LEXUS CT200H (2017 year). Instruction - part 16

251

4-6. Driving tips

iving

WARNING

■

Driving with snow tires
Observe the following precautions to reduce the risk of accidents.

Failure to do so may result in a loss of vehicle control and cause death or serious injury.

●

Use tires of the specified size.

●

Maintain the recommended level of air pressure.

●

Do not drive in excess of 75 mph (120 km/h), regardless of the type of snow tires

being used.

●

Use snow tires on all, not just some wheels.

■

Driving with tire chains
Observe the following precautions to reduce the risk of accidents.

Failure to do so may result in the vehicle being unable to be driven safely, and may

cause death or serious injury.

●

Do not drive in excess of the speed limit specified for the tire chains being used, or 30

mph (50 km/h), whichever is lower.

●

Avoid driving on bumpy road surfaces or over potholes.

●

Avoid sudden acceleration, abrupt steering, sudden braking and shifting operations

that cause sudden engine braking.

●

Slow down sufficiently before entering a curve to ensure that vehicle control is main-

tained.

■

When parking the vehicle
When parking the vehicle without applying the parking brake, make sure to chock the

wheels. If you do not chock the wheels, the vehicle may move unexpectedly, possibly

resulting in an accident.

NOTICE

■

Repairing or replacing snow tires
Request repairs or replacement of snow tires from Lexus dealers or legitimate tire

retailers.

This is because the removal and attachment of snow tires affects the operation of the

tire pressure warning valves and transmitters.

■

Fitting tire chains
The tire pressure warning valves and transmitters may not function correctly when tire

chains are fitted.

252

4-6. Driving tips

253

Audio system

5-1. Basic Operations

Audio system types ..................256
Using the steering wheel

audio switches .........................258

AUX port/USB port................259

5-2. Using the audio system

Optimal use of the audio

system ...........................................261

5-3. Using the radio

Radio operation .........................263

5-4. Playing audio CDs and

MP3/WMA discs

CD player operation................ 269

5-5. Using an external device

Listening to an iPod ...................276
Listening to a USB memory

device..........................................282

Using the AUX port................. 287

254

5-6. Using Bluetooth

devices

Bluetooth

audio/phone ...... 288

Using the steering wheel

switches ......................................295

Registering a Bluetooth

audio system for the
first time ......................................296

Registering a Bluetooth

phone for the first time ......... 297

5-7. Setup menu

Setting up a Bluetooth

enabled portable player ..... 298

Bluetooth

audio system

setup ........................................... 302

Setting a cellular phone ......... 303
Security and system setup .... 306
Using the phone book............ 309

5-8. Bluetooth

Audio

Operating a Bluetooth

enabled portable player ....... 314

5-9. Bluetooth

Phone

Making a phone call..................316
Receiving a phone call .............318
Speaking on the phone............319

5-10. Bluetooth

Bluetooth

.................................. 320

5-11. Basic Operations

(Lexus Display Audio System)

Lexus Display Audio

System......................................... 324

Steering wheel audio

switches......................................329

USB/AUX ports ........................330

5-12. Setup (Lexus Display Audio

System)

Setup menu..................................332
General settings........................333
Voice settings..............................336
Display settings .......................... 337

5-13. Using the audio system

(Lexus Display Audio System)

Selecting the audio

source .........................................338

Optimal use of the audio

system .........................................339

Audio settings.............................340
Audio menu screen

operation ...................................342

5-14. Using the radio

(Lexus Display Audio System)

Radio operation .........................345

5-15. Playing an audio CD and

MP3/WMA/AAC discs
(Lexus Display Audio System)

CD player operation................. 351

255

Audio system

5-16. Using an external device

(Lexus Display Audio System)

Listening to an iPod...................357
Using USB memory

device ......................................... 360

Using the AUX port.................364

5-17. Connecting Bluetooth

(Lexus Display Audio System)

Steps for using Bluetooth

devices........................................365

Registering a Bluetooth

device ..........................................367

Selecting a Bluetooth

device ......................................... 368

Connecting a Bluetooth

audio player ..............................369

Connecting a Bluetooth

phone...........................................370

Displaying a Bluetooth

device details..............................371

Detailed Bluetooth

settings........................................ 372

5-18. Bluetooth

Audio

(Lexus Display Audio System)

Listening to Bluetooth

Audio...........................................373

5-19. Bluetooth

Phone (Lexus

Display Audio System)

Using a Bluetooth

Phone.......................................... 375

Making a call................................377
Receiving a call .......................... 379
Speaking on the phone.......... 380
Using a Bluetooth

phone message.......................382

Using the steering wheel

switches......................................384

Bluetooth

phone settings...385

5-20.Phonebook (Lexus

Display Audio System)

Contact settings ........................387
Messaging setting.....................390

5-21. Bluetooth

(Lexus

Display Audio System)

What to do if...

