Lexus NX450H+ (2022 year). Manual in english

■

When the shift control system malfunctions

If the shift control system is malfunctioning, when attempting to turn the power switch off,
it may not be able to be turned off. In this situation, it may be possible to turn the power
switch off by applying the parking brake and then operating the power switch.
If there is a malfunction in the system, have the vehicle inspected by your Lexus dealer
immediately.

NOTICE

Do not leave the vehicle with the power switch in ACC or ON for long periods of time
when the hybrid system is not operating.
If "ACCESSORY" or "IGNITION ON" is displayed on the meters while the hybrid
system is not operating, the power switch is not off. Exit the vehicle after turning the
power switch off.

Related Links

Customizable features(P. 763)

2-1. Starting and stopping the hybrid system

185

Driving the v

ehicle

Stopping the hybrid system

WARNING

If you want to stop the hybrid system in an emergency while driving the vehicle, press
and hold the power switch for more than 2 seconds, or press it briefly 3 times or more in
succession.
However, do not touch the power switch while driving, except in an emergency. Turning
the hybrid system off while driving will not cause loss of steering or braking control,
however power assist to the steering will be lost. This will make it more difficult to steer.
Pull over and stop the vehicle as soon as it is safe to do so.

Stop the vehicle completely.

Press the P position switch.

Check that the shift position indicator shows P and the parking brake indicator is
illuminated.

Press the power switch.

The hybrid system will stop, and the meter display will be extinguished (the shift position
indicator will be extinguished a few seconds after the meter display).

Release the brake pedal and check that the display on the instrument cluster is
off.

INFORMATION

■

Automatic hybrid system shut off feature

●

The vehicle is equipped with a feature that automatically shuts off the hybrid
system when the shift position is in P with the hybrid system operating for an
extended period.

●

The hybrid system will automatically shut off after approximately 1 hour if it has
been left running while the shift position is in P.

●

The timer for the automatic hybrid system shut off feature will reset if the brake
pedal is depressed or if the shift position is in a position other than P.

●

After the vehicle is parked, if the door is locked with the door lock switch from the
inside or the mechanical key from the outside, the automatic hybrid system shut off
feature will be disabled. The timer for the automatic hybrid system shut off feature
will be re-enabled if the driver’s door is opened.

2-1. Starting and stopping the hybrid system

186

Driving procedures

Driving procedure

WARNING

■

When driving the vehicle

●

If the vehicle is coasting due to the hybrid system being stopped, etc., do not operate
the door locks or open a door until the vehicle has been safely stopped. Doing so may
cause the steering lock function to operate, possibly leading to an accident.

●

When backing up, you may twist your body around, leading to difficulty in operating
the pedals.
Make sure to operate the pedals properly.

●

Make sure to keep a correct driving posture even when moving the vehicle only
slightly. This allows you to depress the brake and accelerator pedals properly.

●

Depress the brake pedal using your right foot.
Depressing the brake pedal using your left foot may delay response in an emergency,
resulting in an accident.

●

Do not drive the vehicle over or stop the vehicle near flammable materials. The
exhaust system and exhaust gases can be extremely hot. These hot parts may cause a
fire if there is any flammable material nearby.

●

Never turn the power switch off during normal driving. If the hybrid system is stopped
while driving, steering and brake operations will still be possible, however, power assist
will no longer be provided and the steering wheel will become difficult to operate.
After checking the safety of the area around your vehicle, stop the vehicle on the side
of the road. In an emergency, if the vehicle cannot be stopped normally, perform an
emergency stop.

●

Use engine braking (downshift) to maintain a safe speed when driving down a steep
hill. Using the brakes continuously may cause the brakes to overheat and lose effec-
tiveness.

●

Do not adjust the positions of the steering wheel, the seat, or the inside or outside rear
view mirrors while driving. Doing so may result in a loss of vehicle control.

●

Always check that all passengers’ arms, heads or other parts of their body are not
outside the vehicle.

●

This vehicle is not designed for extreme off-roading.

