8-1. Specifications

Vehi

cle

spec

ifi

tions

■

Traction AA, A, B, C

The traction grades, from highest to
lowest, are AA, A, B and C, and they
represent the tire’s ability to stop on
wet pavement as measured under con-
trolled conditions on specified govern-
ment test surfaces of asphalt and
concrete.

A tire marked C may have poor traction
performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction.

■

Temperature A, B, C

The temperature grades are A (the
highest), B, and C, representing the
tire’s resistance to the generation of
heat and its ability to dissipate heat

when tested under controlled condi-
tions on a specified indoor laboratory
test wheel.

Sustained high temperature can cause the
material of the tire to degenerate and
reduce tire life, and excessive temperature
can lead to sudden tire failure.
Grade C corresponds to a level of perfor-
mance which all passenger car tires must
meet under the Federal Motor Vehicle
Safety Standard No. 109.
Grades B and A represent higher levels of
performance on the laboratory test wheel
than the minimum required by law.
Warning: The temperature grades of a tire
assume that it is properly inflated and not
overloaded.
Excessive speed, underinflation, or exces-
sive loading, either separately or in combi-
nation, can cause heat buildup and
possible tire failure.

Glossary of tire terminology

Tire related term

Meaning

Cold tire inflation pressure

Tire pressure when the vehicle has been parked for three
hours or more, or has not been driven more than 1 mile or
1.5 km under that condition

Maximum inflation pressure

The maximum cold inflated pressure to which a tire may
be inflated, shown on the sidewall of the tire

Recommended inflation pres-
sure

Cold tire inflation pressure recommended by a manufac-
turer

Accessory weight

The combined weight (in excess of those standard items
which may be replaced) of automatic transmission, power
steering, power brakes, power windows, power seats,
radio and heater, to the extent that these items are avail-
able as factory-installed equipment (whether installed or
not)

400

8-1. Specifications

Curb weight

The weight of a motor vehicle with standard equipment,
including the maximum capacity of fuel, oil and coolant,
and if so equipped, air conditioning and additional weight
optional engine

Maximum loaded vehicle
weight

The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

Normal occupant weight

150 lb. (68 kg) times the number of occupants specified
in the second column of Table 1

that follows

Occupant distribution

Distribution of occupants in a vehicle as specified in the
third column of Table 1

below

Production options weight

The combined weight of installed regular production
options weighing over 5 lb. (2.3 kg) in excess of the stan-
dard items which they replace, not previously considered
in curb weight or accessory weight, including heavy duty
brakes, ride levelers, roof rack, heavy duty battery, and
special trim

Rim

A metal support for a tire or a tire and tube assembly upon
which the tire beads are seated

Rim diameter
(Wheel diameter)

Nominal diameter of the bead seat

Rim size designation

Rim diameter and width

Rim type designation

The industry manufacturer’s designation for a rim by style
or code

Rim width

Nominal distance between rim flanges

Vehicle capacity weight
(Total load capacity)

The rated cargo and luggage load plus 150 lb. (68 kg)
times the vehicle’s designated seating capacity

Vehicle maximum load on the
tire

The load on an individual tire that is determined by distrib-
uting to each axle its share of the maximum loaded vehicle
weight, and dividing by two

Vehicle normal load on the tire

The load on an individual tire that is determined by distrib-
uting to each axle its share of curb weight, accessory
weight, and normal occupant weight (distributed in accor-
dance with Table 1

below), and dividing by two

Tire related term

Meaning

401

8-1. Specifications

Vehi

cle

spec

ifi

tions

Weather side

The surface area of the rim not covered by the inflated tire

Bead

The part of the tire that is made of steel wires, wrapped or
reinforced by ply cords and that is shaped to fit the rim

Bead separation

A breakdown of the bond between components in the
bead

Bias ply tire

A pneumatic tire in which the ply cords that extend to the
beads are laid at alternate angles substantially less than
90 degrees to the centerline of the tread

Carcass

The tire structure, except tread and sidewall rubber
which, when inflated, bears the load

