Lexus UX250h (2023 year). Manual in english - page 6

106

3-1. Key information

The electronic keys are equipped with
the following wireless remote control:

Locks all the doors (



P.110)

Unlocks all the doors (



P.110)

Opens the windows and moon

roof

*1, 2

(



P.110)

Opens and closes the power back
door

(



P.117)

Sounds the alarm (



P.106)

: If equipped

: This setting must be customized at your

Lexus dealer.

■

Theft deterrent panic mode

When

is pressed for longer than

about 1 second, an alarm will sound inter-
mittently and the vehicle lights will flash to
deter any person from trying to break into
or damage your vehicle.
To stop the alarm, press any button on the
electronic key.

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
(



P.396)

NOTICE

●

Do not crush the battery cover or use

a screwdriver to remove the battery

cover.

Forcibly removing the battery cover

may bend or damage the key.

●

If the battery cover is frequently

removed, the battery cover may

become loose.

●

When installing the battery, make sure

to check the direction of the battery.

Installing the battery in the wrong

direction may cause the battery to

deplete rapidly.

●

The surface of the card key may be

damaged, or its coating may peel off in

the following situations:

• The card key is carried together with

hard objects, such as coins and keys.

• The card key is scraped with a sharp

object, such as the tip of a mechanical

pencil.

• The surface of the card key is wiped

with thinner or benzene.

Wireless remote control

A
B
C

Using the mechanical key

107

3-1. Key information

Before drivi

■

When required to leave the vehicle’s

key with a parking attendant

Lock the glove box as circumstances

demand. (



P.289)

Remove the mechanical key for your own

use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys



P.394

■

If a wrong key is used

The key cylinder rotates freely to isolate

inside mechanism.

■

Card key (if equipped)

●

If it is difficult to take out the mechanical

key, push down the release button using

a pen tip, etc. If it is still difficult to pull it

out, use a coin, etc.

●

To store the mechanical key in the card

key, insert it while pressing the release

button.

NOTICE

■

Handling the card key (if equipped)

Do not apply excess force when inserting

the mechanical key into the card key.

Doing so may damage the card key.

108

3-1. Key information

: If equipped

■

Free/open source software information

This product contains Free/open source

software (FOSS). License information

and/or the source code of this FOSS can

be obtained at the following URL:
https://www.denso.com/global/en/

opensource/dkey/toyota/

In order to use the Digital Key, you
need to install the Lexus App, Register
the Vehicle to the customer’s Lexus
App profile, and subscribe to Remote
Services, and enroll in Digital Key.



A Digital Key can be used when the
smartphone and server can com-
municate. The Digital Key may
become unusable if the smartphone
is not connected to the Internet. Be
sure to carry the electronic key of
the vehicle if traveling to a location
with unreliable communications.



If the smartphone battery is
depleted, the smartphone cannot be
used as Digital Key. If the battery

level is low, be sure to charge the
smartphone prior to going out.



The Digital Key system is related to
the smart access system with push-
button start. If the smart access sys-
tem with push-button start has been
deactivated in the vehicle customi-
zation setting, the Digital Key will
also be disabled.



The Digital Key cannot be used to
lock or unlock the doors by touch-
ing or gripping a door handle.
(Doors can be locked or unlocked
using the Digital Key App.)



Depending on the radio wave envi-
ronment, the Digital Key may not be
able to be used. (



P.128)



When transferring vehicle owner-
ship, make sure to delete the Digital
Keys.



If the vehicle is not operated for 14
days or more, the Digital Key will
not connect automatically. In this sit-
uation, the Digital Key connection
may change to a manual operation.



A part of the services may be
stopped for a certain period of time
due to server maintenance. How-
ever, registered Digital Keys can be
used during the maintenance.



A smartphone with the Digital Key
App enabled will be able to lock and
unlock the doors, start the hybrid
system and perform any other oper-
ations as same as the electronic key
of the vehicle. Be especially careful
not to lose the smartphone or allow
it to be stolen.

Digital Key

A smartphone can be used instead
of the electronic key of the vehicle
by installing the dedicated Digital
Key App on a smartphone.
Also, Digital Key can be shared
with your family or friends using the
Digital Key App.

