531

5-22. Other function (Lexus Display Audio System)

“Information” screen

Go to “Information”: “MENU” button



“Info”

Display the “MirrorLink



” screen.

(



P. 532)

Display the “USB photo” screen.
(



P. 536)

Display “Information” screen

532

5-22. Other function (Lexus Display Audio System)

MirrorLink™



P. 453

The MirrorLink™ function enables operations of some smartphone content
via the Lexus Display Audio system.
Depending on differences between models or software version etc., some
models might be incompatible with this system.
Connect a smartphone to USB port using a USB cable.
For safety reasons, the safe driving screen is displayed while driving depend-
ing on the application.

Connecting a smartphone

533

5-22. Other function (Lexus Display Audio System)

Go to “MirrorLink



”: “MENU” button



“Info”



“MirrorLink



”

Select the desired application on the application list screen.

■

MirrorLink™ screen

Follow the specific operation procedures for the smartphone application.

Control area
Press the back button on the
Lexus Display Audio controller to
turn the control area display on/
off.
Return application list screen
If you select the other application,
the new application screen will
displayed.
Displays software buttons that function as the buttons on the smartphone.
Change the other audio source (Radio, Disc, etc.).

To display the left menu screen, turn the
controller to the left while the
MirrorLink™ screen is being displayed.

Select a device
Change the screen size
Adjust the display settings.

■

Selecting a MirrorLink™ device

If more than one MirrorLink™ device is available, select the desired device.

Select “Select MirrorLink™ device” on the left menu screen.
Select “MirrorLink™ 1” or “MirrorLink™ 2”.

Using MirrorLink™ function

Menu screen

3
4

2
3

534

5-22. Other function (Lexus Display Audio System)

■

Operational conditions

●

When MirrorLink

™

is activated, previous applications, run with a USB, are closed, and

vice versa.

●

Compatible devices
Smartphones, which passed the Car Connectivity Consortium certification program

ver1.1 or later. Confirm with the smartphone manufacture or the distributor for the

MirrorLink

™

compatibility.

●

Compatible applications
Applications, which are certified by Car Connectivity Consortium as MirrorLink

™

Base-Certified or Drive-Certified applications.

■

About MirrorLink™

MirrorLink is a registered trademark of Car Connectivity Consortium, Inc.

■

When using MirrorLink™

●

Check that the smartphone screen is unlocked. Unlock the smartphone screen before

connecting it to the Lexus Display Audio system. (Some smartphones may not be able

to be connected via MirrorLink

™

if the screen is locked.)

●

Make sure that the smartphone has been connected via Bluetooth

. (Some

smartphones may not be able to perform hands-free calls using the MirrorLink

™

func-

tion if it has not been connected to the vehicle via Bluetooth

●

If a MirrorLink

™

application cannot be started, check that the MirrorLink

™

applica-

tion certificate has not expired. The certificates of MirrorLink

™

applications have an

expiration date. (An internet connection is required to automatically update the certifi-

cate.) If a MirrorLink

™

application becomes unavailable, it may be due to the certifi-

cate expiring. In this case, the certificate must be updated manually. Check with the

smartphone manufacturer or application developer for how to update the certificate.

●

Make sure the volume of the smartphone is set to an appropriate level. If the

MirrorLink

™

application volume is excessively low even when the volume of the Lexus

Display Audio system is increased, check the volume of the smartphone and increase it

as necessary.

535

5-22. Other function (Lexus Display Audio System)

WARNING

■

While driving

Do not connect smartphone or operate the controls.

NOTICE

■

To avoid damaging the smartphone

●

Depending on the size and shape of the smartphone that is connected to the system,

the console box may not close fully. In this case, do not forcibly close the console box

as this may damage the smartphone or the terminal, etc.

●

Do not leave your smartphone in the vehicle. The temperature inside may rise to a

level that could damage the smartphone.

●

Do not push down on or apply unnecessary pressure to the smartphone device while

it is connected.

●

Do not insert foreign objects into the port.

