2-1. Instrument cluster

Warning lights and indicators.

Gauges and meters (except F

SPORT models) ........................

Gauges and meters (F SPORT

models)..........................................

Multi-information display..........

Head-up display ...........................

Energy monitor/consumption

screen ............................................

2-1. Instrument cluster

icle

rmat

ion
an

dica
tor

Warning lights inform the driver of
malfunctions in the indicated vehicle’s
systems.

Warning lights

(U.S.A.)

Brake system warning light

(



P.378)

(red)

(Canada)

Brake system warning light

(



P.378)

Charging system warning
light

(



P.378)

Low engine oil pressure warn-
ing light

(



P.378)

(U.S.A.)

Malfunction indicator lamp

(



P.379)

(Canada)

Malfunction indicator lamp

(



P.379)

High coolant temperature
warning light

(



P.379)

Tire pressure warning light

(



P.379)

(yellow)

Brake system warning light

(



P.379)

SRS warning light

(



P.380)

(U.S.A.)

ABS warning light

(



P.380)

(Canada)

ABS warning light

(



P.380)

(red)

Electric power steering system
warning light

(



P.380)

(yellow)

Electric power steering system
warning light

(



P.380)

Slip indicator

(



P.380)

(Flashes)

(U.S.A.)

Parking brake indicator
(



P.381)

(Flashes)

(Canada)

Parking brake indicator
(



P.381)

(Flashes)

Brake hold operated indica-
tor

(



P.381)

(Flashes)

Intuitive parking assist OFF indi-
cator

(if equipped) (



P.381)

(Flashes)

RCTA OFF indicator

(if

equipped) (



P.382)

(Flashes)

PKSB OFF indicator

(if

equipped) (



P.382)

Low fuel level warning light
(



P.382)

Driver’s and front passenger’s
seat belt reminder light
(



P.382)

Rear passengers’ seat belt
reminder lights

(



P.383)

Inappropriate pedal operation
warning light

(



P.383)

(orange)

LTA indicator

(



P.384)

(Flashes or

illuminates)

PCS warning light

(



P.384)

2-1. Instrument cluster

: These lights come on when the power

switch is turned to ON to indicate that a
system check is being performed. They
will go off after the hybrid system is on,
or after a few seconds. There may be a
malfunction in a system if the lights do
not come on, or go off. Have the vehicle
inspected by your Lexus dealer.

: This light illuminates on the multi-infor-

mation display.

The indicators inform the driver of the
operating state of the vehicle’s various
systems.

Hybrid system overheat warn-
ing light

(



P.384)

(orange)

Low traction battery charge
warning light

(



P.384)

WARNING

■

If a safety system warning light does

not come on

Should a safety system light such as the

ABS and SRS warning light not come on

when you start the hybrid system, this

could mean that these systems are not

available to help protect you in an acci-

dent, which could result in death or seri-

ous injury. Have the vehicle inspected by

your Lexus dealer immediately if this

occurs.

Indicators

Turn signal indicator (



P.173)

(U.S.A.)

Headlight indicator (



P.180)

(Canada)

Tail light indicator (



P.180)

Headlight high beam indicator
(



P.182)

Automatic High Beam indica-
tor

(



P.183)

Fog light indicator (if equipped)
(



P.186)

PCS warning light

*1, 2

(



P.199)

Cruise control indicator

(



P.221)

Dynamic radar cruise control
indicator

(



P.221)

Cruise control “SET” indica-
tor

(



P.221)

(white)

LTA indicator

*3, 4

(



P.214)

(green)

LTA indicator

*3, 4

(



P.214,

199)

(orange)

LTA indicator

*3, 4, 5

(



P.214)

BSM outside rear view mirror
indicators

*1, 6

(if equipped)

(



P.232)

BSM indicator (if equipped)
(



P.232)

Intuitive parking assist OFF indi-
cator

*1, 2

(if equipped)

(



P.238)

RCTA OFF indicator

*1, 2

(if

equipped) (



P.245)

PKSB OFF indicator

*1, 2

(if

equipped) (



P.251)

Slip indicator

*1, 5

(



P.261)

VSC OFF indicator

*1, 2

(



P.261)

2-1. Instrument cluster

icle

rmat

ion
an

dica
tor



Drive mode indicators



Except F SPORT models



F SPORT models

: These lights come on when the power

: This light comes on when the system is

turned off.

: This light illuminates on the multi-infor-

mation display.

: Depending on the operating condition,

the color and illuminating/flashing state
of the light change.

: This light flashes to indicate that the sys-

tem is operating.

: This light illuminates on the outside rear

view mirrors.

: Except F SPORT models: This light illu-

minates on the multi-information dis-
play.

: When the outside temperature is

approximately 37°F (3°C) or lower,
this indicator will flash for approxi-

Smart access system with push-
button start indicator

(



P.163)

“READY” indicator (



P.163)

EV drive mode indicator
(



P.167)

(U.S.A.)