Chunking

The breaking away of pieces of the tread or sidewall

Cord

The strands forming the plies in the tire

Cord separation

The parting of cords from adjacent rubber compounds

Cracking

Any parting within the tread, sidewall, or innerliner of the
tire extending to cord material

A pneumatic tire with an inverted flange tire and rim sys-
tem in which the rim is designed with rim flanges pointed
radially inward and the tire is designed to fit on the under-
side of the rim in a manner that encloses the rim flanges
inside the air cavity of the tire

Extra load tire

A tire designed to operate at higher loads and at higher
inflation pressures than the corresponding standard tire

Groove

The space between two adjacent tread ribs

Innerliner

The layer(s) forming the inside surface of a tubeless tire
that contains the inflating medium within the tire

Innerliner separation

The parting of the innerliner from cord material in the car-
cass

Intended outboard sidewall

(a)The sidewall that contains a whitewall, bears white let-
tering, or bears manufacturer, brand, and/or model name
molding that is higher or deeper than the same molding
on the other sidewall of the tire, or
(b)The outward facing sidewall of an asymmetrical tire
that has a particular side that must always face outward
when mounted on a vehicle

Tire related term

Meaning

402

8-1. Specifications

Light truck (LT) tire

A tire designated by its manufacturer as primarily
intended for use on lightweight trucks or multipurpose
passenger vehicles

Load rating

The maximum load that a tire is rated to carry for a given
inflation pressure

Maximum load rating

The load rating for a tire at the maximum permissible infla-
tion pressure for that tire

Maximum permissible inflation
pressure

The maximum cold inflation pressure to which a tire may
be inflated

Measuring rim

The rim on which a tire is fitted for physical dimension
requirements

Open splice

Any parting at any junction of tread, sidewall, or innerliner
that extends to cord material

Outer diameter

The overall diameter of an inflated new tire

Overall width

The linear distance between the exteriors of the sidewalls
of an inflated tire, including elevations due to labeling,
decorations, or protective bands or ribs

Passenger car tire

A tire intended for use on passenger cars, multipurpose
passenger vehicles, and trucks, that have a gross vehicle
weight rating (GVWR) of 10,000 lb. or less.

Ply

A layer of rubber-coated parallel cords

Ply separation

A parting of rubber compound between adjacent plies

Pneumatic tire

A mechanical device made of rubber, chemicals, fabric
and steel or other materials, that, when mounted on an
automotive wheel, provides the traction and contains the
gas or fluid that sustains the load

Radial ply tire

A pneumatic tire in which the ply cords that extend to the
beads are laid at substantially 90 degrees to the center-
line of the tread

Reinforced tire

A tire designed to operate at higher loads and at higher
inflation pressures than the corresponding standard tire

Section width

The linear distance between the exteriors of the sidewalls
of an inflated tire, excluding elevations due to labeling,
decoration, or protective bands

Sidewall

That portion of a tire between the tread and bead

Tire related term

Meaning

403

8-1. Specifications

Vehi

cle

spec

ifi

tions

: Table 1



Occupant loading and distribution for vehicle normal load for various desig-

nated seating capacities

Sidewall separation

The parting of the rubber compound from the cord mate-
rial in the sidewall

Snow tire

A tire that attains a traction index equal to or greater than
110, compared to the ASTM E-1136 Standard Reference
Test Tire, when using the snow traction test as described
in ASTM F-1805-00, Standard Test Method for Single
Wheel Driving Traction in a Straight Line on Snow-and
Ice-Covered Surfaces, and which is marked with an
Alpine Symbol (

) on at least one sidewall

Test rim

The rim on which a tire is fitted for testing, and may be any
rim listed as appropriate for use with that tire

Tread

That portion of a tire that comes into contact with the road

Tread rib

A tread section running circumferentially around a tire

Tread separation

Pulling away of the tread from the tire carcass

Treadwear indicators (TWI)

The projections within the principal grooves designed to
give a visual indication of the degrees of wear of the tread

Wheel-holding fixture

The fixture used to hold the wheel and tire assembly
securely during testing

Designated seating capac-

ity, Number of occupants

Vehicle normal load, Num-

ber of occupants

Occupant distribution in a

normally loaded vehicle

2 through 4

2 in front

5 through 10

2 in front, 1 in second seat

11 through 15

2 in front, 1 in second seat, 1 in

third seat, 1 in fourth seat

16 through 20

2 in front, 2 in second seat, 2

in third seat, 1 in fourth seat

Tire related term

Meaning

404

8-2. Customization

8-2.Customization

■

Changing using the meter control
switches

Press

of the meter con-

trol switches, and select

Press

of the meter con-

trol switches, select the item, and
press “OK”.

