147

3-3. Adjusting the seats

Before drivi

: If equipped

The seat and steering wheel are auto-
matically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the seat and steering wheel
are automatically adjusted to a position
that allows the driver to enter and exit
the vehicle easily.



The shift lever has been shifted to P.



The power switch has been turned
off.



The driver’s seat belt has been
unfastened.

When any of the following has been
performed, the driver’s seat and steer-
ing wheel automatically return to their
original positions.



The power switch has been turned
to ACCESSORY mode or ON
mode.



The driver’s seat belt has been fas-
tened.

Operation of the power easy access

system

When exiting the vehicle, the power easy

access system may not operate if the seat

is already in the rearmost or uppermost

position or close to the rear seat.

If the seat position is adjusted during

power easy access system operation, the

automatic operation will stop. (The seat

will change to manual operation.)

If the seat position is adjusted during or

after the power easy access system oper-

ation when the driver is exiting the vehi-

cle, the power easy access system will not

operate when entering the vehicle.

Customization

The seat movement amount settings of the

power easy access system can be custom-

ized. (Customizable features:



P.463)

Driving position memory

This feature automatically adjusts
the positions of the driver’s seat,
steering wheel, outside rear view
mirrors (if equipped), the Digital
Side-view Monitor display range (if
equipped) and head-up display (if
equipped) to make entering and
exiting the vehicle easier or to suit
your preferences.
Up to 3 different driving positions
can be recorded.
Each electronic key (including a
card key) can be registered to
recall your preferred driving posi-
tion.

Power easy access system

148

3-3. Adjusting the seats

Check that the shift lever is in P.

Turn the power switch to ON
mode.

Adjust the driver’s seat, steering
wheel, outside rear view mirrors (if
equipped) and head-up display to
the desired positions, and the Digi-
tal Side-view Monitor (if equipped)
to the desired display range.

While pressing the “SET” button, or
within 3 seconds after the “SET”
button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.

If the selected button has already been

preset, the previously recorded position

will be overwritten.

Vehicles with position memory for the
front passenger’s seat: To record the
position of the front passenger’s seat,
adjust the front passenger’s seat to the
desired position and perform step

using the buttons on the front passen-
ger’s side.

Seat positions that can be memorized

(



P.145)

The positions adjusted by the following pro-

cedure can be recorded:

Seat position adjustment

Seatback adjustment

Seat cushion (front) angle adjustment

Vertical height adjustment

In order to correctly use the driving

position memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

may be slightly different when it is recalled.

Check that the shift lever is in P.

Turn the power switch to ON
mode.

Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

To stop the position recall operation

part-way through

Perform any of the following:

Press the “SET” button.

Recording a driving position into
memory

WARNING

Seat adjustment caution

Take care during seat adjustment so that

the seat does not strike the rear passen-

ger or squeeze your body against the

steering wheel.

Recalling a driving position

149

3-3. Adjusting the seats

Before drivi

Press button “1”, “2” or “3”.

Operate any of the seat adjustment

switches (only cancels seat position

recall).

Operate the tilt and telescopic steering

control switch (only cancels steering

wheel position recall).

Vehicles with the head-up display: Oper-

ate the meter control switches to adjust

the head-up display position (only can-

cels head-up display position recall).

Operating the driving position memory

after turning the power switch off

Driver’s seat:

Recorded seat positions can be activated

up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is

closed again.
Front passenger’s seat (if equipped):

Recorded seat positions can be activated

up to 180 seconds after the front passen-

ger’s door is opened.

When the recorded seat position can-

not be recalled

The seat position may not be recalled in

some situations when the seat position is

recorded in a certain range. For details,

contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

Registering procedure

Record your driving position to button
“1”, “2” or “3” before performing the
following:
Carry only the key you want to regis-
ter, and then close the driver’s door.
If 2 or more keys are in the vehicle, the

driving position cannot be recorded
properly.

Check that the shift lever is in P.

Turn the power switch to ON
mode.

Recall the driving position that you
want to record.

While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds.

If the button could not be registered, the

buzzer sounds continuously for approxi-

mately 3 seconds.

Cancelation procedure

Carry only the key you want to can-
cel and then close the driver’s door.

