403

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

vehicle, the towing eyelet must be
installed to your vehicle. Install the tow-
ing eyelet using the following proce-
dure.

Take out the wheel nut wrench and
towing eyelet. (



P.422, 432)

Remove the eyelet cover using a
flathead screwdriver.

To protect the bodywork, place a rag

between the screwdriver and the vehicle

body as shown in the illustration.

Insert the towing eyelet into the
hole and tighten partially by hand.

Tighten down the towing eyelet
securely using a wheel nut wrench
or hard metal bar.

Securely attach cables or chains to
the towing eyelet.

Take care not to damage the vehicle body.

Enter the vehicle being towed and
start the hybrid system.

If the hybrid system does not start, turn the

power switch to ON mode.

Shift the shift lever to N and release
the parking brake.

Turn automatic mode off. (



P.197)

When the shift lever cannot be shifted:



P.192

While towing

If the hybrid system is off, the power assist

for the brakes and steering will not function,

making steering and braking more difficult.

Wheel nut wrench

Wheel nut wrench is installed in trunk.

(



P.422, 432)

WARNING

Observe the following precautions. Fail-

ure to do so may result in death or seri-

ous injury.

404

7-2. Steps to take in an emergency



Fluid leaks under the vehicle.
(Water dripping from the air condi-
tioning after use is normal.)



Flat-looking tires or uneven tire
wear



Engine coolant temperature gauge
continually points higher than nor-
mal.



Changes in exhaust sound



Excessive tire squeal when corner-
ing



Strange noises related to the sus-
pension system



Pinging or other noises related to
the hybrid system



Engine missing, stumbling or run-
ning roughly



Appreciable loss of power

WARNING

While towing

When towing using cables or chains,

avoid sudden starts, etc. which place

excessive stress on the towing eyelets,

cables or chains. The towing eyelets,

cables or chains may become dam-

aged, broken debris may hit people,

and cause serious damage.

Do not turn the power switch off.

There is a possibility that the steering

wheel is locked and cannot be oper-

ated.

Installing towing eyelets to the vehi-

cle

Make sure that towing eyelets are

installed securely.

If not securely installed, towing eyelets

may come loose during towing.

NOTICE

To prevent damage to the vehicle

during emergency towing

Do not secure cables or chains to the

suspension components.

If you think something is
wrong

If you notice any of the following
symptoms, your vehicle probably
needs adjustment or repair. Con-
tact any authorized Lexus retailer
or Lexus authorized repairer, or
any reliable repairer as soon as pos-
sible.

Visible symptoms

Audible symptoms

Operational symptoms

405

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises



Vehicle pulls heavily to one side
when braking



Vehicle pulls heavily to one side
when driving on a level road



Loss of brake effectiveness, spongy
feeling, pedal almost touches the
floor

406

7-2. Steps to take in an emergency

Brake system warning light (warning buzzer)

High coolant temperature warning light

(warning buzzer)

: This light illuminates on the multi-information display.

If a warning light turns on or a warning buzzer sounds

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by any authorized Lexus retailer or Lexus autho-
rized repairer, or any reliable repairer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

(red)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning



Immediately stop the vehicle in a safe place and contact any autho-
rized Lexus retailer or Lexus authorized repairer, or any reliable
repairer. Continuing to drive the vehicle may be dangerous.

Warning light

Details/Actions

(yellow)

Indicates a malfunction in:



The regenerative braking system;



The electronically controlled brake system; or



The parking brake system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

Indicates that the engine coolant temperature is too high



Immediately stop the vehicle in a safe place.
Handling method (



P.448)

407

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

Charging system warning light

(warning buzzer)

: This light illuminates on the multi-information display.

Low engine oil pressure warning light

(warning buzzer)

: This light illuminates on the multi-information display.

Malfunction indicator lamp (warning buzzer)

SRS warning light (warning buzzer)

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and contact any autho-
rized Lexus retailer or Lexus authorized repairer, or any reliable
repairer.