Press

of the meter con-

trol switches, select the desired set-
ting, and press “OK”.

To go back to the previous screen or
exit the customize mode, press

■

Changing using the Remote Touch

Press the “MENU” button on the
Remote Touch.

Select “Setup” on the menu screen
and select “Vehicle”.

Select “Vehicle Customization”.

Various setting can be changed. Refer to

the list of settings that can be changed for

details.

For details on the Remote Touch, refer
to the “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MAN-
UAL”.

■

When customizing using the Remote

Touch

Stop the vehicle in a safe place, apply the

parking brake, and shift the shift lever to P.

Also, to prevent battery discharge, leave

the engine running while customizing the

features.

Some function settings are changed simultaneously with other functions being cus-
tomized. Contact your Lexus dealer for further details.

Settings that can be changed using the Remote Touch

Settings that can be changed using the meter control switches

Customizable features

Your vehicle includes a variety of
electronic features that can be per-
sonalized to your preferences. The
settings of these features can be
changed by using the meter control
switches, the Remote Touch or at
your Lexus dealer.

Customizing vehicle features

WARNING

■

Cautions during customization

As the engine needs to be running

during customization, ensure that the

vehicle is parked in a place with ade-

quate ventilation. In a closed area such as

a garage, exhaust gases including harm-

ful carbon monoxide (CO) may collect

and enter the vehicle. This may lead to

death or a serious health hazard.

NOTICE

■

During customization

To prevent battery discharge, ensure

that the engine is running while custom-

izing features.

Customizable features

405

8-2. Customization

Vehi

cle

spec

ifi

tions

Settings that can be changed by your Lexus dealer

Definition of symbols: O = Available,



= Not available

■

Gauges, meters and multi-information display (



P.70, 73, 77)

Function

Default setting

Customized setting

Language

English

French



Spanish

Units

miles (MPG)

km (km/L)



km (L/100 km)

miles (MPG Imperial)

Speedometer display

Digital

Analog



Drive information 1

Current fuel con-

sumption



Average fuel

economy (after

reset)

Drive information 2

Distance (driving

range)



Average vehicle

speed (after

reset)

Clock

12-hour display

24-hour display



Pop-up display

Off



Accent color

Color 1

Color 2



Rev indicator

Off



Rev indicator red zone set-
ting

5000 rpm

2000 - 6800 rpm



Rev peak

Off



Eco Driving Indicator Light

Off



Suggestion function

On (when the vehicle is

stopped)



Off

Rear seat reminder function

Off



406

8-2. Customization

: For details about each function:



P.70, 73, 82

: The default setting varies according to country.

: Except F SPORT models

: 2 of the following items: current fuel consumption, average fuel economy (after reset),

average fuel economy (after start), average fuel economy (after refuel), average vehicle
speed (after reset), average vehicle speed (after start), elapsed time (after reset),
elapsed time (after start), distance (driving range), distance (after start), blank.

: F SPORT models

■

Head-up Display

(



P.84)

: If equipped

■

Door lock (



P.96, 376)

Function

Default setting

Customized setting

Gauge information

Tachometer

Eco Driving Indicator



No content

Route guidance to destina-
tion

Off



Street name

Off



Driving support system dis-
play

Off



Compass

Off



Audio system operation sta-
tus

Off



Rotation

Horizontal posi-

tion

Rotating counterclock-

wise/clockwise



Function

Default setting

Customized setting

Unlocking using a mechani-
cal key

Driver’s door

unlocked in one

step, all doors

unlocked in two

step

All doors unlocked in

one step

 

Automatic door locking func-
tion

Shift position

linked door lock-

ing operation

Off



Speed linked door

locking operation

407

8-2. Customization

Vehi

cle

spec

ifi

tions

■

Smart access system with push-button start and wireless remote control
(



P.94, 112)