If 2 or more keys are in the vehicle, the

driving position cannot be canceled prop-

erly.

Check that the shift lever is in P.

Turn the power switch to ON
mode.

While pressing the “SET” button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds twice.

If the button could not be canceled, the

buzzer sounds continuously for approxi-

Registering/canceling/recall-
ing a driving position to an elec-
tronic key (including a card key)
(memory recall function)

150

3-3. Adjusting the seats

mately 3 seconds.

Recall procedure

Make sure that the doors are
locked before recalling the driving
position. Carry the electronic key
that has been registered to the driv-
ing position, and then unlock and
open the driver’s door using the
smart entry & start system or wire-
less remote control.

The driving position will move to the

recorded position (not including the steer-

ing wheel and head-up display). However,

the seat will move to a position slightly

behind the recorded position in order to

make entering the vehicle easier.
If the driving position is in a position that

has already been recorded, the seat and

outside rear view mirrors will not move.

Turn the power switch to ACCES-
SORY mode or ON mode, or fas-
ten a seat belt.

The seat, steering wheel and head-up dis-

play will move to the recorded position.

Recalling the driving position using the

memory recall function

Different driving positions can be regis-

tered for each electronic key. Therefore,

the driving position that is recalled may

be different depending on the key being

carried.

If a door other than the driver’s door is

unlocked with the smart entry & start sys-

tem, the driving position cannot be

recalled. In this case, press the driving

position button which has been set.

Customization

The unlock door settings of the memory

recall function can be changed.

(Customizable features:



P.463)

Pull the head restraints up.

Down

Push the head restraint down while press-
ing the lock release button

Head restraints

Head restraints are provided for all
seats.

WARNING

Head restraint precautions

Observe the following precautions

regarding the head restraints. Failure to

do so may result in death or serious

injury.

Use the head restraints designed for

each respective seat.

Adjust the head restraints to the cor-

rect position at all times.

After adjusting the head restraints,

push down on them and make sure

they are locked in position.

Do not drive with the head restraints

removed.

Vertical adjustment

151

3-3. Adjusting the seats

Before drivi

Adjusting the height of the head

restraints (front seats)

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

Adjusting the outboard rear seat head

restraint (except reclining type)

Always raise the head restraint one level

from the stowed position when using.

The position of the head restraint can
be adjusted forward in 4 stages.

If the head restraint is pulled forward from
the foremost position, it will return to the
rearmost position.

Pull the head restraint up while press-
ing the lock release button

Front seats: If the head restraint

touches the ceiling, making the
removal difficult, change the seat
height or angle. (



P.145)

Align the head restraint with the instal-
lation holes and push it down to the
lock position.
Press and hold the lock release button

when lowering the head restraint.

Horizontal adjustment (if
equipped)

Removing the head restraints

Installing the head restraints

152

3-4. Adjusting the steering wheel and mirrors

3-4.Adjusting the steering wheel and mirrors

Operating the switch moves the steer-
ing wheel in the following directions:

Down

Toward the driver

Away from the driver

The steering wheel can be adjusted

when

The power switch is in ACCESSORY or

ON mode.

Automatic adjustment of the steering

position (vehicles with the driving posi-

tion memory)

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

(



P.147)

Power easy access system



Vehicles with the driving position mem-

ory

The steering wheel and driver’s seat move

in accordance with power switch mode and

the driver’s seat belt condition. (



P.147)



Vehicles without the driving position

memory

The steering wheel moves in accordance

with power switch mode.
When all of the following have been per-

formed, the steering wheel is automatically

adjusted to a position that allows the driver

to enter and exit the vehicle easily.

• The shift lever has been shifted to P.

• The power switch has been turned off.

When the power switch has been turned to

ACCESSORY or ON mode, the steering

wheel automatically returns to the original

position.

Customization

The steering wheel movement can be

changed. (Customizable features:



P.463)

Press on or close to the

mark.

Steering wheel

Adjustment procedure

WARNING

Caution while driving

Do not adjust the steering wheel while

driving.

Doing so may cause the driver to mis-

handle the vehicle and cause an acci-

dent, resulting in death or serious injury.

