed, take appropriate

measures based on the displayed message.
When only an alarm sounds, circumstances

and correction procedures are as follows.

●

When an exterior alarm sounds once for

5 seconds

●

When an interior alarm sounds continu-

ously

■

If “Key Detected in Vehicle” is shown on

the multi-information display

An attempt was made to lock the doors

using the smart access system with push-

button start while the electronic key was still

inside the vehicle. Retrieve the electronic

key from the vehicle and lock the doors

again.

Situation

Correction proce-

dure

The trunk was
closed while the
electronic key was
still inside the trunk
and all the doors
were locked.

Retrieve the elec-
tronic key from the
trunk and close the
trunk lid.

An attempt was
made to lock the
vehicle while a door
was open.

Close all of the
doors and lock the
doors again.

Situation

Correction proce-

dure

The power switch
was turned to
ACCESSORY
mode while the
driver’s door was
open (or the driver’s
door was opened
while the power
switch was in
ACCESSORY
mode).

Turn the power
switch off and close
the driver’s door.

The power switch
was turned off while
the driver’s door
was open.

Close the driver’s
door.

117

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

■

Battery-saving function

The battery-saving function will be acti-

vated in order to prevent the electronic key

battery and the 12-volt battery from being

discharged while the vehicle is not in opera-

tion for a long time.

●

In the following situations, the smart

access system with push-button start may

take some time to unlock the doors.

• The electronic key has been left within

approximately 6 ft. (2 m) of the outside of

the vehicle for 10 minutes or longer.

• The smart access system with push-but-

ton start has not been used for 5 days or

longer.

●

If the smart access system with push-but-

ton start has not been used for 14 days or

longer, the doors cannot be unlocked at

any doors except the driver’s door. In this

case, take hold of the driver’s door han-

dle, or use the wireless remote control or

mechanical key, to unlock the doors.

■

Turning an electronic key to battery-

saving mode

●

When battery-saving mode is set, battery
depletion is minimized by stopping the
electronic key from receiving radio
waves.
Press

twice while pressing and

holding

. Confirm that the elec-

tronic key indicator flashes 4 times.
While the battery-saving mode is set, the
smart access system with push-button
start cannot be used. To cancel the func-
tion, press any of the electronic key but-
tons.

●

Electronic keys that will not be used for

long periods of time can be set to the bat-

tery-saving mode in advance.

■

When electronic key function stops

If the position of the electronic key has not

changed for a certain amount of time such

as when the electronic key is left some-

where, the function of the electronic key

stops to reduce depletion of the battery.

■

Conditions affecting operation

The smart access system with push-button

start uses weak radio waves. In the follow-

ing situations, the communication between

the electronic key and the vehicle may be

affected, preventing the smart access sys-

tem with push-button start, wireless remote

control and immobilizer system from oper-

ating properly.

(Ways of coping:



P.385)

●

When the electronic key battery is

depleted

●

Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

●

When the electronic key is in contact

with, or is covered by the following metal-

lic objects

• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil

inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that emit

radio waves) are being used nearby

●

When carrying the electronic key

together with the following devices that

emit radio waves

• Portable radio, cellular phone, cordless

phone or other wireless communication

device

• Another electronic key or a wireless key

that emits radio waves

• Personal computers or personal digital

assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic content or

metallic objects are attached to the rear

window

118

3-2. Opening, closing and locking the doors and trunk

●

When the electronic key is placed near a

battery charger or electronic devices

●

When the vehicle is parked in a pay park-

ing spot where radio waves are emitted.

■

Notes for the entry function

●

Even when the electronic key is within the

effective range (detection areas), the sys-

tem may not operate properly in the fol-

lowing cases:

• The electronic key is too close to the win-

dow or outside door handle, near the

ground, or in a high place when the doors

are locked or unlocked.

• The electronic key is near the ground or

in a high place, or too close to the center

of the rear bumper when the trunk is

opened.