■

Smart access system with push-button start (



P.112)

Automatic door unlocking
function

Shift position

linked door

unlocking opera-

tion

Off



Driver’s door linked

door unlocking opera-

tion

Function

Default setting

Customized setting

Operating signal (Buzzers)

Off



1 to 7

Operation signal (Emer-
gency flashers)

Off



Time elapsed before auto-
matic door lock function is
activated if door is not
opened after being unlocked

60 seconds

Off



30 seconds

120 seconds

Open door warning buzzer

Off

 

Function

Default setting

Customized setting

Smart access system with
push-button start

Off

 

Smart door unlocking

Driver’s door

All the doors



Time elapsed before unlock-
ing all the door when gripping
and holding the driver’s door
handle

2 seconds

Off

 

1.5 seconds

2.5 seconds

Number of consecutive door
lock operations

2 times

As many as desired

 

Function

Default setting

Customized setting

408

8-2. Customization

■

Wireless remote control (



P.94)

: If equipped

■

Power back door

(



P.100)

: If equipped

Function

Default setting

Customized setting

Wireless remote control

Off

 

Unlocking operation

Driver’s door

unlocked in one

step, all doors

unlocked in two

step

All doors unlocked in

one step



Locking operation when door
opened

Off



Theft deterrent panic mode

Off

 

Reservation lock

Off



The function that activates the

switch of the wireless

remote control when locking
the door (



P.103)

On (Unlocking all

the door)

Off

 

On (Unlocking back

door only)

Function

Default setting

Customized setting

Power back door operation

Off



Power back door opening
position

1 to 4

 

Buzzer volume

Level 3

Level 1



Level 2

Operation buzzer

Off

 

Hands Free Power Back
Door (kick sensor)

Off



Hands Free Power Back
Door (kick sensor) when the
engine switch is off

Off

 

409

8-2. Customization

Vehi

cle

spec

ifi

tions

■

Driving position memory

(



P.119)

: If equipped

■

Outside rear view mirrors (



P.129)

: If equipped

■

Power windows and moon roof

(



P.132, 134)

: If equipped

■

Automatic light control system (



P.162)

Function

Default setting

Customized setting

Selecting doors linked to the
memory recall function

Driver’s door

All doors

 

Driver’s seat slide movement
when exiting the vehicle

Full

Off



Partial

Steering wheel movement

Tilt only

Off



Telescopic only

Tilt and telescopic

Function

Default setting

Customized setting

Automatic mirror folding and
extending operation

Linked to the

locking/unlock-

ing of the doors

Off

 

Linked to operation of

the engine switch

Function

Default setting

Customized setting

Mechanical key linked opera-
tion

Off

 

Wireless remote control
linked operation

Off

On (open only)

 

Wireless remote control
linked operation signal
(buzzer)

Off

 

Function

Default setting

Customized setting

Light sensor sensitivity

Standard

-2 to 2



410

8-2. Customization

■

Lights (



P.162)

: Except for Canada

: If equipped

■

Rear window wiper (



P.173)

■

PCS (Pre-Collision System) (



P.183)

Time elapsed before head-
lights automatically turn off
after doors are closed

30 seconds

Off



60 seconds

90 seconds

Windshield wiper linked
headlight illumination

Off

 

Function

Default setting

Customized setting

Daytime running lights

Off



Welcome lighting

Off

 

AFS (Adaptive Front-Light-
ing System)

Off

 

Function

Default setting

Customized setting

Rear window wiper operation
when the back door is
opened

Off

 

Washer linked rear window
wiper operation

Off

 

Shift position linked rear win-
dow wiper operation

Once

Off

 

Continuous

Function

Default setting

Customized setting

PCS (Pre-Collision System)

Off



Adjust alert timing

Middle

Early



Late

Function

Default setting

Customized setting

411

8-2. Customization

Vehi

cle

spec

ifi

tions

■

LTA (Lane Tracing Assist) (



P.190)

■

RSA (Road Sign Assist)

(



P.199)