Sounding the horn

153

3-4. Adjusting the steering wheel and mirrors

Before drivi

The height of the rear view mirror can
be adjusted to suit your driving pos-
ture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness
of the headlights of vehicles behind, the
reflected light is automatically
reduced.
Turn the automatic anti-glare function

Inside rear view mirror

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

Adjusting the height of rear view
mirror

WARNING

Caution while driving

Do not adjust the position of the mirror

while driving.

Doing so may lead to mishandling of the

vehicle and cause an accident, resulting

in death or serious injury.

Anti-glare function

154

3-4. Adjusting the steering wheel and mirrors

mode on/off

When the automatic anti-glare function is
in ON mode, the indicator

illuminates.

The function will set to ON mode each
time the power switch is turned to ON
mode.
Pressing the button turns the function to
OFF mode. (The indicator

also turns

off.)

To prevent sensor error

To ensure that the sensors operate prop-

erly, do not touch or cover them.

: If equipped

To select a mirror to adjust, press
the switch.

Left

Right

Outside rear view mirrors

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

WARNING

Important points while driving

Observe the following precautions while

driving.

Failure to do so may result in loss of con-

trol of the vehicle and cause an accident,

resulting in death or serious injury.

Do not adjust the mirrors while driving.

Do not drive with the mirrors folded.

Both the driver and passenger side

mirrors must be extended and prop-

erly adjusted before driving.

Adjustment procedure

A
B

155

3-4. Adjusting the steering wheel and mirrors

Before drivi

To adjust the mirror, press the
switch.

Right

Down

Left

Mirror angle can be adjusted when

The power switch is in ACCESSORY or

ON mode.

Defogging the mirrors

The outside rear view mirrors can be

cleared using the mirror defoggers. Turn on

the rear window defogger to turn on the

outside rear view mirror defoggers.

(



P.322)

Auto anti-glare function

When the anti-glare inside rear view mirror

is set to automatic mode, the driver’s side

outside rear view mirror will activate in con-

junction with the anti-glare inside rear view

mirror to reduce reflected light. (



P.153)

Automatic adjustment of the mirror

angle (vehicles with driving position

memory)

A desired mirror face angle can be entered

to memory and recalled automatically by

the driving position memory. (



P.147)

Folds the mirrors

Extends the mirrors

Vehicles with automatic folding/extending
mirror function:
Putting the outside rear view mirror folding
switch in the neutral position sets the mir-
rors to automatic mode.
Automatic mode allows the folding or
extending of the mirrors to be linked to
locking/unlocking of the doors.

Using automatic mode in cold weather

(vehicles with automatic fold-

ing/extending mirror function)

When automatic mode is used in cold

weather, the door mirror could freeze up

and automatic stowing and return may not

be possible. In this case, remove any ice and

snow from the door mirror, then either

operate the mirror using manual mode or

move the mirror by hand.

A
B
C
D

WARNING

When the outside rear view mirror

defoggers are operating

Do not touch the outside rear view mir-

ror surfaces, as they can become very

hot and burn you.

Folding and extending the mir-
rors

156

3-4. Adjusting the steering wheel and mirrors

Customization (vehicles with automatic

folding/extending mirror function)

The automatic mirror folding and extending

operation can be changed.

(Customizable features:



P.463)

When the mirror select switch is in the
“L” or “R” position, the outside rear
view mirrors will automatically angle
downwards when the vehicle is revers-
ing in order to give a better view of the
ground.
To disable this function, move the mir-
ror select switch to the neutral position
(between “L” or “R”).

Adjusting the mirror angle when
the vehicle is reversing

With the shift lever in R, adjust the mir-
ror angle at a desired position.
The adjusted angle will be memorized
and the mirror will automatically tilt to
the memorized angle whenever the
shift lever is shifted to R from next time.

The memorized downward tilt position of
the mirror is linked to the normal position
(angle adjusted with the shift lever in other
than R). Therefore, if the normal position is
changed after adjustment, the tilt position
will also change.

When the normal position is changed,
readjust the angle in reversing.

WARNING

When a mirror is moving

To avoid personal injury and mirror mal-

function, be careful not to get your hand

caught by the moving mirror.