•

When driving in sand or mud is unavoidable, drive carefully and avoid continuous
driving on sand or mud.

•

Do not drive on extremely rocky roads or extremely uneven roads.

●

Do not drive across a river or through other bodies of water. This may cause elec-
tric/electronic components to short circuit, damage the hybrid system or cause other
serious damage to the vehicle.

2-2. Driving procedures

188

WARNING

●

Do not drive in excess of the speed limit. Even if the legal speed limit permits it, do
not drive over 85 mph (140 km/h) unless your vehicle has high-speed capability tires.
Driving over 85 mph (140 km/h) may result in tire failure, loss of control and possible
injury. Be sure to consult a tire dealer to determine whether the tires on your vehicle
are high-speed capability tires or not before driving at such speeds.

●

Avoid sudden braking, acceleration, and steering inputs when driving on slick road
surfaces. Doing so may cause the tires to lose traction, leading to loss of control of the
vehicle.

●

Avoid sudden accelerator pedal operations and shift operations when driving on slick
road surfaces.Doing so may cause engine braking or changes in engine speed may
cause the vehicle to slide sideways.

●

After driving through a puddle, lightly depress the brake pedal to make sure that
the brakes are functioning properly. Wet brake pads may prevent the brakes from
functioning properly. If the brakes on only one side are wet and not functioning
properly, steering control may be affected.

●

When driving in sand or mud is unavoidable, drive carefully and avoid continuous
driving on sand or mud.
Do not drive on extremely rocky roads or extremely uneven roads.

■

If you hear a squealing or scraping noise (brake pad wear limit indicators)

Have the brake pads checked and replaced by your Lexus dealer as soon as possible.
Rotor damage may result if the pads are not replaced when needed.
It is dangerous to drive the vehicle when the wear limits of the brake pads and/or those of
the brake discs are exceeded.

NOTICE

■

Avoiding damage to vehicle parts

●

Do not turn and hold the steering wheel at either fully turned position for an extended
period of time. Doing so may damage the power steering motor.

●

When driving over bumps or areas where the road height changes, drive as slowly as
possible. Otherwise the wheels, etc. may be damaged.

■

If you get a flat tire while driving

In the following situations, firmly hold the steering wheel and gradually apply the brakes
to decrease the vehicle’s speed, as a tire may be flat or damaged:

●

When the steering wheel pulls either direction

●

When there are abnormal sounds or vibrations

●

When the vehicle leans abnormally

2-2. Driving procedures

189

Driving the v

ehicle

NOTICE

■

When encountering flooded roads

Do not drive on roads which have become flooded due to heavy rain, etc. Doing so may
cause serious damage to the vehicle, such as the following:

●

Engine stalling

●

Shorts in electrical components

●

Engine damage caused by water immersion

In the event that you drive on a flooded road and the vehicle is flooded, be sure to have
your Lexus dealer check the following:

●

Brake function

●

Changes in quantity and quality of oil and fluid used for the engine, hybrid transmis-
sion, etc.

●

Lubricant condition for the bearings and suspension joints (where possible), and the
function of all joints, bearings, etc.

If the shift control system is damaged by flooding, it may not be possible to change the
shift position to P, or from P to other positions.
In this case, contact your Lexus dealer.

■

Operating your vehicle in a foreign country

Comply with the relevant vehicle registration laws and confirm the availability of
the correct fuel.

2-2. Driving procedures

190

Breaking in your new Lexus

To extend the life of the vehicle, observing the following precautions is recom-
mended:

●

For the first 200 miles (300 km):
Avoid sudden stops.

●

For the first 1000 miles (1600 km):

•

Do not drive at extremely high speeds.

•

Avoid sudden acceleration.

•

Do not drive continuously in low gears.

•

Do not drive at a constant speed for extended periods.

●

For the first 500 miles (800 km):
Do not tow a trailer. (vehicles with towing package)

2-2. Driving procedures

191

Driving the v

ehicle

Intended use of each shift position

Select the shift position depending on your purpose and situation.