Digital key usage conditions

Digital key precautions

109

3-1. Key information

Before drivi

If the smartphone is lost or stolen,
contact your Lexus dealer immedi-
ately.



When taking your vehicle to a Lexus
dealer for an inspection or repairs,
make sure to bring an electronic
key.

110

3-2. Opening, closing and locking the doors

3-2.Opening, closing and locking the doors

■

Smart access system with push-
button start

Carry the electronic key to enable this
function.

Grip the driver’s door handle to
unlock the door. Holding the
driver’s door handle for approxi-
mately 2 seconds unlocks all the
doors. Grip the front passenger
door handle to unlock all the
doors.

Make sure to touch the sensor on the back
of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

: The door unlock settings can be

changed.

Touch the lock sensor (the indenta-
tion on the upper part of the front
door handle) to lock all the doors.

Check that the door is securely locked.

■

Wireless remote control

Locks all the doors

Check that the door is securely locked.

Unlocks all the doors

Pressing the button unlocks the driver’s
door. Pressing the button again within 3
seconds unlocks the other doors.
Press and hold to open the windows and
moon roof

*1, 2

: If equipped

: This setting must be customized at your

Lexus dealer.

■

Switching the door unlock function

It is possible to set which doors the entry

function unlocks using the wireless remote

control.

Turn the power switch off.

When the indicator light on the key sur-
face is not on, press and hold

for approximately 5

seconds while pressing and holding

The setting changes each time an operation
is performed, as shown below. (When
changing the setting continuously, release
the buttons, wait for at least 5 seconds, and
repeat step

Side doors

Unlocking and locking the doors
from the outside

111

3-2. Opening, closing and locking the doors

Before drivi

To prevent unintended triggering of the
alarm, unlock the doors using the wireless
remote control and open and close a door
once after the settings have been changed.
(If a door is not opened within 60 seconds
after

is pressed, the doors will be

locked again and the alarm will automati-
cally be set.)
In a case that the alarm is triggered, imme-
diately stop the alarm. (



P.69)

■

Locking the front doors from the outside

without a key

Push down the inside lock button.

(



P.113)

Close the door.

The door cannot be locked if the power

switch is in ACC or ON, or the electronic

key is left inside the vehicle.
The key may not be detected correctly and
the door may be locked.

■

Impact detection door lock release sys-

tem

In the event that the vehicle is subject to a

strong impact, all the doors are unlocked.

Depending on the force of the impact or the

type of accident, however, the system may

not operate.

■

Operation signals

A buzzer sounds and the emergency flash-

ers flash to indicate that the doors have

been locked/unlocked. (Locked: Once;

Unlocked: Twice)
A buzzer sounds to indicate that all win-

dows are opening.

■

Security feature

If a door is not opened within approximately

60 seconds after the vehicle is unlocked,

the security feature automatically locks the

vehicle again.

■

When the door cannot be locked by the

lock sensor on the upper part of the

door handle

When the door cannot be locked even if the

lock sensor on the upper part of the door

handle is touched by a finger, touch the lock

sensor with the palm.

When gloves are being worn, remove the

gloves.

■

Open door warning buzzer

If an attempt to lock the doors is made when

a door is not fully closed, a buzzer sounds

continuously for 5 seconds. Fully close the

door to stop the buzzer, and lock the vehi-

cle once more.

■

Setting the alarm

Locking the doors will set the alarm system.

(



P.69)

■

Conditions affecting the operation of

the smart access system with push-but-

ton start or wireless remote control



P.128

Multi-information

display/Beep

Unlocking function

Exterior: Beeps 3

times

Interior: Pings

once

Holding the driver’s

door handle unlocks

only the driver’s door.

Holding the front pas-

senger door handle

unlocks all the doors.

Exterior: Beeps

twice

Interior: Pings

once

Holding a front door

handle unlocks all the

doors.