Linked mirror function when
reversing (vehicles with driving
position memory)

157

3-4. Adjusting the steering wheel and mirrors

Before drivi

: If equipped

Cameras

Displays

Camera indicators

Indicate that the cameras are operating
normally.

Icon display areas

Displays adjustment menu icons, etc.

Digital Side-view Monitor

The Digital Side-view Monitor is a
system that uses the cameras on
the sides of the vehicle and displays
their images on the display of the
Digital Side-view Monitor.

WARNING

Before using the Digital Side-view

Monitor

Observe the following precautions. Fail-

ure to do so may result in death or seri-

ous injury.

Make sure to adjust the display range

of the image before driving. (



P.158)

If it is not adjusted, the area behind the

vehicle may not be displayed properly.

When wide range image mode is

being used (either reverse-linked wide

range image mode, front door open-

linked wide range image mode, turn

signal-linked wide range image mode

or manual wide range image mode),

the sizes of images shown in the dis-

play (people, objects, vehicles, etc.)

will differ from their sizes when dis-

played normally.

Check the difference in advance.

Make sure that the front doors are

closed. If the front doors are even

slightly open, Digital Side-view Moni-

tor images may not be displayed prop-

erly.

Check that the cameras are not

retracted or tilted forward. If the cam-

eras are retracted or tilted forward,

the Digital Side-view Monitor image

may not be displayed properly.

When parking in extremely hot tem-

peratures, the metal part of the display

may become hot, and touching it may

result in burns.

System components

158

3-4. Adjusting the steering wheel and mirrors

Switches

Displays the screens and the
adjustment menu.

Retracts the cameras or returns
them to their original positions.
(



P.162)

Selects the adjustment menu items
and adjusts the image. (



P.158)

Selects the screen on the right side.

Selects the screen on the left side.

Operation conditions

When any of the following conditions is

met, the display is shown or turned off.



Image is shown

• The power switch is in ON mode.

• ON/MENU switch pressed

• The front door is open



Image is turned off

• Approximately 2 minutes have elapsed

since the power switch is turned off

• The doors are locked from the outside

: The image will disappear after the cam-

era indicators flash for approximately 10
seconds.

Digital Side-view Monitor

If the display is difficult to see due to

reflected light, adjust the brightness of

the display. (



P.159)

Any of the following conditions may

occur, however, none of these indicates

that a malfunction has occurred.

• Lights from vehicles behind may appear

to flicker.

• Colors of objects in the displayed image

may differ from their actual color.

• The areas around headlights of vehicles

behind may appear white and blurry at

night.

• Flickering may occur when driving in the

dark, such as at night.

The display of the Digital Side-view Mon-

itor may become hot, however, this is not

a malfunction.

Depending on your physical condition or

age, it may take longer than usual to

focus on the display. In this case, stop the

vehicle in a safe place and adjust the

brightness of the display etc. (



P.159)

Avoid driving until you can focus on the

display.

Do not let passengers stare at the dis-

played image when the vehicle is being

driven, as doing so may cause motion

sickness.

Adjusting the display range

The display range of the Digital Side-
view Monitor display can be adjusted.



Adjusting the display range when
the shift lever is in other than R

To select the display to adjust, press
the switch.

Adjusting the Digital Side-view
Monitor display

159

3-4. Adjusting the steering wheel and mirrors

Before drivi

Left

Right

When the switch is pressed, the indicator

will turn on. Press the switch again to can-

cel the selection.

Press the switches to adjust the dis-
play range of the Digital Side-view
Monitor display.

Right

Down

Left



Adjusting the display range when
the shift lever is in R

Perform the following while firmly
depressing the brake pedal.

Shift the shift lever to R. (



P.192)

To select the display to adjust, press
the switch.

Left

Right

When the switch is pressed, the indicator

will turn on. Press the switch again to can-

cel the selection.

Press the switches to adjust the dis-
play range of the Digital Side-view
Monitor display.

Down

Operating the adjustment menu



Adjustment of other than the angle
of the image

Press the switch to display the
adjustment menu.

A
B

A
B
C
D

A
B

160

3-4. Adjusting the steering wheel and mirrors

Press the switches to display the
menu item to adjust.

