1-1. For safe use

For safety and security

●

The portion of the front pillars, rear pillars

or roof side rail garnishes (padding) con-

taining the SRS curtain shield airbags

inside is scratched, cracked, or otherwise

damaged.

WARNING

■

SRS airbag precautions

Observe the following precautions

regarding the SRS airbags.

Failure to do so may cause death or seri-

ous injury.

●

The driver and all passengers in the

vehicle must wear their seat belts

properly.

The SRS airbags are supplemental

devices to be used with the seat belts.

●

The SRS driver airbag deploys with

considerable force, and can cause

death or serious injury especially if the

driver is very close to the airbag. The

National Highway Traffic Safety

Administration (NHTSA) advises:

Since the risk zone for the driver’s air-

bag is the first 2 - 3 in. (50 - 75 mm) of

inflation, placing yourself 10 in. (250

mm) from your driver airbag provides

you with a clear margin of safety. This

distance is measured from the center

of the steering wheel to your breast-

bone. If you sit less than 10 in. (250

mm) away now, you can change your

driving position in several ways:

• Move your seat to the rear as far as

you can while still reaching the pedals

comfortably.

• Slightly recline the back of the seat.

Although vehicle designs vary, many

drivers can achieve the 10 in. (250

mm) distance, even with the driver

seat all the way forward, simply by

reclining the back of the seat some-

what. If reclining the back of your seat

makes it hard to see the road, raise

yourself by using a firm, non-slippery

cushion, or raise the seat if your vehi-

cle has that feature.

• If your steering wheel is adjustable, tilt

it downward. This points the airbag

toward your chest instead of your

head and neck.

The seat should be adjusted as recom-

mended by NHTSA above, while still

maintaining control of the foot pedals,

steering wheel, and your view of the

instrument panel controls.

1-1. For safe use

WARNING

●

If the seat belt extender has been con-

nected to the driver’s seat belt buckle

but the seat belt extender has not also

been fastened to the latch plate of the

driver’s seat belt, the SRS front airbags

for the driver will judge that the driver

is wearing the seat belt even though

the seat belt has not been connected.

In this case, the SRS front airbags for

the driver may not activate correctly in

a collision, resulting in death or serious

injury in the event of a collision. Be

sure to wear the seat belt with the seat

belt extender.

●

The SRS front passenger airbag also

deploys with considerable force, and

can cause death or serious injury

especially if the front passenger is very

close to the airbag. The front passen-

ger seat should be as far from the air-

bag as possible with the seatback

adjusted, so the front passenger sits

upright.

●

Improperly seated and/or restrained

infants and children can be killed or

seriously injured by a deploying air-

bag. An infant or child who is too small

to use a seat belt should be properly

secured using a child restraint system.

Lexus strongly recommends that all

infants and children be placed in the

rear seats of the vehicle and properly

restrained. The rear seats are safer for

infants and children than the front pas-

senger seat. (



P.43)

●

Do not sit on the edge of the seat or

lean against the dashboard.

●

Do not allow a child to stand in front of

the SRS front passenger airbag unit or

sit on the knees of a front passenger.

●

Do not allow the front seat occupants

to hold items on their knees.

●

Do not lean against the door, the roof

side rail or the front, side and rear pil-

lars.

●

Do not allow anyone to kneel on the

passenger seats toward the door or

put their head or hands outside the

vehicle.

1-1. For safe use

For safety and security

WARNING

●

Do not attach anything to or lean any-

thing against areas such as the dash-

board, steering wheel pad and lower

portion of the instrument panel.

These items can become projectiles

when the SRS driver, front passenger

and knee airbags deploy.

●

Do not attach anything to areas such

as a door, windshield, side window,

front or rear pillar, roof side rail and

assist grip.

●

Do not hang coat hangers or other

hard objects on the coat hooks. All of

these items could become projectiles

and may cause death or serious injury,

should the SRS curtain shield airbags

deploy.

●

If a vinyl cover is put on the area where

the SRS knee airbag will deploy, be

sure to remove it.

●

Do not use seat accessories which

cover the parts where the SRS side air-

bags inflate as they may interfere with

inflation of the SRS airbags. Such

accessories may prevent the side air-

bags from activating correctly, disable

the system or cause the side airbags to

inflate accidentally, resulting in death

or serious injury.

●

Do not strike or apply significant levels

of force to the area of the SRS airbag

components or the front doors.

Doing so can cause the SRS airbags to

malfunction.

●

Do not touch any of the component

parts immediately after the SRS air-

bags have deployed (inflated) as they

may be hot.

●

If breathing becomes difficult after the

SRS airbags have deployed, open a

door or window to allow fresh air in, or

leave the vehicle if it is safe to do so.

Wash off any residue as soon as possi-

ble to prevent skin irritation.

●

If the areas where the SRS airbags are

stored, such as the steering wheel pad

and front and rear pillar garnishes, are

damaged or cracked, have them

replaced by your Lexus dealer.

●

Do not place anything, such as a cush-

ion, on the front passenger’s seat.

Doing so will disperse the passenger’s

weight, which prevents the sensor

from detecting the passenger’s weight

properly. As a result, the SRS front air-

bags for the front passenger may not

deploy in the event of a collision.

■

Modification and disposal of SRS air-

bag system components

Do not dispose of your vehicle or per-

form any of the following modifications

without consulting your Lexus dealer.

The SRS airbags may malfunction or

deploy (inflate) accidentally, causing

death or serious injury.