Shift position

Objective or function

Parking the vehicle/starting the hybrid sys-
tem

Reversing

Neutral

Normal driving

(1)

S mode driving

(2)

(1)

To improve fuel efficiency and reduce noise, set the shift position in D for normal

driving. You can choose gear range suitable for your driving situation by operating the

paddle shift switches.

(2)

By selecting shift ranges using S mode, you can control accelerating force and engine

braking force.

INFORMATION

■

When engine braking is not performed

When the vehicle is being driven with the dynamic radar cruise control operating, engine
braking will not be performed even if the following operations are performed.

●

While driving in D or S mode, downshifting to 5 or 4.

●

When Sport mode is selected while driving in D position.

■

If a message about a shift operation is shown

To prevent the shift position from being selected incorrectly or the vehicle from moving
unexpectedly, the shift position may be changed automatically or operating the shift lever
may be required. In this case, change the shift position following the messages on the
multi-information display.

WARNING

Avoid sudden accelerator pedal operations and shift operations when driving on slick
road surfaces. Engine braking or changes in engine speed may cause the vehicle to slide
sideways.

NOTICE

■

Situations where shift control system malfunctions are possible

If any of the following situations occurs, shift control system malfunctions are possible.

2-2. Driving procedures

192

NOTICE

Immediately stop the vehicle in a safe place on level ground, apply the parking brake, and
then contact your Lexus dealer.

●

When the warning message indicating the shift control system appears on the multi-in-
formation display.

●

The display indicates that no shift position is selected for more than a few seconds.

■

Hybrid battery (traction battery) charge

If the shift position is in N, the hybrid battery (traction battery) will not be charging, even
when the engine is running. Therefore, if the vehicle is left with the shift position in N, the
hybrid battery (traction battery) will discharge, and this may result in the vehicle not being
able to start.

2-2. Driving procedures

193

Driving the v

ehicle

Changing the shift position

WARNING

●

Do not let the vehicle roll backward while a forward driving position is selected, or roll
forward while the shift position is in R.
Doing so may result in an accident or damage to the vehicle.

●

Do not shift the shift position to P while the vehicle is moving. Doing so can damage
the transmission and may result in a loss of vehicle control.

●

Do not shift the shift position to R while the vehicle is moving forward. Doing so can
damage the transmission and may result in a loss of vehicle control.

●

Do not shift the shift position to a driving position while the vehicle is moving back-
ward. Doing so can damage the transmission and may result in a loss of vehicle
control.

●

Changing the shift position to N while the vehicle is moving will disengage the hybrid
system. Regenerative braking is not available with the hybrid system disengaged.

●

Be careful not to change the shift position with the accelerator pedal depressed.
Changing the shift position to any positions other than P or N may lead to unexpected
rapid acceleration of the vehicle that may cause an accident and result in death or
serious injury. After changing the shift position, make sure to confirm the current shift
position displayed on the shift position indicator inside the meter.

Shift position display and how to change the shift position

Shift lever

Operate the shift lever gently and securely in
the direction of the arrow on the shift position
indicator.
To shift to N , slide the shift lever in the direction
of the arrow and hold it.
Release the shift lever after each shifting opera-
tion to allow it to return to its regular position
(

●

Shifting to S is only possible when the shift posi-
tion is in D.

2-2. Driving procedures

194

When shifting from P to N, D or R, from N, D,
S or R to P, from D or M to R, or from R to D,
ensure that the brake pedal is being depressed
and the vehicle is stationary.

Shift position indicator

Meter display:

The current shift position is illuminated.

Shift lever display:

The current shift position is illuminated.
When selecting the shift position, make
sure that the shift position has been
changed to the desired position by check-
ing the shift position indicator provided on
the instrument cluster.

P position switch

Fully stop the vehicle and set the parking brake,
and then press the P position switch.
When the shift position is changed to P, the
switch illuminates.
Check that the shift position indicator shows P.

INFORMATION

■

Changing the shift position in each power switch mode

●

The shift position cannot be changed when the power switch is in ACC or off.