Parking brake indicator
(



P.174)

(Canada)

Parking brake indicator
(



P.174)

Brake hold standby indicator

(



P.177)

Brake hold operated indica-
tor

(



P.177)

EV indicator

(



P.61)

Low outside temperature indi-
cator

*3, 8

(



P.79, 83)

Security indicator

(



P.68,

69)

(U.S.A.)

“AIR BAG ON/OFF” indica-
tor

*10

(



P.39)

(Canada)

“AIR BAG ON/OFF” indica-
tor

*10

(



P.39)

Eco drive mode indicator
(



P.258)

Sport mode indicator
(



P.258)

Custom mode indicator (if
equipped) (



P.258)

Eco drive mode indicator
(



P.258)

Sport mode indicator (if
equipped) (



P.258)

Sport S mode indicator (if
equipped) (



P.258)

Sport S+ mode indicator (if
equipped) (



P.258)

2-1. Instrument cluster

icle

rmat

ion
an

dica
tor

■

Locations of gauges and meters

The units of measure may differ depending on the intended destination of the vehicle.

Multi-information display

Presents the driver with a variety of vehicle data (



P.89)

Displays warning messages if a malfunction occurs (



P.387)

Outside temperature

Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C)
Low outside temperature indicator comes on when the ambient temperature is 37°F
(3°C) or lower

Speedometer

Displays the vehicle speed

Hybrid System Indicator/tachometer

Displays hybrid system output or regeneration level (



P.80)

This display changes to a tachometer depending on the driving mode, and can be set to
show the tachometer in any driving mode on the settings display. (



P.93, 258)

Clock

The GPS clock’s time is automatically adjusted by utilizing GPS time information. For
details, refer to the “MULTIMEDIA OWNER’S MANUAL”.

Engine coolant temperature gauge

Displays the engine coolant temperature

Fuel gauge

Gauges and meters (except F SPORT models)

Meter display

2-1. Instrument cluster

Displays the quantity of fuel remaining in the tank
In the following situations, the actual quantity of fuel remaining in the tank may not be dis-
played correctly. Refer to P.80 if the actual quantity of fuel remaining in the tank is not dis-
played correctly.
• A small amount of fuel is added.
• Fuel is added with the fuel gauge near or at “F”.
• The vehicle is stopped on an uneven surface, such as a slope.
• The vehicle is driven on a slope or around a curve.

Shift position/shift range (



P.169)

Odometer and trip meter display (



P.81)

■

Hybrid System Indicator

Charge area

Shows regeneration

status.

Regenerated energy will be used to
charge the hybrid battery (traction bat-
tery).

Hybrid Eco area

Shows that gasoline engine power is not
being used very often.
The gasoline engine will automatically stop
and restart under various conditions.

Eco area

Shows that the vehicle is being driven in an
Eco-friendly manner.
By keeping the bar display within Eco area,
more Eco-friendly driving can be
achieved.

Power area

Shows that an Eco-friendly driving range is
being exceeded (during full power driving

etc.)

: When used in this manual, regeneration

refers to the conversion of energy cre-
ated by the movement of the vehicle into
electrical energy.

■

Engine speed

On Hybrid Electric Vehicles, engine speed

is precisely controlled in order to help

improve fuel efficiency and reduce exhaust

emissions etc.

There are times when the engine speed that

is displayed may differ even when vehicle

operation and driving conditions are the

same.

■

Hybrid System Indicator is displayed

when

The Hybrid System Indicator is displayed in

the following situations:

●

The shift lever is in D or S.

●

The driving mode is other than Sport

mode.

■

Manually updating the fuel gauge and

possible driving range

The fuel gauge and the possible driving

range are linked. If the displays of the fuel

gauge and possible driving range do not

update after adding a small amount of fuel,

the displays can be updated by performing

the following procedure.

Stop the vehicle on a level surface.

Press the “ODO TRIP” switch to

change the odometer and trip meter

display to odometer.

Turn the power switch off.

2-1. Instrument cluster

icle

rmat

ion
an

dica
tor

While pressing and holding the “ODO

TRIP” switch, turn the power switch to

ON mode.

Continue to hold the “ODO TRIP”

switch for approximately 5 seconds,

and then release it once the odometer

begins flashing.

Updating is complete once the odometer

flashes for approximately 5 seconds and

then the display returns to normal.

■

Outside temperature display

●

In the following situations, the correct

outside temperature may not be dis-

played, or the display may take longer

than normal to change:

• When stopped, or driving at low speeds

(less than 12 mph [20 km/h])

• When the outside temperature has

changed suddenly (at the entrance/exit

of a garage, tunnel, etc.)

●

When “--” or “E” is displayed, the system

may be malfunctioning. Take your vehicle

to your Lexus dealer.