●

Installation, removal, disassembly and

repair of the SRS airbags

●

Repairs, modifications, removal or

replacement of the steering wheel,

instrument panel, dashboard, seats or

seat upholstery, front, side and rear pil-

lars, roof side rails, front door panels,

front door trims or front door speakers

●

Modifications to the front door panel

(such as making a hole in it)

1-1. For safe use

For safety and security

Driver’s and front passenger’s seat belt reminder light

SRS warning light

“PASSENGER AIR BAG” indicator lights

Front passenger occupant classification system

Your vehicle is equipped with a front passenger occupant classification sys-
tem. This system detects the conditions of the front passenger seat and acti-
vates or deactivates the front passenger airbag, and front passenger knee
airbag.

System components

WARNING

■

Front passenger occupant classifica-

tion system precautions

Observe the following precautions

regarding the front passenger occupant

classification system.

Failure to do so may cause death or seri-

ous injury.

●

Wear the seat belt properly.

●

Make sure the front passenger’s seat

belt plate has not been left inserted

into the buckle before someone sits in

the front passenger seat.

1-1. For safe use

WARNING

●

Make sure the “PASSENGER AIR

BAG OFF” indicator light is not illumi-

nated when using the seat belt

extender for the front passenger seat.

If the “PASSENGER AIR BAG OFF”

indicator light is illuminated, discon-

nect the extender tongue from the

seat belt buckle, and reconnect the

seat belt. Reconnect the seat belt

extender after making sure the “PAS-

SENGER AIR BAG ON” indicator

light is illuminated. If you use the seat

belt extender while the “PASSENGER

AIR BAG OFF” indicator light is illu-

minated, the SRS airbags for the front

passenger will not activate, which

could cause death or serious injury in

the event of a collision.

●

Do not apply a heavy load to the front

passenger seat or equipment (e.g.

seatback pocket).

●

Do not put weight on the front passen-

ger seat by putting your hands or feet

on the front passenger seat seatback

from the rear passenger seat.

●

Do not let a rear passenger lift the

front passenger seat with their feet or

press on the seatback with their legs.

●

Do not put objects under the front pas-

senger seat.

●

Do not recline the front passenger

seatback so far that it touches a rear

seat. This may cause the “PASSEN-

GER AIR BAG OFF” indicator light to

be illuminated, which indicates that the

SRS airbags for the front passenger

will not activate in the event of a severe

accident. If the seatback touches the

rear seat, return the seatback to a

position where it does not touch the

rear seat. Keep the front passenger

seatback as upright as possible when

the vehicle is moving. Reclining the

seatback excessively may lessen the

effectiveness of the seat belt system.

●

If an adult sits in the front passenger

seat, the “PASSENGER AIR BAG

ON” indicator light is illuminated. If the

“PASSENGER AIR BAG OFF” indi-

cator is illuminated, ask the passenger

to sit up straight, well back in the seat,

feet on the floor, and with the seat belt

worn correctly. If the “PASSENGER

AIR BAG OFF” indicator still remains

illuminated, either ask the passenger

to move to the rear seat, or if that is not

possible, move the front passenger

seat fully rearward.

●

When it is unavoidable to install a for-

ward-facing child restraint system on

the front passenger seat, install the

child restraint system on the front pas-

senger seat in the proper order.

(



P.45)

●

Do not modify or remove the front

seats.

●

Do not kick the front passenger seat or

subject it to severe impact. Otherwise,

the SRS warning light may come on to

indicate a malfunction of the front pas-

senger occupant classification system.

In this case, contact your Lexus dealer

immediately.

●

Child restraint systems installed on the

rear seat should not contact the front

seatbacks.

●

Do not use a seat accessory, such as a

cushion and seat cover, that covers the

seat cushion surface.

●

Do not modify or replace the uphol-

stery of the front seat.

●

Do not place anything between the

console box and front passenger seat.

Otherwise, the system may not detect

the front passenger properly, leading

to improper operation of the airbags.

1-1. For safe use

For safety and security

■

Adult

■

Child

WARNING

●

Adjust the front passenger seat so that

the head restraint does not touch the

ceiling. If the head restraint is left in

contact with the ceiling, the system

may not detect the front passenger

properly, leading to improper opera-

tion of the airbags.

Condition and operation in the front passenger occupant classification
system

Indicator/warning

light

“PASSENGER AIR BAG” indicator lights

“PASSENGER AIR

BAG ON”

SRS warning light

Off

Driver’s and front passenger’s seat belt

reminder light

Off

or flashing

Devices

Front passenger airbag

Activated

Front passenger knee airbag

Indicator/warning

light

“PASSENGER AIR BAG” indicator lights

“PASSENGER AIR

BAG OFF” or “PAS-

SENGER AIR BAG

ON”

SRS warning light

Off

Driver’s and front passenger’s seat belt

reminder light

Off

or flashing

Devices

Front passenger airbag

Deactivated or acti-

vated

Front passenger knee airbag

1-1. For safe use

■

Child restraint system with infant

■

Unoccupied

■

There is a malfunction in the system

: The system judges a person of adult size as an adult. When a smaller adult sits in the

front passenger seat, the system may not recognize him/her as an adult depending on
his/her physique and posture.

: In the event the front passenger is wearing a seat belt.

: In the event the front passenger does not wear a seat belt.

: For some children, child in seat, child in booster seat or child in convertible seat, the sys-

tem may not recognize him/her as a child. Factors which may affect this can be the phy-
sique or posture.

: Never install a rear-facing child restraint system on the front passenger seat. A forward-

Indicator/warning

light

“PASSENGER AIR BAG” indicator lights

“PASSENGER AIR

BAG OFF”

SRS warning light

Off

Driver’s and front passenger’s seat belt

reminder light

Off

or flashing

Devices

Front passenger airbag

Deactivated

Front passenger knee airbag

Indicator/warning

light

“PASSENGER AIR BAG” indicator lights

“PASSENGER AIR

BAG OFF”

SRS warning light

Off

Driver’s and front passenger’s seat belt

reminder light

Devices

Front passenger airbag

Deactivated

Front passenger knee airbag

Indicator/warning

light

“PASSENGER AIR BAG” indicator lights

“PASSENGER AIR

BAG OFF”

SRS warning light

Driver’s and front passenger’s seat belt

reminder light

Devices

Front passenger airbag

Deactivated

Front passenger knee airbag

1-1. For safe use

Exhaust gas precautions

Harmful substance to the human
body is included in exhaust gases if
inhaled.

