285

Interio

r fe

atures

Interior features

5-1. Remote Touch

Remote Touch............................

286

5-2. Using the air conditioning system

and defogger

Automatic air conditioning system

.........................................................

291

Heated steering wheel/seat heat-

ers/seat ventilators................

299

5-3. Using the interior lights

Interior lights list.........................

302

5-4. Using the storage features

List of storage features............

305

Luggage compartment features

........................................................

308

5-5. Using the other interior features

Other interior features ............

312

Garage door opener...............

322

Compass.......................................

328

286

5-1. Remote Touch

5-1.Remote Touch

■

Switches



10.3-inch display model

“MAP” button

Press this button to display the vehicle’s
current position.



8-inch display model

“HOME” button

Press this button to display the home
screen.

“MENU” button

Press this button to display the menu
screen.

Back button

Press this button to display the previous
screen.

Touchpad

Slide your finger on the touchpad and
move the pointer to select a function, letter
and screen button.
Press the touchpad to enter the selected
function, letter or screen button. Certain
finger movements on the touchpad can
perform functions, such as changing map
scalings and scrolling list screens.

Sub function button

When

is displayed on the screen, a

function screen assigned to the screen can
be displayed.

■

Using the touchpad

Select: Touch the touchpad to
select the desired button on the
screen.

Enter: The buttons on the screen
can be selected by either depress-
ing or double tapping on the touch-
pad. Once a button has been
selected, the screen will change.

■

Touch operation

Operations are performed by touching
the touchpad with your finger.



Trace

Trace the pad surface while maintaining
contact with the touchpad. Moving the
cursor and the pointer.

Remote Touch

The Remote Touch can be used to
operate the navigation/multimedia
system display Owners of models
equipped with a navigation system
should refer to the “NAVIGATION
AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

Remote Touch operation

287

5-1. Remote Touch

Interio

r fe

atures



Double tap

Tap the touchpad twice, quickly. Select the
button on the screen.



Flick

Quick and long movement along the
touchpad with your finger. Move the list
screen or map screen.



Pinch in/Pinch out

Slide fingers toward each other or apart on
the touchpad. Change the scale of the
map.

■

Apple CarPlay

The Apple CarPlay Maps app is not com-

patible with pinch multi-touch gestures.

Press the “MENU” button on the
Remote Touch to display the menu
screen.
The display may differ depending on
the type of the system.

NOTICE

■

To prevent damage to the Remote

Touch

Observe the following precautions. Fail-

ure to do so may cause damage to the

Remote Touch.

●

Do not allow the Remote Touch to

come into contact with food, liquid,

stickers or lit cigarettes.

●

Do not subject the Remote Touch to

excessive pressure or strong impact.

●

Do not push the touchpad with a

strong force or use a sharp pointed

object to operate the pad.

Menu screen

288

5-1. Remote Touch



8-inch display model



10.3-inch display model

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

: This function is not made available in

some countries or areas.

: This function is not made available on

some models.



8-inch display models

The home screen can be display multiple information screens. For details about the
functions and operation of the display, refer to the respective section and “NAVI-

Switch

Function

Select to display the “Destina-
tion” screen.

Select to display the audio con-
trol screen.

Select to display the hands-free
control screen.

Select to display the “Apps”
screen.

*1, 2

Select to display the information
screen.

(



P.99)

When an Apple Car-
Play/Android Auto connection is
established and this button dis-
plays “Apple CarPlay”/“Android
Auto”, select to display the
home screen of Apple Car-
Play/Android Auto.

*1, 2

Select to display the “Setup”
screen.

Select to display the air condi-
tioning control screen.
(



P.295)

Select to adjust the contrast and
brightness of the screens, turn
the screen off, etc.

*1, 3

Switch

Function

Display overview

289

5-1. Remote Touch

Interio

r fe

atures

GATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”



10.3-inch display models



Split-screen display

Different information can be displayed on the left and right of the screen. For example, air
conditioning system screen can be displayed and operated while the fuel consumption
information screen is being displayed. The large screen on the left of the display is called
the main display, and the small screen to the right is called the side display.



Main display

For details about the functions and operation of the main display, refer to the respective
section and “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.



