Lexus CT (2021 year). Manual in english - page 26

548

6-2. Using the air conditioning system and defogger

■

Adjusting the temperature setting

Press

to increase the temperature and

to decrease the tem-

perature.

If “A/C” is not pressed, the system will blow ambient temperature air or heated air.

■

Adjusting the fan speed setting

Press

to increase the fan speed and

to decrease the fan

speed.
Press the “OFF” button to turn the fan off.

■

Change the airflow mode

To change the airflow, press

The air outlets used are switched

each time the button is pressed.

Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
Air flows to the feet and the wind-
shield defogger operates.

Control panel

3
4

549

6-2. Using the air conditioning system and defogger

rio

r f

eat
ur



Vehicles with a Lexus Display Audio System
Adjust the left-hand side tempera-
ture setting
Adjust the fan speed setting
Select to set automatic mode on/off
Set cooling and dehumidification
function on/off
Adjust the temperature for the
driver’s and front passenger’s seats
separately (“DUAL” mode)
(



P. 551)

Display the option control screen (



P. 550)

Select the air flow mode
Adjust the right-hand side temperature setting



Vehicles with a navigation system
Adjust the left-hand side tempera-
ture setting
Adjust the fan speed setting
Select the air flow mode
Adjust the right-hand side tempera-
ture setting
Display the option control screen
(



P. 550)

Select to set automatic mode on/off
Set cooling and dehumidification function on/off
Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) (



P. 551)

To adjust or select settings, move the Remote Touch knob to select the screen
button, and then press the Remote Touch knob to enter the selected function.

Control screen

2
3
4

6
7
8

2
3
4

6
7
8

550

6-2. Using the air conditioning system and defogger

■

Option control screen

Select

on the climate screen to display the option control screen. The

functions can be switched on and off.

Prevent ice from building up on the windshield and wiper blades
(if equipped) (



P. 552)

Remove pollen from the air (Pollen removal mode) (



P. 552)

■

Side display operation screen (Vehicles with a navigation system)

Select the air flow mode
Adjust the left-hand side tempera-
ture setting
Adjust the fan speed setting
Adjust the right-hand side tempera-
ture setting
Select to set auto mode on/off

Select to set cooling and dehumidification function on/off
Adjust the temperature for driver and passenger seats separately (“DUAL”
mode) (



P. 558)



Vehicles with a Lexus Display Audio
System



Vehicles with a navigation system

3
4

6
7

551

6-2. Using the air conditioning system and defogger

rio

r f

eat
ur

■

Using the automatic mode

Press the “AUTO” button.

Adjust the temperature setting.
To stop the operation, press the “OFF” button.

■

Automatic mode indicator

If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated is maintained.

■

Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)

To turn on the “DUAL” mode, perform any of the following procedures:

●

Press the “DUAL” button or select “DUAL” on the air conditioning control
screen.

●

Select “DUAL” on the side display operation screen. (Vehicles with a navi-
gation system)

●

Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.

■

Switching between outside air and recirculated air modes

Press .

The mode switches between

(recirculated air mode) and

(outside

air mode) modes each time the button is pressed.

Air conditioning controls

Other functions

2
3

552

6-2. Using the air conditioning system and defogger

■

Defogging the windshield

Defoggers are used to defog the windshield and front side windows.

Press .

Set

to outside air mode if the recirculated air mode is used. (It may

switch automatically.)
To defog the windshield and the side windows early, turn the air flow and tempera-

ture up.
To return to the previous mode, press

again when the windshield is

defogged.

■

Defogging the rear window and outside rear view mirrors

Defoggers are used to defog the rear window and to remove raindrops, dew
and frost from the outside rear view mirrors.

Press .

The defoggers will automatically turn off after a period of time.

■

Pollen removal mode

Pollen is removed from the air and the air flows to the upper part of the body.

Press

or select

on the option control screen.

When the pollen removal mode is on,

is displayed on the air conditioning

control screen.
In order to prevent the windshield from fogging up when the outside air is cold, the

dehumidification function may operate.
The pollens are filtered out even if the pollen removal mode is turned off.

■

Windshield wiper de-icer (if equipped)

This feature is used to prevent ice from building up on the windshield and
wiper blades.
Select

on the option control screen.

When the windshield wiper de-icer is on,

is displayed on the air condition-

ing control screen.
The windshield wiper de-icer will automatically turn off after a period of time.

553

6-2. Using the air conditioning system and defogger

rio

r f

eat
ur

■

Location of air outlets

The air outlets and air volume
changes according to the selected
air flow mode.

■

Adjusting the air flow direction and opening/closing the air outlets

Direct air flow to the left or right,
up or down.
Turn the knob to open or close
the vent.

Air outlets

554

6-2. Using the air conditioning system and defogger

■

Registering air conditioning settings to electronic keys (vehicles with a smart entry &

start system)

●

Unlocking the vehicle using an electronic key and turning the power switch to ON

mode will recall that key’s registered air conditioning settings.