WARNING

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.

Failure to do so may cause exhaust gases

enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

■

Important points while driving

●

Keep the trunk lid closed.

●

If you smell exhaust gases in the vehi-

cle even when the trunk lid is closed,

open the windows and have the vehi-

cle inspected at your Lexus dealer as

soon as possible.

■

When parking

●

If the vehicle is in a poorly ventilated

area or a closed area, such as a

garage, stop the hybrid system.

●

Do not leave the vehicle with the

hybrid system operating for a long

time.

If such a situation cannot be avoided,

park the vehicle in an open space and

ensure that exhaust fumes do not enter

the vehicle interior.

●

Do not leave the hybrid system oper-

ating in an area with snow build-up, or

where it is snowing. If snowbanks build

up around the vehicle while the hybrid

system is operating, exhaust gases

may collect and enter the vehicle.

■

Exhaust pipe

The exhaust system needs to be checked

periodically. If there is a hole or crack

caused by corrosion, damage to a joint

or abnormal exhaust noise, be sure to

have the vehicle inspected and repaired

by your Lexus dealer.

1-2. Child safety

For safety and security

1-2.Child safety

Points to remember: P.43
Child restraint system: P.44
When using a child restraint system:
P.45
Child restraint system installation
method
• Fixed with a seat belt: P.47
• Fixed with a child restraint LATCH

anchor: P.50

• Using an anchor bracket (for top

tether strap): P.53

The laws of all 50 states of the U.S.A.
as well as Canada now require the use
of child restraint systems.



Prioritize and observe the warnings,
as well as the laws and regulations

Riding with children

Observe the following precautions
when children are in the vehicle.
Use a child restraint system appro-
priate for the child, until the child
becomes large enough to properly
wear the vehicle’s seat belt.



It is recommended that children
sit in the rear seats to avoid acci-
dental contact with the shift lever,
wiper switch, etc.



Use the rear door child-protector
lock or the window lock switch to
avoid children opening the door
while driving or operating the
power window accidentally.
(



P.107, 132)



Do not let small children operate
equipment which may catch or
pinch body parts, such as the
power window, hood, trunk, seats
etc.

WARNING

■

When children are in the vehicle

Never leave children unattended in the

vehicle, and never allow children to have

or use the key.
Children may be able to start the vehicle

or shift the vehicle into neutral. There is

also a danger that children may injure

themselves by playing with the windows,

the moon roof or other features of the

vehicle. In addition, heat build-up or

extremely cold temperatures inside the

vehicle can be fatal to children.

Child restraint systems

Before installing a child restraint
system in the vehicle, there are pre-
cautions that need to be observed,
different types of child restraint sys-
tems, as well as installation meth-
ods, etc., written in this manual.

Use a child restraint system when
riding with a small child that cannot
properly use a seat belt. For the
child’s safety, install the child
restraint system to a rear seat. Be
sure to follow the installation method
that is in the operation manual
enclosed with the restraint system.

Table of contents

Points to remember

1-2. Child safety

for child restraint systems.



Use a child restraint system until the
child becomes large enough to
properly wear the vehicle’s seat
belt.



Choose a child restraint system that
suits your vehicle and is appropriate
to the age and size of the child.

■

Types of child restraint system installation methods

Confirm with the operation manual enclosed with the child restraint system about
the installation of the child restraint system.

WARNING

■

When a child is riding

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

For effective protection in automobile

accidents and sudden stops, a child

must be properly restrained, using a

seat belt or child restraint system

which is correctly installed. For instal-

lation details, refer to the operation

manual enclosed with the child

restraint system. General installation

instruction is provided in this manual.

●

Lexus strongly urges the use of a

proper child restraint system that con-

forms to the weight and size of the

child, installed on the rear seat.

According to accident statistics, the

child is safer when properly restrained

in the rear seat than in the front seat.

●

Holding a child in your or someone

else’s arms is not a substitute for a child

restraint system. In an accident, the

child can be crushed against the wind-

shield or between the holder and the

interior of the vehicle.

■

Handling the child restraint system

If the child restraint system is not prop-

erly fixed in place, the child or other pas-

sengers may be seriously injured or even

killed in the event of sudden braking,

sudden swerving, or an accident.

●

If the vehicle were to receive a strong

impact from an accident, etc., it is pos-

sible that the child restraint system has

damage that is not readily visible. In

such cases, do not reuse the restraint

system.

●

Make sure you have complied with all

installation instructions provided with

the child restraint system manufac-

turer and that the system is properly

secured.

●

Keep the child restraint system prop-

erly secured on the seat even if it is not

in use. Do not store the child restraint

system unsecured in the passenger

compartment.

●

If it is necessary to detach the child

restraint system, remove it from the

vehicle or store it securely in the trunk.

Child restraint system

1-2. Child safety

For safety and security

■

When installing a child restraint
system to a front passenger seat

For the safety of a child, install child
restraint systems to a rear seats. When
installing child restraint system to a
front passenger seat is unavoidable,
adjust the seat as follows and install the
child restraint system.



Move the front seat fully rearward.



Adjust the seatback angle to the
most upright position.

When installing a forward-facing child
seat, if there is a gap between the child seat
and the seatback, adjust the seatback
angle until good contact is achieved.



Adjust the front of the seat cushion
to the uppermost position.