112

3-2. Opening, closing and locking the doors

■

If the smart access system with push-

button start or the wireless remote con-

trol does not operate properly

●

Use the mechanical key to lock and

unlock the doors. (



P.396)

●

Replace the key battery with a new one if

it is depleted. (



P.359)

■

If the 12-volt battery is discharged

The doors cannot be locked and unlocked

using the smart access system with push-

button start or wireless remote control.
Lock or unlock the doors using the

mechanical key. (



P.396)

■

Rear seat reminder function

●

In order to remind you not to forget lug-

gage, etc. on the rear seat, when the

power switch is turned off after any of the

following conditions is met, a buzzer will

sound and a message will be displayed on

the multi-information display for approxi-

mately 6 seconds.

• The hybrid system is started within 10

minutes after opening and closing a rear

door.

• A rear door has been opened and closed

after the hybrid system was started.

However, if a rear door is opened and then

closed within approximately 2 seconds, the

rear seat reminder function may not oper-

ate.

●

The rear seat reminder function deter-

mines that luggage, etc. has been placed

on a rear seat based on opening and

closing of a rear door. Therefore,

depending on the situation, the rear seat

reminder function may not operate and

you may still forget luggage, etc. on the

rear seat, or it may operate unnecessar-

ily.

●

The rear seat reminder function can be

enabled/disabled. (



P.427)

■

Customization

Settings (e.g. unlocking function using a

key) can be changed. (Customizable fea-

tures:



P.428)

■

Door lock switches (to
lock/unlock)

Locks all the doors

WARNING

■

To prevent an accident

Observe the following precautions while

driving the vehicle.

Failure to do so may result in a door

opening and an occupant falling out,

resulting in death or serious injury.

●

Ensure that all doors are properly

closed and locked.

●

Do not pull the inside handle of the

doors while driving.

Be especially careful for the front

doors, as the doors may be opened

even if the inside lock buttons are in

locked position.

●

Set the rear door child-protector locks

when children are seated in the rear

seats.

■

When opening or closing a door

Check the surroundings of the vehicle

such as whether the vehicle is on an

incline, whether there is enough space

for a door to open and whether a strong

wind is blowing. When opening or clos-

ing the door, hold the door handle tightly

to prepare for any unpredictable move-

ment.

Unlocking and locking the doors
from the inside

113

3-2. Opening, closing and locking the doors

Before drivi

Unlocks all the doors

■

Inside lock buttons (to lock)

Push down the inside lock button to
lock the door.

■

Inside door handles (to unlock)



For the front doors

Pull the handle to unlock and open the
door.

When the door is unlocked, the inside lock
button will pop up.



For the rear doors

Pull the handle to unlock the door. Pull
the handle a second time to open the
door.

When the door is unlocked, the inside lock
button will pop up.

■

If a symbol indicating one or more doors

are open is shown on the multi-informa-

tion display

The hood or one or more of the doors are

not fully closed. The system also indicates

which doors are not fully closed. If the vehi-

cle reaches a speed of 3 mph (5 km/h), a

buzzer sounds to indicate that the door(s)

are not yet fully closed.
Make sure that the hood and all the doors

are closed.

The door cannot be opened from
inside the vehicle when the lock is set.

Unlock

Lock

These locks can be set to prevent children
from opening the rear doors. Push down
on each rear door switch to lock both rear
doors.

The following functions can be set or
canceled:

For instructions on customizing, refer to
P.426.

Rear door child-protector lock

Automatic door locking and
unlocking systems

114

3-2. Opening, closing and locking the doors

Function

Operation

Speed linked door
locking function

All doors are auto-
matically locked
when vehicle speed
is approximately 12
mph (20 km/h) or
higher.

Shift position linked
door locking func-
tion

All doors are auto-
matically locked
when shifting the
shift lever out of P.

Shift position linked
door unlocking
function

All doors are auto-
matically unlocked
when shifting the
shift lever to P.

Driver’s door linked
door unlocking
function

All doors are auto-
matically unlocked
when driver’s door is
opened within
approximately 45
seconds after turn-
ing the power switch
off.

Back door

The back door can be
locked/unlocked and
opened/closed by the following
procedures.

WARNING

Observe the following precautions.
Failure to do so may cause parts of the

body to be caught, resulting in death or

serious injury.

■

Before driving the vehicle

Before driving the vehicle, make sure

that the back door is fully closed. If the

back door is not fully closed, it may open

unexpectedly while driving, causing an

accident.

■

Caution while driving

●

Keep the back door closed while driv-

ing.