Warning light

Details/Actions

Indicates that the engine oil pressure is too low



Immediately stop the vehicle in a safe place and contact any autho-
rized Lexus retailer or Lexus authorized repairer, or any reliable
repairer.

Warning light

Details/Actions

Indicates a malfunction in:



The emission control system (on some models);



The hybrid system;



The electronic engine control system; or



The electronic throttle control system



Immediately stop the vehicle in a safe place and contact any autho-
rized Lexus retailer or Lexus authorized repairer, or any reliable
repairer.

Warning light

Details/Actions

Indicates a malfunction in:



The SRS airbag system; or



The seat belt pretensioner system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

408

7-2. Steps to take in an emergency

Pop Up Hood warning light (warning buzzer)

ABS warning light (warning buzzer)

Inappropriate pedal operation warning light

(warning buzzer)

: This light illuminates on the multi-information display.

Warning light

Details/Actions

Indicates that the Pop Up Hood system has operated



The Pop Up Hood system cannot be reused once it has operated.
Have it replaced by any authorized Lexus retailer or Lexus autho-
rized repairer, or any reliable repairer.

Indicates a malfunction in the Pop Up Hood system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

Indicates a malfunction in:



The ABS; or



The brake assist system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

When a buzzer sounds:
Indicates a malfunction in:



The Brake Override System



The Drive-Start Control (DSC)



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.



Indicates that the shift position was changed and Drive-Start Control
was operated while depressing the accelerator pedal



Momentarily release the accelerator pedal.

When a buzzer does not sound:
Indicates that the accelerator and brake pedals are being depressed
simultaneously, and the Brake Override System is operating



Release the accelerator pedal and depress the brake pedal.

409

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

Electric power steering system warning light (warning buzzer)

Low fuel level warning light

Driver’s and front passenger’s seat belt reminder light (warning buzzer)

: Driver’s and front passenger’s seat belt warning buzzer:

The driver’s and front passenger’s seat belt warning buzzer sounds to alert the driver and
front passenger that his or her seat belt is not fastened. If the seat belt is unfastened, the
buzzer sounds intermittently for a certain period of time after the vehicle reaches a certain
speed.

Rear passengers’ seat belt reminder lights

(warning buzzer)

: This light illuminates on the multi-information display.

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear passenger that his

Warning light

Details/Actions

(red)

(yellow)

Indicates a malfunction in the EPS (Electric Power Steering) system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

Indicates that remaining fuel is approximately 7 L (1.8 gal., 1.5 Imp.gal.)
or less



Refuel the vehicle.

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front passenger’s seat
belt also needs to be fastened to make the warning light (warning
buzzer) turn off.

Warning light

Details/Actions

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

410

7-2. Steps to take in an emergency

or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds intermit-
tently for a certain period of time after the vehicle reaches a certain speed.

Tire pressure warning light

LTA indicator

(warning buzzer)

: This light illuminates on the multi-information display.

Lexus parking assist-sensor OFF indicator (warning buzzer)

Warning light

Details/Actions

When the light comes on after blinking for approximately 1 minute:
Malfunction in the tire pressure warning system



Have the system checked by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer.

When the light comes on:
Low tire inflation pressure such as



Natural causes



Flat tire



Immediately stop the vehicle in a safe place.
Handling method (



P.413)

Warning light

Details/Actions

(orange)

(if equipped)

Indicates a malfunction in the LTA (Lane Tracing Assist)



Follow the instructions displayed on the multi-information display.
(



P.243)

Warning light

Details/Actions

(flashes)

When a buzzer sounds:
Indicates a malfunction in the Lexus parking assist-sensor function



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

When a buzzer does not sound:
Indicates that the system is temporarily unavailable, possibly due to a
sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-information display.
(



P.273)

411

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

RCTA OFF indicator (warning buzzer)

RCD OFF indicator (warning buzzer)

PKSB OFF indicator (warning buzzer)

Warning light

Details/Actions

(flashes)

When a buzzer sounds:
Indicates a malfunction in the RCTA (Rear Crossing Traffic Alert) func-
tion



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

When a buzzer does not sound:
Indicates that the rear bumper around the radar sensor is covered with
dirt, etc. (



P.264)



Follow the instructions displayed on the multi-information display.
(



P.281)

Warning light

Details/Actions

(flashes)

(if equipped)

When a buzzer sounds:
Indicates a malfunction in the RCD (Rear Camera Detection) function



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

When a buzzer does not sound:
Indicates that the function temporarily cannot be used due to the cam-
era being dirty, etc.