• The electronic key is on the instrument

panel, rear package tray or floor, or in the

door pockets or glove box when the

hybrid system is started or power switch

modes are changed.

●

Do not leave the electronic key on top of

the instrument panel or near the door

pockets when exiting the vehicle.

Depending on the radio wave reception

conditions, it may be detected by the

antenna outside the cabin and the doors

will become lockable from the outside,

possibly trapping the electronic key

inside the vehicle.

●

As long as the electronic key is within the

effective range, the doors may be locked

or unlocked by anyone. However, only

the doors detecting the electronic key

can be used to unlock the vehicle.

●

Even if the electronic key is not inside the

vehicle, it may be possible to start the

hybrid system if the electronic key is near

the window.

●

The doors may unlock or lock if a large

amount of water splashes on the door

handle, such as in the rain or in a car

wash, when the electronic key is within

the effective range. (The doors will auto-

matically be locked after approximately

60 seconds if the doors are not opened

and closed.)

●

If the wireless remote control is used to

lock the doors when the electronic key is

near the vehicle, there is a possibility that

the door may not be unlocked by the

entry function. (Use the wireless remote

control to unlock the doors.)

●

Touching the door lock sensor while

wearing gloves may delay or prevent

lock operation. Remove the gloves and

touch the lock sensor again.

●

When the lock operation is performed

using the lock sensor, recognition signals

will be shown up to two consecutive

times. After this, no recognition signals

will be given.

●

Unlocking the vehicle may take more

time if another electronic key is within the

effective range.

●

If the door handle becomes wet while the

electronic key is within the effective

range, the door may lock and unlock

repeatedly. In this case, follow the follow-

ing correction procedures to wash the

vehicle:

• Place the electronic key in a location 6 ft.

(2 m) or more away from the vehicle.

(Take care to ensure that the key is not

stolen.)

• Set the electronic key to battery-saving

mode to disable the smart access system

with push-button start. (



P.117)

●

If the electronic key is inside the vehicle

and a door handle becomes wet during a

car wash, a message may be shown on

the multi-information display and a

buzzer will sound outside the vehicle. To

turn off the alarm, lock all the doors.

●

The lock sensor may not work properly if

it comes into contact with ice, snow, mud,

etc.

Clean the lock sensor and attempt to

operate it again.

●

A sudden approach to the effective

range or door handle may prevent the

doors from being unlocked. In this case,

return the door handle to the original

position and check that the doors unlock

before pulling the door handle again.

■

When the vehicle is not driven for

extended periods

●

To prevent theft of the vehicle, do not

leave the electronic key within 6 ft. (2 m)

of the vehicle.

119

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

●

The smart access system with push-but-

ton start can be deactivated in advance.

●

Battery-saving mode can reduce the

power consumption of electronic keys.

(



P.117)

■

To operate the system properly

●

Make sure to carry the electronic key

when operating the system. Do not get

the electronic key too close to the vehicle

when operating the system from the out-

side of the vehicle.

Depending on the position and holding

condition of the electronic key, the key

may not be detected correctly and the

system may not operate properly. (The

alarm may go off accidentally, or the door

lock prevention function may not oper-

ate.)

●

Do not leave the electronic key inside the

trunk.

The key confinement prevention function

may not operate, depending on the loca-

tion of the key (close to a spare tire, the

inside edge of the trunk), conditions

(inside a metal bag, close to metallic

objects) and the radio waves in the sur-

rounding area. (



P.112)

■

If an electronic key does not work prop-

erly

●

If the doors cannot be locked or

unlocked and the trunk cannot be

opened, perform the following.

• Bring the electronic key close to the door

handle and perform a lock or unlock

operation.

• Bring the electronic key close to the but-

ton on the trunk (



P.111) and press the

button.

• Use the wireless remote control.
If the doors cannot be locked or unlocked
by perform the above, use the mechanical
key. (



P.385)

For Canada: However, if the mechanical
key is used while the alarm system is set, the
warning will sound. (



P.68)

●

If the hybrid system cannot be started,

refer to P.386

■

Customization

Settings (e. g. smart access system with

push-button start) can be changed.

