PREPARATION

LUBRICATION

02-19

62

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

(09954-05010)

Claw No.1

OIL PUMP ASSY

(09954-05030)

Claw No.3

OIL PUMP ASSY

09960-10010

Variable Pin Wrench Set

OIL PUMP ASSY

(09962-01000)

Variable Pin Wrench Arm Assy

OIL PUMP ASSY

(09963-01000)

Pin 10

OIL PUMP ASSY

Recomended Tools

09040-0001 1

Hexagon Wrench Set

OIL PUMP ASSY

(09043-20100)

Socket Hexagon Wrench 10

OIL PUMP ASSY

09216-00021

Belt Tension Gauge

OIL PUMP ASSY

Equipment

Feeler gauge

Precision straight edge

Torque wrench

SSM

08826-00080

Seal Packing Black or equivalent

(FIPG)

OIL PUMP ASSY

020X2-01

02-20

-

PREPARATION

IGNITION

63

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

IGNITION

PREPARATION

Recomended Tools

09200-00010

Engine Adjust Kit .

IGNITION SYSTEM

(09857-00031)

Spark Plug Gap Gauge

IGNITION SYSTEM

Equipment

Spark plug cleaner

Torque wrench

020X3-01

-

PREPARATION

STARTING & CHARGING

02-21

64

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

STARTING & CHARGING

PREPARATION

SST

09820-63010

Alternator Pulley Set Nut Wrench

Set

GENERATOR ASSY

(09820-06010)

Alternator Rotor Shaft Wrench

GENERATOR ASSY

(09820-06020)

Alternator Pulley Set Nut 22 mm

Wrench

GENERATOR ASSY

Recomended Tools

(09083-00150)

Test Lead Set

STARTING SYSTEM

GENERATOR ASSY

STARTER ASSY

09216-00021

Belt Tension Gauge

GENERATOR ASSY

09904-00010

Expander Set

STARTER ASSY

(09904-00050)

No. 4 Claw

STARTER ASSY

Equipment

Service Wire Harness

Dial indicator

Dial indicator with magnetic base

Ammmeter(A)

Ohmmeter

Torque wrench

Vernier calipers

V-block

Press

020WD-01

02-22

-

PREPARATION

SUSPENSION CONTROL SYSTEM

65

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

SUSPENSION CONTROL SYSTEM

PREPARATION

Equipment

Torque wrench
