TABLE OF HOUSING CROSS SECTION

C–11

74

Wire Harness Repair Manual (RM1022E)

Type

: Position of the lance
: Direction of lock released
: Direction of the special tool inserted

Male

Female

SFPC

[Housing Lance]

SL

[Terminal Lance]

SP

[Housing Lance]

TLC

Non–
waterproof
Type

(Double Lock Type)

[Housing Lance]

(Double Lock Type)

[Housing Lance]

C–12

TABLE OF HOUSING CROSS SECTION

Wire Harness Repair Manual (RM1022E)

75

Type

: Position of the lance
: Direction of lock released
: Direction of the special tool inserted

Male

Female

TLC

Waterproof
Type

[Housing Lance]

[Housing Lance]

TNS

(Double Lock Type)

[Housing Lance]

(Double Lock Type)

[Housing Lance]

TODC

[Housing Lance]

(Double Lock Type)

[Housing Lance]

B–3

TERMINAL AND CONNECTOR REPAIR–TERMINAL REPLACEMENT

13

Wire Harness Repair Manual (RM1022E)

TERMINAL REPLACEMENT

These steps must be followed when replacing a terminal.

Step 1. Identify the connector and the terminal type.

Step 2. Disconnect the terminal from the connector.

Step 3. Replace the terminal.

Step 4. Install the terminal into the connector.

B

F–15

TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

Wire Harness Repair Manual (RM1022E)

411

Terminal Packing

Type

6.3

Cav.

No.

1

3

P/N

90980–09210

90980–09211

Type

7.7

Cav.

No.

1

P/N

90980–09380

Type

TODC

Cav.

No.

1

3

P/N

90980–09378

90980–09379