(Troubleshooting).................... 391

Bluetooth

..................................394

5-22.Other function (Lexus

Display Audio System)

“Information” screen................399
USB photo .................................... 401
Weather information................403
Voice command system .........404
Mobile Assistant....................... 408
LEXUS Enform Remote.......... 410

256

5-1. Basic Operations

Audio system types



Vehicles without a Lexus Display Audio System or navigation system



Vehicles with a Lexus Display Audio System

P. 324



Vehicles with a navigation system

Owners of models equipped with a navigation system should refer to the
“NAVIGATION SYSTEM OWNER’S MANUAL”.

■

Using cellular phones
Interference may be heard through the audio system’s speakers if a cellular phone is

being used inside or close to the vehicle while the audio system is operating.

257

5-1. Basic Operations

Audio system

WARNING

■

Certification

●

Part 15 of the FCC Rules
FCC Warning:

Any unauthorized changes or modifications to this equipment would void the user’s

authority to operate this device.

●

Laser products

NOTICE

■

To prevent 12-volt battery discharge
Do not leave the audio system on longer than necessary with the hybrid system is not

operating.

■

To avoid damaging the audio system
Take care not to spill drinks or other fluids over the audio system.

258

5-1. Basic Operations

Using the steering wheel audio switches

Volume switch:

• Press: Increases/decreases vol-

ume

• Press and hold: Continuously

increases/decreases volume

Radio mode:

• Press: Selects a radio station
• Press and hold: Seeks up/down

CD, MP3/WMA disc, Bluetooth

, iPod or USB mode:

• Press: Selects a track/file/song
• Press and hold: Selects a folder or album (MP3/WMA disc, Bluetooth

iPod or USB)

“MODE” switch:

• Press: Turns the power on, selects an audio source
• Press and hold: Turns the power off

■

Canceling automatic selection of a radio station
Press the “

” or “” button again.

Some audio features can be controlled using the switches on the steering
wheel.
Operation may differ depending on the type of audio system or navigation
system. For details, refer to the manual provided with the audio system or nav-
igation system.

WARNING

■

To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.

259

5-1. Basic Operations

Audio system

AUX port/USB port

■

iPod

Press down and release the lid.

Open the cover and connect an
iPod using an iPod cable.

Turn on the power of the iPod if it is

not turned on.

■

USB memory

Press down and release the lid.
Open the cover and connect the USB memory device.

Turn on the power of the USB memory device if it is not turned on.

■

Portable audio player

Press down and release the lid.
Open the cover and connect the portable audio player.

Turn on the power of the portable audio player if it is not turned on.

Connect an iPod, USB memory device or portable audio player to the AUX
port/USB port as indicated below. Press the “CD•AUX” button to select
“iPod”, “USB” or “AUX”.

Connecting using the AUX port/USB port

260

5-1. Basic Operations

WARNING

■

While driving
Do not connect a device or operate the device controls.

261

5-2. Using the audio system

Audio system

Optimal use of the audio system

Displays the current mode
Changes the following settings:

• Sound quality and volume bal-

ance
P. 261

The sound quality and balance set-

ting can be changed to produce the

best sound.

• Automatic Sound Levelizer on/off

P. 262

■

Changing sound quality modes
Press the “TUNE•SEL” knob.
Pressing the knob changes sound modes in the following order:
“BAS”

 “MID”  “TRE”  “FAD”  “BAL”  “ASL”

■

Adjusting sound quality
Turning the “TUNE•SEL” knob adjusts the level.

: The sound quality level is adjusted individually in each audio mode.

The sound quality, volume balance and ASL settings can be adjusted.

Adjusting sound quality and volume balance

Mode

displayed

Sound

quality mode

Level

Turn counter-

clockwise

Turn

clockwise

“BAS”

Bass

-5 to 5

Low

High

“MID”

Mid-range

-5 to 5

“TRE”

Treble

-5 to 5

“FAD”

Front/rear

volume

balance

F7 to R7

Shifts to rear

Shifts to front

“BAL”

Left/right

volume

balance

L7 to R7

Shifts to left

Shifts to right

262

5-2. Using the audio system

Turning the “TUNE•SEL” knob clockwise turns on the ASL, and turning the
“TUNE•SEL” knob counterclockwise turns off the ASL.

ASL automatically adjusts the volume and tone quality according to the noise level as

you drive your vehicle.

Turning the Automatic Sound Levelizer (ASL) on/off

263

5-3. Using the radio

Audio system

Radio operation

Search for the desired stations by turning the “TUNE•SEL” knob or pressing
“

”or “” on the “SEEK•TRACK” button.

Press and hold the button (from

the

“1” button to the “6” button) the station is to

be set to until you hear a beep.