Adjust the seat height to the upper-
most position.

Installation method

Page

Seat belt attachment

P.47

Child restraint LATCH

anchors attachment

P.50

Anchor brackets (for top

tether strap) attachment

P.53

When using a child restraint sys-
tem

1-2. Child safety



Adjust the lumbar support to the
lowest position.



If the head restraint interferes with
the child restraint system installation
and the head restraint can be
removed, remove the head
restraint. Otherwise, put the head
restraint in the upper most position.

WARNING

■

When using a child restraint system

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Never install a rear-facing child

restraint system on the front passen-

ger seat even if the “PASSENGER

AIR BAG OFF” indicator light is illu-

minated. In the event of an accident,

the force of the rapid inflation of the

front passenger airbag can cause

death or serious injury to the child if

the rear-facing child restraint system is

installed on the front passenger seat.

●

A forward-facing child restraint sys-

tem may be installed on the front pas-

senger seat only when it is

unavoidable. A child restraint system

that requires a top tether strap should

not be used in the front passenger seat

since there is no top tether strap

anchor for the front passenger seat.

●

A forward-facing child restraint sys-

tem may be installed on the front pas-

senger seat only when it is

unavoidable. When installing a for-

ward-facing child restraint system on

the front passenger seat, adjust the

seatback angle to the most upright

position, move the seat to the rearmost

position, and raise the seat to the

upper most position, even if the “PAS-

SENGER AIR BAG OFF” indicator

light is illuminated.

●

Do not allow the child to lean his/her

head or any part of his/her body

against the door or the area of the seat,

front or rear pillars, or roof side rails

from which the SRS side airbags or

SRS curtain shield airbags deploy even

if the child is seated in the child

restraint system. It is dangerous if the

SRS side and curtain shield airbags

inflate, and the impact could cause

death or serious injury to the child.

●

When a booster seat is installed,

always ensure that the shoulder belt is

positioned across the center of the

child’s shoulder. The belt should be

kept away from the child’s neck, but

not so that it could fall off the child’s

shoulder.

●

Use child restraint system suitable to

the age and size of the child and install

it to the rear seat.

1-2. Child safety

For safety and security

A child restraint system for a small
child or baby must itself be properly
restrained on the seat with the lap por-
tion of the lap/shoulder belt.

■

Installing child restraint system
using a seat belt (child restraint
lock function belt)

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.

■

Rear-facing



Infant seat/con-

vertible seat

Place the child restraint system on
the rear seat facing the rear of the
vehicle.

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot
be extended.

WARNING

●

If the driver’s seat interferes with the

child restraint system and prevents it

from being attached correctly, attach

the child restraint system to the right-

hand rear seat.

●

Adjust the front passenger seat so that

it does not interfere with the child

restraint system.

Child restraint system fixed with
a seat belt

1-2. Child safety

While pushing the child restraint
system down into the rear seat,
allow the shoulder belt to retract
until the child restraint system is
securely in place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

extended.

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.50)

■

Forward-facing



Convertible

seat

Adjust the seat

When using the front passenger seat: If

installing the child restraint system to the

front passenger seat is unavoidable, refer

to P.45 for front passenger seat adjust-

ment.

Place the child restraint system on
the seat facing the front of the vehi-
cle.

Run the seat belt through the child
restraint system and insert the plate
into the buckle. Make sure that the
belt is not twisted.

Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot
be extended.

While pushing the child restraint
system into the rear seat, allow the
shoulder belt to retract until the
child restraint system is securely in
place.

After the shoulder belt has retracted to a

point where there is no slack in the belt,

pull the belt to check that it cannot be

1-2. Child safety

For safety and security

extended.

If the child restraint has a top tether
strap, follow the child restraint
manufacturer’s operation manual
regarding the installation, using the
top tether strap to latch onto the
top tether strap anchor. (



P.53)

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.50)

■

Booster seat

If installing the child restraint sys-
tem to the front passenger seat is
unavoidable, refer to P.45 for front
passenger seat adjustment.

Place the child restraint system on
the seat facing the front of the vehi-
cle.



Booster type



High back type

Sit the child in the child restraint
system. Fit the seat belt to the child
restraint system according to the
manufacturer’s instructions and
insert the plate into the buckle.
Make sure that the belt is not
twisted.

Check that the shoulder belt is correctly

positioned over the child’s shoulder and

that the lap belt is as low as possible.

(



P.24)

■

Removing a child restraint system
installed with a seat belt

Press the buckle release button and
fully retract the seat belt.

When releasing the buckle, the child
restraint system may spring up due to the
rebound of the seat cushion. Release the
buckle while holding down the child
restraint system.
Since the seat belt automatically reels itself,
slowly return it to the stowing position.

1-2. Child safety

■

Child restraint LATCH anchors

LATCH anchors are provided for the
outboard rear seat. (Marks displaying
the location of the anchors are
attached to the seats.)

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not allow children to play with the

seat belt. If the seat belt becomes

twisted around a child’s neck, it may

lead to choking or other serious inju-

ries that could result in death.

If this occurs and the buckle cannot be

unfastened, scissors should be used to

cut the belt.

●

Ensure that the belt and plate are

securely locked and the seat belt is not

twisted.

●

Shake the child restraint system left

and right, and forward and backward

to ensure that it has been securely

installed.

●

After securing a child restraint system,

never adjust the seat.

●

When a booster seat is installed,

always ensure that the shoulder belt is

positioned across the center of the

child’s shoulder. The belt should be

kept away from the child’s neck, but

not so that it could fall off the child’s

shoulder.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

●

When securing some types of child

restraint systems in rear seats, it may

not be possible to properly use the

seat belts in positions next to the child

restraint without interfering with it or

affecting seat belt effectiveness. Be

sure your seat belt fits snugly across

your shoulder and low on your hips. If it

does not, or if it interferes with the

child restraint, move to a different

position. Failure to do so may result in

death or serious injury.

