TABLE OF HOUSING CROSS SECTION
C–3
66
Wire Harness Repair Manual (RM1022E)
Type
: Position of the lance
: Direction of lock released
: Direction of the special tool inserted
Male
Female
1.3
Non–
waterproof
Type
(Double Lock Type)
[Housing Lance]
(Double Lock Type)
[Housing Lance]
1.3
Non–
waterproof
Type
(Double Lock Type)
[Housing Lance]
(Double Lock Type)
[Housing Lance]
1.3
Non–
waterproof
Type
(Double Lock Type)
[Housing Lance]
1.3
Waterproof
Type
90980–11188
(Double Lock Type)
[Housing Lance]
90980–11189
(Double Lock Type)
[Housing Lance]
C
