330

4-6. Driving tips



Vehicles with front and rear tires of
differing sizes

Tire chains cannot be mounted.
Snow tires should be used instead.

Regulations regarding the use of tire
chains vary depending on location and
type of road. Always check local regu-
lations before installing chains.

■

Tire chain installation

Observe the following precautions when

installing and removing chains:

●

Install and remove tire chains in a safe

location.

●

Install tire chains on the rear tires. Do not

install tire chains on the front tires.

●

Install tire chains on the rear tires as

tightly as possible. Retighten chains after

driving 0.5



1.0 km (1/4



1/2 mile).

●

Install tire chains following the instruc-

tions provided with the tire chains.

To enable the windshield wipers to be
lifted when heavy snow or icy condi-
tions are expected, change the rest
position of the windshield wipers from
the retracted position below the hood
to the service position using the wiper

lever. (



P.198)

Regulations on the use of tire
chains

NOTICE

■

Fitting tire chains

The tire pressure warning valves and

transmitters may not function correctly

when tire chains are fitted.

Windshield wipers

331

rior f
ea

ture
s

Interior features

5-1. Remote Touch/Display

Remote Touch............................

332

Center Display...........................

334

Rear Multi Operation Panel

........................................................

336

5-2. Lexus Climate Concierge

Lexus Climate Concierge.....

339

5-3. Using the air conditioning system

and defogger

Front automatic air conditioning

system ..........................................

341

Rear automatic air conditioning

system ..........................................

351

Heated steering wheel/seat heat-

ers/seat ventilators................

354

5-4. Using the interior lights

Interior lights list.........................

358

5-5. Using the storage features

List of storage features ...........

362

Trunk features.............................

367

5-6. Using the other interior features

Other interior features ...........

370

332

5-1. Remote Touch/Display

5-1.Remote Touch/Display

■

Switches

“MAP” button

Vehicles with navigation function:
Press this button to display the vehicle’s
current position.
Vehicles without navigation function:
Press this button to display the global map
screen.

“MENU” button

Press this button to display the menu
screen.

Back button

Press this button to display the previous
screen.

Touchpad

Slide your finger on the touchpad and
move the pointer to select a function, letter
and screen button.

Press the touchpad to enter the selected
function, letter or screen button. Certain
finger movements on the touchpad can
perform functions, such as changing map
scalings and scrolling list screens.

Sub function button

When

is displayed on the screen, a

function screen assigned to the screen can
be displayed.

■

Using the touchpad

Select: Touch the touchpad to
select the desired button on the
screen.

Enter: Buttons on the screen can be
selected by either depressing or
double tapping the touchpad.
Once a button has been selected,
the screen will change.

■

Touch operation

Operations are performed by touching
the touchpad with your finger.



Trace

Trace the pad surface while maintaining
contact with the touchpad. Moving the
cursor and the pointer.

Remote Touch

The Remote Touch can be used to
operate the Center Display.

For details on the Remote touch,
refer to “NAVIGATION AND
MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

Remote Touch operation

333

5-1. Remote Touch/Display

rior f
ea

ture
s



Double tap

Tap the touchpad twice, quickly. Select the
button on the screen.



Flick

Quick and short movement along the
touchpad with you finger. Move the list
screen.



Pinch in/Pinch out

Slide fingers toward each other or apart on
the touchpad. Change the scale of the
map.

NOTICE

■

To prevent damage to the Remote

Touch

Observe the following precautions. Fail-

ure to do so may cause damage to the

Remote Touch.

●

Do not allow food, liquid, stickers or lit

cigarettes to contact the Remote

Touch.

●

Do not subject the Remote Touch to

excessive pressure or strong impact.

●

Do not push the touchpad with a

strong force or use a sharp pointed

object to operate the pad.

334

5-1. Remote Touch/Display

■

Menu screen

Press the “MENU” button on the
Remote Touch to display the menu
screen.

This system can also be operated by the
touch screen. For details, refer to “NAVI-
GATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

The displays shown in the illustrations
are used for example only and may dif-
fer from the actual vehicle.

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

: This function is not made available in

some models or areas.

■

Split-screen display

Different information can be displayed on the left and right sides of the screen. For

Center Display

Center Display overview

Switch

Function

Select to display the
“Destination” screen.

*1,

Select to display the
audio control screen.