Press the “AM•SAT”, “FM1” or “FM2” button to begin listening to the radio.

Control panel

Displaying text message
Station selector
Scanning for receivable stations
“TUNE•SEL” knob
Adjusting the frequency
Changing the program type

Seeking the frequency
AM•SAT/FM mode buttons
Power/volume knob

Press: Turning the audio system on or

off
Turn: Adjusting the volume

Setting station presets (excluding XM

Satellite Radio)

2
3
4

6
7
8

264

5-3. Using the radio

■

Scanning the preset radio stations

Press and hold the “SCAN” button until you hear a beep.
When the desired station is reached, press the button again.

■

Scanning all the radio stations within range

Press the “SCAN” button.

All the stations with reception will be played for 5 seconds each.

When the desired station is reached, press the button again.

This feature allows your radio to receive station identification information and
program information (classical, jazz, etc.) from radio stations which broadcast
this information.

■

Receiving RDS broadcasts

Press “

”or “” on the “TYPE•FOLDER” button during FM reception.

The type of program changes each time the button is pressed.
●

“ROCK”

●

“EASYLIS” (Easy listening)

●

“CLS/JAZZ” (Classical music and Jazz)

●

“R & B” (Rhythm and Blues)

●

“INFORM” (Information)

●

“RELIGION”

●

“MISC” (Miscellaneous)

●

“ALERT” (Emergency messages)

If the system receives no RDS stations, “NO PTY” appears on the display.

Press the “SCAN” button, or “

”or “” on the “SEEK•TRACK” button.

The radio seeks or scans for stations of the relevant program type.

■

Displaying radio station names
Press the “TEXT” button.

■

Displaying radio text messages
Press the “TEXT” button twice.
A text message is displayed when “MSG” is shown on the screen.

If the text continues past the end of the display,

is displayed. Press and hold the

button until you hear a beep.

Scanning radio stations (excluding XM

Satellite Radio)

RDS (Radio Data System)

265

5-3. Using the radio

Audio system

■

Receiving XM

Satellite Radio

Press the “AM•SAT” button.
The display changes as follows each time the button is pressed.
“AM”

“SAT1” “SAT2” “SAT3”

Turn the “TUNE•SEL” knob to select the desired channel in all the catego-
ries or press “

”or “” on the “SEEK•TRACK” button to select the desired

channel in the current category.

■

Setting XM

Satellite Radio channel presets

Select the desired channel. Press and hold the button (from the “1” button to
the “6” button) the channel is to be set to until you hear a beep.

■

Changing the channel category
Press “

”or “” on the “TYPE•FOLDER” button.

■

Scanning the XM

Satellite Radio channels

●

Scanning the channels in the current category

Press the “SCAN” button.
When the desired channel is reached, press the button again.

●

Scanning the preset channels

Press and hold the “SCAN” button until you hear a beep.
When the desired channel is reached, press the button again.

■

Displaying text information
Press the “TEXT” button.

The display will show up to 10 characters.
The display changes as follows each time the button is pressed:

●

CH NAME

●

TITLE (SONG/PROGRAM TITLE)

●

NAME (ARTIST NAME/FEATURE)

●

CH NUMBER

Satellite Radio

266

5-3. Using the radio

■

When the 12-volt battery is disconnected
All preset stations are erased.

■

Reception sensitivity

●

Cargo loaded on the roof luggage carrier, especially metal objects, may adversely

affect the reception of XM

Satellite Radio.

●

Maintaining perfect radio reception at all times is difficult due to the continually chang-

ing position of the antenna, differences in signal strength and surrounding objects, such

as trains, transmitters, etc.

●

When the “SCAN” button is used, automatic station selection may not be possible.

●

The radio antenna is mounted inside the rear window. To maintain clear radio reception,

do not attach metallic window tinting or other metallic objects to the antenna wire

mounted inside the rear window.

■

Receiving XM

Satellite Radio

An XM

Satellite Radio is a tuner designed exclusively to receive broadcasts provided

under a separate subscription. Availability is limited to the 48 contiguous states and 10

Canadian provinces.

●

subscriptions

For detailed information about XM

Satellite Radio or to subscribe:

U.S.A.



Visit on the web at www.siriusxm.com or call 1-877-447-0011.

Canada



Visit on the web at www.siriusxm.ca or call 1-877-438-9677.

●

Radio ID

You will need the radio ID when activating XM

service or reporting a problem. Select

“CH000” using the “TUNE•SEL” knob, and the receiver’s 8-character ID number will

appear.

●

Satellite tuner

The tuner supports only Audio Services (Music and Talk) and the accompanying Text
Information of XM

Satellite Radio.

●

Infotainment and Data services

XM offers a variety of advanced Infotainment and data services.

Content .. 14 15 16 17 ..