Follow the instructions displayed on the multi-information display.
(



P.286)

Warning light

Details/Actions

(flashes)

When a buzzer sounds:
Indicates a malfunction in the PKSB (Parking Support Brake) system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

When a buzzer does not sound:
Indicates that the system is temporarily unavailable, possibly due to a
sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-information display.
(



P.293)

412

7-2. Steps to take in an emergency

PCS warning light (warning buzzer)

Slip indicator

Parking brake indicator

Brake hold operated indicator (warning buzzer)

Warning light

Details/Actions

(flashes or illumi-

nates)

(if equipped)

When a buzzer sounds simultaneously:
Indicates a malfunction has occurred in the PCS (Pre-Collision System)



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

When a buzzer does not sound:
The PCS (Pre-Collision System) has become temporarily unavailable,
corrective action may be necessary.



Follow the instructions displayed on the multi-information display.
(



P.222, 415)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability Control)
system is disabled, the PCS warning light will illuminate.



P.234

Warning light

Details/Actions

Indicates a malfunction in:



The VSC system;



The TRC system; or



The hill-start assist control system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

(flashes)

Indicates a malfunction in the parking brake system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

(flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

413

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

Hybrid system overheat warning light

(warning buzzer)

: This light illuminates on the multi-information display.

Front door open warning light

: This light illuminates on the Digital Side-view Monitor display.

Master warning light (warning buzzer)

Warning buzzer

In some cases, the buzzer may not be heard

due to being in a noisy location or audio

sound.

Front passenger detection sensor, seat

belt reminder and warning buzzer

If luggage is placed on the front passen-

ger seat, the front passenger detection

sensor may cause the warning light to

flash and the warning buzzer to sound

even if a passenger is not sitting in the

seat.

If a cushion is placed on the seat, the sen-

sor may not detect a passenger, and the

warning light may not operate properly.

Electric power steering system warning

light (warning buzzer)

When the 12-volt battery charge becomes

insufficient or the voltage temporarily

drops, the electric power steering system

warning light may come on and the warning

buzzer may sound.

When the tire pressure warning light

comes on

Inspect the tires to check if a tire is punc-

tured.
If a tire is punctured:



P.420, 432

If none of the tires are punctured:

Turn the power switch off then turn it to ON

mode. Check if the tire pressure warning

light comes on or blinks.

Warning light

Details/Actions

Indicates the hybrid system has overheated
This light may be displayed when driving under severe operating condi-
tions. (For example, when driving up a long steep hill.)



Stop the vehicle in a safe place.
Handling method (



P.448)

Warning light

Details/Actions

(if equipped)

Front door is not fully closed
If the front doors are even slightly open, Digital Side-view Monitor
images may not be displayed properly.



Close the front door.

Warning light

Details/Actions

A buzzer sounds and the warning light comes on and flashes to indicate
that the master warning system has detected a malfunction.



P.415

414

7-2. Steps to take in an emergency



If the tire pressure warning light blinks for

approximately 1 minute then stays on

There may be a malfunction in the tire pres-

sure warning system. Have the vehicle

inspected by any authorized Lexus retailer

or Lexus authorized repairer, or any reli-

able repairer immediately.



If the tire pressure warning light comes

After the temperature of the tires has

lowered sufficiently, check the inflation

pressure of each tire and adjust them to

the specified level.