Side display

The following functions can be displayed and operated on the side display.

Select

to display the desired screen.

Navigation system

Audio

Vehicle information

Air conditioning system (



P.295)

Show/hide the side display.

: Refer to the “NAVIGATION AND

MULTIMEDIA SYSTEM OWNER’S
MANUAL”.

■

Screen display during low temperatures

When the ambient temperature is

extremely low, screen response may be

delayed even if the Remote Touch is oper-

ated.

A
B
C

290

5-2. Using the air conditioning system and defogger

5-2.Using the air conditioning system and defogger

Left-hand side temperature control switch

Fan speed control switch

Airflow mode control switch

Right-hand side temperature control switch

Automatic mode switch

Off switch

Front windshield defogger switch

Rear windshield and outside rear view mirror defogger switch

Automatic air conditioning system

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.
Press the “MENU” button on the Remote Touch, then select

to display the

air conditioning control screen.
The air conditioning system can be displayed and operated on the side display.

Air conditioning controls

A
B
C
D

E
F

291

5-2. Using the air conditioning system and defogger

Interio

r fe

atures

Outside/recirculated air mode switch

A/C switch

DUAL switch

■

Adjusting the temperature setting

Operate the temperature control
switch upwards to increase the tem-
perature and downwards to decrease
the temperature.
If “A/C” switch is not pressed, the sys-
tem will blow ambient temperature air
or heated air.

■

Adjusting the fan speed setting

Operate the fan speed control switch
upwards to increase the fan speed and
downwards to decrease the fan speed.
Press the off switch to turn the fan off.

■

Change the airflow mode

Operate the airflow mode control
switch upwards or downwards.

The mode changes as follows each time
the switch is operated.

Air flows to the upper body.

Air flows to the upper body and

feet.

Air flows to the feet.

Air flows to the feet and the wind-
shield defogger operates.

■

Switching between outside air and
recirculated air modes

Press the outside/recirculated air
mode switch.

The mode switches between outside air
mode (the indicator is off) and recirculated
air mode (the indicator is on) each time the
button is pressed.

■

Defogging the windshield

Defoggers are used to defog the wind-
shield and front side windows.
Press the front windshield defogger
switch.

Set the outside/recirculated air mode
switch to outside air mode if the recircu-
lated air mode is used. (It may switch auto-
matically.)
To defog the windshield and the side win-
dows early, turn the air flow and tempera-
ture up.
To return to the previous mode, press the
front windshield defogger switch again
when the windshield is defogged.

■

Defogging the rear window and
outside rear view mirrors

Defoggers are used to defog the rear
window and to remove raindrops, dew
and frost from the outside rear view
mirrors.

A
B

C
D

292

5-2. Using the air conditioning system and defogger

Press the rear windshield and outside
rear view mirror defogger switch.

The defoggers will automatically turn off
after a period of time.

■

Windshield wiper de-icer (if
equipped)



P.296

■

When the outside temperature exceeds

75°F (24°C) and the air conditioning

system is on

●

In order to reduce the air conditioning

power consumption, the air conditioning

system may switch to recirculated air

mode automatically.

This may also reduce fuel consumption.

●

Recirculated air mode is selected as a

default mode when the power switch is

turned to ON mode.

●

It is possible to switch to outside air mode

at any time by pressing the outside/recir-

culated air mode switch.

■

Fogging up of the windows

●

The windows will easily fog up when the

humidity in the vehicle is high. Pressing

“A/C” button or selecting “A/C” will

dehumidify the air from the outlets and

defog the windshield effectively.

●

If you turn “A/C” off, the windows may

fog up more easily.

●

The windows may fog up if the recircu-

lated air mode is used.

■

When driving on dusty roads

Close all windows. If dust thrown up by the

vehicle is still drawn into the vehicle after

closing the windows, it is recommended

that the air intake mode be set to outside air

mode and the fan speed to any setting

except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode tem-

porarily is recommended in preventing

dirty air from entering the vehicle interior

and helping to cool the vehicle when the

outside air temperature is high.

●

Outside/recirculated air mode may auto-

matically switch depending on the tem-

perature setting or the inside

temperature.

