Lexus ES300 (2002 year). Manual - part 102

MO-3

NEW MODEL OUTLINE

Rear View

211IN02

MO-36

NEW MODEL OUTLINE

MODEL CODE

MCV30

L – B E A G K A

1

2

3

4

5

6

7

8

1

BASIC MODEL CODE

1

MCV30 :  With 1MZ-FE Engine

2

STEERING WHEEL POSITION

2

L :  Left-Hand Drive

3

MODEL NAME

3

B :  ES300

4

BODY TYPE

4

E :  4-Door Sedan

5

GEAR SHIFT TYPE

5

A :  5-Speed Automatic, Floor

6

GRADE

6

G :  —

7

ENGINE SPECIFICATION

7

K :  DOHC and SFI

8

DESTINATION

8

A : U.S.A. and Canada

MODEL LINE-UP

Destination

Engine

Body Type

Grade

Transaxle

Destination

Engine

Body Type

Grade

U150E 5-Speed Automatic

U.S.A. and Canada

1MZ-FE

4-Door Sedan

–

MCV30L - BEAGKA

MO-8

211MO07

211MO11

211MO12

Cruise Control Switch

Leather (Standard)

Wood & Leather (Option)

Steering Wheel Pad Switch

NEW MODEL OUTLINE

INTERIOR

The sophisticated feel of the interior, with its roomy cabin space,
is permeated with sense of intelligence.

Interior Design

The instrument panel evokes a sense of elegance, with a modern, deep red-toned
wood grain and chrome treatment decoration.

Lustrous wood grain and the auto-
matic transmission gate housing with
metallic paint impart sophistication
and sportiness.

The instrument panel, door trim,
seats, and console exude sophistica-
tion and excellence with their
rounded surfaces.

Each function is fitted cleanly into
the layout with regard to the appear-
ance of the overall design.

The amount of height offset has been
minimized at the center cluster, regis-
ter, instrument panel pads, etc., to
achieve high quality.

Steering Wheel

The three-spoke steering wheel exudes a sense of fine quality.

Two choices are available: a
sporty leather-covered type or a
stylish type with a combination of
wood and leather.

The metal core is solid die-cast
magnesium, achieving weight
reduction with regard for greater
operationality.

A steering wheel pad switch and
cruise control switch are built into
the steering wheel to enable
operation of the multi-information
display and cruise control system,
thereby improving operability
while driving.

MO-9

211MO09

Multi-Information Display

U.S.A. Models

(1)

(2)

(3)

211MO10

NEW MODEL OUTLINE

Roominess

Packaging with capacious seating space that comfortably accommodates four adults.

The head clearance in both front and back is spacious. Also, the distance between the
front and rear seats and between the driver and passenger seats has been widened, ensuring
greater room.

The hip point has been raised, with the aim of making getting in and out easier.

211MO08

Comparison of ’01 ES300

mm (in.)

+2.5
(+0.1)

+40
(+1.6)

+20 (+0.8)

+10 (+0.4)

+25
(+1.0)

+20
(+0.8)

+45 (+1.8)

+40 (+1.6)

+20 (+0.8)

+20 (+0.8)

Combination Meter

Three separate Optitron sections with excellent visibility and functionality.

A sporty, elegant design with wood grain. Visi-
bility is excellent due to the luminous dial and
pointer.

The multi-information display is located in the
center speedometer for high visibility. The fol-
lowing modes can be selected using the MODE
switch on the steering wheel pad switch.

(1) Instant fuel consumption
(2) Average fuel consumption
(3) Drivable distance
(4) Average speed
(5) Elapsed time

It can be reset using the RESET switch on the steering wheel pad switch.

Console Box

A large capacity, multi-functional,
easy-to-use console box that is the
optimum height when used as an
arm rest.

A 2-tier console box has been
adopted with the following features:

(1) DC 12V power outlet
(2) Cup holder
(3) Illuminate light