●

When the power switch is turned off, the current air conditioning settings will automati-

cally be registered to the electronic key that was used to unlock the vehicle.

The system may not operate correctly if more than one electronic key is in the vicinity or

if the smart entry & start system is used to unlock a passenger door.

■

Using automatic mode

Fan speed is adjusted automatically according to the temperature setting and the ambi-

ent conditions.

Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately

after the “AUTO” button is pressed or “AUTO” is selected.

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high. Pressing “A/C”

button or selecting “A/C” will dehumidify the air from the outlets and defog the wind-

shield effectively.

●

If you turn “A/C” off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Windshield fog detection function (if equipped)

When automatic mode is set, the humidity sensor (



P. 556) detects fog on the wind-

shield and controls the air conditioning system to prevent fog.

■

When driving on dusty roads

Close all windows. If dust thrown up by the vehicle is still drawn into the vehicle after clos-

ing the windows, it is recommended that the air intake mode be set to outside air mode

and the fan speed to any setting except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode temporarily is recommended in preventing dirty air

from entering the vehicle interior and helping to cool the vehicle when the outside air

temperature is high.

●

Outside/recirculated air mode may automatically switch depending on the tempera-

ture setting or the inside temperature.

555

6-2. Using the air conditioning system and defogger

rio

r f

eat
ur

■

When the outside temperature is low

The dehumidification function may not operate even when “A/C” is pressed or “A/C” is

selected.

■

Operation of the air conditioning system in Eco drive mode

●

In the Eco drive mode, the air conditioning system is controlled as follows to prioritize

fuel efficiency
• Engine speed and compressor operation controlled to restrict heating/cooling

capacity

• Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations
• Adjust the fan speed

• Turn off Eco drive mode

• Customize the air conditioning control of Eco drive mode. (



P. 748)

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into and accu-

mulate in the air conditioning system. This may then cause odor to be emitted from the

vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode prior

to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time immediately

after the air conditioning system is started in automatic mode.

■

Air conditioning filter



P. 634

■

Customization

Settings (e.g. A/C automatic mode switch operation) can be changed.

(Customizable features:



P. 742)

556

6-2. Using the air conditioning system and defogger

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather. The differ-

ence between the temperature of the outside air and that of the windshield can cause

the outer surface of the windshield to fog up, blocking your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mirror defog-

gers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the front pillars

when the windshield wiper de-icer is on. (vehicles with windshield wiper de-icer)

NOTICE

■

Humidity sensor (if equipped)

■

To prevent 12-volt battery discharge

Do not leave the air conditioning system on longer than necessary when the hybrid sys-

tem is off.

●

Do not place anything on the instrument

panel which may cover the air outlets. Other-

wise, air flow may be obstructed, preventing

the windshield defoggers from defogging.

In order to detect fog on the windshield, a sen-

sor which monitors the temperature of the

windshield, the surround humidity, etc. is

installed. (



P. 554)

Follow these points to avoid damaging the sen-

sor:

●

Do not disassemble the sensor

●

Do not spray the glass cleaner on the sensor

or subject it to strong impacts

●

Do not stick anything on the sensor

557

6-2. Using the air conditioning system and defogger

rio

r f

eat
ur

Automatic air conditioning system (Vehicles without
a navigation system or Lexus Display Audio System)

■

Adjusting the temperature setting

Press

to increase the temperature and

to decrease the tem-

perature.

If “A/C” is not pressed, the system will blow ambient temperature air or heated air.

■

Adjusting the fan speed setting

Press

to increase the fan speed and

to decrease the fan

speed.
Press the “OFF” button to turn the fan off.

Air outlets and fan speed are automatically adjusted according to the tem-
perature setting.

Control panel

558

6-2. Using the air conditioning system and defogger

■

Change the airflow mode

To change the airflow, press

The air outlets used are switched

each time the button is pressed.

Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
Air flows to the feet and the wind-
shield defogger operates.

■

Using the automatic mode

Press the “AUTO” button.

Adjust the temperature setting.
To stop the operation, press the “OFF” button.

■

Automatic mode indicator

If the fan speed setting or air flow modes are operated, the automatic mode
indicator goes off. However, automatic mode for functions other than that
operated are maintained.

■

Adjusting the temperature for driver and passenger seats separately
(“DUAL” mode)

To turn on the “DUAL” mode, perform any of the following procedures:

●

Press the “DUAL” button.

●

Adjust the passenger’s side temperature setting.
The indicator comes on when the “DUAL” mode is on.

3
4

Air conditioning controls

2
3

559

6-2. Using the air conditioning system and defogger

rio

r f

eat
ur

■

Switching between outside air and recirculated air modes

Press .

The mode switches between

(recirculated air mode) and

(outside

air mode) modes each time the button is pressed.

■

Defogging the windshield

Defoggers are used to defog the windshield and front side windows.

Press .