(Customizable features:



P.417)

If the smart access system with push-button

start has been deactivated in a customized

setting, refer to the explanations for the fol-

lowing operations.

●

Locking and unlocking the doors and

opening the trunk:

Use the wireless remote control or

mechanical key. (



P.104, 111, 385)

●

Starting the hybrid system and changing

power switch modes:



P.386

●

Stopping the hybrid system:



P.149

WARNING

■

Caution regarding interference with

electronic devices

●

People with implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should keep

away from the smart access system

with push-button start antennas.

(



P.115)

The radio waves may affect the opera-

tion of such devices. If necessary, the

entry function can be disabled. Ask

your Lexus dealer for details, such as

the frequency of radio waves and tim-

ing of the emitted radio waves. Then,

consult your doctor to see if you

should disable the entry function.

●

Users of any electrical medical device

other than implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should con-

sult the manufacturer of the device for

information about its operation under

the influence of radio waves.

Radio waves could have unexpected

effects on the operation of such medi-

cal devices.

Ask your Lexus dealer for details on dis-

abling the entry function.

120

3-3. Adjusting the seats

3-3.Adjusting the seats

Seat position adjustment

Seatback angle adjustment

Seat cushion (front) angle adjust-
ment

Vertical height adjustment

Lumbar support adjustment

Pelvic support adjustment (if
equipped for driver’s side)

Seat cushion length adjustment (if
equipped)

■

When adjusting the seat

●

Make sure that no surrounding passen-

gers or objects are in contact with the

seat.

●

Take care when adjusting the seat so that

the head restraint does not touch the ceil-

ing.

■

Power easy access system (if equipped)

The driver’s seat and steering wheel move

in accordance with power switch mode and

the driver’s seat belt condition. (



P.121)

Front seats

The seats can be adjusted (longitu-
dinally, vertically, etc.). Adjust the
seat to ensure the correct driving
posture.

Adjustment procedure

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat

position to ensure that other passen-

gers are not injured by the moving

seat.

●

Do not put your hands under the seat

or near the moving parts to avoid

injury.

Fingers or hands may become

jammed in the seat mechanism.

●

Make sure to leave enough space

around the feet so they do not get

stuck.

■

Seat adjustment

To reduce the risk of sliding under the lap

belt during a collision, do not recline the

seat more than necessary.

If the seat is too reclined, the lap belt may

slide past the hips and apply restraint

forces directly to the abdomen, or your

neck may contact the shoulder belt,

increasing the risk of death or serious

injury in the event of an accident.

Adjustments should not be made while

driving as the seat may unexpectedly

move and cause the driver to lose con-

trol of the vehicle.

121

3-3. Adjusting the seats

fore
dri
ving

: If equipped

When all of the following have been
performed, the driver’s seat and steer-
ing wheel are automatically adjusted to
a position that allows the driver to
enter and exit the vehicle easily.



The shift lever has been shifted to P.



The power switch has been turned
off.



The driver’s seat belt has been
unfastened.

When any of the following has been
performed, the driver’s seat and steer-
ing wheel automatically return to their
original positions.



The power switch has been turned
to ACCESSORY mode or ON
mode.



The driver’s seat belt has been fas-
tened.

■

Operation of the power easy access

system

●

When exiting the vehicle, the power easy

access system may not operate if the seat

is already in the rearmost or uppermost

position or close to the rear seat.

●

If the seat position is adjusted during

power easy access system operation, the

automatic operation will stop. (The seat

will change to manual operation.)

●

If the seat position is adjusted during or

after the power easy access system oper-

ation when the driver is exiting the vehi-

cle, the power easy access system will not

operate when entering the vehicle.

■

Customization

The seat movement amount settings of the

power easy access system can be custom-

ized. (Customizable features:



P.417)

Check that the shift lever is in P.