If the back door is left open, it may hit

nearby objects while driving or lug-

gage may be unexpectedly thrown

out, causing an accident.

In addition, exhaust gases may enter

the vehicle, causing death or a serious

health hazard. Make sure to close the

back door before driving.

●

Never let anyone sit in the luggage

compartment. In the event of sudden

braking, sudden swerving or a colli-

sion, they are susceptible to death or

serious injury.

■

When children are in the vehicle

Observe the following precautions.

Failure to do so may result in death or

serious injury.

●

Do not allow children to play in the

luggage compartment.

If a child is accidentally locked in the

luggage compartment, they could

have heat exhaustion or other injuries.

115

3-2. Opening, closing and locking the doors

Before drivi

WARNING

●

Do not allow a child to open or close

the back door.

Doing so may cause the back door to

move unexpectedly, or cause the

child’s hands, arms, head, or neck to

be caught by the closing back door.

■

Operating the back door

Observe the following precautions.

Failure to do so may cause parts of the

body to be caught, resulting in death or

serious injury.

●

Remove any heavy loads, such as

snow and ice, from the back door

before opening it. Failure to do so may

cause the back door to suddenly shut

again after it is opened.

●

When opening or closing the back

door, thoroughly check to make sure

the surrounding area is safe.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the back door is about to open or

close.

●

Use caution when opening or closing

the back door in windy weather as it

may move abruptly in strong wind.

●

Vehicles without power back door:

The back door may suddenly shut if it is

not opened fully. It is more difficult to

open or close the back door on an

incline than on a level surface, so

beware of the back door unexpectedly

opening or closing by itself. Make sure

that the back door is fully open and

secure before using the luggage com-

partment.

●

Vehicles with power back door: The

back door may suddenly shut if it is not

opened fully, while on a steep incline.

Make sure that the back door is

secured before using the luggage

compartment.

●

When closing the back door, take

extra care to prevent your fingers, etc.,

from being caught.

●

When closing the back door, make

sure to press it lightly on its outer sur-

face. If the back door handle is used to

fully close the back door, it may result

in hands or arms being caught.

●

Do not pull on the back door damper

stay (vehicles without power back

door) (



P.117) or back door spindle

(vehicles with power back door)

(



P.123) to close the back door, and

do not hang on the back door damper

stay (vehicles without power back

door) or back door spindle (vehicles

with power back door).

Doing so may cause hands to be

caught or the back door damper stay

(vehicles without power back door) or

back door spindle (vehicles with

power back door) to break, causing an

accident.

●

If a bicycle carrier or similar heavy

object is attached to the back door, it

may suddenly shut again after being

opened, causing someone’s hands,

arms, head or neck to be caught and

injured. When installing an accessory

part to the back door, using a genuine

Lexus part is recommended.

116

3-2. Opening, closing and locking the doors

■

Smart access system with push-
button start

Carry the electronic key to enable this
function.

Locks all the doors

Check that the door is securely locked.

Unlocks all the doors

The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

■

Wireless remote control



P.110

■

Door lock switch



P.112

■

Open

Raise the back door while pressing up
the back door opener switch.

■

Lower the back door using the back
door handle, and make sure to push
the back door down from the outside
to close it.

■

Luggage compartment light

●

The luggage compartment light turns on

when the back door is opened.

●

If the luggage compartment light is left on

when the power switch is turned off, the

light will go off automatically after 20

minutes.

■

If the back door opener is inoperative

The back door can be unlocked from the

inside.

Remove the cover.

To protect the cover, place a rag between

the flathead screwdriver and the cover as

shown in the illustration.

Unlocking and locking the back
door from the outside

Unlocking and locking the back
door from the inside

Opening/closing the back door
(vehicles without power back
door)

117

3-2. Opening, closing and locking the doors

Before drivi

Move the lever.

■

Opening/closing the back door
using the wireless remote control

Press the switch for 1 second.
If the back door is locked, unlock it
before operating the power back door.

■

Opening/closing the back door
from the inside

Press the switch for 1 second.

A buzzer sounds and the back door auto-
matically opens and closes.
Pressing the switch while the back door is
opening/closing stops the operation.
When the switch is pressed again for 1 sec-
ond during the halted operation, the back
door will perform the reverse operation.