If the warning light does not turn off

even after several minutes have

elapsed, check that the inflation pres-

sure of each tire is at the specified level

and perform initialization. (



P.377)

The tire pressure warning light may

come on due to natural causes

The tire pressure warning light may come

on due to natural causes such as natural air

leaks and tire inflation pressure changes

caused by temperature. In this case, adjust-

ing the tire inflation pressure will turn off the

warning light (after a few minutes).

When a tire is replaced with a spare tire

(vehicles with compact spare tire)

The compact spare tire is not equipped with

a tire pressure warning valve and transmit-

ter. If a tire goes flat, the tire pressure warn-

ing light will not turn off even though the flat

tire has been replaced with the spare tire.

Replace the spare tire with the repaired tire

and adjust the tire inflation pressure. The

tire pressure warning light will go off after a

few minutes.

Conditions that the tire pressure warn-

ing system may not function properly



P.376

WARNING

If both the ABS and the brake system

warning lights remain on

Stop your vehicle in a safe place immedi-

ately and contact any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

The vehicle will become extremely

unstable during braking, and the ABS

system may fail, which could cause an

accident resulting in death or serious

injury.

When the electric power steering

system warning light comes on

When the light comes on yellow, the

assist to the power steering is restricted.

When the light comes on red, the assist

to the power steering is lost and handling

operations of the steering wheel become

extremely heavy.

When steering wheel operations are

heavier than usual, grip the steering

wheel firmly and operate it using more

force than usual.

If the tire pressure warning light

comes on

Be sure to observe the following precau-

tions.

Failure to do so could cause a loss of

vehicle control and result in death or

serious injury.

Stop your vehicle in a safe place as

soon as possible. Check and adjust the

tire inflation pressure immediately.

If the tire pressure warning light comes

on even after tire inflation pressure

adjustment, it is probable that you have

a flat tire. Check the tires. If a tire is flat,

change it with the spare tire and have

the flat tire repaired by the nearest any

authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer.

415

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

WARNING

Avoid abrupt maneuvering and brak-

ing.

If the vehicle tires deteriorate, you

could lose control of the steering

wheel or the brakes.

If a blowout or sudden air leakage

should occur

The tire pressure warning system may

not activate immediately.

NOTICE

To ensure the tire pressure warning

system operates properly

Do not install tires with different specifi-

cations or makers, as the tire pressure

warning system may not operate prop-

erly.

If a warning message is dis-
played

The multi-information display
shows warnings of system malfunc-
tions, incorrectly performed opera-
tions, and messages that indicate a
need for maintenance. When a
message is shown, perform the cor-
rection procedure appropriate to
the message.

Except F SPORT models:

Master warning light

The master warning light also comes on
or flashes in order to indicate that a mes-
sage is currently being displayed on the
multi-information display.

Multi-information display

Follow the instructions of the message
on the multi-information display.
If any of the warning messages are
shown again after the appropriate
actions have been performed, contact
any authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

416

7-2. Steps to take in an emergency

F SPORT models (main meter in
center position):

Master warning light

The master warning light also comes on
or flashes in order to indicate that a mes-
sage is currently being displayed on the
multi-information display.

Multi-information display

F SPORT models (main meter
moved to the right):

Master warning light

The master warning light also comes on
or flashes in order to indicate that a mes-
sage is currently being displayed on the
multi-information display.

Multi-information display

417

7-2. Steps to take in an emergency

Wh
en

troubl
e ar
ises

The master warning light and warning buzzers operate as follows depending on
the content of the message. If a message indicates the need for inspection by a
dealer, have the vehicle inspected by any authorized Lexus retailer or Lexus
authorized repairer, or any reliable repairer immediately.

: A buzzer sounds the first time a message is shown on the multi-information display.



In some situations, the master warning light and warning buzzer may not oper-
ate as specified. In this case, follow the instructions displayed in the warning
message.



If a warning light comes on or flashes at the same time that a warning message is
displayed, take corrective action according to the warning light. (



P.406)

Warning messages

The warning messages explained below

may differ from the actual messages

according to operation conditions and vehi-

cle specifications.

