PP0BL–01

–

PREPARATION

SUPPLEMENTAL RESTRAINT SYSTEM

PP–53

98

1997 LEXUS ES300   (RM511U)

EQUIPMENT

Torque wrench

Bolt: Length: 35 mm (1.38 in.) Pitch: 1.0 mm (0.039 in.)

Diam: 6.0 mm (0.236 in.)

Airbag disposal

Tire Width: 185 mm (7.28 in.) Inner diam: 360 mm (14.17 in.)

Airbag disposal

Tire with disc wheel Width: 185 mm (7.28 in.)

Inner diam: 360 mm (14.17 in.)

Airbag disposal

Vinyl bag

Airbag disposal

PP0B2–01

PP–54

–

PREPARATION

BODY ELECTRICAL

99

1997 LEXUS ES300   (RM511U)

BODY ELECTRICAL

SST (Special Service Tools)

09843–18020

Diagnosis Check Wire

PP0B3–01

–

PREPARATION

BODY ELECTRICAL

PP–55

100

1997 LEXUS ES300   (RM511U)

RECOMMENDED TOOLS

09082–00040

TOYOTA Electrical Tester.

09041–00030

Torx Driver T30 .

For removing and installing

steering wheel pad

09042–00010

Torx Socket T30 .

For removing and installing

steering wheel pad

PP0B4–01

PP–56

–

PREPARATION

BODY ELECTRICAL

101

1997 LEXUS ES300   (RM511U)

EQUIPMENT

Voltmeter

Ammeter

Ohmmeter

Test lead

Thermometer

Engine oil level warning switch, Seat heater

Syphon

Brake fluid level warning switch

Oil bath

Engine oil level warning switch

Bulb (3 W)

Fuel sender gauge

Bulb (3.4 W)

Seat belt warning relay

Bulb (21 W)

Turn signal flasher relay

Dry cell battery

Fuel sender gauge

Heat light

Seat heater

Torque wrench

Masking tape

Rear window defogger wire

Tin foil

Rear window defogger wire