■

Registering air conditioning settings to

electronic keys (vehicles with driving

position memory)

●

Unlocking the vehicle using an electronic

key and turning the power switch to ON

mode will recall that key’s registered air

conditioning settings.

●

When the power switch is turned off, the

current air conditioning settings will auto-

matically be registered to the electronic

key that was used to unlock the vehicle.

●

The system may not operate correctly if

more than one electronic key is in the

vicinity or if the smart access system with

push-button start is used to unlock a pas-

senger door.

●

The doors that can recall the air condi-

tioning setting when unlocked using the

smart access system with push-button
start can be changed.

For details, con-

tact your Lexus dealer.

: The doors that can recall the driving posi-

tion memory are changed at the same
time.

■

Operation of the air conditioning sys-

tem in Eco mode

●

In the Eco mode, the air conditioning sys-

tem is controlled as follows to prioritize

fuel efficiency

• Engine speed and compressor operation

controlled to restrict heating/cooling

capacity

• Fan speed restricted when automatic

mode is selected

●

To improve air conditioning performance,

perform the following operations

• Adjust the fan speed

• Adjust the temperature setting

• Turn off Eco mode

●

Even when the driving mode is set to Eco
mode, the air conditioning eco mode can
be turned off by selecting the

293

5-2. Using the air conditioning system and defogger

Interio

r fe

atures

■

When the outside temperature is low

The dehumidification function may not

operate even when “A/C” is pressed or

“A/C” is selected.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning

system to the outside air mode.

●

During use, various odors from inside and

outside the vehicle may enter into and

accumulate in the air conditioning sys-

tem. This may then cause odor to be

emitted from the vents.

●

To reduce potential odors from occur-

ring:

• It is recommended that the air condition-

ing system be set to outside air mode

prior to turning the vehicle off.

• The start timing of the blower may be

delayed for a short period of time imme-

diately after the air conditioning system is

started in automatic mode.

■

Air conditioning filter



P.368

■

Air conditioning system refrigerant

●

A label regarding the refrigerant of the

air conditioning system is attached to the

hood at the location shown in the follow-

ing illustration.

●

The meaning of each symbol on the label

are as follows:

■

Customization

Settings (e.g. A/C automatic mode switch

operation) can be changed.

(Customizable features:



P. 443)

Caution

Air conditioning system

Air conditioning system lubri-
cant type

Requires registered techni-
cian to service air conditioning
system

Flammable refrigerant

WARNING

■

To prevent the windshield from fog-

ging up

Do not use the front windshield defogger

switch during cool air operation in

extremely humid weather. The difference

between the temperature of the outside

air and that of the windshield can cause

the outer surface of the windshield to fog

up, blocking your vision.

■

To prevent burns

●

Do not touch the rear view mirror sur-

faces when the outside rear view mir-

ror defoggers are on.

●

Vehicles with windshield wiper de-

icer: Do not touch the glass at lower

part of the windshield or to the side of

the front pillars when the windshield

wiper de-icer is on.

NOTICE

■

To prevent 12-volt battery discharge

Do not leave the air conditioning system

on longer than necessary when the

hybrid system is off.

■

When repairing/replacing parts of

the air conditioning system

Have repair/replacement performed by

your Lexus dealer. When a part of the air

conditioning system, such as the evapo-

rator, is to be replaced, it must be

replaced with a new one.

294

5-2. Using the air conditioning system and defogger

■

Main control screen

Using the touchpad of the Remote
Touch (



P.286), select the button on

the screen.

to can be adjusted by perform-

ing the following operations.
Flick operation: Move the pointer to
the desired item and flick the touchpad
up or down.

The item can be adjusted by one level.

Trace operation: After selecting the
desired item, slide your finger up or
down.

The item can be adjusted by the amount
that you trace.
Trace operation cannot be used while driv-
ing.

Sub menu

Selecting the sub menu item to switch the
main screen.

: Display the air conditioning control

screen

: Display the option control screen

Adjust the left-hand side tempera-
ture setting

Adjust the fan speed setting

Select the air flow mode

: Air flows to the upper body

: Air flows to the upper body and feet

: Air flows to the feet

: Air flows to the feet and the wind-

shield defogger operates

Adjust the right-hand side tem-
perature setting

Function on/off indicators

When the function is on, the indicator illu-
minates on the control screen.

