Lexus ES300 (2002 year). Manual - part 97

MO-26

211MO60

The TRAC, VSC and ABS system
work cooperatively to bring the
vehicle back into ordinary traveling
conditions.

Deceleration

Turning

Turning

Acceleration

Physical
Limit

NEW MODEL OUTLINE

SAFETY

Safety has been thoroughly pursued from every angle.
No opportunity has been overlooked to consider the safety of
the passengers.

Active Safety

ABS

 (Anti-lock Brake System)

With EBD

 (Electronic Brake force Distribution)

The ABS system helps to prevent the
tires from locking up, thereby ensur-
ing vehicle performance and handling
ability.
The EBD system distributes optimal
breaking force to the front and rear
tires in accordance with driving condi-
tions. Furthermore, braking force is
distributed to the left and right wheels
during braking when cornering to en-
sure vehicle performance and superior
braking power.

Item

Application

ABS w/EBD

Standard

ABS w/EBD, VSC, TRAC, Brake Assist

Option

Brake Assist

This system works in conjunction with the
ABS to support drivers who are unable to apply
the brakes fully during emergency braking and
for drivers who tend to apply the brakes too
lightly. When the brakes are applied rapidly,
it is judged by the computer to be emergency
braking and additional braking power is gener-
ated automatically by the system to ensure suf-
ficient vehicle braking power.

TRAC (Traction Control)

VSC (Vehicle Skid Control)

In addition to controlling driving wheel
slip on slippery road surfaces to help en-
sure driving force suited to road surface
conditions, this system maintains acceler-
ating ability at takeoff, forward mobility
and turning performance.

This system controls engine output and
directly applies optimal breaking force to
the front and rear wheels to help maintain
intended vehicle directional control if it
is about to be lost while cornering due
to over- or under-steering.

MO-4

211MO39

NEW MODEL OUTLINE

CONCEPT

A high-class car that sets the world standard for
the new century.
Embodying the essence of an emotional and
elegant sedan . . . the LEXUS ES300.
Debuting with a myriad of innovations that
contribute to increased value.

Everything a leading world-class car should be . . .

Harmonizing attractively with your lifestyle and community, the

stately appearance of the LEXUS ES300 has evolved and

matured.

Dynamic, flowing surfaces define the form, and the

sophisticated interior evokes a sense of intelligence.

Add to that powerfully elegant handling and safety features that

brook no compromise.

The ES300’s overall polish and refinement inspire overwhelming

satisfaction in every owner.

MO-5

1

2

3

4

5

6

FEATURE2

INTERIOR

FEATURE3

PERFORMANCE

FEATURE4

EQUIPMENT

FEATURE5

SAFETY

FEATURE6

ENVIRONMENT

Form that captivates with dynamic
flowing surfaces.

The sophisticated feel of the interior,
with its roomy cabin space, is permeated
with sense of intelligence.

Powerful, smooth driving with
consideration for the environment.

Driving performance with polish and
distinction.

The joy of cruising has been heightened
with delightful features installed at every
turn.

Safety has been thoroughly pursued from
every angle.

No opportunity has been overlooked to
consider the safety of the passengers.

With the future of both humanity and the
earth firmly in mind, special attention has
been paid to environmental conservation.

FEATURE1

EXTERIOR

NEW MODEL OUTLINE

LEXUS ES300: Crystallization of evolution & maturation

Six features that offer ultimate satisfaction

MO-33

NEW MODEL OUTLINE

DIMENSIONS

211MO33

2720 mm (107.1 in.)

4855 mm (191.1 in.)

1455 mm (57.3 in.)

1810 mm (71.3 in.)

Front: 1545 mm (60.8 in.)
Rear: 1535 mm (60.4 in.)

1140 mm (44.9 in.)

995 mm (39.2 in.)

910 mm

(35.8 in.)