■

Opening/closing the back door
from the outside



Open

NOTICE

■

Back door damper stays

The back door is equipped with damper
stays

that hold the back door in

place.

Observe the following precautions.

Failure to do so may cause damage to
the back door damper stay

resulting

in malfunction.

●

Do not attach any foreign objects,

such as stickers, plastic sheets, or

adhesives to the damper stay rod.

●

Do not touch the damper stay rod with

gloves or other fabric items.

●

Do not attach any accessories other

than genuine Lexus parts to the back

door.

●

Do not place your hand on the damper

stay or apply lateral forces to it.

Opening/closing the back door
(vehicles with power back door)

118

3-2. Opening, closing and locking the doors

When the back door is unlocked: Press the
back door opener switch.
When the back door is locked: While car-
rying the electronic key on your person,
press the back door opener switch.
A buzzer sounds and the back door auto-
matically opens.
Pressing the switch while the back door is
opening stops the operation.



Press the switch.
A buzzer sounds and the back door auto-
matically closes.
Pressing the switch while the back door is
closing stops the operation.
Pressing the switch again will open the
back door automatically.



Close the back door and lock all
doors (close & lock function)

Press the switch.
A different buzzer than the normal one will
sound and the power back door will begin
closing automatically. When the power

back door is closed, all of the doors will
lock simultaneously and operation signals
will indicate that all of the doors have been
locked.
If the switch is pressed while the power
back door is closing, the operation will
stop.
Pressing the switch again will close the
power back door automatically.

■

Closing the back door using the
back door handle

Lower the back door using the back
door handle, then a buzzer sounds and
the back door automatically closes.

■

Hands Free Power Back Door

While carrying an electronic key,
stand within the smart access sys-
tem with push-button start opera-
tion range, approximately 19.7 to

119

3-2. Opening, closing and locking the doors

Before drivi

27.6 in. (50 to 70 cm) from the
rear bumper.

Kick sensor

Hands Free Power Back Door
operation detection area

Smart access system with push-
button start operation detection
area (



P.127)

Perform a kick operation by mov-
ing your foot to within approxi-
mately 3.9 in. (10 cm) of the rear
bumper, and then pulling your foot
back after the buzzer sounds.

• Perform the entire kick operation

within 1 second.

• The Hands Free Power Back Door

will not start operating while a foot is
detected under the rear bumper.

• Operate the Hands Free Power

Back Door without contacting the
rear bumper with your foot.

• If another electronic key is in the

cabin or luggage compartment, it
may take slightly longer than normal
for the operation to occur.

• If the buzzer sounds twice, perform

a kick operation again.

Kick sensor

Hands Free Power Back Door
operation detection area

When the kick sensor detects that
your foot is pulled back, a buzzer
will sound and the back door will
automatically fully open/close.

If a foot is moved under the rear bumper

while the back door is operating, the back

door will stop moving.

■

Luggage compartment light

●

The luggage compartment light turns on

when the back door is opened.

●

If the luggage compartment light is left on

when the power switch is turned off, the

light will go off automatically after 20

minutes.

■

Power back door operating conditions

With the power back door operations set to

ON, it can automatically open and close for

the following conditions:

●

The power back door is unlocked. How-

ever, the power back door will operate if

it is locked, in the following situations:

• When the electronic key is being carried

and the power back door opener switch

is pressed

• When the wireless remote control is

used

●

When the power switch is in ON, in addi-

tion to the above for the opening opera-

tions, the back door operates for any of

A
B

120

3-2. Opening, closing and locking the doors

the following conditions:

• Parking brake is engaged

• The brake pedal is depressed

• The shift lever is in P

: When configured with the customization

function so that it can be operated after
being unlocked, operate the back door
after it has been unlocked.

■

Hands Free Power Back Door operat-

ing conditions

●

When the Hands Free Power Back Door

operation setting is turned on

●

When an electronic key is carried within

the operation range

■

Back door closer

In the event that the back door is left slightly

open, the back door closer will automati-

cally close it to the fully closed position.

Whatever the state of the power switch, the

back door closer operates.

■

Operation of the power back door

●

A buzzer sounds and the emergency

flashers flash twice to indicate that the

back door is opening/closing.