■

When installing a booster seat

To prevent the belt from going into ALR

lock mode, do not fully extend the shoul-

der belt. ALR mode causes the belt to

tighten only. This could cause injury or

discomfort to the child. (



P.26)

■

Do not use a seat belt extender

If a seat belt extender is used when

installing a child restraint system, the seat

belt will not securely hold the child

restraint system, which could cause

death or serious injury to the child or

other passengers in the event of sudden

braking, sudden swerving or an accident.

Child restraint system fixed with
a child restraint LATCH anchor

1-2. Child safety

For safety and security

■

When installing in the rear out-
board seats

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.

Remove the cover.



With flexible lower attachments

Latch the hooks of the lower
attachments onto the LATCH
anchors.
For owners in Canada:
The symbol on a child restraint sys-

tem indicates

the presence of a

lower connector system.

Canada only



With rigid lower attachments

Latch the buckles onto the LATCH
anchors.
For owners in Canada:
The symbol on a child restraint sys-

1-2. Child safety

tem indicates

the presence of a

lower connector system.

Canada only



P.53)

After installing the child restraint
system, rock it back and forth to
ensure that it is installed securely.
(



P.50)

■

When installing in the rear center
seat

There are no LATCH anchors behind
the rear center seat. However, the
inboard LATCH anchors of the out-
board seats, which are 16.9 in. (430
mm) apart, can be if the child restraint
system manufacturer’s instructions
permit use of those anchors with the

anchor spacing stated.
Child restraint systems with rigid lower
attachments cannot be installed in the
center seat. This type of child restraint
system can only be installed in the out-
board seat.

■

Laws and regulations pertaining to

anchors

The LATCH system conforms to

FMVSS225 or CMVSS210.2.

Child restraint systems conforming to

FMVSS213 or CMVSS213 specifications

can be used.

This vehicle is designed to conform to SAE

J1819.

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

When using the LATCH anchors, be

sure that there are no foreign objects

around the anchors and that the seat

belt is not caught behind the child

restraint system.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

●

Never attach two child restraint sys-

tem attachments to the same anchor.

In a collision, one anchor may not be

strong enough to hold two child

restraint system attachments and may

break. If the LATCH anchors are

already in use, use the seat belt to

install a child restraint system in the

center seat.

1-2. Child safety

For safety and security

■

Anchor brackets (for top tether
strap)

Anchor brackets are provided for each
rear seat.
Use anchor brackets when fixing the
top tether strap.



Outboard rear seats

Anchor brackets

Top tether strap



Rear center seat

Anchor bracket

Top tether strap

■

Fixing the top tether strap to the
anchor bracket

Install the child restraint system in
accordance to the operation manual
enclosed with the child restraint sys-
tem.

Remove the head restraint.

Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top tether
strap.

Make sure the top tether strap is securely
latched. (



P.50)

WARNING

●

When securing some types of child

restraint systems in rear seats, it may

not be possible to properly use the

seat belts in positions next to the child

restraint without interfering with it or

affecting seat belt effectiveness. Be

sure your seat belt fits snugly across

your shoulder and low on your hips. If it

does not, or if it interferes with the

child restraint, move to a different

position. Failure to do so may result in

death or serious injury.

●

If the seat is adjusted, reconfirm the

security of the child restraint system.

Using an anchor bracket (for top
tether strap)

1-2. Child safety



Outboard rear seats

Hook

Top tether strap



Rear center seat

Hook

Top tether strap

■

Laws and regulations pertaining to

anchors

The LATCH system conforms to

FMVSS225 or CMVSS210.2.

Child restraint systems conforming to

FMVSS213 or CMVSS213 specifications

can be used.

This vehicle is designed to conform to SAE

J1819.

WARNING

■

When installing a child restraint sys-

tem

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Firmly attach the top tether strap and

make sure that the belt is not twisted.

●

Do not attach the top tether strap to

anything other than the anchor

bracket.

●

After securing a child restraint system,

never adjust the seat.

●

Follow all installation instructions pro-

vided by the child restraint system

manufacturer.

NOTICE

■

Anchor brackets (for top tether

strap)

When not in use, make certain to close

the lid. If it remains open, the lid may be

damaged.

1-3. Lexus Enform

For safety and security

1-3.Lexus Enform

“SOS” button

LED light indicators

Microphone

Subscribers have the following Safety
Connect services available:



Automatic Collision Notification

Helps drivers receive necessary response
from emergency service providers.
(



P.56

)

: U.S. Patent No. 7,508,298 B2



Stolen Vehicle Location

Helps drivers in the event of vehicle theft.
(



P.57

)



Emergency Assistance Button
(“SOS”)

Connects drivers to response-center sup-
port. (



P.57

)



Enhanced Roadside Assistance

Provides drivers various on-road assis-
tance. (



P.57

)

After you have signed the Telematics
Subscription Service Agreement and
are enrolled, you can begin receiving
services.
A variety of subscription terms is avail-
able for purchase. Contact your Lexus
dealer, call the following or push the
“SOS” button in your vehicle for fur-
ther subscription details.
• The United States

1-800-25-LEXUS (1-800-255-3987)

• Canada

1-800-26-LEXUS (1-800-265-3987)

• Puerto Rico

Safety Connect

Safety Connect is a subscription-
based telematics service that uses
Global Positioning System (GPS)
data and embedded cellular tech-
nology to provide safety and secu-
rity features to subscribers. Safety
Connect is supported by Lexus’
designated response center, which
operates 24 hours per day, 7 days
per week.

Safety Connect service is available
by subscription on select, telemat-
ics hardware-equipped vehicles.