Turn the power switch to ON
mode.

Adjust the driver’s seat, steering
wheel, outside rear view mirrors
and head-up display (if equipped)
to the desired positions.

While pressing the “SET” button, or
within 3 seconds after the “SET”

Driving position memory

This feature automatically adjusts
the positions of the driver’s seat,
steering wheel, outside rear view
mirrors and head-up display (if
equipped) to make entering and
exiting the vehicle easier or to suit
your preferences.
Up to 3 different driving positions
can be recorded.
Each electronic key (including a
card key) can be registered to
recall your preferred driving posi-
tion.

Power easy access system

Recording a driving position into
memory

122

3-3. Adjusting the seats

button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.

If the selected button has already been

preset, the previously recorded position

will be overwritten.

■

Seat positions that can be memorized

(



P.120)

The positions adjusted by the following pro-

cedure can be recorded:

●

Seat position adjustment

●

Seatback angle adjustment

●

Seat cushion (front) angle adjustment

●

Vertical height adjustment

■

In order to correctly use the driving

position memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

may be slightly different when it is recalled.

Check that the shift lever is in P.

Turn the power switch to ON
mode.

Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

■

To stop the position recall operation

part-way through

Perform any of the following:

●

Press the “SET” button.

●

Press button “1”, “2” or “3”.

●

Operate any of the seat adjustment

switches (only cancels seat position

recall).

●

Operate the tilt and telescopic steering

control switch (only cancels steering

wheel position recall).

●

Vehicles with the head-up display: Oper-

ate the meter control switches to adjust

the head-up display position (only can-

cels head-up display position recall).

■

Operating the driving position memory

after turning the power switch off

Recorded seat positions can be activated

up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is

closed again.

■

When the recorded seat position can-

not be recalled

The seat position may not be recalled in

some situations when the seat position is

recorded in a certain range. For details,

contact your Lexus dealer.

WARNING

■

Seat adjustment caution

Take care during seat adjustment so that

the seat does not strike the rear passen-

ger or squeeze your body against the

steering wheel.

Recalling a driving position

123

3-3. Adjusting the seats

fore
dri
ving

■

Registering procedure

Record your driving position to button
“1”, “2” or “3” before performing the
following:
Carry only the key you want to regis-
ter, and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be recorded
properly.

Check that the shift lever is in P.

Turn the power switch to ON
mode.

Recall the driving position that you
want to record.

While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds.

If the button could not be registered, the

buzzer sounds continuously for approxi-

mately 3 seconds.

■

Cancelation procedure

Carry only the key you want to can-
cel and then close the driver’s door.

If 2 or more keys are in the vehicle, the

driving position cannot be canceled prop-

erly.

Check that the shift lever is in P.

Turn the power switch to ON
mode.

While pressing the “SET” button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds twice.

If the button could not be canceled, the

buzzer sounds continuously for approxi-

mately 3 seconds.

■

Recall procedure

Make sure that the doors are
locked before recalling the driving
position. Carry the electronic key
that has been registered to the driv-
ing position, and then unlock and
open the driver’s door using the
smart access system with push-but-
ton start or wireless remote control.

The driving position will move to the

recorded position (not including the steer-

ing wheel and head-up display [if

equipped]). However, the seat will move to

a position slightly behind the recorded

position in order to make entering the

vehicle easier.
If the driving position is in a position that

has already been recorded, the seat and

outside rear view mirrors will not move.

Turn the power switch to ACCES-
SORY mode or ON mode, or fas-
ten a seat belt.

The seat, steering wheel and head-up dis-

play (if equipped) will move to the

recorded position.

■

Recalling the driving position using the

memory recall function

●

Different driving positions can be regis-

tered for each electronic key. Therefore,

Registering/canceling/recall a
driving position to an electronic
key (including a card key) (mem-
ory recall function)

124

3-3. Adjusting the seats

the driving position that is recalled may

be different depending on the key being

carried.