Warning buzzer

In some cases, the buzzer may not be heard

due to being in a noisy location or audio

sound.

If “Engine Oil Level Low Add or

Replace” is displayed

The engine oil level is low. Check the level

of the engine oil, and add if necessary.
This message may appear if the vehicle is

stopped on a slope. Move the vehicle to a

level surface and check to see if the mes-

sage disappears.

If “Hybrid System Stopped Steering

Power Low” is displayed

This message is displayed if the hybrid sys-

tem is stopped while driving.

Messages and warnings

Warning buzzer

Warning

Comes on

Sounds

Indicates an important situation, such as when a sys-
tem related to driving is malfunctioning or that dan-
ger may result if the correction procedure is not
performed

Flashes

Sounds

Indicates a situation, such as when damage to the
vehicle or danger may result

Comes on

Does not sound

Indicates a condition, such as malfunction of electri-
cal components, their condition, or indicates the
need for maintenance

Flashes

Does not sound

Indicates a situation, such as when an operation has
been performed incorrectly, or indicates how to
perform an operation correctly

418

7-2. Steps to take in an emergency

When steering wheel operations are

heavier than usual, grip the steering wheel

firmly and operate it using more force than

usual.

If “Hybrid System Overheated

Reduced Output Power” is displayed

This message may be displayed when driv-

ing under severe operating conditions. (For

example, when driving up a long steep hill.)

Handling method:



P.448

If “Traction Battery Needs to be Pro-

tected Refrain From the Use of N Posi-

tion” is displayed

This message may be displayed when the

shift lever is in N.
As the hybrid battery (traction battery) can

not be charged when the shift lever is in N,

shift the shift lever to P when the vehicle is

stopped.

If “Traction Battery Needs to be Pro-

tected Shift into P to Restart” is dis-

played

This message is displayed when the hybrid

battery (traction battery) charge has

become extremely low because the shift

lever has been left in N for a certain amount

of time.
When operating the vehicle, shift to P and

restart the hybrid system.

If “Shift to P Before Exiting Vehicle” is

displayed

Message is displayed when the driver’s

door is opened without turning the power

switch off with the shift lever in any position

other than P.
Shift the shift lever to P.

If “Shift is in N Release accelerator

before shifting” is displayed

The accelerator pedal has been depressed

when the shift lever is in N.
Release the accelerator pedal and shift the

shift lever to D or R.

If “Accelerator pedal is pressed” is dis-

played

The accelerator pedal has been depressed

when the shift lever is in P.

Release the accelerator pedal.

If “Press brake when vehicle is stopped

Hybrid system may overheat” is dis-

played

The message may be displayed when the

accelerator pedal is depressed to hold the

vehicle while the vehicle is stopped on an

incline, etc. The hybrid system may over-

heat. Release the accelerator pedal and

depress the brake pedal.

If “Auto Power Off To Conserve Bat-

tery” is displayed

Power was turned off due to the automatic

power off function. Next time when starting

the hybrid system, operate the hybrid sys-

tem for approximately 5 minutes to

recharge the 12-volt battery.

If “High Power Consumption Power to

Climate Temporarily Limited” is dis-

played

Turn off unnecessary electronic equipment

to reduce power consumption.
Please wait until the power supply returns

to normal.

If “Headlight System Malfunction Visit

Your Dealer” is displayed

The following systems may be malfunction-

ing. Have the vehicle inspected by any

authorized Lexus retailer or Lexus autho-

rized repairer, or any reliable repairer

immediately.

The LED headlight system

The automatic headlight leveling system

AHS (Adaptive High-beam System) (if

equipped)

AHB (Automatic High Beam) (if

equipped)

Multi Weather Lights (if equipped)

If “Radar Cruise Control Temporarily

Unavailable See Owner’s Manual” is

shown

The dynamic radar cruise control with full-

speed range system is suspended tempo-

rarily or until the problem shown in the mes-

sage is resolved. (causes and coping

methods:



P.222)

Content .. 22 23 24 25 ..