By using the Safety Connect ser-
vice, you are agreeing to be bound
by the Connected Services Terms
of Use, as in effect and amended
from time to time, a current copy of
which is available at Lexus.com. All
use of the Safety Connect service is
subject to such then-applicable
Terms and Conditions.

System components

A
B

Services

Subscription

1-3. Lexus Enform

1-877-539-8777

■

Safety Connect Services Information

●

Phone calls using the vehicle’s
Bluetooth

technology will not be possi-

ble during Safety Connect.

●

Safety Connect is available beginning

Fall 2009 on select Lexus models (in the

contiguous United States only). Contact

with the Safety Connect response center

is dependent upon the telematics device

being in operative condition, cellular con-

nection availability, and GPS satellite sig-

nal reception, which can limit the ability to

reach the response center or receive

emergency service support. Enrollment

and Telematics Subscription Service

Agreement required. A variety of sub-

scription terms is available; charges vary

by subscription term selected and loca-

tion.

●

Automatic Collision Notification, Emer-

gency Assistance and Stolen Vehicle

Location will function in the United

States, including Hawaii and Alaska,

Puerto Rico and in Canada, and

Enhanced Roadside Assistance will func-

tion in the United States, Puerto Rico and

in Canada.

●

Automatic Collision Notification, Emer-

gency Assistance, Stolen Vehicle and

Enhanced Road Assistance will not func-

tion in the United States Virgin Islands.

For vehicles first sold in the USVI, no

Safety Connect services will function in

and outside the United States Virgin

Islands.

●

Safety Connect services are not subject

to section 255 of the Telecommunica-

tions Act and the device is not TTY com-

patible.

■

Languages

The Safety Connect response center will

offer support in multiple languages. The

Safety Connect system will offer voice

prompts in English, Spanish, and French.

Please indicate your language of choice

when enrolling.

■

When contacting the response center

You may be unable to contact the response

center if the network is busy.

When the power switch is turned to
ON mode, the red indicator light
comes on for 2 seconds then turns off.
Afterward, the green indicator light
comes on, indicating that the service is
active.
The following indicator light patterns
indicate specific system usage condi-
tions:



Green indicator light on = Active
service



Green indicator light flashing =
Safety Connect call in process



Red indicator light (except at vehi-
cle start-up) = System malfunction
(contact your Lexus dealer)



No indicator light (off) = Safety
Connect service not active

■

Automatic Collision Notification

In case of either airbag deployment or
severe rear-end collision, the system is
designed to automatically call the
response center. The responding
agent receives the vehicle’s location
and attempts to speak with the vehicle
occupants to assess the level of emer-
gency. If the occupants are unable to
communicate, the agent automatically
treats the call as an emergency, con-

Safety Connect LED light Indi-
cators

Safety Connect services

1-3. Lexus Enform

For safety and security

tacts the nearest emergency services
provider to describe the situation, and
requests that assistance be sent to the
location.

■

Stolen Vehicle Location

If your vehicle is stolen, Safety Connect
can work with local authorities to assist
them in locating and recovering the
vehicle. After filing a police report, call
the Safety Connect response center at
1-800-25-LEXUS (1-800-255-
3987) in the United States, 1-877-
539-8777 in Puerto Rico or 1-800-
265-3987 in Canada, and follow the
prompts for Safety Connect to initiate
this service.
In addition to assisting law enforce-
ment with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle
location data may, under certain cir-
cumstances, be shared with third par-
ties to locate your vehicle. Further
information is available at Lexus.com.

■

Emergency Assistance Button
(“SOS”)

In the event of an emergency on the
road, push the “SOS” button to reach
the Safety Connect response center.
The answering agent will determine
your vehicle’s location, assess the
emergency, and dispatch the neces-
sary assistance required.

If you accidentally press the “SOS” button,
tell the response-center agent that you are
not experiencing an emergency.

■

Enhanced Roadside Assistance

Enhanced Roadside Assistance adds
GPS data to the already included war-

ranty-based Lexus roadside service.
Subscribers can press the “SOS” but-
ton to reach a Safety Connect
response-center agent, who can help
with a wide range of needs, such as:
towing, flat tire, fuel delivery, etc. For a
description of the Roadside Assistance
services and their limitations, please
see the Safety Connect Terms and
Conditions, which are available at
Lexus.com.

Important! Read this information about
exposure to radio frequency signals
before using Safety Connect;
The Safety Connect system installed in
your vehicle is a low-power radio
transmitter and receiver. It receives
and also sends out radio frequency
(RF) signals.
In August 1996, the Federal Commu-
nications Commission (FCC) adopted
RF exposure guidelines with safety lev-
els for mobile wireless phones. Those
guidelines are consistent with the
safety standards previously set by the
following U.S. and international stan-
dards bodies.



ANSI (American National Stan-
dards Institute) C95.1 [1992]



NCRP (National Council on Radia-
tion Protection and Measurement)
Report 86 [1986]



ICNIRP (International Commission
on Non-Ionizing Radiation Protec-

Safety information for Safety
Connect

1-4. Hybrid system

For safety and security

1-4.Hybrid system

The illustration is an example for explanation and may differ from the actual item.

Gasoline engine

Electric motor (traction motor)

■

When stopped/during start off

The gasoline engine stops

when the

vehicle is stopped. During start off, the
electric motor (traction motor) drives
the vehicle. At slow speeds or when
traveling down a gentle slope, the
engine is stopped

and the electric

motor (traction motor) is used.
When the shift lever is in N, the hybrid
battery (traction battery) is not being

charged.

: When the hybrid battery (traction bat-

tery) requires charging or the engine is
warming up, etc., the gasoline engine will
not automatically stop.