Sub function menu

When the

button on the Remote

Touch is pressed, the following functions
can be switched on and off.
“AUTO”: Set automatic mode on/off
(



P.297)

“OFF”: Turn the fan off
“A/C”: Set cooling and dehumidification
function
“DUAL”: Adjust the temperature for driver
and passenger seats separately (“DUAL”
mode) (



P.298)

: Set eco air conditioning mode

■

Option control screen

Select

on the sub menu to display

the option control screen.

The functions can be switched on and off.
When the function is on, the indicator illu-

Air conditioning control screen

C
D

295

5-2. Using the air conditioning system and defogger

Interio

r fe

atures

minates on the screen.

Adjusting the temperature for
driver and passenger seats sepa-
rately (“DUAL” mode) (



P.298)

Set eco air conditioning mode

Air conditioning and heater output is lim-
ited to prioritize fuel economy.

Cooling and dehumidification func-
tion

Select S-FLOW mode (



P.296)

Prevent ice from building up on the
windshield and wiper blades
(Windshield wiper de-icer) (if
equipped)

Removing pollen from the air
(Micro dust and pollen filter)

■

Side display (Vehicles with naviga-
tion system)

Adjust the left-hand side tempera-
ture setting

Adjust the fan speed setting

Adjust the right-hand side tem-
perature setting

Set cooling and dehumidification
function on/off

Adjust the temperature for the
driver’s and front passenger’s seats
separately (“DUAL” mode)
(



P.298)

Select the air flow mode

■

Fogging up of the windows

●

The windows will easily fog up when the

humidity in the vehicle is high. Pressing

“A/C” button or selecting “A/C” will

dehumidify the air from the outlets and

defog the windshield effectively.

●

If you turn “A/C” off, the windows may

fog up more easily.

●

The windows may fog up if the recircu-

lated air mode is used.

■

Windshield wiper de-icer (if equipped)

This feature is used to prevent ice from
building up on the windshield and wiper
blades.
Select

on the option control screen.

When the windshield wiper de-icer on,

is displayed on the air conditioning

control screen.
The windshield wiper de-icer will automati-
cally turn off after a period of time.

■

Eco air conditioning mode

When Eco mode is selected using the driv-

ing mode select switch, eco air conditioning

mode turns on. When a drive mode other

than Eco mode is selected, eco air condi-

tioning mode may turn off.

■

S-FLOW mode

Priority for airflow is given to the front seats,
and the airflow and air conditioning for the
rear seats is effectively controlled.

B
C

296

5-2. Using the air conditioning system and defogger

Select

on the option control screen.

The indicator comes on when S-FLOW
mode is on.
Select

again to return to the previ-

ous mode.

■

Micro dust and pollen filter

Pollen is removed from the air and the air
flows to the upper part of the body.
Select

on the option control screen.

When the micro dust and pollen filter is on,

is displayed on the air conditioning

control screen.
In order to prevent the windshield from fog-
ging up when the outside air is cold, the
dehumidification function may operate.
The pollens are filtered out even if the micro
dust and pollen filter is turned off.

Press the “AUTO” button.

Adjust the temperature setting.

To stop the operation, press the
“OFF” button.

If the fan speed setting or air flow
modes are operated, the automatic
mode indicator goes off. However,
automatic mode for functions other
than that operated is maintained.

■

Using automatic mode

Fan speed is adjusted automatically accord-

ing to the temperature setting and the

ambient conditions.

Therefore, the fan may stop for a while until

warm or cool air is ready to flow immedi-

ately after the “AUTO” button is pressed or

“AUTO” is selected.

■

Windshield fog detection function

When automatic mode is set, the humidity

sensor (



P.297) detects fog on the wind-

shield and controls the air conditioning sys-

tem to prevent fog.

■

Air conditioning filter



P.368

■

Customization

Settings (e.g. A/C automatic mode switch

operation) can be changed.

(Customizable features:



P.443)

To turn on the “DUAL” mode, perform

WARNING

■

To prevent burns (vehicles with wind-

shield wiper de-icer)

Do not touch the glass at lower part of

the windshield or to the side of the front

pillars when the windshield wiper de-icer

is on.