Select to display the
hands-free control
screen.

Select to display the
“Apps” screen.

*1, 2

Select to display the
home screen of Apple
CarPlay.

*1, 2

Select to display the
Android Auto screen.

*1,

Select to display the
information screen.

(



P.93)

Select to display the
setup screen.

Select to display the air
conditioning control
screen. (



P.344)

Switch

Function

335

5-1. Remote Touch/Display

rior f
ea

ture
s

example, audio control screen can be displayed and operated while the fuel con-
sumption information screen is being displayed. The large screen on the left of the
display is called the main display, and the small screen to the right is called the side
display.

■

Main display

For details about the functions and
operation of the main display, refer to
the respective section and “NAVIGA-
TION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

■

Side display

The following functions can be dis-
played and operated on the side dis-
play.
Select

to display the desired

screen.

Navigation system

Audio

Vehicle information (



P.95)

Air conditioning system (



P.347)

Show/hide the side display

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

■

Screen display during low temperatures

When the ambient temperature is

extremely low, screen response may be

delayed even if the Remote Touch is oper-

ated.

A
B
C
D

336

5-1. Remote Touch/Display

: If equipped

■

Home screen

Touch to display the audio control
screen.

Refer to “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MANUAL”.

Touch to display the rear air condi-
tioning control screen. (



P.352,

356)
Touch to display the rear seat
adjustment screen. (



P.126, 135,

137)
Touch to display the relaxation seat

(if equipped) control screen.
(



P.129)

Touch to display the rear sun-
shade/rear interior light control
screen. (



P.359, 360, 374)

Touch to display the Rear Multi
Operation Panel settings screen.
(



P.336)

Touch to display/hide the shortcut
screen.
Shortcut screen

The following can be adjusted or operated:
• Rear air conditioning system tempera-

ture setting (



P.352)

• Rear seat heaters/rear seat ventilators

(



P.356)

• Audio system
Refer to “NAVIGATION AND MULTI-
MEDIA SYSTEM OWNER’S MANUAL”.
• Rear door sunshades/rear quarter sun-

shades/rear sunshade (



P.374)

button

Press to display the home screen.
When the screen is on, press and
hold to turn the screen off.

■

Rear Multi Operation Panel set-
tings screen

Screen operation settings and the
brightness of the screen can be
changed.

Rear Multi Operation Panel

The Rear Multi Operation Panel
built-into the rear armrest can be
used to operate the audio system,
air conditioning system, seat, relax-
ation seat, shades or lights.

Rear Multi Operation Panel
overview

337

5-1. Remote Touch/Display

rior f
ea

ture
s

Touch to turn the screen off.

Press the

buttun to display the

home screen.

Touch to adjust the brightness of
the screen.
Touch to display the automatic
screen transition settings screen.
Touch to lock the Rear Multi Oper-
ation Panel.

■

Auto screen change settings
screen

Touch to turn the automatic screen
transition function on/off.
Touch to set whether the screen will
transition to the home screen or
turn off when the automatic screen
transition function operates.
Touch to set the amount of time
(10/30/60/120 seconds) the Rear

Multi Operation Panel must be idle
before the automatic screen transi-
tion function operates.

When the screen is off, press the

button to turn the screen on and display
the previously displayed screen. Press
again to display the home screen.

■

Unlocking the Rear Multi Opera-
tion Panel

Touch and hold until the unlock sta-
tus indicators ( ) are completely illu-
minated to unlock the Rear Multi
Operation Panel.

■

Operating the Rear Multi Operation

Panel

●

When operating the Rear Multi Opera-

tion Panel, only use the tip of a finger. The

Rear Multi Operation Panel cannot be

operated with a fingernail, pen, etc.

●

Use only one finger when operating the

Rear Multi Operation Panel. The Rear

Multi Operation Panel cannot be oper-

ated with multiple fingers.

●

When the engine switch is changed to

ACCESSORY or IGNITION ON mode,

if a hand object, liquid or foreign matter is

touching the Rear Multi Operation Panel,

it may not operate correctly. In this case,

remove anything touching the Rear Multi

Operation Panel and wait for approxi-

mately 30 seconds before operating it

again.

338

5-1. Remote Touch/Display

If the Rear Multi Operation Panel still

cannot be operated normally, press and

hold the

button to turn the Rear

Multi Operation Panel off, and then press

the

button again to turn it back

on and operate it.