■

During normal driving

The gasoline engine is predominantly
used. The electric motor (traction
motor) charges the hybrid battery
(traction battery) as necessary.

Hybrid system features

Your vehicle is a Hybrid Electric Vehicle. It has characteristics different from
conventional vehicles. Be sure you are closely familiar with the characteristics
of your vehicle, and operate it with care.
The hybrid system combines the use of a gasoline engine and an electric
motor (traction motor) according to driving conditions, improving fuel effi-
ciency and reducing exhaust emissions.

System components

A
B

1-4. Hybrid system

■

When accelerating sharply

When the accelerator pedal is
depressed heavily, the power of the
hybrid battery (traction battery) is
added to that of the gasoline engine via
the electric motor (traction motor).

■

When braking (regenerative brak-
ing)

The wheels operate the electric motor
(traction motor) as a power generator,
and the hybrid battery (traction bat-
tery) is charged.

■

Regenerative braking

In the following situations, kinetic energy is

converted to electric energy and decelera-

tion force can be obtained in conjunction

with the recharging of the hybrid battery

(traction battery).

●

The accelerator pedal is released while

driving with the shift lever in D or S.

●

The brake pedal is depressed while driv-

ing with the shift lever in D or S.

■

EV indicator

The EV indicator comes on when the vehi-

cle is driven using only the electric motor

(traction motor) or the gasoline engine is

stopped.

■

Conditions in which the gasoline engine

may not stop

The gasoline engine starts and stops auto-

matically. However, it may not stop auto-
matically in the following conditions

●

During gasoline engine warm-up

●

During hybrid battery (traction battery)

charging

●

When the temperature of the hybrid bat-

tery (traction battery) is high or low

●

When the heater is switched on

: Depending on the circumstances, the

gasoline engine may also not stop auto-
matically in other situations.

■

Charging the hybrid battery (traction

battery)

As the gasoline engine charges the hybrid

battery (traction battery), the battery does

not need to be charged from an outside

source. However, if the vehicle is left

parked for a long time the hybrid battery

(traction battery) will slowly discharge. For

this reason, be sure to drive the vehicle at

least once every few months for at least 30

minutes or 10 miles (16 km). If the hybrid

battery (traction battery) becomes fully dis-

charged and you are unable to start the

hybrid system, contact your Lexus dealer.

■

Charging the 12-volt battery



P.389

■

After the 12-volt battery has discharged

or when the terminal has been removed

and installed during exchange, etc.

The gasoline engine may not stop even if

the vehicle is being driven by the hybrid

battery (traction battery). If this continues

for a few days, contact your Lexus dealer.

■

Sounds and vibrations specific to a

Hybrid Electric Vehicle

There may be no engine sound or vibration

even though the vehicle is able to move with

the “READY” indicator is illuminated. For

safety, apply the parking brake and make

sure to shift the shift lever to P when parked.
The following sounds or vibrations may

occur when the hybrid system is operating

and are not a malfunction:

●

Motor sounds may be heard from the

engine compartment.

●

Sounds may be heard from the hybrid

battery (traction battery) under the rear

seats when the hybrid system starts or

stops.

●

Relay operating sounds such as a snap or

1-4. Hybrid system

For safety and security

soft clank will be emitted from the hybrid

battery (traction battery), under the rear

seats, when the hybrid system is started

or stopped.

●

Sounds from the hybrid system may be

heard when the trunk lid is open.

●

Sounds may be heard from the transmis-

sion when the gasoline engine starts or

stops, when driving at low speeds, or

during idling.

●

Engine sounds may be heard when

accelerating sharply.

●

Sounds may be heard due to regenera-

tive braking when the brake pedal is

depressed or as the accelerator pedal is

released.

●

Vibration may be felt when the gasoline

engine starts or stops.

●

Cooling fan sounds may be heard from

the air intake vent under the rear seat.

■

Maintenance, repair, recycling, and dis-

posal

Contact your Lexus dealer regarding main-

tenance, repair, recycling and disposal. Do

not dispose of the vehicle yourself.

■

Customization

Settings (e.g. on/off operation of the EV

indicator) can be changed.

(Customizable features:



P.417)

When driving with the gasoline engine
stopped, a sound, which changes in
accordance with the driving speed, will
be played in order to warn people
nearby of the vehicle’s approach. This
sound may be heard inside the vehicle.
The sound will stop when the vehicle
speed exceeds approximately 22 mph
(35 km/h).

■

Acoustic Vehicle Alerting System

In the following cases, the Acoustic Vehicle

Alerting System may be difficult for sur-

rounding people to hear.

●

In very noisy areas

●

In the wind or the rain

■

If “Acoustic Vehicle Alerting System

Malfunction Visit your Dealer” is dis-

played on the multi-information display

The system may be malfunctioning. Have

the vehicle inspected by your Lexus dealer.

Acoustic Vehicle Alerting Sys-
tem

1-4. Hybrid system

The illustration is an example for explanation and may differ from the actual item.

Warning label

Service plug

Hybrid battery (traction battery)

High voltage cables (orange)

Electric motor (traction motor)

Power control unit

Air conditioning compressor

■

Running out of fuel

When the vehicle has run out of fuel and the

hybrid system cannot be started, refuel the

vehicle with at least enough gasoline to

make the low fuel level warning light

(



P.363) go off. If there is only a small

amount of fuel, the hybrid system may not

be able to start. (The standard amount of

fuel is about 2.4 gal. [9.0 L, 2.0 Imp.gal.],

when the vehicle is on a level surface. This

value may vary when the vehicle is on a

slope. Add extra fuel when the vehicle is

inclined.)