536

5-22. Other function (Lexus Display Audio System)

USB photo

Go to “USB photo”: “MENU” button



“Info”



“USB 1 photo” or “USB 2

photo”



P. 453

Move the controller to the left to display the menu screen.

Change the full screen mode.
Select to set the slide show display
on/off.

Start the slide show at a selected folder.

Change the play speed.
Change the play mode.

Move the controller to the right and select “Browse”.
Select the desired folder, and then select a desired file to begin using the
selected folder.

Connecting a USB memory device enables you to enjoy photo on the Lexus
Display Audio display.

USB photo screen

Connecting a USB memory device

Menu screen

3
4

Selecting a folder and a file

537

5-22. Other function (Lexus Display Audio System)

■

USB memory functions



P. 487

■

USB memory

●

Compatible devices
USB memory device that can be used for JPEG display.

●

Compatible device formats
The following device format can be used:
• USB communication format: USB2.0 FS (480 Mbps)

• File system format: FAT16/32 (Windows)

• Correspondence class: Mass storage class

●

JPEG file compatibility
• Compatible image size: Maximum 10MB

• Compatible pixel size: Maximum 10,000,000 pixels

NOTICE

■

To prevent damage to the USB memory device or its terminals



P. 490

538

5-22. Other function (Lexus Display Audio System)

Speech command system

You can register desired contacts to enable the speech command system. Up to
50 contacts per phone can be registered.

Go to “Voice tags”: “MENU” button



“Setup”



“Telephone”



“Contact/

call history settings”



“Voice tag”



“New” or “Edit”

Select the desired contact.
Move the controller to the left and then select “REC”.
Say the registered voice tag.

To play the registered voice, select “Play”.

■

Deleting a voice tag

Display the “Voice tags” screen.
Select “Delete” and then the desired contact.
Move the controller to the left and then select “Delete”.

Press the talk switch.

To cancel the speech command system,

press and hold the talk switch.

After a beep sounds, say the desired
contact name.

When the icon is displayed, you can

speak a command.

If more than 1 contact name is dis-
played, select the desired contact
name.
If more than 1 phone number is displayed, select the desired phone number.

When the off-hook switch on the steering wheel is pressed, the system calls the first

phone number entry of the first contact.

Using the speech command system enables you to make a call to contacts
that have a voice tag.

Editing a voice tag

Using the speech command system

2
3
4

2
3

539

5-22. Other function (Lexus Display Audio System)

■

Microphone



P. 502

■

Speech commands may not be recognized if:

●

Spoken too quickly

●

Spoken at a low or high volume

●

Passengers are talking while speech commands are spoken

541

Interior features

6-1. Remote Touch screen

Remote Touch/

10.3-inch display .....................542

6-2. Using the air conditioning

system and defogger

Automatic air conditioning

system (Vehicles with
a navigation system or
Lexus Display Audio
System)........................................547

Automatic air conditioning

system (Vehicles without
a navigation system or
Lexus Display Audio
System)........................................557

Heated steering wheel/

seat heaters ...............................564
• Heated steering wheel ......564
• Seat heaters............................565

6-3. Using the interior lights

Interior lights list .........................566

• Personal/interior light

main switch.............................566

• Front personal/

interior lights.......................... 567

• Rear interior light................. 567

6-4. Using the storage features

List of storage features ............568

• Glove box...............................569
• Console box ..........................569
• Cup holders/

bottle holders/
door pockets..........................570

• Auxiliary boxes.......................571

Luggage compartment

features ....................................... 572

6-5. Using the other interior features

Other interior features ............575

• Sun visors ................................575
• Vanity mirrors .......................575
• Clock ........................................ 576
• Power outlet........................... 576
• Assist grips ............................. 577

542

6-1. Remote Touch screen

Remote Touch/10.3-inch display



“MAP” button

Press this button to display the vehicle’s current position.

“



•



” button

Press this button to change map scale and scroll through lists.

“MENU” button

Press this button to display the “Menu” screen.

Remote Touch knob

Move in the desired direction to select a function, letter and screen button.

Press the knob to enter the selected function, letter or screen button.