●

In the following situations, the Rear Multi

Operation Panel may not operate prop-

erly:

• If wearing gloves during operation, non

response may occur.

• If a wet hand is used to operate the Rear

Multi Operation Panel.

• If a screen cover or coating is applied to

on the Rear Multi Operation Panel.

• If the Rear Multi Operation Panel is dirty

or has liquid attached to it, incorrect

operation or non-response may occur.

• If the Rear Multi Operation Panel

receives electro magnetic waves, incor-

rect operation or non-response may

occur.

• If a mobile phone or other wireless com-

munication device brought near the Rear

Multi Operation Panel.

●

If the a metal object, such as the follow-

ing, is touching or covering the Rear

Multi Operation Panel:

• Coins

• Keys

• Metallic wallets or bags

• Magnetic isolation cards

• Metallic foil, such as the inner packaging

of a cigarette box

• Disposable heat packs

• Discs, such as a CD or DVD, Cables,

such as a USB cable

• Mobile devices, such as smartphones,

mobile phones, tablets, etc.

●

Make sure to keep the Rear Multi Oper-

ation Panel clean. If the Rear Multi Oper-

ation Panel is dirty, it may not operate

correctly. (When cleaning the Rear Multi

Operation Panel, turn the screen off to

avoid unexpected operation.)

NOTICE

■

To prevent damage to the Rear Multi

Operation Panel

Observe the following precautions. Fail-

ure to do so may cause damage to the

Rear Multi Operation Panel.

●

Keep the Rear Multi Operation Panel

free of liquids, such as drinks or rain, as

they may cause a short circuit.

●

Do not sit on or set heavy objects on

the Rear Multi Operation Panel.

●

Do not push the Rear Multi Operation

Panel with a strong force or use a

sharp pointed object to operate the

panel.

339

5-2. Lexus Climate Concierge

rior f
ea

ture
s

5-2.Lexus Climate Concierge

Select .

The indicator on the Lexus Climate Con-
cierge control screen illuminates, and the
automatic air conditioning system, seat
heaters and ventilators, and heated steer-
ing wheel operate in automatic mode.
If any of the system is operated manually,
the indicator turns off. However, all other
functions continue to operate in automatic
mode.

■

Changing Lexus Climate Con-
cierge control screen between
front/rear (vehicles with 4-ZONE
climate control)

Select “Rear” to display the rear air
conditioning system screen.

Select “Front” to display the front air condi-
tioning system screen.

■

When using the Lexus Climate Con-

cierge

Lexus Climate Concierge can be operated

on the sub function menu or option control

screen. (



P.344)

■

Automatic air conditioning system
(



P.341, 351)

The temperature can be adjusted inde-
pendently for each seat.

■

Seat heaters and ventilators (if
equipped) (



P.354)

Heating or ventilation is automatically
selected according to the set tempera-
ture of the air conditioning system, the
outside temperature, etc.

■

Heated steering wheel (if
equipped) (



P.354)

Heated steering wheel operates auto-

Lexus Climate Concierge

The seat heaters (if equipped), seat
ventilators (if equipped) and heated
steering wheel (if equipped) are
each automatically controlled
according to the set temperature of
the air conditioning system, the out-
side and cabin temperature, etc.
Lexus Climate Concierge allows a
comfortable condition to be main-
tained without adjusting each sys-
tem.

Press the “MENU” button on the
Remote Touch to display the main
menu and move the cursor to

to display the climate control short-
cut buttons. Then, select

to dis-

play the Lexus Climate Concierge
control screen.

Turning on Lexus Climate Con-
cierge

Operation of each system

340

5-2. Lexus Climate Concierge

matically according to the set tempera-
ture of the air conditioning system, the
outside temperature, etc.

■

Passenger detection functions

●

When a passenger is detected in the

front passenger seat, the seat heater and

ventilator will operate automatically.

●

When a passenger is detected in a rear

seat, the seat heater and ventilator will

operate automatically. (vehicles with

power rear seat)

■

Seat heater/ventilator operation

When automatic mode is selected using the

seat heater/ventilator switch, passenger

detection is not performed.

■

Rear seat heater operation (vehicles

with DUAL-ZONE climate control)

The rear seat heaters are not controlled by

the Lexus Climate Concierge.