■

Electromagnetic waves

●

High voltage parts and cables on Hybrid

Electric Vehicles incorporate electro-

Hybrid system precautions

Take care when handling the hybrid system, as it is a high voltage system
(about 650 V at maximum) as well as contains parts that become extremely
hot when the hybrid system is operating. Obey the warning labels attached to
the vehicle.

System components

A
B
C
D

E
F

1-4. Hybrid system

For safety and security

magnetic shielding, and therefore emit

approximately the same amount of elec-

tromagnetic waves as conventional gaso-

line powered vehicles or home electronic

appliances.

●

Your vehicle may cause sound interfer-

ence in some third party-produced radio

parts.

■

Hybrid battery (traction battery)

The hybrid battery (traction battery) has a

limited service life. The lifespan of the

hybrid battery (traction battery) can change

in accordance with driving style and driving

conditions.

■

Starting the hybrid system in an

extremely cold environment (for vehi-

cles sold in except Canada)

When the hybrid battery (traction battery)

is extremely cold (below approximately -

22°F [-30°C]) under the influence of the

outside temperature, it may not be possible

to start the hybrid system. In this case, try to

start the hybrid system again after the tem-

perature of the hybrid battery increases

due to the outside temperature increase

etc.

WARNING

■

High voltage precautions

This vehicle has high voltage DC and AC

systems as well as a 12-volt system. DC

and AC high voltage is very dangerous

and can cause severe burns and electric

shock that may result in death or serious

injury.

●

Never touch, disassemble, remove or

replace the high voltage parts, cables

or their connectors.

●

The hybrid system will become hot

after starting as the system uses high

voltage. Be careful of both the high

voltage and the high temperature, and

always obey the warning labels

attached to the vehicle.

●

Never try to open the service plug

access hole located under the rear

seat (right side). The service plug is

used only when the vehicle is serviced

and is subject to high voltage.

■

Road accident cautions

Observe the following precautions to

reduce the risk of death or serious injury:

●

Pull your vehicle off the road, apply the

parking brake, shift the shift lever to P,

and turn the hybrid system off.

●

Do not touch the high voltage parts,

cables and connectors.

●

If electric wires are exposed inside or

outside your vehicle, an electric shock

may occur. Never touch exposed

electric wires.

●

If a fire occurs in the Hybrid Electric

Vehicle, leave the vehicle as soon as

possible. Never use a fire extinguisher

that is not meant for electric fires.

Using even a small amount of water

may be dangerous.

●

If your vehicle needs to be towed, do

so with front wheels raised. If the

wheels connected to the electric

motor (traction motor) are on the

ground when towing, the motor may

continue to generate electricity. This

may cause a fire. (



P.357)

●

Carefully inspect the ground under the

vehicle. If you find that liquid has

leaked onto the ground, the fuel sys-

tem may have been damaged. Leave

the vehicle as soon as possible.

1-4. Hybrid system

There is an air intake vent under the
rear seat (right side) for the purpose of
cooling the hybrid battery (traction
battery). If the vent becomes blocked,

WARNING

●

For vehicles sold in Canada: If a fluid

leak occurs, do not touch the fluid as it

may be strong alkaline electrolyte

from the hybrid battery (traction bat-

tery). If it comes into contact with your

skin or eyes, wash it off immediately

with a large amount of water or, if pos-

sible, boric acid solution. Seek imme-

diate medical attention.

●

For vehicles sold in except Canada:

Do not touch the battery if liquid is

leaking from or adhering to it. If elec-

trolyte (carbonic-based organic elec-

trolyte) from the hybrid battery

(traction battery) comes into contact

with the eyes or skin, it could cause

blindness or skin wounds. In the

unlikely event that it comes into con-

tact with the eyes or skin, wash it off

immediately with a large amount of

water, and seek immediate medical

attention.

●

For vehicles sold in except Canada: If

electrolyte is leaking from the hybrid

battery (traction battery), do not

approach the vehicle.

Even in the unlikely event that the

hybrid battery (traction battery) is

damaged, the internal construction of

the battery will prevent a large amount

of electrolyte from leaking out. How-

ever, any electrolyte that does leak out

will give off a vapor. This vapor is an

irritant to skin and eyes and could

cause acute poisoning if inhaled.

●

For vehicles sold in except Canada:

Do not bring burning or high-tem-

perature items close to the electrolyte.

The electrolyte may ignite and cause a

fire.

■

Hybrid battery (traction battery)

●

For vehicles sold in except Canada:

Your vehicle contains a sealed lithium-

ion battery.

●

Never resell, hand over or modify the

hybrid battery. To prevent accidents,

hybrid batteries that have been

removed from a disposed vehicle are

collected through Lexus dealer. Do

not dispose of the battery yourself.

Unless the battery is properly col-

lected, the following may occur, result-

ing in death or serious injury:

• The hybrid battery may be illegally dis-

posed of or dumped, and it is hazard-

ous to the environment or someone

may touch a high voltage part, result-

ing in an electric shock.

• The hybrid battery is intended to be

used exclusively with your Hybrid

Electric Vehicle. If the hybrid battery is

used outside of your vehicle or modi-

fied in any way, accidents such as elec-

tric shock, heat generation, smoke

generation, an explosion and electro-

lyte leakage may occur.

When reselling or handing over your

vehicle, the possibility of an accident is

extremely high because the person

receiving the vehicle may not be aware

of these dangers.

●

If your vehicle is disposed of without

the hybrid battery having been

removed, there is a danger of serious

electric shock if high voltage parts,

cables and their connectors are

touched. In the event that your vehicle

must be disposed of, the hybrid battery

must be disposed of by your Lexus

dealer or a qualified service shop. If the

hybrid battery is not disposed of prop-

erly, it may cause electric shock that

can result in death or serious injury.

Hybrid battery (traction battery)
air intake vent

Lexus ES300H (2024 year). Manual in english - page 2