●

When the power switch is in ON, if the "READY" indicator is not illuminated, the shift
position can only be changed to N.

●

When the "READY" indicator is illuminated, the shift position can be changed from P
to D, N, or R.

●

When the "READY" indicator is flashing, the shift position cannot be changed from P
to any other position, even if the shift lever is operated. Operate the shift lever again
after the "READY" indicator changes from flashing to illuminated.

■

Shifting the shift position from P to other positions

●

While depressing the brake pedal firmly, operate the shift lever. If the shift lever is
operated without depressing the brake pedal, the buzzer will sound and the shifting
operation will be disabled.

●

When selecting the shift position, make sure that the shift position has been changed
to the desired position by checking the shift position indicator provided on the
instrument cluster.

2-2. Driving procedures

195

Driving the v

ehicle

●

The shift position cannot be changed from P to S directly.

■

The shift position cannot be changed when

In the following situations, a buzzer will sound to inform you that the shift position cannot
be changed. Use the appropriate operation to attempt to change the shift position again.

●

When attempting to change the shift position from P with the brake pedal not
depressed

●

When attempting to change the shift position from P with the accelerator pedal
depressed

●

When attempting to change the shift position from N while stopped or driving at an
extremely low speed with the brake pedal not depressed

●

When attempting to change the shift position from N while stopped or driving at an
extremely low speed with the accelerator pedal depressed

●

When attempting to change the shift position from P or N to S

●

When the P position switch is pressed while driving
When driving at an extremely low speed, the shift position may change to P.

■

The shift position automatically changes to N when

In the following situations, a buzzer will sound to inform you that the shift position
has been changed to N. Use the appropriate operation to attempt to change the shift
position again.

●

When attempting to change the shift position to R while the vehicle is moving forward
When driving at a low speed, the shift position may change to R.

●

When attempting to change the shift position to D while the vehicle is moving
backward
When driving at a low speed, the shift position may change to D.

●

When attempting to change the shift position from R to S

■

If the N shift position is selected while driving

If the shift lever is moved to N while driving above a certain speed, the shift position will
change to N without holding the shift lever in the N position. In this situation, a buzzer will
sound and a message will be displayed on the multi-information display to inform you that
the shift position has been changed to N.

■

Automatic P position selection function

In the following situations, the shift position is automatically changed to P.

●

When pressing the power switch with the vehicle stopped while the power switch is
in ON and the shift position is in a position other than P (after the shift position has
changed to P, the power switch will turn off )

2-2. Driving procedures

196

●

If the driver’s door is opened and all of the following conditions are met, while the shift
position is in a position other than P

•

The power switch is in ON.

•

The driver is not wearing the seat belt.

•

The brake pedal is not depressed.

To start off the vehicle after the shift position is changed to P, operate the shift lever
again.

●

When the vehicle is stopped after the hybrid system has been stopped in an emergen-
cy while driving.

●

When voltage of the 12-volt battery drops while the shift position is in a position other
than P.

■

If the shift position cannot be shifted from P

There is a possibility that the 12-volt battery is discharged. Check the 12-volt battery in
this situation.

(

→

P.672)

WARNING

■

For the shift lever

●

Do not remove the shift lever knob or use anything but a genuine Lexus shift lever
knob. Also, do not hang anything on the shift lever. Doing so could prevent the shift
lever from returning to position, causing unexpected accidents to occur when the
vehicle is in motion.

●

In order to prevent the shift position from accidentally being changed, do not touch the
shift lever when not using them.

■

P position switch

●

Do not press the P position switch while the vehicle is moving.
If the P position switch is pressed when driving at very low speeds (for example,
directly before stopping the vehicle), the vehicle may stop suddenly when the shift
position switches to P, which could lead to an accident.

●

In order to prevent the shift position from accidentally being changed, do not touch the
P position switch when not using them.

*1 :

When the power switch is pressed while driving at extremely slow speeds, such as

immediately before stopping the vehicle, the shift position may automatically change

to P. Make sure that the vehicle is completely stopped before pressing the power

switch.