341

5-3. Using the air conditioning system and defogger

rior f
ea

ture
s

5-3.Using the air conditioning system and defogger

Left-hand side temperature control switch
Automatic mode switch
Off switch
Fan speed decreases switch
Fan speed increases switch
Windshield defogger switch
Rear window defogger and outside rear view mirror defoggers switch
Outside/recirculated air mode switch
Right-hand side temperature control switch

■

Adjusting the temperature

Operate the temperature control
switch upwards to increase the tem-
perature and downwards to decrease
the temperature.

■

Setting the fan speed

Operate the

switch to increase the

fan speed and the

switch to

decrease the fan speed.

Front automatic air conditioning system

Air outlets and fan speed are automatically adjusted according to the temper-
ature setting.

Press the “MENU” button on the Remote Touch to display the main menu and
move the cursor to

to display the climate control shortcut buttons. Then,

select

to display the air conditioning control screen.

The air conditioning system can be displayed and operated on the side display.

Air conditioning controls

A
B
C
D

E
F

342

5-3. Using the air conditioning system and defogger

Press the off switch to turn the fan off.

■

Changing the air flow mode



P.344

■

Switching between outside air and
recirculated air modes

Press the outside/recirculated air
mode switch.

The mode changes as follows each time
the switch is pressed.

automatic mode



(outside air

mode)



(recirculated air mode)



automatic mode

When the system is switched to automatic
mode, the air conditioning system operates
automatically.

■

Defogging the windshield

Defoggers are used to defog the wind-
shield and front side windows.
Press the windshield defogger switch.

Set the outside/recirculated air mode
switch to outside air mode if the recircu-
lated air mode is used. (It may switch auto-
matically.)
To defog the windshield and the side win-
dows quickly, turn the air flow and temper-
ature up.
To return to the previous mode, press the
windshield defogger switch again when the
windshield is defogged.

■

Defogging the rear window and
outside rear view mirrors

Defoggers are used to defog the rear
window, and to remove raindrops, dew
and frost from the outside rear view
mirrors.
Press the rear window and outside rear

view mirror defoggers switch.

The defoggers will automatically turn off
after a while. The operation time changes
according to the ambient temperature and
vehicle speed.

■

Blower customization



P.347

■

Windshield wiper de-icer (if
equipped)



P.348

■

Fogging up of the windows

The windows will easily fog up when the

humidity in the vehicle is high. Turning “A/C”

on will dehumidify the air from the outlets

and defog the windshield effectively.

●

If you turn “A/C” off, the windows may fog

up more easily.

●

The windows may fog up if the recircu-

lated air mode is used.

■

When driving on dusty roads

Close all windows. If dust thrown up by the

vehicle is still drawn into the vehicle after

closing the windows, it is recommended

that the air intake mode be set to outside air

mode and the fan speed to any setting

except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode tem-

porarily is recommended in preventing

dirty air from entering the vehicle interior

and helping to cool the vehicle when the

outside air temperature is high.

●

Outside/recirculated air mode may auto-

matically switch depending on the tem-

perature setting or the inside

temperature.

■

Registering air conditioning settings to

electronic keys

●

Unlocking the vehicle using an electronic

key and turning the engine switch to

IGNITION ON mode will recall that

key’s registered air conditioning settings.

343

5-3. Using the air conditioning system and defogger

rior f
ea

ture
s

●

When the engine switch is turned off, the

current air conditioning settings will auto-

matically be registered to the electronic

key that was used to unlock the vehicle.

●

The system may not operate correctly if

more than one electronic key is in the

vicinity or if the smart entry & start system

is used to unlock a passenger door.

●

The doors that can recall the air condi-
tioning setting

when unlocked using the

smart entry & start system can be

changed. For details, contact any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

: The doors that can recall the driving

position memory are changed at the
same time.

■

Operation of the air conditioning sys-

tem in Eco drive mode

In Eco drive mode, the air conditioning sys-

tem is controlled as follows to prioritize fuel

efficiency:

●

Engine speed and compressor operation

controlled to restrict heating/cooling

capacity

●

Fan speed restricted when automatic

mode is selected

To improve air conditioning performance,

perform the following operations:

●

Adjust the fan speed

●

Turn off Eco drive mode (



P.316)

■

When the outside temperature falls to

nearly 0°C (32°F)

The dehumidification function may not

operate even when “A/C” is selected.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning

system to the outside air mode.