Press the switches to change the
adjustment menu setting.



Adjustment of the angle of the

Press and hold the switch to display
the adjustment menu.

To select the display to adjust, press
the switch.

Left

Right

When the switch is pressed, the indicator
will turn on. Press the switch again to can-
cel the selection.

Press the switches to adjust the
angle of the image.

A
B

161

3-4. Adjusting the steering wheel and mirrors

Before drivi

Adjustment menu icons

When adjusting the Digital Side-view

Monitor display

Stop the vehicle in a safe place before

adjusting.

Adjusting the Digital Side-view Moni-

tor display

In the following situations, the icon turns

off.

• When the ON/MENU switch is pressed

• When the power switch is turned off

• When the driver side door is opened

• When the switches are not operated for a

certain period of time

• When the shift lever shifted to R

(When

the shift lever shifted to R, the system

switches to reverse-linked wide range

image mode.)

: When reverse-linked wide range image

mode is turned on

When the following operations are per-

formed, the system will switch to wide

range image mode.

• The shift lever is shifted to R (only when

the adjustment icon

is on)

When the shift lever is shifted out of R,

wide range image mode is canceled.

•

and

are not selected and

any direction on

is pressed.

When the vehicle is driven for a certain

amount at or above a certain speed, wide

range image mode is canceled.

Also, if

is pressed

again, wide range image mode is can-

celed.

• The turn signal lever is operated (only

when adjustment icon

is on)

When a few seconds have been elapsed

after the turn signal lever is returned to its

original position, wide range image mode

is canceled.

If the displayed image is adjusted to the

limit, it may appear distorted. This is not a

malfunction.

If the brightness of the display is set too

high, it may cause eye strain. Adjust the

display to an appropriate brightness.

The brightness of the display will change

automatically according to the brightness

of the surrounding area.

To prevent sensors from operating

improperly

Do not place anything over the sensors or

attach anything to the windshield that

blocks the sensors. If external light is

Icons

Settings

Select to adjust the brightness
of the display.

Select to enable/disable the
function that automatically
retracts and extends the cam-
eras linked with the door lock
and unlock operations of the
smart entry & start system and
wireless remote control.
(



P.162)

Select to enable/disable the
function that expands the dis-
play range when the shift lever
shifted to R. (



P.162)

Select to enable/disable the
function that expands the dis-
play range when the turn signal
lever is operated. (



P.165)

Select to enable/disable the
function that displays the dis-
tance guideline when moving
forward.

Select to adjust the angle of the
image shown on the display.

162

3-4. Adjusting the steering wheel and mirrors

obstructed, the function that automatically

adjusts the brightness of the image will not

operate normally.

Retracting/extending manually

Press the button.

Press the button again to return the cam-
eras to their original positions.

Retracting/extending automati-
cally

The cameras can be automatically
retracted and extended linked with the
door lock and unlock operations of the
smart entry & start system and wireless
remote control.

Turn the

adjustment menu icon

on. (



P.159)

This provides an expanded display
range and displays distance guidelines
on the display when backing up. When
not using this function, turn the

adjustment menu icon off. (



P.159)

During operation,

and

are

shown on the display.

Adjusting the range displayed
when backing up

(



P.158)

Distance guidelines

These lines are shown on the display

WARNING

Important points while driving

Observe the following precautions. Fail-

ure to do so may result in death or seri-

ous injury.

Do not adjust the display range of the

Digital Side-view Monitor or operate

the adjustment menu while driving.

Stop the vehicle in a safe place before

operating the Digital Side-view Moni-

tor control switches. Operating the

Digital Side-view Monitor control

switches may cause a steering wheel

operation error, resulting in an acci-

dent.

Always pay attention to the vehicle’s

surroundings.

• The distance to nearby people and

objects shown in the display may differ

from the actual distance such as when

backing up.

• The vehicle’s surroundings may

appear dark in multistory parking lots

or other areas with mixed bright and

dark areas, or when headlights from

vehicles to the rear are shown in the

display at night.

Retracting the cameras

Reverse-linked wide range
image mode

Content .. 6 7 8 9 ..
