TABLE OF REPAIR WIRE, TERMINAL PACKING, HOLE PLUG AND PRESS SLEEVE

F–16

412

Wire Harness Repair Manual (RM1022E)

Terminal Packing

Type

2.3

Cav.

No.

1

P/N

90980–09148, 09151, 09149

Type

2.3II

Cav.

No.

1

P/N

90980–09451

Type

HB3, HB4

Cav.

No.

1

P/N

90980–09396

G–1

APPENDIX–WIRE HARNESS REPAIR KIT WITH CASE

Wire Harness Repair Manual (RM1022E)

397

WIRE HARNESS REPAIR KIT WITH CASE (REFERENCE ONLY)

We would like to recommend to you use of the ”Wire Harness Repair Kit with the Case”
according to your after service market demand.

Example:

or

[portable type]

[stationary type]

Remark:

This kind of kit is not available from Toyota Motor Corporation.

G

0305S-01

4

5

6

7

8

9

10

11

B06431

Bolt Type

Hexagon Head Bolt

Normal Recess Bolt

Deep Recess Bolt

Stud Bolt

Weld Bolt

Class

4T

5T

6T

7T

8T

9T

10T

11T

No Mark

w/ Washer

No Mark

No Mark

w/ Washer

-

SERVICE SPECIFICATIONS

STANDARD BOLT

03-1

102

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

STANDARD BOLT

HOW TO DETERMINE BOLT STRENGTH

030GY-01

03-10

-

SERVICE SPECIFICATIONS

INTAKE

111

2002 LEXUS ES300 REPAIR MANUAL   (RM911U)

TORQUE SPECIFICATION

Part Tightened

N

⋅

m

kgf

⋅

cm

ft

⋅

lbf

Intake air control valve assy x Intake air surge tank

21

214

15

Surge tank stay No. 2 x Throttle body assy

20

199

14

Front suspension upper brace center x Body

80

816

59

Intake air control valve assy No. 2 x Intake air surge tank

10

102

7.4