●

During use, various odors from inside and

outside the vehicle may enter into and

accumulate in the air conditioning sys-

tem. This may then cause odor to be

emitted from the vents.

●

To reduce potential odors from occur-

ring:

• It is recommended that the air condition-

ing system be set to outside air mode

prior to turning the vehicle off.

• The start timing of the blower may be

delayed for a short period of time imme-

diately after the air conditioning system is

started in automatic mode or pollen

removal mode.

●

When parking, the system automatically

switches to outside air mode to encour-

age better air circulation throughout the

vehicle, helping to reduce odors that

occur when starting the vehicle.

■

Air conditioning filter



P.417

■

Customization

Some functions can be customized.

(



P.476)

WARNING

■

To prevent the windshield from fog-

ging up

Do not use the windshield defogger

switch during cool air operation in

extremely humid weather. The difference

between the temperature of the outside

air and that of the windshield can cause

the outer surface of the windshield to fog

up, blocking your vision.

■

When the outside rear view mirror

defoggers are operating

Do not touch the outside rear view mir-

ror surfaces, as they can become very

hot and burn you.

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning system

on longer than necessary when the

engine is off.

344

5-3. Using the air conditioning system and defogger

■

Main control screen

Using the touchpad of the Remote
Touch, select the button on the screen.

This system can also be operated by the
touch screen.



Vehicles with DUAL-ZONE climate
control

Sub menu

Selecting the sub menu item to switch the
main screen.

: Display the air conditioning control

screen

: Display the heated steering

wheel/front seat heater/front seat ventila-
tor control screen (if equipped)

: Display the rear seat heater/rear seat

ventilator control screen (if equipped)

: Display the Lexus Climate Con-

cierge control screen

: Display the option control screen

Adjust the left side seat tempera-
ture setting
Adjust the fan speed setting
Select the air flow mode

: Air flows to the upper body

: Air flows to the upper body and feet

: Air flows to the feet

: Air flows to the feet and the wind-

shield defogger operates

Adjust the right side seat tempera-
ture setting
Switch the following functions on
and off

“A/C”: Set cooling and dehumidification
function
If the indicator is turned off, the system will
blow ambient temperature airor heated air.

: Select front seat concentrated

airflow mode (S-FLOW) (



P.349)

: Changing the fan speed setting

during the automatic mode operation
(Blower customization)

: Set Lexus Climate Concierge

(



P.339)

“DUAL”: Adjust the temperature for driver
and passenger seats separately (“DUAL”
mode) (



P.350)

Air conditioning control screen

C
D

345

5-3. Using the air conditioning system and defogger

rior f
ea

ture
s



Vehicles with 4-ZONE climate con-
trol

Sub menu

Selecting the sub menu item to switch the
main screen.

: Display the front air conditioning

control screen

: Display the heated steering

wheel/front seat heater/front seat ventila-
tor control screen

: Display the rear air conditioning con-

trol screen

: Display the rear seat heater/rear seat

ventilator control screen

: Display the Lexus Climate Con-

cierge control screen

: Display the option control screen

Adjust the left side seat tempera-
ture setting
Select the right side seat air flow
mode

: Air flows to the upper body

: Air flows to the upper body and feet

: Air flows to the feet

: Air flows to the feet and the wind-

shield defogger operates

Select the left side seat air flow
mode
Adjust the fan speed setting
Switch the following functions on
and off

“A/C”: Set cooling and dehumidification
function
If the indicator is turned off, the system will
blow ambient temperature airor heated air.

: Select front seat concentrated

airflow mode (S-FLOW) (



P.349)

: Changing the fan speed setting

during the automatic mode operation
(Blower customization)

: Set Lexus Climate Concierge

(



P.339)

“4-ZONE”: Adjust the temperature for the
driver, front passenger and left and right
rear passenger seats separately
(“4-ZONE” mode) (



P.350)

Adjust the right side seat tempera-
ture setting

■

Option control screen

Select

on the sub menu to display

the option control screen.

The functions can be switched on and off.
When the function is on, the indicator illu-
minates on the screen.

E
F

Content .. 18 19 20 21 ..