Using automatic mode

NOTICE

■

Humidity sensor

In order to detect fog on the windshield,

a sensor which monitors the temperature

of the windshield, the surround humidity,

etc., is installed.

Follow these points to avoid damaging

the sensor:

●

Do not disassemble the sensor

●

Do not spray the glass cleaner on the

sensor or subject it to strong impacts

●

Do not stick anything on the sensor

Adjusting the temperature for
driver and passenger seats sepa-
rately (“DUAL” mode)

297

5-2. Using the air conditioning system and defogger

Interio

r fe

atures

any of the following procedures:



Press the “DUAL” button.



Select “DUAL” on the option con-
trol screen.



Adjust the temperature setting of
the passenger side with the passen-
ger side temperature adjustment
button.

The indicator comes on when the “DUAL”
mode is on.

■

Location of air outlets

The air outlets and air volume changes
according to the selected air flow
mode.

■

Adjusting the position of and open-
ing and closing the air outlets



Front

Direct air flow to the left or right, up

or down

Turn the knob to open or close the
vent



Rear

Direct air flow to the left or right, up
or down

Turn the knob to open or close the
vent

Air outlet layout and operations

WARNING

■

To not interrupt the windshield defog-

ger from operating

Do not place anything on the instrument

panel which may cover the air outlets.

Otherwise, air flow may be obstructed,

preventing the windshield defoggers

from defogging.

298

5-2. Using the air conditioning system and defogger

: If equipped

Turns the heated steering wheel on/off

The indicator light comes on when the
heated steering wheel is operating.

■

Operation condition

The power switch is in ON mode.

■

Timer function

The heated steering wheel will automati-

cally turn off after about 30 minutes.

■

Front



Vehicles without seat ventilators

Each time the switch is pressed, the
operation condition changes as fol-
lows.
Hi (3 segments lit)



Mid (2 segments

lit)



Lo (1 segment lit)



Off

The level indicator (amber)

light up

during operation.

Heated steering wheel

/seat

heaters

/seat ventilators



Heated steering wheel

Warm up the grip of the steering wheel



Seat heaters

Warm up the seat upholstery



Seat ventilators

Maintain good airflow on the seat uphol-
stery by blowing air from the seats

WARNING

■

To prevent minor burn injuries

Care should be taken if anyone in the fol-

lowing categories comes in contact with

the steering wheel or seats when the

heater is on:

●

Babies, small children, the elderly, the

sick and the physically challenged

●

Persons with sensitive skin

●

Persons who are fatigued

●

Persons who have taken alcohol or

drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

NOTICE

■

To prevent damage to the seat heat-

ers and seat ventilators

Do not put heavy objects that have an

uneven surface on the seat and do not

stick sharp objects (needles, nails, etc.)

into the seat.

■

To prevent battery discharge

Do not use the functions when the hybrid

system is off.

Heated steering wheel

Seat heaters

299

5-2. Using the air conditioning system and defogger

Interio

r fe

atures



Vehicles with seat ventilators

Each time the switch is pressed, the
operation condition changes as fol-
lows.
Hi (3 segments lit)



Mid (2 segments

lit)



Lo (1 segment lit)



Off

The indicator (amber) and level indicator
(green)

light up during operation.

■

Rear

Each time the switch is pressed, the
operation condition changes as fol-
lows.
Hi (3 segments lit)



Mid (2 segments

lit)



Lo (1 segment lit)



Off

The level indicator (amber) lights up
during operation.

■

Operation condition

The seat heaters can be used when the

power switch is in ON mode.

Each time the switch is pressed, the
operation condition changes as fol-
lows.
Hi (3 segments lit)



Mid (2 segments

lit)



Lo (1 segment lit)



Off

The indicator (green) and level indicator
(green)

light up during operation.

WARNING

■

To prevent causes of overheating and

minor burn injuries

Observe the following precautions when

using a seat heater

●

Do not cover the seat with a blanket or

cushion when using the seat heater.

●

Do not use seat heater more than nec-

essary.

Seat ventilators (front)

300

5-2. Using the air conditioning system and defogger

■

Operation condition

The power switch is in ON mode.

Content .. 15 16 17 18 ..
