Lexus ES300 (2002 year). Manual - part 260

020WZ-01

-

PREPARATION

EXHAUST

02-15

58

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

EXHAUST

PREPARATION

Equipment

Torque wrench

020X0-01

02-16

-

PREPARATION

COOLING

59

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

COOLING

PREPARATION

SST

09213-54015

Crankshaft Pulley Holding Tool

WATER PUMP ASSY

(91651-60855)

Bolt

WATER PUMP ASSY

09249-63010

Torque Wrench Adaptor

WATER PUMP ASSY

09330-00021

Companion Flange Holding Tool

WATER PUMP ASSY

09950-50013

Puller C Set

WATER PUMP ASSY

(09951-05010)

Hanger 150

WATER PUMP ASSY

(09952-05010)

Slide Arm

WATER PUMP ASSY

(09953-05010)

Center Bolt 100

WATER PUMP ASSY

(09954-05030)

Claw No.3

WATER PUMP ASSY

09960-10010

Variable Pin Wrench Set

WATER PUMP ASSY

(09962-01000)

Variable Pin Wrench Arm Assy

WATER PUMP ASSY

(09963-01000)

Pin 10

WATER PUMP ASSY

-

PREPARATION

COOLING

02-17

60

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

(09962-01000)

Variable Pin Wrench Arm Assy

WATER PUMP ASSY

(09963-01000)

Pin 10

WATER PUMP ASSY

Recomended Tools

09216-00021

Belt Tension  Gauge

WATER PUMP ASSY

Equipment

Ohmmeter

Radiator cap tester

Thermomete

Torque wrench

Vernier calipers

Heater

SSM

08826-00080

Seal Packing Black or equivalent

(FIPG)

WATER PUMP ASSY

020X1-01

02-18

-

PREPARATION

LUBRICATION

61

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

LUBRICATION

PREPARATION

SST

09032-00100

Oil Pan Seal Cutter

OIL PUMP ASSY

09213-54015

Crankshaft Pulley Holding Tool

OIL PUMP ASSY

(91651-60855)

Bolt

OIL PUMP ASSY

09223-00010

Cover & Seal Replacer

OIL PUMP ASSY

09228-07501

Oil Filter Wrench

OIL FILTER  SUB-ASSY

09249-63010

Torque Wrench Adaptor

OIL PUMP ASSY

09330-00021

Companion Flange Holding Tool

OIL PUMP ASSY

09950-50013

Puller C Set

OIL PUMP ASSY

(09951-05010)

Hanger 150

OIL PUMP ASSY

(09952-05010)

Slide Arm

OIL PUMP ASSY

(09953-05010)

Center Bolt 100

OIL PUMP ASSY

(09953-05020)

Center Bolt 150

OIL PUMP ASSY
