PP2XJ–01

–

PREPARATION

BODY ELECTRICAL

PP–57

102

1997 LEXUS ES300   (RM511U)

SSM (Special Service Materials)

08888–88888

DuPont Paste No. 4817  or

equivalent

Rear window defogger

PP0AX–03

PP–58

–

PREPARATION

BODY

103

1997 LEXUS ES300   (RM511U)

BODY

SST (Special Service Tools)

09082–00700

SRS Airbag Deployment Tool

09082–00740

Airbag Deployment Wire

Sub–harness No.2

09804–24010

Luggage Compartment Door Torsion

Bar Tool

09812–00010

Door Hinge Set Bolt Wrench

PP0AY–03

–

PREPARATION

BODY

PP–59

104

1997 LEXUS ES300   (RM511U)

RECOMMENDED TOOLS

09070–20010

Moulding Remover .

PP0AZ–10

PP–60

–

PREPARATION

BODY

105

1997 LEXUS ES300   (RM511U)

EQUIPMENT

Clip remover

Torque wrench

Hexagon wrench (6 mm)

Torx driver

Hog ring pliers

Hand riveter

Tape

To avoid surface damage

Adhesive tape

To avoid surface damage

Double–stick tape

Adhesive

Cleaner

Shop rag

Knife

Sealer gun

Brush

Putty spatula

Glass plate or similar object

Wooden block or similar object

Heat light

Piano wire

Rope (no projections, difficult to break)

Seat belt pretensioner

Tire Width: 185 mm (7.28 in.) Inner diam: 360 mm (14.17 in.)

Seat belt pretensioner

Tire with wheel   Width: 185 mm (7.28 in.)

Inner diam: 360 mm (14.17 in.)

Seat belt pretensioner

Vinyl bag

Seat belt pretensioner