●

If the a door other than the driver’s door

is unlocked with the smart access system

with push-button start, the driving posi-

tion cannot be recalled. In this case, press

the driving position button which has

been set.

■

Customization

The unlock door settings of the memory

recall function can be changed.

(Customizable features:



P.417)

Pull the head restraints up.

Down

Push the head restraint down while press-
ing the lock release button

■

Adjusting the height of the head

restraints (front seats)

Make sure that the head restraints are

Head restraints

Head restraints are provided for all
seats.

WARNING

■

Head restraint precautions

Observe the following precautions

regarding the head restraints. Failure to

do so may result in death or serious

injury.

●

Use the head restraints designed for

each respective seat.

●

Adjust the head restraints to the cor-

rect position at all times.

●

After adjusting the head restraints,

push down on them and make sure

they are locked in position.

●

Do not drive with the head restraints

removed.

Vertical adjustment

126

3-4. Adjusting the steering wheel and mirrors

3-4.Adjusting the steering wheel and mirrors



Manual adjustment type

Hold the steering wheel and pull
the lever down.

Adjust to the ideal position by mov-
ing the steering wheel horizontally
and vertically.

After adjustment, pull the lever up to

secure the steering wheel.



Power adjustment type

Operating the switch moves the steer-
ing wheel in the following directions:

Down

Toward the driver

Away from the driver

■

The power adjustment type steering

wheel can be adjusted when

The power switch is in ACCESSORY or

ON mode.

■

Automatic adjustment of the steering

position (power adjustment type)

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

(



P.121)

■

Power easy access system (vehicles

with power adjustment type steering

wheel)

The driver’s seat and steering wheel move

in accordance with power switch mode and

the driver’s seat belt condition. (



P.121)

■

Customization

The steering wheel movement can be

changed. (Customizable features:



P.417)

Steering wheel

Adjustment procedure

WARNING

■

Caution while driving

Do not adjust the steering wheel while

driving.

Doing so may cause the driver to mis-

handle the vehicle and cause an acci-

dent, resulting in death or serious injury.

127

3-4. Adjusting the steering wheel and mirrors

fore
dri
ving

Press on or close to the

mark.

The height of the rear view mirror can
be adjusted to suit your driving pos-
ture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness
of the headlights of vehicles behind, the
reflected light is automatically
reduced.
Turn the automatic anti-glare function
mode on/off

WARNING

■

After adjusting the steering wheel

(manual adjustment type)

Make sure that the steering wheel is

securely locked.
Otherwise, the steering wheel may move

suddenly, possibly causing an accident,

and resulting in death or serious injury.

Also, the horn may not sound if the steer-

ing wheel is not securely locked.

Sounding the horn

Inside rear view mirror

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

Adjusting the height of rear view
mirror

WARNING

■

Caution while driving

Do not adjust the position of the mirror

while driving.

Doing so may lead to mishandling of the

vehicle and cause an accident, resulting

in death or serious injury.

Anti-glare function

128

3-4. Adjusting the steering wheel and mirrors

When the automatic anti-glare function is
in ON mode, the indicator

illuminates.

The function will set to ON mode each
time the power switch is turned to ON
mode.
Pressing the button turns the function to
OFF mode. (The indicator

also turns

off.)

■

To prevent sensor error

To ensure that the sensors operate prop-

erly, do not touch or cover them.

■

When using the outside rear view mir-

rors in a cold weather

When it is cold and the outside rear view

mirrors are frozen, it may not be possible to

fold/extend them or adjust the mirror sur-

face. Remove the ice, snow, etc. covering

the outside rear view mirrors.

To select a mirror to adjust, press
the switch.

Left

Outside rear view mirrors

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

WARNING

■

Important points while driving

Observe the following precautions while

driving.

Failure to do so may result in loss of con-

trol of the vehicle and cause an accident,

resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side

mirrors must be extended and prop-

erly adjusted before driving.

Adjustment procedure

Lexus ES300H (2024 year). Manual in english - page 4