■

Speed unit setting for the speedometer

When the speed unit has been changed

from the default setting, the vehicle speed in

the default unit is also displayed in the

meter.

■

GPS automatic adjustment of the clock

When the system is malfunctioning, the

clock adjustment screen may be displayed

on the multi-information display. In this

case, have the vehicle inspected by your

Lexus dealer.

■

Liquid crystal display



P.90

■

Customization

The gauges and meters can be customized
on

of the multi-information display.

(



P.427)

■

Display items



Odometer

Displays the total distance the vehicle has
been driven.



Trip meter A/trip meter B

Displays the distance the vehicle has been
driven since the meter was last reset. Trip
meters A and B can be used to record and
display different distances independently.

WARNING

■

The information display at low tem-

peratures

Allow the interior of the vehicle to warm

up before using the liquid crystal infor-

mation display. At extremely low tem-

peratures, the information display

monitor may respond slowly, and display

changes may be delayed.
For example, there is a lag between the

driver’s shifting and the new gear num-

ber appearing on the display. This lag

could cause the driver to downshift

again, causing rapid and excessive

engine braking and possibly an accident

resulting in death or injury.

NOTICE

■

To prevent damage to the engine and

its components

●

Do not let the indicator of the tachom-

eter enter the red zone, which indi-

cates the maximum engine speed.

●

The engine may be overheating if the

engine coolant temperature gauge is

in the red zone (H). In this case, imme-

diately stop the vehicle in a safe place,

and check the engine after it has

cooled completely. (



P.402)

Odometer and trip meter dis-
play

2-1. Instrument cluster

icle

rmat

ion
an

dica
tor

■

Locations of gauges and meters

When the main meter is in the side position, some of the meter displays and the
gauge layout will change.



When the main meter is in the center position

The units of measure may differ depending on the intended destination of the vehicle.

Engine coolant temperature gauge

Displays the engine coolant temperature

Outside temperature

Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C)
Low outside temperature indicator comes on when the ambient temperature is 37°F
(3°C) or lower

Speedometer

Displays the vehicle speed

Hybrid System Indicator/tachometer

Displays hybrid system output or regeneration level (



P.85)

This display changes to a tachometer depending on the driving mode, and can be set to
show the tachometer in any driving mode on the settings display. (



P.93, 258)

• Rev indicator
• Rev peak

Shift position/shift range (



P.169)

Clock

Gauges and meters (F SPORT models)

Meter display

E
F

2-1. Instrument cluster

The GPS clock’s time is automatically adjusted by utilizing GPS time information. For
details, refer to the “MULTIMEDIA OWNER’S MANUAL”.

Fuel gauge

Displays the quantity of fuel remaining in the tank
In the following situations, the actual quantity of fuel remaining in the tank may not be dis-
played correctly. Refer to P.86 if the actual quantity of fuel remaining in the tank is not dis-
played correctly.
• A small amount of fuel is added.
• Fuel is added with the fuel gauge near or at “F”.
• The vehicle is stopped on an uneven surface, such as a slope.
• The vehicle is driven on a slope or around a curve.

Multi-information display

Presents the driver with a variety of vehicle data (



P.89)

Displays warning messages if a malfunction occurs (



P.387)

Odometer and trip meter display (



P.87)



When the main meter is in the side position

The units of measure may differ depending on the intended destination of the vehicle.

Multi-information display

Presents the driver with a variety of vehicle data (



P.89)

Displays warning messages if a malfunction occurs (



P.387)

Outside temperature

Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C)
Low outside temperature indicator comes on when the ambient temperature is 37°F
(3°C) or lower

Clock

The GPS clock’s time is automatically adjusted by utilizing GPS time information. For

2-1. Instrument cluster

icle

rmat

ion
an

dica
tor

details, refer to the “MULTIMEDIA OWNER’S MANUAL”.

Speedometer

Displays the vehicle speed

Hybrid System Indicator/tachometer

Displays hybrid system output or regeneration level (



P.85)

This display changes to a tachometer depending on the driving mode, and can be set to
show the tachometer in any driving mode on the settings display. (



P.93, 258)

• Rev indicator
• Rev peak

Shift position/shift range (



P.169)

Odometer and trip meter display (



P.87)

Fuel gauge

Engine coolant temperature gauge

Displays the engine coolant temperature

■

Hybrid System Indicator

Charge area

Shows regeneration

status.

Regenerated energy will be used to
charge the hybrid battery (traction bat-
tery).

Hybrid Eco area

Shows that gasoline engine power is not
being used very often.
The gasoline engine will automatically stop
and restart under various conditions.

Eco area

Shows that the vehicle is being driven in an
Eco-friendly manner.
By keeping the bar display within Eco area,
more Eco-friendly driving can be
achieved.