2-2. Driving procedures

197

Driving the v

ehicle

NOTICE

■

Notes regarding shift lever and P position switch operation

Avoid repeatedly operating the shift lever and P position switch in quick succession. The
system protection function may activate and it will not be temporarily possible to shift the
shift position other than P. If this happens, please wait for a while before attempting to
change the shift position again.

■

When exiting the vehicle(driver's seat only)

Check that the shift position indicator shows P and that the parking brake indicator is
illuminated before opening the door and exiting the vehicle.

When the power switch is changed to ACC with the shift position held in
N

Performing the following operations allows the power switch to be set to ACC with
the shift position held in N.

Operate the shift lever and change the shift position to N when the hybrid
system is operating.

Return the shift lever to its regular position (

●

Operate the shift lever to N and hold it there until the buzzer sounds.

Press the power switch within 5 seconds after the buzzer sounds.

Make sure to check that the buzzer sounds and "Holding N Push P Switch When
Done" is displayed on the multi-information display.

●

To change to a shift position other than N, press the P position switch. The shift
position will be changed to P.

●

Even if the hybrid system is not operating, by operating the shift lever and the power
switch, the power switch may be changed to ACC with the shift position held in N.
Make sure that the hybrid system is operating before performing the operation.

2-2. Driving procedures

198

Starting off

With the brake pedal depressed, shift the shift position to D.

Check that the shift position indicator shows D.

WARNING

Always keep your foot on the brake pedal while stopped with the "READY" indicator
is illuminated. This prevents the vehicle from creeping.

If the parking brake is set, release the parking brake.

Gradually release the brake pedal and gently depress the accelerator pedal to
accelerate the vehicle.

Starting off on an incline

Firmly depress the brake pedal and shift the shift position to D.

The hill-start assist control will be activated.

WARNING

Always keep your foot on the brake pedal while stopped with the "READY" indicator
is illuminated. This prevents the vehicle from creeping.

Set the parking brake.

Release the brake pedal and gently depress the accelerator pedal to acceler-
ate the vehicle.

Release the parking brake.

2-2. Driving procedures

199

Driving the v

ehicle

Operations when turning left or right or changing lanes

By operating the turn signal lever, the intent of the driver can be shown as follows.

INFORMATION

●

The turn signal lights can be operated when the power switch is in ON.

●

If the indicator flashes faster than usual, check that a light bulb in the front or rear turn
signal lights has not burned out.

Move the lever to position

The right turn signal lights will blink.

Move the lever to position

and release it.

The right hand signals will flash 3 times.

Move the lever to position

and release it.

The left hand signals will flash 3 times.

Move the lever to position

The left turn signal lights will blink.

2-2. Driving procedures

200

Changing the shift range

The shift range can be changed by operating the paddle shift switches. Changing
the shift range enables the level of engine braking force to be selected.

Selecting shift ranges in the D position

To drive using temporary shift range selection, operate the [-] paddle shift switch
with the shift position in D.
The shift range can then be selected by operating the [-] and [+] paddle shift
switches.

Upshift

Downshift

The selected shift range, from D1 to D6, will be displayed on the multi-information
display.
To return to normal D position driving, hold the [+] paddle shift switch for a certain
amount of time.

●

Shift ranges and their functions

•

You can choose from 6 levels of engine braking force.

•

A lower shift range will provide greater engine braking force than a shift range. As a
result, the engine speed will increase.

INFORMATION

■

Automatic deactivation of shift range selection in the D position

Shift range selection in the D position will be deactivated in the following situations:

●

When the vehicle comes to a stop

●

If the accelerator pedal is depressed for more than a certain period of time

●

When the shift position is shifted to a position other than D

■

Downshifting restriction warning buzzer

To help ensure safety and driving performance, downshift operations may be restricted.
In some circumstances, downshifting may not be possible even when the paddle shift
switch is operated. (A buzzer will sound twice.)

2-2. Driving procedures

201

Driving the v

ehicle

Lexus NX450H+ (2022 year). Manual in english - page 11