: If equipped

The Remote Touch can be used to operate the Remote Touch screens.
Owners of models equipped with a navigation system should refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

Remote Touch operation

543

6-1. Remote Touch screen

rio

r f

eat
ur

■

Using the Remote Touch knob

Select: Move the knob in the
desired direction.
Enter: Press the knob.

■

Screen display during low temperatures

When the ambient temperature is extremely low, screen response may be delayed even

if the Remote Touch is operated.

WARNING

■

When using the Remote Touch

●

Do not allow fingers, fingernails or hair to become caught in the Remote Touch as this

may cause an injury.

●

Be careful when selecting the Remote Touch in extreme temperatures as it may

become very hot or cold due to the temperature inside the vehicle.

NOTICE

■

To prevent damage to the Remote Touch

●

Do not allow the Remote Touch to come into contact with food, liquid, stickers or lit

cigarettes as doing so may cause it to change color, emit a strange odor or stop func-

tioning.

●

Do not subject the Remote Touch to excessive pressure or strong impact as the knob

may bend or break off.

●

Do not allow coins, contact lenses or other such items to become caught in the

Remote Touch as this may cause it to stop functioning.

●

Items of clothing may rip if they become caught on the Remote Touch knob.

●

If your hand or any object is on the Remote Touch knob when the power switch is

turned to ACCESSORY mode, the Remote Touch knob may not operate properly.

544

6-1. Remote Touch screen

Press the “MENU” button on the
Remote Touch to display the “Menu”
screen.
The display may differ depending on
the type of the system.

When an interruption screen is being

displayed on the side display, the

“Menu” screen will be shown on the

main display.

: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

: If equipped

“Menu” screen

Switch

Function

Select to display the map screen or the navigation menu screen.

1, 2

Select to display the radio control screen.

Select to operate the media control screen.

Select to display the hands-free operation screen.

Select to display the fuel consumption screen. (



P. 109, 112)

Select to display the “Information” screen.

Select to display the air conditioning control screen. (



P. 549)

Select to display the “Setup” screen.

“Display”

Select to adjust the contrast and brightness of the screens, turn the

screen off, etc.

545

6-1. Remote Touch screen

rio

r f

eat
ur

■

Full screen display

The following functions can be displayed full screen:

: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

■

Split-screen display

Different information can be displayed on the left and right of the screen. For
example, air conditioning system screen can be displayed and operated while
the fuel consumption information screen is being displayed. The large screen
on the left of the display is called the main display, and the small screen to the
right is called the side display.

10.3-inch display operation

●

Initial screen

●

“Menu” screen (



P. 544)

●

Map screen

●

Audio screen

●

Energy monitor/fuel consumption
screen (



P. 108)

●

Air conditioning control screen
(



P. 549)

546

6-1. Remote Touch screen

For details of the functions and operation of the main display, refer to the respec-
tive section.

■

Display the side display



Basic screens

The following functions can be displayed and operated on the side display.
Select the desired button.

Navigation system

Audio

Phone

Vehicle information (



P. 115)

Air conditioning system
(



P. 550)

Hide the side display

If the item displayed on the main display is full screen display compatible (



P. 545), it

will be displayed full screen.



Interruption screens

Each of the following screens is displayed automatically in accordance with
conditions.

• Lexus parking assist-sensor

(if equipped)

• Phone

: Refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.

10.3-inch display function

2
3
4
5

547

6-2. Using the air conditioning system and defogger

rio

r f

eat
ur

Automatic air conditioning system (Vehicles with a
navigation system or Lexus Display Audio System)

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.
Vehicles with a Lexus Display Audio System: Press the “MENU” button on the
Lexus Display Audio controller, then select “Climate” to display the air condi-
tioning operation screen.
For details on the Lexus Display Audio controller, refer to P. 448.
Vehicles with a navigation system: Press the “MENU” button on the Remote

Touch, then select

to display the air conditioning operation screen.

The air conditioning system can be displayed and operated on the side display.
(



P. 550)

For details on the Remote Touch, refer to P. 542.
When an interruption screen is being displayed on the side display, the
“Menu” screen will be shown on the main display.

Content .. 23 24 25 26 ..