●

When the power back door operations

are OFF, the power back door does not

operate but it can be opened and closed

by hand.

●

When the power back door automati-

cally opens, if an abnormality due to peo-

ple or objects is detected, operation will

stop.

■

Back door reserve lock function

This function reserves locking of all doors

beforehand, when the power back door is

open.
When the following procedure is per-

formed, all the doors except the power

back door are locked and then power back

door will also be locked at the same time it

is closed.

Close all doors, except the back door.

During the power back door closing

operation, lock the doors using the

smart access system with push-button

start (



P.110) or the wireless remote

control. (



P.106)

A buzzer sounds and the emergency flash-

ers flash to indicate that all the doors have

been closed and locked.
Before leaving the vehicle, make sure that

all the doors are closed and locked. The

doors may not be locked due to the jam

protection function or door lock prevention

function.

■

Close & lock function

When the power back door is open, this

function closes the power back door and

then locks all of the doors simultaneously.
When the following procedures are per-

formed and there are no electronic keys for

the vehicle within the vehicle, all of the

doors will lock when the power back door is

completely closed.

Close all of the doors except the power

back door.

While carrying an electronic key, press
the

switch on the lower part of

the power back door (



P.117).

A different buzzer than the normal one will

sound and then the power back door will

begin closing automatically. When the

power back door is closed, all of the doors

will lock simultaneously and operation sig-

nals will indicate that all of the doors have

been locked.

■

Situations in which the close & lock

function may not operate properly

In the following situations, the close & lock

function may not operate properly:

●

If the

switch on the lower part of

the power back door (



P.117) is pressed

by a hand which is holding an electronic
key

●

If the

switch on the lower part of

the power back door (



P.117) is pressed

when the electronic key is in a bag, etc.
that is placed on the ground

●

If the

switch on the lower part of

the power back door (



P.117) is pressed

with the electronic key not near the vehi-

121

3-2. Opening, closing and locking the doors

Before drivi

cle

■

Situations in which the Hands Free

Power Back Door may not operate

properly

In the following situations, the Hands Free

Power Back Door may not operate prop-

erly:

●

When a foot remains under the rear

bumper

●

If the rear bumper is strongly hit with a

foot or is touched for a while

If the rear bumper has been touched for a

while, wait for a short time before

attempting to operate the Hands Free

Power Back Door again.

●

When operated while a person is too

close to the rear bumper

●

When an external radio wave source

interferes with the communication

between the electronic key and the vehi-

cle (



P.128)

●

When the vehicle is parked near an elec-

trical noise source or a metallic object

which affects the sensitivity of the Hands

Free Power Back Door, such as a pay

parking spot, gas station, electrically

heated road, fluorescent light or iron

plate

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When mud, snow, ice, etc. is attached to

the rear bumper

●

When the vehicle has been parked for a

while near objects that may move and

contact the rear bumper, such as plants

●

When an accessory is installed to the rear

bumper

If an accessory has been installed, turn

the Hands Free Power Back Door opera-

tion setting off.

■

Preventing unintentional operation of

the Hands Free Power Back Door

When an electronic key is in the operation

range, the Hands Free Power Back Door

may operate unintentionally, so be careful

in the following situations.

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When dirt is wiped off the rear bumper

●

When a small animal or small object, such

as a ball, moves under the rear bumper

●

When an object is moved from under the

rear bumper

●

If someone is swinging their legs while sit-

ting on the rear bumper

●

If the legs or another part of someone’s

body contacts the rear bumper while

passing by the vehicle

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Back

Door, such as a pay parking spot, gas sta-

tion, electrically heated road, or fluores-

cent light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When the vehicle is parked in a place

where objects such as plants are near the

rear bumper

●

If luggage, etc. is set near the rear

bumper

●

If accessories or a vehicle cover is

installed/removed near the rear bumper

●

When the vehicle is being towed

To prevent unintentional operation, turn the
Hands Free Power Back Door operation
setting off.

■

When reconnecting the 12-volt battery

To enable the power back door to operate

properly, close the back door manually.

■

Jam protection function

Sensors are installed in the right and left

Content .. 4 5 6 7 ..