Set

to outside air mode if the recirculated air mode is used. (It may

switch automatically.)
To defog the windshield and the side windows early, turn the air flow and tempera-

ture up.
To return to the previous mode, press

again when the windshield is

defogged.

■

Defogging the rear window and outside rear view mirrors

Defoggers are used to defog the rear window and to remove raindrops, dew
and frost from the outside rear view mirrors.

Press .

The defoggers will automatically turn off after a period of time.

■

Pollen removal mode

Pollen is removed from the air and the air flows to the upper part of the body.

Press .

In order to prevent the windshield from fogging up when the outside air is cold, the

dehumidification function may operate.
The pollens are filtered out even if the pollen removal mode is turned off.

Other functions

560

6-2. Using the air conditioning system and defogger

■

Windshield wiper de-icer (if equipped)

This feature is used to prevent ice from building up on the windshield and
wiper blades.
Turns on/off.

The indicator comes on when the

windshield wiper de-icer is on.
The windshield wiper de-icer will

automatically turn off after a period

of time.

■

Location of air outlets

The air outlets and air volume
changes according to the selected
air flow mode.

■

Adjusting the air flow direction and opening/closing the air outlets

Direct air flow to the left or right,
up or down.
Turn the knob to open or close
the vent.

Air outlets

561

6-2. Using the air conditioning system and defogger

rio

r f

eat
ur

■

Registering air conditioning settings to electronic keys (vehicles with a smart entry &

start system)

●

Unlocking the vehicle using an electronic key and turning the power switch to ON

mode will recall that key’s registered air conditioning settings.

●

When the power switch is turned off, the current air conditioning settings will automati-

cally be registered to the electronic key that was used to unlock the vehicle.

The system may not operate correctly if more than one electronic key is in the vicinity or

if the smart entry & start system is used to unlock a passenger door.
Settings for the electronic key and the corresponding door can be changed.
Contact any authorized Lexus retailer or Lexus authorized repairer, or any reliable

repairer.

■

Using automatic mode

Fan speed is adjusted automatically according to the temperature setting and the ambi-

ent conditions.

Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately

after the “AUTO” button is pressed.

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high. Pressing “A/C”

button on will dehumidify the air from the outlets and defog the windshield effectively.

●

If you turn “A/C” off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Windshield fog detection function (if equipped)

When automatic mode is set, the humidity sensor (



P. 563) detects fog on the wind-

shield and controls the air conditioning system to prevent fog.

■

When driving on dusty roads

Close all windows. If dust thrown up by the vehicle is still drawn into the vehicle after clos-

ing the windows, it is recommended that the air intake mode be set to outside air mode

and the fan speed to any setting except off.

■

Outside/recirculated air mode

●

Setting to the recirculated air mode temporarily is recommended in preventing dirty air

from entering the vehicle interior and helping to cool the vehicle when the outside air

temperature is high.

●

Outside/recirculated air mode may automatically switch depending on the tempera-

ture setting or the inside temperature.

562

6-2. Using the air conditioning system and defogger

■

When the outside temperature is low

The dehumidification function may not operate even when “A/C” is pressed.

■

Operation of the air conditioning system in Eco drive mode

●

In the Eco drive mode, the air conditioning system is controlled as follows to prioritize

fuel efficiency
• Engine speed and compressor operation controlled to restrict heating/cooling

capacity

• Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations
• Adjust the fan speed

• Turn off Eco drive mode

• Customize the air conditioning control of Eco drive mode. (



P. 748)

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into and accu-

mulate in the air conditioning system. This may then cause odor to be emitted from the

vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air mode prior

to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time immediately

after the air conditioning system is started in automatic mode.

■

Air conditioning filter



P. 634

■

Customization

Settings (e.g. A/C automatic mode switch operation) can be changed.

(Customizable features:



P. 742)

563

6-2. Using the air conditioning system and defogger

rio

r f

eat
ur

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather. The differ-

ence between the temperature of the outside air and that of the windshield can cause

the outer surface of the windshield to fog up, blocking your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mirror defog-

gers are on.

●

Do not touch the glass at lower part of the windshield or to the side of the front pillars

when the windshield wiper de-icer is on. (vehicles with windshield wiper de-icer)

NOTICE

■

Humidity sensor (if equipped)

■

To prevent 12-volt battery discharge

Do not leave the air conditioning system on longer than necessary when the hybrid sys-

tem is off.

●

Do not place anything on the instrument

panel which may cover the air outlets. Other-

wise, air flow may be obstructed, preventing

the windshield defoggers from defogging.

In order to detect fog on the windshield, a sen-

sor which monitors the temperature of the

windshield, the surround humidity, etc. is

installed. (



P. 561)

Follow these points to avoid damaging the sen-

sor:

●

Do not disassemble the sensor

●

Do not spray the glass cleaner on the sensor

or subject it to strong impacts

●

Do not stick anything on the sensor

Content .. 24 25 26 27 ..