Power area

Shows that an Eco-friendly driving range is
being exceeded (during full power driving
etc.)

: When used in this manual, regeneration

refers to the conversion of energy cre-

2-1. Instrument cluster

ated by the movement of the vehicle into
electrical energy.

■

Rev indicator

When the engine speed reaches a set
speed or the red zone, a ring-shaped
indicator (

) will be displayed on the

tachometer.

The indicators will be displayed in amber
when the engine speed reaches a set
speed, and in red when the engine speed
reaches the red zone.
The engine speed at which the rev indica-
tor will begin to be displayed can be set on

of the multi-information display.

(



P.89)

■

Rev peak

When the engine speed reaches or
exceeds 4000 rpm, an afterimage of
the tachometer will be displayed at the
highest engine speed for approxi-
mately 1 second.

■

Engine speed

On Hybrid Electric Vehicles, engine speed

is precisely controlled in order to help

improve fuel efficiency and reduce exhaust

emissions etc.

There are times when the engine speed that

is displayed may differ even when vehicle

operation and driving conditions are the

same.

■

Hybrid System Indicator is displayed

when

The Hybrid System Indicator is displayed in

the following situations:

●

The shift lever is in D or S.

●

The driving mode is other than Sport

mode.

■

Manually updating the fuel gauge and

possible driving range

The fuel gauge and the possible driving

range are linked. If the displays of the fuel

gauge and possible driving range do not

update after adding a small amount of fuel,

the displays can be updated by performing

the following procedure.

Stop the vehicle on a level surface.

Press the “ODO TRIP” switch to

change the odometer and trip meter

display to odometer.

Turn the power switch off.

While pressing and holding the “ODO

TRIP” switch, turn the power switch to

ON mode.

Continue to hold the “ODO TRIP”

switch for approximately 5 seconds,

and then release it once the odometer

begins flashing.

Updating is complete once the odometer

flashes for approximately 5 seconds and

then the display returns to normal.

■

Outside temperature display

●

In the following situations, the correct

outside temperature may not be dis-

played, or the display may take longer

than normal to change:

• When stopped, or driving at low speeds

(less than 12 mph [20 km/h])

• When the outside temperature has

changed suddenly (at the entrance/exit

2-1. Instrument cluster

icle

rmat

ion
an

dica
tor

of a garage, tunnel, etc.)

●

When “--” or “E” is displayed, the system

may be malfunctioning. Take your vehicle

to your Lexus dealer.

■

Speed unit setting for the speedometer

When the speed unit has been changed

from the default setting, the vehicle speed in

the default unit is also displayed in the

meter.

■

GPS automatic adjustment of the clock

When the system is malfunctioning, the

clock adjustment screen may be displayed

on the multi-information display. In this

case, have the vehicle inspected by your

Lexus dealer.

■

Liquid crystal display



P.90

■

Customization

The gauges and meters can be customized
on

of the multi-information display.

(



P.427)

■

Display items



Odometer

Displays the total distance the vehicle has
been driven.



Trip meter A/trip meter B

Displays the distance the vehicle has been
driven since the meter was last reset. Trip
meters A and B can be used to record and
display different distances independently.



Distance until next engine oil

WARNING

■

The information display at low tem-

peratures

Allow the interior of the vehicle to warm

up before using the liquid crystal infor-

mation display. At extremely low tem-

peratures, the information display

monitor may respond slowly, and display

changes may be delayed.
For example, there is a lag between the

driver’s shifting and the new gear num-

ber appearing on the display. This lag

could cause the driver to downshift

again, causing rapid and excessive

engine braking and possibly an accident

resulting in death or injury.

NOTICE

■

To prevent damage to the engine and

its components

●

Do not let the indicator of the tachom-

eter enter the red zone, which indi-

cates the maximum engine speed.

●

The engine may be overheating if the

engine coolant temperature gauge is

in the red zone (H). In this case, imme-

diately stop the vehicle in a safe place,

and check the engine after it has

cooled completely. (



P.402)

Odometer and trip meter dis-
play

2-1. Instrument cluster

change

Displays the distance the vehicle can be
driven until an oil change is necessary.

■

Changing the display

Each time the “ODO TRIP” switch is
pressed, the displayed item will be
changed. When the trip meter is dis-
played, pressing and holding the switch
will reset the trip meter.

■

Pop-up display

Distance until the next engine oil
change will be displayed when a warn-
ing message indicating that oil mainte-
nance should be performed soon or is
required is displayed.

The brightness of the instrument panel
lights can be adjusted.

Darker

Brighter

■

Instrument panel brightness adjustment

The instrument panel brightness levels

when the surroundings are bright (daytime

etc.) and dark (nighttime etc.) can be

adjusted individually.

The display can be switched between
the center and side positions.

Changing the instrument panel
light brightness

Changing the display

Lexus UX250h (2023 year). Manual in english - page 4
