MO-31

NEW MODEL OUTLINE

ENVIRONMENT

With the future of both humanity and the earth firmly in mind,
special attention has been paid to environmental conservation.

TSOP & Kenaf Material

TSOP (The Super Olefin Polymer) and TPO (Thermoplastic Olefin), both materials offering
excellent recyclability, have been extensively used throughout the vehicle as an environmental
protection measure.

211MO63

: TSOP Material

*TSOP material:

This material is easy to recycle; because its relative density is low, a reduction in weight is possible.
It is utilized as a substitute for PP (polypropylene).

Kenaf* material, with similar quality to wood pulp, has been utilized as the core material
for the package tray trim in an effort to protect the earth’s forests.

*Kenaf material:

This material, which uses the fiber of 1-year old Kenaf grass as its raw material, is receiving acclaim
as it can be used in place of wood pulp. If this material were to be widely used in place of pulp,
it would contribute to the protection of the world’s forests.

MO-32

211MO81

Amount of Lead Used

’02 ES300

The average amount
of lead used in 1996

1/3

NEW MODEL OUTLINE

PVC-Free Parts

PVC (PolyVinyl Chloride), which contains chlorine, is said to be a cause of the environmental
pollutant dioxin. The use of PVC in the following parts has been discontinued.

PVC-Free Parts:

Sound insulating under body coating

Dash silencer pad

Floor tunnel silencer

Room partition board

Door opening trim

Door glass run

Door outside molding

Rear wheel house liner

Moon roof drain hose (front side)

Reduction in the Amount of Lead Used

To help protect the environment, the
amount of lead used has been reduced
and through development of lead-free
parts has been implemented.
The amount of lead used in one ES300
has been reduced to about one-third of
the average amount of lead used in 1996.

Main lead-free parts:

Body paint (electrodeposited coating)

Window glass ceramic sunshade

Bulbs

Front axle hub

Heater core

Main parts with reduced lead:

Wheel Balance Weight

MO-16

211MO69

211MO42

211MO70

Figure for Mark Levinson Version

NEW MODEL OUTLINE

Audio System

Realistic, refined sound that transports you into your own personal
space.

A clean, symmetrical head unit layout has been achieved through the adoption of large,
easy-to-use switches.

The LEXUS Premium Sound System with a power amplifier (max. 440W) and speakers
from Mark Levinson, famous for products in the high end of the home audio market, is
available as an option.

<Head Unit Specification>

Design

Specification

Application

AM/FM tuner

Cassette player

CD Player with CD Text function

RDS (Radio Date System) with
RT (Radio Text) function

Separate Power Amplifier and
7-speaker System (Mark Levinson
version available)

Option

AM/FM tuner

Cassette player

In-dash- 6-CD Changer

ASL (Automatic Sound Levelizer)
with ON/OFF selection possible

RDS (Radio Date System) with
RT (Radio Text) function

Separate Power Amplifier and
7-speaker System (Mark Levinson
version available)

Option

AM/FM tuner

Cassette player

CD Player

ASL (Automatic Sound Levelizer)
with ON/OFF selection possible

Separate Power Amplifier and
7-speaker System

Standard

MO-17

NEW MODEL OUTLINE

<Speaker Layout>

211MO25

Figure for Mark Levinson Version

Front Door Full Range

Tweeter

Sub Woofer

Rear Door Full Range

<Speaker Specifications>

Manufactured by Mark Levinson (Option)

Manufactured by Pioneer (Standard)

Caliber (in.)

Impedance

Input Rating

Caliber (in.)

Impedance

Input Rating

Tweeter

20 mm (0.8)

Ω

55 W

or more

25 mm (1.0)

Ω

17.5 W

Front Full

Range

16 cm (6.3)

Ω

55 W

or more

16 cm (6.3)

Ω

17.5 W

Rear Full

Range

12 cm (4.7)

Ω

55 W

or more

16 cm (6.3)

Ω

17.5 W

Sub Woofer

20 cm (7.9)

Ω

110 W

or more

20 cm (7.9)

Ω

30 W