: If equipped

■

BSM (Blind Spot Monitor)

(



P.211)

Function

Default setting

Customized setting

Lane centering function

Off



Steering assist function

Off



Alert type

Steering wheel

vibration

Buzzer



Alert sensitivity

High

Standard



Vehicle sway warning func-
tion

Off



Vehicle sway warning sensi-
tivity

Standard

High



Low

Function

Default setting

Customized setting

RSA (Road Sign Assist)

Off



Excess speed notification
method

Display only

No notification



Display and buzzer

Excess speed notification
level

1 mph (2 km/h)

3 mph (5 km/h)



5 mph (10 km/h)

Other notifications method
(No-entry notification)

Display only

No notification



Display and buzzer

Function

Default setting

Customized setting

BSM (Blind Spot Monitor)

Off



Outside rear view mirror
indicator brightness

Bright

Dim



Alert timing for presence of
approaching vehicle (sensi-
tivity)

Intermediate

Early



Late

Only when vehicle

detected in blind spot

412

8-2. Customization

: If equipped

■

PKSA (Parking Support Alert)

(



P.217)

: If equipped

■

Intuitive parking assist

(



P.218)

: If equipped

■

RCTA (Rear Cross Traffic Alert) function

(



P.226)

: If equipped

■

PKSB (Parking Support Brake)

(



P.231)

: If equipped

■

Automatic air conditioning system (



P.259)

Function

Default setting

Customized setting

Buzzer volume

Level 2

Level 1



Level 3

Function

Default setting

Customized setting

Intuitive parking assist

Off



Function

Default setting

Customized setting

RCTA (Rear Cross Traffic
Alert) function

Off



Buzzer volume

Level2

Level1



Level3

Function

Default setting

Customized setting

PKSB (Parking Support
Brake) function

Off



Function

Default setting

Customized setting

A/C auto switch operation

Off



413

8-2. Customization

Vehi

cle

spec

ifi

tions

■

Seat heaters

/seat ventilators

(



P.268)

: If equipped

■

Heated steering wheel

(



P.268)

: If equipped

■

Illumination (



P.271)

Function

Default setting

Customized setting

Driver’s seat temperature
preference in automatic
mode

Standard

-2 (cooler) to 2

(warmer)



Passenger’s seat tempera-
ture preference in automatic
mode

Standard

-2 (cooler) to 2

(warmer)



Function

Default setting

Customized setting

Steering wheel heating pref-
erence in automatic mode

Standard

-2 (low) to 2 (high)



Function

Default setting

Customized setting

Time elapsed before the inte-
rior lights turn off

15 seconds

Off



7.5 seconds

30 seconds

Operation after the engine
switch is turned off

Off

 

Operation when the doors
are unlocked

Off

 

Operation when you
approach the vehicle with the
electronic key on your person

Off

 

Outside door handle lights

Off

 

Time elapsed before the out-
side door handle lights

turn

off

15 seconds

Off



7.5 seconds

30 seconds

414

8-2. Customization

: If equipped

■

Vehicle customization

●

When the smart access system with

push-button start is off, the entry unlock

function cannot be customized.

●

When the doors remain closed after

unlocking the doors and the timer acti-

vated automatic door lock function acti-

vates, signals will be generated in

accordance with the operation buzzer

volume and operational signal (Emer-

gency flashers) function settings.

●

Some settings can be changed using a

switch or the Center Display. If a setting

is changed using a switch, the changed

setting will not be reflected on the Center

Display until the engine switch is turned

off and then to ON.

■

Clock settings screen

If the clock adjustment screen is displayed

continuously when attempting to change

the clock settings, the system may be mal-

functioning. Have the vehicle inspected by

your Lexus dealer.

Operation of the outside
door handle lights

when you

approach the vehicle with the
electronic key on your person

Off

 

Operation of the outside
door handle lights

when the

doors are unlocked

Off

 

Operation of the outside
door handle lights

when a

door is opened

Off

 

Rear interior light and foot-
well lights

Off

 

Fading out of the outside
door handle lights

when they

turn off

Long

Short

 

Function

Default setting

Customized setting

Lexus UX200 (2022 year). Manual in english - page 24
